Aiwa HS-TX494 YU User manual
S E R V I C E M A N U A L
SIMPLE MANUAL
•Replace this Service Manual with ”Revision Publishing” when it is issued.
HS-TX494
HS-TX496
HS-TX591
• TYPE: YU<494, 591>
YL<496>
S/M Code No. 09–992–407–8T1
STEREO RADIO
CASSETTE PLAYER
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
ELECTRICAL MAIN PARTS LIST - 1/3
NOTE: The characters in the suffix column indicate the part usage.
591YU ..................XX..................................A...................
496YL ..................XX...................................B..................
494YU ..................XX....................................C.................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
C 5 87-012-276-080 CAP, CHIP SS 1500 PBK ABC.................
C 6 87-012-276-080 CAP, CHIP SS 1500 PBK ABC.................
C 8 87-A10-504-080 C-CAP,U 0.047-16 K B ABC.................
C 3 87-A10-952-080 C-CAP,TN 22-4 M A MCM ABC.................
C 4 87-A10-952-080 C-CAP,TN 22-4 M A MCM ABC.................
C 19 87-010-674-080 CAP, ELECT 220-2 ABC.................
C 13 87-012-336-080 CAP, CHIP SS 3300 SL ABC.................
C 14 87-012-336-080 CAP, CHIP SS 3300 SL ABC.................
C 20 87-010-674-080 CAP, ELECT 220-2 ABC.................
C 96 87-010-505-080 CA, CHIP TANTALUM 1-16 A...................
C 92 87-010-831-080 C-CAP,U,0.1-16F ABC.................
C 95 87-010-853-080 C-CAP,220-4V H5.5 ABC.................
C 90 87-A10-047-080 C-CAP,U 1-10 Z F ABC.................
C 99 87-A10-422-080 C-CAP,TN 10-4 A TCF ABC.................
C 94 87-A10-952-080 C-CAP,TN 22-4 M A MCM ABC.................
C 93 87-A11-244-080 C-CAP,TN 47-4 A MCM A...................
C 914 87-012-274-080 CHIP CAP,U 1000P-50B ABC.................
IC 1 87-002-423-080 IC,TA2002 FN ABC.................
J 1 87-A60-437-010 JACK,3.5 BLK ST W/O SW 4P(1637 ....................
J 1 87-A60-438-010 JACK,3.5 BLK ST W/O SW (1537) ABC.................
L 3 87-003-231-080 C-COIL 1UH .BC.................
L 1 87-003-231-080 C-COIL 1UH .BC.................
L 2 87-003-231-080 C-COIL 1UH .BC.................
L 3 87-003-240-080 C-COIL,S 3.3UH A...................
L 2 87-003-240-080 C-COIL,S 3.3UH A...................
L 1 87-003-240-080 C-COIL,S 3.3UH A...................
L 4 87-003-243-080 C-COIL,S 10UH ....................
Q 1 87-026-414-080 C-TR RN1307 .BC.................
Q 2 87-026-414-080 C-TR RN1307 .BC.................
Q 1 87-026-418-080 TR,RN1311 (0.1W) A...................
Q 2 87-026-418-080 TR,RN1311 (0.1W) A...................
R 97 87-012-270-080 CAP, U 470P-50 .BC.................
S 2 87-A90-050-010 SW, SL 2-2-2 NS (BLK) ABC.................
S 1 8Z-HRB-607-010 SW,SL 2-2-2 SSZZ-S-502(S) ABC.................
VR 1 87-A90-818-010 VR,RTRY 20KCX2 ABC.................
C 15 87-010-831-080 C-CAP,U,0.1-16F ABC.................
C 16 87-010-831-080 C-CAP,U,0.1-16F ABC.................
Q 4 87-026-417-080 TR,RN1310 ABC.................
Q 3 87-026-417-080 TR,RN1310 ABC.................
C 105 87-010-503-010 CAP,E 220-4 GAS ABC.................
C 104 87-010-831-080 C-CAP,U,0.1-16F ABC.................
C 102 87-012-280-080 CAP, U 3300P-50 ABC.................
C 103 87-A10-047-080 C-CAP,U 1-10 Z F ABC.................
IC 101 87-017-370-080 IC,MM1038AFF ABC.................
Q 103 87-026-414-080 C-TR RN1307 ABC.................
