SERVICE MANUAL

DATA

CDC-R507M

STEREO CAR CD RECEIVER

SIMPLE

S/M Code No. 09-003-431-3T1

• Replace this Service manual with “Revision Publishing” when it is issued.

BASIC CD MECHANISM : AZA-2 MCHNF

ELECTRICAL MAIN PARTS LIST - 1 / 4

NOTE: The characters in the suffix column indicate the part usage.

MYZSTF .................XX..................................A...................

KANRI

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

C 907 87-010-178-080 CHIP CAP 1000P A...................

C 908 87-010-178-080 CHIP CAP 1000P A...................

C 906 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 903 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 909 87-010-198-080 CAP, CHIP 0.022 A...................

C 905 87-010-314-080 C-CAP,S 22P-50V A...................

C 904 87-010-315-080 C-CAP,S 27P-50 CH A...................

C 902 87-012-358-080 C-CAP,S 0.47-10 F Z A...................

C 901 87-016-039-090 CAP,DL 0.022F-5.5 Z 70 FM A...................

C 912 87-010-198-080 CAP, CHIP 0.022 A...................

C 916 87-010-198-080 CAP, CHIP 0.022 A...................

C 914 87-010-198-080 CAP, CHIP 0.022 A...................

C 913 87-010-198-080 CAP, CHIP 0.022 A...................

C 910 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 911 87-010-322-080 C-CAP,S 100P-50 CH A...................

D 905 87-020-331-080 CHIP-DIODE,DAN202K A...................

D 904 87-020-331-080 CHIP-DIODE,DAN202K A...................

D 907 87-020-331-080 CHIP-DIODE,DAN202K A...................

D 909 87-027-262-010 LEDE,TLR-124(RED) A...................

IC 903 87-020-784-080 IC,TC4053BF A...................

IC 901 87-A21-528-030 C-IC,UPD178018A-XXX A...................

S 901 87-A91-070-010 SW,TACT SKHHLV A...................

X 901 87-A70-175-010 VIB,XTAL 4.5MHZ AT-49 A...................

ANT 101 8Z-KT1-614-010 ANT,AW-002 A...................

C 101 87-010-178-080 CHIP CAP 1000P A...................

C 104 87-010-186-080 CAP,CHIP 4700P A...................

C 102 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 109 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 107 87-010-198-080 CAP, CHIP 0.022 A...................

C 106 87-010-198-080 CAP, CHIP 0.022 A...................

C 103 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 105 87-010-490-040 CAP, ELECT 0.1-50 A...................

C 108 87-018-131-080 CAP, CER 1000P-50V A...................

C 111 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 116 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 118 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 113 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 117 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 112 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 119 87-010-495-040 CAP,E 2.2-50 GAS A...................

C 120 87-010-185-080 C-CAP,S 3900P-50 B A...................

C 124 87-012-358-080 C-CAP,S 0.47-10 F Z A...................

C 123 87-012-358-080 C-CAP,S 0.47-10 F Z A...................

C 122 87-012-365-080 C-CAP,S 0.027-25VBK A...................

C 121 87-012-365-080 C-CAP,S 0.027-25VBK A...................

D 101 87-A40-250-080 C-DIODE,DAN217 A...................

L 107 87-003-143-080 COIL 4.7 UH A...................

L 102 8Z-KT1-619-010 COIL,68MH K7-D A...................

Q 104 87-A30-287-040 C-TR,DTC114TKA A...................

Q 101 87-A30-287-040 C-TR,DTC114TKA A...................

Q 102 87-A30-289-040 C-TR,2SA1037AK(R) A...................

Q 106 89-324-122-080 TR,2SC2412K A...................

Q 109 89-324-122-080 TR,2SC2412K A...................

Q 105 89-324-122-080 TR,2SC2412K A...................

Q 108 89-324-122-080 TR,2SC2412K A...................

Q 103 89-324-122-080 TR,2SC2412K A...................

SFR 101 87-024-437-080 SFR100K,RH063EC A...................

TU 101 8A-KC8-620-010 TU UNIT, FAE347-A11 A...................

C 155 87-010-175-080 CAP 560P A...................

C 156 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 152 87-010-315-080 C-CAP,S 27P-50 CH A...................

C 153 87-010-495-040 CAP,E 2.2-50 GAS A...................

C 157 87-010-553-040 CAP,E 47-16 GAS A...................

C 151 87-012-149-080 C-CAP,S 30P-50 CH A...................

