SERVICE MANUAL

DATA

NSX-SZ30

NSX-SZ36

HS, HT

COMPACT DISC STEREO

CASSETTE RECEIVER

SIMPLE

S/M Code No. 09-007-423-3T3

• Replace this Service manual with “Revision Publishing” when it is issued.

BASIC TAPE MECHANISM: 6ZM-3 PR2NM, ZZM-3 YPR1NM

BASIC CD MECHANISM : AZG-1 ZD3RDM / YZD3RDM

SYSTEM TAPE MECHANISM

NSX-SZ30<HS>

NSX-SZ30<HT>

6ZM-3 PR2NM

ZZM-3 YPR1NMNSX-SZ36<LH>

CD MECHANISM

AZG-1 ZD3RDM

AZG-1 YZD3RDM

ELECTRICAL MAIN PARTS LIST - 1/8

NOTE: The characters in the suffix column indicate the part usage.

HS .....................XX..................................A...................

LH .....................XX...................................B..................

HT .....................XX....................................C.................

KANRI

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

C 402 87-010-112-040 CAP,E 100-16 A.C.................

C 401 87-010-186-080 CAP,CHIP 4700P A.C.................

C 409 87-010-265-040 CAP,E 33-16 SME A.C.................

C 404 87-010-320-080 CHIP CAP 68P A.C.................

C 408 87-010-322-080 C-CAP,S 100P-50 CH A.C.................

C 407 87-010-405-040 CAP,E 10-50 A.C.................

C 406 87-010-544-040 CAP,E 0.1-50 SME A.C.................

C 405 87-010-544-040 CAP,E 0.1-50 SME A.C.................

C 403 87-010-545-040 CAP,E 0.22-50 SME A.C.................

C 413 87-010-177-080 C-CAP,S 820P-50 SL A.C.................

C 410 87-012-369-080 C-CAP,S 0.047-50F A.C.................

EMI 401 87-008-372-080 FILTER, EMI BL OIRNI A.C.................

J 401 87-A61-242-010 JACK,6.3 BLK MONO W/SW V KM A...................

J 401 87-A61-243-010 JACK,6.3 BLK MONO W/SW V MSC ..C.................

Q 404 87-A30-075-080 C-TR,2SA1235F A.C.................

Q 402 87-A30-075-080 C-TR,2SA1235F A.C.................

Q 401 87-A30-076-080 C-TR,2SC3052F A.C.................

Q 406 87-A30-076-080 C-TR,2SC3052F A.C.................

Q 403 87-A30-076-080 C-TR,2SC3052F A.C.................

Q 405 87-A30-087-080 C-FET,2SK2158 A.C.................

VR 401 86-NFA-607-010 VR,RTRY 10K15AX1 1 V XV0121PVN A.C.................

C 1 87-010-387-080 CAP,E 470-25 SME A.C.................

C 31 87-010-403-080 CAP, ELECT 3.3-50V A.C.................

CN 1 87-A61-110-010 CONN,9P V TID-A ABC.................

D 2 87-020-465-080 DIODE,1SS133 (110MA) ABC.................

D 4 87-020-465-080 DIODE,1SS133 (110MA) ABC.................

D 3 87-020-465-080 DIODE,1SS133 (110MA) ABC.................

D 1 87-020-465-080 DIODE,1SS133 (110MA) ABC.................

D 5 87-020-465-080 DIODE,1SS133 (110MA) ABC.................

D 32 87-020-465-080 DIODE,1SS133 (110MA) ABC.................

D 31 87-020-465-080 DIODE,1SS133 (110MA) ABC.................

PT 2 8A-NF8-673-010 PT,SUB ANF-8 (H)KAMI ABC.................

Q 31 87-026-245-080 TR,DTC114ES ABC.................

Q 32 87-A30-198-080 TR,KTC3199GR ABC.................

RY 1 87-A91-339-010 RELAY,AC DC12V G5PA-2 ABC.................

S 1 87-A90-165-010 SW,SL 1-2-3 SWS2301 .BC.................

T 1 87-A60-317-010 TERMINAL, 1P MSC ABC.................

T 2 87-A60-317-010 TERMINAL, 1P MSC ABC.................

C 101 87-010-196-080 CHIP CAPACITOR,0.1-25 A.C.................

C 104 87-010-196-080 CHIP CAPACITOR,0.1-25 A.C.................

C 102 87-010-196-080 CHIP CAPACITOR,0.1-25 A.C.................

C 107 87-010-493-040 CAP,E 0.47-50 GAS A.C.................

C 103 87-010-498-040 CAP,E 10-16 GAS A.C.................

C 108 87-012-393-080 C-CAP,S 0.22-16 R K A.C.................

C 153 87-010-198-080 CAP, CHIP 0.022 A.C.................

C 154 87-010-246-040 CAP,E 47-35 SME A.C.................

C 155 87-010-404-040 CAP,E 4.7-50 SME A.C.................

C 156 87-010-404-040 CAP,E 4.7-50 SME A.C.................

C 361 87-010-178-080 CHIP CAP 1000P A.C.................

C 362 87-010-178-080 CHIP CAP 1000P A.C.................

C 371 87-010-178-080 CHIP CAP 1000P A.C.................

C 372 87-010-178-080 CHIP CAP 1000P A.C.................

C 601 87-010-382-040 CAP,E 22-25 SME A.C.................

C 802 87-010-195-080 C-CAP,S 0.068-25 F A.C.................

C 801 87-010-195-080 C-CAP,S 0.068-25 F A.C.................

C 805 87-010-196-080 CHIP CAPACITOR,0.1-25 A.C.................

C 806 87-010-196-080 CHIP CAPACITOR,0.1-25 A.C.................

C 804 87-010-402-040 CAP,E 2.2-50 SME A.C.................

C 803 87-010-402-040 CAP,E 2.2-50 SME A.C.................

C 810 87-010-379-040 CAP,E 22-16 M SME A.C.................

C 901 87-010-322-080 C-CAP,S 100P-50 CH A.C.................

C 907 87-010-322-080 C-CAP,S 100P-50 CH A.C.................

C 903 87-010-322-080 C-CAP,S 100P-50 CH A.C.................

C 902 87-010-322-080 C-CAP,S 100P-50 CH A.C.................

C 908 87-010-322-080 C-CAP,S 100P-50 CH A.C.................

C 905 87-010-322-080 C-CAP,S 100P-50 CH A.C.................

C 904 87-010-322-080 C-CAP,S 100P-50 CH A.C.................

C 906 87-010-322-080 C-CAP,S 100P-50 CH A.C.................

C 909 87-010-322-080 C-CAP,S 100P-50 CH A.C.................

C 911 87-010-178-080 CHIP CAP 1000P A.C.................

C 912 87-010-196-080 CHIP CAPACITOR,0.1-25 A.C.................

C 917 87-010-196-080 CHIP CAPACITOR,0.1-25 A.C.................

C 916 87-010-196-080 CHIP CAPACITOR,0.1-25 A.C.................

C 915 87-010-196-080 CHIP CAPACITOR,0.1-25 A.C.................

C 919 87-010-197-080 CAP, CHIP 0.01 DM A.C.................

C 914 87-010-248-040 CAP,E 220-10 SME A.C.................

C 913 87-010-248-040 CAP,E 220-10 SME A.C.................

C 910 87-010-322-080 C-CAP,S 100P-50 CH A.C.................

C 921 87-010-186-080 CAP,CHIP 4700P A.C.................

ELECTRICAL MAIN PARTS LIST - 2/8

C 920 87-012-369-080 C-CAP,S 0.047-50F A.C.................

C 951 87-010-312-080 C-CAP,S 15P-50 CH A.C.................