R 111 87-022-656-080 C-RES,K43G 0.68 ABC.................
SFR 101 87-024-050-010 SEMI-FIXED RESISTOR, 1K ABC.................
TH 101 87-A91-322-080 C-THMS,157-101-53028-TP ABC.................
C 110 87-010-853-080 C-CAP,220-4V H5.5 ABC.................
C 906 87-A10-047-080 C-CAP,U 1-10 Z F ABC.................
D 101 87-001-553-080 C-DIODE 1SS322 A...................
D 101 87-A40-642-040 C-DIODE,1SS367 .BC.................
J 101 87-A60-849-010 JACK,DC DIA 2.75 BLK ABC.................
L 900 87-003-243-080 C-COIL,S 10UH ABC.................
Q 102 89-113-625-080 TR,2SA1362GR(120MHZ,0. ABC.................
Q 101 89-113-625-080 TR,2SA1362GR(120MHZ,0. ABC.................
R 998 87-012-286-080 CAP, U 0.01-25 A...................
S 101 87-A91-077-010 SW,LEAF ABC.................
BPF 201 87-A90-709-010 FLTR,GTVSB3 A...................
C 204 87-012-180-080 C-CAP,U 22P-50 CH A...................
C 209 87-012-186-080 C-CAP,U 39P-50 CH A...................
C 205 87-012-272-080 C-CAP,U 680P-50 B A...................
C 208 87-012-286-080 CAP, U 0.01-25 A...................
C 207 87-012-286-080 CAP, U 0.01-25 A...................
C 202 87-012-286-080 CAP, U 0.01-25 A...................
C 201 87-A10-504-080 C-CAP,U 0.047-16 K B A...................
C 215 87-012-162-080 C-CAP,U 1P-50 CK A...................
C 216 87-012-162-080 C-CAP,U 1P-50 CK A...................
C 213 87-012-195-080 C-CAP,U 100P-50CH A...................
C 210 87-012-272-080 C-CAP,U 680P-50 B A...................
C 212 87-012-286-080 CAP, U 0.01-25 A...................
C 245 87-012-275-080 C-CAP,U 1200P-50 B A...................
C 909 87-012-271-080 CAP, U 560P-50 A...................
C 901 87-012-274-080 CHIP CAP,U 1000P-50B A...................
D 204 87-A40-471-070 C-VARI-CAP,KV1435 A...................
D 202 87-A40-471-070 C-VARI-CAP,KV1435 A...................
D 203 87-A40-485-070 C-VARI-CAP,SVC208 A...................
D 201 87-A40-485-070 C-VARI-CAP,SVC208 A...................
IC 201 87-A20-745-040 C-IC,TA2030FN A...................
L 208 87-003-231-080 C-COIL 1UH A...................
L 205 87-005-898-080 C-COIL,S 2.2UH K LK2125 A...................
L 204 8Z-HRB-602-080 C-COIL,OSC FM A...................
L 202 8Z-HRB-603-080 C-COIL,RF FM A...................
L 203 8Z-HRB-604-080 C-COIL,OSC TV A...................
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
KBNC ...................XX.......................................F..............
VJ1B ...................XX........................................G.............
Z1BC ...................XX................................................O.....
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
86-HRM-005-110 WINDOW,TUN ABCDEFGHIJKLMNO.....
86-HRM-009-110 POINTER,TUN ABCDEFGHIJKLMNO.....
88-HRJ-001-010 LID,CASS EGS .....F.....L..O.....
88-HRJ-002-010 WINDOW,MSP ABCDEFGHIJKLMNO.....
88-HRJ-004-010 LID,CASS YU ..C.................
88-HRJ-005-010 LID,CASS YVJ ......G.............
88-HRJ-006-010 LID,CASS YJ ...DE..HI...........
88-HRJ-008-010 LID,CASS SI YH .........JK.MN......
88-HRJ-009-010 LID,CASS SI YZ A...................
88-HRJ-012-010 LID,CASS BU YZ .B..................
88-HRJ-003-010 KNOB,RTRY MSP ABCDEFGHIJKLMNO.....
87-067-527-010 SCREW,VT+1.4-2.5(B) ABCDEFGHIJKLMNO.....
88-HRJ-201-010 GEAR,MSP ABCDEFGHIJKLMNO.....