C 154 87-012-157-080 C-CAP,S 330P-50 CH A...................

D 151 87-070-136-080 ZENER,MTZJ5.1B A...................

IC 151 88-KT1-607-080 C-IC,SAA6579T A...................

L 151 87-003-147-080 COIL, 22UH A...................

X 151 87-A70-091-010 VIB,XTAL 4.332MHZ CSA-309 A...................

C 305 87-010-184-080 CHIP CAPACITOR 3300P(K) A...................

C 306 87-010-184-080 CHIP CAPACITOR 3300P(K) A...................

C 308 87-010-198-080 CAP, CHIP 0.022 A...................

C 307 87-010-198-080 CAP, CHIP 0.022 A...................

C 304 87-010-805-080 CAP, S 1-16 A...................

C 303 87-010-805-080 CAP, S 1-16 A...................

C 309 87-012-358-080 C-CAP,S 0.47-10 F Z A...................

C 301 87-012-358-080 C-CAP,S 0.47-10 F Z A...................

C 302 87-012-358-080 C-CAP,S 0.47-10 F Z A...................

C 317 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 318 87-010-498-040 CAP,E 10-16 GAS A...................

C 310 87-012-358-080 C-CAP,S 0.47-10 F Z A...................

ELECTRICAL MAIN PARTS LIST - 2 / 4

C 315 87-012-358-080 C-CAP,S 0.47-10 F Z A...................

C 316 87-012-358-080 C-CAP,S 0.47-10 F Z A...................

C 313 87-A11-177-080 C-CAP,S 0.15-16 K B A...................

C 314 87-A11-177-080 C-CAP,S 0.15-16 K B A...................

C 312 87-A11-177-080 C-CAP,S 0.15-16 K B A...................

C 311 87-A11-177-080 C-CAP,S 0.15-16 K B A...................

C 322 87-010-198-080 CAP, CHIP 0.022 A...................

C 321 87-010-555-040 CAP,E 100-10 GAS A...................

C 336 87-010-491-040 CAP,E 0.22-50 GAS A...................

C 335 87-010-491-040 CAP,E 0.22-50 GAS A...................

C 334 87-010-498-040 CAP,E 10-16 GAS A...................

C 333 87-010-498-040 CAP,E 10-16 GAS A...................

C 332 87-010-498-040 CAP,E 10-16 GAS A...................

C 331 87-010-498-040 CAP,E 10-16 GAS A...................

C 338 87-010-805-080 CAP, S 1-16 A...................

C 337 87-010-805-080 CAP, S 1-16 A...................

C 339 87-010-805-080 CAP, S 1-16 A...................

C 340 87-010-805-080 CAP, S 1-16 A...................

C 343 87-012-140-080 CAP 470P A...................

C 342 87-012-140-080 CAP 470P A...................

C 341 87-012-140-080 CAP 470P A...................

C 344 87-012-140-080 CAP 470P A...................

IC 301 8Z-KT1-622-010 C-IC,LC75374E A...................

J 401 87-A61-225-010 JACK,PIN 2P XR-401 A...................

L 301 87-003-102-080 COIL, 10UH A...................

Q 301 87-A30-287-040 C-TR,DTC114TKA A...................

Q 302 87-A30-287-040 C-TR,DTC114TKA A...................

Q 303 87-A30-287-040 C-TR,DTC114TKA A...................

Q 304 87-A30-287-040 C-TR,DTC114TKA A...................

Q 405 87-A30-287-040 C-TR,DTC114TKA A...................

Q 406 87-A30-287-040 C-TR,DTC114TKA A...................

C 506 87-010-178-080 CHIP CAP 1000P A...................

C 507 87-010-178-080 CHIP CAP 1000P A...................

C 508 87-010-178-080 CHIP CAP 1000P A...................

C 505 87-010-178-080 CHIP CAP 1000P A...................

C 509 87-010-805-080 CAP, S 1-16 A...................

C 502 87-012-358-080 C-CAP,S 0.47-10 F Z A...................

C 504 87-012-358-080 C-CAP,S 0.47-10 F Z A...................

C 503 87-012-358-080 C-CAP,S 0.47-10 F Z A...................

C 501 87-012-358-080 C-CAP,S 0.47-10 F Z A...................

C 514 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 516 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 511 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 517 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 513 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 518 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 515 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 512 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 519 87-010-494-040 CAP,E 1-50 GAS A...................

C 510 87-010-498-040 CAP,E 10-16 GAS A...................