C 953 87-012-140-080 CAP 470P A.C.................

C 952 87-012-155-080 C-CAP 180P-50CH A.C.................

C 963 87-010-196-080 CHIP CAPACITOR,0.1-25 A.C.................

C 961 87-010-378-040 CAP,E 10-16 A.C.................

C 962 87-012-157-080 C-CAP,S 330P-50 CH A.C.................

CN 104 87-A60-057-010 CONN,11P V 9604S-11C ABC.................

CN 701 87-099-720-010 CONN,30P TYK-B(P) ABC.................

CN 731 87-099-015-010 CONN,13P 6216V ABC.................

D 102 87-A40-752-080 ZENER,UZ6.2BSC ABC.................

D 601 87-A40-269-080 C-DIODE,MC2836 ABC.................

D 652 87-A40-269-080 C-DIODE,MC2836 ABC.................

D 651 87-A40-269-080 C-DIODE,MC2836 ABC.................

D 653 87-A40-269-080 C-DIODE,MC2836 ABC.................

D 654 87-A40-269-080 C-DIODE,MC2836 ABC.................

D 984 87-020-465-080 DIODE,1SS133 (110MA) ABC.................

D 987 87-020-465-080 DIODE,1SS133 (110MA) ABC.................

FL 901 8A-NF9-605-010 FL,HNA-10SS12 ABC.................

IC 901 8A-NF9-604-010 C-IC,UPD780226-*** ABC.................

IC 961 87-A21-482-010 IC,RPM6938-H4 ABC.................

L 951 87-A50-434-010 COIL,CLK 4.19M(TOKO) ABC.................

LED 209 87-A40-317-080 LED,SLR-342VCT31 RED ABC.................

LED 202 87-A40-619-040 LED,SLR-56PT-T31-W GRN ABC.................

LED 201 87-A40-619-040 LED,SLR-56PT-T31-W GRN ABC.................

LED 205 87-A40-619-040 LED,SLR-56PT-T31-W GRN ABC.................

LED 204 87-A40-619-040 LED,SLR-56PT-T31-W GRN ABC.................

Q 101 87-026-610-080 TR,KTC3198GR ABC.................

Q 103 87-A30-074-080 C-TR,RT1P 141C ABC.................

Q 104 87-A30-074-080 C-TR,RT1P 141C ABC.................

Q 102 87-A30-076-080 C-TR,2SC3052F ABC.................

Q 105 87-A30-468-080 C-TR,KRC102S-RTK ABC.................

Q 201 87-A30-087-080 C-FET,2SK2158 ABC.................

Q 602 87-A30-318-080 TR,CSA952K ABC.................

Q 601 87-A30-318-080 TR,CSA952K ABC.................

Q 603 87-A30-329-080 TR,CD1585BC ABC.................

Q 804 87-A30-075-080 C-TR,2SA1235F ABC.................

Q 805 87-A30-075-080 C-TR,2SA1235F ABC.................

Q 806 87-A30-075-080 C-TR,2SA1235F ABC.................

Q 803 87-A30-075-080 C-TR,2SA1235F ABC.................

Q 802 87-A30-076-080 C-TR,2SC3052F ABC.................

Q 801 87-A30-076-080 C-TR,2SC3052F ABC.................

Q 901 87-A30-074-080 C-TR,RT1P 141C ABC.................

Q 902 87-A30-468-080 C-TR,KRC102S-RTK ABC.................

Q 951 87-A30-087-080 C-FET,2SK2158 ABC.................

S 349 87-A90-164-080 SW,TACT SKQAB(N) ABC.................

S 347 87-A90-164-080 SW,TACT SKQAB(N) ABC.................

S 348 87-A90-164-080 SW,TACT SKQAB(N) ABC.................

S 346 87-A90-164-080 SW,TACT SKQAB(N) ABC.................

S 350 87-A90-164-080 SW,TACT SKQAB(N) ABC.................

S 361 87-A91-633-010 SW,RTRY XRE012103PVB25FINA 1-2 ABC.................

S 371 87-A91-632-010 SW,RTRY XRE012103PVB25FINB 1-2 ABC.................

C 303 87-010-178-080 CHIP CAP 1000P A.C.................

C 302 87-010-178-080 CHIP CAP 1000P A.C.................

C 301 87-010-178-080 CHIP CAP 1000P A.C.................

C 304 87-010-178-080 CHIP CAP 1000P A.C.................

C 307 87-010-263-080 CAP, ELECT 100-10V A.C.................

C 308 87-010-263-080 CAP, ELECT 100-10V A.C.................

C 309 87-010-318-080 C-CAP,S 47P-50 CH A.C.................

C 314 87-010-188-080 CAP,CHIP 6800P A.C.................

C 313 87-010-188-080 CAP,CHIP 6800P A.C.................

C 315 87-010-263-080 CAP, ELECT 100-10V A.C.................

C 310 87-010-318-080 C-CAP,S 47P-50 CH A.C.................

C 318 87-010-546-080 CAP, ELECT 0.33-50V A.C.................

C 317 87-010-546-080 CAP, ELECT 0.33-50V A.C.................

C 326 87-010-198-080 CAP, CHIP 0.022 A.C.................

C 327 87-012-368-080 C-CAP,S 0.1-50 F A.C.................

C 360 87-010-401-080 CAP, ELECT 1-50V A.C.................

C 399 87-012-140-080 CAP 470P A.C.................

C 409 87-010-182-080 C-CAP,S 2200P-50 B A.C.................

C 406 87-010-197-080 CAP, CHIP 0.01 DM A.C.................

C 407 87-010-197-080 CAP, CHIP 0.01 DM A.C.................

C 408 87-010-197-080 CAP, CHIP 0.01 DM A.C.................

C 405 87-010-197-080 CAP, CHIP 0.01 DM A.C.................

C 403 87-010-321-080 CHIP CAPACITOR,82P(J) A.C.................

C 404 87-010-321-080 CHIP CAPACITOR,82P(J) A.C.................

C 402 87-010-544-080 CAP, ELECT 0.1-50V A.C.................

C 401 87-010-544-080 CAP, ELECT 0.1-50V A.C.................

C 410 87-010-182-080 C-CAP,S 2200P-50 B A.C.................

C 411 87-010-405-080 CAP, ELECT 10-50V A.C.................

C 412 87-010-405-080 CAP, ELECT 10-50V A.C.................

C 453 87-010-183-080 C-CAP,S 2700P-50 B A.C.................

C 455 87-010-183-080 C-CAP,S 2700P-50 B A.C.................

C 454 87-010-183-080 C-CAP,S 2700P-50 B A.C.................

C 456 87-010-197-080 CAP, CHIP 0.01 DM A.C.................

C 452 87-010-382-080 CAP, ELECT 22-25V A.C.................

C 460 87-010-196-080 CHIP CAPACITOR,0.1-25 A.C.................

ELECTRICAL MAIN PARTS LIST - 3/8

C 462 87-012-158-080 C-CAP,S 390P-50 CH A.C.................

C 461 87-012-158-080 C-CAP,S 390P-50 CH A.C.................

C 470 87-018-127-080 CAP, CER 470P-50V A.C.................

CN 301 87-A60-620-010 CONN,3P V 2MM JMT ABC.................

CN 351 87-A60-625-010 CONN,8P V 2MM JMT ABC.................

D 401 87-020-465-080 DIODE,1SS133 (110MA) ABC.................

IC 301 87-A21-419-040 C-IC,NJM14558MD-TE2 ABC.................

IC 401 87-A21-419-040 C-IC,NJM14558MD-TE2 ABC.................

L 451 87-007-342-010 COIL,OSC 85K BIAS ABC.................

Q 306 87-A30-062-080 C-TR,KRC104S ABC.................

