S E R V I C E M A N U A L

SIMPLE MANUAL

• Replace this Service Manual with ”Revision Publishing” when it is issued.

AV-D35

• TYPE: EZ(B)

S/M Code No. 09–993–326–8T2

STEREO AV RECEIVER

ELECTRICAL MAIN PARTS LIST - 1

NOTE: The characters in the suffix column indicate the part usage.

EZ .....................XX...................................B...................

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

88-NF6-205-010 GUIDE,FL 40-150- 9 ABC.................

C 109 87-010-322-080 C-CAP,S 100P-50 CH ABC.................

C 107 87-016-526-080 C-CAP,S 0.47-16 BK ABC.................

C 108 87-016-526-080 C-CAP,S 0.47-16 BK ABC.................

C 105 87-016-526-080 C-CAP,S 0.47-16 BK ABC.................

C 114 87-010-322-080 C-CAP,S 100P-50 CH ABC.................

C 113 87-010-322-080 C-CAP,S 100P-50 CH ABC.................

C 115 87-010-322-080 C-CAP,S 100P-50 CH ABC.................

C 110 87-010-322-080 C-CAP,S 100P-50 CH ABC.................

C 112 87-010-322-080 C-CAP,S 100P-50 CH ABC.................

C 118 87-010-498-040 CAP,E 10-16 GAS ABC.................

C 111 87-015-699-040 CAP,E 10-50 7L ABC.................

C 116 87-015-699-040 CAP,E 10-50 7L ABC.................

C 117 87-016-526-080 C-CAP,S 0.47-16 BK ABC.................

C 123 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................

C 125 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................

C 129 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................

C 120 87-015-694-040 E/CAP 0.47-50 ABC.................

C 128 87-015-695-040 E/CAP 1UF 50V TAPG ABC.................

C 124 87-015-699-040 CAP,E 10-50 7L ABC.................

C 122 87-015-699-040 CAP,E 10-50 7L ABC.................

C 121 87-016-526-080 C-CAP,S 0.47-16 BK ABC.................

C 127 87-016-526-080 C-CAP,S 0.47-16 BK ABC.................

C 126 87-A10-189-040 CAP,E 220-10 ABC.................

C 134 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................

C 130 87-010-198-080 CAP, CHIP 0.022 ABC.................

C 137 87-010-312-080 C-CAP,S 15P-50 CH ABC.................

C 139 87-010-316-080 C-CAP,S 33P-50 CH ABC.................

C 138 87-010-318-080 C-CAP,S 47P-50 CH ABC.................

C 131 87-010-408-040 CAP,E 47-50 SME ABC.................

C 132 87-012-368-080 C-CAP,S 0.1-50 F ABC.................

C 133 87-016-526-080 C-CAP,S 0.47-16 BK ABC.................

C 136 87-016-526-080 C-CAP,S 0.47-16 BK ABC.................

C 140 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................

C 142 87-010-198-080 CAP, CHIP 0.022 ABC.................

C 141 87-012-156-080 C-CAP,S 220P-50 CH ABC.................

C 143 87-012-156-080 C-CAP,S 220P-50 CH ABC.................

C 153 87-012-368-080 C-CAP,S 0.1-50 F ABC.................

C 154 87-012-368-080 C-CAP,S 0.1-50 F ABC.................

C 158 87-012-368-080 C-CAP,S 0.1-50 F ABC.................

C 156 87-015-699-040 CAP,E 10-50 7L ABC.................

C 162 87-010-182-080 C-CAP,S 2200P-50 B ABC.................

C 164 87-A10-189-040 CAP,E 220-10 ABC.................

C 171 87-012-157-080 C-CAP,S 330P-50 CH ABC.................

C 188 87-010-178-080 CHIP CAP 1000P ABC.................

C 189 87-010-178-080 CHIP CAP 1000P ABC.................

C 190 87-010-178-080 CHIP CAP 1000P ABC.................

C 240 87-016-526-080 C-CAP,S 0.47-16 BK ABC.................

C 407 87-010-178-080 CHIP CAP 1000P ABC.................

C 406 87-010-182-080 C-CAP,S 2200P-50 B ABC.................

C 405 87-010-182-080 C-CAP,S 2200P-50 B ABC.................

C 402 87-012-156-080 C-CAP,S 220P-50 CH ABC.................

C 411 87-010-322-080 C-CAP,S 100P-50 CH ABC.................

C 412 87-010-322-080 C-CAP,S 100P-50 CH ABC.................

CN 202 87-A60-039-010 CONN,32P V 9604S-32C A.C.................

CN 201 87-A60-053-010 CONN,17P V 9604S-17C ABC.................

CN 203 87-A60-061-010 CONN,06P V 9604S-06C ..C.................

CN 202 87-A60-553-010 CONN,35P V 9604S-35C .B..................

CN 401 87-009-371-010 CONNECTOR, 6P ..C.................

D 103 87-020-465-080 DIODE,1SS133 (110MA) ABC.................

D 102 87-020-465-080 DIODE,1SS133 (110MA) ABC.................

D 105 87-020-465-080 DIODE,1SS133 (110MA) ABC.................

D 104 87-020-465-080 DIODE,1SS133 (110MA) ABC.................

D 107 87-020-465-080 DIODE,1SS133 (110MA) ABC.................

D 106 87-020-465-080 DIODE,1SS133 (110MA) ABC.................

D 108 87-020-465-080 DIODE,1SS133 (110MA) ABC.................

D 101 87-A40-344-080 ZENER,MTZJ6.2C ABC.................

D 122 87-020-465-080 DIODE,1SS133 (110MA) ABC.................

D 121 87-020-465-080 DIODE,1SS133 (110MA) ABC.................

FL 101 8Z-AR1-602-010 FL,BJ691 GK ABC.................

IC 101 87-017-915-080 IC,BU4094BCF ABC.................

IC 102 87-017-915-080 IC,BU4094BCF ABC.................

IC 104 87-070-083-010 IC,GP1U281X ABC.................

IC 103 8Z-AR3-610-010 C-IC,UPD780228GF ABC.................

IC 103 8Z-AR3-611-010 C-IC,UPD780228GF-*** ....................

LED 108 87-A40-317-080 LED,SLR-342VCT31 RED ABC.................

LED 101 87-A40-317-080 LED,SLR-342VCT31 RED ABC.................

LED 104 87-A40-317-080 LED,SLR-342VCT31 RED ABC.................

LED 106 87-A40-317-080 LED,SLR-342VCT31 RED ABC.................

LED 107 87-A40-496-040 LED,SLR-342MCT31 GRN ABC.................

LED 103 87-A40-496-040 LED,SLR-342MCT31 GRN ABC.................

LED 105 87-A40-496-040 LED,SLR-342MCT31 GRN ABC.................

LED 109 87-A40-496-040 LED,SLR-342MCT31 GRN ABC.................

LED 102 87-A40-496-040 LED,SLR-342MCT31 GRN ABC.................

LED 114 87-A40-317-080 LED,SLR-342VCT31 RED ABC.................

LED 110 87-A40-317-080 LED,SLR-342VCT31 RED ABC.................

LED 119 87-A40-317-080 LED,SLR-342VCT31 RED ABC.................

LED 116 87-A40-317-080 LED,SLR-342VCT31 RED ABC.................

LED 112 87-A40-317-080 LED,SLR-342VCT31 RED ABC.................

LED 117 87-A40-496-040 LED,SLR-342MCT31 GRN ABC.................

LED 115 87-A40-496-040 LED,SLR-342MCT31 GRN ABC.................

LED 113 87-A40-496-040 LED,SLR-342MCT31 GRN ABC.................

LED 111 87-A40-496-040 LED,SLR-342MCT31 GRN ABC.................

Q 106 87-A30-071-080 C-TR,RT1N 144C ABC.................

Q 103 87-A30-073-080 C-TR,RT1N 141C ABC.................

Q 101 87-A30-073-080 C-TR,RT1N 141C ABC.................

Q 104 87-A30-073-080 C-TR,RT1N 141C ABC.................

Q 108 87-A30-073-080 C-TR,RT1N 141C ABC.................

Q 102 87-A30-073-080 C-TR,RT1N 141C ABC.................

Q 105 89-112-965-080 TR,2SA1296 (0.75W) ABC.................

Q 116 87-026-263-080 C-TR,RN1410 ABC.................

