SERVICE MANUAL
COMPACT DISC /
STEREO CASSETTE RECORDER
BASIC TAPE MECHANISM : ZZM-1 AR2NC
BASIC CD MECHANISM : DA11T3C
CSD-TD21 HE
S/M Code No. 09-006-426-7R2
REVISION
• This Service Manual is the "Revision Publishing" and replaces "Simple Manual",
(S/M Code No. 09-006-426-7T2).
DATA
All manuals and user guides at all-guides.com
all-guides.com

– 2 –
Tuner section
Frequency range
FM : 87.5 MHz - 108.0 MHz
Antenna : Rod antenna
AM : 531/530 kHz - 1,602/1,710 kHz
(9/10 kHz/step)
Antenna : Ferrite bar antenna
Deck section
Track format 4 tracks, 2 channels
Frequency range Normal tape : 50 Hz-12,500 Hz (EIAJ)
Recording system AC bias
Erasing system Magnet erase
Heads Recording/Playback head x 1/
Erasure head x 1
CD player section
Disc Compact disc
Scanning methodd Non-contact optical scanner
(semiconductor laser)
General
Speaker 100 mm cone type (2)
60 mm cone type (2)
Output Headphones jack (stereo mini-jack)
Power output 2.5 W + 2.5 W (EIAJ 7 ohms DC)
1.9 W + 1.9 W (DIN 1 % Rated Power)
Power requirements DC 12 V using eight R14 (size C)
batteries,
AC 110 - 120 V / 220 - 240 V
switchable,50/60 Hz
Power consumption 16 W
Dimensions (W xH xD) 435 (W) x 184 (H) x 277 (D) mm
Weight 3.7 kg (excluding batteries)
• Design and specifications are subject to change without notice.
SPECIFICATIONS
ACCESSORIES / PACKAGE LIST
DESCRIPTIONREF. NO. KANRI
NO.
PART NO.
1 8A-CH9-901-010 IB,H (ECA) B
2 87-A80-081-010 AC CORD SET ASSY,EZ BLK
3 87-A91-017-010 PLUG CONVERSION JT-0476
!
!
All manuals and user guides at all-guides.com

– 3 –
PROTECTION OF EYES FROM LASER BEAM DURING SERVICING
VAROITUS!
Laiteen Käyttäminen muulla kuin tässä käyttöohjeessa mainit-
ulla tavalla saattaa altistaa käyt-täjän turvallisuusluokan 1 ylit-
tävälle näkymättömälle lasersäteilylle.
VARNING!
Om apparaten används på annat sätt än vad som specificeras i
denna bruksanvising, kan användaren utsättas för osynling
laserstrålning, som överskrider gränsen för laserklass 1.
Caution: Invisible laser radiation when
open and interlocks defeated avoid expo-
sure to beam.
Advarsel:Usynling laserståling ved åbning,
når sikkerhedsafbrydere er ude af funktion.
Undgå udsættelse for stråling.
CAUTION
Use of controls or adjustments or performance of procedures
other than those specified herein may result in hazardous
radiation exposure.
ATTENTION
L'utilisation de commandes, réglages ou procédures autres que
ceux spécifiés peut entraîner une dangereuse exposition aux
radiations.
ADVARSEL!
Usynlig laserståling ved åbning, når sikkerhedsafbrydereer ude
af funktion. Undgå udsættelse for stråling.
This Compact Disc player is classified as a CLASS 1 LASER
product.
The CLASS 1 LASER PRODUCT label is located on the rear
exterior.
This set employs laser. Therefore, be sure to follow carefully the
instructions below when servicing.
WARNING!
WHEN SERVICING, DO NOT APPROACH THE LASER EXIT
WITH THE EYE TOO CLOSELY. IN CASE IT IS NECESSARY TO
CONFIRM LASER BEAM EMISSION. BE SURE TO OBSERVE
FROM A DISTANCE OF MORE THAN 30cm FROM THE
SURFACE OF THE OBJECTIVE LENS ON THE OPTICAL
PICK-UP BLOCK.
CLASS 1
KLASSE 1
LUOKAN 1
KLASS 1
LASER PRODUCT
LASER PRODUKT
LASER LAITE
LASER APPARAT
Precaution to replace Optical block
1) After the connection, remove solder shown in
the right figure.
