SERVICE MANUAL

DATA

BASIC TAPE MECHANISM : ZZM-1 YR2NF

BASIC CD MECHANISM : DA11T3C

COMPACT DISC RADIO

CASSETTE RECORDER

CSD-A170

CSD-A110

CSD-A100

CSD-A99

S/M Code No. 09-003-342-2T4

U(S),HA(S)

EZ(L),HR(S)

HE(S),HT(S)

EZ(L,P)

K(S)

SIMPLE

• Replace this Service Manual with ”Revision Publishing” when it is issued.

ELECTRICAL MAIN PARTS LIST - 1

NOTE: The characters in the suffix column indicate the part usage.

110HRJ(S) ..............XX..................................A...................

100HE(S) ...............XX...................................B..................

100EZ(P) ...............XX........................................G.............

100EZ(L) ...............XX.........................................H............

100HT(S) ...............XX..........................................I...........

99K(S) .................XX...........................................J..........

110EZ(L) ...............XX.............................................L........

170U(S) ................XX................................................O.....

170HA(S) ...............XX..................................................Q...

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

JW 605 87-003-097-080 0E COIL,1UH ABCDEFGHIJKLM.......

JW 606 87-003-097-080 0E COIL,1UH ABCDEFGHIJKLM.......

JW 608 87-003-097-080 0E COIL,1UH ABCDEFGHIJKLM.......

JW 633 87-003-098-080 0E COIL,2.2UH ABCDEFGHIJKLM.......

JW 603 87-008-372-080 0E FILTER, EMI BL OIRNI ABCDEFGHIJKLM.......

JW 627 87-008-372-080 0E FILTER, EMI BL OIRNI ABCDEFGHIJKLM.......

C 605 87-010-264-040 0E CAP,E 100-10 5L ABCDEFGHIJKLM.......

C 630 87-010-264-040 0E CAP,E 100-10 5L ABCDEFGHIJKLM.......

C 614 87-010-312-080 0E C-CAP,S 15P-50 CH ABCDEFGHIJKLM.......

C 601 87-010-313-080 0E CAP, CHIP 18P ABCDEFGHIJKLM.......

C 602 87-010-315-080 0E C-CAP,S 27P-50 CH ABCDEFGHIJKLM.......

C 604 87-010-317-010 0E CHIP CAP,S 39P CH ABCDEFGHIJKLM.......

C 603 87-010-319-080 0E C-CAP,S 56P-50 CH ABCDEFGHIJKLM.......

C 608 87-010-415-080 0E CAP ELE SRE 10-50V ABCDEFGHIJKLM.......

C 609 87-010-493-080 0E CAP,E 0.47-50 GAS ABCDEFGHIJKLM.......

C 606 87-012-368-080 0E C-CAP,S 0.1-50 F ABCDEFGHIJKLM.......

C 613 87-012-368-080 0E C-CAP,S 0.1-50 F ABCDEFGHIJKLM.......

C 607 87-015-779-010 0E CHIP CAPACITOR, 0.01 ABCDEFGHIJKLM.......

C 627 87-015-779-010 0E CHIP CAPACITOR, 0.01 ABCDEFGHIJKLM.......

C 628 87-015-779-010 0E CHIP CAPACITOR, 0.01 ABCDEFGHIJKLM.......

C 629 87-015-779-010 0E CHIP CAPACITOR, 0.01 ABCDEFGHIJKLM.......

C 631 87-015-779-010 0E CHIP CAPACITOR, 0.01 ABCDEFGHIJKLM.......

D 601 87-020-465-080 0E DIODE,1SS133 (110MA) ABCDEFGHIJKLM.......

D 602 87-020-465-080 0E DIODE,1SS133 (110MA) ABCDEFGHIJKLM.......

D 607 87-020-465-080 0E DIODE,1SS133 (110MA) ABCDEFGHIJKLM.......

D 608 87-020-465-080 0E DIODE,1SS133 (110MA) ABCDEFGHIJKLM.......

Q 603 87-026-213-080 0E CHIP-TR,DTC114YK ABCDEFGHIJKLM.......

Q 606 87-026-239-080 0E TR,DTC114TK (0.2W) ABCDEFGHIJKLM.......

Q 607 87-026-239-080 0E TR,DTC114TK (0.2W) ABCDEFGHIJKLM.......

Q 608 87-026-239-080 0E TR,DTC114TK (0.2W) ABCDEFGHIJKLM.......

Q 613 87-026-239-080 0E TR,DTC114TK (0.2W) ABCDEFGHIJKLM.......

Q 610 87-026-463-080 0E TR,2SA933S (0.3W) ABCDEFGHIJKLM.......

X 601 87-030-273-010 1A VIB,XTAL 32.768K5PPM ABCDEFGHIJKLM.......

X 602 87-030-376-080 1A VIB,CER CSA5.76MG200 ABCDEFGHIJKLM.......

D 606 87-070-345-080 0E DIODE,IN4148 ABCDEFGHIJKLM.......

CN 601 87-099-757-010 0E CONN,16P 9604S F ABCDEFGHIJKLM.......

C 611 87-A10-189-040 0E CAP,E 220-10 ABCDEFGHIJKLM.......

CN 602 87-A60-079-010 0E CONN,08P H 9604S-08F ABCDEFGHIJKLM.......

S 601 87-A91-704-080 SW,TACT EVQ 214 05R ABCDEFGHIJKLM.......

S 602 87-A91-704-080 SW,TACT EVQ 214 05R ABCDEFGHIJKLM.......

S 603 87-A91-704-080 SW,TACT EVQ 214 05R ABCDEFGHIJKLM.......

S 604 87-A91-704-080 SW,TACT EVQ 214 05R ABCDEFGHIJKLM.......

S 605 87-A91-704-080 SW,TACT EVQ 214 05R ABCDEFGHIJKLM.......

S 611 87-A91-704-080 SW,TACT EVQ 214 05R ABCDEFGHIJKLM.......

LED 611 87-CD8-616-010 LED,SA36-11 HWA-11.0 ABCDEFGHIJKLM.......

LED 602 88-CD6-630-010 LED,934ID RED ABCDEFGHIJKLM.......

LED 608 88-CD6-630-010 LED,934ID RED ABCDEFGHIJKLM.......

LED 610 88-CD6-631-010 LED,934GD GRN A.C..F..............

Q 604 89-317-403-080 0E TR,2SC1740S ABCDEFGHIJKLM.......

IC 601 8A-CD9-610-010 1D C-IC,LC865516A-*** ABCDEFGHIJKLM.......

CNA 604 8A-CDA-623-010 1A CONN ASSY,7P KEY ABCDEFGHIJKLM.......

JW 605 87-003-097-080 COIL,1UH .............NOPQR..

JW 606 87-003-097-080 COIL,1UH .............NOPQR..

JW 608 87-003-097-080 COIL,1UH .............NOPQR..

JW 633 87-003-098-080 COIL,2.2UH .............NOPQR..

JW 603 87-008-372-080 FILTER, EMI BL OIRNI .............NOPQR..

JW 627 87-008-372-080 FILTER, EMI BL OIRNI .............NOPQR..

C 610 87-010-178-010 CAP, S 1000P-50 .............NOPQR..

C 605 87-010-264-040 CAP,E 100-10 5L .............NOPQR..

C 630 87-010-264-040 CAP,E 100-10 5L .............NOPQR..

C 614 87-010-312-080 C-CAP,S 15P-50 CH .............NOPQR..

C 601 87-010-313-080 CAP, CHIP 18P .............NOPQR..

C 602 87-010-315-080 C-CAP,S 27P-50 CH .............NOPQR..

C 604 87-010-317-010 CHIP CAP,S 39P CH .............NOPQR..

C 603 87-010-319-080 C-CAP,S 56P-50 CH .............NOPQR..

C 608 87-010-415-080 CAP ELE SRE 10-50V .............NOPQR..

C 612 87-010-415-080 CAP ELE SRE 10-50V .............NOPQR..

C 609 87-010-493-080 CAP,E 0.47-50 GAS .............NOPQR..

C 606 87-012-368-080 C-CAP,S 0.1-50 F .............NOPQR..

C 613 87-012-368-080 C-CAP,S 0.1-50 F .............NOPQR..

C 607 87-015-779-010 CHIP CAPACITOR, 0.01 .............NOPQR..

C 627 87-015-779-010 CHIP CAPACITOR, 0.01 .............NOPQR..

C 628 87-015-779-010 CHIP CAPACITOR, 0.01 .............NOPQR..

C 629 87-015-779-010 CHIP CAPACITOR, 0.01 .............NOPQR..

C 631 87-015-779-010 CHIP CAPACITOR, 0.01 .............NOPQR..

D 601 87-020-465-080 DIODE,1SS133 (110MA) .............NOPQR..

D 602 87-020-465-080 DIODE,1SS133 (110MA) .............NOPQR..

D 604 87-020-465-080 DIODE,1SS133 (110MA) .............NOPQR..

ELECTRICAL MAIN PARTS LIST - 2

D 605 87-020-465-080 DIODE,1SS133 (110MA) .............NOPQR..

D 607 87-020-465-080 DIODE,1SS133 (110MA) .............NOPQR..

