Ver 1.0 2004. 01
Model Name Using Similar Mechanism CDX-R3300/R3300T
CD Drive Mechanism Type MG-611MA-186//Q
Optical Pick-up Name KSS1000E
SERVICE MANUAL
US Model
Canadian Model
CDC-X504MP
AEP Model
UK Model
CDC-R504MP/X504MP
CDC-R504MP/X504MP
AUDIO POWER SPECIFICATIONS (US MODEL)
POWER OUTPUTAND TOTAL HARMONIC DISTORTION
23.2 watts per channel minimum continuous average power into
4 ohms, 4 channels driven from 20 Hz to 20 kHz with no more
than 5% total harmonic distortion.
Tuner section
FM
Tuning range US, Canadian Model:
87.5 – 107.9 MHz
AEP, UK Model:
87.5 – 108 MHz
Antenna terminal External antenna connector
Intermediate frequency 10.7 MHz/450 kHz
Usable sensitivity 9 dBf
Selectivity 75 dB at 400 kHz
Signal-to-noise ratio 67 dB (stereo),
69 dB (mono)
Harmonic distortion at 1 kHz
0.5% (stereo),
0.3% (mono)
Separation 35 dB at 1 kHz
Frequency response 30 – 15,000 Hz
AM (US, Canadian Model)
Tuning range 530 – 1,710 kHz
Antenna terminal External antenna connector
Intermediate frequency 10.7 MHz/450 kHz
Sensitivity 30 µV
MW/LW (AEP, UK Model)
Tuning range MW: 531 – 1,602 kHz
LW: 153 – 279 kHz
Antenna terminal External antenna connector
Intermediate frequency 10.7 MHz/450 kHz
Sensitivity MW: 30 µV
LW: 40 µV
CD player section
Signal-to-noise ratio 120 dB
Frequency response 10 – 20,000 Hz
Wow and flutter Below measurable limit
SPECIFICATIONS
Power amplifier section
Outputs Speaker outputs
(sure seal connectors)
Speaker impedance 4 – 8 ohms
Maximum power output 52 W ×4 (at 4 ohms)
General
Outputs Audio outputs terminal (rear/sub switchable)
Power antenna relay control terminal
Power amplifier control terminal
Inputs Telephone ATT control terminal (AEP, UK Model)
Antenna input terminal
Tone controls Low: ±10 dB at 60 Hz (HIP-HOP)
Mid: ±10 dB at 1 kHz (HIP-HOP)
High: ±10 dB at 10 kHz (HIP-HOP)
Power requirements 12V DC car battery (negative ground)
Dimensions Approx. 178 ×50 ×176 mm
(7 1/8 ×2 ×7 in.) (w/h/d)
Mounting dimensions Approx. 182 ×53 ×161 mm
(7 1/4 ×2 1/8 ×6 3/8 in.) (w/h/d)
Mass Approx. 1.2 kg (2 lb. 10 oz.)
Supplied accessories Parts for installation and connections (1 set)
Front panel case (1)
Card remote control RM-Z304
Design and specifications are subject to change without
notice.
• The tuner and CD sections have no adjustments.
Sony Corporation
e Vehicle Company
Published by Sony Engineering Corporation
9-877-518-01
2004A04-1
© 2004. 01
Photo: CDC-X504MP
FM/AM COMPACT DISC PLAYER
US, Canadian model
FM/MW/LW COMPACT DISC PLAYER
AEP, UK model