Body or clothes electrostatic potential could ruin
laser diode in the optical block. Be sure ground
body and workbench, and use care the clothes
do not touch the diode.
Solder
1
16
TO/FROM CD C.B
PICK UP ASSY
SF-P101NR
(SF-P101NR)
All manuals and user guides at all-guides.com

– 4 –
ELECTRICAL MAIN PARTS LIST
DESCRIPTIONREF. NO. KANRI
NO.
PART NO. DESCRIPTIONREF. NO. KANRI
NO.
PART NO.
IC
87-A21-550-010 IC,TA2149N
87-A21-185-040 C-IC,LC72121M
87-A21-064-010 IC,LA4227
87-A21-520-040 C-IC,M61509FP
87-A20-446-010 C-IC,LA9241ML
87-A20-459-010 C-IC,LC78622ED
87-A21-093-010 IC,LA6541D
8A-CH4-661-010 C-IC,LC867132V-5P07
87-A21-431-010 IC,BA4560N
TRANSISTOR
87-026-237-080 C-TR,DTC124XK
89-327-143-080 TR,2SC2714O
87-026-447-080 TR,2SC1740SR
89-111-624-080 TR,2SA1162Y
87-026-213-080 CHIP-TR,DTC114YK
89-327-125-080 CHIP TR,2SC2712GR
89-318-154-080 TR,2SC1815Y
89-112-965-080 TR,2SA1296GR
87-026-463-080 TR,2SA933SRS
87-A30-436-040 C-TR,DTC144TKA
87-026-291-080 TR,DTC124XS
89-213-702-080 TR,2SB1370E
89-320-011-080 TR,2SC2001K
87-026-462-080 TR,2SC1740SRS
89-109-332-380 TR,2SA933RS
89-113-187-080 TR,2SA1318T
87-026-239-080 TR,DTC114TK
87-026-210-080 TR,DTC144EK
87-026-464-080 TR,DTC114TS
87-026-230-080 C-TR,DTA114YK
DIODE
87-A40-234-080 ZENER,MTZJ5.6A
87-020-465-080 DIODE,1SS133
87-017-072-080 ZENER,HZS3B1
87-027-703-080 ZENER,HZ7A1L
87-A40-648-080 ZENER,MTZJ8.2A
87-070-345-080 DIODE,1N4148
87-017-978-080 DIODE,1N4003
87-027-702-080 ZENER,HZ6C2L
87-A40-465-010 DIODE,FR202
87-027-399-080 ZENER,HZ7A3L
MAIN C.B
C211 87-A11-603-080 CAP, S 0.15-16
C212 87-A11-603-080 CAP, S 0.15-16
C215 87-016-460-080 C-CAP,S 0.22-16 B
C216 87-016-460-080 C-CAP,S 0.22-16 B
C231 87-010-213-080 C-CAP,S 0.015-50 B
C232 87-010-213-080 C-CAP,S 0.015-50 B
C233 87-A10-201-080 C-CAP,S0.33-16 KB
C234 87-A10-201-080 C-CAP,S0.33-16 KB
C235 87-016-669-080 C-CAP,S 0.1-25 K B
C236 87-016-669-080 C-CAP,S 0.1-25 K B
C237 87-010-371-080 CAP, ELECT 470-6.3M
C239 87-010-197-080 CAP, CHIP 0.01 DM
C240 87-010-197-080 CAP, CHIP 0.01 DM
C247 87-010-401-080 CAP, ELECT 1-50V
C248 87-010-401-080 CAP, ELECT 1-50V
C310 87-010-248-080 CAP, ELECT 220-10V
C316 87-010-263-080 CAP,E 100-10
C317 87-010-197-080 CAP, CHIP 0.01 DM
C801 87-010-248-080 CAP, ELECT 220-10V
C805 87-012-365-080 C-CAP,S 0.027-25 BK
C806 87-012-365-080 C-CAP,S 0.027-25 BK
C807 87-010-405-080 CAP, ELECT 10-50V
C808 87-010-405-080 CAP, ELECT 10-50V
C809 87-010-401-080 CAP, ELECT 1-50V
C810 87-010-401-080 CAP, ELECT 1-50V
C811 87-010-178-080 CHIP CAP 1000P