D 608 87-020-465-080 DIODE,1SS133 (110MA) .............NOPQR..

Q 603 87-026-213-080 CHIP-TR,DTC114YK .............NOPQR..

Q 646 87-026-237-080 CHIP-TR,DTC124XK .............NOPQR..

Q 606 87-026-239-080 TR,DTC114TK (0.2W) .............NOPQR..

Q 607 87-026-239-080 TR,DTC114TK (0.2W) .............NOPQR..

Q 608 87-026-239-080 TR,DTC114TK (0.2W) .............NOPQR..

Q 613 87-026-239-080 TR,DTC114TK (0.2W) .............NOPQR..

Q 610 87-026-463-080 TR,2SA933S (0.3W) .............NOPQR..

X 601 87-030-273-010 VIB,XTAL 32.768K5PPM .............NOPQR..

X 602 87-030-376-080 VIB,CER CSA5.76MG200 .............NOPQR..

D 606 87-070-345-080 DIODE,IN4148 .............NOPQR..

CN 601 87-099-757-010 CONN,16P 9604S F .............NOPQR..

C 611 87-A10-189-040 CAP,E 220-10 .............NOPQR..

IC 602 87-A20-650-010 IC,RPM6938-V11 .............NOPQR..

CN 602 87-A60-079-010 CONN,08P H 9604S-08F .............NOPQR..

S 601 87-A91-704-080 SW,TACT EVQ 214 05R .............NOPQR..

S 602 87-A91-704-080 SW,TACT EVQ 214 05R .............NOPQR..

S 603 87-A91-704-080 SW,TACT EVQ 214 05R .............NOPQR..

S 604 87-A91-704-080 SW,TACT EVQ 214 05R .............NOPQR..

S 605 87-A91-704-080 SW,TACT EVQ 214 05R .............NOPQR..

S 609 87-A91-704-080 SW,TACT EVQ 214 05R .............NOPQR..

S 611 87-A91-704-080 SW,TACT EVQ 214 05R .............NOPQR..

LED 611 87-CD8-616-010 LED,SA36-11 HWA-11.0 .............NOPQR..

LED 602 88-CD6-630-010 LED,934ID RED .............NOPQR..

LED 608 88-CD6-630-010 LED,934ID RED .............NOPQR..

LED 610 88-CD6-631-010 LED,934GD GRN .............NOPQR..

Q 604 89-317-403-080 TR,2SC1740S .............NOPQR..

IC 601 8A-CD9-610-010 C-IC,LC865516A-*** .............NOPQR..

CNA 604 8A-CDA-623-010 CONN ASSY,7P KEY .............NOPQR..

CN 605 87-A60-117-010 0E CONN,7P H S2M-7WR ABCDEFGHIJKLM.......

J 251 87-A60-569-010 1C JACK,HTJ-035-18 ABCDEFGHIJKLM.......

CN 204 87-A60-685-010 0E CONN,4P H WHT EH ABCDEFGHIJKLM.......

LED 606 88-CD6-630-010 LED,934ID RED ABCDEFGHIJKLM.......

LED 607 88-CD6-630-010 LED,934ID RED ABCDEFGHIJKLM.......

CNA 203 8A-CDA-628-010 CONN ASSY,4P MA-HP ABCDEFGHIJKLM.......

CN 605 87-A60-117-010 CONN,7P H S2M-7WR .............NOPQR..

J 251 87-A60-569-010 JACK,HTJ-035-18 .............NOPQR..

CN 204 87-A60-685-010 CONN,4P H WHT EH .............NOPQR..

S 606 87-A91-704-080 SW,TACT EVQ 214 05R .............NOPQR..

S 607 87-A91-704-080 SW,TACT EVQ 214 05R .............NOPQR..

S 608 87-A91-704-080 SW,TACT EVQ 214 05R .............NOPQR..

S 614 87-A91-704-080 SW,TACT EVQ 214 05R .............NOPQR..

S 615 87-A91-704-080 SW,TACT EVQ 214 05R .............NOPQR..

D 606 88-CD6-630-010 LED,934ID RED .............NOPQR..

D 607 88-CD6-630-010 LED,934ID RED .............NOPQR..

CNA 203 8A-CDA-628-010 CONN ASSY,4P MA-HP .............NOPQR..

C 901 87-010-192-080 0E C-CAP,S 0.022-50 F ABCDEFGHIJKLM.......

C 902 87-010-192-080 0E C-CAP,S 0.022-50 F ABCDEFGHIJKLM.......

C 903 87-010-192-080 0E C-CAP,S 0.022-50 F ABCDEFGHIJKLM.......

C 904 87-010-192-080 0E C-CAP,S 0.022-50 F ABCDEFGHIJKLM.......

D 901 87-A40-465-010 0E DIODE,FR202 ABCDEFGHIJKLM.......

D 902 87-A40-465-010 0E DIODE,FR202 ABCDEFGHIJKLM.......

D 903 87-A40-465-010 0E DIODE,FR202 ABCDEFGHIJKLM.......

D 904 87-A40-465-010 0E DIODE,FR202 ABCDEFGHIJKLM.......

D 905 87-A40-465-010 0E DIODE,FR202 ABCDEFGHIJKLM.......

PR 901 87-A90-092-080 1A PROTECTOR,2.5A 491 AB.DEFGHIJKLM.......

SP 901 87-CD6-213-010 SPR-C,BATT (-) ABCDEFGHIJKLM.......

SP 902 87-CD6-213-010 SPR-C,BATT (-) ABCDEFGHIJKLM.......

SP 903 87-CD6-213-010 SPR-C,BATT (-) ABCDEFGHIJKLM.......

SP 904 87-CD6-213-010 SPR-C,BATT (-) ABCDEFGHIJKLM.......

CNA 901 8A-CDA-627-010 CONN ASSY,3P PWR ABCDEFGHIJKLM.......

C 901 87-010-192-080 C-CAP,S 0.022-50 F .............NOPQR..

C 902 87-010-192-080 C-CAP,S 0.022-50 F .............NOPQR..

C 903 87-010-192-080 C-CAP,S 0.022-50 F .............NOPQR..

C 904 87-010-192-080 C-CAP,S 0.022-50 F .............NOPQR..

D 901 87-A40-465-010 DIODE,FR202 .............NOPQR..

D 902 87-A40-465-010 DIODE,FR202 .............NOPQR..

D 903 87-A40-465-010 DIODE,FR202 .............NOPQR..

D 904 87-A40-465-010 DIODE,FR202 .............NOPQR..

D 905 87-A40-465-010 DIODE,FR202 .............NOPQR..

PR 901 87-A90-092-080 PROTECTOR,2.5A 491 .............N.PQR..

SP 901 87-CD6-213-010 SPR-C,BATT (-) .............NOPQR..

SP 902 87-CD6-213-010 SPR-C,BATT (-) .............NOPQR..

SP 903 87-CD6-213-010 SPR-C,BATT (-) .............NOPQR..

SP 904 87-CD6-213-010 SPR-C,BATT (-) .............NOPQR..

CNA 901 8A-CDA-627-010 CONN ASSY,3P PWR .............NOPQR..

C 239 87-010-197-080 0E CAP, CHIP 0.01 DM ABCDEFGHIJKLM.......

C 240 87-010-197-080 0E CAP, CHIP 0.01 DM ABCDEFGHIJKLM.......

C 231 87-010-213-080 0E C-CAP,S 0.015-50 B ABCDEFGHIJKLM.......

C 232 87-010-213-080 0E C-CAP,S 0.015-50 B ABCDEFGHIJKLM.......

C 310 87-010-248-080 0E CAP, ELECT 220-10V ABCDEFGHIJKLM.......

C 316 87-010-263-080 0E CAP, ELECT 100-10V ABCDEFGHIJKLM.......

C 237 87-010-371-080 0E CAP, ELECT 470-6.3V ABCDEFGHIJKLM.......

C 239 87-010-805-080 0E CAP, S 1-16 .B..E.GHIJK.........

C 240 87-010-805-080 0E CAP, S 1-16 .B..E.GHIJK.........

C 317 87-015-819-080 0E CAPACITOR,0.01 ABCDEFGHIJKLM.......

C 215 87-016-460-080 0E C-CAP,S 0.22-16 B ABCDEFGHIJKLM.......

C 216 87-016-460-080 0E C-CAP,S 0.22-16 B ABCDEFGHIJKLM.......

C 235 87-016-669-080 0E C-CAP,S 0.1-25 K B ABCDEFGHIJKLM.......

C 236 87-016-669-080 0E C-CAP,S 0.1-25 K B ABCDEFGHIJKLM.......

C 233 87-A10-201-080 0E C-CAP,S0.33-16 KB ABCDEFGHIJKLM.......

ELECTRICAL MAIN PARTS LIST - 3

C 234 87-A10-201-080 0E C-CAP,S0.33-16 KB ABCDEFGHIJKLM.......

C 211 87-A11-177-080 0E C-CAP,S 0.15-16 K B ABCDEFGHIJKLM.......

C 212 87-A11-177-080 0E C-CAP,S 0.15-16 K B ABCDEFGHIJKLM.......

IC 203 87-A21-443-040 1C C-IC,M62495AFP .B.DE.GHIJK.M.......