Q 309 87-A30-075-080 C-TR,2SA1235F ABC.................

Q 303 87-A30-090-080 FET,2SK2541 ABC.................

Q 304 87-A30-090-080 FET,2SK2541 ABC.................

Q 307 87-A30-091-080 FET,2SJ460 ABC.................

Q 305 87-A30-091-080 FET,2SJ460 ABC.................

Q 301 87-A30-091-080 FET,2SJ460 ABC.................

Q 308 87-A30-091-080 FET,2SJ460 ABC.................

Q 302 87-A30-091-080 FET,2SJ460 ABC.................

Q 310 87-A30-075-080 C-TR,2SA1235F ABC.................

Q 443 87-A30-075-080 C-TR,2SA1235F ABC.................

Q 444 87-A30-075-080 C-TR,2SA1235F ABC.................

Q 451 87-A30-318-080 TR,CSA952K ABC.................

Q 453 89-333-317-880 TR,2SC3331 (0.5W) ABC.................

Q 454 89-333-317-880 TR,2SC3331 (0.5W) ABC.................

SFR 452 87-A90-432-080 SFR,30K H NVZ6TLTA ABC.................

SFR 451 87-A90-432-080 SFR,30K H NVZ6TLTA ABC.................

C 971 87-010-381-080 CAP, ELECT 330-16V A.C.................

C 972 87-010-404-080 CAP, ELECT 4.7-50V A.C.................

C 982 87-010-196-080 CHIP CAPACITOR,0.1-25 A.C.................

C 989 87-010-197-080 CAP, CHIP 0.01 DM A.C.................

C 981 87-010-260-080 CAP, ELECT 47-25V A.C.................

C 993 87-010-178-080 CHIP CAP 1000P A.C.................

C 995 87-010-178-080 CHIP CAP 1000P A.C.................

C 997 87-010-196-080 CHIP CAPACITOR,0.1-25 A.C.................

C 998 87-010-260-080 CAP, ELECT 47-25V A.C.................

C 992 87-010-312-080 C-CAP,S 15P-50 CH A.C.................

C 991 87-010-312-080 C-CAP,S 15P-50 CH A.C.................

C 999 87-A11-155-080 CAP,TC U 0.01-16 Z F A.C.................

D 804 87-020-465-080 DIODE,1SS133 (110MA) ABC.................

D 991 87-017-149-080 ZENER,HZS6A2L ABC.................

IC 991 87-070-127-110 IC,LC72131 D ABC.................

Q 981 87-A30-234-080 TR,CSC4115BC ABC.................

R 993 87-010-322-080 C-CAP,S 100P-50 CH A.C.................

R 991 87-010-322-080 C-CAP,S 100P-50 CH A.C.................

R 995 87-010-322-080 C-CAP,S 100P-50 CH A.C.................

X 991 87-A70-061-010 VIB,XTAL 4.500MHZ CSA-309 ABC.................

C 771 87-010-263-080 CAP, ELECT 100-10V A.C.................

C 788 87-010-149-080 C-CAP,S 5P-50 CH A.C.................

C 789 87-A10-801-080 C-CAP,S 0.022-16 J B CM A.C.................

C 789 87-A12-052-080 C-CAP,S 0.033-25 J B ....................

C 791 87-010-196-080 CHIP CAPACITOR,0.1-25 A.C.................

C 793 87-010-404-080 CAP, ELECT 4.7-50V A.C.................

C 797 87-010-405-080 CAP, ELECT 10-50V A.C.................

C 799 87-010-407-080 CAP, ELECT 33-50V A.C.................

C 790 87-A10-801-080 C-CAP,S 0.022-16 J B CM A.C.................

C 790 87-A12-052-080 C-CAP,S 0.033-25 J B ....................

C 802 87-010-194-080 CAP, CHIP 0.047 A.C.................

C 803 87-010-198-080 CAP, CHIP 0.022 A.C.................

C 804 87-010-263-080 CAP, ELECT 100-10V A.C.................

C 807 87-010-400-080 CAP, ELECT 0.47-50V A.C.................

C 808 87-010-401-080 CAP, ELECT 1-50V A.C.................

C 809 87-010-401-080 CAP, ELECT 1-50V A.C.................

C 801 87-010-403-080 CAP, ELECT 3.3-50V A.C.................

C 800 87-012-369-080 C-CAP,S 0.047-50F A.C.................

C 810 87-010-196-080 CHIP CAPACITOR,0.1-25 A.C.................

C 815 87-010-400-080 CAP, ELECT 0.47-50V A.C.................

C 816 87-010-400-080 CAP, ELECT 0.47-50V A.C.................

C 823 87-010-177-080 C-CAP,S 820P-50 SL A.C.................

C 824 87-010-404-080 CAP, ELECT 4.7-50V A.C.................

C 821 87-010-405-080 CAP, ELECT 10-50V A.C.................

C 825 87-010-596-080 CAP, S 0.047-16 A.C.................

D 803 87-020-465-080 DIODE,1SS133 (110MA) ABC.................

IC 801 87-A21-560-010 IC,LA1844L-A ABC.................

L 801 87-A50-608-010 COIL,FM DET-N(TOK) ABC.................

L 802 87-A91-551-010 FLTR,PCFJZH-450 L(TOK) AB..................

L 802 87-A91-552-010 FLTR,CFMT-450AL (TOK) ..C.................

L 811 87-005-847-080 COIL,2.2UH(CECS) ABC.................

R 790 87-010-197-080 CAP, CHIP 0.01 DM A.C.................

C 859 87-010-196-080 CHIP CAPACITOR,0.1-25 A.C.................

C 858 87-010-196-080 CHIP CAPACITOR,0.1-25 A.C.................

C 850 87-010-260-080 CAP, ELECT 47-25V A.C.................

C 948 87-010-148-080 CAP, CHIP S 75P SL ..C.................

C 940 87-010-197-080 CAP, CHIP 0.01 DM A.C.................

C 947 87-010-197-080 CAP, CHIP 0.01 DM A.C.................

C 941 87-010-314-080 C-CAP,S 22P-50V ..C.................

C 946 87-010-971-080 C-CAP,S 4700P-50 B J ..C.................

C 959 87-010-196-080 CHIP CAPACITOR,0.1-25 A.C.................

ELECTRICAL MAIN PARTS LIST - 4/8

C 952 87-010-197-080 CAP, CHIP 0.01 DM A.C.................

C 956 87-010-263-080 CAP, ELECT 100-10V ..C.................

C 954 87-010-400-080 CAP, ELECT 0.47-50V ..C.................

C 961 87-010-152-080 C-CAP,S 8P-50 CH A...................

C 962 87-010-401-080 CAP, ELECT 1-50V ..C.................

C 964 87-010-854-080 C-CAP,S 560PCH ..C.................

C 963 87-015-785-080 CHIP CAPACITOR, 0.1FZ-25Z A.C.................

CF 831 87-008-261-010 FILTER, SFE10.7MA5-A ABC.................

CF 832 87-008-261-010 FILTER, SFE10.7MA5-A ABC.................

D 941 87-020-465-080 DIODE,1SS133 (110MA) ..C.................

D 951 87-A40-618-080 VARI-CAP,SVC 348(S/T) ..C.................

FFE 831 A8-8ZA-190-030 8ZA-1 FEUNM A.C.................

FFE 831 A8-8ZA-191-030 8ZA-1 YFEUNM .B..................

FFE 831 A8-8ZA-192-070 8ZA-1 FEUNC ....................

J 831 87-A60-202-010 TERMINAL,ANT 4P MSP-154V-02 ABC.................

J 940 87-A60-633-010 CONN,2P H 2.5MM JMT ..C.................