Q 119 87-A30-071-080 C-TR,RT1N 144C ABC.................

Q 117 87-A30-071-080 C-TR,RT1N 144C ABC.................

Q 112 87-A30-073-080 C-TR,RT1N 141C ABC.................

Q 110 87-A30-073-080 C-TR,RT1N 141C ABC.................

Q 115 87-A30-073-080 C-TR,RT1N 141C ABC.................

Q 114 87-A30-073-080 C-TR,RT1N 141C ABC.................

Q 113 87-A30-074-080 C-TR,RT1P 141C ABC.................

Q 111 87-A30-087-080 C-FET,2SK2158 ABC.................

Q 120 87-A30-071-080 C-TR,RT1N 144C ABC.................

S 101 87-A90-095-080 SW,TACT EVQ11G04M ABC.................

S 108 87-A90-095-080 SW,TACT EVQ11G04M ABC.................

S 107 87-A90-095-080 SW,TACT EVQ11G04M ABC.................

S 109 87-A90-095-080 SW,TACT EVQ11G04M ABC.................

S 114 87-A90-095-080 SW,TACT EVQ11G04M ABC.................

S 111 87-A90-095-080 SW,TACT EVQ11G04M ABC.................

S 115 87-A90-095-080 SW,TACT EVQ11G04M ABC.................

S 112 87-A90-095-080 SW,TACT EVQ11G04M ABC.................

S 113 87-A90-095-080 SW,TACT EVQ11G04M ABC.................

S 116 87-A90-095-080 SW,TACT EVQ11G04M ABC.................

SW 101 87-A90-535-010 SW,RTRY EC16B24304 ABC.................

SW 102 87-A90-950-010 SW,RTRY EC12E12504 ENCORDER ABC.................

X 101 87-A70-075-080 VIB,CER 4.19MHZ CRHF ABC.................

C 503 87-012-157-080 C-CAP,S 330P-50 CH ABC.................

C 504 87-012-157-080 C-CAP,S 330P-50 CH ABC.................

C 519 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................

C 517 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................

C 518 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................

C 513 87-010-260-080 CAP, ELECT 47-25V ABC.................

C 514 87-010-260-080 CAP, ELECT 47-25V ABC.................

C 515 87-010-370-080 CAP,E 330-6.3 SME ABC.................

C 516 87-010-370-080 CAP,E 330-6.3 SME ABC.................

C 520 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................

C 531 87-010-213-080 C-CAP,S 0.015-50 B ABC.................

C 539 87-010-401-080 CAP, ELECT 1-50V ABC.................

C 533 87-015-785-080 CHIP CAPACITOR, 0.1FZ-25Z ABC.................

C 541 87-010-185-080 C-CAP,S 3900P-50 B ABC.................

C 542 87-010-185-080 C-CAP,S 3900P-50 B ABC.................

C 540 87-010-401-080 CAP, ELECT 1-50V ABC.................

C 549 87-016-081-080 C-CAP,S 0.1-16 RK ABC.................

C 559 87-010-183-080 C-CAP,S 2700P-50 B ABC.................

C 554 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................

C 556 87-010-248-080 CAP, ELECT 220-10V ABC.................

C 557 87-010-405-080 CAP, ELECT 10-50V ABC.................

C 555 87-010-405-080 CAP, ELECT 10-50V ABC.................

C 558 87-010-992-080 C-CAP,S 0.047-25 B ABC.................

C 550 87-016-081-080 C-CAP,S 0.1-16 RK ABC.................

C 566 87-010-404-080 CAP, ELECT 4.7-50V ABC.................

C 561 87-012-140-080 CAP 470P ABC.................

C 562 87-012-140-080 CAP 470P ABC.................

CN 501 87-A60-039-010 CONN,32P V 9604S-32C A.C.................

CN 503 87-A60-057-010 CONN,11P V 9604S-11C ABC.................

CN 502 87-A60-061-010 CONN,06P V 9604S-06C ..C.................

CN 506 87-A60-063-010 CONN,04P V 9604S-04C .B..................

CN 501 87-A60-553-010 CONN,35P V 9604S-35C .B..................

CN 702 87-099-568-010 CONN,11P TUC-P11P-B1 ABC.................

D 503 87-070-274-080 DIODE,1N4003 SEM ABC.................

D 502 87-A40-438-080 ZENER,MTZJ4.7A ABC.................

D 501 87-A40-438-080 ZENER,MTZJ4.7A ABC.................

IC 501 87-017-022-080 IC,NJM2068M-D(T1) ABC.................

IC 502 87-017-726-080 IC,BU4052 BCF ABC.................

IC 503 87-A21-202-040 C-IC,M62445AFP ABC.................

J 501 87-099-609-010 JACK,PIN 4P KM EARTH ABC.................

J 502 87-099-609-010 JACK,PIN 4P KM EARTH ABC.................

87-067-579-010 TAPPING SCREW, BVT2+3-8 ABC.................

C 102 87-010-235-080 CAP,E 470-16 SME ABC.................

C 101 87-010-235-080 CAP,E 470-16 SME ABC.................

C 104 87-010-382-080 CAP, ELECT 22-25V ABC.................

C 106 87-010-384-080 CAP, ELECT 100-25V ABC.................

C 103 87-010-384-080 CAP, ELECT 100-25V ABC.................

C 108 87-012-140-080 CAP 470P ABC.................

C 109 87-012-368-080 C-CAP,S 0.1-50 F ABC.................

C 115 87-012-368-080 C-CAP,S 0.1-50 F ABC.................

C 118 87-012-368-080 C-CAP,S 0.1-50 F ABC.................

C 116 87-012-368-080 C-CAP,S 0.1-50 F ABC.................

C 111 87-012-368-080 C-CAP,S 0.1-50 F ABC.................

C 110 87-012-368-080 C-CAP,S 0.1-50 F ABC.................

C 112 87-012-368-080 C-CAP,S 0.1-50 F ABC.................

C 117 87-012-368-080 C-CAP,S 0.1-50 F ABC.................

ELECTRICAL MAIN PARTS LIST - 2

C 114 87-016-658-090 CAP,E 4700-35 SMG ABC.................

C 113 87-016-658-090 CAP,E 4700-35 SMG ABC.................

C 119 87-A10-462-090 CAP,E 6800-63 SMG VB ABC.................

C 127 87-010-197-080 CAP, CHIP 0.01 DM ABC.................

C 125 87-010-247-080 CAP, ELECT 100-50V ABC.................

C 121 87-010-260-080 CAP, ELECT 47-25V ABC.................

C 126 87-010-263-080 CAP, ELECT 100-10V ABC.................

C 123 87-010-385-080 CAP, ELECT 220-25V ABC.................

C 122 87-010-403-080 CAP, ELECT 3.3-50V ABC.................

C 120 87-A10-462-090 CAP,E 6800-63 SMG VB ABC.................

C 143 87-A10-712-080 C-CAP,S 0.22-50 Z F ..C.................

C 144 87-A10-712-080 C-CAP,S 0.22-50 Z F ..C.................

CN 110 87-009-032-010 CONNECTOR,4P YEL ABC.................

D 107 87-A40-115-060 DIODE,RS603M ABC.................

D 101 87-A40-345-080 ZENER,MTZJ10C ABC.................

D 102 87-A40-468-080 C-DIODE,HSM2836CTR ABC.................

D 108 87-A40-468-080 C-DIODE,HSM2836CTR ABC.................

D 109 87-A40-469-080 C-DIODE,HSM2838CTR ABC.................

D 110 87-A40-004-080 ZENER,MTZJ16A ABC.................

D 112 87-A40-335-080 ZENER,MTZJ11C T-72 ABC.................

D 126 87-020-465-080 DIODE,1SS133 (110MA) ABC.................

D 125 87-020-465-080 DIODE,1SS133 (110MA) ABC.................

D 123 87-070-274-080 DIODE,1N4003 SEM ABC.................

D 122 87-070-274-080 DIODE,1N4003 SEM ABC.................

D 121 87-A40-224-010 DIODE,GBU8D ABC.................

D 124 87-A40-435-080 ZENER,MTZJ30D ABC.................

PR 101 87-026-682-080 PROTECTOR,10A 60V491 .BC.................

PR 104 87-026-682-080 PROTECTOR,10A 60V491 .BC.................

PR 101 87-026-691-080 FUSE,10A 125V 251 A...................