IC 203 87-A21-520-040 1E C-IC,M61509FP A.C..F.....L........

D 307 87-A40-234-080 0E ZENER,MTZJ5.6A ABCDEFGHIJKLM.......

Q 306 89-318-154-080 0E TR,2SC1815 (0.4W) ABCDEFGHIJKLM.......

C 239 87-010-197-080 CAP, CHIP 0.01 DM .............NOPQR..

C 240 87-010-197-080 CAP, CHIP 0.01 DM .............NOPQR..

C 231 87-010-213-080 C-CAP,S 0.015-50 B .............NOPQR..

C 232 87-010-213-080 C-CAP,S 0.015-50 B .............NOPQR..

C 310 87-010-248-080 CAP, ELECT 220-10V .............NOPQR..

C 316 87-010-263-080 CAP, ELECT 100-10V .............NOPQR..

C 237 87-010-371-080 CAP, ELECT 470-6.3V .............NOPQR..

C 483 87-012-156-080 C-CAP,S 220P-50 CH .............NOPQR..

C 484 87-012-156-080 C-CAP,S 220P-50 CH .............NOPQR..

C 317 87-015-819-080 CAPACITOR,0.01 .............NOPQR..

C 215 87-016-460-080 C-CAP,S 0.22-16 B .............NOPQR..

C 216 87-016-460-080 C-CAP,S 0.22-16 B .............NOPQR..

C 235 87-016-669-080 C-CAP,S 0.1-25 K B .............NOPQR..

C 236 87-016-669-080 C-CAP,S 0.1-25 K B .............NOPQR..

C 233 87-A10-201-080 C-CAP,S0.33-16 KB .............NOPQR..

C 234 87-A10-201-080 C-CAP,S0.33-16 KB .............NOPQR..

C 211 87-A11-177-080 C-CAP,S 0.15-16 K B .............NOPQR..

C 212 87-A11-177-080 C-CAP,S 0.15-16 K B .............NOPQR..

IC 203 87-A21-520-040 C-IC,M61509FP .............NOPQR..

D 307 87-A40-234-080 ZENER,MTZJ5.6A .............NOPQR..

Q 306 89-318-154-080 TR,2SC1815 (0.4W) .............NOPQR..

C 267 87-010-112-080 0E CAP, ELECT 100-16V ABCDEFGHIJKLM.......

C 268 87-010-112-080 0E CAP, ELECT 100-16V ABCDEFGHIJKLM.......

C 263 87-010-178-080 0E CHIP CAP 1000P ABCDEFGHIJKLM.......

C 264 87-010-178-080 0E CHIP CAP 1000P ABCDEFGHIJKLM.......

C 271 87-010-237-080 1A CAP, ELECT 1000-16V ABCDEFGHIJKLM.......

C 272 87-010-237-080 1A CAP, ELECT 1000-16V ABCDEFGHIJKLM.......

C 265 87-010-263-080 0E CAP, ELECT 100-10V ABCDEFGHIJKLM.......

C 266 87-010-263-080 0E CAP, ELECT 100-10V ABCDEFGHIJKLM.......

C 279 87-010-385-080 0E CAP, ELECT 220-25V ABCDEFGHIJKLM.......

C 261 87-010-402-080 0E CAP, ELECT 2.2-50V ABCDEFGHIJKLM.......

C 262 87-010-402-080 0E CAP, ELECT 2.2-50V ABCDEFGHIJKLM.......

C 251 87-010-404-080 0E CAP, ELECT 4.7-50V ABCDEFGHIJKLM.......

C 278 87-010-405-080 0E CAP, ELECT 10-50V ABCDEFGHIJKLM.......

IC 202 87-A21-064-010 1D IC,LA4227 ABCDEFGHIJKLM.......

Q 244 89-318-154-080 0E TR,2SC1815 (0.4W) ABCDEFGHIJKLM.......

Q 245 89-318-154-080 0E TR,2SC1815 (0.4W) ABCDEFGHIJKLM.......

CN 202 8A-CH4-689-010 0E CONN,3P V 2.5 ABCDEFGHIJKLM.......

C 267 87-010-112-080 CAP, ELECT 100-16V .............NOPQR..

C 268 87-010-112-080 CAP, ELECT 100-16V .............NOPQR..

C 263 87-010-178-080 CHIP CAP 1000P .............NOPQR..

C 264 87-010-178-080 CHIP CAP 1000P .............NOPQR..

C 271 87-010-237-080 CAP, ELECT 1000-16V .............NOPQR..

C 272 87-010-237-080 CAP, ELECT 1000-16V .............NOPQR..

C 265 87-010-263-080 CAP, ELECT 100-10V .............NOPQR..

C 266 87-010-263-080 CAP, ELECT 100-10V .............NOPQR..

C 279 87-010-385-080 CAP, ELECT 220-25V .............NOPQR..

C 261 87-010-402-080 CAP, ELECT 2.2-50V .............NOPQR..

C 262 87-010-402-080 CAP, ELECT 2.2-50V .............NOPQR..

C 251 87-010-404-080 CAP, ELECT 4.7-50V .............NOPQR..

C 278 87-010-405-080 CAP, ELECT 10-50V .............NOPQR..

IC 202 87-A21-064-010 IC,LA4227 .............NOPQR..

Q 244 89-318-154-080 TR,2SC1815 (0.4W) .............NOPQR..

Q 245 89-318-154-080 TR,2SC1815 (0.4W) .............NOPQR..

CN 202 8A-CH4-689-010 CONN,3P V 2.5 .............NOPQR..

C 308 87-010-221-080 0E CAP, ELECT 470-10V ABCDEFGHIJKLM.......

C 311 87-010-374-080 0E CAP, ELECT 47-10V ABCDEFGHIJKLM.......

C 312 87-010-385-080 0E CAP, ELECT 220-25V ABCDEFGHIJKLM.......

C 307 87-010-401-080 0E CAP, ELECT 1-50V ABCDEFGHIJKLM.......

C 306 87-010-404-080 0E CAP, ELECT 4.7-50V ABCDEFGHIJKLM.......

C 325 87-010-405-080 0E CAP, ELECT 10-50V ABCDEFGHIJKLM.......

C 301 87-016-495-000 1B CAP,E 3300-25 M SMG ABCDEFGHIJKLM.......

D 311 87-017-932-080 0E ZENER,MTJ6.2B ABCDEFGHIJKLM.......

Q 303 87-026-291-080 1A TR,DTC124XS ABCDEFGHIJKLM.......

Q 305 87-026-462-080 0E TR,2SC1740 S(RS 0.3W) ABCDEFGHIJKLM.......

Q 302 87-026-463-080 0E TR,2SA933S (0.3W) ABCDEFGHIJKLM.......

D 303 87-070-345-080 0E DIODE,IN4148 ABCDEFGHIJKLM.......

D 305 87-070-345-080 0E DIODE,IN4148 ABCDEFGHIJKLM.......

D 306 87-070-345-080 0E DIODE,IN4148 ABCDEFGHIJKLM.......

D 304 87-A40-648-080 0E ZENER,MTZJ8.2A ABCDEFGHIJKLM.......

Q 301 89-112-965-080 0E TR,2SA1296 (0.75W) ABCDEFGHIJKLM.......

Q 304 89-213-702-010 1A TR,2SB1370 (1.8W) ABCDEFGHIJKLM.......

Q 310 89-318-154-080 0E TR,2SC1815 (0.4W) ABCDEFGHIJKLM.......

CN 301 8A-CH4-689-010 0E CONN,3P V 2.5 ABCDEFGHIJKLM.......

C 308 87-010-221-080 CAP, ELECT 470-10V .............NOPQR..

C 311 87-010-374-080 CAP, ELECT 47-10V .............NOPQR..

C 312 87-010-385-080 CAP, ELECT 220-25V .............NOPQR..

C 307 87-010-401-080 CAP, ELECT 1-50V .............NOPQR..

C 306 87-010-404-080 CAP, ELECT 4.7-50V .............NOPQR..

C 325 87-010-405-080 CAP, ELECT 10-50V .............NOPQR..

C 301 87-016-495-000 CAP,E 3300-25 M SMG .............NOPQR..

D 311 87-017-932-080 ZENER,MTJ6.2B .............NOPQR..

Q 303 87-026-291-080 TR,DTC124XS .............NOPQR..

Q 305 87-026-462-080 TR,2SC1740 S(RS 0.3W) .............NOPQR..

Q 302 87-026-463-080 TR,2SA933S (0.3W) .............NOPQR..

D 303 87-070-345-080 DIODE,IN4148 .............NOPQR..

ELECTRICAL MAIN PARTS LIST - 4

D 305 87-070-345-080 DIODE,IN4148 .............NOPQR..

D 306 87-070-345-080 DIODE,IN4148 .............NOPQR..

D 304 87-A40-648-080 ZENER,MTZJ8.2A .............NOPQR..

Q 301 89-112-965-080 TR,2SA1296 (0.75W) .............NOPQR..

Q 304 89-213-702-010 TR,2SB1370 (1.8W) .............NOPQR..

Q 310 89-318-154-080 TR,2SC1815 (0.4W) .............NOPQR..

CN 301 8A-CH4-689-010 CONN,3P V 2.5 .............NOPQR..

