SERVICE MANUAL

DATA

AV-NW30

U (B)

STEREORECEIVER

S/M Code No. 09-026-358-2T1

SIMPLE

Replace this Service Manual with “Revision Publishing” when it is issued.

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

! = ! SAFTY PARTS

C = Components marked

All components used on this model at the production line are shown in this service manual.

However, please note that not all components will be available as spare parts for after-sales service.

Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.

Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL

-2-

ACCESSORIES PARTS LIST-1/1

AV-NW30

UBC

ACCESSORY O AS1001 87-006-226-010 ANT,LOOP AM X a

ACCESSORY O AS1002 87-A92-346-010 ANT,WIRE FM(FASTEN) X a

ACCESSORY O AS1003 8C-AR6-701-010 RC UNIT,RC-CAR01 X a

LBL,POP X AS1004 87-B40-034-010 LBL,USA 1-800 a

LBL,POP X AS1005 8A-NF8-972-010 LBL,POP ENG a

PACKING DU X AS1006 87-B40-098-010 BAG,PV 0.025-650-750 PL a

PACKING DU X AS1007 8C-AR6-851-010 CUSHION,LEFT C a

PACKING DU X AS1008 8C-AR6-852-010 CUSHION,RIGHT C a

PACKING DU X AS1009 8C-AR6-853-010 CTN,PRINTED UBC a

PACKING DU X AS1010 8C-AR6-857-010 PAD,FRONT TOP a

PACKING DU X AS1011 92-370-716-010 SH,FOAMED-MAT 0.31-700-500 a

PRINTED DU X AS1012 87-B40-086-010 BAG,PV 0.04-230-400 PL a

PRINTED DU X AS1013 87-B50-053-010 WARR-CARD,USA CUST/AV,VISUAL a

PRINTED DU O AS1014 8C-AR6-903-110 IB,U(ESF)S AV-NW30/31 a

PRINTED DU X AS1015 8C-AR6-918-010 SH,ADDITIONAL HP(ESF) a

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

! = ! SAFTY PARTS

C = Components marked

All components used on this model at the production line are shown in this service manual.

However, please note that not all components will be available as spare parts for after-sales service.

Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.

Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL

-3-

ELECTRICAL PARTS LIST -1/28

AV-NW30

UBC

AC1 X JW 0011 88-100-000-010 PLATING-JW, 0.58 SN95 a

AC1 ! O W 0002 8C-AR6-627-010 CONN ASSY,1P BLACK a

AC1 ! O W 0003 8C-AR6-628-010 CONN ASSY,1P WHITE a

AC2 ! O CNA0002 8C-AR6-626-010 CONN ASSY,9P VH a

AC2 X JW 0005 88-100-000-010 PLATING-JW, 0.58 SN95 a

AC2 X JW 0006 88-100-000-010 PLATING-JW, 0.58 SN95 a

AC2 ! S JW 0009 87-A91-970-080 FUSE,5A 125V F 20N a

AC2 ! S JW 0010 87-A91-970-080 FUSE,5A 125V F 20N a

AC2 ! O WH 0001 87-A90-510-010 HLDR,WIRE 2.5-9P a

AV SEL O C 0701 87-010-407-080 CAP,E 33-50 M 11L SME a

AV SEL O C 0702 87-010-407-080 CAP,E 33-50 M 11L SME a

AV SEL O C 0703 87-010-407-080 CAP,E 33-50 M 11L SME a

AV SEL O C 0717 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a

AV SEL O C 0731 87-012-188-080 C-CAP,U 47P-50 J CH GRM a

AV SEL O C 0732 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a

AV SEL O C 0733 87-012-188-080 C-CAP,U 47P-50 J CH GRM a

AV SEL O C 0735 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a

AV SEL O C 0761 87-010-407-080 CAP,E 33-50 M 11L SME a

AV SEL O C 0762 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a

AV SEL O C 0763 87-010-383-080 CAP,E 33-25 M 11L SME a

AV-NW30

UBC

AV SEL O C 0764 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a

AV SEL O C 0781 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a

AV SEL S D 0761 87-A40-754-080 ZENER,UZ6.8BSC a

AV SEL S D 0762 87-A40-754-080 ZENER,UZ6.8BSC a

AV SEL S IC 0701 87-A22-287-040 C-IC,NJM2279M a

AV SEL ! O J 0701 87-A61-865-010 JACK,PIN 6P YWR/YWR W/E a

AV SEL ! O J 0702 87-A61-865-010 JACK,PIN 6P YWR/YWR W/E a

AV SEL ! O J 0731 87-A61-862-010 JACK,PIN 3P Y/W/R W/E a

AV SEL X JW 0711 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV SEL X JW 0712 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV SEL X JW 0713 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV SEL X JW 0714 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV SEL X JW 0715 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV SEL X JW 0716 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV SEL X JW 0717 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV SEL X JW 0718 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV SEL X JW 0719 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV SEL X JW 0720 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV SEL X JW 0721 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV SEL X JW 0722 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV-NW30

UBC

AV SEL X JW 0723 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV SEL X JW 0724 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV SEL X JW 0725 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV SEL X JW 0726 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV SEL X JW 0727 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV SEL X JW 0728 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV SEL X JW 0729 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV SEL X JW 0730 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV SEL X JW 0731 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV SEL X JW 0732 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV SEL X JW 0733 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV SEL X JW 0734 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV SEL X JW 0735 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV SEL X JW 0736 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV SEL X JW 0737 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV SEL X JW 0738 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV SEL X JW 0739 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV SEL X JW 0740 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV SEL X JW 0741 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV SEL X JW 0742 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV-NW30

UBC

AV SEL X JW 0743 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV SEL X JW 0744 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV SEL X JW 0745 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV SEL X JW 0746 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV SEL X JW 0747 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV SEL X JW 0748 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV SEL X JW 0749 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV SEL X JW 0750 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV SEL O L 0761 87-005-239-080 COIL,100UH K LAL03 a

AV SEL O L 0762 87-005-239-080 COIL,100UH K LAL03 a

AV SEL X R 0641 88-108-000-080 C-JUMPER,U a

AV SEL X R 0642 88-108-000-080 C-JUMPER,U a

AV SEL X R 0643 88-108-000-080 C-JUMPER,U a

AV SEL X R 0644 88-108-000-080 C-JUMPER,U a

AV SEL X R 0645 88-108-000-080 C-JUMPER,U a

AV SEL X R 0646 88-108-000-080 C-JUMPER,U a

AV SEL X R 0647 88-108-000-080 C-JUMPER,U a

AV SEL X R 0648 88-108-000-080 C-JUMPER,U a

AV SEL X R 0649 88-108-000-080 C-JUMPER,U a

AV SEL X R 0650 88-108-000-080 C-JUMPER,U a

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

! = ! SAFTY PARTS

C = Components marked

All components used on this model at the production line are shown in this service manual.

However, please note that not all components will be available as spare parts for after-sales service.

Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.

Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL

-4-

ELECTRICALPARTSLIST-2/28

AV-NW30

UBC

AV SEL X R 0651 88-108-000-080 C-JUMPER,U a

AV SEL X R 0652 88-108-000-080 C-JUMPER,U a

AV SEL X R 0653 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV SEL X R 0654 88-108-000-080 C-JUMPER,U a

AV SEL X R 0655 88-108-000-080 C-JUMPER,U a

AV SEL X R 0656 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV SEL X R 0657 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV SEL X R 0658 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV SEL X R 0659 88-108-000-080 C-JUMPER,U a

AV SEL X R 0660 88-108-000-080 C-JUMPER,U a

AV SEL X R 0701 88-118-750-080 C-RES,S 75-1/10W J a

AV SEL X R 0702 88-118-750-080 C-RES,S 75-1/10W J a

AV SEL X R 0703 88-118-750-080 C-RES,S 75-1/10W J a

AV SEL O R 0711 88-108-101-080 C-RES,U 100-1/16W J a

AV SEL O R 0712 88-108-101-080 C-RES,U 100-1/16W J a

AV SEL O R 0713 88-108-101-080 C-RES,U 100-1/16W J a

AV SEL O R 0714 88-108-101-080 C-RES,U 100-1/16W J a

AV SEL O R 0715 88-108-101-080 C-RES,U 100-1/16W J a

AV SEL O R 0716 88-108-101-080 C-RES,U 100-1/16W J a

AV SEL O R 0721 88-108-473-080 C-RES,U 47K-1/16W J a

AV-NW30

UBC

AV SEL O R 0722 88-108-473-080 C-RES,U 47K-1/16W J a

AV SEL O R 0723 88-108-473-080 C-RES,U 47K-1/16W J a

AV SEL O R 0724 88-108-473-080 C-RES,U 47K-1/16W J a

AV SEL O R 0725 88-108-473-080 C-RES,U 47K-1/16W J a

AV SEL O R 0726 88-108-473-080 C-RES,U 47K-1/16W J a

AV SEL X R 0731 88-121-750-080 RES,75-1/8W J a

AV SEL X R 0732 88-121-750-080 RES,75-1/8W J a

AV SEL X R 0761 88-128-181-080 C-RES, 180-1/8W J a

AV SEL X R 0762 88-128-181-080 C-RES, 180-1/8W J a

AV SEL X R 0763 88-128-181-080 C-RES, 180-1/8W J a

AV SEL O R 0764 88-108-102-080 C-RES,U 1K-1/16W J a

AV SEL O R 0766 88-108-102-080 C-RES,U 1K-1/16W J a

AV SEL O R 0771 88-108-102-080 C-RES,U 1K-1/16W J a

AV SEL O R 0772 88-108-102-080 C-RES,U 1K-1/16W J a

AV SEL O R 0773 88-108-102-080 C-RES,U 1K-1/16W J a

AV SEL O R 0774 88-108-102-080 C-RES,U 1K-1/16W J a

AV SEL X R 0775 88-121-472-080 RES,4.7K-1/8W J a

AV SEL X R 0776 88-108-182-080 C-RES,U 1.8K-1/16W J a

AV SEL O R 0781 88-108-473-080 C-RES,U 47K-1/16W J a

AV SEL O R 0782 88-108-473-080 C-RES,U 47K-1/16W J a

AV-NW30

UBC

AV SEL O R 0783 88-108-473-080 C-RES,U 47K-1/16W J a

AV SEL O R 0784 88-108-473-080 C-RES,U 47K-1/16W J a

AV SEL X R 0791 88-128-820-080 C-RES, 82-1/8W J a

AV SEL X R 0792 88-128-820-080 C-RES, 82-1/8W J a

AV SEL X R 0793 88-129-000-080 C-JUMPER, 3216 a

CODEC X * 8C-AR6-645-010 PWB,DSP 4M CAR-6 a

CODEC O C 0001 87-010-101-080 CAP,E 220-16 M SME a

CODEC O C 0002 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a

CODEC O C 0003 87-010-401-010 CAP,E 1-50 M SME a

CODEC O C 0004 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a

CODEC O C 0005 87-010-401-010 CAP,E 1-50 M SME a

CODEC O C 0006 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a

CODEC O C 0013 87-010-248-080 CAP,E 220-10 M 11L SME a

CODEC O C 0014 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a

CODEC O C 0401 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a

CODEC O C 0402 87-010-405-080 CAP,E 10-50 M 11L SME a

CODEC O C 0403 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a

CODEC O C 0404 87-010-405-080 CAP,E 10-50 M 11L SME a

CODEC O C 0405 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a

CODEC O C 0406 87-010-405-080 CAP,E 10-50 M 11L SME a

AV-NW30

UBC

CODEC O C 0407 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a

CODEC O C 0408 87-010-402-080 CAP,E 2.2-50 M 11L SME a

CODEC O C 0409 87-010-405-080 CAP,E 10-50 M 11L SME a

CODEC O C 0410 87-010-405-080 CAP,E 10-50 M 11L SME a

CODEC O C 0411 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a

CODEC O C 0412 87-010-405-080 CAP,E 10-50 M 11L SME a

CODEC O C 0413 87-012-274-080 C-CAP,U 1000P-50 K B GRM a

CODEC ! O CN 0101 87-099-014-010 CONN,12P V BLK 6216 a

CODEC ! O CN 0102 87-A61-013-010 CONN,15P H BLK TAC-L15P-A3 a

CODEC O FB 0011 87-008-372-080 FLTR,EMI BL01 RN1 a

CODEC X FB 0401 88-108-000-080 C-JUMPER,U a

CODEC O FB 0402 87-005-512-080 C-COIL,2125 80H BLM21 a

CODEC O FB 0403 87-005-512-080 C-COIL,2125 80H BLM21 a

CODEC O FB 0405 87-005-512-080 C-COIL,2125 80H BLM21 a

CODEC O FB 0406 87-005-512-080 C-COIL,2125 80H BLM21 a

CODEC X FB 0408 88-108-000-080 C-JUMPER,U a

CODEC S IC 0001 87-A21-363-010 IC,NJM7805FA(A) a

CODEC S IC 0011 87-A20-736-010 IC,BA033ST a

CODEC S IC 0401 87-A22-266-030 C-IC,AK4586 a

CODEC X JR 0401 88-108-000-080 C-JUMPER,U a

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

! = ! SAFTY PARTS

C = Components marked

All components used on this model at the production line are shown in this service manual.

However, please note that not all components will be available as spare parts for after-sales service.

Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.

Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL

-5-

ELECTRICALPARTSLIST-3/28

AV-NW30

UBC

CODEC O JR 0402 87-005-512-080 C-COIL,2125 80H BLM21 a

CODEC X R 0011 88-130-479-080 RES,4.7-1/4W J a

CODEC X R 0141 88-108-000-080 C-JUMPER,U a

CODEC X R 0142 88-108-000-080 C-JUMPER,U a

CODEC X R 0143 88-108-000-080 C-JUMPER,U a

CODEC X R 0144 88-108-000-080 C-JUMPER,U a

CODEC X R 0145 88-108-000-080 C-JUMPER,U a

CODEC X R 0146 88-108-000-080 C-JUMPER,U a

CODEC X R 0147 88-108-000-080 C-JUMPER,U a

CODEC X R 0148 88-108-000-080 C-JUMPER,U a

CODEC X R 0149 88-108-000-080 C-JUMPER,U a

CODEC X R 0150 88-108-331-080 C-RES,U 330-1/16W J a

CODEC O R 0401 88-108-101-080 C-RES,U 100-1/16W J a

CODEC O R 0402 88-108-101-080 C-RES,U 100-1/16W J a

CODEC O R 0403 88-108-101-080 C-RES,U 100-1/16W J a

CODEC O R 0404 88-108-101-080 C-RES,U 100-1/16W J a

CODEC O R 0405 88-108-101-080 C-RES,U 100-1/16W J a

CODEC O R 0406 88-108-101-080 C-RES,U 100-1/16W J a

CODEC O R 0407 88-108-102-080 C-RES,U 1K-1/16W J a

CODEC O R 0408 88-108-102-080 C-RES,U 1K-1/16W J a

AV-NW30

UBC

CODEC O R 0409 88-108-102-080 C-RES,U 1K-1/16W J a

CODEC O R 0410 88-108-102-080 C-RES,U 1K-1/16W J a

CODEC X R 0411 88-108-183-080 C-RES,U 18K-1/16W J a

CODEC X R 0412 88-108-104-080 C-RES,U 100K-1/16W J a

CODEC X R 0413 88-108-104-080 C-RES,U 100K-1/16W J a

CODEC X R 0415 88-108-331-080 C-RES,U 330-1/16W J a

CODEC X R 0416 88-108-331-080 C-RES,U 330-1/16W J a

CODEC X R 0417 88-108-331-080 C-RES,U 330-1/16W J a

CODEC X R 0418 88-108-331-080 C-RES,U 330-1/16W J a

CODEC X R 0419 88-108-331-080 C-RES,U 330-1/16W J a

CODEC X R 0420 88-108-331-080 C-RES,U 330-1/16W J a

DIGITAL IN O C 0451 87-012-180-080 C-CAP,U 22P-50 J CH GRM a

DIGITAL IN O C 0452 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a

DIGITAL IN O C 0461 87-012-278-080 C-CAP,U 2200P-50 K B GRM a

DIGITAL IN O C 0471 87-012-278-080 C-CAP,U 2200P-50 K B GRM a

DIGITAL IN S IC 0461 87-A21-974-010 IC,GP1FA551RZ a

DIGITAL IN S IC 0471 87-A21-974-010 IC,GP1FA551RZ a

DIGITAL IN ! O J 0451 87-A61-861-010 JACK,PIN 1P ORN W/E a

DIGITAL IN X JR 0501 88-108-000-080 C-JUMPER,U a

DIGITAL IN X R 0451 88-118-820-080 C-RES,S 82-1/10W J a

AV-NW30

UBC

DIGITAL IN X R 0460 88-128-100-010 C-RES, 10-1/8W J a

DIGITAL IN X R 0461 88-118-471-080 C-RES,S 470-1/10W J a

DIGITAL IN X R 0471 88-118-471-080 C-RES,S 470-1/10W J a

DIGITAL IN X R 0563 88-108-104-080 C-RES,U 100K-1/16W J a

DSP O C 0501 87-010-405-080 CAP,E 10-50 M 11L SME a

DSP O C 0502 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a

DSP O C 0503 87-012-170-080 C-CAP,U 8P-50 D CH GRM a

DSP O C 0504 87-012-176-080 C-CAP,U 15P-50 J CH GRM a

DSP O C 0505 87-010-263-080 CAP,E 100-10 M 11L SME a

DSP O C 0506 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a

DSP O C 0507 87-A10-039-080 C-CAP,U 470P-50 J CH a

DSP O C 0508 87-010-374-080 CAP,E 47-10 M 11L SME a

DSP O C 0509 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a

DSP O C 0510 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a

DSP O C 0511 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a

DSP O C 0512 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a

DSP O C 0513 87-010-404-080 CAP,E 4.7-50 M 11L SME a

DSP O C 0514 87-012-195-080 C-CAP,U 100P-50 J CH GRM a

DSP O C 0515 87-012-195-080 C-CAP,U 100P-50 J CH GRM a

DSP O C 0516 87-012-195-080 C-CAP,U 100P-50 J CH GRM a

AV-NW30

UBC

DSP O C 0517 87-012-195-080 C-CAP,U 100P-50 J CH GRM a

DSP O C 0518 87-012-195-080 C-CAP,U 100P-50 J CH GRM a

DSP O C 0519 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a

DSP O C 0520 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a

DSP O C 0521 87-010-401-080 CAP,E 1-50 M 11L SME a

DSP O C 0522 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a

DSP O C 0523 87-012-274-080 C-CAP,U 1000P-50 K B GRM a

DSP S D 0501 87-020-465-080 DIODE,1SS133 a

DSP S D 0502 87-A40-740-080 ZENER,UZ3.3BSA a

DSP S D 0503 87-020-465-080 DIODE,1SS133 a

DSP O FB 0501 87-005-512-080 C-COIL,2125 80H BLM21 a

DSP O FB 0502 87-005-512-080 C-COIL,2125 80H BLM21 a

DSP O FB 0503 87-005-512-080 C-COIL,2125 80H BLM21 a

DSP O FB 0504 87-005-512-080 C-COIL,2125 80H BLM21 a

DSP O FB 0505 87-005-512-080 C-COIL,2125 80H BLM21 a

DSP O FB 0506 87-005-512-080 C-COIL,2125 80H BLM21 a

DSP O FB 0507 87-005-512-080 C-COIL,2125 80H BLM21 a

DSP O FB 0508 87-005-512-080 C-COIL,2125 80H BLM21 a

DSP S IC 0501 87-A21-500-010 C-IC,YSS912 a

DSP X JR 0502 88-108-000-080 C-JUMPER,U a

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

! = ! SAFTY PARTS

C = Components marked

All components used on this model at the production line are shown in this service manual.

However, please note that not all components will be available as spare parts for after-sales service.

Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.

Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL

-6-

ELECTRICALPARTSLIST-4/28

AV-NW30

UBC

DSP X JR 0503 88-108-000-080 C-JUMPER,U a

DSP S Q 0501 87-A30-076-080 C-TR,2SC3052F a

DSP S Q 0502 87-A30-429-040 C-TR,DTC123JKA a

DSP X R 0501 88-108-391-080 C-RES,U 390-1/16W J a

DSP X R 0502 88-108-105-080 C-RES,U 1M-1/16W J a

DSP X R 0503 88-108-271-080 C-RES,U 270-1/16W J a

DSP O R 0504 88-108-103-080 C-RES,U 10K-1/16W J a

DSP O R 0505 88-108-101-080 C-RES,U 100-1/16W J a

DSP O R 0506 88-108-101-080 C-RES,U 100-1/16W J a

DSP O R 0507 88-108-101-080 C-RES,U 100-1/16W J a

DSP X R 0508 88-108-104-080 C-RES,U 100K-1/16W J a

DSP O R 0509 88-108-101-080 C-RES,U 100-1/16W J a

DSP O R 0510 88-108-101-080 C-RES,U 100-1/16W J a

DSP O R 0511 88-108-101-080 C-RES,U 100-1/16W J a

DSP O R 0512 88-108-101-080 C-RES,U 100-1/16W J a

DSP O R 0513 88-108-101-080 C-RES,U 100-1/16W J a

DSP X R 0514 88-108-100-080 C-RES,U 10-1/16W J a

DSP X R 0515 88-108-472-080 C-RES,U 4.7K-1/16W J a

DSP O R 0516 88-108-102-080 C-RES,U 1K-1/16W J a

DSP O R 0517 88-108-101-080 C-RES,U 100-1/16W J a

AV-NW30

UBC

DSP O R 0518 88-108-101-080 C-RES,U 100-1/16W J a

DSP O R 0519 88-108-101-080 C-RES,U 100-1/16W J a

DSP O X 0501 87-A70-115-010 VIB,XTAL 12.288MHZ a

FUNCTION O C 0631 87-010-404-080 CAP,E 4.7-50 M 11L SME a

FUNCTION O C 0632 87-010-404-080 CAP,E 4.7-50 M 11L SME a

FUNCTION O C 0633 87-010-404-080 CAP,E 4.7-50 M 11L SME a

FUNCTION O C 0634 87-010-404-080 CAP,E 4.7-50 M 11L SME a

FUNCTION O C 0635 87-010-404-080 CAP,E 4.7-50 M 11L SME a

FUNCTION O C 0636 87-010-404-080 CAP,E 4.7-50 M 11L SME a

FUNCTION O C 0641 87-010-405-080 CAP,E 10-50 M 11L SME a

FUNCTION O C 0642 87-010-405-080 CAP,E 10-50 M 11L SME a

FUNCTION O C 0643 87-010-405-080 CAP,E 10-50 M 11L SME a

FUNCTION O C 0644 87-010-405-080 CAP,E 10-50 M 11L SME a

FUNCTION O C 0645 87-010-405-080 CAP,E 10-50 M 11L SME a

FUNCTION O C 0646 87-010-405-080 CAP,E 10-50 M 11L SME a

FUNCTION O C 0651 87-A11-014-080 CAP,M 0.22-50 J DE a

FUNCTION O C 0652 87-A11-014-080 CAP,M 0.22-50 J DE a

FUNCTION O C 0653 87-A11-014-080 CAP,M 0.22-50 J DE a

FUNCTION O C 0654 87-A11-014-080 CAP,M 0.22-50 J DE a

FUNCTION O C 0655 87-A10-307-080 CAP,M 0.1-50 J a

AV-NW30

UBC

FUNCTION O C 0656 87-A10-307-080 CAP,M 0.1-50 J a

FUNCTION O C 0657 87-A10-307-080 CAP,M 0.1-50 J a

FUNCTION O C 0658 87-A10-307-080 CAP,M 0.1-50 J a

FUNCTION O C 0659 87-A10-291-080 CAP,M 4700P-50 J a

FUNCTION O C 0660 87-A10-291-080 CAP,M 4700P-50 J a

FUNCTION O C 0661 87-010-404-080 CAP,E 4.7-50 M 11L SME a

FUNCTION O C 0662 87-010-404-080 CAP,E 4.7-50 M 11L SME a

FUNCTION O C 0663 87-010-404-080 CAP,E 4.7-50 M 11L SME a

FUNCTION O C 0665 87-010-404-080 CAP,E 4.7-50 M 11L SME a

FUNCTION O C 0666 87-010-404-080 CAP,E 4.7-50 M 11L SME a

FUNCTION O C 0681 87-010-263-080 CAP,E 100-10 M 11L SME a

FUNCTION O C 0682 87-010-383-080 CAP,E 33-25 M 11L SME a

FUNCTION O C 0683 87-012-274-080 C-CAP,U 1000P-50 K B GRM a

FUNCTION O C 0692 87-A12-317-080 C-CAP,U 0.1-50 Z F a

FUNCTION O C 0693 87-A12-317-080 C-CAP,U 0.1-50 Z F a

FUNCTION ! O CN 0602 87-A60-625-010 CONN,8P V 2MM JMT a

FUNCTION ! O CN 0604 87-A60-998-010 CONN,15P V BLK TAC-L15X-A3 a

FUNCTION ! O CN 0605 87-099-015-010 CONN,13P V BLK 6216 a

FUNCTION ! O CN 0608 87-099-018-010 CONN,16P V BLK 6216 a

FUNCTION ! O CN 0691 87-099-014-010 CONN,12P V BLK 6216 a

AV-NW30

UBC

FUNCTION ! O CN 0692 87-099-014-010 CONN,12P V BLK 6216 a

FUNCTION S D 0681 87-A40-754-080 ZENER,UZ6.8BSC a

FUNCTION S IC 0501 87-A22-267-030 C-IC,BD3811K1 a

FUNCTION X JR 0603 88-108-000-080 C-JUMPER,U a

FUNCTION X JR 0606 88-108-000-080 C-JUMPER,U a

FUNCTION X JR 0608 88-108-000-080 C-JUMPER,U a

FUNCTION X JR 0611 88-108-000-080 C-JUMPER,U a

FUNCTION X JR 0612 88-129-000-080 C-JUMPER, 3216 a

FUNCTION X JR 0615 88-118-000-080 C-JUMPER,S a

FUNCTION X JR 0616 88-118-000-080 C-JUMPER,S a

FUNCTION X JW 0603 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0605 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0611 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0612 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0613 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0614 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0615 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0616 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0617 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0618 88-100-000-010 PLATING-JW, 0.58 SN95 a

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

! = ! SAFTY PARTS

C = Components marked

All components used on this model at the production line are shown in this service manual.

However, please note that not all components will be available as spare parts for after-sales service.

Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.

Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL

-7-

ELECTRICALPARTSLIST-5/28

AV-NW30

UBC

FUNCTION X JW 0619 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0620 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0621 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0622 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0623 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0624 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0625 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0627 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0628 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0629 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0630 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0631 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0632 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0633 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0634 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0635 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0636 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0637 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0638 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0639 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV-NW30

UBC

FUNCTION X JW 0640 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0641 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0642 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0643 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0644 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0647 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0648 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0649 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0650 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0651 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0652 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0653 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0655 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0656 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0657 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0658 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0659 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0660 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0661 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0662 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV-NW30

UBC

FUNCTION X JW 0664 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0665 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0666 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0667 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0668 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0669 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0670 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0671 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0672 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0674 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0675 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0676 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0677 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0678 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0679 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0680 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0681 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0682 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0683 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION X JW 0698 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV-NW30

UBC

FUNCTION S Q 0681 87-A30-075-080 C-TR,2SA1235F a

FUNCTION S Q 0682 87-A30-612-080 TR,2SC5343Y a

FUNCTION S Q 0683 87-A30-075-080 C-TR,2SA1235F a

FUNCTION S Q 0684 87-A30-075-080 C-TR,2SA1235F a

FUNCTION O R 0601 88-108-101-080 C-RES,U 100-1/16W J a

FUNCTION O R 0602 88-108-101-080 C-RES,U 100-1/16W J a

FUNCTION O R 0603 88-108-101-080 C-RES,U 100-1/16W J a

FUNCTION O R 0604 88-108-101-080 C-RES,U 100-1/16W J a

FUNCTION O R 0605 88-108-101-080 C-RES,U 100-1/16W J a

FUNCTION O R 0606 88-108-101-080 C-RES,U 100-1/16W J a

FUNCTION X R 0607 88-108-472-080 C-RES,U 4.7K-1/16W J a

FUNCTION X R 0608 88-108-472-080 C-RES,U 4.7K-1/16W J a

FUNCTION X R 0609 88-108-472-080 C-RES,U 4.7K-1/16W J a

FUNCTION X R 0610 88-108-472-080 C-RES,U 4.7K-1/16W J a

FUNCTION O R 0611 88-108-473-080 C-RES,U 47K-1/16W J a

FUNCTION O R 0612 88-108-473-080 C-RES,U 47K-1/16W J a

FUNCTION O R 0613 88-108-473-080 C-RES,U 47K-1/16W J a

FUNCTION O R 0614 88-108-473-080 C-RES,U 47K-1/16W J a

FUNCTION O R 0615 88-108-473-080 C-RES,U 47K-1/16W J a

FUNCTION O R 0616 88-108-473-080 C-RES,U 47K-1/16W J a

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

! = ! SAFTY PARTS

C = Components marked

All components used on this model at the production line are shown in this service manual.

