SERVICE MANUAL
DATA
NSX-DST717 U
SIMPLE
S/M Code No. 09-006-432-7T1
• Replace this Service manual with “Revision Publishing” when it is issued.
COMPACT DISC
STEREO CASSETTE RECEIVER BASIC CD MECHANISM: 6ZG-1 ZRNDM BASIC TAPE MECHANISM: 2ZM-3MK2 PR4NM

NOTE: The characters in the suffix column indicate the part usage.
U ......................XX..................................A...................
KANRI
RE .NO PARTS NO. NO. DESCRIPTION SU IX
C 603 87-010-112-040 CAP,E 100-16 A...................
C 602 87-010-186-080 CAP,CHIP 4700P A...................
C 601 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 606 87-010-320-080 CHIP CAP 68P A...................
C 604 87-010-405-040 CAP,E 10-50 A...................
C 605 87-010-546-040 CAP,E 0.33-50 A...................
C 608 87-012-157-080 C-CAP,S 330P-50 CH A...................
C 621 87-010-178-080 CHIP CAP 1000P A...................
CN 602 87-A60-082-010 CONN,05P H 9604S-05 A...................
B 601 87-003-098-080 COIL,2.2UH A...................
J 601 87-A61-242-010 JACK,6.3 BLK MONO W/SW V KM A...................
J 602 87-A61-242-010 JACK,6.3 BLK MONO W/SW V KM A...................
* 8A-N 3-204-010 GUIDE,LED-CASS A...................
C 161 87-010-178-080 CHIP CAP 1000P A...................
C 162 87-012-156-080 C-CAP,S 220P-50 CH A...................
C 401 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 407 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 410 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 417 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 424 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 423 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 501 87-010-178-080 CHIP CAP 1000P A...................
C 502 87-012-156-080 C-CAP,S 220P-50 CH A...................
C 532 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 531 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
CN 104 87-099-018-010 CONN,16P A...................
CN 302 87-A60-059-010 CONN,08P V 9604S-08C A...................
IC 402 87-A21-021-040 C-IC,BU2099 V A...................
IC 401 87-A21-021-040 C-IC,BU2099 V A...................
LED 101 87-A40-317-080 LED,SLR-342VCT31 RED A...................
LED 421 87-A40-831-010 LED,SELU1E10CXM-L 70 BLUE-DE A...................
LED 422 87-A40-831-010 LED,SELU1E10CXM-L 70 BLUE-DE A...................
LED 446 87-A40-380-180 LED,SEL6510C-TP5 GRN A...................
LED 447 87-A40-380-180 LED,SEL6510C-TP5 GRN A...................
LED 445 87-A40-380-180 LED,SEL6510C-TP5 GRN A...................
LED 441 87-A40-380-180 LED,SEL6510C-TP5 GRN A...................
LED 444 87-A40-380-180 LED,SEL6510C-TP5 GRN A...................
LED 449 87-A40-380-180 LED,SEL6510C-TP5 GRN A...................
LED 442 87-A40-380-180 LED,SEL6510C-TP5 GRN A...................
LED 443 87-A40-380-180 LED,SEL6510C-TP5 GRN A...................
LED 448 87-A40-380-180 LED,SEL6510C-TP5 GRN A...................
LED 440 87-A40-380-180 LED,SEL6510C-TP5 GRN A...................
LED 452 87-A40-809-040 LED,LTL-307KK PGRN A...................
LED 455 87-A40-809-040 LED,LTL-307KK PGRN A...................
LED 453 87-A40-809-040 LED,LTL-307KK PGRN A...................
LED 456 87-A40-809-040 LED,LTL-307KK PGRN A...................
LED 451 87-A40-809-040 LED,LTL-307KK PGRN A...................
LED 454 87-A40-809-040 LED,LTL-307KK PGRN A...................
LED 464 87-A40-317-080 LED,SLR-342VCT31 RED A...................
LED 465 87-A40-317-080 LED,SLR-342VCT31 RED A...................
LED 462 87-A40-317-080 LED,SLR-342VCT31 RED A...................
LED 463 87-A40-317-080 LED,SLR-342VCT31 RED A...................
LED 461 87-A40-317-080 LED,SLR-342VCT31 RED A...................
LED 521 87-A40-678-010 LED,SELU1E10CXM BLUE-DE A...................
LED 522 87-A40-678-010 LED,SELU1E10CXM BLUE-DE A...................
S 208 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 204 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 203 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 205 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 206 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 201 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 202 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 207 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 217 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 216 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 211 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 214 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 229 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 225 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 228 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 222 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 221 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 224 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 223 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 233 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 230 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 232 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 231 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 249 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 244 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 243 87-A90-095-080 SW,TACT EVQ11G04M A...................
ELECTRICAL MAIN PARTS LIST - 1/11

S 248 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 242 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 246 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 241 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 247 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 245 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 250 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 251 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 511 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 515 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 514 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 513 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 512 87-A90-095-080 SW,TACT EVQ11G04M A...................
SW 101 87-A91-740-010 SW,RTRY EC12E24308-30MM A...................