D 505 87-001-783-080 DIODE,1N4002 A...................

D 506 87-001-783-080 DIODE,1N4002 A...................

D 507 87-001-783-080 DIODE,1N4002 A...................

D 503 87-001-783-080 DIODE,1N4002 A...................

D 508 87-001-783-080 DIODE,1N4002 A...................

D 501 87-001-783-080 DIODE,1N4002 A...................

D 504 87-001-783-080 DIODE,1N4002 A...................

D 502 87-001-783-080 DIODE,1N4002 A...................

IC 501 87-A21-562-010 IC,LA4743B A...................

C 209 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 208 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 207 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 206 87-010-198-080 CAP, CHIP 0.022 A...................

C 205 87-010-553-040 CAP,E 47-16 GAS A...................

C 202 87-012-358-080 C-CAP,S 0.47-10 F Z A...................

C 219 87-010-182-080 C-CAP,S 2200P-50 B A...................

C 217 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 213 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 214 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 218 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 212 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 211 87-010-198-080 CAP, CHIP 0.022 A...................

C 216 87-010-198-080 CAP, CHIP 0.022 A...................

C 252 87-010-182-080 C-CAP,S 2200P-50 B A...................

C 251 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 801 8A-KC7-623-000 CAP,E 2200U-16 BT(125C) A...................

D 209 87-017-932-080 ZENER,MTJ6.2B A...................

D 206 87-020-330-080 DIODE,DAP202K A...................

D 207 87-A40-002-080 ZENER,MTZJ5.1C A...................

D 205 87-A40-509-080 ZENER,MTZJ6.8C A...................

D 204 87-A40-523-080 ZENER,MTZJ9.1B A...................

D 201 87-A40-649-080 ZENER,MTZJ11A A...................

D 208 87-A40-650-080 ZENER,MTZJ6.8A A...................

D 212 87-070-136-080 ZENER,MTZJ5.1B A...................

D 255 87-070-136-080 ZENER,MTZJ5.1B A...................

D 251 87-A40-798-010 DIODE,1N5402 (3A/200V) A...................

F 251 8Z-KC1-621-010 FUSE,15A 32V A...................

ELECTRICAL MAIN PARTS LIST - 3 / 4

IC 201 88-KT1-606-080 IC,PST994D A...................

L 202 87-003-102-080 COIL, 10UH A...................

L 201 87-003-102-080 COIL, 10UH A...................

L 251 8Z-KT1-615-010 FLTR,AMORPHOUS -CHOKE A...................

Q 208 87-A30-287-040 C-TR,DTC114TKA A...................

Q 204 87-A30-287-040 C-TR,DTC114TKA A...................

Q 207 87-A30-289-040 C-TR,2SA1037AK(R) A...................

Q 205 87-A30-290-010 TR,KTA1658(Y) A...................

Q 201 87-A30-290-010 TR,KTA1658(Y) A...................

Q 206 87-A30-291-010 TR,KTC4369(Y) A...................

Q 203 89-324-122-080 TR,2SC2412K A...................

Q 202 89-324-122-080 TR,2SC2412K A...................

Q 209 89-418-580-080 TR,2SD1858 TV2 A...................

Q 211 87-A30-287-040 C-TR,DTC114TKA A...................

Q 210 87-A30-287-040 C-TR,DTC114TKA A...................

Q 213 89-423-953-010 TR,2SD2395F A...................

8A-KT1-631-010 CONN ASSY,8P ISO-BLACK-A A...................

8A-KT1-632-010 CONN ASSY,8P ISO-WHITE-A A...................

C 406 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 405 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 404 87-010-198-080 CAP, CHIP 0.022 A...................

C 407 87-012-358-080 C-CAP,S 0.47-10 F Z A...................

C 408 87-012-358-080 C-CAP,S 0.47-10 F Z A...................

C 403 87-012-358-080 C-CAP,S 0.47-10 F Z A...................

C 402 87-012-358-080 C-CAP,S 0.47-10 F Z A...................

C 409 87-012-358-080 C-CAP,S 0.47-10 F Z A...................

C 410 87-012-358-080 C-CAP,S 0.47-10 F Z A...................

CON 401 87-A61-219-010 CONN,20P H 52089-2020 A...................

CON 402 88-KTA-603-010 CONN,15P CAM-B68 A...................

D 408 87-A40-337-080 ZENER,MTZJ 6.8B A...................