L 832 87-005-847-080 COIL,2.2UH(CECS) ABC.................

L 941 87-A50-022-010 COIL,ANT SW(COI) ..C.................

L 944 87-A50-159-010 COIL,10MH K C2B ..C.................

L 943 87-A50-522-080 COIL,1MH K CEC ..C.................

L 942 87-A50-550-010 COIL,OSC SW-2N(COI) ..C.................

L 952 87-A50-430-010 COIL,ANT MW(3BSW) ..C.................

L 953 87-A50-431-010 COIL,OSC MW(3BSW) ..C.................

L 951 8A-NF8-667-010 COIL,AM PACK 4(TOK) AB..................

Q 837 87-A30-072-080 C-TR,RT1P 144C ABC.................

Q 835 89-327-143-080 TR,2SC2714 (0.1W) ABC.................

Q 941 87-A30-074-080 C-TR,RT1P 141C ..C.................

Q 943 87-A30-075-080 C-TR,2SA1235F ..C.................

Q 942 87-A30-075-080 C-TR,2SA1235F ..C.................

Q 949 87-A30-076-080 C-TR,2SC3052F ..C.................

Q 944 87-A30-076-080 C-TR,2SC3052F ..C.................

Q 945 87-A30-076-080 C-TR,2SC3052F ..C.................

Q 948 87-A30-086-040 C-TR,CSD1306E ..C.................

Q 946 87-A30-086-040 C-TR,CSD1306E ..C.................

Q 951 87-A30-074-080 C-TR,RT1P 141C ..C.................

Q 950 87-A30-086-040 C-TR,CSD1306E ..C.................

Q 953 89-503-602-080 C-FET,2SK360E ..C.................

TC 943 87-011-253-080 TRIMER,30P LAR ..C.................

TC 941 87-011-254-080 TRIMER,20P LAR ..C.................

C 4 87-012-368-080 C-CAP,S 0.1-50 F A.C.................

C 6 87-012-368-080 C-CAP,S 0.1-50 F A.C.................

C 5 87-012-368-080 C-CAP,S 0.1-50 F A.C.................

C 3 87-012-368-080 C-CAP,S 0.1-50 F A.C.................

C 9 87-012-368-080 C-CAP,S 0.1-50 F A.C.................

C 10 87-012-368-080 C-CAP,S 0.1-50 F A.C.................

C 11 87-012-368-080 C-CAP,S 0.1-50 F A.C.................

C 12 87-012-368-080 C-CAP,S 0.1-50 F A.C.................

C 19 87-A12-036-000 CAP,E 2200-63 SMG A.C.................

C 26 87-010-247-080 CAP, ELECT 100-50V A.C.................

C 25 87-010-385-080 CAP, ELECT 220-25V A.C.................

C 21 87-A10-520-000 CAP,E 3300-35 M SMG A.C.................

C 22 87-A10-520-000 CAP,E 3300-35 M SMG A.C.................

C 20 87-A12-036-000 CAP,E 2200-63 SMG A.C.................

C 32 87-010-197-080 CAP, CHIP 0.01 DM A.C.................

C 38 87-010-197-080 CAP, CHIP 0.01 DM A.C.................

C 34 87-010-247-080 CAP, ELECT 100-50V A.C.................

C 31 87-010-263-080 CAP, ELECT 100-10V A.C.................

C 35 87-010-380-080 CAP, ELECT 47-16V A.C.................

C 36 87-010-381-080 CAP, ELECT 330-16V A.C.................

C 30 87-010-430-080 CAP, ELECT 100-63 A.C.................

C 61 87-010-260-080 CAP, ELECT 47-25V A.C.................

C 60 87-010-403-080 CAP, ELECT 3.3-50V A.C.................

C 97 87-010-196-080 CHIP CAPACITOR,0.1-25 A.C.................

CNA 1 8A-NF8-653-010 CONN ASSY,9P TID-A(480) ABC.................

D 19 87-A40-455-090 DIODE,RL203 GW ABC.................

D 17 87-A40-455-090 DIODE,RL203 GW ABC.................

D 18 87-A40-455-090 DIODE,RL203 GW ABC.................

D 13 87-A40-535-080 DIODE,1N5393-GOODARK A.C.................

D 16 87-A40-535-080 DIODE,1N5393-GOODARK A.C.................

D 15 87-A40-535-080 DIODE,1N5393-GOODARK A.C.................

D 14 87-A40-535-080 DIODE,1N5393-GOODARK A.C.................

D 20 87-A40-455-090 DIODE,RL203 GW ABC.................

D 26 87-A40-553-080 DIODE,1N4003 LES ABC.................

D 27 87-A40-553-080 DIODE,1N4003 LES ABC.................

D 29 87-A40-776-080 ZENER,UZ27BSD ABC.................

D 35 87-020-465-080 DIODE,1SS133 (110MA) ABC.................

D 30 87-020-465-080 DIODE,1SS133 (110MA) ABC.................

D 34 87-020-465-080 DIODE,1SS133 (110MA) ABC.................

D 31 87-A40-764-080 ZENER,UZ10BSC ABC.................

D 60 87-020-465-080 DIODE,1SS133 (110MA) ABC.................

D 64 87-A40-269-080 C-DIODE,MC2836 ABC.................

D 63 87-A40-270-080 C-DIODE,MC2838 ABC.................

D 65 87-A40-313-080 C-DIODE,MC 2840 ABC.................

D 66 87-A40-854-080 ZENER,UZ15BSA ABC.................

Q 2 87-026-609-080 TR,KTA1266GR ABC.................

Q 9 87-026-609-080 TR,KTA1266GR ABC.................

Q 1 87-026-609-080 TR,KTA1266GR ABC.................

Q 5 87-026-610-080 TR,KTC3198GR ABC.................

Q 8 87-A30-075-080 C-TR,2SA1235F ABC.................

Q 6 87-A30-076-080 C-TR,2SC3052F ABC.................

Q 4 89-213-702-010 TR,2SB1370 (1.8W) ABC.................

Q 10 87-A30-076-080 C-TR,2SC3052F ABC.................

Q 59 87-A30-107-070 C-TR,CMBT5401 ....................

Q 65 87-A30-074-080 C-TR,RT1P 141C ....................

Q 63 87-A30-075-080 C-TR,2SA1235F ABC.................

Q 61 87-A30-075-080 C-TR,2SA1235F ABC.................

Q 64 87-A30-076-080 C-TR,2SC3052F ABC.................

Q 62 87-A30-076-080 C-TR,2SC3052F ABC.................

Q 60 87-A30-076-080 C-TR,2SC3052F ABC.................

WH 1 87-A90-510-010 HLDR,WIRE 2.5-9P ABC.................

C 605 87-010-179-080 CAP,CHIP S B1200P A.C.................

C 606 87-010-179-080 CAP,CHIP S B1200P A.C.................

C 606 87-010-184-080 CHIP CAPACITOR 3300P(K) ....................

C 605 87-010-184-080 CHIP CAPACITOR 3300P(K) ....................

C 609 87-010-213-080 C-CAP,S 0.015-50 B A.C.................

C 615 87-010-154-080 CAP CHIP 10P A.C.................

C 610 87-010-213-080 C-CAP,S 0.015-50 B A.C.................

C 616 87-010-221-080 CAP, ELECT 470-10V A.C.................

C 617 87-010-221-080 CAP, ELECT 470-10V A.C.................

C 618 87-010-405-080 CAP, ELECT 10-50V A.C.................

C 611 87-010-545-080 CAP, ELECT 0.22-50V A.C.................

C 614 87-010-545-080 CAP, ELECT 0.22-50V A.C.................