C812 87-010-178-080 CHIP CAP 1000P
C816 87-010-180-080 C-CER 1500P
C817 87-010-180-080 C-CER 1500P
C821 87-010-401-080 CAP, ELECT 1-50V
C822 87-010-401-080 CAP, ELECT 1-50V
C823 87-010-178-080 CHIP CAP 1000P
C824 87-010-178-080 CHIP CAP 1000P
C829 87-010-178-080 CHIP CAP 1000P
C830 87-010-178-080 CHIP CAP 1000P
C831 87-010-198-080 C-CAP, 0.022-25 K B
C834 87-010-248-080 CAP, ELECT 220-10V
C843 87-010-197-080 CAP, CHIP 0.01 DM
C844 87-018-124-080 CAP, CER 270P-50V
C845 87-010-178-080 CHIP CAP 1000P
C846 87-010-263-080 CAP, ELECT 100-10V
C851 87-010-186-080 CAP,CHIP 4700P
C852 87-010-178-080 CHIP CAP 1000P
C853 87-018-211-080 CAP, TC U 0.01-50 Z F SA
CN201 87-099-018-010 CONN,16P
CN801 87-A60-110-010 CONN,4P V S2M-4W
CN302 8A-CD9-629-010 CONN ASSY, 6P MA-TU
CNA801 8A-CD9-630-010 CONN ASSY, 4P RPH
FC201 8A-CD9-620-010 FF-CABLE, 16P FR-MAIN
L801 87-007-342-010 COIL,OSC 85K BIAS
SW801 8Z-CD9-609-010 SW,SL 1-6-2 PS62D01
CD C.B0
C30 87-010-260-080 CAP, ELECT 47-25V
C251 87-010-404-080 CAP, ELECT 4.7-50V
C261 87-010-402-080 CAP,E 2.2-50 M
C262 87-010-402-080 CAP,E 2.2-50 M
C263 87-010-178-080 CHIP CAP 1000P
C264 87-010-178-080 CHIP CAP 1000P
C265 87-010-263-080 CAP, ELECT 100-10V
C266 87-010-263-080 CAP, ELECT 100-10V
C267 87-010-112-080 CAP, ELECT 100-16V
C268 87-010-112-080 CAP, ELECT 100-16V
C271 87-010-237-080 CAP, ELECT 1000-16V
C272 87-010-237-080 CAP, ELECT 1000-16V
C278 87-010-405-080 CAP, ELECT 10-50V
C279 87-010-385-080 CAP, ELECT 220-25V
C301 87-016-495-000 CAP,E 3300-25 M SMG
C306 87-010-404-080 CAP, ELECT 4.7-50V
C307 87-010-401-080 CAP, ELECT 1-50V
C308 87-010-221-080 CAP, ELECT 470-10V
C311 87-010-263-080 CAP, ELECT 100-10
C312 87-010-385-080 CAP, ELECT 220-25V
C321 87-010-197-080 CAP, CHIP 0.01 DM
C322 87-010-263-080 CAP, ELECT 100-10V
C325 87-010-405-080 CAP, ELECT 10-50V
C401 87-010-403-080 CAP, ELECT 3.3-50V
C402 87-010-197-080 CAP, CHIP 0.01 DM
C403 87-010-263-080 CAP, ELECT 100-10V
C404 87-010-248-080 CAP, ELECT 220-10V
C405 87-010-197-080 CAP, CHIP 0.01 DM
C406 87-010-374-080 CAP, ELECT 47-10V
C407 87-010-178-080 CHIP CAP 1000P
C408 87-010-198-080 CAP, CHIP 0.022
C409 87-010-248-080 CAP, ELECT 220-10V
C410 87-010-263-080 CAP, ELECT 100-10V
C411 87-A11-177-080 C-CAP,S 0.15-16 K B
C412 87-010-401-080 CAP, ELECT 1-50V
C413 87-016-369-080 C-CAP,S 0.033-25 B K
C414 87-010-405-080 CAP, ELECT 10-50V
All manuals and user guides at all-guides.com

– 5 –
DESCRIPTIONREF. NO. KANRI
NO.
PART NO. DESCRIPTIONREF. NO. KANRI
NO.