D 405 87-A40-337-080 ZENER,MTZJ 6.8B A...................

D 407 87-A40-337-080 ZENER,MTZJ 6.8B A...................

D 409 87-A40-337-080 ZENER,MTZJ 6.8B A...................

D 406 87-A40-337-080 ZENER,MTZJ 6.8B A...................

D 402 87-A40-817-040 C-ZENER,STZ6.8N A...................

D 404 87-A40-817-040 C-ZENER,STZ6.8N A...................

D 403 87-A40-817-040 C-ZENER,STZ6.8N A...................

D 411 87-A40-337-080 ZENER,MTZJ 6.8B A...................

D 410 87-A40-337-080 ZENER,MTZJ 6.8B A...................

D 412 87-A40-337-080 ZENER,MTZJ 6.8B A...................

J 402 8A-KC7-620-010 JACK,DIN 13 P SKDS1302 A...................

L 401 87-003-102-080 COIL, 10UH A...................

L 402 87-003-102-080 COIL, 10UH A...................

Q 403 87-A30-283-040 C-TR,DTA114YKA A...................

Q 404 87-A30-287-040 C-TR,DTC114TKA A...................

C 401 87-010-553-040 CAP,E 47-16 GAS A...................

C 454 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 452 87-012-358-080 C-CAP,S 0.47-10 F Z A...................

C 453 87-012-358-080 C-CAP,S 0.47-10 F Z A...................

C 451 87-012-358-080 C-CAP,S 0.47-10 F Z A...................

D 401 87-020-331-080 CHIP-DIODE,DAN202K A...................

D 451 87-A40-250-080 C-DIODE,DAN217 A...................

JW 29 88-100-000-080 JUMPER WIRE,PLATING A...................

Q 401 87-A30-283-040 C-TR,DTA114YKA A...................

Q 402 87-A30-287-040 C-TR,DTC114TKA A...................

Q 451 89-324-122-080 TR,2SC2412K A...................

Q 851 87-A30-287-040 C-TR,DTC114TKA A...................

Q 852 89-113-625-080 TR,2SA1362GR(120MHZ,0. A...................

8A-KC7-611-010 F-CABLE,3P (AUX) A...................

C 953 87-010-176-080 C-CAP,S 680P-50 SL A...................

C 956 87-010-194-080 CAP, CHIP 0.047 A...................

C 955 87-010-194-080 CAP, CHIP 0.047 A...................

C 954 87-010-194-080 CAP, CHIP 0.047 A...................

C 959 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 958 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 952 87-012-358-080 C-CAP,S 0.47-10 F Z A...................

C 957 87-012-358-080 C-CAP,S 0.47-10 F Z A...................

C 951 87-012-358-080 C-CAP,S 0.47-10 F Z A...................

C 960 87-010-194-080 CAP, CHIP 0.047 A...................

CON 951 88-KTA-602-010 CONN,15P CAM-B67 A...................

D 951 87-A40-817-040 C-ZENER,STZ6.8N A...................

D 952 87-A40-817-040 C-ZENER,STZ6.8N A...................

D 953 87-A40-817-040 C-ZENER,STZ6.8N A...................

IC 952 87-A90-951-010 RCR UNIT,SBX1971-52 A...................

IC 951 88-KT1-608-010 C-IC,LC75854W A...................

J 951 85-HRL-623-010 JACK,3.5 ST BLK A...................

L 952 87-005-906-080 C-COIL,S 10.0UHK A...................

L 951 87-005-906-080 C-COIL,S 10.0UHK A...................

L 953 87-005-906-080 C-COIL,S 10.0UHK A...................

LCD 951 8A-KC3-610-010 LCD,AKC-3/4(2COLOR) A...................

LCD 951 8A-KC3-611-010 LCD,AKC-3/4(NO COLOR) ....................

LED 952 87-017-827-070 C-LED,SEC 1201C RED A...................

LED 951 87-017-827-070 C-LED,SEC 1201C RED A...................

LED 953 87-017-827-070 C-LED,SEC 1201C RED A...................

LED 954 87-A40-813-040 C-LED,SEC1E01C BLUE A...................

LED 955 87-A40-813-040 C-LED,SEC1E01C BLUE A...................

LED 956 87-A40-813-040 C-LED,SEC1E01C BLUE A...................

ELECTRICAL MAIN PARTS LIST - 4 / 4

LED 958 87-A40-814-080 LED,SEL2E10C BLUE ....................

