Aiwa VXA-1A User manual
2
REF. NO PART NO. KANRI DESCRIPTION
NO.
REF. NO PART NO. KANRI DESCRIPTION
NO.
ELECTRICAL MAIN PARTS LIST
IC
87-070-364-040 IC,MM74HC14
87-002-684-080 IC,BA10339F
88-ZEC-606-040 C-IC,ADC08134CIWM
88-ZEC-609-040 C-IC,DS2401P
88-ZEC-605-040 C-IC,NM93C66M8
87-001-550-080 IC,TC7S04F
87-A21-120-040 C-IC,BA10324AF
88-ZEC-604-010 C-IC,PCA1366B
87-A21-123-040 C-IC,74VHC4051M
87-A21-124-040 C-IC,LM50C
88-ZEC-603-010 C-IC,PCA1385F
87-A21-234-040 C-IC,CD74ACT164M
87-A21-121-040 C-IC,MM74HCT05M
88-ZEC-602-010 C-IC,SSI32R2105R
87-A20-712-040 C-IC,BA6417F
88-ZEC-607-040 C-IC,TDA5145T
88-ZEB-607-010 C-IC,ALDC1-20S-LP
88-ZEB-605-010 C-IC,TC1
88-ZEB-621-010 C-IC,AIC-43C97C
87-001-551-080 IC,TC7S08F
88-ZEB-611-040 C-IC,MAX706CSA
87-A21-233-040 C-IC,W241024AJ-15
87-A21-129-040 C-IC,74VHCT573MTC
88-ZEB-602-040 C-IC,TL5001CD
88-ZEB-612-040 C-IC,P51XAG30KBA
88-ZEB-623-040 C-IC ASSY,MBM29F040C-55PD-9
88-ZEB-610-040 C-IC,MAX202ECSE
87-001-803-080 IC,TA7745F
TRANSISTOR
87-026-235-080 CHIP-TR,DTC114EK
87-A30-258-040 C-FET,CPH6301
87-A30-277-040 C-TR,UMX4N
87-A30-267-040 C-TR,SST4403
87-A30-312-040 C-TR,2SB1201S
87-A30-017-080 C-TR,2SB1188R
DIODE
87-A40-613-040 C-DIODE,SFPB-54
87-A40-614-040 C-DIODE,SFPB-72
87-001-764-080 DIODE,CHIP IMN10
ANALOG C.B
C201 87-010-197-080 CAP, CHIP 0.01 DM
C202 87-010-198-080 CAP, CHIP 0.022
C203 87-A11-159-080 C-CAP,TN 33-16 M D F93
C204 87-010-198-080 CAP, CHIP 0.022
C205 87-010-197-080 CAP, CHIP 0.01 DM
C206 87-A11-159-080 C-CAP,TN 33-16 M D F93
C207 87-010-197-080 CAP, CHIP 0.01 DM
C208 87-010-197-080 CAP, CHIP 0.01 DM
C209 87-A11-160-080 C-CAP,TN 100-10 M D F93
C210 87-016-669-080 C-CAP,S 0.1-25 K B
C211 87-016-669-080 C-CAP,S 0.1-25 K B
C214 87-A11-159-080 C-CAP,TN 33-16 M D F93
C215 87-010-197-080 CAP, CHIP 0.01 DM
C216 87-010-197-080 CAP, CHIP 0.01 DM
C217 87-010-197-080 CAP, CHIP 0.01 DM
C219 87-010-198-080 CAP, CHIP 0.022
C220 87-016-669-080 C-CAP,S 0.1-25 K B
C222 87-010-197-080 CAP, CHIP 0.01 DM
C223 87-010-197-080 CAP, CHIP 0.01 DM
C224 87-010-198-080 CAP, CHIP 0.022
C227 87-A11-158-080 C-CAP,TN 4.7-16 M A F93
C229 87-010-198-080 CAP, CHIP 0.022
C231 87-010-197-080 CAP, CHIP 0.01 DM
C232 87-010-197-080 CAP, CHIP 0.01 DM
C233 87-010-198-080 CAP, CHIP 0.022
C234 87-010-198-080 CAP, CHIP 0.022
C235 87-010-197-080 CAP, CHIP 0.01 DM
C236 87-010-154-080 CAP CHIP 10P
C237 87-010-197-080 CAP, CHIP 0.01 DM
C238 87-010-154-080 CAP CHIP 10P
C239 87-010-197-080 CAP, CHIP 0.01 DM