PART NO.
C416 87-010-545-080 CAP, ELECT 0.22-50V
C417 87-012-157-080 C-CAP,S 330P-50 CH
C418 87-010-213-080 C-CAP,S 0.015-25 B
C419 87-A11-608-080 C-CAP,S 0.33-25 K B
C420 87-016-369-080 C-CAP,S 0.033-25 B K
C421 87-A11-177-080 C-CAP,S 0.15-16 K B
C422 87-010-184-080 C-CAP,S 3300P-50 K B
C423 87-010-992-080 CHIP-CAP,S 0.047-25
C424 87-A11-606-080 C-CAP,S 0.22-25 K B
C425 87-010-176-080 C-CAP,S 680P-50 SL
C426 87-A11-608-080 C-CAP,S 0.33-25 K B
C428 87-010-197-080 CAP, CHIP 0.01 DM
C429 87-010-186-080 CAP,CHIP 4700P
C430 87-012-156-080 C-CAP,S 220P-50 CH
C431 87-010-545-080 CAP, ELECT 0.22-50V
C432 87-010-374-080 CAP, ELECT 47-10V
C433 87-010-401-080 CAP, ELECT 1-50V
C434 87-010-184-080 CHIP CAPACITOR 3300P(K)
C435 87-010-197-080 CAP, CHIP 0.01 DM
C436 87-010-374-080 CAP, ELECT 47-10V
C437 87-010-404-080 CAP, ELECT 4.7-50V
C438 87-016-669-080 C-CAP,S 0.1-25 K B
C439 87-010-178-080 CHIP CAP 1000P
C440 87-010-145-080 C-CAP, S 1P-50 C CH
C441 87-010-197-080 CAP, CHIP 0.01 DM
C442 87-010-313-080 C-CAP,S 18P-50 CH
C445 87-012-368-080 C-CAP,S 0.1-50 F
C446 87-012-368-080 C-CAP,S 0.1-50 F
C447 87-012-368-080 C-CAP,S 0.1-50 F
C448 87-010-315-080 C-CAP,S 27P-50 CH
C450 87-012-140-080 C-CAP,S 470P-50
C451 087-012-156-080 C-CAP,S 220P-50 CH
C455 87-010-247-080 CAP, ELECT 100-50 M SME
C457 87-010-312-080 C-CAP,S 15P-50 CH
C458 87-010-312-080 C-CAP,S 15P-50 CH
C459 87-010-263-080 CAP, ELECT 100-10V
C460 87-015-819-080 CAPACITOR,0.01
C461 87-010-197-080 CAP, CHIP 0.01 DM
C462 87-010-248-080 CAP, ELECT 220-10V
C463 87-010-197-080 C-CAP,S 0.01-25 K B
C465 87-010-404-080 CAP, ELECT 4.7-50V
C466 87-012-368-080 C-CAP,S 0.1-50 F
C467 87-010-263-080 CAP, ELECT 100-10V
C469 87-012-154-080 C-CAP,S 150P-50 CH
C470 87-010-544-080 CAP, ELECT 0.1-50V
C471 87-010-196-080 CHIP CAPACITOR, 0.1FZ-25Z
C472 87-015-785-080 CHIP CAPACITOR, 0.1FZ-25Z
C473 87-010-196-080 CHIP CAPACITOR, 0.1FZ-25Z
C474 87-015-785-080 CHIP CAPACITOR, 0.1FZ-25Z
C475 87-010-197-080 CAP, CHIP 0.01 DM
C476 87-010-236-080 CAP,E 1000-10 SME
C477 87-010-197-080 CAP, CHIP 0.01 DM
C478 87-010-263-080 CAP, ELECT 100-10V
C479 87-010-197-080 CAP, CHIP 0.01 DM
C480 87-010-221-080 CAP, ELECT 470-10V
C481 87-010-405-080 CAP, ELECT 10-50V
C482 87-010-405-080 CAP, ELECT 10-50V
C489 87-012-368-080 C-CAP,S 0.1-50 F
C490 87-012-368-080 C-CAP,S 0.1-50 F
C491 87-010-197-080 CAP, CHIP 0.01 DM
C492 87-010-221-080 CAP, ELECT 470-10V
C494 87-010-197-080 CAP, CHIP 0.01 DM
C495 87-016-669-080 C-CAP,S 0.1-25 K
C501 87-012-368-080 C-CAP,S 0.1-50 F
C502 87-010-322-080 C-CAP,S 100P-50 CH
C503 87-010-322-080 C-CAP,S 100P-50 CH
C504 87-010-322-080 C-CAP,S 100P-50 CH
C505 87-010-322-080 C-CAP,S 100P-50 CH