87-HRL-005-010 LID,BAT ..CDEFGHI..L..O.....
87-HRL-024-010 CABI,REAR YZC .....F.....L..O.....
87-HRL-035-010 CABI,REAR ..CDE.GHI...........
87-HRR-015-010 CABI,REAR BLUE .B..................
87-HRR-017-010 LID,BATT BLUE .B..................
87-HRR-020-010 FRAME,CENTRE GRAY .BCDEFGHI..L..O.....
87-HRR-034-010 LID,CASS SIL A........JK.MN......
87-HRR-036-010 FRAME,CENTRE J034 A........JK.MN......
88-HRL-024-010 CABI,REAR YZ SIL A...................
86-HRM-006-010 KNOB,RTRY TUN ABCDEFGHIJKLMNO.....
87-HRL-014-010 KNOB,SL EGS .....F.....L..O.....
87-HRR-019-010 KNOB,SL EGS BLUE .B..................
88-HRL-031-010 KNOB,SL EGS SIL A...................
88-HRJ-021-010 LBL,SPEC YU ..C.................
88-HRJ-022-010 LBL,SPEC YVJ ......G.............
88-HRJ-025-010 LBL,SPEC YZ AB...F.....L..O.....
87-067-691-010 SCREW VT+1.7-6 ABCDEFGHIJKLMNO.....
87-B10-044-010 V+1.7-6.5 ABCDEFGHIJKLMNO.....
81-HK9-208-210 SPR-P,CASS A ABCDEFGHIJKLMNO.....
86-HRM-202-010 BAT-CONTACT,(+) ABCDEFGHIJKLMNO.....
86-HRM-203-010 BAT-CONTACT,(-) ABCDEFGHIJKLMNO.....
86-HRM-205-010 SPR-T,CLICK ABCDEFGHIJKLMNO.....
87-HRM-201-010 PLATE,HEAD GRAY .BCDEFGHI...........
87-HRR-206-010 PLATE,HEAD J034 A........JKLMNO.....
L 201 8Z-HRB-605-080 C-COIL,RF TV A...................
Q 208 89-342-153-080 TR,2SC4215 A...................
BPF 201 87-A90-601-010 FLTR,BPF GFWB7 .BC.................
BPF 201 87-A90-609-010 FLTR,BPF GFMB7 ....................
C 206 87-012-172-080 CAPACITOR CHIP U 10P CH .BC.................
C 205 87-012-272-080 C-CAP,U 680P-50 B .BC.................
C 202 87-012-273-080 C-CAP,U 820P-50 B .BC.................
C 207 87-012-286-080 CAP, U 0.01-25 .BC.................
C 201 87-A10-504-080 C-CAP,U 0.047-16 K B .BC.................
C 210 87-012-156-080 C-CAP,S 220P-50 CH .BC.................
C 216 87-012-162-080 C-CAP,U 1P-50 CK .BC.................
C 212 87-012-286-080 CAP, U 0.01-25 .BC.................
C 217 87-A10-047-080 C-CAP,U 1-10 Z F .BC.................
C 222 87-010-831-080 C-CAP,U,0.1-16F .BC.................
C 224 87-012-274-080 CHIP CAP,U 1000P-50B .BC.................
C 226 87-A10-047-080 C-CAP,U 1-10 Z F .BC.................
C 231 87-010-959-080 CHIP CAP,U 0.056-16F .BC.................
C 233 87-012-275-080 C-CAP,U 1200P-50 B .BC.................
C 234 87-012-275-080 C-CAP,U 1200P-50 B .BC.................
C 235 87-A10-047-080 C-CAP,U 1-10 Z F .BC.................
C 237 87-A10-047-080 C-CAP,U 1-10 Z F .BC.................
C 236 87-A10-420-080 C-CAP,TN 4.7-4 A TCF .BC.................
C 239 87-A10-707-080 C-CAP,U 0.47U-16 F Z .BC.................
C 242 87-010-574-080 C-CAP,S 470P-50 UJ .BC.................
C 244 87-010-831-080 C-CAP,U,0.1-16F .BC.................
C 241 87-012-176-080 CAP 15P .BC.................
C 245 87-012-191-080 CHIP CAP 68 PF .BC.................
C 240 87-012-193-080 C-CAP,U 82P-50 CH .BC.................
C 248 87-012-195-080 C-CAP,U 100P-50CH .BC.................