C240 87-012-140-080 CAP 470P
C241 87-012-140-080 CAP 470P
C242 87-A11-159-080 C-CAP,TN 33-16 M D F93
C243 87-010-197-080 CAP, CHIP 0.01 DM
C244 87-010-197-080 CAP, CHIP 0.01 DM
C245 87-A10-799-080 C-CAP,S 5600P-16 J B CM
C246 87-010-197-080 CAP, CHIP 0.01 DM
C247 87-010-197-080 CAP, CHIP 0.01 DM
C248 87-010-197-080 CAP, CHIP 0.01 DM
C249 87-A10-799-080 C-CAP,S 5600P-16 J B CM
C250 87-012-156-080 C-CAP,S 220P-50 CH
C251 87-010-197-080 CAP, CHIP 0.01 DM
C252 87-012-156-080 C-CAP,S 220P-50 CH
C253 87-010-197-080 CAP, CHIP 0.01 DM
C254 87-010-197-080 CAP, CHIP 0.01 DM
C255 87-010-197-080 CAP, CHIP 0.01 DM
C256 87-010-181-080 CAP,CHIP S 1800P
C257 87-010-181-080 CAP,CHIP S 1800P
C258 87-010-988-080 C-CAP,S 1800P-50 J CH
C259 87-010-988-080 C-CAP,S 1800P-50 J CH
C260 87-010-988-080 C-CAP,S 1800P-50 J CH
C261 87-010-988-080 C-CAP,S 1800P-50 J CH
C262 87-010-197-080 CAP, CHIP 0.01 DM
C263 87-010-197-080 CAP, CHIP 0.01 DM
C264 87-010-197-080 CAP, CHIP 0.01 DM
C265 87-010-197-080 CAP, CHIP 0.01 DM
C266 87-010-198-080 CAP, CHIP 0.022
C267 87-010-988-080 C-CAP,S 1800P-50 J CH
C268 87-010-988-080 C-CAP,S 1800P-50 J CH
C269 87-010-988-080 C-CAP,S 1800P-50 J CH
C270 87-010-988-080 C-CAP,S 1800P-50 J CH
C273 87-016-669-080 C-CAP,S 0.1-25 K B
C274 87-016-669-080 C-CAP,S 0.1-25 K B
C275 87-010-971-080 C-CAP,S 4700P-50 B J
C276 87-010-971-080 C-CAP,S 4700P-50 B J
C277 87-010-971-080 C-CAP,S 4700P-50 B J
C278 87-010-971-080 C-CAP,S 4700P-50 B J
C279 87-010-198-080 CAP, CHIP 0.022
C280 87-016-669-080 C-CAP,S 0.1-25 K B
C281 87-010-198-080 CAP, CHIP 0.022
C282 87-A11-180-080 C-CAP,S 51P-50 J CH
C283 87-A11-180-080 C-CAP,S 51P-50 J CH
C284 87-A11-180-080 C-CAP,S 51P-50 J CH
C285 87-A11-180-080 C-CAP,S 51P-50 J CH
C286 87-010-197-080 CAP, CHIP 0.01 DM
C287 87-016-669-080 C-CAP,S 0.1-25 K B
C288 87-010-198-080 CAP, CHIP 0.022
C289 87-016-669-080 C-CAP,S 0.1-25 K B
C290 87-010-198-080 CAP, CHIP 0.022
C291 87-010-198-080 CAP, CHIP 0.022
C292 87-010-197-080 CAP, CHIP 0.01 DM
C293 87-A11-159-080 C-CAP,TN 33-16 M D F93
C294 87-016-669-080 C-CAP,S 0.1-25 K B
C295 87-010-596-080 CAP, S 0.047-16
C296 87-010-198-080 CAP, CHIP 0.022
C297 87-016-669-080 C-CAP,S 0.1-25 K B
C298 87-010-178-080 CHIP CAP 1000P
C299 87-010-186-080 CAP,CHIP 4700P
C300 87-010-198-080 CAP, CHIP 0.022
C301 87-010-197-080 CAP, CHIP 0.01 DM
C302 87-016-669-080 C-CAP,S 0.1-25 K B
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
3
REF. NO PART NO. KANRI DESCRIPTION
NO.