L 801 87-007-342-010 0E COIL,OSC 85K BIAS ABCDEFGHIJKLM.......

C 811 87-010-178-080 0E CHIP CAP 1000P ABCDEFGHIJKLM.......

C 812 87-010-178-080 0E CHIP CAP 1000P ABCDEFGHIJKLM.......

C 829 87-010-178-080 0E CHIP CAP 1000P ABCDEFGHIJKLM.......

C 830 87-010-178-080 0E CHIP CAP 1000P ABCDEFGHIJKLM.......

C 845 87-010-178-080 0E CHIP CAP 1000P ABCDEFGHIJKLM.......

C 852 87-010-178-080 0E CHIP CAP 1000P ABCDEFGHIJKLM.......

C 816 87-010-180-080 0E C-CER 1500P ABCDEFGHIJKLM.......

C 817 87-010-180-080 0E C-CER 1500P ABCDEFGHIJKLM.......

C 851 87-010-186-080 0E CAP,CHIP 4700P ABCDEFGHIJKLM.......

C 843 87-010-197-080 0E CAP, CHIP 0.01 DM ABCDEFGHIJKLM.......

C 831 87-010-198-080 0E CAP, CHIP 0.022 ABCDEFGHIJKLM.......

C 801 87-010-248-080 0E CAP, ELECT 220-10V ABCDEFGHIJKLM.......

C 834 87-010-248-080 0E CAP, ELECT 220-10V ABCDEFGHIJKLM.......

C 30 87-010-260-080 0E CAP, ELECT 47-25V ABCDEFGHIJKLM.......

C 322 87-010-260-080 0E CAP, ELECT 47-25V ABCDEFGHIJKLM.......

C 846 87-010-263-080 0E CAP, ELECT 100-10V ABCDEFGHIJKLM.......

C 247 87-010-401-080 0E CAP, ELECT 1-50V ABCDEFGHIJKLM.......

C 248 87-010-401-080 0E CAP, ELECT 1-50V ABCDEFGHIJKLM.......

C 809 87-010-401-080 0E CAP, ELECT 1-50V ABCDEFGHIJKLM.......

C 810 87-010-401-080 0E CAP, ELECT 1-50V ABCDEFGHIJKLM.......

C 821 87-010-401-080 0E CAP, ELECT 1-50V ABCDEFGHIJKLM.......

C 822 87-010-401-080 0E CAP, ELECT 1-50V ABCDEFGHIJKLM.......

C 807 87-010-405-080 0E CAP, ELECT 10-50V ABCDEFGHIJKLM.......

C 808 87-010-405-080 0E CAP, ELECT 10-50V ABCDEFGHIJKLM.......

C 805 87-012-365-080 0E C-CAP,S 0.027-25VBK ABCDEFGHIJKLM.......

C 806 87-012-365-080 0E C-CAP,S 0.027-25VBK ABCDEFGHIJKLM.......

D 308 87-017-978-080 0E DIODE,1N4003 ABCDEFGHIJKLM.......

C 844 87-018-124-080 0E CAP, CER 270P-50V ABCDEFGHIJKLM.......

C 833 87-018-195-080 0E CAP, CER 1200P-16V ABCDEFGHIJKLM.......

D 809 87-020-465-080 0E DIODE,1SS133 (110MA) ABCDEFGHIJKLM.......

D 810 87-020-465-080 0E DIODE,1SS133 (110MA) ABCDEFGHIJKLM.......

Q 810 87-026-464-080 0E TR,DTC114TS (0.3W) ABCDEFGHIJKLM.......

R 840 87-029-124-010 0E RES,FUSE 2.2-1/4 ABCDEFGHIJKLM.......

D 309 87-070-345-080 0E DIODE,IN4148 ABCDEFGHIJKLM.......

D 807 87-070-345-080 0E DIODE,IN4148 ABCDEFGHIJKLM.......

D 808 87-070-345-080 0E DIODE,IN4148 ABCDEFGHIJKLM.......

C 853 87-A11-132-080 0E CAP,TC U 0.01-50 K B ABCDEFGHIJKLM.......

IC 801 87-A21-431-010 0E IC,BA4560N ABCDEFGHIJKLM.......

CN 801 87-A60-110-010 0E CONN,4P V S2M-4W ABCDEFGHIJKLM.......

Q 801 89-318-154-080 0E TR,2SC1815 (0.4W) ABCDEFGHIJKLM.......

CN 802 8A-CH4-687-010 0E CONN,4P V 2.5 ABCDEFGHIJKLM.......

SW 801 8Z-CD9-609-010 SW,SL 1-6-2 PS62D01 ABCDEFGHIJKLM.......

L 801 87-007-342-010 COIL,OSC 85K BIAS .............NOPQR..

C 811 87-010-178-080 CHIP CAP 1000P .............NOPQR..

C 812 87-010-178-080 CHIP CAP 1000P .............NOPQR..

C 829 87-010-178-080 CHIP CAP 1000P .............NOPQR..

C 830 87-010-178-080 CHIP CAP 1000P .............NOPQR..

C 845 87-010-178-080 CHIP CAP 1000P .............NOPQR..

C 852 87-010-178-080 CHIP CAP 1000P .............NOPQR..

C 816 87-010-180-080 C-CER 1500P .............NOPQR..

C 817 87-010-180-080 C-CER 1500P .............NOPQR..

C 851 87-010-186-080 CAP,CHIP 4700P .............NOPQR..

C 843 87-010-197-080 CAP, CHIP 0.01 DM .............NOPQR..

C 831 87-010-198-080 CAP, CHIP 0.022 .............NOPQR..

C 801 87-010-248-080 CAP, ELECT 220-10V .............NOPQR..

C 834 87-010-248-080 CAP, ELECT 220-10V .............NOPQR..

C 30 87-010-260-080 CAP, ELECT 47-25V .............NOPQR..

C 322 87-010-260-080 CAP, ELECT 47-25V .............NOPQR..

C 846 87-010-263-080 CAP, ELECT 100-10V .............NOPQR..

C 821 87-010-401-080 CAP, ELECT 1-50V .............NOPQR..

C 822 87-010-401-080 CAP, ELECT 1-50V .............NOPQR..

C 807 87-010-405-080 CAP, ELECT 10-50V .............NOPQR..

C 808 87-010-405-080 CAP, ELECT 10-50V .............NOPQR..

C 805 87-012-365-080 C-CAP,S 0.027-25VBK .............NOPQR..

C 806 87-012-365-080 C-CAP,S 0.027-25VBK .............NOPQR..

D 308 87-017-978-080 DIODE,1N4003 .............NOPQR..

C 844 87-018-124-080 CAP, CER 270P-50V .............NOPQR..

C 833 87-018-195-080 CAP, CER 1200P-16V .............NOPQR..

D 809 87-020-465-080 DIODE,1SS133 (110MA) .............NOPQR..

D 810 87-020-465-080 DIODE,1SS133 (110MA) .............NOPQR..

Q 810 87-026-464-080 TR,DTC114TS (0.3W) .............NOPQR..

R 840 87-029-124-010 RES,FUSE 2.2-1/4 .............NOPQR..

D 309 87-070-345-080 DIODE,IN4148 .............NOPQR..

D 807 87-070-345-080 DIODE,IN4148 .............NOPQR..

D 808 87-070-345-080 DIODE,IN4148 .............NOPQR..

C 853 87-A11-132-080 CAP,TC U 0.01-50 K B .............NOPQR..

IC 801 87-A21-431-010 IC,BA4560N .............NOPQR..

CN 801 87-A60-110-010 CONN,4P V S2M-4W .............NOPQR..

Q 801 89-318-154-080 TR,2SC1815 (0.4W) .............NOPQR..

CN 802 8A-CH4-687-010 CONN,4P V 2.5 .............NOPQR..

SW 801 8Z-CD9-609-010 SW,SL 1-6-2 PS62D01 .............NOPQR..

C 321 87-010-197-080 0E CAP, CHIP 0.01 DM ABCDEFGHIJKLM.......

C 322 87-010-263-080 0E CAP, ELECT 100-10V ABCDEFGHIJKLM.......

Q 841 87-026-291-080 1A TR,DTC124XS ABCDEFGHIJKLM.......

D 323 87-070-345-080 0E DIODE,IN4148 AB.DEFGHIJKLM.......

ELECTRICAL MAIN PARTS LIST - 5

CN 201 87-099-018-010 0E CONN,16P ABCDEFGHIJKLM.......

D 32 87-A40-509-080 0E ZENER,MTZJ6.8C ..C.................

D 32 87-A40-650-080 0E ZENER,MTZJ6.8A AB.DEFGHIJKLM.......

Q 321 89-318-154-080 0E TR,2SC1815 (0.4W) ABCDEFGHIJKLM.......

CNA 302 8A-CDA-629-010 CONN ASSY,6P MA-TU ABCDEFGHIJKLM.......

C 321 87-010-197-080 CAP, CHIP 0.01 DM .............NOPQR..

C 322 87-010-263-080 CAP, ELECT 100-10V .............NOPQR..

Q 841 87-026-291-080 TR,DTC124XS .............NOPQR..

D 32 87-027-399-080 ZENER,HZ7A3L (200MA) .............NOPQR..