2
CDC-R504MP/X504MP
If the optical pick-up block is defective, please replace the whole
optical pick-up block.
Never turn the semi-fixed resistor located at the side of optical
pick-up block.
CAUTION
Use of controls or adjustments or performance of procedures
other than those specified herein may result in hazardous
radiation exposure.
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK 0OR DOTTED LINE
WITH MARK 0ON THE SCHEMATIC DIAGRAMS AND IN
THE PARTS LIST ARE CRITICAL TO SAFE OPERATION.
REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE
PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR
IN SUPPLEMENTS PUBLISHED BY SONY.
ATTENTION AU COMPOSANT AYANT RAPPORT
À LA SÉCURITÉ!!
LES COMPOSANTS IDENTIFIÉS PAR UNE MARQUE 0SUR LES
DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES PIÈCES
SONT CRITIQUES POUR LASÉCURITÉ DE FONCTIONNEMENT.
NE REMPLACER CES COMPOSANTS QUE PAR DES PIÈCES
SONY DONT LES NUMÉROS SONT DONNÉS DANS CE MANUEL
OU DANS LES SUPPLÉMENTS PUBLIÉS PAR SONY.
NOTES ON HANDLING THE OPTICAL PICK-UP BLOCK
OR BASE UNIT
The laser diode in the optical pick-up block may suffer electrostatic
breakdown because of the potential difference generated by the
charged electrostatic load, etc. on clothing and the human body.
During repair, pay attention to electrostatic breakdown and also use
the procedure in the printed matter which is included in the repair
parts.
The flexible board is easily damaged and should be handled with
care.
NOTES ON LASER DIODE EMISSION CHECK
The laser beam on this model is concentrated so as to be focused on
the disc reflective surface by the objective lens in the optical pick-
up block. Therefore, when checking the laser diode emission, ob-
serve from more than 30 cm away from the objective lens.
Notes on Chip Component Replacement
•Never reuse a disconnected chip component.
•Notice that the minus side of a tantalum capacitor may be dam-
aged by heat.
TEST DISCS
This set can playback CD-R and CD-ROM discs. The following
test discs should be used to check the capability:
CD-R test disc TCD-R082LMT (Part No. J-2502-063-1)
CD-RW test disc TCD-W082L (Part No. J-2502-063-2)
SERVICE NOTES
optical pick-up
semi-fixed resistor
• US, Canadian model
• AEP, UK model
CAUTION
Use of controls or adjustments or performance of procedures other
than those specified herein may result in hazardous radiation
exposure.
This compact disc player is classified as a CLASS 1 LASER
product. The CLASS 1 LASER PRODUCT label is located on the
exterior.
This label is located on the bottom of the chassis.

3
CDC-R504MP/X504MP
Notes on CD-Rs (recordable CDs)/CD-RWs (rewritable
CDs)
This unit can play the following discs:
Type of discs Label on the disc
Audio CD
MP3 files
•Some CD-Rs/CD-RWs (depending on the equipment used for
its recording or the condition of the disc) may not play on this
unit.
•You cannot play a CD-R/CD-RW that is not finalized∗.
•You can play MP3 files recorded on CD-ROMs, CD-Rs, and
CD-RWs.
•A CD-R/CD-RW to which a session can be added can be played.
∗A process necessary for a recorded CD-R/CD-RW disc to be
played on the audio CD player.
EXTENSION CABLE AND SERVICE POSITION
Whenrepairingor servicingthisset, connectthejig (extensioncable)
as shown below.
•Connect the MAIN board (CN301) and the SERVO board (CN2)
with the extension cable (Part No. J-2502-076-1).
zUNLEADED SOLDER
Boards requiring use of unleaded solder are printed with the lead
free mark (LF) indicating the solder contains no lead.
(Caution: Some printed circuit boards may not come printed with
the lead free mark due to their particular size.)
: LEAD FREE MARK
Unleaded solder has the following characteristics.
• Unleaded solder melts at a temperature about 40°C higher than
ordinary solder.
Ordinary soldering irons can be used but the iron tip has to be
applied to the solder joint for a slightly longer time.
Soldering irons using a temperature regulator should be set to
about 350°C.
Caution: The printed pattern (copper foil) may peel away if the
heated tip is applied for too long, so be careful!
•Strong viscosity
Unleaded solder is more viscous (sticky, less prone to flow)
than ordinary solder so use caution not to let solder bridges
occur such as on IC pins, etc.
•Usable with ordinary solder
It is best to use only unleaded solder but unleaded solder may
also be added to ordinary solder.
SERVO BOAR
D
CN2
J-2502-076-1
MAIN BOARD
CN301