C 613 87-010-545-080 CAP, ELECT 0.22-50V A.C.................

C 612 87-010-545-080 CAP, ELECT 0.22-50V A.C.................

C 632 87-010-185-080 C-CAP,S 3900P-50 B A.C.................

C 631 87-010-185-080 C-CAP,S 3900P-50 B A.C.................

C 633 87-016-369-080 C-CAP,S 0.033-25 B K A.C.................

C 634 87-016-369-080 C-CAP,S 0.033-25 B K A.C.................

C 630 87-016-669-080 C-CAP,S 0.1-25 K B A.C.................

C 669 87-010-322-080 C-CAP,S 100P-50 CH A.C.................

C 673 87-010-182-080 C-CAP,S 2200P-50 B A.C.................

C 671 87-010-196-080 CHIP CAPACITOR,0.1-25 A.C.................

C 672 87-010-196-080 CHIP CAPACITOR,0.1-25 A.C.................

C 677 87-010-197-080 CAP, CHIP 0.01 DM A.C.................

C 670 87-010-322-080 C-CAP,S 100P-50 CH A.C.................

CN 601 87-099-719-010 CONN,30P TYK-B(X) ABC.................

CN 602 87-A60-131-010 CONN,6P V FE ABC.................

D 601 87-A40-739-080 ZENER,UZ2.7BSA ABC.................

D 602 87-A40-739-080 ZENER,UZ2.7BSA ABC.................

IC 601 87-A21-401-040 C-IC,M61503FP ABC.................

J 602 87-A60-881-010 JACK,PIN 2P MSP 242V05 PBSN ABC.................

Q 607 87-A30-076-080 C-TR,2SC3052F ABC.................

Q 606 87-A30-090-080 FET,2SK2541 ABC.................

Q 605 87-A30-090-080 FET,2SK2541 ABC.................

R 654 87-A11-144-080 CAP,TC U 0.1-50 K B A.C.................

R 653 87-A11-144-080 CAP,TC U 0.1-50 K B A.C.................

C 102 87-010-196-080 CHIP CAPACITOR,0.1-25 .B..................

C 104 87-010-196-080 CHIP CAPACITOR,0.1-25 .B..................

C 101 87-010-196-080 CHIP CAPACITOR,0.1-25 .B..................

C 107 87-010-493-040 CAP,E 0.47-50 GAS .B..................

C 103 87-010-498-040 CAP,E 10-16 GAS .B..................

C 108 87-012-393-080 C-CAP,S 0.22-16 R K .B..................

C 153 87-010-198-080 CAP, CHIP 0.022 .B..................

C 154 87-010-246-040 CAP,E 47-35 SME .B..................

C 155 87-010-404-040 CAP,E 4.7-50 SME .B..................

C 156 87-010-404-040 CAP,E 4.7-50 SME .B..................

C 361 87-010-178-080 CHIP CAP 1000P .B..................

C 362 87-010-178-080 CHIP CAP 1000P .B..................

C 371 87-010-178-080 CHIP CAP 1000P .B..................

C 372 87-010-178-080 CHIP CAP 1000P .B..................

C 601 87-010-382-040 CAP,E 22-25 SME .B..................

C 801 87-010-195-080 C-CAP,S 0.068-25 F .B..................

C 802 87-010-195-080 C-CAP,S 0.068-25 F .B..................

C 805 87-010-196-080 CHIP CAPACITOR,0.1-25 .B..................

C 806 87-010-196-080 CHIP CAPACITOR,0.1-25 .B..................

C 803 87-010-402-040 CAP,E 2.2-50 SME .B..................

C 804 87-010-402-040 CAP,E 2.2-50 SME .B..................

C 810 87-010-379-040 CAP,E 22-16 M SME .B..................

C 902 87-010-322-080 C-CAP,S 100P-50 CH .B..................

C 907 87-010-322-080 C-CAP,S 100P-50 CH .B..................

C 903 87-010-322-080 C-CAP,S 100P-50 CH .B..................

C 901 87-010-322-080 C-CAP,S 100P-50 CH .B..................

C 908 87-010-322-080 C-CAP,S 100P-50 CH .B..................

C 905 87-010-322-080 C-CAP,S 100P-50 CH .B..................

C 904 87-010-322-080 C-CAP,S 100P-50 CH .B..................

C 906 87-010-322-080 C-CAP,S 100P-50 CH .B..................

C 909 87-010-322-080 C-CAP,S 100P-50 CH .B..................

C 911 87-010-178-080 CHIP CAP 1000P .B..................

C 912 87-010-196-080 CHIP CAPACITOR,0.1-25 .B..................

C 917 87-010-196-080 CHIP CAPACITOR,0.1-25 .B..................

C 915 87-010-196-080 CHIP CAPACITOR,0.1-25 .B..................

C 916 87-010-196-080 CHIP CAPACITOR,0.1-25 .B..................

C 919 87-010-197-080 CAP, CHIP 0.01 DM .B..................

C 913 87-010-248-040 CAP,E 220-10 SME .B..................

ELECTRICAL MAIN PARTS LIST - 5/8

C 914 87-010-248-040 CAP,E 220-10 SME .B..................

C 910 87-010-322-080 C-CAP,S 100P-50 CH .B..................

C 921 87-010-186-080 CAP,CHIP 4700P .B..................

C 920 87-012-369-080 C-CAP,S 0.047-50F .B..................

C 951 87-010-312-080 C-CAP,S 15P-50 CH .B..................

C 953 87-012-140-080 CAP 470P .B..................

C 952 87-012-155-080 C-CAP 180P-50CH .B..................

C 963 87-010-196-080 CHIP CAPACITOR,0.1-25 .B..................

C 961 87-010-378-040 CAP,E 10-16 .B..................

C 962 87-012-157-080 C-CAP,S 330P-50 CH .B..................

C 109 87-010-179-080 CAP,CHIP S B1200P A.C.................

C 101 87-010-185-080 C-CAP,S 3900P-50 B A.C.................

C 102 87-010-185-080 C-CAP,S 3900P-50 B A.C.................

C 106 87-010-187-080 CAP CHIP S5600P A.C.................

C 105 87-010-187-080 CAP CHIP S5600P A.C.................

C 107 87-010-404-080 CAP, ELECT 4.7-50V A.C.................

C 108 87-010-404-080 CAP, ELECT 4.7-50V A.C.................

C 104 87-010-545-080 CAP, ELECT 0.22-50V A.C.................

C 103 87-010-545-080 CAP, ELECT 0.22-50V A.C.................

C 110 87-010-179-080 CAP,CHIP S B1200P A.C.................

C 119 87-010-197-080 CAP, CHIP 0.01 DM A.C.................

C 112 87-010-391-080 CAP,E 10-35 SME A.C.................

C 111 87-010-391-080 CAP,E 10-35 SME A.C.................

C 114 87-010-866-080 CAP, ELECT 10-63 ....................

C 113 87-010-866-080 CAP, ELECT 10-63 ....................

C 119 87-012-369-080 C-CAP,S 0.047-50F ..C.................

C 119 87-016-369-080 C-CAP,S 0.033-25 B K A...................

C 114 87-A10-946-080 C-CAP,S 220P-100 J CH ....................

C 113 87-A10-946-080 C-CAP,S 220P-100 J CH ....................

C 129 87-010-191-080 C-CAP,S 0.015-50 F A.C.................

C 120 87-010-197-080 CAP, CHIP 0.01 DM A.C.................

C 126 87-012-368-080 C-CAP,S 0.1-50 F A.C.................

C 128 87-012-368-080 C-CAP,S 0.1-50 F A.C.................

C 125 87-012-368-080 C-CAP,S 0.1-50 F A.C.................