C 250 87-010-853-080 C-CAP,220-4V H5.5 .BC.................
C 251 87-012-195-080 C-CAP,U 100P-50CH .BC.................
C 904 87-012-274-080 CHIP CAP,U 1000P-50B .BC.................
CF 203 87-A90-710-010 FLTR,AM IF PFS450A3 .BC.................
CF 204 87-A91-313-080 C-FLTR,CDACV10.7 MG77-A-TC .BC.................
CF 202 87-A91-343-010 FLTR,SK107M2N A0-2003 .BC.................
CT 201 87-A91-183-080 C-TRIMMER,CER 10P TZC03 .BC.................
D 205 87-A40-462-040 C-VARI-CAP,SVC347(S) .BC.................
D 202 87-A40-485-070 C-VARI-CAP,SVC208 .BC.................
D 204 87-A40-485-070 C-VARI-CAP,SVC208 .BC.................
IC 202 87-A21-215-040 C-IC,TA2104AFN .BC.................
IFT 201 87-005-788-080 C-IFT,AM (450K) .BC.................
L 207 87-003-226-080 MICRO INDUCTOR 100UJ .BC.................
L 206 87-HRA-603-010 BAR-ANT,MW .BC.................
L 204 8Z-HRB-609-010 COIL,FM OSC .BC.................
L 202 8Z-HRB-610-010 COIL,FM RF .BC.................
Q 203 87-026-414-080 C-TR RN1307 .BC.................
Q 202 87-026-418-080 TR,RN1311 (0.1W) .BC.................
Q 204 87-026-423-080 C-TR RN2305 .BC.................
Q 208 89-327-143-080 TR,2SC2714 (0.1W) .BC.................
ELECTRICAL MAIN PARTS LIST - 2/3
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
C 222 87-010-831-080 C-CAP,U,0.1-16F A...................
C 227 87-012-273-080 C-CAP,U 820P-50 B A...................
C 228 87-012-274-080 CHIP CAP,U 1000P-50B A...................
C 224 87-012-336-080 CAP, CHIP SS 3300 SL A...................
C 226 87-A10-047-080 C-CAP,U 1-10 Z F A...................
C 232 87-010-959-080 CHIP CAP,U 0.056-16F A...................
C 231 87-010-959-080 CHIP CAP,U 0.056-16F A...................
C 233 87-012-275-080 C-CAP,U 1200P-50 B A...................
C 234 87-012-275-080 C-CAP,U 1200P-50 B A...................
C 238 87-012-286-080 CAP, U 0.01-25 A...................
C 239 87-012-358-080 C-CAP,S 0.47-10 F Z A...................
C 237 87-A10-047-080 C-CAP,U 1-10 Z F A...................
C 236 87-A10-420-080 C-CAP,TN 4.7-4 A TCF A...................
C 244 87-010-787-080 CAP, U 0.022-25 A...................
C 241 87-012-170-080 C-CAP,U 8P-50 CH A...................
C 243 87-012-174-080 CAP CHIP CERA SS 12P CHJ A...................
C 240 87-012-193-080 C-CAP,U 82P-50 CH A...................
C 242 87-012-270-080 CAP, U 470P-50 A...................
C 249 87-012-286-080 CAP, U 0.01-25 A...................
C 247 87-012-286-080 CAP, U 0.01-25 A...................
C 250 87-010-853-080 C-CAP,220-4V H5.5 A...................
C 259 87-012-167-080 C-CAP,U 5P-50 CH A...................
C 252 87-012-271-080 CAP, U 560P-50 A...................
C 251 87-012-286-080 CAP, U 0.01-25 A...................
CF 203 87-A90-456-080 C-FLTR,PFWCC 450J3 A...................
CF 204 87-A91-313-080 C-FLTR,CDACV10.7 MG77-A-TC A...................
CF 202 87-A91-321-080 C-FLTR,SFECV10.7 MA-5-A-TC A...................
CT 202 87-A91-183-080 C-TRIMMER,CER 10P TZC03 A...................
D 205 87-A40-462-040 C-VARI-CAP,SVC347(S) A...................
IC 202 87-A21-232-040 C-IC,TA2111FN A...................
IFT 201 87-005-788-080 C-IFT,AM (450K) A...................