C506 87-010-322-080 C-CAP,S 100P-50 CH
C510 87-016-669-080 C-CAP,S 0.1-25 K
CN202 8A-CH4-689-010 CONN,3P V 2.5
CN205 87-A60-109-010 CONN,2P V S2M-2W
CN301 8A-CH4-689-010 CONN,3P V 2.5
CN401 87-A60-424-010 CONN,16P V TOC-B
CN403 87-099-201-010 CONN,8P 6216 H
CN802 8A-CH4-687-010 CONN,4P V 2.5
CNA205 8A-CD9-626-010 CONN ASSY,2P DOOR
CNA402 8A-CD9-625-010 CONN ASSY,6P CD-ME
CNA802 8A-CD9-631-010 CONN ASSY,4P TP-ME
FC401 8A-CD9-621-010 FF-CABLE, 16P CD-RF
FC403 8A-CD9-622-010 FF-CABLE, 8P CD-FR
L401 87-003-102-080 COIL, 10UH
L404 87-003-152-080 COIL, 100UH
R840 87-029-124-010 RES,FUSE 2.2-1/4
SFR430 87-024-437-080 SFR,100K H RH063MC
SW205 87-036-389-010 SW, PUSH 1-1-1 R8120125
X401 8Z-CD5-633-010 VIB, CER16.93MHZ FCR16.93M2
FRONT C.B
C601 87-010-313-080 CAP, CHIP 18P
C602 87-010-315-080 C-CAP,S 27P-50 CH
C603 87-010-319-080 C-CAP,S 56P-50 CH
C604 87-010-312-080 C-CAP,S 15P-50 CH
C605 87-010-317-080 C-CAP,S 39P-50 CH
C607 87-A10-826-080 CHIP CAPACITOR,S 1-10 K B
C608 87-010-196-080 CHIP CAPACITOR,0.1-25
C612 87-A10-189-040 CAP,E 220-10
C613 87-010-495-040 CAP,E 2.2-50 GAS
C614 87-010-196-080 CHIP CAPACITOR,0.1-25
C615 87-010-493-040 CAP,E 0.47-50 GAS
C616 87-010-494-040 CAP,E 1-50 GAS
C620 87-015-785-080 CHIP CAPACITOR, 0.1FZ-25Z
C627 87-A10-826-080 CHIP CAPACITOR,S 1-10 K B
CN601 87-099-033-010 16P 6216 H
CN602 87-099-201-010 CONN,8P 6216 H
CNA603 8A-CD9-624-010 CONN ASSY,4P TU-FR
CNA604 8A-CH9-623-010 CONN ASSY,2P KEY
L601 87-003-102-080 COIL, 10UH J LAL02
L690 87-003-231-080 C-COIL, 2125 1UH K
L691 87-003-231-080 C-COIL, 2125 1UH K
LCD601 8Z-CH4-635-010 LCD,HLC7365 ZCH-4
LED601 8A-CDA-645-010 LED,6224-10ID RED
LED602 8A-CDA-645-010 LED,6224-10ID RED
LED603 8A-CDA-645-010 LED,6224-10ID RED
LED604 8A-CDA-645-010 LED,6224-10ID RED
LED606 8A-CDA-645-010 LED,6224-10ID RED
LED607 8A-CDA-645-010 LED,6224-10ID RED
LED608 8A-CDA-645-010 LED,6224-10ID RED
LED610 8A-CDA-646-010 LED,6224-10GD GRN
S601 87-A91-704-080 SW,TACT EVQ 214 05R
S602 87-A91-704-080 SW,TACT EVQ 214 05R
S603 87-A91-704-080 SW,TACT EVQ 214 05R
S604 87-A91-704-080 SW,TACT EVQ 214 05R
S605 87-A91-704-080 SW,TACT EVQ 214 05R
S607 87-A91-704-080 SW,TACT EVQ 214 05R
S608 87-A91-704-080 SW,TACT EVQ 214 05R
S614 87-A91-704-080 SW,TACT EVQ 214 05R
X601 87-030-273-010 VIB,XTAL 32.768K5PPM
X602 87-030-376-080 VIB,CER CSA5.76MG200
TUNER C.B
C1 87-010-312-080 C-CAP,S 15P-50V
C2 87-010-316-080 C-CAP,S 33P-50 CH
C3 87-010-312-080 C-CAP,S 15P-50V
C5 87-016-669-080 C-CAP,S 0.1-25 KB
C6 87-010-313-080 CAP, CHIP 18P
C7 87-014-049-080 CAP,PP 470P-100 J
C8 87-012-349-080 CHIP CAP 1000P
All manuals and user guides at all-guides.com

– 6 –
DESCRIPTIONREF. NO. KANRI
NO.