REF. NO PART NO. KANRI DESCRIPTION
NO.
C303 87-016-669-080 C-CAP,S 0.1-25 K B
C304 87-016-669-080 C-CAP,S 0.1-25 K B
C305 87-016-669-080 C-CAP,S 0.1-25 K B
C306 87-010-186-080 CAP,CHIP 4700P
C307 87-010-994-080 C-CAP,S 680P-50 CH
C309 87-016-669-080 C-CAP,S 0.1-25 K B
C310 87-010-198-080 CAP, CHIP 0.022
C311 87-016-669-080 C-CAP,S 0.1-25 K B
C312 87-012-140-080 CAP 470P
C313 87-012-157-080 C-CAP,S 330P-50 CH
C314 87-010-198-080 CAP, CHIP 0.022
C315 87-010-197-080 CAP, CHIP 0.01 DM
CN201 87-A60-837-080 C-CONN,6P H SM06B-SRSS
CN202 88-ZEC-608-010 C-CONN,4P H BLK D-A0195-00400
CN203 87-A60-798-080 C-CONN,80P V 177985
CN204 87-A60-796-080 C-CONN,13P V 6214 013 010
CN205 87-A60-797-080 C-CONN,8P V 6208 508 110
CN206 87-A60-027-080 C-CONN,8P H WHT
CN207 87-009-984-080 C-CONN,2PZR WHT
CN208 87-A60-829-080 C-CONN,3P V BM03B-SRSS
CN209 87-009-984-480 C-CONN,2P ZR BLU
CN210 87-A60-707-080 C-CONN,7P H 52207
D203 87-A40-572-080 C-LED,LT1EH67A GRN/YEL
D204 87-A40-572-080 C-LED,LT1EH67A GRN/YEL
D205 87-A40-572-080 C-LED,LT1EH67A GRN/YEL
D206 87-A40-573-080 C-LED,LT1ED67A GRN/RED
L201 87-A50-395-080 C-COIL,100UHD73C-636CY
L202 87-A50-395-080 C-COIL,100UHD73C-636CY
L203 87-A50-453-080 C-COIL, 0.33UH M ACL3225
L204 87-A50-453-080 C-COIL, 0.33UH M ACL3225
L205 87-A50-453-080 C-COIL, 0.33UH M ACL3225
L206 87-A50-453-080 C-COIL, 0.33UH M ACL3225
Q210 87-A30-260-040 C-P-TR,SFH320FA-3
Q211 87-A30-260-040 C-P-TR,SFH320FA-3
R208 87-022-355-080 C-RES,S10K-1/10W F
R209 87-A00-535-080 C-RES, 470-1/4W J MCR18
R220 87-022-355-080 C-RES,S10K-1/10W F
R221 87-A00-532-080 C-RES,S 6.81K-1/10W F
R226 87-022-344-080 C-RES,S 1K-1/10W F
R227 87-022-344-080 C-RES,S 1K-1/10W F
R228 87-A00-525-080 C-RES,S 27.4K-1/10W F
R229 87-022-361-080 C-RES,S 47K-1/10W F
R230 87-022-361-080 C-RES,S 47K-1/10W F
R231 87-A91-065-080 C-ARRAY,R 100X4 EXBV8V
R232 87-A91-065-080 C-ARRAY,R 100X4 EXBV8V
R234 87-022-365-080 C-RES,S 100K-1/10W F
R249 87-022-355-080 C-RES,S10K-1/10W F
R253 87-A00-520-080 C-RES,S 825-1/10W F
R255 87-A00-520-080 C-RES,S 825-1/10W F
R259 87-A00-517-080 C-RES,S 182-1/10W F
R260 87-A00-517-080 C-RES,S 182-1/10W F
R261 87-A00-523-080 C-RES,S 8.25K-1/10W F
R263 87-A00-525-080 C-RES,S 27.4K-1/10W F
R265 87-A00-523-080 C-RES,S 8.25K-1/10W F
R267 87-A00-525-080 C-RES,S 27.4K-1/10W F
R271 83-212-858-080 C-RES,1.5K-1/8W F
R273 83-212-858-080 C-RES,1.5K-1/8W F
R275 87-022-591-080 C-RES,S 3.65K-1/10W F
R276 87-022-591-080 C-RES,S 3.65K-1/10W F
R277 87-022-344-080 C-RES,S 1K-1/10W F
R278 87-022-344-080 C-RES,S 1K-1/10W F