C 127 87-012-368-080 C-CAP,S 0.1-50 F A.C.................

C 120 87-012-369-080 C-CAP,S 0.047-50F ..C.................

C 120 87-016-369-080 C-CAP,S 0.033-25 B K A...................

C 133 87-010-186-080 CAP,CHIP 4700P A.C.................

C 130 87-010-191-080 C-CAP,S 0.015-50 F A.C.................

C 140 87-010-182-080 C-CAP,S 2200P-50 B A.C.................

C 186 87-010-196-080 CHIP CAPACITOR,0.1-25 A.C.................

C 187 87-010-405-080 CAP, ELECT 10-50V A.C.................

C 188 87-010-405-080 CAP, ELECT 10-50V A.C.................

D 150 87-A40-270-080 C-DIODE,MC2838 ABC.................

D 160 87-A40-270-080 C-DIODE,MC2838 ABC.................

D 189 87-A40-270-080 C-DIODE,MC2838 ABC.................

D 190 87-A40-269-080 C-DIODE,MC2836 ABC.................

IC 101 87-A21-398-010 IC,STK490-110 ABC.................

J 203 87-A60-238-010 TERMINAL,SP 4P (MSC) ABC.................

J 202 87-A60-488-010 JACK,DIA6.3 BLK ST W/SW KM16AT ABC.................

L 101 87-A50-610-010 COIL,1UH K(MDEC) ABC.................

L 102 87-A50-610-010 COIL,1UH K(MDEC) ABC.................

Q 124 87-A30-107-070 C-TR,CMBT5401 ABC.................

Q 123 87-A30-107-070 C-TR,CMBT5401 ABC.................

Q 126 87-A30-107-070 C-TR,CMBT5401 ABC.................

Q 130 87-A30-106-040 C-TR,CMBT5551 ABC.................

R 131 87-A00-669-080 RES,M/F 0.22-2W J RA ABC.................

R 132 87-A00-669-080 RES,M/F 0.22-2W J RA ABC.................

R 143 87-A00-440-050 RES,220-1/2W J RP A.C.................

R 144 87-A00-440-050 RES,220-1/2W J RP A.C.................

R 145 87-A00-440-050 RES,220-1/2W J RP A.C.................

R 146 87-A00-440-050 RES,220-1/2W J RP A.C.................

C 239 87-010-196-080 CHIP CAPACITOR,0.1-25 A.C.................

C 973 87-010-197-080 CAP, CHIP 0.01 DM .B..................

C 974 87-010-197-080 CAP, CHIP 0.01 DM .B..................

C 971 87-010-381-080 CAP, ELECT 330-16V .B..................

C 972 87-010-404-080 CAP, ELECT 4.7-50V .B..................

C 982 87-010-196-080 CHIP CAPACITOR,0.1-25 .B..................

C 987 87-010-197-080 CAP, CHIP 0.01 DM .B..................

C 983 87-010-197-080 CAP, CHIP 0.01 DM .B..................

C 984 87-010-197-080 CAP, CHIP 0.01 DM .B..................

C 981 87-010-260-080 CAP, ELECT 47-25V .B..................

C 995 87-010-178-080 CHIP CAP 1000P .B..................

C 993 87-010-178-080 CHIP CAP 1000P .B..................

C 997 87-010-196-080 CHIP CAPACITOR,0.1-25 .B..................

C 998 87-010-260-080 CAP, ELECT 47-25V .B..................

C 992 87-010-312-080 C-CAP,S 15P-50 CH .B..................

C 991 87-010-312-080 C-CAP,S 15P-50 CH .B..................

C 999 87-A11-155-080 CAP,TC U 0.01-16 Z F .B..................

R 991 87-010-322-080 C-CAP,S 100P-50 CH .B..................

R 993 87-010-322-080 C-CAP,S 100P-50 CH .B..................

R 995 87-010-322-080 C-CAP,S 100P-50 CH .B..................

C 771 87-010-263-080 CAP, ELECT 100-10V .B..................

C 788 87-010-149-080 C-CAP,S 5P-50 CH .B..................

C 789 87-A12-052-080 C-CAP,S 0.033-25 J B .B..................

C 791 87-010-196-080 CHIP CAPACITOR,0.1-25 .B..................

C 793 87-010-404-080 CAP, ELECT 4.7-50V .B..................

ELECTRICAL MAIN PARTS LIST - 6/8

C 797 87-010-405-080 CAP, ELECT 10-50V .B..................

C 799 87-010-407-080 CAP, ELECT 33-50V .B..................

C 790 87-A12-052-080 C-CAP,S 0.033-25 J B .B..................

C 802 87-010-194-080 CAP, CHIP 0.047 .B..................

C 803 87-010-198-080 CAP, CHIP 0.022 .B..................

C 804 87-010-263-080 CAP, ELECT 100-10V .B..................

C 807 87-010-400-080 CAP, ELECT 0.47-50V .B..................

C 808 87-010-401-080 CAP, ELECT 1-50V .B..................

C 809 87-010-401-080 CAP, ELECT 1-50V .B..................

C 801 87-010-403-080 CAP, ELECT 3.3-50V .B..................

C 800 87-012-369-080 C-CAP,S 0.047-50F .B..................

C 810 87-010-196-080 CHIP CAPACITOR,0.1-25 .B..................

C 816 87-010-400-080 CAP, ELECT 0.47-50V .B..................

C 815 87-010-400-080 CAP, ELECT 0.47-50V .B..................

C 823 87-010-177-080 C-CAP,S 820P-50 SL .B..................

C 824 87-010-404-080 CAP, ELECT 4.7-50V .B..................

C 821 87-010-405-080 CAP, ELECT 10-50V .B..................

C 825 87-010-596-080 CAP, S 0.047-16 .B..................

R 790 87-010-197-080 CAP, CHIP 0.01 DM .B..................

C 842 87-010-197-080 CAP, CHIP 0.01 DM .B..................

C 844 87-010-197-080 CAP, CHIP 0.01 DM .B..................

C 858 87-010-196-080 CHIP CAPACITOR,0.1-25 .B..................

C 859 87-010-196-080 CHIP CAPACITOR,0.1-25 .B..................

C 852 87-010-197-080 CAP, CHIP 0.01 DM .B..................

C 851 87-010-197-080 CAP, CHIP 0.01 DM .B..................

C 853 87-010-197-080 CAP, CHIP 0.01 DM .B..................

C 850 87-010-260-080 CAP, ELECT 47-25V .B..................

C 860 87-010-197-080 CAP, CHIP 0.01 DM .B..................

C 959 87-010-196-080 CHIP CAPACITOR,0.1-25 .B..................

C 961 87-010-152-080 C-CAP,S 8P-50 CH .B..................

C 963 87-015-785-080 CHIP CAPACITOR, 0.1FZ-25Z .B..................

C 4 87-012-368-080 C-CAP,S 0.1-50 F .B..................

C 6 87-012-368-080 C-CAP,S 0.1-50 F .B..................

C 5 87-012-368-080 C-CAP,S 0.1-50 F .B..................

C 3 87-012-368-080 C-CAP,S 0.1-50 F .B..................

C 9 87-012-368-080 C-CAP,S 0.1-50 F .B..................

C 10 87-012-368-080 C-CAP,S 0.1-50 F .B..................

C 11 87-012-368-080 C-CAP,S 0.1-50 F .B..................

C 12 87-012-368-080 C-CAP,S 0.1-50 F .B..................

C 19 87-A12-036-000 CAP,E 2200-63 SMG .B..................

C 26 87-010-247-080 CAP, ELECT 100-50V .B..................

C 25 87-010-385-080 CAP, ELECT 220-25V .B..................

C 22 87-A10-520-000 CAP,E 3300-35 M SMG .B..................