However, please note that not all components will be available as spare parts for after-sales service.

Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.

Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL

-8-

ELECTRICALPARTSLIST-6/28

AV-NW30

UBC

FUNCTION O R 0617 88-108-103-080 C-RES,U 10K-1/16W J a

FUNCTION O R 0618 88-108-103-080 C-RES,U 10K-1/16W J a

FUNCTION X R 0681 88-128-120-080 C-RES, 12-1/8W J a

FUNCTION X R 0682 88-128-120-080 C-RES, 12-1/8W J a

FUNCTION X R 0683 88-128-120-080 C-RES, 12-1/8W J a

FUNCTION X R 0684 88-128-150-080 C-RES, 15-1/8W J a

FUNCTION X R 0685 88-100-000-010 PLATING-JW, 0.58 SN95 a

FUNCTION O R 0686 88-108-103-080 C-RES,U 10K-1/16W J a

FUNCTION O R 0687 88-108-223-080 C-RES,U 22K-1/16W J a

FUNCTION O R 0688 88-108-103-080 C-RES,U 10K-1/16W J a

FUNCTION X R 0691 88-128-120-080 C-RES, 12-1/8W J a

FUNCTION O R 0692 87-A00-147-050 RES,M/F 68-1W J RSF(S) a

FUNCTION O R 0693 87-A00-147-050 RES,M/F 68-1W J RSF(S) a

FUNCTION X R 0694 88-129-000-080 C-JUMPER, 3216 a

FUNCTION X R 0695 88-128-120-080 C-RES, 12-1/8W J a

FUNCTION X R 0696 88-128-120-080 C-RES, 12-1/8W J a

FUNCTION X R 0697 88-128-120-080 C-RES, 12-1/8W J a

FUNCTION O R 0698 88-108-103-080 C-RES,U 10K-1/16W J a

HP/VIDEO O C 0551 87-012-278-080 C-CAP,U 2200P-50 K B GRM a

HP/VIDEO O C 0552 87-012-278-080 C-CAP,U 2200P-50 K B GRM a

AV-NW30

UBC

HP/VIDEO O C 0553 87-A12-317-080 C-CAP,U 0.1-50 Z F a

HP/VIDEO ! O CN 0551 87-099-209-010 CONN,4P H BLK 6216 a

HP/VIDEO O FB 0551 87-008-372-080 FLTR,EMI BL01 RN1 a

HP/VIDEO ! O J 0551 87-A60-483-010 JACK,DIA6.3 BLK ST W/S KM a

KEY ! O CN 0501 87-099-202-010 CONN,9P H BLK 6216 a

KEY ! O CN 0502 87-099-209-010 CONN,4P H BLK 6216 a

KEY O D 0525 87-A41-142-010 LED,SPR-39MVWF GRN/RED (L/M/N) a

KEY X JW 0521 88-100-000-010 PLATING-JW, 0.58 SN95 a

KEY S Q 0525 87-A30-677-040 C-TR,SRA2207S a

KEY S Q 0526 87-A30-071-080 C-TR,RT1N 144C a

KEY X R 0521 88-108-182-080 C-RES,U 1.8K-1/16W J a

KEY X R 0522 88-108-000-080 C-JUMPER,U a

KEY O R 0523 88-108-102-080 C-RES,U 1K-1/16W J a

KEY X R 0525 88-121-182-080 RES,1.8K-1/8W J a

KEY X R 0526 88-121-681-080 RES,680-1/8W J a

KEY O S 0521 87-A90-164-080 SW,TACT SKQNAB(N) a

KEY O S 0522 87-A90-164-080 SW,TACT SKQNAB(N) a

LPF/BUFFER O C 0101 87-010-405-080 CAP,E 10-50 M 11L SME a

LPF/BUFFER O C 0102 87-010-405-080 CAP,E 10-50 M 11L SME a

LPF/BUFFER O C 0111 87-012-270-080 C-CAP,U 470P-50 K B GRM a

AV-NW30

UBC

LPF/BUFFER O C 0112 87-012-270-080 C-CAP,U 470P-50 K B GRM a

LPF/BUFFER O C 0113 87-012-188-080 C-CAP,U 47P-50 J CH GRM a

LPF/BUFFER O C 0114 87-012-188-080 C-CAP,U 47P-50 J CH GRM a

LPF/BUFFER O C 0115 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a

LPF/BUFFER O C 0116 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a

LPF/BUFFER O C 0117 87-010-405-080 CAP,E 10-50 M 11L SME a

LPF/BUFFER O C 0118 87-010-405-080 CAP,E 10-50 M 11L SME a

LPF/BUFFER O C 0121 87-012-199-080 C-CAP,U 220P-50 J CH GRM a

LPF/BUFFER O C 0122 87-012-199-080 C-CAP,U 220P-50 J CH GRM a

LPF/BUFFER O C 0123 87-A10-369-080 C-CAP,S 0.47-16 K B a

LPF/BUFFER O C 0124 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a

LPF/BUFFER O C 0125 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a

LPF/BUFFER O C 0127 87-010-405-080 CAP,E 10-50 M 11L SME a

LPF/BUFFER O C 0128 87-010-405-080 CAP,E 10-50 M 11L SME a

LPF/BUFFER O C 0201 87-010-405-080 CAP,E 10-50 M 11L SME a

LPF/BUFFER O C 0202 87-010-405-080 CAP,E 10-50 M 11L SME a

LPF/BUFFER O C 0211 87-012-270-080 C-CAP,U 470P-50 K B GRM a

LPF/BUFFER O C 0212 87-012-270-080 C-CAP,U 470P-50 K B GRM a

LPF/BUFFER O C 0213 87-012-188-080 C-CAP,U 47P-50 J CH GRM a

LPF/BUFFER O C 0214 87-012-188-080 C-CAP,U 47P-50 J CH GRM a

AV-NW30

UBC

LPF/BUFFER O C 0215 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a

LPF/BUFFER O C 0216 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a

LPF/BUFFER O C 0217 87-010-405-080 CAP,E 10-50 M 11L SME a

LPF/BUFFER O C 0218 87-010-405-080 CAP,E 10-50 M 11L SME a

LPF/BUFFER O C 0221 87-012-199-080 C-CAP,U 220P-50 J CH GRM a

LPF/BUFFER O C 0222 87-012-199-080 C-CAP,U 220P-50 J CH GRM a

LPF/BUFFER O C 0223 87-A10-369-080 C-CAP,S 0.47-16 K B a

LPF/BUFFER O C 0224 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a

LPF/BUFFER O C 0225 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a

LPF/BUFFER O C 0227 87-010-405-080 CAP,E 10-50 M 11L SME a

LPF/BUFFER O C 0228 87-010-405-080 CAP,E 10-50 M 11L SME a

LPF/BUFFER O C 0301 87-010-405-080 CAP,E 10-50 M 11L SME a

LPF/BUFFER O C 0302 87-010-405-080 CAP,E 10-50 M 11L SME a

LPF/BUFFER O C 0311 87-012-270-080 C-CAP,U 470P-50 K B GRM a

LPF/BUFFER O C 0312 87-012-274-080 C-CAP,U 1000P-50 K B GRM a

LPF/BUFFER O C 0313 87-012-188-080 C-CAP,U 47P-50 J CH GRM a

LPF/BUFFER O C 0314 87-012-195-080 C-CAP,U 100P-50 J CH GRM a

LPF/BUFFER O C 0315 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a

LPF/BUFFER O C 0316 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a

LPF/BUFFER O C 0317 87-010-405-080 CAP,E 10-50 M 11L SME a

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

! = ! SAFTY PARTS

C = Components marked

All components used on this model at the production line are shown in this service manual.

However, please note that not all components will be available as spare parts for after-sales service.

Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.

Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL

-9-

ELECTRICALPARTSLIST-7/28

AV-NW30

UBC

LPF/BUFFER O C 0318 87-010-405-080 CAP,E 10-50 M 11L SME a

LPF/BUFFER O C 0321 87-012-199-080 C-CAP,U 220P-50 J CH GRM a

LPF/BUFFER O C 0322 87-012-274-080 C-CAP,U 1000P-50 K B GRM a

LPF/BUFFER O C 0323 87-A10-369-080 C-CAP,S 0.47-16 K B a

LPF/BUFFER O C 0324 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a

LPF/BUFFER O C 0325 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a

LPF/BUFFER O C 0327 87-010-405-080 CAP,E 10-50 M 11L SME a

LPF/BUFFER O C 0328 87-010-405-080 CAP,E 10-50 M 11L SME a

LPF/BUFFER S IC 0101 87-A21-760-040 C-IC,NJM4580V a

LPF/BUFFER S IC 0102 87-A21-760-040 C-IC,NJM4580V a

LPF/BUFFER S IC 0201 87-A21-760-040 C-IC,NJM4580V a

LPF/BUFFER S IC 0202 87-A21-760-040 C-IC,NJM4580V a

LPF/BUFFER S IC 0301 87-A21-760-040 C-IC,NJM4580V a

LPF/BUFFER S IC 0302 87-A21-760-040 C-IC,NJM4580V a

LPF/BUFFER X R 0101 88-108-104-080 C-RES,U 100K-1/16W J a

LPF/BUFFER X R 0102 88-108-104-080 C-RES,U 100K-1/16W J a

LPF/BUFFER X R 0103 88-118-000-080 C-JUMPER,S a

LPF/BUFFER X R 0104 88-118-000-080 C-JUMPER,S a

LPF/BUFFER O R 0105 88-108-102-080 C-RES,U 1K-1/16W J a

LPF/BUFFER O R 0106 88-108-102-080 C-RES,U 1K-1/16W J a

AV-NW30

UBC

LPF/BUFFER O R 0107 88-108-103-080 C-RES,U 10K-1/16W J a

LPF/BUFFER O R 0108 88-108-103-080 C-RES,U 10K-1/16W J a

LPF/BUFFER O R 0111 88-108-223-080 C-RES,U 22K-1/16W J a

LPF/BUFFER O R 0112 88-108-223-080 C-RES,U 22K-1/16W J a

LPF/BUFFER O R 0113 88-108-223-080 C-RES,U 22K-1/16W J a

LPF/BUFFER O R 0114 88-108-223-080 C-RES,U 22K-1/16W J a

LPF/BUFFER O R 0117 88-108-473-080 C-RES,U 47K-1/16W J a

LPF/BUFFER O R 0118 88-108-473-080 C-RES,U 47K-1/16W J a

LPF/BUFFER X R 0119 88-108-472-080 C-RES,U 4.7K-1/16W J a

LPF/BUFFER O R 0121 88-108-332-080 C-RES,U 3.3K-1/16W J a

LPF/BUFFER O R 0122 88-108-332-080 C-RES,U 3.3K-1/16W J a

LPF/BUFFER X R 0127 88-118-000-080 C-JUMPER,S a

LPF/BUFFER X R 0128 88-118-000-080 C-JUMPER,S a

LPF/BUFFER O R 0129 88-108-822-080 C-RES,U 8.2K-1/16W J a

LPF/BUFFER O R 0130 88-108-822-080 C-RES,U 8.2K-1/16W J a

LPF/BUFFER X R 0131 88-108-104-080 C-RES,U 100K-1/16W J a

LPF/BUFFER X R 0132 88-108-104-080 C-RES,U 100K-1/16W J a

LPF/BUFFER X R 0133 88-108-471-080 C-RES,U 470-1/16W J a

LPF/BUFFER X R 0134 88-108-471-080 C-RES,U 470-1/16W J a

LPF/BUFFER X R 0135 88-108-104-080 C-RES,U 100K-1/16W J a

AV-NW30

UBC

LPF/BUFFER X R 0136 88-108-104-080 C-RES,U 100K-1/16W J a

LPF/BUFFER X R 0201 88-108-104-080 C-RES,U 100K-1/16W J a

LPF/BUFFER X R 0202 88-108-104-080 C-RES,U 100K-1/16W J a

LPF/BUFFER X R 0203 88-118-000-080 C-JUMPER,S a

LPF/BUFFER X R 0204 88-118-000-080 C-JUMPER,S a

LPF/BUFFER O R 0205 88-108-102-080 C-RES,U 1K-1/16W J a

LPF/BUFFER O R 0206 88-108-102-080 C-RES,U 1K-1/16W J a

LPF/BUFFER O R 0207 88-108-103-080 C-RES,U 10K-1/16W J a

LPF/BUFFER O R 0208 88-108-103-080 C-RES,U 10K-1/16W J a

LPF/BUFFER O R 0211 88-108-223-080 C-RES,U 22K-1/16W J a

LPF/BUFFER O R 0212 88-108-223-080 C-RES,U 22K-1/16W J a

LPF/BUFFER O R 0213 88-108-223-080 C-RES,U 22K-1/16W J a

LPF/BUFFER O R 0214 88-108-223-080 C-RES,U 22K-1/16W J a

LPF/BUFFER O R 0215 88-108-332-080 C-RES,U 3.3K-1/16W J a

LPF/BUFFER O R 0216 88-108-332-080 C-RES,U 3.3K-1/16W J a

LPF/BUFFER O R 0217 88-108-473-080 C-RES,U 47K-1/16W J a

LPF/BUFFER O R 0218 88-108-473-080 C-RES,U 47K-1/16W J a

LPF/BUFFER X R 0219 88-108-472-080 C-RES,U 4.7K-1/16W J a

LPF/BUFFER X R 0227 88-108-000-080 C-JUMPER,U a

LPF/BUFFER X R 0228 88-108-000-080 C-JUMPER,U a

AV-NW30

UBC

LPF/BUFFER O R 0229 88-108-822-080 C-RES,U 8.2K-1/16W J a

LPF/BUFFER O R 0230 88-108-822-080 C-RES,U 8.2K-1/16W J a

LPF/BUFFER X R 0231 88-108-104-080 C-RES,U 100K-1/16W J a

LPF/BUFFER X R 0232 88-108-104-080 C-RES,U 100K-1/16W J a

LPF/BUFFER X R 0233 88-108-471-080 C-RES,U 470-1/16W J a

LPF/BUFFER X R 0234 88-108-471-080 C-RES,U 470-1/16W J a

LPF/BUFFER X R 0235 88-108-104-080 C-RES,U 100K-1/16W J a

LPF/BUFFER X R 0236 88-108-104-080 C-RES,U 100K-1/16W J a

LPF/BUFFER X R 0301 88-108-104-080 C-RES,U 100K-1/16W J a

LPF/BUFFER X R 0302 88-108-104-080 C-RES,U 100K-1/16W J a

LPF/BUFFER X R 0303 88-118-000-080 C-JUMPER,S a

LPF/BUFFER X R 0304 88-118-000-080 C-JUMPER,S a

LPF/BUFFER O R 0305 88-108-102-080 C-RES,U 1K-1/16W J a

LPF/BUFFER O R 0306 88-108-102-080 C-RES,U 1K-1/16W J a

LPF/BUFFER O R 0307 88-108-103-080 C-RES,U 10K-1/16W J a

LPF/BUFFER O R 0308 88-108-103-080 C-RES,U 10K-1/16W J a

LPF/BUFFER O R 0311 88-108-223-080 C-RES,U 22K-1/16W J a

LPF/BUFFER X R 0312 88-108-000-080 C-JUMPER,U a

LPF/BUFFER O R 0313 88-108-223-080 C-RES,U 22K-1/16W J a

LPF/BUFFER O R 0314 88-108-223-080 C-RES,U 22K-1/16W J a

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

! = ! SAFTY PARTS

C = Components marked

All components used on this model at the production line are shown in this service manual.