PR 104 87-026-691-080 FUSE,10A 125V 251 A...................

Q 107 87-026-610-080 TR,KTC3198GR ABC.................

Q 106 87-A30-076-080 C-TR,2SC3052F ABC.................

Q 103 87-A30-083-080 TR,CSD1489B ABC.................

Q 104 87-A30-085-040 C-TR,CSA1362GR ..C.................

Q 101 89-110-372-080 TR,2SA1037(140MHZ 200MW) ABC.................

Q 108 89-213-702-010 TR,2SB1370 (1.8W) ABC.................

Q 109 89-213-702-010 TR,2SB1370 (1.8W) ABC.................

Q 102 89-213-750-010 TR,2SB1375 (25W) ABC.................

Q 118 87-026-609-080 TR,KTA1266GR ABC.................

Q 117 87-026-609-080 TR,KTA1266GR ABC.................

Q 115 87-A30-075-080 C-TR,2SA1235F ABC.................

Q 113 87-A30-075-080 C-TR,2SA1235F ABC.................

Q 116 87-A30-076-080 C-TR,2SC3052F ABC.................

Q 112 87-A30-076-080 C-TR,2SC3052F ABC.................

Q 114 87-A30-076-080 C-TR,2SC3052F ABC.................

R 109 87-029-060-080 RES,FUSE 33-1/4 W ABC.................

R 143 87-A00-261-080 RES,M/F 0.56-1W J A...................

W 3 8Z-NF3-645-010 CONN ASSY,9P VH ABC.................

WH 101 87-A90-510-010 HLDR,WIRE 2.5-9P ABC.................

87-067-579-010 TAPPING SCREW, BVT2+3-8 ..C.................

87-067-703-010 TAPPING SCREW, BVT2+3-10 AB..................

C 203 87-010-176-080 C-CAP,S 680P-50 SL ABC.................

C 204 87-010-176-080 C-CAP,S 680P-50 SL ABC.................

C 209 87-010-392-080 CAP ELECT 33SME-35V ..C.................

C 206 87-010-405-080 CAP, ELECT 10-50V ABC.................

C 205 87-010-405-080 CAP, ELECT 10-50V ABC.................

C 208 87-016-299-080 CAP,E 10-100 SME ABC.................

C 211 87-010-322-080 C-CAP,S 100P-50 CH ABC.................

C 212 87-010-322-080 C-CAP,S 100P-50 CH ABC.................

C 210 87-010-392-080 CAP ELECT 33SME-35V ..C.................

C 218 87-A10-516-080 C-CAP,S 100P-200 J CH ABC.................

C 217 87-A10-516-080 C-CAP,S 100P-200 J CH ABC.................

C 216 87-A10-897-080 CAP,E 100-25 BP SME ABC.................

C 215 87-A10-897-080 CAP,E 100-25 BP SME ABC.................

C 227 87-010-178-080 CHIP CAP 1000P ABC.................

C 228 87-010-178-080 CHIP CAP 1000P ABC.................

C 225 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................

C 229 87-010-384-080 CAP, ELECT 100-25V AB..................

C 226 87-010-384-080 CAP, ELECT 100-25V AB..................

C 224 87-010-402-080 CAP, ELECT 2.2-50V ABC.................

C 223 87-010-402-080 CAP, ELECT 2.2-50V ABC.................

C 221 87-010-805-080 CAP, S 1-16 ABC.................

C 222 87-010-805-080 CAP, S 1-16 ABC.................

C 229 87-016-251-080 CAP,E 220-16 M SMG ..C.................

C 226 87-016-251-080 CAP,E 220-16 M SMG ..C.................

C 231 87-A10-354-080 C-CAP,S 0.047-50 K B ABC.................

C 230 87-A10-354-080 C-CAP,S 0.047-50 K B ABC.................

C 232 87-A10-946-080 C-CAP,S 220P-100 J CH ..C.................

C 285 87-010-186-080 CAP,CHIP 4700P ABC.................

C 289 87-010-190-080 S CHIP F 0.01 A.C.................

C 287 87-010-190-080 S CHIP F 0.01 A.C.................

C 288 87-010-190-080 S CHIP F 0.01 A.C.................

C 287 87-010-191-080 C-CAP,S 0.015-50 F .B..................

C 289 87-010-191-080 C-CAP,S 0.015-50 F .B..................

C 288 87-010-191-080 C-CAP,S 0.015-50 F .B..................

C 290 87-010-190-080 S CHIP F 0.01 A.C.................

C 290 87-010-191-080 C-CAP,S 0.015-50 F .B..................

C 303 87-010-179-080 CAP,CHIP S B1200P ABC.................

C 304 87-010-179-080 CAP,CHIP S B1200P ABC.................

C 309 87-010-260-080 CAP, ELECT 47-25V ABC.................

C 305 87-010-404-080 CAP, ELECT 4.7-50V AB..................

C 306 87-010-404-080 CAP, ELECT 4.7-50V AB..................

C 308 87-016-299-080 CAP,E 10-100 SME ABC.................

ELECTRICAL MAIN PARTS LIST - 3

C 310 87-010-260-080 CAP, ELECT 47-25V ABC.................

C 312 87-010-322-080 C-CAP,S 100P-50 CH ABC.................

C 311 87-010-322-080 C-CAP,S 100P-50 CH ABC.................

C 317 87-A10-516-080 C-CAP,S 100P-200 J CH ABC.................

C 318 87-A10-516-080 C-CAP,S 100P-200 J CH ABC.................

C 315 87-A10-897-080 CAP,E 100-25 BP SME ABC.................

C 316 87-A10-897-080 CAP,E 100-25 BP SME ABC.................

C 327 87-010-178-080 CHIP CAP 1000P ABC.................

C 328 87-010-178-080 CHIP CAP 1000P ABC.................

C 325 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................

C 323 87-010-402-080 CAP, ELECT 2.2-50V ABC.................

C 324 87-010-402-080 CAP, ELECT 2.2-50V ABC.................

C 322 87-010-805-080 CAP, S 1-16 ABC.................

C 321 87-010-805-080 CAP, S 1-16 ABC.................

C 320 87-A10-946-080 C-CAP,S 220P-100 J CH ..C.................

C 330 87-A10-354-080 C-CAP,S 0.047-50 K B ABC.................

C 331 87-A10-354-080 C-CAP,S 0.047-50 K B ABC.................

C 335 87-A10-918-080 CAP,E 100-16 SMG ABC.................

C 334 87-A10-918-080 CAP,E 100-16 SMG ABC.................

C 385 87-010-186-080 CAP,CHIP 4700P ABC.................

C 396 87-010-190-080 S CHIP F 0.01 A.C.................

C 395 87-010-190-080 S CHIP F 0.01 A.C.................

C 395 87-010-191-080 C-CAP,S 0.015-50 F .B..................

C 396 87-010-191-080 C-CAP,S 0.015-50 F .B..................

C 393 87-012-368-080 C-CAP,S 0.1-50 F ABC.................

C 394 87-012-368-080 C-CAP,S 0.1-50 F ABC.................

C 402 87-010-181-080 CAP,CHIP S 1800P ABC.................

C 406 87-010-322-080 C-CAP,S 100P-50 CH ABC.................

C 403 87-010-405-080 CAP, ELECT 10-50V ABC.................

C 405 87-010-406-080 CAP, ELECT 22-50 ABC.................

C 409 87-A10-516-080 C-CAP,S 100P-200 J CH ABC.................

C 408 87-A10-897-080 CAP,E 100-25 BP SME ABC.................

C 414 87-010-178-080 CHIP CAP 1000P ABC.................

C 413 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................

C 412 87-010-402-080 CAP, ELECT 2.2-50V ABC.................

C 411 87-010-805-080 CAP, S 1-16 ABC.................

C 416 87-016-299-080 CAP,E 10-100 SME ABC.................

C 417 87-A10-946-080 C-CAP,S 220P-100 J CH ..C.................

C 420 87-A10-354-080 C-CAP,S 0.047-50 K B ABC.................

C 485 87-010-186-080 CAP,CHIP 4700P ABC.................

C 493 87-010-190-080 S CHIP F 0.01 A.C.................

C 493 87-010-191-080 C-CAP,S 0.015-50 F .B..................

C 491 87-012-368-080 C-CAP,S 0.1-50 F ABC.................

C 492 87-012-368-080 C-CAP,S 0.1-50 F ABC.................