D 323 87-070-345-080 DIODE,IN4148 .............NOPQR..

CN 201 87-099-018-010 CONN,16P .............NOPQR..

D 32 87-A40-509-080 ZENER,MTZJ6.8C ..............O.....

D 32 87-A40-650-080 ZENER,MTZJ6.8A .............N.PQR..

Q 321 89-318-154-080 TR,2SC1815 (0.4W) .............NOPQR..

CNA 302 8A-CDA-629-010 CONN ASSY,6P MA-TU .............NOPQR..

L 401 87-003-102-080 0E COIL, 10UH ABCDEFGHIJKLM.......

L 404 87-003-152-080 0E COIL, 100UH ABCDEFGHIJKLM.......

C 440 87-010-145-080 0E C-CAP,S 1P-50 CH ABCDEFGHIJKLM.......

C 425 87-010-176-080 0E C-CAP,S 680P-50 SL ABCDEFGHIJKLM.......

C 407 87-010-178-080 0E CHIP CAP 1000P ABCDEFGHIJKLM.......

C 439 87-010-178-080 0E CHIP CAP 1000P ABCDEFGHIJKLM.......

C 493 87-010-180-080 0E C-CER 1500P ..C.................

C 422 87-010-184-080 0E CHIP CAPACITOR 3300P(K) ABCDEFGHIJKLM.......

C 434 87-010-184-080 0E CHIP CAPACITOR 3300P(K) ABCDEFGHIJKLM.......

C 429 87-010-186-080 0E CAP,CHIP 4700P ABCDEFGHIJKLM.......

C 494 87-010-197-080 0E CAP, CHIP 0.01 DM ABCDEFGHIJKLM.......

C 408 87-010-198-080 0E CAP, CHIP 0.022 ABCDEFGHIJKLM.......

C 418 87-010-213-080 0E C-CAP,S 0.015-50 B ABCDEFGHIJKLM.......

C 480 87-010-221-080 0E CAP, ELECT 470-10V ABCDEFGHIJKLM.......

C 476 87-010-236-080 0E CAP,E 1000-10 SME ABCDEFGHIJKLM.......

C 455 87-010-247-080 0E CAP, ELECT 100-50V ABCDEFGHIJKLM.......

C 404 87-010-248-080 0E CAP, ELECT 220-10V ABCDEFGHIJKLM.......

C 409 87-010-248-080 0E CAP, ELECT 220-10V ABCDEFGHIJKLM.......

C 462 87-010-248-080 0E CAP, ELECT 220-10V ABCDEFGHIJKLM.......

C 403 87-010-263-080 0E CAP, ELECT 100-10V ABCDEFGHIJKLM.......

C 410 87-010-263-080 0E CAP, ELECT 100-10V ABCDEFGHIJKLM.......

C 459 87-010-263-080 0E CAP, ELECT 100-10V ABCDEFGHIJKLM.......

C 467 87-010-263-080 0E CAP, ELECT 100-10V ABCDEFGHIJKLM.......

C 478 87-010-263-080 0E CAP, ELECT 100-10V ABCDEFGHIJKLM.......

C 457 87-010-312-080 0E C-CAP,S 15P-50 CH ABCDEFGHIJKLM.......

C 458 87-010-312-080 0E C-CAP,S 15P-50 CH ABCDEFGHIJKLM.......

C 442 87-010-313-080 0E CAP, CHIP 18P ABCDEFGHIJKLM.......

C 448 87-010-315-080 0E C-CAP,S 27P-50 CH ABCDEFGHIJKLM.......

C 502 87-010-322-080 0E C-CAP,S 100P-50 CH ABCDEFGHIJKLM.......

C 503 87-010-322-080 0E C-CAP,S 100P-50 CH ABCDEFGHIJKLM.......

C 504 87-010-322-080 0E C-CAP,S 100P-50 CH ABCDEFGHIJKLM.......

C 505 87-010-322-080 0E C-CAP,S 100P-50 CH ABCDEFGHIJKLM.......

C 506 87-010-322-080 0E C-CAP,S 100P-50 CH ABCDEFGHIJKLM.......

C 406 87-010-374-080 0E CAP, ELECT 47-10V ABCDEFGHIJKLM.......

C 432 87-010-374-080 0E CAP, ELECT 47-10V ABCDEFGHIJKLM.......

C 436 87-010-374-080 0E CAP, ELECT 47-10V ABCDEFGHIJKLM.......

C 412 87-010-401-080 0E CAP, ELECT 1-50V ABCDEFGHIJKLM.......

C 433 87-010-401-080 0E CAP, ELECT 1-50V ABCDEFGHIJKLM.......

C 401 87-010-403-080 0E CAP, ELECT 3.3-50V ABCDEFGHIJKLM.......

C 437 87-010-404-080 0E CAP, ELECT 4.7-50V ABCDEFGHIJKLM.......

C 465 87-010-404-080 0E CAP, ELECT 4.7-50V ABCDEFGHIJKLM.......

C 414 87-010-405-080 0E CAP, ELECT 10-50V ABCDEFGHIJKLM.......

C 481 87-010-405-080 0E CAP, ELECT 10-50V ABCDEFGHIJKLM.......

C 482 87-010-405-080 0E CAP, ELECT 10-50V ABCDEFGHIJKLM.......

C 470 87-010-544-080 0E CAP, ELECT 0.1-50V ABCDEFGHIJKLM.......

C 416 87-010-545-080 0E CAP, ELECT 0.22-50V ABCDEFGHIJKLM.......

C 431 87-010-545-080 0E CAP, ELECT 0.22-50V ABCDEFGHIJKLM.......

C 423 87-010-992-080 0E C-CAP,S 0.047-25 B ABCDEFGHIJKLM.......

C 450 87-012-140-080 0E CAP 470P ABCDEFGHIJKLM.......

C 469 87-012-154-080 0E C-CAP,S 150P-50 CH ABCDEFGHIJKLM.......

C 430 87-012-156-080 0E C-CAP,S 220P-50 CH ABCDEFGHIJKLM.......

C 451 87-012-156-080 0E C-CAP,S 220P-50 CH ABCDEFGHIJKLM.......

C 417 87-012-157-080 0E C-CAP,S 330P-50 CH ABCDEFGHIJKLM.......

C 445 87-012-368-080 0E C-CAP,S 0.1-50 F ABCDEFGHIJKLM.......

C 446 87-012-368-080 0E C-CAP,S 0.1-50 F ABCDEFGHIJKLM.......

C 447 87-012-368-080 0E C-CAP,S 0.1-50 F ABCDEFGHIJKLM.......

C 466 87-012-368-080 0E C-CAP,S 0.1-50 F ABCDEFGHIJKLM.......

C 489 87-012-368-080 0E C-CAP,S 0.1-50 F ABCDEFGHIJKLM.......

C 490 87-012-368-080 0E C-CAP,S 0.1-50 F ABCDEFGHIJKLM.......

C 501 87-012-368-080 0E C-CAP,S 0.1-50 F ABCDEFGHIJKLM.......

C 471 87-015-785-080 0E CHIP CAPACITOR, 0.1FZ-25Z ABCDEFGHIJKLM.......

C 472 87-015-785-080 0E CHIP CAPACITOR, 0.1FZ-25Z ABCDEFGHIJKLM.......

C 473 87-015-785-080 0E CHIP CAPACITOR, 0.1FZ-25Z ABCDEFGHIJKLM.......

C 474 87-015-785-080 0E CHIP CAPACITOR, 0.1FZ-25Z ABCDEFGHIJKLM.......

C 460 87-015-819-080 0E CAPACITOR,0.01 ABCDEFGHIJKLM.......

C 413 87-016-369-080 0E C-CAP,S 0.033-25 B K ABCDEFGHIJKLM.......

C 420 87-016-369-080 0E C-CAP,S 0.033-25 B K ABCDEFGHIJKLM.......

C 438 87-016-669-080 0E C-CAP,S 0.1-25 K B ABCDEFGHIJKLM.......

C 510 87-016-669-080 0E C-CAP,S 0.1-25 K B ABCDEFGHIJKLM.......

SFR 430 87-024-437-080 0E SFR100K,RH063EC ABCDEFGHIJKLM.......

Q 403 87-026-295-080 0E TR,DTC144TK ABCDEFGHIJKLM.......

Q 406 87-026-295-080 0E TR,DTC144TK ABCDEFGHIJKLM.......

Q 407 87-026-295-080 0E TR,DTC144TK ABCDEFGHIJKLM.......

Q 408 87-026-295-080 0E TR,DTC144TK ABCDEFGHIJKLM.......

D 401 87-070-345-080 0E DIODE,IN4148 ABCDEFGHIJKLM.......

D 402 87-070-345-080 0E DIODE,IN4148 ABCDEFGHIJKLM.......

D 403 87-070-345-080 0E DIODE,IN4148 ABCDEFGHIJKLM.......

CN 403 87-099-201-010 0E CONN,8P 6216 H ABCDEFGHIJKLM.......

ELECTRICAL MAIN PARTS LIST - 6

C 411 87-A11-177-080 0E C-CAP,S 0.15-16 K B ABCDEFGHIJKLM.......