C 21 87-A10-520-000 CAP,E 3300-35 M SMG .B..................

C 20 87-A12-036-000 CAP,E 2200-63 SMG .B..................

C 32 87-010-197-080 CAP, CHIP 0.01 DM .B..................

C 38 87-010-197-080 CAP, CHIP 0.01 DM .B..................

C 34 87-010-247-080 CAP, ELECT 100-50V .B..................

C 31 87-010-263-080 CAP, ELECT 100-10V .B..................

C 35 87-010-380-080 CAP, ELECT 47-16V .B..................

C 36 87-010-381-080 CAP, ELECT 330-16V .B..................

C 30 87-010-430-080 CAP, ELECT 100-63 .B..................

C 61 87-010-260-080 CAP, ELECT 47-25V .B..................

C 60 87-010-403-080 CAP, ELECT 3.3-50V .B..................

C 97 87-010-196-080 CHIP CAPACITOR,0.1-25 .B..................

C 302 87-010-178-080 CHIP CAP 1000P .B..................

C 301 87-010-178-080 CHIP CAP 1000P .B..................

C 303 87-010-178-080 CHIP CAP 1000P .B..................

C 304 87-010-178-080 CHIP CAP 1000P .B..................

C 307 87-010-263-080 CAP, ELECT 100-10V .B..................

C 308 87-010-263-080 CAP, ELECT 100-10V .B..................

C 309 87-010-318-080 C-CAP,S 47P-50 CH .B..................

C 314 87-010-188-080 CAP,CHIP 6800P .B..................

C 313 87-010-188-080 CAP,CHIP 6800P .B..................

C 315 87-010-263-080 CAP, ELECT 100-10V .B..................

C 310 87-010-318-080 C-CAP,S 47P-50 CH .B..................

C 317 87-010-546-080 CAP, ELECT 0.33-50V .B..................

C 318 87-010-546-080 CAP, ELECT 0.33-50V .B..................

C 326 87-010-198-080 CAP, CHIP 0.022 .B..................

C 327 87-012-368-080 C-CAP,S 0.1-50 F .B..................

C 360 87-010-401-080 CAP, ELECT 1-50V .B..................

C 399 87-012-140-080 CAP 470P .B..................

C 409 87-010-182-080 C-CAP,S 2200P-50 B .B..................

C 406 87-010-197-080 CAP, CHIP 0.01 DM .B..................

C 407 87-010-197-080 CAP, CHIP 0.01 DM .B..................

C 408 87-010-197-080 CAP, CHIP 0.01 DM .B..................

C 405 87-010-197-080 CAP, CHIP 0.01 DM .B..................

C 404 87-010-321-080 CHIP CAPACITOR,82P(J) .B..................

C 403 87-010-321-080 CHIP CAPACITOR,82P(J) .B..................

C 402 87-010-544-080 CAP, ELECT 0.1-50V .B..................

C 401 87-010-544-080 CAP, ELECT 0.1-50V .B..................

C 410 87-010-182-080 C-CAP,S 2200P-50 B .B..................

C 411 87-010-405-080 CAP, ELECT 10-50V .B..................

C 412 87-010-405-080 CAP, ELECT 10-50V .B..................

C 453 87-010-183-080 C-CAP,S 2700P-50 B .B..................

C 455 87-010-183-080 C-CAP,S 2700P-50 B .B..................

C 454 87-010-183-080 C-CAP,S 2700P-50 B .B..................

ELECTRICAL MAIN PARTS LIST - 7/8

C 456 87-010-197-080 CAP, CHIP 0.01 DM .B..................

C 452 87-010-382-080 CAP, ELECT 22-25V .B..................

C 460 87-010-196-080 CHIP CAPACITOR,0.1-25 .B..................

C 461 87-012-158-080 C-CAP,S 390P-50 CH .B..................

C 462 87-012-158-080 C-CAP,S 390P-50 CH .B..................

C 470 87-018-127-080 CAP, CER 470P-50V .B..................

C 605 87-010-184-080 CHIP CAPACITOR 3300P(K) .B..................

C 606 87-010-184-080 CHIP CAPACITOR 3300P(K) .B..................

C 609 87-010-213-080 C-CAP,S 0.015-50 B .B..................

C 615 87-010-154-080 CAP CHIP 10P .B..................

C 610 87-010-213-080 C-CAP,S 0.015-50 B .B..................

C 616 87-010-221-080 CAP, ELECT 470-10V .B..................

C 617 87-010-221-080 CAP, ELECT 470-10V .B..................

C 618 87-010-405-080 CAP, ELECT 10-50V .B..................

C 612 87-010-545-080 CAP, ELECT 0.22-50V .B..................

C 613 87-010-545-080 CAP, ELECT 0.22-50V .B..................

C 611 87-010-545-080 CAP, ELECT 0.22-50V .B..................

C 614 87-010-545-080 CAP, ELECT 0.22-50V .B..................

C 632 87-010-185-080 C-CAP,S 3900P-50 B .B..................

C 631 87-010-185-080 C-CAP,S 3900P-50 B .B..................

C 633 87-016-369-080 C-CAP,S 0.033-25 B K .B..................

C 634 87-016-369-080 C-CAP,S 0.033-25 B K .B..................

C 630 87-016-669-080 C-CAP,S 0.1-25 K B .B..................

C 669 87-010-322-080 C-CAP,S 100P-50 CH .B..................

C 677 87-010-197-080 CAP, CHIP 0.01 DM .B..................

C 670 87-010-322-080 C-CAP,S 100P-50 CH .B..................

R 654 87-A11-144-080 CAP,TC U 0.1-50 K B .B..................

R 653 87-A11-144-080 CAP,TC U 0.1-50 K B .B..................

C 109 87-010-179-080 CAP,CHIP S B1200P .B..................

C 102 87-010-185-080 C-CAP,S 3900P-50 B .B..................

C 101 87-010-185-080 C-CAP,S 3900P-50 B .B..................

C 105 87-010-187-080 CAP CHIP S5600P .B..................

C 106 87-010-187-080 CAP CHIP S5600P .B..................

C 108 87-010-404-080 CAP, ELECT 4.7-50V .B..................

C 107 87-010-404-080 CAP, ELECT 4.7-50V .B..................

C 103 87-010-545-080 CAP, ELECT 0.22-50V .B..................

C 104 87-010-545-080 CAP, ELECT 0.22-50V .B..................

C 110 87-010-179-080 CAP,CHIP S B1200P .B..................

C 111 87-010-391-080 CAP,E 10-35 SME .B..................

C 112 87-010-391-080 CAP,E 10-35 SME .B..................

C 113 87-010-866-080 CAP, ELECT 10-63 .B..................

C 114 87-010-866-080 CAP, ELECT 10-63 .B..................

C 119 87-016-369-080 C-CAP,S 0.033-25 B K .B..................

C 129 87-010-191-080 C-CAP,S 0.015-50 F .B..................

C 127 87-012-368-080 C-CAP,S 0.1-50 F .B..................

C 126 87-012-368-080 C-CAP,S 0.1-50 F .B..................

C 125 87-012-368-080 C-CAP,S 0.1-50 F .B..................

C 128 87-012-368-080 C-CAP,S 0.1-50 F .B..................

C 120 87-016-369-080 C-CAP,S 0.033-25 B K .B..................

C 133 87-010-186-080 CAP,CHIP 4700P .B..................

C 130 87-010-191-080 C-CAP,S 0.015-50 F .B..................

C 132 87-010-197-080 CAP, CHIP 0.01 DM .B..................

C 131 87-010-197-080 CAP, CHIP 0.01 DM .B..................

C 140 87-010-182-080 C-CAP,S 2200P-50 B .B..................