However, please note that not all components will be available as spare parts for after-sales service.

Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.

Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL

-10-

ELECTRICALPARTSLIST-8/28

AV-NW30

UBC

LPF/BUFFER O R 0315 88-108-332-080 C-RES,U 3.3K-1/16W J a

LPF/BUFFER O R 0317 88-108-473-080 C-RES,U 47K-1/16W J a

LPF/BUFFER O R 0318 88-108-473-080 C-RES,U 47K-1/16W J a

LPF/BUFFER X R 0319 88-108-472-080 C-RES,U 4.7K-1/16W J a

LPF/BUFFER X R 0327 88-108-000-080 C-JUMPER,U a

LPF/BUFFER X R 0328 88-108-000-080 C-JUMPER,U a

LPF/BUFFER O R 0329 88-108-822-080 C-RES,U 8.2K-1/16W J a

LPF/BUFFER O R 0330 88-108-822-080 C-RES,U 8.2K-1/16W J a

LPF/BUFFER X R 0331 88-108-104-080 C-RES,U 100K-1/16W J a

LPF/BUFFER X R 0332 88-108-104-080 C-RES,U 100K-1/16W J a

LPF/BUFFER X R 0333 88-108-471-080 C-RES,U 470-1/16W J a

LPF/BUFFER X R 0334 88-108-471-080 C-RES,U 470-1/16W J a

LPF/BUFFER X R 0335 88-108-104-080 C-RES,U 100K-1/16W J a

LPF/BUFFER X R 0336 88-108-104-080 C-RES,U 100K-1/16W J a

LPF/BUFFER O R 0338 88-108-332-080 C-RES,U 3.3K-1/16W J a

MICON O C 0052 87-010-403-080 CAP,E 3.3-50 M 11L SME a

MICON O C 0101 87-010-405-080 CAP,E 10-50 M 11L SME a

MICON O C 0102 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a

MICON O C 0103 87-012-274-080 C-CAP,U 1000P-50 K B GRM a

MICON O C 0104 87-012-286-080 C-CAP,U 0.01-25 K B GRM a

AV-NW30

UBC

MICON O C 0105 87-012-176-080 C-CAP,U 15P-50 J CH GRM a

MICON O C 0106 87-012-198-080 C-CAP,U 180P-50 J CH GRM a

MICON O C 0107 87-A10-039-080 C-CAP,U 470P-50 J CH a

MICON O C 0108 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a

MICON O C 0112 87-012-278-080 C-CAP,U 2200P-50 K B GRM a

MICON O C 0119 87-012-278-080 C-CAP,U 2200P-50 K B GRM a

MICON O C 0120 87-012-195-080 C-CAP,U 100P-50 J CH GRM a

MICON O C 0121 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a

MICON O C 0122 87-A11-242-080 CAP,E 220-10 M 5L SRM a

MICON O C 0123 87-012-368-080 C-CAP,S 0.1-50 Z F GRM a

MICON O C 0124 87-010-405-080 CAP,E 10-50 M 11L SME a

MICON O C 0125 87-010-405-080 CAP,E 10-50 M 11L SME a

MICON O C 0126 87-010-408-080 CAP,E 47-50 M 11L SME a

MICON O C 0127 87-012-368-080 C-CAP,S 0.1-50 Z F GRM a

MICON O C 0130 87-010-405-080 CAP,E 10-50 M 11L SME a

MICON O C 0159 87-012-336-080 C-CAP,U 330P-50 J SL GRM a

MICON O C 0160 87-012-336-080 C-CAP,U 330P-50 J SL GRM a

MICON O C 0161 87-012-336-080 C-CAP,U 330P-50 J SL GRM a

MICON O C 0162 87-012-336-080 C-CAP,U 330P-50 J SL GRM a

MICON O C 0163 87-012-336-080 C-CAP,U 330P-50 J SL GRM a

AV-NW30

UBC

MICON O C 0164 87-012-336-080 C-CAP,U 330P-50 J SL GRM a

MICON O C 0165 87-012-336-080 C-CAP,U 330P-50 J SL GRM a

MICON O C 0166 87-012-336-080 C-CAP,U 330P-50 J SL GRM a

MICON O C 0167 87-012-336-080 C-CAP,U 330P-50 J SL GRM a

MICON O C 0168 87-012-336-080 C-CAP,U 330P-50 J SL GRM a

MICON O C 0169 87-012-336-080 C-CAP,U 330P-50 J SL GRM a

MICON O C 0201 87-010-387-080 CAP,E 470-25 M SME a

MICON O C 0202 87-010-385-080 CAP,E 220-25 M SME a

MICON O C 0203 87-010-785-080 C-CAP,U 0.015-25 K B GRM a

MICON O C 0204 87-012-278-080 C-CAP,U 2200P-50 K B GRM a

MICON O C 0205 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a

MICON O C 0206 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a

MICON O C 0207 87-010-248-040 CAP,E 220-10 M 11L SME a

MICON O C 0211 87-010-677-080 CAP,E 0.15-50 M 7L SRA a

MICON O C 0215 87-012-274-080 C-CAP,U 1000P-50 K B GRM a

MICON O C 0331 87-012-278-080 C-CAP,U 2200P-50 K B GRM a

MICON O C 0332 87-012-199-080 C-CAP,U 220P-50 J CH GRM a

MICON O C 0341 87-012-278-080 C-CAP,U 2200P-50 K B GRM a

MICON O C 0342 87-010-787-080 C-CAP,U 0.022-25 K B GRM a

MICON O C 0343 87-012-199-080 C-CAP,U 220P-50 J CH GRM a

AV-NW30

UBC

MICON O C 0351 87-010-787-080 C-CAP,U 0.022-25 K B GRM a

MICON O C 0352 87-012-199-080 C-CAP,U 220P-50 J CH GRM a

MICON O C 0421 87-012-195-080 C-CAP,U 100P-50 J CH GRM a

MICON O C 0422 87-012-195-080 C-CAP,U 100P-50 J CH GRM a

MICON O C 0423 87-012-195-080 C-CAP,U 100P-50 J CH GRM a

MICON O C 0424 87-012-195-080 C-CAP,U 100P-50 J CH GRM a

MICON O C 0425 87-012-195-080 C-CAP,U 100P-50 J CH GRM a

MICON O C 0426 87-012-195-080 C-CAP,U 100P-50 J CH GRM a

MICON O C 0427 87-012-195-080 C-CAP,U 100P-50 J CH GRM a

MICON O C 0428 87-012-195-080 C-CAP,U 100P-50 J CH GRM a

MICON O C 0429 87-012-195-080 C-CAP,U 100P-50 J CH GRM a

MICON O C 0430 87-012-195-080 C-CAP,U 100P-50 J CH GRM a

MICON ! O CN 0401 87-099-202-010 CONN,9P H BLK 6216 a

MICON ! O CN 0404 87-099-029-010 CONN,12P H BLK 6216 a

MICON ! O CN 0407 87-099-033-010 CONN,16P H BLK 6216 a

MICON ! O CNA0401 88-805-083-690 CONN ASSY,8P V WHT 360 MM a

MICON S D 0051 87-020-465-080 DIODE,1SS133 a

MICON S D 0052 87-020-465-080 DIODE,1SS133 a

MICON S D 0053 87-020-465-080 DIODE,1SS133 a

MICON S D 0054 87-020-465-080 DIODE,1SS133 a

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

! = ! SAFTY PARTS

C = Components marked

All components used on this model at the production line are shown in this service manual.

However, please note that not all components will be available as spare parts for after-sales service.

Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.

Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL

-11-

ELECTRICALPARTSLIST-9/28

AV-NW30

UBC

MICON S D 0055 87-020-465-080 DIODE,1SS133 a

MICON S D 0056 87-020-465-080 DIODE,1SS133 a

MICON S D 0057 87-020-465-080 DIODE,1SS133 a

MICON S D 0110 87-020-465-080 DIODE,1SS133 a

MICON S D 0201 87-A40-748-080 ZENER,UZ5.6BSA a

MICON S D 0202 87-020-465-080 DIODE,1SS133 a

MICON S D 0203 87-020-465-080 DIODE,1SS133 a

MICON S D 0211 87-020-465-080 DIODE,1SS133 a

MICON O FL 0101 8C-AR6-601-010 FL,HNA-11SM25 CAR-6 a

MICON S IC 0101 8C-AR6-602-030 C-IC,UPD780228GF-090 a

MICON S IC 0102 87-A21-831-010 IC,SPS-442-1-F1 a

MICON X JR 0101 88-108-000-080 C-JUMPER,U a

MICON X JR 0102 88-108-000-080 C-JUMPER,U a

MICON X JR 0103 88-108-000-080 C-JUMPER,U a

MICON X JR 0104 88-108-000-080 C-JUMPER,U a

MICON X JR 0105 88-108-000-080 C-JUMPER,U a

MICON X JR 0106 88-108-000-080 C-JUMPER,U a

MICON X JR 0401 88-108-000-080 C-JUMPER,U a

MICON X JR 0402 88-108-000-080 C-JUMPER,U a

MICON X JR 0403 88-108-000-080 C-JUMPER,U a

AV-NW30

UBC

MICON X JW 0102 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0103 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0104 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0105 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0106 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0107 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0108 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0109 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0110 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0111 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0112 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0113 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0114 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0115 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0116 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0117 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0118 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0119 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0120 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0121 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV-NW30

UBC

MICON X JW 0122 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0123 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0124 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0125 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0126 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0127 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0128 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0129 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0130 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0131 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0132 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0133 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0134 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0135 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0136 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0137 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0138 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0139 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0140 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0141 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV-NW30

UBC

MICON X JW 0142 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0145 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0146 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0147 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0148 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0149 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0150 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0151 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0152 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0153 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0154 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0155 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0156 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0157 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0158 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0159 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0160 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0161 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0162 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0163 88-100-000-010 PLATING-JW, 0.58 SN95 a

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

! = ! SAFTY PARTS

C = Components marked

All components used on this model at the production line are shown in this service manual.

However, please note that not all components will be available as spare parts for after-sales service.

Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.

Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL

-12-

ELECTRICALPARTSLIST-10/28

AV-NW30

UBC

MICON X JW 0164 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0165 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0166 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0167 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0168 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0169 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0170 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0171 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0172 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0173 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0174 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0175 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0176 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0178 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0179 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0180 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0181 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0182 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0183 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0184 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV-NW30

UBC

MICON X JW 0185 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0186 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0187 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0188 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0189 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0190 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0191 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0192 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0193 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0197 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0199 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0206 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0401 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0402 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0407 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0408 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0409 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0410 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X JW 0411 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON O L 0101 87-A50-655-010 COIL,CLK 4.19MHZ (TOKO)7KLY a

AV-NW30

UBC

MICON S Q 0101 87-A30-538-040 C-TR,SRA2202S a

MICON S Q 0102 87-A30-071-080 C-TR,RT1N 144C a

MICON S Q 0103 87-A30-087-080 C-FET,2SK2158 a

MICON S Q 0201 87-A30-494-080 TR,2SA1980G a

MICON S Q 0202 87-A30-076-080 C-TR,2SC3052F a

MICON S Q 0203 87-A30-076-080 C-TR,2SC3052F a

MICON S Q 0204 87-A30-538-040 C-TR,SRA2202S a

MICON S Q 0211 87-A30-076-080 C-TR,2SC3052F a

MICON O R 0100 88-108-101-080 C-RES,U 100-1/16W J a

MICON O R 0101 88-108-103-080 C-RES,U 10K-1/16W J a

MICON X R 0102 88-108-104-080 C-RES,U 100K-1/16W J a

MICON X R 0103 88-108-152-080 C-RES,U 1.5K-1/16W J a

MICON X R 0104 88-108-152-080 C-RES,U 1.5K-1/16W J a

MICON X R 0105 88-108-104-080 C-RES,U 100K-1/16W J a

MICON O R 0109 88-108-103-080 C-RES,U 10K-1/16W J a

MICON O R 0110 88-108-103-080 C-RES,U 10K-1/16W J a

MICON O R 0111 88-108-103-080 C-RES,U 10K-1/16W J a

MICON O R 0112 88-108-103-080 C-RES,U 10K-1/16W J a

MICON O R 0113 88-108-103-080 C-RES,U 10K-1/16W J a

MICON O R 0114 88-108-103-080 C-RES,U 10K-1/16W J a

AV-NW30

UBC

MICON O R 0115 88-108-103-080 C-RES,U 10K-1/16W J a

MICON X R 0117 88-108-104-080 C-RES,U 100K-1/16W J a

MICON X R 0118 88-108-104-080 C-RES,U 100K-1/16W J a

MICON X R 0120 88-121-563-080 RES,56K-1/8W J a

MICON X R 0121 88-108-104-080 C-RES,U 100K-1/16W J a

MICON O R 0122 88-108-102-080 C-RES,U 1K-1/16W J a

MICON O R 0123 88-108-102-080 C-RES,U 1K-1/16W J a

MICON X R 0125 88-108-104-080 C-RES,U 100K-1/16W J a

MICON X R 0126 88-121-470-080 RES,47-1/8W J a

MICON X R 0127 88-121-101-080 RES,100-1/8W J a

MICON O R 0128 88-108-101-080 C-RES,U 100-1/16W J a

MICON X R 0129 88-108-683-080 C-RES,U 68K-1/16W J a

MICON X R 0130 88-108-104-080 C-RES,U 100K-1/16W J a

MICON X R 0131 88-108-104-080 C-RES,U 100K-1/16W J a

MICON O R 0132 88-108-103-080 C-RES,U 10K-1/16W J a

MICON O R 0133 88-108-103-080 C-RES,U 10K-1/16W J a

MICON X R 0134 88-108-104-080 C-RES,U 100K-1/16W J a

MICON O R 0135 88-108-473-080 C-RES,U 47K-1/16W J a

MICON O R 0136 88-108-473-080 C-RES,U 47K-1/16W J a

MICON O R 0137 88-108-473-080 C-RES,U 47K-1/16W J a

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

! = ! SAFTY PARTS

C = Components marked

All components used on this model at the production line are shown in this service manual.