C 745 87-012-368-080 C-CAP,S 0.1-50 F ABC.................

CNA 202 8Z-AR4-605-010 CONN ASSY,6P VH ..C.................

CNA 201 8Z-AR4-606-010 CONN ASSY,8P VH ..C.................

D 213 87-070-136-080 ZENER,MTZJ5.1B ABC.................

D 211 87-A40-274-010 DIODE,FMB-G16L A...................

D 212 87-A40-274-010 DIODE,FMB-G16L A...................

D 214 87-A40-344-080 ZENER,MTZJ6.2C ABC.................

D 211 87-A40-646-010 DIODE,FMB-G16L .BC.................

D 212 87-A40-646-010 DIODE,FMB-G16L .BC.................

D 221 87-070-274-080 DIODE,1N4003 SEM ABC.................

D 243 87-A40-345-080 ZENER,MTZJ10C ABC.................

D 242 87-A40-488-080 DIODE,1SS244 ABC.................

D 241 87-A40-488-080 DIODE,1SS244 ABC.................

D 313 87-070-136-080 ZENER,MTZJ5.1B ABC.................

D 311 87-A40-274-010 DIODE,FMB-G16L A...................

D 312 87-A40-274-010 DIODE,FMB-G16L A...................

D 314 87-A40-344-080 ZENER,MTZJ6.2C ABC.................

D 311 87-A40-646-010 DIODE,FMB-G16L .BC.................

D 312 87-A40-646-010 DIODE,FMB-G16L .BC.................

D 321 87-070-274-080 DIODE,1N4003 SEM ABC.................

D 343 87-A40-345-080 ZENER,MTZJ10C ABC.................

D 341 87-A40-488-080 DIODE,1SS244 ABC.................

D 342 87-A40-488-080 DIODE,1SS244 ABC.................

D 405 87-020-465-080 DIODE,1SS133 (110MA) ABC.................

D 401 87-020-465-080 DIODE,1SS133 (110MA) ABC.................

D 408 87-070-136-080 ZENER,MTZJ5.1B ABC.................

D 407 87-A40-274-010 DIODE,FMB-G16L A...................

D 406 87-A40-274-010 DIODE,FMB-G16L A...................

D 409 87-A40-344-080 ZENER,MTZJ6.2C ABC.................

D 406 87-A40-646-010 DIODE,FMB-G16L .BC.................

D 407 87-A40-646-010 DIODE,FMB-G16L .BC.................

D 410 87-020-465-080 DIODE,1SS133 (110MA) ABC.................

D 414 87-020-465-080 DIODE,1SS133 (110MA) ABC.................

D 412 87-020-465-080 DIODE,1SS133 (110MA) ABC.................

D 411 87-020-465-080 DIODE,1SS133 (110MA) ABC.................

D 413 87-070-274-080 DIODE,1N4003 SEM ABC.................

D 425 87-020-465-080 DIODE,1SS133 (110MA) ABC.................

D 423 87-020-465-080 DIODE,1SS133 (110MA) ABC.................

D 420 87-020-465-080 DIODE,1SS133 (110MA) ABC.................

D 433 87-A40-345-080 ZENER,MTZJ10C ABC.................

D 441 87-020-465-080 DIODE,1SS133 (110MA) ABC.................

J 201 87-A60-199-010 TERMINAL,SP 8P CJ-9034-07 V0 AB..................

J 301 87-A60-200-110 TERMINAL,SP 6P CJ-9033 AB..................

J 715 87-A60-244-010 JACK,PIN 1P BLK ABC.................

L 294 87-003-383-010 COIL,1UH-S ABC.................

L 291 87-003-383-010 COIL,1UH-S ABC.................

L 293 87-003-383-010 COIL,1UH-S ABC.................

L 292 87-003-383-010 COIL,1UH-S ABC.................

L 392 87-003-383-010 COIL,1UH-S ABC.................

ELECTRICAL MAIN PARTS LIST - 4

L 391 87-003-383-010 COIL,1UH-S ABC.................

L 491 87-003-383-010 COIL,1UH-S ABC.................

PR 202 87-026-682-080 PROTECTOR,10A 60V491 .BC.................

PR 201 87-026-682-080 PROTECTOR,10A 60V491 .BC.................

PR 201 87-026-691-080 FUSE,10A 125V 251 A...................

PR 202 87-026-691-080 FUSE,10A 125V 251 A...................

PR 302 87-026-682-080 PROTECTOR,10A 60V491 .BC.................

PR 301 87-026-682-080 PROTECTOR,10A 60V491 .BC.................

PR 301 87-026-691-080 FUSE,10A 125V 251 A...................

PR 302 87-026-691-080 FUSE,10A 125V 251 A...................

PR 401 87-026-682-080 PROTECTOR,10A 60V491 .BC.................

PR 402 87-026-682-080 PROTECTOR,10A 60V491 .BC.................

PR 401 87-026-691-080 FUSE,10A 125V 251 A...................

PR 402 87-026-691-080 FUSE,10A 125V 251 A...................

Q 201 87-A30-257-080 C-TR,2SD1306E ABC.................

Q 202 87-A30-257-080 C-TR,2SD1306E ABC.................

Q 213 87-A30-097-010 TR,FN 1016 ABC.................

Q 214 87-A30-097-010 TR,FN 1016 ABC.................

Q 215 87-A30-098-010 TR,FP 1016 ABC.................

Q 216 87-A30-098-010 TR,FP 1016 ABC.................

Q 218 87-A30-106-070 C-TR,CMBT5551 ABC.................

Q 217 87-A30-106-070 C-TR,CMBT5551 ABC.................

Q 219 87-A30-162-010 FET,2SK2937 ABC.................

Q 211 87-A30-190-080 TR,CC5551 ABC.................

Q 212 87-A30-190-080 TR,CC5551 ABC.................

Q 228 87-026-232-080 TR,DTA144WK ABC.................

Q 226 87-026-236-080 TR,DTC124E,K ABC.................

Q 221 87-A30-072-080 C-TR,RT1P 144C ABC.................

Q 223 87-A30-074-080 C-TR,RT1P 141C .BC.................

Q 227 87-A30-075-080 C-TR,2SA1235F ABC.................

Q 225 87-A30-075-080 C-TR,2SA1235F ABC.................

Q 220 87-A30-162-010 FET,2SK2937 ABC.................

Q 240 87-A30-107-070 C-TR,CMBT5401 ABC.................

Q 301 87-A30-257-080 C-TR,2SD1306E ABC.................

Q 302 87-A30-257-080 C-TR,2SD1306E ABC.................

Q 314 87-A30-097-010 TR,FN 1016 ABC.................

Q 313 87-A30-097-010 TR,FN 1016 ABC.................

Q 315 87-A30-098-010 TR,FP 1016 ABC.................

Q 316 87-A30-098-010 TR,FP 1016 ABC.................

Q 318 87-A30-106-070 C-TR,CMBT5551 ABC.................

Q 317 87-A30-106-070 C-TR,CMBT5551 ABC.................

Q 319 87-A30-162-010 FET,2SK2937 ABC.................

Q 312 87-A30-190-080 TR,CC5551 ABC.................

Q 311 87-A30-190-080 TR,CC5551 ABC.................

Q 326 87-026-236-080 TR,DTC124E,K ABC.................

Q 321 87-A30-072-080 C-TR,RT1P 144C ABC.................

Q 323 87-A30-074-080 C-TR,RT1P 141C .BC.................

Q 327 87-A30-075-080 C-TR,2SA1235F ABC.................

Q 325 87-A30-075-080 C-TR,2SA1235F ABC.................

Q 320 87-A30-162-010 FET,2SK2937 ABC.................

Q 340 87-A30-107-070 C-TR,CMBT5401 ABC.................

Q 407 87-A30-097-010 TR,FN 1016 ABC.................

Q 408 87-A30-098-010 TR,FP 1016 ABC.................

Q 409 87-A30-106-070 C-TR,CMBT5551 ABC.................

Q 406 87-A30-190-080 TR,CC5551 ABC.................

Q 401 87-A30-257-080 C-TR,2SD1306E ABC.................

Q 417 87-026-236-080 TR,DTC124E,K ABC.................

Q 412 87-A30-072-080 C-TR,RT1P 144C ABC.................

Q 414 87-A30-074-080 C-TR,RT1P 141C .BC.................