4
CDC-R504MP/X504MP
TABLE OF CONTENTS
1. GENERAL
Location of Controls................................................................ 5
Connections (US, Canadian Model)........................................ 6
Connections (AEP, UK Model) ............................................... 7
2. DISASSEMBLY
2-1. Sub Panel Assy .................................................................... 9
2-2. CD Mechanism Block ......................................................... 9
2-3. Main Board ....................................................................... 10
2-4. Chassis (T) Sub Assy ........................................................ 10
2-5. Roller Arm Assy ................................................................ 11
2-6. Chassis (OP) Assy ............................................................. 11
2-7. Optical Pick-up ................................................................. 12
2-8. SL MotorAssy (M902) ..................................................... 12
2-9. LE Motor Assy (M903) ..................................................... 13
2-10. Servo Board....................................................................... 13
3. DIAGRAMS
3-1. IC Pin Descriptions ........................................................... 14
3-2. Block Diagram –CD Section–........................................... 19
3-3. Block Diagram –Main Section–........................................ 20
3-4. Block Diagram –Display Section–.................................... 21
3-5. Circuit Boards Location .................................................... 21
3-6. Note for Printed Wiring Boards and
Schematic Diagrams .......................................................... 22
3-7. Waveforms......................................................................... 22
3-8. Printed Wiring Boards –CD Mechanism Section–............ 23
3-9. Schematic Diagram –CD Mechanism Section (1/2)– .......24
3-10. Schematic Diagram –CD Mechanism Section (2/2)– ....... 25
3-11. Schematic Diagram –Main Section (1/2)– ........................ 26
3-12. Schematic Diagram –Main Section (2/2)– ........................ 27
3-13. Printed Wiring Board –Main Section– .............................. 28
3-14. Printed Wiring Boards –Display Section– ........................ 29
3-15. Schematic Diagram –Display Section–............................. 30
3-16. IC Block Diagrams............................................................ 31
4. EXPLODED VIEWS
4-1. Main Section ..................................................................... 35
4-2. Front Panel Section ........................................................... 36
4-3. CD Mechanism Section (1) ...............................................37
4-4. CD Mechanism Section (2) ...............................................38
4-5. CD Mechanism Section (3) ...............................................39
4-6. CD Mechanism Section (4) ...............................................40
5. ELECTRICAL PARTS LIST ........................................ 41

5
CDC-R504MP/X504MP
SECTION 1
GENERAL This section is extracted
from instruction manual.
LOCATION OF CONTROLS

6
CDC-R504MP/X504MP
CONNECTIONS (US, Canadian Model)

7
CDC-R504MP/X504MP
CONNECTIONS (AEP, UK Model)

8
CDC-R504MP/X504MP SECTION 2
DISASSEMBLY
Note : This set can be disassemble according to the following sequence.
2-1. SUB PANEL ASSY
(Page 9)
2-2. CD MECHANISM BLOCK
(Page 9)
SET
2-3. MAIN BOARD
(Page 10) 2-4. CHASSIS (T) SUB ASSY
(Page 10)
2-5. ROLLER ARM ASSY
(Page 11)
2-6. CHASSIS (OP) ASSY
(Page 11)
2-8. SL MOTOR ASSY (M902)
(Page 12)
2-10. SERVO BOARD
(Page 13)
2-7. OPTICAL PICK-UP
(Page 12) 2-9. LE MOTOR ASSY (M903)
(Page 13)

9
CDC-R504MP/X504MP
2-2. CD MECHANISM BLOCK
Note : Follow the disassembly procedure in the numerical order given.
2-1. SUB PANEL ASSY
2 two claw
s
3 two claws
4 sub panel assy
1 two screws
(+PTT 2.6
x 6)
7 bracket (CD)
5 CD mechanism block
4 CN301
3
1 screw
(+PTT 2.6 x 6
)
2 screw
(+PTT 2.6 x 6)
6 two screws
(+PTT 2.6 x 4)

10
CDC-R504MP/X504MP
2-4. CHASSIS (T) SUB ASSY
2-3. MAIN BOARD
1 three ground point screws
(+PTT 2.6 x 6)
3 MAIN board
2 two screws
(+PTT 2.6
x 6
)
insulating sheet
5 SENSOR board
6 chassis (T) sub assy
4 claw
3 claw
1 two screws
(+P 1.7
x 2.2)
2 two screws
(+P 1.7
x 2.2)