R279 87-022-344-080 C-RES,S 1K-1/10W F
R280 87-022-355-080 C-RES,S10K-1/10W F
R281 87-022-344-080 C-RES,S 1K-1/10W F
R282 87-022-355-080 C-RES,S10K-1/10W F
R300 87-A00-518-080 C-RES,S 200-1/10W F
R301 87-A00-518-080 C-RES,S 200-1/10W F
R302 87-A00-518-080 C-RES,S 200-1/10W F
R303 87-A00-518-080 C-RES,S 200-1/10W F
R308 87-A00-532-080 C-RES,S 6.81K-1/10W F
R310 87-A00-532-080 C-RES,S 6.81K-1/10W F
R312 87-022-525-080 C-RES,S 20K-1/10W F
R313 87-022-525-080 C-RES,S 20K-1/10W F
R316 87-022-355-080 C-RES,S10K-1/10W F
R319 87-022-355-080 C-RES,S10K-1/10W F
R321 87-022-517-080 C-RES,S4.99K-1/10W F
R322 87-022-517-080 C-RES,S4.99K-1/10W F
R324 87-022-365-080 C-RES,S 100K-1/10W F
R326 88-118-102-080 C-RES,S 1K-1/10W J
R328 87-022-344-080 C-RES,S 1K-1/10W F
R344 87-022-355-080 C-RES,S10K-1/10W F
R345 87-A00-183-080 C-RES,S 3.32K-1/10W F
R346 87-022-519-080 C-RES,S5.62K-1/10W F
R347 87-A00-531-080 C-RES,S 464-1/10W F
R349 87-A00-533-080 C-RES,S 33.2K-1/10W F
R350 87-022-365-080 C-RES,S 100K-1/10W F
R354 87-A91-066-080 C-ARRAY,R 150X4 EXBV8V
R355 87-022-357-080 C-RES,S 15K-1/10W F
R356 87-022-357-080 C-RES,S 15K-1/10W F
R357 87-022-357-080 C-RES,S 15K-1/10W F
R358 87-A00-524-080 C-RES,S 24.9K-1/10W F
R359 87-A91-066-080 C-ARRAY,R 150X4 EXBV8V
R362 87-022-357-080 C-RES,S 15K-1/10W F
R363 87-A00-524-080 C-RES,S 24.9K-1/10W F
S201 87-A90-846-010 C-SW,PUSH SPPW81-12.0
S202 87-A90-846-010 C-SW,PUSH SPPW81-12.0
S203 87-A90-845-010 C-SW,PUSH SPPW81-10.3
S204 87-A90-846-010 C-SW,PUSH SPPW81-12.0
S205 87-A91-050-080 C-SW,MICRO SPVG12
S206 87-A91-051-080 C-SW,TACT SKQTLA
DIGITAL C.B
C1 87-010-198-080 CAP, CHIP 0.022
C2 87-010-198-080 CAP, CHIP 0.022
C3 87-010-198-080 CAP, CHIP 0.022
C4 87-010-198-080 CAP, CHIP 0.022
C5 87-012-158-080 C-CAP,S 390P-50 CH
C6 87-010-198-080 CAP, CHIP 0.022
C7 87-010-198-080 CAP, CHIP 0.022
C8 87-010-198-080 CAP, CHIP 0.022
C9 87-010-198-080 CAP, CHIP 0.022
C10 87-010-198-080 CAP, CHIP 0.022
C11 87-016-669-080 C-CAP,S 0.1-25 K B
C12 87-A11-160-080 C-CAP,TN 100-10 M D F93
C13 87-010-198-080 CAP, CHIP 0.022
C14 87-010-198-080 CAP, CHIP 0.022
C15 87-A11-157-080 C-CAP,TN 1-16 M A F93
C16 87-010-186-080 CAP,CHIP 4700P
C17 87-010-426-080 C-CAP,S 0.012-25 B
C18 87-010-198-080 CAP, CHIP 0.022
C19 87-010-198-080 CAP, CHIP 0.022
C20 87-010-198-080 CAP, CHIP 0.022
C21 87-010-198-080 CAP, CHIP 0.022
C22 87-010-149-080 C-CAP,S 5P-50 C CH
C23 87-010-152-080 C-CAP,S 5P-50 C CH
C24 87-A11-158-080 C-CAP,TN 4.7-16 M A F93
C25 87-010-198-080 CAP, CHIP 0.022