However, please note that not all components will be available as spare parts for after-sales service.

Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.

Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL

-13-

ELECTRICALPARTSLIST-11/28

AV-NW30

UBC

MICON O R 0138 88-108-473-080 C-RES,U 47K-1/16W J a

MICON O R 0139 88-108-103-080 C-RES,U 10K-1/16W J a

MICON O R 0140 88-108-103-080 C-RES,U 10K-1/16W J a

MICON O R 0141 88-108-103-080 C-RES,U 10K-1/16W J a

MICON O R 0142 88-108-153-080 C-RES,U 15K-1/16W J a

MICON X R 0143 88-121-100-080 RES,10-1/8W J a

MICON X R 0145 88-121-223-080 RES,22K-1/8W J a

MICON X R 0146 88-121-152-080 RES,1.5K-1/8W J a

MICON X R 0147 88-121-682-080 RES,6.8K-1/8W J a

MICON X R 0148 88-121-682-080 RES,6.8K-1/8W J a

MICON X R 0149 88-121-152-080 RES,1.5K-1/8W J a

MICON X R 0150 88-121-100-080 RES,10-1/8W J a

MICON X R 0151 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X R 0155 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X R 0159 88-108-104-080 C-RES,U 100K-1/16W J a

MICON X R 0160 88-108-104-080 C-RES,U 100K-1/16W J a

MICON X R 0161 88-108-104-080 C-RES,U 100K-1/16W J a

MICON X R 0162 88-108-104-080 C-RES,U 100K-1/16W J a

MICON X R 0163 88-108-104-080 C-RES,U 100K-1/16W J a

MICON X R 0164 88-108-104-080 C-RES,U 100K-1/16W J a

AV-NW30

UBC

MICON X R 0165 88-108-104-080 C-RES,U 100K-1/16W J a

MICON X R 0166 88-108-104-080 C-RES,U 100K-1/16W J a

MICON X R 0167 88-108-104-080 C-RES,U 100K-1/16W J a

MICON X R 0168 88-108-104-080 C-RES,U 100K-1/16W J a

MICON X R 0169 88-108-104-080 C-RES,U 100K-1/16W J a

MICON X R 0170 88-108-104-080 C-RES,U 100K-1/16W J a

MICON X R 0171 88-108-104-080 C-RES,U 100K-1/16W J a

MICON X R 0172 88-108-104-080 C-RES,U 100K-1/16W J a

MICON X R 0173 88-108-104-080 C-RES,U 100K-1/16W J a

MICON X R 0174 88-108-104-080 C-RES,U 100K-1/16W J a

MICON X R 0175 88-108-104-080 C-RES,U 100K-1/16W J a

MICON X R 0176 88-108-104-080 C-RES,U 100K-1/16W J a

MICON X R 0177 88-108-104-080 C-RES,U 100K-1/16W J a

MICON X R 0178 88-108-104-080 C-RES,U 100K-1/16W J a

MICON X R 0179 88-108-104-080 C-RES,U 100K-1/16W J a

MICON X R 0180 88-108-104-080 C-RES,U 100K-1/16W J a

MICON X R 0181 88-108-104-080 C-RES,U 100K-1/16W J a

MICON X R 0182 88-108-104-080 C-RES,U 100K-1/16W J a

MICON X R 0183 88-108-104-080 C-RES,U 100K-1/16W J a

MICON X R 0184 88-108-104-080 C-RES,U 100K-1/16W J a

AV-NW30

UBC

MICON X R 0185 88-108-104-080 C-RES,U 100K-1/16W J a

MICON X R 0186 88-108-104-080 C-RES,U 100K-1/16W J a

MICON X R 0187 88-108-104-080 C-RES,U 100K-1/16W J a

MICON X R 0191 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X R 0195 88-100-000-010 PLATING-JW, 0.58 SN95 a

MICON X R 0201 88-121-124-080 RES,120K-1/8W J a

MICON X R 0202 88-121-104-080 RES,100K-1/8W J a

MICON X R 0203 88-108-472-080 C-RES,U 4.7K-1/16W J a

MICON O R 0204 88-108-153-080 C-RES,U 15K-1/16W J a

MICON O R 0205 88-108-102-080 C-RES,U 1K-1/16W J a

MICON X R 0206 88-108-471-080 C-RES,U 470-1/16W J a

MICON X R 0211 88-121-393-080 RES,39K-1/8W J a

MICON X R 0212 88-108-183-080 C-RES,U 18K-1/16W J a

MICON O R 0213 88-108-103-080 C-RES,U 10K-1/16W J a

MICON O R 0214 88-108-224-080 C-RES,U 220K-1/16W J a

MICON O R 0215 88-108-224-080 C-RES,U 220K-1/16W J a

MICON O R 0301 88-108-103-080 C-RES,U 10K-1/16W J a

MICON X R 0302 88-121-103-080 RES,10K-1/8W J a

MICON O R 0303 88-108-102-080 C-RES,U 1K-1/16W J a

MICON X R 0304 88-108-152-080 C-RES,U 1.5K-1/16W J a

AV-NW30

UBC

MICON X R 0305 88-108-152-080 C-RES,U 1.5K-1/16W J a

MICON X R 0306 88-108-222-080 C-RES,U 2.2K-1/16W J a

MICON X R 0307 88-108-222-080 C-RES,U 2.2K-1/16W J a

MICON O R 0308 88-108-332-080 C-RES,U 3.3K-1/16W J a

MICON X R 0309 88-108-472-080 C-RES,U 4.7K-1/16W J a

MICON O R 0315 88-108-102-080 C-RES,U 1K-1/16W J a

MICON X R 0331 88-108-222-080 C-RES,U 2.2K-1/16W J a

MICON O R 0332 88-108-123-080 C-RES,U 12K-1/16W J a

MICON X R 0333 88-108-273-080 C-RES,U 27K-1/16W J a

MICON X R 0334 88-108-152-080 C-RES,U 1.5K-1/16W J a

MICON O R 0335 88-108-473-080 C-RES,U 47K-1/16W J a

MICON X R 0341 88-108-222-080 C-RES,U 2.2K-1/16W J a

MICON O R 0342 88-108-123-080 C-RES,U 12K-1/16W J a

MICON X R 0343 88-108-273-080 C-RES,U 27K-1/16W J a

MICON X R 0344 88-108-152-080 C-RES,U 1.5K-1/16W J a

MICON O R 0345 88-108-473-080 C-RES,U 47K-1/16W J a

MICON O R 0346 88-108-103-080 C-RES,U 10K-1/16W J a

MICON X R 0351 88-108-222-080 C-RES,U 2.2K-1/16W J a

MICON O R 0352 88-108-123-080 C-RES,U 12K-1/16W J a

MICON X R 0353 88-108-273-080 C-RES,U 27K-1/16W J a

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

! = ! SAFTY PARTS

C = Components marked

All components used on this model at the production line are shown in this service manual.

However, please note that not all components will be available as spare parts for after-sales service.

Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.

Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL

-14-

ELECTRICALPARTSLIST-12/28

AV-NW30

UBC

MICON X R 0354 88-108-152-080 C-RES,U 1.5K-1/16W J a

MICON O R 0355 88-108-473-080 C-RES,U 47K-1/16W J a

MICON O R 0401 88-108-101-080 C-RES,U 100-1/16W J a

MICON O R 0402 88-108-101-080 C-RES,U 100-1/16W J a

MICON O R 0403 88-108-102-080 C-RES,U 1K-1/16W J a

MICON O R 0404 88-108-102-080 C-RES,U 1K-1/16W J a

MICON O R 0405 88-108-102-080 C-RES,U 1K-1/16W J a

MICON O R 0406 88-108-102-080 C-RES,U 1K-1/16W J a

MICON O R 0407 88-108-101-080 C-RES,U 100-1/16W J a

MICON O R 0409 88-108-102-080 C-RES,U 1K-1/16W J a

MICON O R 0410 88-108-102-080 C-RES,U 1K-1/16W J a

MICON O R 0411 88-108-102-080 C-RES,U 1K-1/16W J a

MICON X R 0412 88-118-102-080 C-RES,S 1K-1/10W J a

MICON O R 0413 88-108-102-080 C-RES,U 1K-1/16W J a

MICON O R 0414 88-108-102-080 C-RES,U 1K-1/16W J a

MICON O R 0415 88-108-102-080 C-RES,U 1K-1/16W J a

MICON O R 0416 88-108-102-080 C-RES,U 1K-1/16W J a

MICON O R 0421 88-108-101-080 C-RES,U 100-1/16W J a

MICON O R 0422 88-108-101-080 C-RES,U 100-1/16W J a

MICON O R 0423 88-108-101-080 C-RES,U 100-1/16W J a

AV-NW30

UBC

MICON O R 0424 88-108-101-080 C-RES,U 100-1/16W J a

MICON O R 0425 88-108-101-080 C-RES,U 100-1/16W J a

MICON O R 0426 88-108-101-080 C-RES,U 100-1/16W J a

MICON O R 0427 88-108-101-080 C-RES,U 100-1/16W J a

MICON O R 0428 88-108-101-080 C-RES,U 100-1/16W J a

MICON O R 0429 88-108-101-080 C-RES,U 100-1/16W J a

MICON O R 0430 88-108-101-080 C-RES,U 100-1/16W J a

MICON O S 0101 87-A92-410-010 SW,RTRY EC12E12F a

MICON O S 0102 87-A92-410-010 SW,RTRY EC12E12F a

MICON O S 0301 87-A90-164-080 SW,TACT SKQNAB(N) a

MICON O S 0302 87-A90-164-080 SW,TACT SKQNAB(N) a

MICON O S 0303 87-A90-164-080 SW,TACT SKQNAB(N) a

MICON O S 0304 87-A90-164-080 SW,TACT SKQNAB(N) a

MICON O S 0305 87-A90-164-080 SW,TACT SKQNAB(N) a

MICON O S 0306 87-A90-164-080 SW,TACT SKQNAB(N) a

MICON O S 0307 87-A90-164-080 SW,TACT SKQNAB(N) a

MICON O S 0313 87-A90-164-080 SW,TACT SKQNAB(N) a

MICON O S 0314 87-A90-164-080 SW,TACT SKQNAB(N) a

MICON O SW 0301 87-A92-411-010 SW,RTRY EC12E24C a

MICON O SW 0302 87-A92-409-010 SW,RTRY EC12E12E a

AV-NW30

UBC

MICON O SW 0303 87-A92-408-010 SW,RTRY EC12E24D a

POWER AMP(CENT) O C 0503 87-010-406-080 CAP,E 22-50 M 11L SME a

POWER AMP(CENT) O C 0504 87-A10-039-080 C-CAP,U 470P-50 J CH a

POWER AMP(CENT) O C 0506 87-012-274-080 C-CAP,U 1000P-50 K B GRM a

POWER AMP(CENT) O C 0507 87-012-164-080 C-CAP,U 2P-50 C CH GRM a

POWER AMP(CENT) O C 0508 87-012-278-080 C-CAP,U 2200P-50 K B GRM a

POWER AMP(CENT) O C 0509 87-012-184-080 C-CAP,U 33P-50 J CH GRM a

POWER AMP(CENT) O C 0510 87-010-406-080 CAP,E 22-50 M 11L SME a

POWER AMP(CENT) O C 0513 87-012-368-080 C-CAP,S 0.1-50 Z F GRM a

POWER AMP(CENT) O C 0519 87-012-184-080 C-CAP,U 33P-50 J CH GRM a

POWER AMP(CENT) O C 0521 87-012-368-080 C-CAP,S 0.1-50 Z F GRM a

POWER AMP(CENT) O C 0522 87-012-282-080 C-CAP,U 4700P-50 K B GRM a

POWER AMP(CENT) O C 0541 87-012-268-080 C-CAP,U 330P-50 K B GRM a

POWER AMP(CENT) O C 0542 87-012-268-080 C-CAP,U 330P-50 K B GRM a

POWER AMP(CENT) O C 0580 87-012-368-080 C-CAP,S 0.1-50 Z F GRM a

POWER AMP(CENT) O C 0581 87-012-368-080 C-CAP,S 0.1-50 Z F GRM a

POWER AMP(CENT) O C 0582 87-012-368-080 C-CAP,S 0.1-50 Z F GRM a

POWER AMP(CENT) O C 0583 87-010-190-080 C-CAP,S 0.01-50 Z F C2012 a

POWER AMP(CENT) S D 0501 87-020-465-080 DIODE,1SS133 a

POWER AMP(CENT) S D 0502 87-020-465-080 DIODE,1SS133 a

AV-NW30

UBC

POWER AMP(CENT) S D 0504 87-020-465-080 DIODE,1SS133 a

POWER AMP(CENT) S D 0505 87-020-465-080 DIODE,1SS133 a

POWER AMP(CENT) S D 0506 87-020-465-080 DIODE,1SS133 a

POWER AMP(CENT) S D 0508 87-020-465-080 DIODE,1SS133 a

POWER AMP(CENT) S D 0510 87-020-465-080 DIODE,1SS133 a

POWER AMP(CENT) S D 0511 87-020-465-080 DIODE,1SS133 a

POWER AMP(CENT) S D 0530 87-020-465-080 DIODE,1SS133 a

POWER AMP(CENT) ! O J 0300 87-A60-200-010 TERMINAL,SP 6P CJ-9033-21-3 V0 a

POWER AMP(CENT) X JR 0504 88-108-000-080 C-JUMPER,U a

POWER AMP(CENT) X JR 0511 88-118-000-080 C-JUMPER,S a

POWER AMP(CENT) X JR 0512 88-129-000-080 C-JUMPER, 3216 a

POWER AMP(CENT) X JR 0513 88-108-000-080 C-JUMPER,U a

POWER AMP(CENT) X JR 0514 88-129-000-080 C-JUMPER, 3216 a

POWER AMP(CENT) X JW 0501 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(CENT) X JW 0502 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(CENT) X JW 0503 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(CENT) X JW 0504 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(CENT) X JW 0505 88-121-223-080 RES,22K-1/8W J a

POWER AMP(CENT) X JW 0513 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(CENT) X JW 0514 88-100-000-010 PLATING-JW, 0.58 SN95 a

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

! = ! SAFTY PARTS

C = Components marked

All components used on this model at the production line are shown in this service manual.