PART NO. DESCRIPTIONREF. NO. KANRI
NO.
PART NO.
C10 87-010-197-080 CAP, CHIP 0.01 DM
C11 87-010-197-080 CAP, CHIP 0.01 DM
C12 87-010-197-080 CAP, CHIP 0.01 DM
C13 87-010-150-080 C-CAP,S 6P-50 CH
C14 87-010-303-080 C-CAP,S 330P-50CH
C15 87-010-178-080 CHIP CAP 1000P
C16 87-010-374-080 CAP, ELECT 47-10V
C17 87-010-198-080 CAP, CHIP 0.022
C18 87-015-835-080 C-CAP,0.047 D
C19 87-010-263-080 CAP, ELECT 100-10V
C20 87-010-404-080 CAP, ELECT 4.7-50V
C21 87-010-197-080 CAP, CHIP 0.01 DM
C22 87-010-197-080 CAP, CHIP 0.01 DM
C23 87-010-197-080 CAP, CHIP 0.01 DM
C24 87-010-303-080 C-CAP,S 330P-50CH
C25 87-016-460-080 C-CAP,S 0.22-16 B
C27 87-A11-067-080 C-CAP,S 1-10 K B
C28 87-016-669-080 C-CAP,S 0.1-25 K B
C29 87-016-669-080 C-CAP,S 0.1-25 K B
C30 87-010-220-080 CAP, CHIP 0.018-25
C31 87-010-220-080 CAP, CHIP 0.018-25
C33 87-012-358-080 C-CAP,S 0.47-10 F Z
C34 87-012-358-080 C-CAP,S 0.47-10 F Z
C35 87-015-819-080 CAPACITOR,0.01
C36 87-010-263-080 CAP, ELECT 100-10V
C37 87-010-197-080 CAP, CHIP 0.01 DM
C38 87-010-263-080 CAP, ELECT 100-10V
C39 87-010-404-080 CAP, ELECT 4.7-50V
C40 87-010-197-080 CAP, CHIP 0.01 DM
C41 87-010-178-080 CHIP CAP 1000P
C42 87-010-178-080 CHIP CAP 1000P
C43 87-010-178-080 CHIP CAP 1000P
C44 87-010-311-080 C-CAP,12P-50 CH
C45 87-010-312-080 C-CAP,S 15P-50 CH
C46 87-010-197-080 CAP, CHIP 0.01 DM
C47 87-010-197-080 CAP, CHIP 0.01 DM
C48 87-010-197-080 CAP, CHIP 0.01 DM
C49 87-012-140-080 CAP 470P
C50 87-010-197-080 CAP, CHIP 0.01 DM
C71 87-010-197-080 CAP, CHIP 0.01 DM
C72 87-010-263-080 CAP, ELECT 100-10V
C73 87-010-197-080 CAP, CHIP 0.01 DM
C75 87-010-197-080 CAP, CHIP 0.01 DM
C91 87-012-140-080 CAP 470P
C92 87-010-197-080 CAP, CHIP 0.01 DM
C93 87-010-197-080 CAP, CHIP 0.01 DM
CF1 87-A91-094-010 FLTR,CDA10.7 MG80A
CF2 87-008-261-010 FILTER, SFE10.7MA5-A
CF3 87-008-261-010 FILTER, SFE10.7MA5-A
CN2 87-099-854-010 CONN,6P S2M-6W
CN3 87-A60-110-010 CONN,4P V S2M-4W
D3 87-A40-616-070 VARI-CAP,SVC384(S/T)
D4 87-A40-916-040 C-VARI-CAP,HVC202A
D5 87-A40-916-040 C-VARI-CAP,HVC202A
L2 87-A50-560-010 COIL,FM BPF(ACD)
L3 8A-CH4-670-010 BAR-ANT,MW 2B-ACH(COI)
L4 87-A50-420-010 COIL,MW OSC(SYN)