C 421 87-A11-177-080 0E C-CAP,S 0.15-16 K B ABCDEFGHIJKLM.......

C 419 87-A11-608-080 0E C-CAP,S 0.33-25 K B ABCDEFGHIJKLM.......

C 426 87-A11-608-080 0E C-CAP,S 0.33-25 K B ABCDEFGHIJKLM.......

IC 401 87-A20-446-010 1E C-IC,LA9241ML ABCDEFGHIJKLM.......

IC 402 87-A20-459-010 2A C-IC,LC78622ED ABCDEFGHIJKLM.......

IC 404 87-A21-093-010 1C IC,LA6541D ABCDEFGHIJKLM.......

CN 205 87-A60-109-010 0E CONN,2P V S2M-2W ABCDEFGHIJKLM.......

CN 401 87-A60-424-010 0E CONN,16P V TOC-B ABCDEFGHIJKLM.......

Q 401 89-109-332-380 0E TR,2SA933RS ABCDEFGHIJKLM.......

Q 402 89-113-187-080 0E TR,2SA1318TU ABCDEFGHIJKLM.......

CNA 402 8A-CDA-625-010 1A CONN ASSY,6P CD-ME ABCDEFGHIJKLM.......

X 401 8Z-CD5-633-010 VIB, CER16.93MHZ FCR16.93M2 ABCDEFGHIJKLM.......

L 401 87-003-102-080 COIL, 10UH .............NOPQR..

L 404 87-003-152-080 COIL, 100UH .............NOPQR..

C 440 87-010-145-080 C-CAP,S 1P-50 CH .............NOPQR..

C 425 87-010-176-080 C-CAP,S 680P-50 SL .............NOPQR..

C 407 87-010-178-080 CHIP CAP 1000P .............NOPQR..

C 439 87-010-178-080 CHIP CAP 1000P .............NOPQR..

C 493 87-010-180-080 C-CER 1500P ..............O.....

C 422 87-010-184-080 CHIP CAPACITOR 3300P(K) .............NOPQR..

C 434 87-010-184-080 CHIP CAPACITOR 3300P(K) .............NOPQR..

C 429 87-010-186-080 CAP,CHIP 4700P .............NOPQR..

C 494 87-010-197-080 CAP, CHIP 0.01 DM .............NOPQR..

C 408 87-010-198-080 CAP, CHIP 0.022 .............NOPQR..

C 418 87-010-213-080 C-CAP,S 0.015-50 B .............NOPQR..

C 480 87-010-221-080 CAP, ELECT 470-10V .............NOPQR..

C 476 87-010-236-080 CAP,E 1000-10 SME .............NOPQR..

C 455 87-010-247-080 CAP, ELECT 100-50V .............NOPQR..

C 404 87-010-248-080 CAP, ELECT 220-10V .............NOPQR..

C 409 87-010-248-080 CAP, ELECT 220-10V .............NOPQR..

C 462 87-010-248-080 CAP, ELECT 220-10V .............NOPQR..

C 403 87-010-263-080 CAP, ELECT 100-10V .............NOPQR..

C 410 87-010-263-080 CAP, ELECT 100-10V .............NOPQR..

C 459 87-010-263-080 CAP, ELECT 100-10V .............NOPQR..

C 467 87-010-263-080 CAP, ELECT 100-10V .............NOPQR..

C 478 87-010-263-080 CAP, ELECT 100-10V .............NOPQR..

C 457 87-010-312-080 C-CAP,S 15P-50 CH .............NOPQR..

C 458 87-010-312-080 C-CAP,S 15P-50 CH .............NOPQR..

C 442 87-010-313-080 CAP, CHIP 18P .............NOPQR..

C 448 87-010-315-080 C-CAP,S 27P-50 CH .............NOPQR..

C 502 87-010-322-080 C-CAP,S 100P-50 CH .............NOPQR..

C 503 87-010-322-080 C-CAP,S 100P-50 CH .............NOPQR..

C 504 87-010-322-080 C-CAP,S 100P-50 CH .............NOPQR..

C 505 87-010-322-080 C-CAP,S 100P-50 CH .............NOPQR..

C 506 87-010-322-080 C-CAP,S 100P-50 CH .............NOPQR..

C 406 87-010-374-080 CAP, ELECT 47-10V .............NOPQR..

C 432 87-010-374-080 CAP, ELECT 47-10V .............NOPQR..

C 436 87-010-374-080 CAP, ELECT 47-10V .............NOPQR..

C 412 87-010-401-080 CAP, ELECT 1-50V .............NOPQR..

C 433 87-010-401-080 CAP, ELECT 1-50V .............NOPQR..

C 401 87-010-403-080 CAP, ELECT 3.3-50V .............NOPQR..

C 437 87-010-404-080 CAP, ELECT 4.7-50V .............NOPQR..

C 465 87-010-404-080 CAP, ELECT 4.7-50V .............NOPQR..

C 414 87-010-405-080 CAP, ELECT 10-50V .............NOPQR..

C 481 87-010-405-080 CAP, ELECT 10-50V .............NOPQR..

C 482 87-010-405-080 CAP, ELECT 10-50V .............NOPQR..

C 470 87-010-544-080 CAP, ELECT 0.1-50V .............NOPQR..

C 416 87-010-545-080 CAP, ELECT 0.22-50V .............NOPQR..

C 431 87-010-545-080 CAP, ELECT 0.22-50V .............NOPQR..

C 423 87-010-992-080 C-CAP,S 0.047-25 B .............NOPQR..

C 450 87-012-140-080 CAP 470P .............NOPQR..

C 469 87-012-154-080 C-CAP,S 150P-50 CH .............NOPQR..

C 430 87-012-156-080 C-CAP,S 220P-50 CH .............NOPQR..

C 451 87-012-156-080 C-CAP,S 220P-50 CH .............NOPQR..

C 417 87-012-157-080 C-CAP,S 330P-50 CH .............NOPQR..

C 445 87-012-368-080 C-CAP,S 0.1-50 F .............NOPQR..

C 446 87-012-368-080 C-CAP,S 0.1-50 F .............NOPQR..

C 447 87-012-368-080 C-CAP,S 0.1-50 F .............NOPQR..

C 466 87-012-368-080 C-CAP,S 0.1-50 F .............NOPQR..

C 489 87-012-368-080 C-CAP,S 0.1-50 F .............NOPQR..

C 490 87-012-368-080 C-CAP,S 0.1-50 F .............NOPQR..

C 501 87-012-368-080 C-CAP,S 0.1-50 F .............NOPQR..

C 471 87-015-785-080 CHIP CAPACITOR, 0.1FZ-25Z .............NOPQR..

C 472 87-015-785-080 CHIP CAPACITOR, 0.1FZ-25Z .............NOPQR..

C 473 87-015-785-080 CHIP CAPACITOR, 0.1FZ-25Z .............NOPQR..

C 474 87-015-785-080 CHIP CAPACITOR, 0.1FZ-25Z .............NOPQR..

C 460 87-015-819-080 CAPACITOR,0.01 .............NOPQR..

C 413 87-016-369-080 C-CAP,S 0.033-25 B K .............NOPQR..

C 420 87-016-369-080 C-CAP,S 0.033-25 B K .............NOPQR..

C 438 87-016-669-080 C-CAP,S 0.1-25 K B .............NOPQR..

C 510 87-016-669-080 C-CAP,S 0.1-25 K B .............NOPQR..

SFR 430 87-024-437-080 SFR100K,RH063EC .............NOPQR..

Q 403 87-026-295-080 TR,DTC144TK .............NOPQR..

Q 406 87-026-295-080 TR,DTC144TK .............NOPQR..

Q 407 87-026-295-080 TR,DTC144TK .............NOPQR..

Q 408 87-026-295-080 TR,DTC144TK .............NOPQR..

D 401 87-070-345-080 DIODE,IN4148 .............NOPQR..

D 402 87-070-345-080 DIODE,IN4148 .............NOPQR..

D 403 87-070-345-080 DIODE,IN4148 .............NOPQR..

CN 403 87-099-201-010 CONN,8P 6216 H .............NOPQR..

C 411 87-A11-177-080 C-CAP,S 0.15-16 K B .............NOPQR..

C 421 87-A11-177-080 C-CAP,S 0.15-16 K B .............NOPQR..

ELECTRICAL MAIN PARTS LIST - 7

C 419 87-A11-608-080 C-CAP,S 0.33-25 K B .............NOPQR..

C 426 87-A11-608-080 C-CAP,S 0.33-25 K B .............NOPQR..

IC 401 87-A20-446-010 C-IC,LA9241ML .............NOPQR..

IC 402 87-A20-459-010 C-IC,LC78622ED .............NOPQR..

IC 404 87-A21-093-010 IC,LA6541D .............NOPQR..

CN 205 87-A60-109-010 CONN,2P V S2M-2W .............NOPQR..

CN 401 87-A60-424-010 CONN,16P V TOC-B .............NOPQR..

Q 401 89-109-332-380 TR,2SA933RS .............NOPQR..

Q 402 89-113-187-080 TR,2SA1318TU .............NOPQR..

CNA 402 8A-CDA-625-010 CONN ASSY,6P CD-ME .............NOPQR..