C 141 87-010-196-080 CHIP CAPACITOR,0.1-25 .B..................

R 145 87-A00-440-050 RES,220-1/2W J RP .B..................

R 144 87-A00-440-050 RES,220-1/2W J RP .B..................

R 143 87-A00-440-050 RES,220-1/2W J RP .B..................

R 146 87-A00-440-050 RES,220-1/2W J RP .B..................

C 239 87-010-196-080 CHIP CAPACITOR,0.1-25 .B..................

C 1 87-010-387-080 CAP,E 470-25 SME .B..................

C 31 87-010-403-080 CAP, ELECT 3.3-50V .B..................

ELECTRICAL MAIN PARTS LIST - 8/8

MECHANICAL PARTS LIST - 1/2

NOTE: The characters in the suffix column indicate the part usage.

HS .....................XX..................................A...................

LH .....................XX...................................B..................

HT .....................XX....................................C.................

KANRI

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

87-CE3-023-010 BADGE,AIWA 30N SILV ABC.................

8A-NF8-005-010 PANEL,TOP ABC.................

8A-NF8-007-010 PANEL,LEFT V-2 ABC.................

8A-NF8-008-010 PANEL,RIGHT V-2 ABC.................

8A-NF9-001-010 CABI,FR U .B..................

8A-NF9-003-010 BOX,CASS 1 .B..................

8A-NF9-004-010 BOX,CASS 2 ABC.................

8A-NF9-014-010 PANEL,TRAY ABC.................

8A-NF9-017-010 PANEL,JOG ABC.................

8A-NF9-047-010 BOX,CASS 1 H A.C.................

8A-NFX-001-110 CABI,REAR LHSM ....................

8A-NFX-003-110 CABI,REAR HRJSM ....................

8A-NFX-004-110 CABI,REAR LHFD ....................

8A-NFX-005-110 CABI,REAR LH W/O SPEC .B..................

8A-NFX-006-010 CABI,FR H A.C.................

8A-NFX-007-110 CABI,REAR HRSM ....................

8A-NFX-008-110 CABI,REAR HS W/O SPEC A...................

8A-NFX-018-010 CABI,REAR HR W/O SPEC ..C.................

8A-NF9-008-010 KEY,POWER ABC.................

8A-NF9-009-010 KEY,FUN ABC.................

8A-NF9-010-110 KEY,ASSY OPE 1 WAY .B..................

8A-NF9-015-010 KNOB,RTRY MIC A.C.................

8A-NF9-016-010 KNOB,RTRY VOL ABC.................

8A-NF9-018-010 KNOB,RTRY JOG ABC.................

8A-NF9-019-010 KEY,SYNC ABC.................

8A-NF9-020-010 KEY,CD AB..................

8A-NF9-020-110 KEY,CD ..C.................

8A-NF9-022-010 REFLECTOR,ECO ABC.................

8A-NF9-023-010 KEY,ASSY OPE REV A.C.................

8A-NF9-026-110 KEY,ENTER ABC.................

81-532-080-010 LABEL, CASS. COMPT ABC.................

8A-NF8-006-010 WINDOW,TOP ABC.................

8A-NF9-006-010 WINDOW,CASS 1 ABC.................

8A-NF9-007-010 WINDOW,CASS 2 ABC.................

8A-NF9-021-010 PLATE,MIC A.C.................

8A-NF9-039-010 WINDOW,CD ABC.................

8A-NFX-002-010 WINDOW,DISP LH A.C.................

8A-NFX-015-010 WINDOW,DISP HA KIT ....................

8A-NFX-016-010 WINDOW,DISP LH KIT .B..................

84-ZG1-245-210 CAP,OPTICAL ABC.................

82-NF5-229-010 PLATE,LOCK ABC.................

86-NF6-211-010 HLDR,IC T1.6 .B..................

86-NF9-224-010 SPR-C,LOCK ABC.................

87-NF4-216-010 HLDR,LOCK 1 ABC.................

87-NF4-217-110 HLDR,LOCK 2 ABC.................

87-NF4-221-010 HLDR,CABLE ABC.................

8A-NF8-205-010 HLDR,IC A.C.................

8A-NF8-206-010 HLDR,PWB M ABC.................

8A-NF8-207-010 SPR-T,EJECT 1 ABC.................

8A-NF8-208-010 SPR-T,EJECT 2 ABC.................

8A-NF8-209-010 OIL-DMPR,120 ABC.................

8A-NF8-216-010 HLDR,IC C ....................

8A-NF9-211-010 HLDR,PWB PT HI ABC.................

8Z-NB8-240-010 COVER, PL ABC.................

87-067-581-010 TAPPING SCREW, BVT2+3-15 A.C.................

87-067-641-010 UTT2+3-8(W/O SLOT)BL A.C.................

87-067-689-010 TAPPING SCREW, BVTT+3-8 A.C.................

87-067-703-010 TAPPING SCREW, BVT2+3-10 A.C.................

87-078-191-010 S-SCREW,IT+4-10 ABC.................

87-721-096-410 QT2+3-10 GLD A.C.................

87-721-097-410 QT2+3-12 GLD A.C.................

87-723-096-410 QT2+3-10W/O SLOT BL A.C.................

87-NF4-224-010 S-SCREW,IT3B+3-8 CU ABC.................

87-067-581-010 TAPPING SCREW, BVT2+3-15 .B..................

87-067-641-010 UTT2+3-8(W/O SLOT)BL .B..................

87-067-689-010 TAPPING SCREW, BVTT+3-8 .B..................

87-067-703-010 TAPPING SCREW, BVT2+3-10 .B..................

87-721-096-410 QT2+3-10 GLD .B..................

87-721-097-410 QT2+3-12 GLD .B..................

87-723-096-410 QT2+3-10W/O SLOT BL .B..................

82-NF7-210-110 GUIDE,FL (*) ABC.................

8A-NF9-201-010 GUIDE,OPE 1 WAY .B..................

8A-NF9-203-010 GUIDE,OPE REV A.C.................

87-067-703-010 TAPPING SCREW, BVT2+3-10 ....................

87-085-185-010 BUSHING, AC CORD (E) ABC.................

88-906-251-110 FF-CABLE,6P 1.25 ABC.................

88-911-101-110 FF-CABLE,11P 1.25 ABC.................

88-913-301-110 FF-CABLE,13P-1.25 ABC.................

PT 1 8A-NF9-614-010 PT,ANF-9 HR-HI A.C.................

Other manuals for NSX-SZ30

This manual suits for next models

Table of contents

Popular Car Receiver manuals by other brands

Linear Series

Linear Series LS5050 Operation and installation manual

Kenwood

Kenwood KRC-160 instruction manual

Sony

Sony XR-CA430X Service manual

T+A Elektroakustik

T+A Elektroakustik K1 CD-RECEIVER operating instructions

SoundMax

SoundMax SM-CDM1052 instruction manual

Xtrons

Xtrons HD107HD user manual

Mopar

Mopar RB3 manual

Clarion

Clarion ADDZEST DMZ615 owner's manual

Sony

Sony XAV-601BT Specifications

PIE

PIE GM12-POD/S Operation manual

Hyundai

Hyundai H-910H instruction manual

Sony

Sony XR-C6100 Service manual

Sony

Sony CDX-L600X - Fm/am Compact Disc Player Installation/connections

Motorola

Motorola VWA63 Service manual

Sound Storm

Sound Storm STM93R user manual

Nextar

Nextar D3201 instruction manual

Alpine

Alpine CDE-163BT owner's manual

Kenwood

Kenwood KDC-X303 quick start guide

Aiwa NSX-SZ30 User manual

Popular Car Receiver manuals by other brands