LED 959 87-A40-814-080 LED,SEL2E10C BLUE ....................

PL 951 8Z-KT1-641-010 LAMP,T-3 A...................

PL 952 8Z-KT1-641-010 LAMP,T-3 A...................

Q 951 87-A30-287-040 C-TR,DTC114TKA A...................

Q 952 89-324-122-080 TR,2SC2412K A...................

S 957 87-036-251-080 SW,T CT 6X3.5 160 A...................

S 955 87-036-251-080 SW,T CT 6X3.5 160 A...................

S 952 87-036-251-080 SW,T CT 6X3.5 160 A...................

S 951 87-036-251-080 SW,T CT 6X3.5 160 A...................

S 953 87-036-251-080 SW,T CT 6X3.5 160 A...................

S 956 87-036-251-080 SW,T CT 6X3.5 160 A...................

S 959 87-A90-001-080 C-SW,TACT SKQMAL A...................

S 958 87-A90-001-080 C-SW,TACT SKQMAL A...................

S 954 87-A90-001-080 C-SW,TACT SKQMAL A...................

S 963 87-036-251-080 SW,T CT 6X3.5 160 A...................

S 964 87-036-251-080 SW,T CT 6X3.5 160 A...................

S 965 87-036-251-080 SW,T CT 6X3.5 160 A...................

S 962 87-036-251-080 SW,T CT 6X3.5 160 A...................

S 961 87-036-251-080 SW,T CT 6X3.5 160 A...................

S 966 87-036-251-080 SW,T CT 6X3.5 160 A...................

S 960 87-A90-001-080 C-SW,TACT SKQMAL A...................

S 967 87-A91-597-010 SW,RTRY SIM-026MT A...................

MECHANICAL PARTS LIST - 1 / 1

NOTE: The characters in the suffix column indicate the part usage.

MYZSTF .................XX..................................A...................

KANRI

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

8A-KC3-001-010 WINDOW,LCD R507M A...................

8A-KC3-002-010 WINDOW,LCD RV607M ....................

8A-KCF-001-010 CABI,FRONT -AC15 A...................

8A-KCF-002-010 CABI,REAR -AC15 A...................

8A-KCF-020-010 CABI,TRIM -AC15 A...................

8A-KCF-021-010 WINDOW,SIDE L -AC15 A...................

8A-KCF-022-010 WINDOW,SIDE R -AC15 A...................

8Z-KC2-011-210 CABI,BASE -C2 A...................

8A-KC1-002-010 BTN,TA-AC A...................

8A-KC3-011-010 BTN,AF -AC3 A...................

8A-KC7-005-010 KNOB,RTRY -AC A...................

8A-KC7-006-010 BTN,PRE.-AC A...................

8A-KC7-007-010 BTN,SEESAW R -AC A...................

8A-KC7-011-010 BTN,CLEAR L -AC A...................

8A-KC7-014-010 BTN,CLEAR S -AC A...................

8A-KC7-020-010 RING,RTRY -AC A...................

8A-KCF-007-010 BTN,SEESAW L -AC15 A...................

8A-KCF-010-010 BTN,CLEAR S2 -AC15 A...................

8A-KCF-011-010 BTN,DETACH -AC15 A...................

8A-KCF-012-010 BTN,CLEAR EJ -AC15 A...................

88-KC4-641-010 FF-CABLE, 20P 1.0 90MM A...................

88-ZG5-317-010 S-SCREW,8ZG5S+2-4 W/O A...................

8A-KC7-255-010 SPR-C,WIRE A...................

8A-KC3-211-010 CASE,LCD LENS -AC3 ....................

8A-KC3-212-010 LENS,LCD -AC3 ....................

8A-KC7-208-010 HLDR,BTN L-AC A...................

8A-KC7-220-010 SPR-C,ROTARY -AC A...................

8A-KC7-224-010 HLDR,P-IC -AC A...................

8A-KC7-230-010 HLDR,TR2 -AC A...................

8A-KCF-208-010 HLDR,BTN R1 -AC15 A...................

8A-KCF-210-010 HLDR,BTN R3 -AC15 A...................

8A-KCF-211-010 LENS,ENCO -AC15 A...................

8A-KCF-212-010 LENS,R -AC15 A...................

8A-KCF-213-010 LENS,LCD -AC15 A...................

8A-KCF-214-010 CASE,LCD LENS -AC15 A...................

8A-KCF-215-110 HLDR,LCD -AC15 A...................