SW 501 87-A91-739-010 SW,RTRY EC12E12404-25MM RT A...................
87-067-703-010 TAPPING SCREW, BVT2+3-10 A...................
C 1 87-010-387-080 CAP,E 470-25 SME A...................
C 6 87-010-917-000 CAP,E 3300-50 M SMG A...................
C 7 87-010-917-000 CAP,E 3300-50 M SMG A...................
C 5 87-A11-148-080 CAP,TC U 0.1-50 Z A...................
C 8 87-A11-148-080 CAP,TC U 0.1-50 Z A...................
C 9 87-A11-148-080 CAP,TC U 0.1-50 Z A...................
C 4 87-A11-148-080 CAP,TC U 0.1-50 Z A...................
C 16 87-010-403-040 CAP,E 3.3-50 SME A...................
C 12 87-010-917-000 CAP,E 3300-50 M SMG A...................
C 13 87-010-917-000 CAP,E 3300-50 M SMG A...................
C 18 87-A11-148-080 CAP,TC U 0.1-50 Z A...................
C 11 87-A11-148-080 CAP,TC U 0.1-50 Z A...................
C 19 87-A11-148-080 CAP,TC U 0.1-50 Z A...................
C 10 87-A11-148-080 CAP,TC U 0.1-50 Z A...................
C 23 87-A10-231-090 CAP,E 3300-80 A...................
C 22 87-A10-231-090 CAP,E 3300-80 A...................
C 25 87-A11-148-080 CAP,TC U 0.1-50 Z A...................
C 28 87-A11-148-080 CAP,TC U 0.1-50 Z A...................
C 21 87-A11-148-080 CAP,TC U 0.1-50 Z A...................
C 27 87-A11-148-080 CAP,TC U 0.1-50 Z A...................
C 29 87-A11-148-080 CAP,TC U 0.1-50 Z A...................
C 24 87-A11-148-080 CAP,TC U 0.1-50 Z A...................
C 20 87-A11-148-080 CAP,TC U 0.1-50 Z A...................
C 31 87-A11-148-080 CAP,TC U 0.1-50 Z A...................
C 38 87-A11-148-080 CAP,TC U 0.1-50 Z A...................
C 36 87-A11-148-080 CAP,TC U 0.1-50 Z A...................
C 37 87-A11-148-080 CAP,TC U 0.1-50 Z A...................
C 32 87-A11-148-080 CAP,TC U 0.1-50 Z A...................
C 30 87-A11-148-080 CAP,TC U 0.1-50 Z A...................
C 35 87-A11-148-080 CAP,TC U 0.1-50 Z A...................
C 34 87-A11-148-080 CAP,TC U 0.1-50 Z A...................
C 33 87-A11-148-080 CAP,TC U 0.1-50 Z A...................
CN 2 87-A61-109-010 CONN,7P V TID-A A...................
CN 1 87-A61-110-010 CONN,9P V TID-A A...................
D 1 87-017-447-010 DIODE,GBU4DL A...................
D 3 87-017-654-060 DIODE,GBU6J A...................
D 2 87-A40-224-010 DIODE,GBU8D A...................
C 2 87-033-213-080 CLAMP, USE A...................
C 1 87-033-213-080 CLAMP, USE A...................
PR 2 87-026-691-080 USE,10A 125V 251 A...................
PR 1 87-026-691-080 USE,10A 125V 251 A...................
PR 8 87-026-691-080 USE,10A 125V 251 A...................
PR 7 87-026-691-080 USE,10A 125V 251 A...................
PR 4 87-A90-210-080 USE,7A 125V 251 A...................
PR 6 87-A90-210-080 USE,7A 125V 251 A...................
PR 5 87-A90-210-080 USE,7A 125V 251 A...................
PR 3 87-A90-210-080 USE,7A 125V 251 A...................
PT 2 8A-N 8-661-010 PT,SUB AN -8 (U) A...................
Q 1 87-026-245-080 TR,DTC114ES A...................
Q 2 87-A30-198-080 TR,KTC3199GR A...................
RY 1 87-A90-976-010 RELAY,AC12V SDT-S-112LMR A...................
T 1 87-A60-317-010 TERMINAL, 1P MSC A...................
T 2 87-A60-317-010 TERMINAL, 1P MSC A...................
87-067-703-010 TAPPING SCREW, BVT2+3-10 A...................
* 8A-N 3-215-010 HLDR,TR A...................
* 8A-N 3-217-110 HLDR,TR-SW A...................
C 102 87-010-183-080 C-CAP,S 2700P-50 B A...................
C 101 87-010-183-080 C-CAP,S 2700P-50 B A...................
C 105 87-010-186-080 CAP,CHIP 4700P A...................
C 106 87-010-186-080 CAP,CHIP 4700P A...................
C 103 87-010-405-080 CAP, ELECT 10-50V A...................
C 104 87-010-405-080 CAP, ELECT 10-50V A...................
C 108 87-010-406-080 CAP, ELECT 22-50 A...................
C 107 87-010-406-080 CAP, ELECT 22-50 A...................