L 207 87-003-226-080 MICRO INDUCTOR 100UJ A...................
L 206 87-HRA-603-010 BAR-ANT,MW A...................
Q 203 87-026-268-080 C-TR,RN2411 A...................
Q 204 87-026-423-080 C-TR RN2305 A...................
Q 202 87-026-425-080 C-TR,RN2307 A...................
Q 206 89-327-143-080 TR,2SC2714 (0.1W) A...................
Q 207 89-342-153-080 TR,2SC4215 A...................
Q 209 89-342-153-080 TR,2SC4215 A...................
C 319 87-010-787-080 CAP, U 0.022-25 ABC.................
C 318 87-016-462-080 C-CAP,S 1-16 F .BC.................
C 317 87-A10-047-080 C-CAP,U 1-10 Z F ABC.................
C 320 87-010-505-080 CA, CHIP TANTALUM 1-16 ABC.................
C 323 87-012-167-080 C-CAP,U 5P-50 CH ABC.................
C 324 87-012-170-080 C-CAP,U 8P-50 CH ABC.................
C 321 87-012-286-080 CAP, U 0.01-25 ABC.................
C 322 87-012-337-080 C-CAP,U 56P-50 CH ABC.................
IC 302 87-A20-124-080 IC, TK11823 ABC.................
L 301 87-A50-037-080 C-COIL,D-D 5CDLU A...................
L 301 87-A50-230-080 C-COIL,D-D(CP4LBM) .BC.................
Q 303 89-341-165-080 CHIP TRANSISTOR 2SC4116GR ABC.................
Q 304 89-341-165-080 CHIP TRANSISTOR 2SC4116GR ABC.................
C 301 87-010-853-080 C-CAP,220-4V H5.5 A...................
C 304 87-012-277-080 C-CAP, U 1800P-50 B .BC.................
C 301 87-012-277-080 C-CAP, U 1800P-50 B .BC.................
C 303 87-012-277-080 C-CAP, U 1800P-50 B .BC.................
C 302 87-012-277-080 C-CAP, U 1800P-50 B .BC.................
C 311 87-012-174-080 CAP CHIP CERA SS 12P CHJ ABC.................
C 312 87-012-176-080 CAP 15P ABC.................
C 313 87-A10-047-080 C-CAP,U 1-10 Z F ABC.................
C 310 87-A10-047-080 C-CAP,U 1-10 Z F ABC.................
C 325 87-012-188-080 C-CAP,U 47P-50 CH .BC.................
C 902 87-010-831-080 C-CAP,U,0.1-16F ABC.................
C 901 87-012-274-080 CHIP CAP,U 1000P-50B .BC.................
IC 301 87-A21-119-010 C-IC,TC9318FB-027RF A...................
IC 301 87-A21-272-010 C-IC,TC9318FB-046 .BC.................
LCD 301 8Z-HR9-603-010 LCD,HS ASSY(BAND/TU) ABC.................
Q 301 87-026-261-080 CHIP-TR,RN1404 A...................
Q 301 87-026-411-080 C-TR RN1304 .BC.................
S 303 87-A90-665-180 C-SW,TACT LS7A2M ABC.................
S 302 87-A90-665-180 C-SW,TACT LS7A2M ABC.................
S 301 87-A91-320-080 C-SW,SL 1-1-2 SSSS8A2-B-2B(NC) ABC.................
TH 301 87-A90-547-080 C-THMS,47K (5%)NTH 5G ABC.................
X 301 87-A70-187-010 VIB,XTAL 75KHZ CFV206 ABC.................
ELECTRICAL MAIN PARTS LIST - 3/3
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
NOTE: The characters in the suffix column indicate the part usage.
591YU ..................XX..................................A...................
496YL ..................XX...................................B..................
494YU ..................XX....................................C.................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
8Z-HRB-001-010 LID,CASS R GRY ABC.................
8Z-HRB-002-010 WINDOW,CASS ABC.................
8Z-HRB-018-010 LID,CASS R GRY EG ....................
8Z-HRB-035-010 LID,CASS R BLU EG ....................
8Z-HRB-217-010 SPR-T,CASS ABC.................
8Z-HRB-004-010 CABI,REAR SIL ABC.................
8Z-HRB-005-010 LID,BAT SIL ABC.................
8Z-HRB-006-010 PANEL,REAR 496 .B..................