C26 87-010-198-080 CAP, CHIP 0.022
C27 87-010-198-080 CAP, CHIP 0.022
C28 87-010-426-080 C-CAP,S 0.012-25 B
C29 87-A11-160-080 C-CAP,TN 100-10 M D F93
C30 87-010-198-080 CAP, CHIP 0.022
C31 87-010-198-080 CAP, CHIP 0.022
C32 87-010-198-080 CAP, CHIP 0.022
C33 87-A11-158-080 C-CAP,TN 4.7-16 M A F93
C34 87-A11-158-080 C-CAP,TN 4.7-16 M A F93
C35 87-A11-158-080 C-CAP,TN 4.7-16 M A F93
C36 87-010-198-080 CAP, CHIP 0.022
C37 87-010-198-080 CAP, CHIP 0.022
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
4
REF. NO PART NO. KANRI DESCRIPTION
NO. REF. NO PART NO. KANRI DESCRIPTION
NO.
• Regarding connectors, they are not stocked as they are not the initial order items.
The connectors are available after they are supplied from connector manufacturers upon the order is received.
88
A
Resistor Code
Chip Resistor Part Coding
Figure
Value of resistor
Chip resistor
Wattage Type Tolerance
1/16W
1/10W
1/8W
1608
2125
3216
5%
5%
5%
CJ
CJ
CJ
Form LW t
1.6 0.8 0.45
2 1.25 0.45
3.2 1.6
108
118
128
: A
: A
CHIP RESISTOR PART CODE
0.55
Resistor Code
Dimensions (mm)
Symbol
1/16W 1005 5% CJ 1.0 0.5 0.35 104
Lt
W
C38 87-010-198-080 CAP, CHIP 0.022
C39 87-010-198-080 CAP, CHIP 0.022
C40 87-010-198-080 CAP, CHIP 0.022
C41 87-010-198-080 CAP, CHIP 0.022
C42 87-010-198-080 CAP, CHIP 0.022
C43 87-010-198-080 CAP, CHIP 0.022
C44 87-016-669-080 C-CAP,S 0.1-25 K B
C45 87-016-669-080 C-CAP,S 0.1-25 K B
C46 87-016-669-080 C-CAP,S 0.1-25 K B
C47 87-016-669-080 C-CAP,S 0.1-25 K B
C48 87-016-669-080 C-CAP,S 0.1-25 K B
C49 87-A12-111-080 C-CAP,TN 15-16 M B F93
C50 87-016-669-080 C-CAP,S 0.1-25 K B
C51 87-016-669-080 C-CAP,S 0.1-25 K B
C52 87-016-669-080 C-CAP,S 0.1-25 K B
C53 87-A11-158-080 C-CAP,TN 4.7-16 M A F93
C54 87-010-198-080 CAP, CHIP 0.022
C55 87-010-198-080 CAP, CHIP 0.022
C56 87-010-198-080 CAP, CHIP 0.022
C57 87-010-198-080 CAP, CHIP 0.022
C58 87-010-198-080 CAP, CHIP 0.022
C59 87-010-198-080 CAP, CHIP 0.022
C60 87-010-198-080 CAP, CHIP 0.022
C61 87-010-198-080 CAP, CHIP 0.022
CN1 87-A61-269-010 CONN,8P H DF11
CN2 88-ZEB-622-010 CONN,68P H QA11343-P1
CN3 87-A60-836-080 C-CONN,4P V 9261B-2-04
CN4 87-A60-799-080 C-CONN,80P V 177986
CN5 87-A61-270-010 CONN,10P H DF11
FB1 87-A91-720-080 C-F-BEAD, FBMJ3216HS800-T
FB3 87-A91-720-080 C-F-BEAD, FBMJ3216HS800-T
FB4 87-A91-720-080 C-F-BEAD, FBMJ3216HS800-T
FB5 87-A91-720-080 C-F-BEAD, FBMJ3216HS800-T
FB6 87-A91-720-080 C-F-BEAD, FBMJ3216HS800-T
FB7 87-A91-720-080 C-F-BEAD, FBMJ3216HS800-T
L1 87-A50-092-080 C-COIL,2.7UH K FLC32
L2 87-A50-387-080 C-COIL,22UHD73C-636CY
!