11
CDC-R504MP/X504MP
2-5. ROLLER ARM ASSY
2-6. CHASSIS (OP) ASSY
3 washer (0.8-2.5)
4 worm wheel (RA)
5 roller arm assy
1 spring (RAL)
2 spring (RAR)
4 washer
0 coil spring (damper)
9 two coil springs (damper)
qa chassis (OP) assy
5 gear (LE1)
1 CN1
lever (D)
slider (R)
6
7
8
2 Remove the six solderings.
3 tension coil spring (KF)

12
CDC-R504MP/X504MP
2-7. OPTICAL PICK-UP
2-8. SL MOTOR ASSY (M902)
1 tension coil spring (CHKG
)
2 chucking arm sub assy
3 screw
(+B 1.4
x 5)
4 rack (SL)
5 claw
6 main shaft
7 optical pick-up
1 screw
(+P 1.4 x 1.8)
2 SL motor assy (M902)

13
CDC-R504MP/X504MP
2-9. LE MOTOR ASSY (M903)
2-10. SERVO BOARD
2 washer
4
qd
3
gear (LE1)
7 leaf spring (LE)
5
lever (D)
bracket (LEM)
slider (R)
6 screw
(+P 1.7
x 2.2)
8 screw
(+M 1.7
x 2.5)
qa screw
(+M 1.7
x 2.5)
qf two toothed lock screws
(+M 1.4
)
qs screw
(+M 1.7
x 2.5)
9 bearing (LEB)
0 woam (LEB) assy
qg LE motor assy
(M903)
1 Remove the soldering.
3 CN1
5 claw
6 SERVO board
4 toothed lock screw
(M 1.7)
1 Remove the eight solderings.
2 Remove the three solderings.

14
CDC-R504MP/X504MP
3-1. IC PIN DESCRIPTIONS
• IC3 CXD3059AR (DIGITAL SERVO/DIGITAL SIGNAL PROCESSOR) (SERVO BOARD (1/2))
Pin No. Pin Name I/O Pin Description
1MIRR I/O Mirrer signal input/output
2DFCT I/O Defect signal input/output
3FOK I/O Focus OK signal input/output
4VSS — Ground pin
5LOCK I/O Not used in this set. (Open)
6MDP O Spindle motor servo control signal output
7SSTP I Disc most inner detection signal input
8IOVSS1 — Digital ground pin for I/O
9SFDR O Sled drive signal output
10 SRDR O Sled drive signal output
11 TFDR O Tracking drive signal output
12 TRDR O Tracking drive signal output
13 FFDR O Focus drive signal output
14 FRDR O Focus drive signal output
15 IOVDD1 — Digital power supply pin for I/O
16 AVDD0 — Analog power supply pin for I/O
17 AVSS0 — Analog ground pin
18 NC — Not used. (Open)
19 E I E signal input
20 F I F signal input
21 TEI I Tracking error signal input from the DSSP block
22 TEO O Tracking error signal output to the RF amp block
23 FEI I Focus error signal input from the DSSP block
24 FEO O Focus error signal output form the RF amp block
25 VC I/O VC voltage output to the RF amp block
Center voltage input from the DSSP block by command select
26 A I A signal input
27 B I B signal input
28 C I C signal input
29 D I D signal input
30 NC — Not used. (Open)
31 AVDD4 — Analog power supply pin
32 RFDCO I/O RFDC signal output
RFDC signal input from the DSSP block by command select
33 PDSENS I Reference voltage input for PD
34 AC SUM O RFAC suming amp signal output
35 EQ IN I Equalizer circuit signal input
36 LD O APC amp signal output
37 PD I APC amp signal input
38 NC — Not used. (Open)
39 RFC I EQ cut off frequency adjustment input
40 AVSS4 — Analog ground pin
41 RFACO O RFAC signal output
42 RFACI I RFAC signal input or EFM signal input
43 AVDD3 — Analog power supply pin
44 BIAS I Asymmetry circuit constant current input
45 ASYI I Asymmetry comparate voltage input
46 ASYO O EFM full swing signal output
47 VPCO O Charge pomp output for wideband EFM PLL
48 VCTL I VCO2 control voltage input for wideband EFM PLL
49 AVSS3 — Analog ground pin
SECTION 3
DIAGRAMS