Q 416 87-A30-075-080 C-TR,2SA1235F ABC.................

Q 418 87-A30-075-080 C-TR,2SA1235F ABC.................

Q 413 87-A30-076-080 C-TR,2SC3052F ABC.................

Q 411 87-A30-162-010 FET,2SK2937 ABC.................

Q 410 87-A30-162-010 FET,2SK2937 ABC.................

Q 420 87-A30-076-080 C-TR,2SC3052F ABC.................

Q 421 87-A30-076-080 C-TR,2SC3052F ABC.................

Q 440 87-A30-107-070 C-TR,CMBT5401 ABC.................

R 281 87-A00-373-050 RES,M/F 270-1W J VTP ABC.................

R 282 87-A00-373-050 RES,M/F 270-1W J VTP ABC.................

R 283 87-A00-373-050 RES,M/F 270-1W J VTP ABC.................

R 284 87-A00-373-050 RES,M/F 270-1W J VTP ABC.................

R 416 87-A00-262-080 RES,M/F 0.15-2W J AB..................

R 417 87-A00-262-080 RES,M/F 0.15-2W J AB..................

R 417 87-A00-571-050 RES,M/F 0.15-2W J RZ ..C.................

R 416 87-A00-571-050 RES,M/F 0.15-2W J RZ ..C.................

R 424 87-A00-262-080 RES,M/F 0.15-2W J AB..................

R 424 87-A00-571-050 RES,M/F 0.15-2W J RZ ..C.................

R 590 87-A00-262-080 RES,M/F 0.15-2W J AB..................

R 590 87-A00-571-050 RES,M/F 0.15-2W J RZ ..C.................

R 611 87-A00-262-080 RES,M/F 0.15-2W J AB..................

R 611 87-A00-571-050 RES,M/F 0.15-2W J RZ ..C.................

S 292 87-A90-174-010 SW,PUSH 2-2-2 ABC.................

S 291 87-A90-174-010 SW,PUSH 2-2-2 ABC.................

TH 202 87-A91-081-080 C-THMS,100K-K 20P .BC.................

TH 201 87-A91-081-080 C-THMS,100K-K 20P .BC.................

TH 302 87-A91-081-080 C-THMS,100K-K 20P .BC.................

TH 301 87-A91-081-080 C-THMS,100K-K 20P .BC.................

TH 401 87-A91-081-080 C-THMS,100K-K 20P .BC.................

C 609 87-010-188-080 CAP,CHIP 6800P ..C.................

C 602 87-010-378-080 CAP, ELECT 10-16V ..C.................

C 601 87-010-378-080 CAP, ELECT 10-16V ..C.................

C 605 87-010-405-080 CAP, ELECT 10-50V ABC.................

C 606 87-010-405-080 CAP, ELECT 10-50V ABC.................

ELECTRICAL MAIN PARTS LIST - 5

C 607 87-012-140-080 CAP 470P ..C.................

C 608 87-012-140-080 CAP 470P ..C.................

C 604 87-012-156-080 C-CAP,S 220P-50 CH ..C.................

C 603 87-012-156-080 C-CAP,S 220P-50 CH ..C.................

C 610 87-010-188-080 CAP,CHIP 6800P ..C.................

C 613 87-010-195-080 C-CAP,S 0.068-25 F ..C.................

C 612 87-010-195-080 C-CAP,S 0.068-25 F ..C.................

C 614 87-010-197-080 CAP, CHIP 0.01 DM ..C.................

C 611 87-010-197-080 CAP, CHIP 0.01 DM ..C.................

C 618 87-010-404-080 CAP, ELECT 4.7-50V ..C.................

C 617 87-010-404-080 CAP, ELECT 4.7-50V ..C.................

C 616 87-010-404-080 CAP, ELECT 4.7-50V ..C.................

C 619 87-010-404-080 CAP, ELECT 4.7-50V ..C.................

C 615 87-010-404-080 CAP, ELECT 4.7-50V ..C.................

C 620 87-010-101-080 CAP, ELECT 220-16 ..C.................

D 602 87-A40-468-080 C-DIODE,HSM2836CTR ..C.................

D 601 87-A40-468-080 C-DIODE,HSM2836CTR ..C.................

IC 601 87-A20-056-010 IC,BA3880S ..C.................

C 701 87-010-260-080 CAP, ELECT 47-25V ABC.................

C 702 87-010-404-080 CAP, ELECT 4.7-50V ABC.................

C 709 87-012-195-080 C-CAP,U 100P-50CH ABC.................

C 704 87-012-286-080 CAP, U 0.01-25 ABC.................

C 703 87-012-286-080 CAP, U 0.01-25 ABC.................

C 712 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................

C 711 87-010-263-080 CAP, ELECT 100-10V ABC.................

C 719 87-012-286-080 CAP, U 0.01-25 ABC.................

C 713 87-012-286-080 CAP, U 0.01-25 ABC.................

C 714 87-012-286-080 CAP, U 0.01-25 ABC.................

C 717 87-012-286-080 CAP, U 0.01-25 ABC.................

C 727 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................

C 728 87-010-248-080 CAP, ELECT 220-10V ABC.................

C 721 87-012-176-080 CAP 15P ABC.................

C 722 87-012-176-080 CAP 15P ABC.................

C 720 87-012-195-080 C-CAP,U 100P-50CH ABC.................

C 725 87-012-274-080 CHIP CAP,U 1000P-50B ABC.................

C 723 87-012-274-080 CHIP CAP,U 1000P-50B ABC.................

D 721 87-A40-234-080 ZENER,MTZJ5.6A ABC.................

IC 721 87-070-127-110 IC,LC72131 D ABC.................

Q 711 87-A30-196-080 TR,2SC4115SRS ABC.................

X 721 87-A70-061-010 VIB,XTAL 4.500MHZ CSA-309 ABC.................

C 758 87-012-167-080 C-CAP,U 5P-50 CH ABC.................

C 757 87-012-188-080 C-CAP,U 47P-50 CH ABC.................

C 753 87-012-195-080 C-CAP,U 100P-50CH .B..................

C 761 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................

C 769 87-010-260-080 CAP, ELECT 47-25V ABC.................

C 764 87-012-337-080 C-CAP,U 56P-50 CH A.C.................

C 774 87-010-263-080 CAP, ELECT 100-10V ABC.................

C 771 87-010-383-080 CAP, ELECT 33-25V ABC.................

C 777 87-010-400-080 CAP, ELECT 0.47-50V ABC.................

C 778 87-010-401-080 CAP, ELECT 1-50V ABC.................

C 779 87-010-401-080 CAP, ELECT 1-50V ABC.................

C 775 87-010-404-080 CAP, ELECT 4.7-50V ABC.................

C 770 87-010-829-080 CAP, U 0.047-16 ABC.................

C 773 87-015-785-080 CHIP CAPACITOR, 0.1FZ-25Z .B..................

C 780 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................

C 782 87-010-405-080 CAP, ELECT 10-50V ABC.................

C 781 87-010-405-080 CAP, ELECT 10-50V ABC.................

C 785 87-010-805-080 CAP, S 1-16 ABC.................

C 786 87-010-805-080 CAP, S 1-16 ABC.................

C 789 87-012-275-080 C-CAP,U 1200P-50 B ABC.................

C 787 87-012-280-080 CAP, U 3300P-50 ..C.................

C 788 87-012-280-080 CAP, U 3300P-50 ..C.................

C 787 87-012-282-080 CAP, U 4700P-50 AB..................

C 788 87-012-282-080 CAP, U 4700P-50 AB..................

C 783 87-012-286-080 CAP, U 0.01-25 ABC.................

C 796 87-010-403-080 CAP, ELECT 3.3-50V ABC.................

C 791 87-010-405-080 CAP, ELECT 10-50V ABC.................

C 794 87-010-406-080 CAP, ELECT 22-50 ABC.................

C 795 87-010-596-080 CAP, S 0.047-16 A.C.................

C 793 87-012-273-080 C-CAP,U 820P-50 B A.C.................

C 790 87-012-275-080 C-CAP,U 1200P-50 B ABC.................

C 797 87-012-276-080 CAP, CHIP SS 1500 PBK .BC.................

C 798 87-012-276-080 CAP, CHIP SS 1500 PBK .BC.................

C 798 87-012-278-080 C-CAP,U 2200P-50 B A...................