However, please note that not all components will be available as spare parts for after-sales service.

Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.

Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL

-15-

ELECTRICALPARTSLIST-13/28

AV-NW30

UBC

POWER AMP(CENT) X JW 0515 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(CENT) X JW 0516 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(CENT) X JW 0517 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(CENT) X JW 0518 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(CENT) X JW 0519 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(CENT) X JW 0520 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(CENT) X JW 0521 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(CENT) X JW 0522 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(CENT) X JW 0523 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(CENT) X JW 0524 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(CENT) X JW 0525 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(CENT) X JW 0526 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(CENT) X JW 0527 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(CENT) X JW 0528 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(CENT) X JW 0529 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(CENT) X JW 0533 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(CENT) X JW 0535 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(CENT) X JW 0536 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(CENT) X JW 0538 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(CENT) X JW 0539 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV-NW30

UBC

POWER AMP(CENT) X JW 0540 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(CENT) X JW 0541 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(CENT) X JW 0542 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(CENT) X JW 0543 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(CENT) X JW 0544 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(CENT) X JW 0551 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(CENT) X JW 0552 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(CENT) X JW 0554 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(CENT) X JW 0555 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(CENT) X JW 0556 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(CENT) X JW 0557 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(CENT) X JW 0558 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(CENT) X JW 0559 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(CENT) X JW 0560 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(CENT) X JW 0561 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(CENT) X JW 0562 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(CENT) X JW 0563 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(CENT) X JW 0564 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(CENT) X JW 0566 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(CENT) X JW 0567 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV-NW30

UBC

POWER AMP(CENT) X JW 0568 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(CENT) X JW 0570 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(CENT) O L 0581 87-A50-611-010 COIL,1UH K(CS) a

POWER AMP(CENT) S Q 0501 87-A30-257-080 C-TR,2SD1306E a

POWER AMP(CENT) S Q 0502 87-A30-659-040 C-TR,2SC4117GR.BL a

POWER AMP(CENT) S Q 0503 87-A30-669-040 C-TR,SBT5401 a

POWER AMP(CENT) S Q 0504 87-A30-659-040 C-TR,2SC4117GR.BL a

POWER AMP(CENT) S Q 0506 87-A30-696-080 TR,2SA1145Y a

POWER AMP(CENT) S Q 0507 87-A30-492-080 TR,2SC5343G a

POWER AMP(CENT) S Q 0508 87-A30-697-080 TR,2SC2705Y a

POWER AMP(CENT) S Q 0509 87-A30-076-080 C-TR,2SC3052F a

POWER AMP(CENT) S Q 0513 87-A30-662-040 C-TR,2SD814A(RS) a

POWER AMP(CENT) S Q 0554 87-A30-663-040 C-TR,2SB792A(RS) a

POWER AMP(CENT) S Q 0555 87-A30-538-040 C-TR,SRA2202S a

POWER AMP(CENT) S Q 0581 87-026-216-080 TR,DTA124ES a

POWER AMP(CENT) X R 0418 88-108-472-080 C-RES,U 4.7K-1/16W J a

POWER AMP(CENT) O R 0419 88-108-103-080 C-RES,U 10K-1/16W J a

POWER AMP(CENT) X R 0501 88-108-222-080 C-RES,U 2.2K-1/16W J a

POWER AMP(CENT) O R 0503 88-108-223-080 C-RES,U 22K-1/16W J a

POWER AMP(CENT) O R 0504 88-108-103-080 C-RES,U 10K-1/16W J a

AV-NW30

UBC

POWER AMP(CENT) X R 0505 88-108-333-080 C-RES,U 33K-1/16W J a

POWER AMP(CENT) O R 0506 88-108-101-080 C-RES,U 100-1/16W J a

POWER AMP(CENT) O R 0507 88-108-101-080 C-RES,U 100-1/16W J a

POWER AMP(CENT) X R 0508 88-108-821-080 C-RES,U 820-1/16W J a

POWER AMP(CENT) X R 0509 88-108-000-080 C-JUMPER,U a

POWER AMP(CENT) X R 0510 88-108-000-080 C-JUMPER,U a

POWER AMP(CENT) X R 0511 88-108-122-080 C-RES,U 1.2K-1/16W J a

POWER AMP(CENT) X R 0512 88-108-222-080 C-RES,U 2.2K-1/16W J a

POWER AMP(CENT) X R 0513 88-108-560-080 C-RES,U 56-1/16W J a

POWER AMP(CENT) O R 0514 88-108-101-080 C-RES,U 100-1/16W J a

POWER AMP(CENT) X R 0517 88-118-682-080 C-RES,S 6.8K-1/10W J a

POWER AMP(CENT) X R 0519 88-118-222-080 C-RES,S 2.2K-1/10W J a

POWER AMP(CENT) X R 0520 88-118-683-080 C-RES,S 68K-1/10W J a

POWER AMP(CENT) X R 0521 88-108-393-080 C-RES,U 39K-1/16W J a

POWER AMP(CENT) X R 0522 88-108-000-080 C-JUMPER,U a

POWER AMP(CENT) X R 0523 88-108-000-080 C-JUMPER,U a

POWER AMP(CENT) X R 0524 88-108-122-080 C-RES,U 1.2K-1/16W J a

POWER AMP(CENT) X R 0525 88-108-122-080 C-RES,U 1.2K-1/16W J a

POWER AMP(CENT) O R 0526 88-108-332-080 C-RES,U 3.3K-1/16W J a

POWER AMP(CENT) O R 0527 87-A00-764-010 RES,M/F 0.22-3W J a

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

! = ! SAFTY PARTS

C = Components marked

All components used on this model at the production line are shown in this service manual.

However, please note that not all components will be available as spare parts for after-sales service.

Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.

Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL

-16-

ELECTRICALPARTSLIST-14/28

AV-NW30

UBC

POWER AMP(CENT) O R 0528 87-A00-764-010 RES,M/F 0.22-3W J a

POWER AMP(CENT) X R 0531 88-108-392-080 C-RES,U 3.9K-1/16W J a

POWER AMP(CENT) X R 0532 88-108-472-080 C-RES,U 4.7K-1/16W J a

POWER AMP(CENT) X R 0533 88-108-333-080 C-RES,U 33K-1/16W J a

POWER AMP(CENT) X R 0534 88-128-333-080 C-RES, 33K-1/8W J a

POWER AMP(CENT) O R 0535 88-108-123-080 C-RES,U 12K-1/16W J a

POWER AMP(CENT) X R 0536 88-118-220-080 C-RES,S 22-1/10W J a

POWER AMP(CENT) O R 0541 88-108-332-080 C-RES,U 3.3K-1/16W J a

POWER AMP(CENT) O R 0542 88-108-332-080 C-RES,U 3.3K-1/16W J a

POWER AMP(CENT) O R 0543 88-108-103-080 C-RES,U 10K-1/16W J a

POWER AMP(CENT) O R 0544 88-108-103-080 C-RES,U 10K-1/16W J a

POWER AMP(CENT) O R 0545 88-108-563-080 C-RES,U 56K-1/16W J a

POWER AMP(CENT) X R 0559 88-108-182-080 C-RES,U 1.8K-1/16W J a

POWER AMP(CENT) X R 0560 88-128-473-080 C-RES, 47K-1/8W J a

POWER AMP(CENT) X R 0581 88-128-153-080 C-RES, 15K-1/8W J a

POWER AMP(CENT) X R 0582 88-128-153-080 C-RES, 15K-1/8W J a

POWER AMP(CENT) X R 0583 88-121-100-080 RES,10-1/8W J a

POWER AMP(CENT) X R 0584 88-128-100-080 C-RES, 10-1/8W J a

POWER AMP(CENT) X R 0585 88-108-182-080 C-RES,U 1.8K-1/16W J a

POWER AMP(CENT) X R 0586 88-108-222-080 C-RES,U 2.2K-1/16W J a

AV-NW30

UBC

POWER AMP(CENT) X R 0589 88-108-151-080 C-RES,U 150-1/16W J a

POWER AMP(CENT) X R 0591 88-108-000-080 C-JUMPER,U a

POWER AMP(CENT) X R 0592 88-108-000-080 C-JUMPER,U a

POWER AMP(CENT) X R 0593 88-128-682-080 C-RES, 6.8K-1/8W J a

POWER AMP(CENT) O TH 0501 87-A91-042-080 C-THMS,100K 55001 a

POWER AMP(FR) O C 0105 87-010-406-080 CAP,E 22-50 M 11L SME a

POWER AMP(FR) O C 0106 87-010-406-080 CAP,E 22-50 M 11L SME a

POWER AMP(FR) O C 0107 87-A10-039-080 C-CAP,U 470P-50 J CH a

POWER AMP(FR) O C 0108 87-A10-039-080 C-CAP,U 470P-50 J CH a

POWER AMP(FR) O C 0113 87-012-274-080 C-CAP,U 1000P-50 K B GRM a

POWER AMP(FR) O C 0114 87-012-274-080 C-CAP,U 1000P-50 K B GRM a

POWER AMP(FR) O C 0115 87-010-406-080 CAP,E 22-50 M 11L SME a

POWER AMP(FR) O C 0116 87-010-406-080 CAP,E 22-50 M 11L SME a

POWER AMP(FR) O C 0117 87-012-164-080 C-CAP,U 2P-50 C CH GRM a

POWER AMP(FR) O C 0118 87-012-164-080 C-CAP,U 2P-50 C CH GRM a

POWER AMP(FR) O C 0119 87-012-278-080 C-CAP,U 2200P-50 K B GRM a

POWER AMP(FR) O C 0120 87-012-278-080 C-CAP,U 2200P-50 K B GRM a

POWER AMP(FR) O C 0121 87-012-184-080 C-CAP,U 33P-50 J CH GRM a

POWER AMP(FR) O C 0122 87-012-184-080 C-CAP,U 33P-50 J CH GRM a

POWER AMP(FR) O C 0129 87-012-184-080 C-CAP,U 33P-50 J CH GRM a

AV-NW30

UBC

POWER AMP(FR) O C 0130 87-012-184-080 C-CAP,U 33P-50 J CH GRM a

POWER AMP(FR) O C 0133 87-012-368-080 C-CAP,S 0.1-50 Z F GRM a

POWER AMP(FR) O C 0134 87-012-368-080 C-CAP,S 0.1-50 Z F GRM a

POWER AMP(FR) O C 0141 87-012-368-080 C-CAP,S 0.1-50 Z F GRM a

POWER AMP(FR) O C 0142 87-012-368-080 C-CAP,S 0.1-50 Z F GRM a

POWER AMP(FR) O C 0143 87-012-282-080 C-CAP,U 4700P-50 K B GRM a

POWER AMP(FR) O C 0144 87-012-282-080 C-CAP,U 4700P-50 K B GRM a

POWER AMP(FR) O C 0201 87-010-246-080 CAP,E 47-35 M 11L SME a

POWER AMP(FR) O C 0202 87-010-246-080 CAP,E 47-35 M 11L SME a

POWER AMP(FR) O C 0203 87-010-195-080 C-CAP,S 0.068-25 Z F C2012 a

POWER AMP(FR) O C 0204 87-012-180-080 C-CAP,U 22P-50 J CH GRM a

POWER AMP(FR) O C 0205 87-A10-417-080 CAP,E 47-63 SME a

POWER AMP(FR) O C 0206 87-A10-417-080 CAP,E 47-63 SME a

POWER AMP(FR) O C 0207 87-A10-039-080 C-CAP,U 470P-50 J CH a

POWER AMP(FR) O C 0208 87-A10-039-080 C-CAP,U 470P-50 J CH a

POWER AMP(FR) O C 0211 87-010-427-080 C-CAP,S 0.039-25 Z F GRM a

POWER AMP(FR) O C 0217 87-012-195-080 C-CAP,U 100P-50 J CH GRM a

POWER AMP(FR) O C 0231 87-012-268-080 C-CAP,U 330P-50 K B GRM a

POWER AMP(FR) O C 0232 87-012-268-080 C-CAP,U 330P-50 K B GRM a

POWER AMP(FR) O C 0233 87-012-268-080 C-CAP,U 330P-50 K B GRM a

AV-NW30

UBC

POWER AMP(FR) O C 0234 87-012-268-080 C-CAP,U 330P-50 K B GRM a

POWER AMP(FR) O C 0251 87-016-460-080 C-CAP,S 0.22-16 K B C2012 a

POWER AMP(FR) O C 0252 87-016-460-080 C-CAP,S 0.22-16 K B C2012 a

POWER AMP(FR) O C 0261 87-012-282-080 C-CAP,U 4700P-50 K B GRM a

POWER AMP(FR) O C 0271 87-012-368-080 C-CAP,S 0.1-50 Z F GRM a

POWER AMP(FR) O C 0272 87-012-368-080 C-CAP,S 0.1-50 Z F GRM a

POWER AMP(FR) O C 0273 87-012-368-080 C-CAP,S 0.1-50 Z F GRM a

POWER AMP(FR) O C 0274 87-012-368-080 C-CAP,S 0.1-50 Z F GRM a

POWER AMP(FR) O C 0275 87-010-190-080 C-CAP,S 0.01-50 Z F C2012 a

POWER AMP(FR) O C 0276 87-010-190-080 C-CAP,S 0.01-50 Z F C2012 a

POWER AMP(FR) O C 0277 87-012-368-080 C-CAP,S 0.1-50 Z F GRM a

POWER AMP(FR) O C 0278 87-012-368-080 C-CAP,S 0.1-50 Z F GRM a

POWER AMP(FR) O CNA0201 8C-AR6-635-010 CONN ASSY,5P - 2/3P SDN a

POWER AMP(FR) S D 0101 87-020-465-080 DIODE,1SS133 a

POWER AMP(FR) S D 0102 87-020-465-080 DIODE,1SS133 a

POWER AMP(FR) S D 0103 87-020-465-080 DIODE,1SS133 a

POWER AMP(FR) S D 0104 87-020-465-080 DIODE,1SS133 a

POWER AMP(FR) S D 0105 87-020-465-080 DIODE,1SS133 a

POWER AMP(FR) S D 0106 87-020-465-080 DIODE,1SS133 a

POWER AMP(FR) S D 0111 87-020-465-080 DIODE,1SS133 a

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

! = ! SAFTY PARTS

C = Components marked

All components used on this model at the production line are shown in this service manual.