15
CDC-R504MP/X504MP
Pin No. Pin Name I/O Pin Description
50 CLTV I VCO1 control voltage input
51 FILO O Filter signal output for master PLL
52 FILI I Filter signal input for master PLL
53 PCO O Charge pomp output for master PLL
54 AVDD5 — Analog power supply pin
55 DDVROUT O DC/DC converter output
56 DDVRSEN I DC/DC converter output voltage monitor signal input
57 AVSS5 — Analog ground pin
58 DDCR I Reset signal input for DC/DC converter
59 NC — Not used. (Open)
60 BCKI I D/A interface bit clock signal input
61 PCMDI I D/A interface serial data signal input
62 LRCKI I D/A interface LR clock signal input
63 LRCK O D/A interface LR clock signal output
64 VSS — Digital ground pin for internal
65 PCMD O D/A interface serial data signal output
66 BCK O D/A interface bit clock signal output
67 VDD — Digital power supply pin for internal
68 EMPH O Not used in this set. (Open)
69 EMPHI I Not used in this set. (Fixed at “L”.)
70 IOVDD2 — Digital power supply pin for I/O
71 DOUT O Digital out signal output
72, 73 TEST I Test pin Normally “L”.
74 IOVSS2 — Digital ground pin for I/O
75 NC — Not used in this set. (Open)
76 XVSS — Ground pin for master clock
77 XTAO O Crystal oscillation circuit output (16.9344 MHz)
78 XTAI I Crystal oscillation circuit input (16.9344 MHz)
79 XVDD — Power supply pin for master clock
80 AVDD1 — Analog power supply pin
81 AOUT1 O L channel analog signal output
82 VREFL O L channel reference voltage output
83 AVSS1 — Analog ground pin
84 AVSS2 — Analog ground pin
85 VREFR O R channel reference voltage output
86 AOUT2 O R channel analog signal output
87 AVDD2 — Analog power supply pin
88 NC — Not used. (Open)
89 IOVDD0 — Digital power supply pin for I/O
90 RMUT O R channel “O” detection flug output
91 LMUT O L channel “O” detection flug output
92 NC — Not used. (Open)
93 XTSL I X’tal select signal input 16.9344 MHz: “L”, 33.8688 MHz: “H”
94 IOVSS0 — Digital ground pin for I/O
95 XTACN I Oscillation circuit control input “H”: Oscillation start, “L”: Oscillation stop
96 SQSO O Sub 80 bit and PCM peak, level data signal output CD text data signal output
97 SQCK I Clock signal input for SQSO read out
98 SBSO O Sub P-W serial data signal output Not used in this set. (Open)
99 EXCK I Clock signal input for SBSO read out Not used in this set. (Open)
100 XRST I System reset signal input “L”: reset
101 SYSM I Mute signal input “H”: mute Not used in this set. (Fixed at “L”.)
102 DATA I Serial data signal input
103 VSS — Digital ground pin for internal

16
CDC-R504MP/X504MP
Pin No. Pin Name I/O Pin Description
104 XLAT I Latch signal input
105 CLOK I Serial data transfer clock signal input
106 VDD — Digital power supply pin for internal
107 SENS O SENS signal output
108 SCLK I Clock signal input for SENS serial data read out
109 ATSK I/O Input/output for anti-shock
110 WFCK O WFCK signal output Not used in this set. (Open)
111 XUGF O XUGF signal output Not used in this set. (Open)
112 XPCK O XPCK signal output Not used in this set. (Open)
113 GFS O GFS signal output
114 C2PO O C2PO signal output
115 SCOR O Sub cord sync signal output
116 VDD — Digital power supply pin for internal
117 C4M O 4.2336 MHz signal output Not used in this set. (Open)
118 WDCK O Word clock signal output Not used in this set. (Open)
119 COUT I/O Track count signal input/output Not used in this set. (Open)
120 NC — Not used. (Open)