8Z-HRB-019-010 PANEL,REAR 496 EG ....................
8Z-HRB-020-010 PANEL,REAR 591 WT A...................
8Z-HRB-021-010 PANEL,REAR 494 ..C.................
8Z-HRB-022-010 PANEL,REAR 494 EG ....................
8Z-HRB-023-010 PANEL,REAR 596 ....................
8Z-HRB-024-010 PANEL,REAR 596 EG ....................
8Z-HRB-025-010 PANEL,REAR 594 EG ....................
8Z-HRB-037-010 CABI,REAR BLU ....................
8Z-HRB-038-010 LID,BAT BLU ....................
8Z-HRB-007-010 KEY,BAND ABC.................
8Z-HRB-008-010 KEY,PRESET L AB..................
8Z-HRB-009-010 KEY,RBR PRESET L ABC.................
8Z-HRB-010-010 KEY,PRESET R AB..................
8Z-HRB-011-010 KEY,RBR PRESET R ABC.................
8Z-HRB-012-010 KEY,RBR TUN ABC.................
8Z-HRB-013-010 KNOB,RTRY HOLD ABC.................
8Z-HRB-033-010 KEY,PRESET L SIL ..C.................
8Z-HRB-034-010 KEY,PRESET R SIL ..C.................
87-067-384-010 SCREWVT1.4-3.5HL ABC.................
87-067-732-010 TAPPING SCREW, VT1.4-3 ABC.................
87-264-527-310 V 1.7-3 SCREW ABC.................
87-B10-048-010 VT2+1.4-3 (3) CR HL ABC.................
* 87-B10-196-010 VT2+1.4-4 BLK (3) HL ABC.................
8Z-HRB-201-010 HLDR,BAR-ANT ABC.................
8Z-HRB-203-010 HLDR,KNOB RTRY ABC.................
8Z-HRB-208-010 BAT-CONTACT,P ABC.................
8Z-HRB-209-010 BAT-CONTACT,M ABC.................
8Z-HRB-212-010 SPR-T,HOLD ABC.................
MECHANICAL PARTS LIST - 1/1
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
NOTE: The characters in the suffix column indicate the part usage.
591YU ..................XX..................................A...................
496YL ..................XX...................................B..................
494YU ..................XX....................................C.................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
8Z-HRB-903-010 IB,YU(3L)S ..C.................
8Z-HRB-904-010 IB,YHJ(ECC)S 496 ....................
8Z-HRB-906-010 IB,YL(3L)S .B..................
8Z-HRB-907-010 IB,YZ(EGF)S 494/496 ....................
8Z-HRB-908-010 IB,YZ(SID)S 494/496 ....................
8Z-HRB-909-010 IB,YZ(PHNCZ)S 494/496 ....................
8Z-HRB-913-010 IB,YU(3L)591 S A...................
8Z-HRB-914-010 IB,YHJ(ECC)S 596 ....................
8Z-HRB-916-010 IB,YL(3L)S 596 ....................
8Z-HRB-917-010 IB,YZ(EGF)S 594/596 ....................
8Z-HRB-918-010 IB,YZ(SID)S 594/596 ....................
8Z-HRB-919-010 IB,YZ(PHNCZ)S 594/596 ....................
87-B30-080-110 HEADPHONE,HP-M009(F) ABC.................
87-B30-092-010 HEADPHONE,HP-MR015(F) ....................
87-B30-258-010 HEADPHONE,HP-M007B(F) ....................
8Z-HRB-050-010 CLIP,BELT ASSY ABC.................
ACCESSORIES / PACKAGE LIST - 1/1
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
Other manuals for HS-TX494 YU
1
This manual suits for next models
3
Table of contents
Other Aiwa Cassette Player manuals
Aiwa
Aiwa HS-TA50 User manual
Aiwa
Aiwa CSD-EX180 User manual
Aiwa
Aiwa TP-VS485 User manual
Aiwa
Aiwa HS-RX408 User manual
Aiwa
Aiwa AD-F810 - SERVICE User manual
Aiwa
Aiwa HS-JS195 User manual
Aiwa
Aiwa CSD-EX150 HR User manual
Aiwa
Aiwa HS-JX2000 User manual
Aiwa
Aiwa CSD-TD34 K User manual
Aiwa
Aiwa HS-RX208 User manual