L5 87-A50-566-010 COIL,FM RF EX(ACH)
L6 87-A50-567-010 COIL,FM OSC(ACH)
L7 87-A91-308-010 FLTR,PCFAZH- 450T (TOK)
L8 87-005-849-080 COIL,10UH(CECS)
TC1 87-011-254-080 TRIMER,20P LAR
X1 87-A70-061-010 VIB,XTAL 4.500MHZ CSA-309
H.P. C.B
CN204 87-A60-685-010 CONN,4P H WHT
CN605 87-A60-113-010 CONN,2P H S2M-2WR
CNA203 8A-CD9-628-010 CONN ASSY,3P MA-HP
CNA204 8A-CD9-633-010 CONN ASSY,4P SP
J251 87-A60-569-010 JACK,HTJ-035-18
S609 87-A91-704-080 SW,TACT EVQ 214 05R
S610 87-A91-704-080 SW,TACT EVQ 214 05R
S611 87-A91-704-080 SW,TACT EVQ 214 05R
S612 87-A91-704-080 SW,TACT EVQ 214 05R
S613 87-A91-704-080 SW,TACT EVQ 214 05R
BATT1 C.B
C901 87-010-192-080 C-CAP,S 0.022-50 Z F
C902 87-010-192-080 C-CAP,S 0.022-50 Z F
C903 87-010-192-080 C-CAP,S 0.022-50 Z F
C904 87-010-192-080 C-CAP,S 0.022-50 Z F
CNA901 8A-CD9-627-010 CONN ASSY,3P PWR
PT901 8A-CD9-608-010 PT,H 2.5W
PR901 87-A90-092-080 PROTECTOR,2.5A 491SERIES 60
SW901 87-A91-369-010 SW,AC SL 222 SDKGA41700
BATT2 C.B
MOTOR C.B
M2 9X-262-576-910 MOTOR GEAR ASSY
PIN3 91-564-722-110 CONNECTOR 6P
SW1 91-572-085-120 LEAF SW
!
!
!
All manuals and user guides at all-guides.com
all-guides.com

– 7 –
TRANSISTOR ILLUSTRATION
88
A
Resistor Code
Chip Resistor Part Coding
Figure
Value of resistor
Chip resistor
Wattage Type Tolerance
1/16W
1/10W
1/8W
1608
2125
3216
5%
5%
5%
CJ
CJ
CJ
Form
LW t
1.6 0.8 0.45
2 1.25 0.45
3.2 1.6
108
118
128
: A
: A
CHIP RESISTOR PART CODE
0.55
Resistor Code
Dimensions (mm)
Symbol
1/16W 1005 5% CJ
1.0 0.5 0.35 104
Lt
W
E C B B C E E C B
E C B
E
B
C
2SA933SRS
2SA933RS
2SC1740SR
2SC1740SRS
DTC114TS
DTC124XS
2SB1370E 2SA1296GR
2SC1815Y
2SA1318T
2SA1162Y
2SC2712GR
2SC2714O
DTA114YK
DTC114TK
DTC114YK
DTC124XK
DTC144EK
DTC144TKA
E C B
2SC2001K
All manuals and user guides at all-guides.com

– 8 –
WIRING – 1 (MAIN / CD)
101112131415161718192021222324
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
1234567892526272829303132
All manuals and user guides at all-guides.com

– 9 –
SCHEMATIC DIAGRAM - 1 (MAIN / CD 1 / 2 / H.P. / BATT1 / BATT2)
All manuals and user guides at all-guides.com

– 10 –
SCHEMATIC DIAGRAM - 2 (CD 2 / 2)
All manuals and user guides at all-guides.com