8A-KCF-230-010 COVER, DUST DFP LOWRAL A...................

8Z-KC1-211-010 COVER, TOP -C A...................

8Z-KC1-213-010 CHAS,SIDE L -C A...................

8Z-KC1-214-010 CHAS,SIDE R -C A...................

8Z-KC1-216-310 HLDR,DECK CDC-01 A...................

8Z-KC1-236-010 COVER, CONN.BLIND -C A...................

8Z-KC1-256-010 COVER, BOTTOM RDS A...................

8Z-KC2-201-210 CHAS,FRONT -C2 A...................

8Z-KC2-203-210 LEVER,DFP HOOK -C2 A...................

8Z-KC2-204-210 LEVER,DFP LOCK -C2 A...................

8Z-KC2-221-110 SPR-C,DETACH HOOK-C2 A...................

8Z-KC2-222-010 SPR-T,DETACH LOCK-C2 A...................

8Z-KC2-223-010 SPR-C,DETACH -C2 A...................

8Z-KT1-236-010 CAP,LAMP BLU A...................

* 8A-KC7-231-010 HLDR,ISO-WIRE 2 -AC A...................

87-251-073-410 SCREW,U+2.6-6 A...................

87-251-100-410 U+3-16 A...................

87-432-903-010 WASHER,WTE 2.6 A...................

87-B10-216-010 U+2.6-4.0 ZINC BLK (BH M2.6) A...................

87-B10-259-010 UT2+3.0-10.0 W/O SLOT (BH TAP) A...................

8Z-KC1-251-010 S-SCREW,TH2.6-4.0-0.8 A...................

8Z-KC1-253-010 S-SCREW,PT 2*8 BH+ BLK A...................

8A-KT1-631-010 CONN ASSY,8P ISO-BLACK-A A...................

8A-KT1-632-010 CONN ASSY,8P ISO-WHITE-A A...................

8A-KC7-611-010 F-CABLE,3P (AUX) A...................

ACCESSORIES / PACKAGE LIST - 1 / 1

NOTE: The characters in the suffix column indicate the part usage.

MYZSTF .................XX..................................A...................

KANRI

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

8A-KC3-901-010 IB,YZ(9L) R507M,RV607M A...................

8A-KCG-905-010 IB,INST,YZ (9L)-I A...................

87-B10-141-010 NUT,5 TYPE-2 A...................

87-B10-143-010 UT1+5-15 W/O SLOT A...................

87-B10-144-010 W,5.2-10-0.5 A...................

87-B10-145-010 W-SPR,5.3-8.5-1.5 A...................

87-B10-216-010 U+2.6-4.0 ZINC BLK (BH M2.6) A...................

8Z-KC1-030-010 CASE,DFP -C A...................

8Z-KC1-231-110 HLDR,HALF -C A...................

8Z-KC1-232-010 KEY,REMOVE -C A...................

8Z-KC1-235-010 HLDR,REAR MTG A...................

8Z-KC1-244-010 S-SCREW,5*6 TH+ TAPPING ST A...................

8Z-KC1-250-010 S-SCREW,HEXAGON A...................

SCHEMATIC DIAGRAM - 1 (MAIN)

SCHEMATIC DIAGRAM - 2 (FRONT)

2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:03 (3827) 3111

Printed in Singapore9920588

Table of contents

Popular Car Receiver manuals by other brands

Linear Series

Linear Series LS5050 Operation and installation manual

Kenwood

Kenwood KRC-160 instruction manual

Sony

Sony XR-CA430X Service manual

T+A Elektroakustik

T+A Elektroakustik K1 CD-RECEIVER operating instructions

SoundMax

SoundMax SM-CDM1052 instruction manual

Xtrons

Xtrons HD107HD user manual

Mopar

Mopar RB3 manual

Clarion

Clarion ADDZEST DMZ615 owner's manual

Sony

Sony XAV-601BT Specifications

PIE

PIE GM12-POD/S Operation manual

Hyundai

Hyundai H-910H instruction manual

Sony

Sony XR-C6100 Service manual

Sony

Sony CDX-L600X - Fm/am Compact Disc Player Installation/connections

Motorola

Motorola VWA63 Service manual

Sound Storm

Sound Storm STM93R user manual

Nextar

Nextar D3201 instruction manual

Alpine

Alpine CDE-163BT owner's manual

Kenwood

Kenwood KDC-X303 quick start guide

Aiwa CDC-R507M User manual

Popular Car Receiver manuals by other brands
