MAXXFAN®2-SWITCH WALL CONTROL
MODEL SERIES 02000K INSTALLATION & OPERATION GUIDE
For use with MAXXFAN®Plus Models 4500K through 4801K
For use with MAXXFAN®Deluxe Models 7000K through 8501K
WALL CONTROL FEATURES
• Allows fan control from convenient
wall location
• Turns fan ON or OFF
• Selects Low, Medium or High
Speeds
• OPENS or CLOSES Vent Lid
• Easy access to Ceiling Fan Mode
• Keypad controls at ceiling remain
active
CONTROL DESCRIPTION
FAN 1-2-3
Turns the fan motor ON at
the last selected speed and
OPENS the Vent Lid.
When Fan is running, select LOW,
MEDIUM or HIGH Speed. Once
HIGH Speed is reached, the fan
motor cycles back to LOW Speed.
FAN OFF Turns the Fan Motor OFF and CLOSES the Vent Lid
VENT OPEN OPENS the Vent Lid Fan motor remains in previous
state
VENT CLOSED CLOSES the Vent Lid
Fan motor remains in previous
state. If fan motor is ON, the
MAXXFAN enters Ceiling Fan
Mode
1980-081
08-2016
For additional product information please visit www.AIRXCEL.com
AIRXCEL, INC. - RV Products Division / MAXXAIR • 3050 N. St. Francis St. • Wichita, KS 67219 • 316-832-3400 ©2015 AIRXCEL, INC.

MAXXFAN®2-SWITCH WALL CONTROL
MODEL SERIES 02000K INSTALLATION INSTRUCTIONS
For use with MAXXFAN®Plus Models 4500K through 4801K
For use with MAXXFAN®Deluxe Models 7000K through 8501K
STEP 1
Cut a 1 5/8” x 2 7/16” rectangular hole
in the wall where you wish to mount the
2-Switch Wall Control.
STEP 2A
Plug one end of RJ-11 cable into GRAY
RJ-11 jack ( ) on MAXXFAN PCB (at
ceiling). Do not use the Black RJ-11 Jack ( ).
STEP 2B
Route RJ-11 cable
through wall to hole
cut in STEP 1.
STEP 3
Plug end of RJ-11 cable into RJ-11 jack
on 2-Switch Wall Control PCB. Note
arrow & ’Up’ marking on PCB for proper
orientation. (Either RJ-11 ( ) jack may be used,
they are identical)
STEP 4
Attach the Wall
Control to wall
with appropriate
screws for wall
construction.
STEP 5
Snap Bezelonto
Wall Control.
The black RJ-11 jack is for other controls