PR1 87-A91-061-080 C-PROTECTOR,1.25A SMD125
R6 87-A00-671-080 C-RES,S 4.75K-1/10W F
R11 87-A00-522-080 C-RES,S 7.5K-1/10W F
R12 87-A00-526-080 C-RES,S 53.6K-1/10W F
R14 87-A91-067-080 C-ARRAY,R 470X4 EXBV8V
R15 87-A91-067-080 C-ARRAY,R 470X4 EXBV8V
R19 87-A00-522-080 C-RES,S 7.5K-1/10W F
R21 87-A00-521-080 C-RES,S 3.24K-1/10W F
R32 87-A00-671-080 C-RES,S 4.75K-1/10W F
R39 83-212-859-080 C-RES,S 1.8K-1/10W F
X1 87-A70-196-080 C-VIB,XTAL 40MHZ 49/U03C
MODE C.B
SN1 87-A90-891-010 SNSR,RDC1032 2.5
LED C.B
7ZS4 C.B
C1 87-016-262-080 C-CAP,TN4.7-16 BTJ
C2 87-016-262-080 C-CAP,TN4.7-16 BTJ
C3 87-016-262-080 C-CAP,TN4.7-16 BTJ
C4 87-016-492-080 C-CAP,S 0.33-16 FZ
FC1 87-ZS4-603-010 F-CABLE, 7ZS4
H1 87-ZS3-684-080 SNSR,HALL HZ106C
H2 87-ZS3-684-080 SNSR,HALL HZ106C
H3 87-ZS3-684-080 SNSR,HALL HZ106C
L1 87-ZS4-602-010 COIL,7ZS4
L2 87-ZS4-602-010 COIL,7ZS4
L3 87-ZS4-602-010 COIL,7ZS4
L4 87-ZS4-602-010 COIL,7ZS4
L5 87-ZS4-602-010 COIL,7ZS4
L6 87-ZS4-602-010 COIL,7ZS4
PS1 87-A91-053-080 C-SNSR,PHOTO NJL5197K-F10
PS2 87-A91-053-080 C-SNSR,PHOTO NJL5197K-F10
MAIN C.B
C1 87-015-968-040 CAP,E 4.7-16 5L SRE
C2 87-015-968-040 CAP,E 4.7-16 5L SRE
C3 87-015-968-040 CAP,E 4.7-16 5L SRE
C4 87-016-492-080 C-CAP,S 0.33-16 FZ
H1 87-ZS3-684-080 SNSR,HALL HZ106C
H2 87-ZS3-684-080 SNSR,HALL HZ106C
H3 87-ZS3-684-080 SNSR,HALL HZ106C
L1 85-ZS3-602-010 COIL,ACM2
L2 85-ZS3-602-010 COIL,ACM2
L3 85-ZS3-602-010 COIL,ACM2
L4 85-ZS3-602-010 COIL,ACM2
L5 85-ZS3-602-010 COIL,ACM2
L6 85-ZS3-602-010 COIL,ACM2
MR1 87-ZS3-683-010 SNSR,MR TDM0404 B
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
2423
EEE
BBB
C
CC
DTC114EK
SST4403
2SB1201S 2SB1188R
GD2D1
SD3D4
CPH6301
C2E1C1
E2
B2B1
UMX4N
TRANSISTOR ILLUSTRATION
1
23
4
56
P.C.B
8
P.C.B
8ZL-1
A
B
B
7
9
B
A
MECHANICAL EXPLODED VIEW 1/1
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
25
REF. NO PART NO. KANRI DESCRIPTION
NO.