17
CDC-R504MP/X504MP
• IC501 MN101E01KSH (SYSTEM CONTROL) (MAIN BOARD (1/2))
Pin No. Pin Name I/O Pin Description
1DAVDD — Power supply pin for D/A output converter (+3.3V)
2BBE-MP O Not used in this set. (Open)
3DAVSS — Ground pin for D/A output converter
4 to 6 NCO O Not used in this set. (Open)
7UNISO O SONY-BUS data signal output
8UNISI I SONY-BUS data signal input
9UNICKO O SONY-BUS clock signal output
10 VDD1 — Power supply pin for internal core (+3.3 V)
11 MMOD I Flash microcomputer write detection signal input Not used in this set.
12 OSCOUT O High speed operation clock signal output (27 MHz)
13 OSCIN I High speed operation clock signal input (27 MHz)
14 VSS1 — Ground pin for internal core
15 XIN I Low speed operation clock signal input (32.768 kHz)
16 XOUT O Low speed operation clock signal output (32.768 kHz)
17 VDD2 — Power supply pin for internal core (+3.3 V)
18 MOD1 — Pull up: “H”
19 RESET I Reset signal input
20 NCO O Not used in this set. (Open)
21 ACC IN I Accessory power supply detection signal input
22 TEST IN I Test mode detection signal input
23 TEL ATT I Telephone attenuate detection signal input
24 ATT O Audio mute control signal output
25 XKEYON O Key power supply control signal output Not used in this set. (Open)
26 NCO O Not used in this set. (Open)
27 KEYACK I Key acknowledge detection signal input
28 TUATTIN I Tuner mute ZERO cross detection signal input
29, 30 NCO O Not used in this set. (Open)
31 BUIN I Back up power supply detection signal input
32 to 35 NCO O Not used in this set. (Open)
36 BUSON O BUS on signal output
37 SYSRST O System reset signal output
38 EJECT OK O CD servo IC eject OK signal output
39 to 41 NCO O Not used in this set. (Open)
42 Z MUTE I Mechadeck mute zero cross detection signal input L/R
43 to 46 NCO O Not used in this set. (Open)
47 CD ON I CD mechanism power supply control signal input (“H”: Power on)
48 CDM ON I CD mechanism deck power supply control signal input (“H”: Power on)
49, 50 NCO O Not used in this set. (Open)
51 AREASEL1 I Destination function setting input 1
52 AREASEL2 I Destination function setting input 2
53 AREASEL3 I Destination function setting input 3
54 LCD CTL O “H” output: LCD unit and key confusion, power off
“L” output: LCD unit and key confusion, power on
55, 56 NCO O Not used in this set. (Open)
57 DSSA O DSSA on/off change signal output (Cut off rear)
58 PANEL SW I Front panel attachment detection signal input “L”: with panel, “H”: without panel
59 DIAG I Condition signal input from the power IC
60 VOLATT O Electronic volume attenuate control signal output
61, 62 NCO O Not used in this set. (Open)
63 VSS2 — Ground pin for I/O port
64 TU ATT O Tuner mute control signal output
65 NCO O Not used in this set. (Open)

18
CDC-R504MP/X504MP
Pin No. Pin Name I/O Pin Description
66 NS MASK O Noise mask signal output
67 EEP CKO O Serial clock signal output for EEPROM communication
68 EEP SIO I/O Serial data signal input/output for EEPROM communication
69 NCO O Not used in this set. (Open)
70 AMPSTB O Power regulator IC standby signal output
71 to 73 NCO O Not used in this set. (Open)
74 NCO O Not used in this set.
75 NCO O Not used in this set. (Open)
76 LCDSO O Serial data signal output to the LCD driver
77 LCDCE O Chip enable signal output to the LCD driver
78 LCDCKO O Serial clock signal output to the LCD driver
79 I2C SIO I/O I2C BUS serial data signal input/output
80 NCO O Not used in this set. (Open)
81 I2C CKO O I2C BUS serial clock signal output
82 DAVN I RDS data block synchronization detection signal input
83 SIRCS I Remote control signal input
84 NCO O Not used in this set. (Open)
85 BEEP O Beep signal output to the power amp
86 to 88 NCO O Not used in this set. (Open)
89 VDD3 — Power supply pin for I/O port (+3.3V)
90 NCO O Not used in this set. (Open)
91 VSS3 — Ground pin for I/O port
92 QUALITY I Noise detection signal input
93 VSM I S meter voltage detection signal input
94 KEYIN1 I Key signal input 1
95 KEYIN0 I Key signal input 0
96 NCO O Not used in this set.
97 KEYIN2 I Key signal input (EJECT, OFF, SOURCE switch)
98 RE I Rotary encoder signal input
99 L METER I Level meter voltage detection signal input
100 VREF+ — Power supply pin forA/D input converter