C 797 87-012-278-080 C-CAP,U 2200P-50 B A...................

CN 601 87-099-028-010 CONN,11P 6216 H ABC.................

D 773 87-020-465-080 DIODE,1SS133 (110MA) A...................

IC 771 87-A20-913-010 IC,LA1837NL ABC.................

L 771 87-A50-266-010 COIL,FM DET-2N(TOK) ABC.................

L 772 87-A90-733-010 FLTR,PCFAZH-450 (TOK) ABC.................

L 781 87-005-847-080 COIL,2.2UH(CECS) ABC.................

L 792 87-A50-027-010 COIL,1 POLE MPX(TOK) .BC.................

L 791 87-A50-027-010 COIL,1 POLE MPX(TOK) .BC.................

L 792 87-A50-209-010 COIL,1POLE MPX(MIT) A...................

L 791 87-A50-209-010 COIL,1POLE MPX(MIT) A...................

C 859 87-012-286-080 CAP, U 0.01-25 .B..................

C 865 87-010-196-080 CHIP CAPACITOR,0.1-25 .B..................

C 864 87-010-405-080 CAP, ELECT 10-50V .B..................

C 866 87-010-405-080 CAP, ELECT 10-50V .B..................

C 869 87-012-180-080 C-CAP,U 22P-50 CH .B..................

C 868 87-012-184-080 C-CAP,U 33P-50 CH .B..................

C 861 87-012-199-080 CAP 220P .B..................

C 862 87-012-199-080 CAP 220P .B..................

ELECTRICAL MAIN PARTS LIST - 6

C 863 87-012-270-080 CAP, U 470P-50 .B..................

C 867 87-012-286-080 CAP, U 0.01-25 .B..................

CN 602 87-099-211-010 CONN,4P 6216V .B..................

IC 851 87-A20-440-040 C-IC,BU1920FS .B..................

L 851 87-005-847-080 COIL,2.2UH(CECS) .B..................

Q 853 87-A30-076-080 C-TR,2SC3052F .B..................

X 851 87-A70-091-010 VIB,XTAL 4.332MHZ CSA-309 .B..................

C 813 87-010-197-080 CAP, CHIP 0.01 DM A.C.................

C 819 87-010-197-080 CAP, CHIP 0.01 DM A.C.................

C 812 87-012-286-080 CAP, U 0.01-25 ABC.................

C 814 87-012-286-080 CAP, U 0.01-25 ABC.................

C 828 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................

C 829 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................

C 820 87-010-260-080 CAP, ELECT 47-25V ABC.................

C 823 87-012-286-080 CAP, U 0.01-25 ABC.................

C 822 87-012-286-080 CAP, U 0.01-25 ABC.................

C 821 87-012-286-080 CAP, U 0.01-25 ABC.................

C 942 87-012-172-080 CAPACITOR CHIP U 10P CH .B..................

C 949 87-A10-039-080 C-CAP,U 470P-50 J CH .B..................

C 959 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................

C 960 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................

C 962 87-010-401-080 CAP, ELECT 1-50V .B..................

C 961 87-012-170-080 C-CAP,U 8P-50 CH ..C.................

C 961 87-012-174-080 CAP CHIP CERA SS 12P CHJ A...................

CF 802 82-785-747-010 CF MS2 GHY R .B..................

CF 801 87-008-261-010 FILTER, SFE10.7MA5-A A.C.................

CF 802 87-008-261-010 FILTER, SFE10.7MA5-A A.C.................

CF 801 87-008-423-010 CERAMIC FILTER, SFE10.7 .B..................

D 942 87-A40-270-080 C-DIODE,MC2838 .B..................

FFE 801 A8-6ZA-191-130 6ZA-1 FEENM .B..................

FFE 801 A8-8ZA-190-030 8ZA-1 FEUNM A.C.................

J 802 87-033-241-010 TERMINAL,ANT AJ-2039 .B..................

J 801 87-A60-657-010 TERMINAL,4P HSP-154V5-02 A.C.................

L 832 87-005-847-080 COIL,2.2UH(CECS) ABC.................

L 942 87-A50-019-010 COIL,OSC LW(COI) .B..................

L 941 87-A50-020-010 COIL,ANT LW(COI) .B..................

L 981 87-NF4-650-010 COIL,AM PACK 4N(TOK) A.C.................

L 981 87-NF4-651-110 COIL,AM PACK2N(TOM) .B..................

Q 806 87-A30-072-080 C-TR,RT1P 144C ABC.................

Q 805 89-327-143-080 TR,2SC2714 (0.1W) ABC.................

Q 948 87-A30-086-070 C-TR,CSD1306E .B..................

Q 947 89-503-602-080 C-FET,2SK360E .B..................

Q 951 87-A30-074-080 C-TR,RT1P 141C .B..................

Q 952 87-A30-086-070 C-TR,CSD1306E .B..................

TC 942 87-011-164-010 CAPACITOR,TRIMMER 30P .B..................

C 801 87-010-176-080 C-CAP,S 680P-50 SL ABC.................

C 802 87-010-176-080 C-CAP,S 680P-50 SL ABC.................

C 808 87-010-405-080 CAP, ELECT 10-50V ..C.................

C 807 87-010-405-080 CAP, ELECT 10-50V ..C.................

C 806 87-010-949-080 CHIP CAPACITOR,S 0.01-50 BJ ABC.................

C 803 87-010-949-080 CHIP CAPACITOR,S 0.01-50 BJ ABC.................

C 805 87-010-949-080 CHIP CAPACITOR,S 0.01-50 BJ ABC.................

C 804 87-010-949-080 CHIP CAPACITOR,S 0.01-50 BJ ABC.................

C 809 87-016-081-080 C-CAP,S 0.1-16 RK ABC.................

C 810 87-010-112-080 CAP, ELECT 100-16V ABC.................

C 819 87-010-188-080 CAP,CHIP 6800P ABC.................

C 817 87-010-221-080 CAP, ELECT 470-10V ABC.................

C 813 87-010-400-080 CAP, ELECT 0.47-50V ABC.................

C 812 87-010-401-080 CAP, ELECT 1-50V ABC.................

C 811 87-010-401-080 CAP, ELECT 1-50V ABC.................

C 812 87-010-402-080 CAP, ELECT 2.2-50V AB..................

C 811 87-010-402-080 CAP, ELECT 2.2-50V AB..................

C 818 87-010-404-080 CAP, ELECT 4.7-50V ABC.................

C 816 87-010-546-080 CAP, ELECT 0.33-50V ABC.................

C 815 87-010-546-080 CAP, ELECT 0.33-50V ABC.................

C 827 87-010-166-080 C-CAP,S 100P-50 SL ABC.................

C 826 87-010-166-080 C-CAP,S 100P-50 SL ABC.................

C 828 87-010-166-080 C-CAP,S 100P-50 SL ABC.................

C 823 87-010-263-080 CAP, ELECT 100-10V ABC.................

C 824 87-010-374-080 CAP, ELECT 47-10V ABC.................

C 829 87-010-544-080 CAP, ELECT 0.1-50V ABC.................

C 825 87-016-081-080 C-CAP,S 0.1-16 RK ABC.................

C 821 87-016-081-080 C-CAP,S 0.1-16 RK ABC.................

C 822 87-016-083-080 C-CAP,S 0.15-16 RK ABC.................

C 830 87-010-546-080 CAP, ELECT 0.33-50V ABC.................

C 831 87-010-971-080 C-CAP,S 4700P-50 B J ABC.................

C 837 87-010-971-080 C-CAP,S 4700P-50 B J ABC.................

C 832 87-012-349-080 C-CAP,S 1000P-50 CH ABC.................

C 838 87-012-349-080 C-CAP,S 1000P-50 CH ABC.................

C 845 87-012-393-080 C-CAP,S 0.22-16 R K ABC.................

C 849 87-012-393-080 C-CAP,S 0.22-16 R K ABC.................

C 848 87-012-393-080 C-CAP,S 0.22-16 R K ABC.................

C 844 87-012-393-080 C-CAP,S 0.22-16 R K ABC.................

C 843 87-A10-229-080 C-CAP,S 0.68-10 K W5 ABC.................

C 841 87-A10-799-080 C-CAP,S 5600P-16 J B CM ABC.................

C 842 87-A10-802-080 C-CAP,S 0.047-16 J B CM ABC.................

C 856 87-A10-801-080 C-CAP,S 0.022-16 J B CM ABC.................