MECHANICAL PARTS LIST 1/1
Basic color symbol Color Basic color symbol Color Basic color symbol Color
B Black C Cream D Orange
G Green H Gray L Blue
LT Transparent Blue N Gold P Pink
R Red S Silver ST Titan Silver
T Brown V Violet W White
WT Transparent White Y Yellow YT Transparent Yellow
LM Metallic Blue LL Light Blue GT Transparent Green
LD Dark Blue DT Transparent Orange
COLOR NAME TABLE
1 88-XX2-010-010 PANEL,FR 5 BLK<YUB>
1 88-XX2-001-010 PANEL,FR 5'<YUW>
2 88-ZL1-360-010 SPR-T,LID
3 88-XX2-002-010 LID,INT 5<YUW>
3 88-XX2-011-010 LID,INT 5 BLK<YUB>
4 88-XX2-004-010 REFLECTOR,LED
5 88-XX2-005-010 REFLECTOR,LED EJ
6 88-XX2-003-010 BTN,EJECT<YUW>
6 88-XX2-012-010 BTN,EJECT BLK<YUB>
7 88-XX2-202-010 HLDR,BOT
8 87-A61-295-010 SOCKET,2P A3-SP(B)
9 88-XX2-201-010 HLDR,TOP
A 88-ZL1-319-010 S-SCREW,PWB-MAIN
B 87-261-032-410 V+2-3 GLD
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
26
REF. NO PART NO. KANRI DESCRIPTION
NO.
REF. NO PART NO. KANRI DESCRIPTION
NO.
TAPE MECHANISM PARTS LIST 1/1
1 88-ZL1-268-010 PLATE,SLIDE-MAIN
2 88-ZL1-354-010 SPR-E,TRG
3 88-ZL1-411-010 PLATE,CNTR-GEAR
4 88-ZL1-228-110 GEAR,IDOL-REEL
5 88-ZL1-365-010 SPR-C,IDOL-REEL
6 87-B10-223-010 W-P,1.58-5-0.5 W/SLIT
7 88-ZL1-250-010 ARM ASSY,S
8 88-ZL1-352-010 SPR-T,ARM-S
9 88-ZL1-255-010 GEAR,STL-S
10 87-081-489-010 POLY-SLIDER WASHER,PW1.7-3.5-0
11 88-ZL1-269-010 GEAR,DRV-STL
12 87-067-569-010 POLY WASHER 0.83-2.5-0.25
13 88-ZL1-266-110 PLATE,LOAD
14 88-ZL1-262-010 GEAR,STL-T
15 88-ZL1-353-010 SPR-T,ARM-T
16 88-ZL1-257-010 ARM ASSY,T
17 88-ZL1-305-010 PLATE ASSY,RVS
18 88-ZL1-267-010 GEAR,LOAD
19 87-B10-222-010 W-P,2.68-4.7-0.25 W/SLIT
20 88-ZL1-256-010 PLATE,STL-S
21 88-ZL1-263-010 PLATE,STL-T
22 88-ZL1-419-010 PLATE,CASS-TOP
23 88-ZL1-284-010 PLATE ASSY,PINCH
24 - - - PIN,GUIDE-S
25 - - - FLANGE,GUIDE-T2
26 - - - ROLLER ASSY,PINCH
27 - - - COLLAR, B PINCH ROLLER
28 87-B10-227-010 W-P,1.28-3.6-0.25 W/SLIT
29 88-ZL1-298-010 LEVER ASSY,BRAKE-S
30 88-ZL1-301-010 LEVER ASSY,BRAKE-T
31 88-ZL1-357-010 SPR-E,BRAKE
32 88-ZL1-308-110 GEAR,WORM-RF370
33 88-ZL1-233-010 REEL TABLE ASSY,
34 85-ZS4-208-010 SPR-C,ARM1
35 88-ZL1-235-010 CAP,REEL
36 86-550-268-010 WASHER STE 0.8-5
37 88-ZL1-270-010 LEVER ASSY,TRG
38 88-ZL1-237-010 HLDR,LN159
39 88-ZL1-280-010 BAND ASSY,BRAKE
40 87-067-473-010 PW,2.1-5-0.25
41 88-ZL1-326-010 COVER,CAM-MAIN
42 88-ZL1-265-010 WORM-WHL,RF370
43 88-ZL1-264-010 CAM,MAIN
44 88-ZL1-309-110 LEVER ASSY,CLN