19 19
CDC-R504MP/X504MP
3-2. BLOCK DIAGRAM — CD SECTION —
46
ASYO
RF AMP,DIGITAL SERVO,
DIGITAL SIGNAL PROCESSOR
IC3
41
RFACO
24
FEO
22
TEO
42 RFACI
23 FEI
21 TEI
13 FFDR
PD1
PD2
E
F
I-V AMP
PD LD
DETECTOR
45 ASYI
27
26
29
28
19
20
E
C
D
A
B
F
36 LD 37
PD
(FOCUS)
(TRACKING)
2-AXIS DEVICE
OPTICAL
PICK-UP BLOCK
(KSS1000E)
• Siganal Path
: CD PLAY
LASER DIODE
M
M
M
13
12
VO1–
VO1+
6
7
VO4+
VO4–
8
9VO3–
VO3+
5
4
VOL+
VOL–
FWD
REV
1
2
VIN2+ 22
14 FRDR
VIN2– 21
11 TFDR
VIN1+B 19
12 TRDR
VIN1–B 18
9SFDR
VIN4+ 31
10 SRDR
VIN4– 32
6MDP
VIN3+ 25
MUTE 34
11
10
VO2–
VO2+
M903
(LOADING)
M901
(SPINDLE)
M902
(SLED)
FOCUS/TRACKING COIL DRIVE,
SLED/SPINDLE/LOADING
MOTOR DRIVE
IC1
3
FOK
96
SQSO
97
SQCK
100
XRST
102
DATA
104
XLAT
105
CLOK
107
SENS
CD-L MAIN
SECTION
A
81
AOUT1
86
AOUT2 R-CH
18 CD SQCK
15 CD XRST
14 CD DATA
13 CD XLAT
53 MEC_SELFSW
45 MEC_INSW
42 MEC_LIMIT
12 CD CLOK
11 CD SENS
108
SCLK 10 CD SCLK
113
GFS 8CD GFS
114
C2POT 7CD C2PO
115
SCOR 52 CD SCORT
81 X1
80 X0
MEC LOAD
43
MEC EJECT
44
CD
SYSTEM CONTROL
IC4
AUDIO INTERFACE
IC8
+1.5V REG
IC7
SYSTEM CONTROL
IC501 (1/3)
19 CD FOK
16 CD SQSO
DRON
41
SD1O
14
LRCK1B
19
LRCK1A
16
SD0O
11
BCK1B
18
BCK1A
15
CLCK
22
SRMSTB
41
RESET
2
STANDBY
3
BUCK
36
I2C SCL
7
I2C SDA
6
BUSO
28
SW2
(SELF)
46 MEC_DSW
SW1
(DOWN)
SW3
(DISC IN)
SW4
(LIMIT)
89
LMUTE 22 CD LMUT
90
RMUTE 23 CD RMUT 56
UNISI
25
RXD
57
UNISO
58
UNICLK
50
BUS ON
51
BU IN
75
RSTX
61
EJECT OK
67
MECON CHK
69
EMPH
32
DEC SDA
31
DEC SCL
30
DEC INT
29
DEC STBY
28
DEC XRST
27
DEC SSTBY
37
DEC XMUTE
65
DECON
63
MECON
64
CDON
66
ZMUT
60
A ATT
26
TXD
PD1
E
F
LD
PD
FCS+
FCS–
TRK+
TRK–
PD2
AUTOMATIC
POWER
CONTROL
Q1
+1.5V
CONTROL
Q2,3
+3.3V
CONTROL
Q5,6
• R-ch is omitted due to same as L-ch.
77
78
X1
16.934MHz
X2
18.43MHz
XTAI
XTAO
66
BCK
60
BCKI
61
PCMDI
63
LRCK
62
LRCKI
65
PCMD
MAIN
SECTION
B
EJECT OK
UNI SI
UNI SO
ATT
UNI SCK
BUS ON
BU IN
SYS RST
38
CD ON
VOUT
47
CDM ON
48
Z MUTE
MECHA+6V
42
68
CDON CHK
15 VDD
3
CE
SERVO+3.3V
+1.5V
+3.3V
U COM+3.3V
(Page 20)
(Page 20)