However, please note that not all components will be available as spare parts for after-sales service.

Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.

Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL

-17-

ELECTRICALPARTSLIST-15/28

AV-NW30

UBC

POWER AMP(FR) S D 0112 87-020-465-080 DIODE,1SS133 a

POWER AMP(FR) S D 0113 87-020-465-080 DIODE,1SS133 a

POWER AMP(FR) S D 0114 87-020-465-080 DIODE,1SS133 a

POWER AMP(FR) S D 0115 87-020-465-080 DIODE,1SS133 a

POWER AMP(FR) S D 0116 87-020-465-080 DIODE,1SS133 a

POWER AMP(FR) S D 0121 87-020-465-080 DIODE,1SS133 a

POWER AMP(FR) S D 0122 87-020-465-080 DIODE,1SS133 a

POWER AMP(FR) S D 0123 87-020-465-080 DIODE,1SS133 a

POWER AMP(FR) S D 0124 87-020-465-080 DIODE,1SS133 a

POWER AMP(FR) S D 0201 87-A40-646-010 DIODE,FMB-G16L a

POWER AMP(FR) S D 0202 87-A40-646-010 DIODE,FMB-G16L a

POWER AMP(FR) S D 0203 87-A40-770-080 ZENER,UZ20BSA a

POWER AMP(FR) S D 0204 87-020-465-080 DIODE,1SS133 a

POWER AMP(FR) S D 0205 87-020-465-080 DIODE,1SS133 a

POWER AMP(FR) S D 0206 87-020-465-080 DIODE,1SS133 a

POWER AMP(FR) S D 0207 87-020-465-080 DIODE,1SS133 a

POWER AMP(FR) S D 0208 87-020-465-080 DIODE,1SS133 a

POWER AMP(FR) S D 0209 87-020-465-080 DIODE,1SS133 a

POWER AMP(FR) S D 0210 87-020-465-080 DIODE,1SS133 a

POWER AMP(FR) S D 0211 87-A40-768-080 ZENER,UZ16BSA a

AV-NW30

UBC

POWER AMP(FR) S D 0231 87-020-465-080 DIODE,1SS133 a

POWER AMP(FR) S D 0232 87-020-465-080 DIODE,1SS133 a

POWER AMP(FR) S D 0233 87-020-465-080 DIODE,1SS133 a

POWER AMP(FR) S D 0234 87-020-465-080 DIODE,1SS133 a

POWER AMP(FR) S D 0261 87-020-465-080 DIODE,1SS133 a

POWER AMP(FR) S D 0281 87-020-465-080 DIODE,1SS133 a

POWER AMP(FR) ! O J 0201 87-A61-859-010 TERMINAL,SP 4P MSP-324V1-03( X a

POWER AMP(FR) X JR 0111 88-108-000-080 C-JUMPER,U a

POWER AMP(FR) X JR 0113 88-108-000-080 C-JUMPER,U a

POWER AMP(FR) X JR 0211 88-118-000-080 C-JUMPER,S a

POWER AMP(FR) X JW 0101 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0102 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0103 88-121-223-080 RES,22K-1/8W J a

POWER AMP(FR) X JW 0104 88-121-223-080 RES,22K-1/8W J a

POWER AMP(FR) X JW 0105 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0106 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0113 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0114 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0115 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0116 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV-NW30

UBC

POWER AMP(FR) X JW 0117 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0118 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0119 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0120 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0121 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0122 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0123 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0124 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0125 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0126 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0127 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0128 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0129 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0130 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0131 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0132 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0133 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0134 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0135 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0136 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV-NW30

UBC

POWER AMP(FR) X JW 0137 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0138 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0139 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0140 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0141 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0142 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0144 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0146 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0147 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0149 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0151 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0152 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0153 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0154 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0155 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0156 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0158 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0159 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0161 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0162 88-100-000-010 PLATING-JW, 0.58 SN95 a

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

! = ! SAFTY PARTS

C = Components marked

All components used on this model at the production line are shown in this service manual.

However, please note that not all components will be available as spare parts for after-sales service.

Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.

Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL

-18-

ELECTRICALPARTSLIST-16/28

AV-NW30

UBC

POWER AMP(FR) X JW 0163 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0164 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0165 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0167 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0168 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0181 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0183 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0185 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0187 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0211 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0212 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0213 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0214 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0215 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0216 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0217 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0218 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0219 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0221 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0223 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV-NW30

UBC

POWER AMP(FR) X JW 0225 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0226 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0227 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0228 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0229 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0230 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0231 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0232 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0251 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0252 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0253 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0254 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0255 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0256 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0257 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0258 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) X JW 0259 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) O L 0211 87-A50-611-010 COIL,1UH K(CS) a

POWER AMP(FR) O L 0212 87-A50-611-010 COIL,1UH K(CS) a

POWER AMP(FR) X PR 0201 88-100-000-010 PLATING-JW, 0.58 SN95 a

AV-NW30

UBC

POWER AMP(FR) X PR 0202 88-100-000-010 PLATING-JW, 0.58 SN95 a

POWER AMP(FR) S Q 0101 87-A30-257-080 C-TR,2SD1306E a

POWER AMP(FR) S Q 0102 87-A30-257-080 C-TR,2SD1306E a

POWER AMP(FR) S Q 0103 87-A30-659-040 C-TR,2SC4117GR.BL a

POWER AMP(FR) S Q 0104 87-A30-659-040 C-TR,2SC4117GR.BL a

POWER AMP(FR) S Q 0105 87-A30-669-040 C-TR,SBT5401 a

POWER AMP(FR) S Q 0106 87-A30-669-040 C-TR,SBT5401 a

POWER AMP(FR) S Q 0107 87-A30-659-040 C-TR,2SC4117GR.BL a

POWER AMP(FR) S Q 0108 87-A30-659-040 C-TR,2SC4117GR.BL a

POWER AMP(FR) S Q 0111 87-A30-696-080 TR,2SA1145Y a

POWER AMP(FR) S Q 0112 87-A30-696-080 TR,2SA1145Y a

POWER AMP(FR) S Q 0113 87-A30-076-080 C-TR,2SC3052F a

POWER AMP(FR) S Q 0114 87-A30-076-080 C-TR,2SC3052F a

POWER AMP(FR) S Q 0115 87-A30-697-080 TR,2SC2705Y a

POWER AMP(FR) S Q 0116 87-A30-697-080 TR,2SC2705Y a

POWER AMP(FR) S Q 0117 87-A30-492-080 TR,2SC5343G a

POWER AMP(FR) S Q 0118 87-A30-492-080 TR,2SC5343G a

POWER AMP(FR) S Q 0125 87-A30-662-040 C-TR,2SD814A(RS) a

POWER AMP(FR) S Q 0126 87-A30-662-040 C-TR,2SD814A(RS) a

POWER AMP(FR) S Q 0191 87-A30-663-040 C-TR,2SB792A(RS) a

AV-NW30

UBC

POWER AMP(FR) S Q 0192 87-A30-538-040 C-TR,SRA2202S a

POWER AMP(FR) S Q 0201 87-A30-186-010 FET,2SK3053 a

POWER AMP(FR) S Q 0202 87-A30-186-010 FET,2SK3053 a

POWER AMP(FR) S Q 0203 87-A30-076-080 C-TR,2SC3052F a

POWER AMP(FR) S Q 0204 87-A30-075-080 C-TR,2SA1235F a

POWER AMP(FR) S Q 0205 87-A30-076-080 C-TR,2SC3052F a

POWER AMP(FR) S Q 0206 87-A30-075-080 C-TR,2SA1235F a

POWER AMP(FR) S Q 0207 87-A30-076-080 C-TR,2SC3052F a

POWER AMP(FR) S Q 0208 87-A30-075-080 C-TR,2SA1235F a

POWER AMP(FR) S Q 0210 87-A30-075-080 C-TR,2SA1235F a

POWER AMP(FR) S Q 0251 87-A30-663-040 C-TR,2SB792A(RS) a

POWER AMP(FR) S Q 0252 87-A30-663-040 C-TR,2SB792A(RS) a

POWER AMP(FR) S Q 0253 87-A30-662-040 C-TR,2SD814A(RS) a

POWER AMP(FR) S Q 0261 87-A30-268-040 C-TR,2SA1514K(S) a

POWER AMP(FR) S Q 0262 87-A30-662-040 C-TR,2SD814A(RS) a

POWER AMP(FR) S Q 0281 87-A30-494-080 TR,2SA1980G a

POWER AMP(FR) S Q 0291 87-A30-075-080 C-TR,2SA1235F a

POWER AMP(FR) X R 0101 88-108-222-080 C-RES,U 2.2K-1/16W J a

POWER AMP(FR) X R 0102 88-108-222-080 C-RES,U 2.2K-1/16W J a

POWER AMP(FR) O R 0105 88-108-223-080 C-RES,U 22K-1/16W J a

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

! = ! SAFTY PARTS

C = Components marked

All components used on this model at the production line are shown in this service manual.

However, please note that not all components will be available as spare parts for after-sales service.

Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.

Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL

-19-

ELECTRICALPARTSLIST-17/28

AV-NW30

UBC

POWER AMP(FR) O R 0106 88-108-223-080 C-RES,U 22K-1/16W J a

POWER AMP(FR) O R 0107 88-108-101-080 C-RES,U 100-1/16W J a

POWER AMP(FR) O R 0108 88-108-101-080 C-RES,U 100-1/16W J a

POWER AMP(FR) X R 0109 88-108-393-080 C-RES,U 39K-1/16W J a

POWER AMP(FR) X R 0110 88-108-393-080 C-RES,U 39K-1/16W J a

POWER AMP(FR) O R 0111 88-108-101-080 C-RES,U 100-1/16W J a

POWER AMP(FR) O R 0112 88-108-101-080 C-RES,U 100-1/16W J a

POWER AMP(FR) O R 0113 88-108-101-080 C-RES,U 100-1/16W J a

POWER AMP(FR) O R 0114 88-108-101-080 C-RES,U 100-1/16W J a

POWER AMP(FR) X R 0115 88-108-821-080 C-RES,U 820-1/16W J a

POWER AMP(FR) X R 0116 88-108-821-080 C-RES,U 820-1/16W J a

POWER AMP(FR) X R 0117 88-108-000-080 C-JUMPER,U a

POWER AMP(FR) X R 0118 88-108-000-080 C-JUMPER,U a

POWER AMP(FR) X R 0119 88-108-000-080 C-JUMPER,U a

POWER AMP(FR) X R 0120 88-108-000-080 C-JUMPER,U a

POWER AMP(FR) X R 0121 88-108-122-080 C-RES,U 1.2K-1/16W J a

POWER AMP(FR) X R 0122 88-108-122-080 C-RES,U 1.2K-1/16W J a

POWER AMP(FR) X R 0123 88-118-560-080 C-RES,S 56-1/10W J a

POWER AMP(FR) X R 0124 88-118-560-080 C-RES,S 56-1/10W J a

POWER AMP(FR) X R 0125 88-108-222-080 C-RES,U 2.2K-1/16W J a

AV-NW30

UBC

POWER AMP(FR) X R 0126 88-108-222-080 C-RES,U 2.2K-1/16W J a

POWER AMP(FR) X R 0127 88-118-101-080 C-RES,S 100-1/10W J a

POWER AMP(FR) X R 0128 88-118-101-080 C-RES,S 100-1/10W J a

POWER AMP(FR) X R 0129 88-108-000-080 C-JUMPER,U a

POWER AMP(FR) X R 0130 88-108-000-080 C-JUMPER,U a

POWER AMP(FR) X R 0131 88-108-222-080 C-RES,U 2.2K-1/16W J a

POWER AMP(FR) X R 0132 88-108-222-080 C-RES,U 2.2K-1/16W J a

POWER AMP(FR) X R 0133 88-108-393-080 C-RES,U 39K-1/16W J a

POWER AMP(FR) X R 0134 88-108-393-080 C-RES,U 39K-1/16W J a

POWER AMP(FR) X R 0135 88-108-000-080 C-JUMPER,U a

POWER AMP(FR) X R 0136 88-108-000-080 C-JUMPER,U a

POWER AMP(FR) X R 0137 88-108-000-080 C-JUMPER,U a

POWER AMP(FR) X R 0138 88-108-000-080 C-JUMPER,U a

POWER AMP(FR) X R 0139 88-118-332-080 C-RES,S 3.3K-1/10W J a

POWER AMP(FR) X R 0140 88-118-332-080 C-RES,S 3.3K-1/10W J a

POWER AMP(FR) X R 0141 88-108-000-080 C-JUMPER,U a

POWER AMP(FR) X R 0142 88-108-000-080 C-JUMPER,U a

POWER AMP(FR) X R 0143 88-108-000-080 C-JUMPER,U a

POWER AMP(FR) X R 0144 88-108-000-080 C-JUMPER,U a

POWER AMP(FR) O R 0145 87-A00-764-010 RES,M/F 0.22-3W J a

AV-NW30

UBC

POWER AMP(FR) O R 0146 87-A00-764-010 RES,M/F 0.22-3W J a

POWER AMP(FR) O R 0147 87-A00-764-010 RES,M/F 0.22-3W J a

POWER AMP(FR) O R 0148 87-A00-764-010 RES,M/F 0.22-3W J a

POWER AMP(FR) X R 0149 88-118-272-080 C-RES,S 2.7K-1/10W J a

POWER AMP(FR) X R 0150 88-118-272-080 C-RES,S 2.7K-1/10W J a

POWER AMP(FR) X R 0153 88-108-392-080 C-RES,U 3.9K-1/16W J a

POWER AMP(FR) X R 0154 88-108-392-080 C-RES,U 3.9K-1/16W J a

POWER AMP(FR) X R 0155 88-108-472-080 C-RES,U 4.7K-1/16W J a

POWER AMP(FR) X R 0156 88-108-472-080 C-RES,U 4.7K-1/16W J a

POWER AMP(FR) X R 0157 88-108-333-080 C-RES,U 33K-1/16W J a

POWER AMP(FR) X R 0158 88-108-333-080 C-RES,U 33K-1/16W J a

POWER AMP(FR) O R 0159 88-108-123-080 C-RES,U 12K-1/16W J a

POWER AMP(FR) O R 0160 88-108-123-080 C-RES,U 12K-1/16W J a

POWER AMP(FR) X R 0161 88-108-220-080 C-RES,U 22-1/16W J a

POWER AMP(FR) X R 0162 88-108-220-080 C-RES,U 22-1/16W J a

POWER AMP(FR) X R 0163 88-128-333-080 C-RES, 33K-1/8W J a

POWER AMP(FR) X R 0164 88-128-333-080 C-RES, 33K-1/8W J a

POWER AMP(FR) X R 0165 88-118-563-080 C-RES,S 56K-1/10W J a

POWER AMP(FR) X R 0166 88-128-563-080 C-RES, 56K-1/8W J a

POWER AMP(FR) X R 0167 88-121-683-080 RES,68K-1/8W J a

AV-NW30

UBC

POWER AMP(FR) X R 0168 88-121-683-080 RES,68K-1/8W J a

POWER AMP(FR) X R 0169 88-108-182-080 C-RES,U 1.8K-1/16W J a

POWER AMP(FR) X R 0170 88-108-182-080 C-RES,U 1.8K-1/16W J a

POWER AMP(FR) X R 0179 88-108-151-080 C-RES,U 150-1/16W J a

POWER AMP(FR) X R 0180 88-108-151-080 C-RES,U 150-1/16W J a

POWER AMP(FR) O R 0181 87-A00-879-050 RES,M/F 270-1W J a

POWER AMP(FR) O R 0182 87-A00-879-050 RES,M/F 270-1W J a

POWER AMP(FR) O R 0183 87-A00-878-050 RES,M/F 220-1W J a

POWER AMP(FR) O R 0184 87-A00-878-050 RES,M/F 220-1W J a

POWER AMP(FR) X R 0189 88-108-122-080 C-RES,U 1.2K-1/16W J a

POWER AMP(FR) X R 0190 88-108-122-080 C-RES,U 1.2K-1/16W J a

POWER AMP(FR) X R 0191 88-108-821-080 C-RES,U 820-1/16W J a

POWER AMP(FR) X R 0192 88-128-473-080 C-RES, 47K-1/8W J a

POWER AMP(FR) O R 0193 88-108-332-080 C-RES,U 3.3K-1/16W J a

POWER AMP(FR) O R 0194 88-108-332-080 C-RES,U 3.3K-1/16W J a

POWER AMP(FR) X R 0203 88-108-472-080 C-RES,U 4.7K-1/16W J a

POWER AMP(FR) O R 0204 88-108-123-080 C-RES,U 12K-1/16W J a

POWER AMP(FR) O R 0205 88-108-272-080 C-RES,U 2.7K-1/16W J a

POWER AMP(FR) O R 0206 88-108-473-080 C-RES,U 47K-1/16W J a

POWER AMP(FR) O R 0207 88-108-103-080 C-RES,U 10K-1/16W J a

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

! = ! SAFTY PARTS

C = Components marked

All components used on this model at the production line are shown in this service manual.

However, please note that not all components will be available as spare parts for after-sales service.

Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.

Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL

-20-

ELECTRICALPARTSLIST-18/28

AV-NW30

UBC

POWER AMP(FR) X R 0208 88-108-331-080 C-RES,U 330-1/16W J a

POWER AMP(FR) X R 0209 88-108-121-080 C-RES,U 120-1/16W J a

POWER AMP(FR) O R 0210 88-108-272-080 C-RES,U 2.7K-1/16W J a

POWER AMP(FR) X R 0211 88-108-222-080 C-RES,U 2.2K-1/16W J a

POWER AMP(FR) O R 0212 88-108-103-080 C-RES,U 10K-1/16W J a

POWER AMP(FR) X R 0213 88-108-152-080 C-RES,U 1.5K-1/16W J a

POWER AMP(FR) X R 0214 88-108-333-080 C-RES,U 33K-1/16W J a

POWER AMP(FR) O R 0215 88-108-103-080 C-RES,U 10K-1/16W J a

POWER AMP(FR) O R 0216 88-108-562-080 C-RES,U 5.6K-1/16W J a

POWER AMP(FR) X R 0217 88-108-472-080 C-RES,U 4.7K-1/16W J a

POWER AMP(FR) X R 0218 88-108-472-080 C-RES,U 4.7K-1/16W J a

POWER AMP(FR) O R 0219 88-108-103-080 C-RES,U 10K-1/16W J a

POWER AMP(FR) X R 0220 88-128-332-080 C-RES, 3.3K-1/8W J a

POWER AMP(FR) X R 0222 88-118-271-080 C-RES,S 270-1/10W J a

POWER AMP(FR) X R 0224 88-108-222-080 C-RES,U 2.2K-1/16W J a

POWER AMP(FR) O R 0226 88-108-103-080 C-RES,U 10K-1/16W J a

POWER AMP(FR) O R 0228 88-108-332-080 C-RES,U 3.3K-1/16W J a

POWER AMP(FR) X R 0229 88-108-682-080 C-RES,U 6.8K-1/16W J a

POWER AMP(FR) O R 0230 88-108-153-080 C-RES,U 15K-1/16W J a

POWER AMP(FR) O R 0231 88-108-332-080 C-RES,U 3.3K-1/16W J a

AV-NW30

UBC

POWER AMP(FR) O R 0232 88-108-332-080 C-RES,U 3.3K-1/16W J a

POWER AMP(FR) O R 0233 88-108-103-080 C-RES,U 10K-1/16W J a

POWER AMP(FR) O R 0234 88-108-103-080 C-RES,U 10K-1/16W J a

POWER AMP(FR) O R 0235 88-108-332-080 C-RES,U 3.3K-1/16W J a

POWER AMP(FR) O R 0236 88-108-332-080 C-RES,U 3.3K-1/16W J a

POWER AMP(FR) O R 0237 88-108-103-080 C-RES,U 10K-1/16W J a

POWER AMP(FR) O R 0238 88-108-103-080 C-RES,U 10K-1/16W J a

POWER AMP(FR) O R 0241 88-108-332-080 C-RES,U 3.3K-1/16W J a

POWER AMP(FR) O R 0242 88-108-332-080 C-RES,U 3.3K-1/16W J a

POWER AMP(FR) O R 0243 88-108-332-080 C-RES,U 3.3K-1/16W J a

POWER AMP(FR) O R 0244 88-108-332-080 C-RES,U 3.3K-1/16W J a

POWER AMP(FR) X R 0245 88-108-682-080 C-RES,U 6.8K-1/16W J a

POWER AMP(FR) X R 0246 88-108-222-080 C-RES,U 2.2K-1/16W J a

POWER AMP(FR) O R 0247 88-108-103-080 C-RES,U 10K-1/16W J a

POWER AMP(FR) X R 0248 88-128-472-080 C-RES, 4.7K-1/8W J a

POWER AMP(FR) X R 0249 88-128-472-080 C-RES, 4.7K-1/8W J a

POWER AMP(FR) X R 0251 88-108-472-080 C-RES,U 4.7K-1/16W J a

POWER AMP(FR) X R 0252 88-108-472-080 C-RES,U 4.7K-1/16W J a

POWER AMP(FR) X R 0253 88-128-473-080 C-RES, 47K-1/8W J a

POWER AMP(FR) O R 0254 88-108-102-080 C-RES,U 1K-1/16W J a

AV-NW30

UBC

POWER AMP(FR) X R 0255 88-128-473-080 C-RES, 47K-1/8W J a

POWER AMP(FR) O R 0261 88-108-103-080 C-RES,U 10K-1/16W J a

POWER AMP(FR) O R 0262 88-108-103-080 C-RES,U 10K-1/16W J a

POWER AMP(FR) X R 0263 88-128-473-080 C-RES, 47K-1/8W J a

POWER AMP(FR) O R 0264 88-108-103-080 C-RES,U 10K-1/16W J a

POWER AMP(FR) X R 0275 88-128-100-080 C-RES, 10-1/8W J a

POWER AMP(FR) X R 0276 88-128-100-080 C-RES, 10-1/8W J a

POWER AMP(FR) X R 0277 88-128-100-080 C-RES, 10-1/8W J a

POWER AMP(FR) X R 0278 88-128-100-080 C-RES, 10-1/8W J a

POWER AMP(FR) X R 0281 88-128-220-080 C-RES, 22-1/8W J a

POWER AMP(FR) X R 0282 88-128-180-080 C-RES, 18-1/8W J a

POWER AMP(FR) X R 0283 88-128-180-080 C-RES, 18-1/8W J a

POWER AMP(FR) X R 0284 88-108-273-080 C-RES,U 27K-1/16W J a

POWER AMP(FR) X R 0291 88-108-683-080 C-RES,U 68K-1/16W J a

POWER AMP(FR) X R 0292 88-108-105-080 C-RES,U 1M-1/16W J a

POWER AMP(FR) O R 0293 88-108-103-080 C-RES,U 10K-1/16W J a

POWER AMP(FR) O R 0294 88-108-102-080 C-RES,U 1K-1/16W J a

POWER AMP(FR) X R 0295 88-128-153-080 C-RES, 15K-1/8W J a

POWER AMP(FR) X R 0296 88-128-153-080 C-RES, 15K-1/8W J a

POWER AMP(FR) X R 0297 88-128-153-080 C-RES, 15K-1/8W J a

AV-NW30

UBC

POWER AMP(FR) X R 0298 88-128-153-080 C-RES, 15K-1/8W J a

POWER AMP(FR) ! O RY 0201 87-A91-686-010 RELAY, G5PA-28(OMRON) a

POWER AMP(FR) O TH 0101 87-A91-042-080 C-THMS,100K 55001 a

POWER AMP(FR) O TH 0102 87-A91-042-080 C-THMS,100K 55001 a

POWER AMP(SURROUND) O C 0305 87-010-406-080 CAP,E 22-50 M 11L SME a

POWER AMP(SURROUND) O C 0306 87-010-406-080 CAP,E 22-50 M 11L SME a

POWER AMP(SURROUND) O C 0307 87-A10-039-080 C-CAP,U 470P-50 J CH a

POWER AMP(SURROUND) O C 0308 87-A10-039-080 C-CAP,U 470P-50 J CH a

POWER AMP(SURROUND) O C 0313 87-012-274-080 C-CAP,U 1000P-50 K B GRM a

POWER AMP(SURROUND) O C 0314 87-012-274-080 C-CAP,U 1000P-50 K B GRM a

POWER AMP(SURROUND) O C 0315 87-010-406-080 CAP,E 22-50 M 11L SME a

POWER AMP(SURROUND) O C 0316 87-010-406-080 CAP,E 22-50 M 11L SME a

POWER AMP(SURROUND) O C 0317 87-012-164-080 C-CAP,U 2P-50 C CH GRM a

POWER AMP(SURROUND) O C 0318 87-012-164-080 C-CAP,U 2P-50 C CH GRM a

POWER AMP(SURROUND) O C 0319 87-012-278-080 C-CAP,U 2200P-50 K B GRM a

POWER AMP(SURROUND) O C 0320 87-012-278-080 C-CAP,U 2200P-50 K B GRM a

POWER AMP(SURROUND) O C 0321 87-012-184-080 C-CAP,U 33P-50 J CH GRM a

POWER AMP(SURROUND) O C 0322 87-012-184-080 C-CAP,U 33P-50 J CH GRM a

POWER AMP(SURROUND) O C 0329 87-012-184-080 C-CAP,U 33P-50 J CH GRM a

POWER AMP(SURROUND) O C 0330 87-012-184-080 C-CAP,U 33P-50 J CH GRM a

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

Other manuals for AV-NW30, AV-NW31

Table of contents

Popular Stereo Receiver manuals by other brands

Denon

Denon AVR-1508 owner's manual

Nakamichi

Nakamichi NA3605 user manual

Sony

Sony STR-LV700R Service manual

Pyle

Pyle PT590AU owner's manual

Pioneer

Pioneer AVH-A7250BT owner's manual

Kenwood

Kenwood KR-A50 instruction manual

Denon

Denon AVR-3600 Brochure & specs

Pyle

Pyle PT270AIU user manual

Denon

Denon AVR-E400P Getting started

Yamaha

Yamaha RX-V485 quick start guide

Block

Block VR 100 instruction manual

Denon

Denon AVR-X5200W Service manual

Pioneer

Pioneer DMH-G225BT quick start guide

Planet Audio

Planet Audio PGR45B user manual

Kenwood

Kenwood VRS-6100 instruction manual

Fisher

Fisher 4020 Service manual

Pioneer

Pioneer DVH-860AV/XEUW5 Service manual

Yamaha

Yamaha RX-950 owner's manual

Aiwa AV-NW30, AV-NW31 Building instructions

Popular Stereo Receiver manuals by other brands