45 88-ZL1-246-010 SHUTTLE ASSY,T
46 88-ZL1-295-010 PLATE ASSY,SADOU-PUSH
47 88-ZL1-238-010 SHUTTLE ASSY,S
48 88-ZL1-414-010 PLATE,SLIDE-CASS
49 88-ZL1-409-010 ARM,CASS-L
50 88-ZL1-362-010 SPR-T,ARM-CASS-L
51 88-ZL1-418-010 REFLECTOR,R
52 87-B10-224-010 W-P,6-8.5-0.25 W/SLIT
53 88-ZL1-415-010 GEAR,CASS-1
54 88-ZL1-364-010 SPR-T,GEAR-CASS
55 88-ZL1-416-010 GEAR,CASS-2
56 88-ZL1-413-010 CHAS,CASS-R
57 88-ZL1-405-010 PLATE,CASS-R
58 88-ZL1-406-210 PLATE ASSY,CASS-BOX
59 88-ZL1-403-010 PLATE,CASS-L
60 88-ZL1-404-010 STOPPER,CASS
61 88-ZL1-361-010 SPR-E,STPR-CASS
62 88-ZL1-420-110 LEVER,LID-OPENER
63 88-ZL1-363-010 SPR-T,ARM-CASS-R
64 88-ZL1-410-010 ARM,CASS-R
65 88-ZL1-412-110 CHAS,CASS-L
66 88-ZL1-356-010 SPR-E,PINCH- RETURN
67 - - - W-P,4.1-5.5-0.25
68 - - - W,2X3.56X0.188 SLIT
69 87-A90-891-010 SNSR,RDC1032 2.5
70 88-ZL1-430-010 CYL ASSY,
71 - - - MAGNET,7ZS4
72 - - - CASE ASSY,7ZS4
73 - - - BRG ASSY,7ZS4
74 - - - PLATE,MOT-REEL
75 - - - GEAR ASSY,MOT-REEL
76 - - - PLATE ASSY,IDOL-REEL
77 - - - F-CABLE, 7ZS4
78 M8-7ZS-490-000 ARM-2 A
79 M8-7ZS-390-000 ACM-3 A
80 - - - ROTOR ASSY,7ZS3
81 - - - PWB,CONN 7ZS3
82 - - - BRG ASSY,7ZS3
83 - - - MAGNET
84 - - - SNSR,MR TDM0404 B
85 - - - W-P,2.5-0.5 7ZS3
86 87-A91-069-010 MOT,RF-370CA15370
87 87-A40-508-010 P-DIODE,LN159
88 88-ZL1-417-010 REFLECTOR,L
89 88-ZL1-201-010 CHAS ASSY,MAIN
90 87-ZM6-242-010 W-P,1.25-3-0.25 SLIT
91 - - - W-P,2.03X6X0.25
92 88-ZL1-333-010 ROLLER ASSY,CLN
93 88-ZL1-330-010 W-L,1.47-3.2-0.1
A 87-261-091-410 V+3-3
B 87-261-032-410 V+2-3 GLD
C 87-251-034-410 U+2-5
D 87-353-507-310 VT2+1.4-3 CHROME
E 87-264-525-310 SCREW, V+1.7-2.5
F 87-264-522-310 V+1.7-1.8
G 87-268-525-310 V+1.7-2.5
H 88-ZL1-422-010 S-SCREW,CASS-2
I 87-352-529-310 VT2+1.7-4.0 BLK
J 88-ZL1-421-010 S-SCREW,CASS
K 87-251-033-410 U+2-4
L 87-481-033-410 VWS+2-4
M 87-ZS3-246-010 S-SCREW,7ZS3
N 87-262-525-310 SCREW,V+1.7-2.5
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
2827
TAPE MECHANISM EXPLODED VIEW 1/1
1
2
45
6
7
8
9
11
10
14
15 16
17
18
19
20 21
23
24
25
27
26
89
88 24
25
10
68
90
28
28
13
66
28
29
30
31
32
33
34
35
36
37
38
P.C.B
39
40
41 42
43
44
45
46
12
92
93
91
47 70
86
a
b
a
b
3
22
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
67
78
74
75
76
P.C.B
77 71
72
73
79
82
85 P.C.B
83
80 81
84
P.C.B
69
87
F
N
L
DDM
A
E
E
B
CHKFI
I
K
G
G
JH
c
c
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
Table of contents
Other Aiwa Media Player manuals