2020
CDC-R504MP/X504MP
1ANT 7TU-LCH
SOUND CONTROL,
ELECTRONIC VOLUME
IC401
J1
(ANTENNA)
TU1
(TUNER UNIT)
POWER AMP
MULTIPLE VOLTAGE
REGULATOR
IC750
SYSTEM CONTROL
IC501 (2/3)
CN601
6TU-RCH
R-CH (FRONT)
R-CH (REAR)
BATT
9CD-LCH
5AUX-LCH
3AUX-RCH
8CD-RCH
R-CH
4
3
10
VCC
11
TU VDD
15
E2P VDD
13
TU-SCL
14
TU-SDA
9
RDS
6
5
8
MULTI
CONDITION
QUALITY
7
S-METER
16
TU MUTE
E2P SCL
17
E2P SDA
UNI SO
UNI SI
UNI SCK
BUS ON
SYS RST
BU IN
ATT
RESET
99 L METER
82 DAVM
28 TU ATTIN
92 QUALITY
66 NS MASK
93 VSM
64 TU ATT
67 EEP CKO
68 EEP SIO
7UNI SO
8UNI SI
9UNI SCK
36 BUS ON
37 SYS RST
AUDIO+8.3V
TU+5V
BACK UP+3.3V
L
R
CD-L
J601
(AUX IN)
R-CH
R-CH
15 OUT-SEL-R
OUT-SEL-L
16
R-CH
17
18
OUT SUB L
OUT SUB R R-CH
L
R
5
3
OUT-FL+
OUT-FL–
OUT-RL+
OUT-RL–
9
7
29
27
AMP-REM
R-CH
ANT-REM
BATT
30
37
AUDIO+8.3V
B.UP+B
31
33
SERVO+3.3V
MECHA+6V
34
PANEL+B
TU+5V
BATT
25
24
OUT-FR
OUT-RR
29
MUTE
2SDA
AUDIO+8.3V
BACK UP+3.3V
SERVO+3.3V
MECHA+6V
PANEL+10V
4SCL
SDA
SCL
16 BEEP
22 STB
25 DIAG
AUDIO+8.3V
35 VP
15
13
7
10
12
11
16
1
9
2
4
3
5
6
30
31
SCL
SDA
SCL
SDA
SCL
SDA
SCL
SDA
81
I2C CKO
79
I2C SIO
60
VOL ATT
24
ATT
85
BEEP
70
AMPSTB
59
DIAG
31
BUIN
22
TEST IN
12 IN-FL FL+
FL–
RL+
RL–
FR+
FR–
RR+
RR–
AMP-REM
ANT-REM
ACC
TEST
23
OUT-FL
11 IN-RL
22
OUT-RL
MUTE
Q431
MUTE
Q481
AUDIO OUT
REAR
MUTE DRIVE
Q491,492
16 MPX
9XTI
10 XTO
11
SCL
12
SDA
SCL
SDA
15
INTN
7
VDDDVDDA
1
21
ACC IN ACC CHECK
Q631
TU+5V REG
Q1
BATT
LOW VOLTAGE
DETECT
Q581
BATTERY
CHECK
Q582
REAR L/R
CUT OFF
SWITCH
Q403
DSSA ON/OFF
SWITCH
Q402
NS MASK
SWITCH
Q3
LEVEL METER
VOLTAGE DETECT
D401,402,Q401
RDS DEMODULATOR
IC51
MUTE
Q451
ATT
23
TEL ATT
57
DSSA
TEL ATT
Q651
D492
D503
FU601
J331
D580
R504MP/X504MP:
AEP,UK MODEL
D581
CD
SECTION A
CD
SECTION B
DISPLAY
SECTION C
BATT
B+ SWITCH
Q51,52
BACK UP
+3.3V
OVER VOLTAGE
DETECT
Q580
X51
8.664MHz
R504MP
R504MP
D301
• Signal Path
• R-CH is omitted due to same as L-CH.
: CD PLAY
: FM
: AM/MW/LW
: AUX
3-3. BLOCK DIAGRAM — MAIN SECTION —
(Page 19)
(Page 19)
(Page 21)