C 855 87-A10-801-080 C-CAP,S 0.022-16 J B CM ABC.................

C 852 87-A10-802-080 C-CAP,S 0.047-16 J B CM ABC.................

C 851 87-A10-802-080 C-CAP,S 0.047-16 J B CM ABC.................

C 869 87-010-166-080 C-CAP,S 100P-50 SL ABC.................

C 862 87-010-263-080 CAP, ELECT 100-10V ABC.................

C 864 87-010-263-080 CAP, ELECT 100-10V ABC.................

ELECTRICAL MAIN PARTS LIST - 7

C 866 87-010-749-080 CAP,S 0.047-25 B AB..................

C 861 87-016-081-080 C-CAP,S 0.1-16 RK ABC.................

C 863 87-016-081-080 C-CAP,S 0.1-16 RK ABC.................

C 868 87-A10-060-080 C-CAP,S 0.18-16 K B ABC.................

C 867 87-A10-201-080 C-CAP,S0.33-16 KB ABC.................

C 870 87-010-166-080 C-CAP,S 100P-50 SL ABC.................

C 871 87-010-166-080 C-CAP,S 100P-50 SL ABC.................

CN 801 87-099-556-010 CONN,10P TUC-P10X-B1 ABC.................

CN 802 87-099-559-010 CONN,13P TUC-P13X-B1 ABC.................

D 802 87-070-136-080 ZENER,MTZJ5.1B ABC.................

D 803 87-A40-438-080 ZENER,MTZJ4.7A ABC.................

D 804 87-A40-438-080 ZENER,MTZJ4.7A ABC.................

D 801 87-A40-442-080 ZENER,MTZJ9.1A ABC.................

IC 801 87-A21-097-040 C-IC,M62463AFP ABC.................

IC 831 87-A21-015-040 C-IC,M62491FP ABC.................

Q 834 87-A30-076-080 C-TR,2SC3052F ABC.................

R 807 87-022-365-080 C-RES,S 100K-1/10W F ABC.................

C 702 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................

C 701 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................

IC 701 87-020-784-080 IC,TC4053BF ABC.................

C 906 87-010-260-080 CAP, ELECT 47-25V ABC.................

C 909 87-010-371-080 CAP, ELECT 470-6.3V ABC.................

C 908 87-010-387-080 CAP,E 470-25 SME ABC.................

C 901 87-010-406-080 CAP, ELECT 22-50 ABC.................

C 905 87-010-406-080 CAP, ELECT 22-50 ABC.................

C 903 87-010-406-080 CAP, ELECT 22-50 ABC.................

C 902 87-010-406-080 CAP, ELECT 22-50 ABC.................

C 904 87-010-406-080 CAP, ELECT 22-50 ABC.................

C 912 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................

C 910 87-010-371-080 CAP, ELECT 470-6.3V ABC.................

C 911 87-010-371-080 CAP, ELECT 470-6.3V ABC.................

C 954 87-010-322-080 C-CAP,S 100P-50 CH .B..................

C 953 87-010-322-080 C-CAP,S 100P-50 CH .B..................

C 952 87-010-322-080 C-CAP,S 100P-50 CH .B..................

C 951 87-010-322-080 C-CAP,S 100P-50 CH .B..................

D 902 87-020-465-080 DIODE,1SS133 (110MA) ABC.................

D 901 87-070-136-080 ZENER,MTZJ5.1B ABC.................

D 903 87-A40-291-080 DIODE,1N4148 (CPT) ABC.................

IC 902 87-017-917-080 IC,BU4066BCF ABC.................

IC 901 87-A20-820-010 IC,BA7625 ABC.................

J 903 87-099-911-010 JACK,PIN 3P YEL ABC.................

J 901 87-099-911-010 JACK,PIN 3P YEL ABC.................

J 904 87-099-911-010 JACK,PIN 3P YEL ABC.................

J 905 87-099-911-010 JACK,PIN 3P YEL ABC.................

J 902 87-099-912-010 JACK,PIN 3P YEL W/E ABC.................

L 901 87-005-239-080 COIL,100UH ABC.................

Q 906 87-A30-074-080 C-TR,RT1P 141C ABC.................

Q 901 87-A30-075-080 C-TR,2SA1235F ABC.................

Q 903 87-A30-075-080 C-TR,2SA1235F ABC.................

Q 907 87-A30-075-080 C-TR,2SA1235F ABC.................

Q 902 87-A30-075-080 C-TR,2SA1235F ABC.................

Q 904 87-A30-076-080 C-TR,2SC3052F ABC.................

Q 905 87-A30-076-080 C-TR,2SC3052F ABC.................

R 905 87-010-317-080 C-CAP,S 39P-50 CH ..C.................

C 102 87-010-186-080 CAP,CHIP 4700P ABC.................

C 101 87-018-131-080 CAP, CER 1000P-50V ABC.................

C 504 87-010-188-080 CAP,CHIP 6800P ABC.................

C 503 87-010-188-080 CAP,CHIP 6800P ABC.................

C 502 87-018-209-080 CAP, CER 0.1-50V ABC.................

C 501 87-018-209-080 CAP, CER 0.1-50V ABC.................

C 507 87-018-209-080 CAP, CER 0.1-50V ABC.................

C 651 87-010-178-080 CHIP CAP 1000P .B..................

C 652 87-010-178-080 CHIP CAP 1000P .B..................

CN 401 87-099-758-010 CONN,17P H 9604 ABC.................

D 503 87-020-465-080 DIODE,1SS133 (110MA) ABC.................

D 504 87-020-465-080 DIODE,1SS133 (110MA) ABC.................

D 502 87-020-465-080 DIODE,1SS133 (110MA) ABC.................

D 501 87-020-465-080 DIODE,1SS133 (110MA) ABC.................

D 505 87-020-465-080 DIODE,1SS133 (110MA) ABC.................

D 506 87-020-465-080 DIODE,1SS133 (110MA) ABC.................

FB 501 87-008-372-080 FILTER, EMI BL OIRNI ABC.................

FB 602 87-008-372-080 FILTER, EMI BL OIRNI ABC.................

J 501 87-A60-606-010 JACK,PIN 3P R/W/Y W/O SW H ABC.................

J 603 87-A60-550-010 JACK,DIA6.3 BLK ST W/SW KM ABC.................

LED 401 87-A40-317-080 LED,SLR-342VCT31 RED ABC.................

S 403 87-A90-095-080 SW,TACT EVQ11G04M ABC.................

S 401 87-A90-095-080 SW,TACT EVQ11G04M ABC.................

S 402 87-A90-095-080 SW,TACT EVQ11G04M ABC.................

SW 401 87-A91-373-010 SW,RTRY EC16B1220408 ABC.................

C 723 87-010-401-080 CAP, ELECT 1-50V ABC.................

C 726 87-010-401-080 CAP, ELECT 1-50V ABC.................

Q 721 87-A30-086-070 C-TR,CSD1306E ABC.................

CN 509 87-099-667-010 CONN,8P TUC-P8P-B1 ..C.................

CN 504 87-099-567-010 CONN,10P TUC-P10P-B1 ABC.................

CN 505 87-099-570-010 CONN,13P TUC-P13P-B1 ABC.................

C 1 87-012-368-080 C-CAP,S 0.1-50 F ..C.................

C 712 87-010-322-080 C-CAP,S 100P-50 CH .B..................

C 714 87-010-322-080 C-CAP,S 100P-50 CH .B..................

C 715 87-010-322-080 C-CAP,S 100P-50 CH .B..................

C 710 87-010-322-080 C-CAP,S 100P-50 CH .B..................

C 711 87-010-322-080 C-CAP,S 100P-50 CH .B..................

C 713 87-010-322-080 C-CAP,S 100P-50 CH .B..................

C 750 87-010-196-080 CHIP CAPACITOR,0.1-25 ABC.................

ELECTRICAL MAIN PARTS LIST - 8

J 750 87-A60-660-010 JACK,PIN 6P W/R,W/R, B/O(G) ABC.................

C 131 87-010-378-080 CAP, ELECT 10-16V ABC.................

C 133 87-010-378-080 CAP, ELECT 10-16V ABC.................

C 135 87-012-368-080 C-CAP,S 0.1-50 F ABC.................

C 136 87-012-368-080 C-CAP,S 0.1-50 F ABC.................