X 401 8Z-CD5-633-010 VIB, CER16.93MHZ FCR16.93M2 .............NOPQR..

C 491 87-010-197-080 0E CAP, CHIP 0.01 DM ABCDEFGHIJKLM.......

C 492 87-010-221-080 0E CAP, ELECT 470-10V ABCDEFGHIJKLM.......

Q 492 87-026-291-080 1A TR,DTC124XS ABCDEFGHIJKLM.......

D 494 87-070-345-080 0E DIODE,IN4148 ABCDEFGHIJKLM.......

Q 491 89-112-965-080 0E TR,2SA1296 (0.75W) ABCDEFGHIJKLM.......

C 491 87-010-197-080 CAP, CHIP 0.01 DM .............NOPQR..

C 492 87-010-221-080 CAP, ELECT 470-10V .............NOPQR..

Q 492 87-026-291-080 TR,DTC124XS .............NOPQR..

D 494 87-070-345-080 DIODE,IN4148 .............NOPQR..

Q 491 89-112-965-080 TR,2SA1296 (0.75W) .............NOPQR..

CF 2 82-785-747-010 1A CF MS2 GHY R ....................

CF 3 82-785-747-010 1A CF MS2 GHY R ....................

L 41 87-005-847-080 0E COIL,2.2UH(CECS) .B..................

L 42 87-005-847-080 0E COIL,2.2UH(CECS) .B..................

L 10 87-005-849-080 0E COIL,10UH(CECS) ABCDEFGHIJKLM.......

CF 2 87-008-261-010 1A FILTER, SFE10.7MA5-A ABCDEFGHIJKLM.......

CF 3 87-008-261-010 1A FILTER, SFE10.7MA5-A ABCDEFGHIJKLM.......

C 4 87-010-148-080 0E CAP, CHIP S 75P SL ABCDEFGHIJKLM.......

C 42 87-010-150-080 0E C-CAP,S 6P-50 CH ...DEFGH.JKL........

C 9 87-010-151-080 0E C-CAP,S 7P-50 CH ....................

C 56 87-010-152-080 0E C-CAP,S 8P-50 CH ABCDEFGHIJKLM.......

C 41 87-010-154-080 0E CAP CHIP 10P .B..................

C 16 87-010-178-080 0E CHIP CAP 1000P ABCDEFGHIJKLM.......

C 8 87-010-197-080 0E CAP, CHIP 0.01 DM ABCDEFGHIJKLM.......

C 10 87-010-197-080 0E CAP, CHIP 0.01 DM ABCDEFGHIJKLM.......

C 22 87-010-197-080 0E CAP, CHIP 0.01 DM ABCDEFGHIJKLM.......

C 32 87-010-197-080 0E CAP, CHIP 0.01 DM ABCDEFGHIJKLM.......

C 33 87-010-197-080 0E CAP, CHIP 0.01 DM ABCDEFGHIJKLM.......

C 34 87-010-197-080 0E CAP, CHIP 0.01 DM ABCDEFGHIJKLM.......

C 35 87-010-197-080 0E CAP, CHIP 0.01 DM ABCDEFGHIJKLM.......

C 37 87-010-197-080 0E CAP, CHIP 0.01 DM ABCDEFGHIJKLM.......

C 38 87-010-197-080 0E CAP, CHIP 0.01 DM ABCDEFGHIJKLM.......

C 51 87-010-197-080 0E CAP, CHIP 0.01 DM ABCDEFGHIJKLM.......

C 18 87-010-198-080 0E CAP, CHIP 0.022 ABCDEFGHIJKLM.......

C 30 87-010-248-080 0E CAP, ELECT 220-10V ABCDEFGHIJKLM.......

C 36 87-010-263-080 0E CAP, ELECT 100-10V ABCDEFGHIJKLM.......

C 44 87-010-302-080 0E C-CAP,S 270P-50CH .B..................

C 9 87-010-311-080 0E CAP 12P ABCDEFGHIJKLM.......

C 1 87-010-313-080 0E CAP, CHIP 18P ....................

C 3 87-010-313-080 0E CAP, CHIP 18P ....................

C 1 87-010-314-080 0E C-CAP,S 22P-50V ABCDEFGHIJKLM.......

C 3 87-010-314-080 0E C-CAP,S 22P-50V ABCDEFGHIJKLM.......

C 12 87-010-314-080 0E C-CAP,S 22P-50V ABCDEFGHIJKLM.......

C 2 87-010-316-080 0E C-CAP,S 33P-50 CH ABCDEFGHIJKLM.......

C 2 87-010-318-080 0E C-CAP,S 47P-50 CH ....................

C 41 87-010-321-080 0E CHIP CAPACITOR,82P(J) ...DEFGH.JKL........

C 13 87-010-322-080 0E C-CAP,S 100P-50 CH ABCDEFGHIJKLM.......

C 5 87-010-378-080 0E CAP, ELECT 10-16V ABCDEFGHIJKLM.......

C 31 87-010-379-080 0E CAP, ELECT 22-16V ABCDEFGHIJKLM.......

C 20 87-010-400-080 0E CAP, ELECT 0.47-50V ABCDEFGHIJKLM.......

C 21 87-010-403-080 0E CAP, ELECT 3.3-50V ABCDEFGHIJKLM.......

C 6 87-010-992-080 0E C-CAP,S 0.047-25 B ABCDEFGHIJKLM.......

C 8 87-010-992-080 0E C-CAP,S 0.047-25 B ABCDEFGHIJKLM.......

C 28 87-010-992-080 0E C-CAP,S 0.047-25 B ABCDEFGHIJKLM.......

C 29 87-010-992-080 0E C-CAP,S 0.047-25 B ABCDEFGHIJKLM.......

C 63 87-010-992-080 0E C-CAP,S 0.047-25 B ABCDEFGHIJKLM.......

TC 5 87-011-253-080 0E TRIMER,30P LAR ...DEFGH.JKL........

TC 6 87-011-253-080 0E TRIMER,30P LAR ...DEFGH.JKL........

C 44 87-012-140-080 0E CAP 470P ...DEFGH.JKL........

C 7 87-012-154-080 0E C-CAP,S 150P-50 CH ....................

C 7 87-012-156-080 0E C-CAP,S 220P-50 CH ABCDEFGHIJKLM.......

C 26 87-012-358-080 0E C-CAP,S 0.47-10 F Z ABCDEFGHIJKLM.......

C 27 87-012-358-080 0E C-CAP,S 0.47-10 F Z ABCDEFGHIJKLM.......

C 45 87-015-786-080 0E CHIP CAPACITOR, 0.0033BK .B..................

C 15 87-016-669-080 0E C-CAP,S 0.1-25 K B ABCDEFGHIJKLM.......

C 17 87-016-669-080 0E C-CAP,S 0.1-25 K B ABCDEFGHIJKLM.......

C 19 87-016-669-080 0E C-CAP,S 0.1-25 K B ABCDEFGHIJKLM.......

C 55 87-018-145-080 0E CAP,TC-U 6.8P-50 CH .B..................

D 1 87-020-465-080 0E DIODE,1SS133 (110MA) ABCDEFGHIJKLM.......

D 2 87-020-465-080 0E DIODE,1SS133 (110MA) ABCDEFGHIJKLM.......

Q 4 87-026-213-080 0E CHIP-TR,DTC114YK ABCDEFGHIJKLM.......

Q 2 87-026-447-080 0E TR,2SC1740S R ABCDEFGHIJKLM.......

Q 3 87-026-463-080 0E TR,2SA933S (0.3W) ABCDEFGHIJKLM.......

C 46 87-A11-523-080 0E C-CAP,S 1200P-50 J B .B..................

IC 1 87-A20-955-010 1C IC,LA1828 ABCDEFGHIJKLM.......

D 13 87-A40-128-080 0E C-VARI-CAP,HVU202A ABCDEFGHIJKLM.......

D 52 87-A40-645-040 0E C-DIODE,HSU277 ....................

D 53 87-A40-645-040 0E C-DIODE,HSU277 ....................

D 56 87-A40-645-040 0E C-DIODE,HSU277 ....................

D 61 87-A40-645-040 0E C-DIODE,HSU277 ....................

L 8 87-A50-335-010 1A COIL,FM IFT (TOKO) ABCDEFGHIJKLM.......

L 17 87-A50-337-010 1A COIL,AM OSC (TOKO) A.CDEFGHIJKLM.......

ELECTRICAL MAIN PARTS LIST - 8

L 2 87-A50-560-010 0E COIL,FM BPF(ACD) ABCDEFGHIJKLM.......

L 4 87-A50-561-010 COIL,FM RF D(ACD) ....................

L 4 87-A50-562-010 0E COIL,FM RF EX(ACD) ABCDEFGHIJKLM.......

L 5 87-A50-563-010 COIL,FM OSC D(ACD) ....................

L 5 87-A50-564-010 COIL,FM OSC EX(ACD) ABCDEFGHIJKLM.......

L 16 87-A50-569-010 COIL,LW OSC-ACD(COI) ...DEFGH.JKL........

L 17 87-A50-570-010 COIL,SW OSC(ACD) .B..................

L 11 87-A50-571-010 COIL,SW ANT(ACD) .B..................

L 6 87-A50-576-010 COIL,MW OSC-HE(ACD) .B..................

L 9 87-A50-577-010 1A COIL,FM DET(ACD) ABCDEFGHIJKLM.......

L 7 87-A50-579-010 0E COIL,AM IFT(ACD) ABCDEFGHIJKLM.......

CN 2 87-A60-116-010 CONN,6P H S2M-6WR ABCDEFGHIJKLM.......

CF 1 87-A90-128-010 0E FLTR,AM IF CFAL-455 ABCDEFGHIJKLM.......

VC 1 87-A91-167-010 TUN-CAP,20P-160P FA-22125 N000 ..C.................

VC 1 87-A91-169-010 1D TUN-CAP,40P-140P FA-22124 AN00 ....................

VC 1 87-A91-170-010 TUN-CAP,20P-335P FA-2217 N000- .B..................

S 1 87-A91-548-010 0E SW,SL-2-3 SK23E01G06 A.C.....I...M.......

S 1 87-A91-549-010 1A SW,SL-6-4 SK64D01G06 .B.DEFGH.JKL........

VC 1 87-A91-635-010 1D TUN-CAP,20P-140P E-ACD(MITSUMI A..DEFGH.JKLM.......

TC 6 87-A91-655-010 TRIMMER,6P 4.0X4.5 ECRL .B..................

TC 7 87-A91-655-010 TRIMMER,6P 4.0X4.5 ECRL .B..................

88-CD6-661-010 HLDR,BAR ANT. ABCDEFGHIJKLM.......

Q 1 89-319-233-080 0E TR,2SC1923 (0.1W) ....................

Q 1 89-327-143-080 0E TR,2SC2714 (0.1W) ABCDEFGHIJKLM.......

L 3 8A-CD9-660-010 1B BAR-ANT,MW 2B-ACD(COI) A.C.....I...M.......

L 3 8A-CD9-661-010 BAR-ANT,MW/LW 3B-ACD(COI) .B.DEFGH.JKL........

L 10 87-005-849-080 COIL,10UH(CECS) .............NOPQR..

CF 2 87-008-261-010 FILTER, SFE10.7MA5-A .............NOPQR..

CF 3 87-008-261-010 FILTER, SFE10.7MA5-A .............NOPQR..

C 4 87-010-148-080 CAP, CHIP S 75P SL .............NOPQR..

C 42 87-010-150-080 C-CAP,S 6P-50 CH ...............P....

C 11 87-010-152-080 C-CAP,S 8P-50 CH .............NOPQR..

C 16 87-010-178-080 CHIP CAP 1000P .............NOPQR..

C 24 87-010-188-080 CAP,CHIP 6800P ...............P....

C 25 87-010-188-080 CAP,CHIP 6800P ...............P....

C 8 87-010-197-080 CAP, CHIP 0.01 DM .............NOPQR..

C 10 87-010-197-080 CAP, CHIP 0.01 DM .............NOPQR..

C 22 87-010-197-080 CAP, CHIP 0.01 DM .............NOPQR..

C 32 87-010-197-080 CAP, CHIP 0.01 DM .............NOPQR..

C 33 87-010-197-080 CAP, CHIP 0.01 DM .............NOPQR..

C 34 87-010-197-080 CAP, CHIP 0.01 DM .............NOPQR..

C 35 87-010-197-080 CAP, CHIP 0.01 DM .............NOPQR..

C 37 87-010-197-080 CAP, CHIP 0.01 DM .............NOPQR..

C 38 87-010-197-080 CAP, CHIP 0.01 DM .............NOPQR..

C 51 87-010-197-080 CAP, CHIP 0.01 DM .............NOPQR..

C 18 87-010-198-080 CAP, CHIP 0.022 .............NOPQR..

C 30 87-010-248-080 CAP, ELECT 220-10V .............NOPQR..

C 36 87-010-263-080 CAP, ELECT 100-10V .............NOPQR..

C 9 87-010-311-080 CAP 12P .............NOPQR..

C 1 87-010-314-080 C-CAP,S 22P-50V .............NOPQR..

C 3 87-010-314-080 C-CAP,S 22P-50V .............NOPQR..

C 12 87-010-314-080 C-CAP,S 22P-50V .............NOPQR..

C 2 87-010-316-080 C-CAP,S 33P-50 CH .............NOPQR..

C 41 87-010-321-080 CHIP CAPACITOR,82P(J) ...............P....

C 13 87-010-322-080 C-CAP,S 100P-50 CH .............NOPQR..

C 5 87-010-378-080 CAP, ELECT 10-16V .............NOPQR..

C 31 87-010-379-080 CAP, ELECT 22-16V .............NOPQR..

C 20 87-010-400-080 CAP, ELECT 0.47-50V .............NOPQR..

C 21 87-010-403-080 CAP, ELECT 3.3-50V .............NOPQR..

C 28 87-010-992-080 C-CAP,S 0.047-25 B .............NOPQR..

C 29 87-010-992-080 C-CAP,S 0.047-25 B .............NOPQR..

TC 5 87-011-253-080 TRIMER,30P LAR ...............P....

TC 6 87-011-253-080 TRIMER,30P LAR ...............P....

C 44 87-012-140-080 CAP 470P ...............P....

C 7 87-012-156-080 C-CAP,S 220P-50 CH .............NOPQR..

C 26 87-012-358-080 C-CAP,S 0.47-10 F Z .............NOPQR..

C 27 87-012-358-080 C-CAP,S 0.47-10 F Z .............NOPQR..

C 15 87-016-669-080 C-CAP,S 0.1-25 K B .............NOPQR..

C 17 87-016-669-080 C-CAP,S 0.1-25 K B .............NOPQR..

C 19 87-016-669-080 C-CAP,S 0.1-25 K B .............NOPQR..

D 1 87-020-465-080 DIODE,1SS133 (110MA) .............NOPQR..

D 2 87-020-465-080 DIODE,1SS133 (110MA) .............NOPQR..

Q 4 87-026-213-080 CHIP-TR,DTC114YK .............NOPQR..

Q 2 87-026-447-080 TR,2SC1740S R .............NOPQR..

Q 3 87-026-463-080 TR,2SA933S (0.3W) .............NOPQR..

IC 1 87-A20-955-010 IC,LA1828 .............NOPQR..

D 3 87-A40-128-080 C-VARI-CAP,HVU202A .............NOPQR..

L 8 87-A50-335-010 COIL,FM IFT (TOKO) .............NOPQR..

L 17 87-A50-337-010 COIL,AM OSC (TOKO) .............NOPQR..

L 2 87-A50-560-010 COIL,FM BPF(ACD) .............NOPQR..

L 4 87-A50-562-010 COIL,FM RF EX(ACD) .............NOPQR..

L 5 87-A50-564-010 COIL,FM OSC EX(ACD) .............NOPQR..

L 16 87-A50-569-010 COIL,LW OSC-ACD(COI) ...............P....

L 9 87-A50-577-010 COIL,FM DET(ACD) .............NOPQR..

L 7 87-A50-579-010 COIL,AM IFT(ACD) .............NOPQR..

CN 2 87-A60-116-010 CONN,6P H S2M-6WR .............NOPQR..

CF 1 87-A90-128-010 FLTR,AM IF CFAL-455 .............NOPQR..

VC 1 87-A91-167-010 TUN-CAP,20P-160P FA-22125 N000 .............NO.QR..

S 1 87-A91-548-010 SW,SL-2-3 SK23E01G06 .............NO.QR..

S 1 87-A91-549-010 SW,SL-6-4 SK64D01G06 ...............P....

VC 1 87-A91-635-010 TUN-CAP,20P-140P E-ACD(MITSUMI ...............P....

88-CD6-661-010 HLDR,BAR ANT. .............NOPQR..

ELECTRICAL MAIN PARTS LIST - 9

Q 1 89-327-143-080 TR,2SC2714 (0.1W) .............NOPQR..

L 3 8A-CD9-660-010 BAR-ANT,MW 2B-ACD(COI) .............NO.QR..

L 3 8A-CD9-661-010 BAR-ANT,MW/LW 3B-ACD(COI) ...............P....

Other manuals for CSD-A170 LH

This manual suits for next models

Table of contents

Popular CD Player manuals by other brands

Arcam

Arcam CD23 Handbook

Sanyo

Sanyo MCD-Z1F Service manual

JVC

JVC RC-ST3SL instructions

Technics

Technics SL-P9066 operating instructions

Marantz

Marantz HD-CD1 quick start guide

Sony

Sony DVP-FX850 Service manual

Philips

Philips AZ1140 Instrukcja obs?ugi

Alpine

Alpine 7909 owner's manual

JVC

JVC CH-X350 instructions

RCA

RCA RP-7923 instruction manual

Pioneer

Pioneer DEH-P3550MP XM Operation manual

Philips

Philips Shockproof AX2102 brochure

Philips

Philips CD582 user manual

Philips

Philips AZ 6821 operating manual

Lasonic

Lasonic MSU-2020 user manual

Denon

Denon DCD-1420 Service manual

Panasonic

Panasonic SJ-MR100 operating instructions

Onkyo

Onkyo DX-7210 instruction manual

Aiwa CSD-A170 LH User manual

Popular CD Player manuals by other brands