IC 101 87-017-888-080 IC,NJM4558MD ABC.................

C 659 87-010-177-080 C-CAP,S 820P-50 SL ..C.................

C 654 87-010-183-080 C-CAP,S 2700P-50 B ..C.................

C 657 87-010-183-080 C-CAP,S 2700P-50 B ..C.................

C 652 87-010-196-080 CHIP CAPACITOR,0.1-25 ..C.................

C 655 87-010-196-080 CHIP CAPACITOR,0.1-25 ..C.................

C 658 87-012-145-080 CAP, CHIP S 270P CH ..C.................

C 653 87-012-154-080 C-CAP,S 150P-50 CH ..C.................

C 656 87-012-154-080 C-CAP,S 150P-50 CH ..C.................

C 671 87-010-177-080 C-CAP,S 820P-50 SL ..C.................

C 672 87-010-196-080 CHIP CAPACITOR,0.1-25 ..C.................

C 673 87-010-196-080 CHIP CAPACITOR,0.1-25 ..C.................

C 674 87-010-196-080 CHIP CAPACITOR,0.1-25 ..C.................

C 675 87-010-263-080 CAP, ELECT 100-10V ..C.................

C 676 87-010-374-080 CAP, ELECT 47-10V ..C.................

C 670 87-012-145-080 CAP, CHIP S 270P CH ..C.................

CN 508 87-099-669-010 CONN,8P TUC-P8X-B1 ..C.................

D 650 87-070-136-080 ZENER,MTZJ5.1B ..C.................

IC 650 87-A20-561-040 C-IC,M65847AFP ..C.................

C 758 87-010-404-080 CAP, ELECT 4.7-50V ABC.................

C 759 87-012-368-080 C-CAP,S 0.1-50 F ABC.................

C 766 87-010-181-080 CAP,CHIP S 1800P ABC.................

C 764 87-010-185-080 C-CAP,S 3900P-50 B ABC.................

C 769 87-010-188-080 CAP,CHIP 6800P ABC.................

C 765 87-010-194-080 CAP, CHIP 0.047 ABC.................

C 762 87-010-197-080 CAP, CHIP 0.01 DM ABC.................

C 761 87-010-198-080 CAP, CHIP 0.022 ABC.................

C 767 87-010-198-080 CAP, CHIP 0.022 ABC.................

C 768 87-010-994-080 C-CAP,S 680P-50 CH ABC.................

C 776 87-010-181-080 CAP,CHIP S 1800P ABC.................

C 771 87-010-183-080 C-CAP,S 2700P-50 B ABC.................

C 778 87-010-185-080 C-CAP,S 3900P-50 B ABC.................

C 777 87-010-194-080 CAP, CHIP 0.047 ABC.................

C 775 87-010-198-080 CAP, CHIP 0.022 ABC.................

C 774 87-010-994-080 C-CAP,S 680P-50 CH ABC.................

C 772 87-012-145-080 CAP, CHIP S 270P CH ABC.................

C 770 87-012-145-080 CAP, CHIP S 270P CH ABC.................

C 782 87-010-183-080 C-CAP,S 2700P-50 B ABC.................

C 780 87-010-197-080 CAP, CHIP 0.01 DM ABC.................

C 783 87-010-198-080 CAP, CHIP 0.022 ABC.................

C 789 87-010-260-080 CAP, ELECT 47-25V ABC.................

C 788 87-010-260-080 CAP, ELECT 47-25V ABC.................

C 786 87-010-402-080 CAP, ELECT 2.2-50V ABC.................

C 787 87-010-402-080 CAP, ELECT 2.2-50V ABC.................

C 790 87-010-260-080 CAP, ELECT 47-25V ABC.................

C 799 87-010-322-080 C-CAP,S 100P-50 CH ABC.................

C 797 87-010-322-080 C-CAP,S 100P-50 CH ABC.................

C 798 87-010-322-080 C-CAP,S 100P-50 CH ABC.................

C 791 87-010-405-080 CAP, ELECT 10-50V ABC.................

C 792 87-010-405-080 CAP, ELECT 10-50V ABC.................

C 794 87-012-368-080 C-CAP,S 0.1-50 F ABC.................

C 793 87-012-368-080 C-CAP,S 0.1-50 F ABC.................

CN 701 87-099-557-010 CONN,11P TUC-P11X-B1 ABC.................

D 722 87-A40-002-080 ZENER,MTZJ5.1C ABC.................

D 723 87-A40-344-080 ZENER,MTZJ6.2C ABC.................

D 721 87-A40-344-080 ZENER,MTZJ6.2C ABC.................

IC 701 87-A20-437-010 C-IC,M62431FP ABC.................

C 608 87-010-186-080 CAP,CHIP 4700P ..C.................

C 609 87-010-188-080 CAP,CHIP 6800P ..C.................

C 607 87-010-196-080 CHIP CAPACITOR,0.1-25 ..C.................

C 601 87-010-196-080 CHIP CAPACITOR,0.1-25 ..C.................

C 606 87-010-321-080 CHIP CAPACITOR,82P(J) ..C.................

C 605 87-010-322-080 C-CAP,S 100P-50 CH ..C.................

C 603 87-010-491-040 CAP,E 0.22-50 GAS ..C.................

C 602 87-010-560-040 CAP,E 10-50 GAS ..C.................

C 604 87-A10-189-040 CAP,E 220-10 ..C.................

C 612 87-010-177-080 C-CAP,S 820P-50 SL ..C.................

C 611 87-010-322-080 C-CAP,S 100P-50 CH ..C.................

C 613 87-010-552-040 CAP,E 22-16 GAS ..C.................

C 610 87-010-560-040 CAP,E 10-50 GAS ..C.................

C 614 87-015-695-040 E/CAP 1UF 50V TAPG ..C.................

CN 601 87-009-362-010 CONN,6P,BTMK P-1R ..C.................

D 601 87-020-465-080 DIODE,1SS133 (110MA) ..C.................

FB 601 87-008-372-080 FILTER, EMI BL OIRNI ..C.................

IC 601 87-017-888-080 IC,NJM4558MD ..C.................

J 601 87-A60-188-010 JACK,6.3 BLK MONO W/SW MIC ..C.................

J 602 87-A60-188-010 JACK,6.3 BLK MONO W/SW MIC ..C.................

Q 601 87-A30-087-080 C-FET,2SK2158 ..C.................

C 1 87-010-387-080 CAP,E 470-25 SME AB..................

C 2 87-010-403-080 CAP, ELECT 3.3-50V AB..................

C 7 87-A10-922-090 CAP,CER 0.01-250 M F KH AB..................

C 141 87-012-368-080 C-CAP,S 0.1-50 F .B..................

C 141 87-018-209-080 CAP, CER 0.1-50V AB..................

CN 103 87-A60-851-010 CONN,9P V VH AB..................

CN 101 88-805-042-690 CONN ASSY,4P AB..................

D 4 87-020-465-080 DIODE,1SS133 (110MA) AB..................

D 2 87-020-465-080 DIODE,1SS133 (110MA) AB..................

D 7 87-020-465-080 DIODE,1SS133 (110MA) AB..................

ELECTRICAL MAIN PARTS LIST - 9

Other manuals for AV-D35

Table of contents

Popular Stereo Receiver manuals by other brands

Teac

Teac AG-680 Service manual

Kenwood

Kenwood KR-V888D instruction manual

Teac

Teac AGV1050 owner's manual

Sony

Sony STR-435 operating instructions

Pioneer

Pioneer Elite SC-68 Service manual

Pioneer

Pioneer SX-1250 operating instructions

Marantz

Marantz CINEMA 70S owner's manual

Kenwood

Kenwood KMDX92 instruction manual

Yamaha

Yamaha RX-830 owner's manual

Pioneer

Pioneer AVH-Z7250BT owner's manual

Denon

Denon AVR-1311 owner's manual

Denon

Denon AVR-S760H owner's manual

Denon

Denon AVR-X7200W Service manual

Sony

Sony XAV-1500 operating instructions

Radio Shack

Radio Shack DX-399 owner's manual

Sony

Sony STR-DE535 - Fm Stereo/fm-am Receiver operating instructions

Pioneer

Pioneer SX-1000TA operating instructions

Yamaha

Yamaha MusicCast TSR-5B3D owner's manual

Aiwa AV-D35 Specification sheet

Popular Stereo Receiver manuals by other brands