C 119 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 111 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 112 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 114 87-A10-812-080 C-CAP,S 220P-200 J CH A...................
C 113 87-A10-812-080 C-CAP,S 220P-200 J CH A...................
C 120 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 121 87-010-260-080 CAP, ELECT 47-25V A...................
ELECTRICAL MAIN PARTS LIST - 2/11

C 122 87-010-260-080 CAP, ELECT 47-25V A...................
C 174 87-010-186-080 CAP,CHIP 4700P A...................
C 173 87-010-186-080 CAP,CHIP 4700P A...................
C 249 87-012-368-080 C-CAP,S 0.1-50 A...................
C 402 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 413 87-A10-119-080 CAP,E 10-100 REA A...................
C 414 87-A10-119-080 CAP,E 10-100 REA A...................
CNA 101 8A-N 8-652-010 CONN ASSY,7P TID-A(480) A...................
CNA 102 8A-N 8-655-010 CONN ASSY,7P TID-A(150) A...................
CON 103 87-A60-058-010 CONN,10P V 9604S-10C A...................
CON 101 87-A61-011-010 CONN,13P H BLK TAC-L13P-A3 A...................
CON 102 87-A61-011-010 CONN,13P H BLK TAC-L13P-A3 A...................
D 103 87-A40-313-080 C-DIODE,MC 2840 A...................
D 113 87-020-331-080 CHIP-DIODE,DAN202K A...................
D 117 87-A40-488-080 DIODE,1SS244 A...................
D 118 87-A40-488-080 DIODE,1SS244 A...................
D 419 87-A40-747-080 ZENER,UZ5.1BSB A...................
D 418 87-A40-751-080 ZENER,UZ6.2BSB A...................
D 417 87-A40-764-080 ZENER,UZ10BSC A...................
D 422 87-A40-646-010 DIODE, MB-G16L A...................
D 421 87-A40-646-010 DIODE, MB-G16L A...................
D 428 87-A40-764-080 ZENER,UZ10BSC A...................
Q 119 87-A30-190-080 TR,CC5551 A...................
Q 120 87-A30-190-080 TR,CC5551 A...................
Q 131 87-A30-204-010 TR,2SD2439 A...................
Q 132 87-A30-204-010 TR,2SD2439 A...................
Q 134 87-A30-205-010 TR,2SB1588 A...................
Q 133 87-A30-205-010 TR,2SB1588 A...................
Q 172 87-A30-106-040 C-TR,CMBT5551 A...................
Q 406 87-A30-186-010 ET,2SK3053 A...................
Q 405 87-A30-186-010 ET,2SK3053 A...................
Q 403 87-A30-484-080 C-TR,KRA102S A...................
Q 401 87-A30-484-080 C-TR,KRA102S A...................
R 166 87-A00-418-010 RES,M/ 0.15-3W J A...................
R 162 87-A00-418-010 RES,M/ 0.15-3W J A...................
R 165 87-A00-418-010 RES,M/ 0.15-3W J A...................
R 161 87-A00-418-010 RES,M/ 0.15-3W J A...................
RY 201 87-A91-686-010 RELAY, G5PA-28(OMRON) A...................
TH 102 87-A91-042-080 C-THMS,100K 55001 A...................
TH 101 87-A91-042-080 C-THMS,100K 55001 A...................
WH 102 87-A90-460-010 HLDR,WIRE 2.5-7P A...................
WH 101 87-A90-460-010 HLDR,WIRE 2.5-7P A...................
* 8A-N 3-222-010 HLDR,TR-2 A...................
C 102 87-010-178-080 CHIP CAP 1000P A...................
C 101 87-010-178-080 CHIP CAP 1000P A...................
C 107 87-010-405-080 CAP, ELECT 10-50V A...................
C 103 87-010-405-080 CAP, ELECT 10-50V A...................
C 108 87-010-405-080 CAP, ELECT 10-50V A...................
C 104 87-010-405-080 CAP, ELECT 10-50V A...................
C 112 87-010-176-080 C-CAP,S 680P-50 SL A...................
C 111 87-010-176-080 C-CAP,S 680P-50 SL A...................
C 118 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 119 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 114 87-010-260-080 CAP, ELECT 47-25V A...................
C 113 87-010-260-080 CAP, ELECT 47-25V A...................
C 116 87-010-405-080 CAP, ELECT 10-50V A...................
C 115 87-010-405-080 CAP, ELECT 10-50V A...................
C 121 87-010-190-080 S CHIP 0.01 A...................
C 122 87-010-190-080 S CHIP 0.01 A...................
C 155 87-010-190-080 S CHIP 0.01 A...................
C 157 87-010-190-080 S CHIP 0.01 A...................
C 156 87-010-190-080 S CHIP 0.01 A...................
C 152 87-012-368-080 C-CAP,S 0.1-50 A...................
C 151 87-012-368-080 C-CAP,S 0.1-50 A...................
C 153 87-A11-595-080 C-CAP,S 0.056-50 K B A...................
C 154 87-A11-595-080 C-CAP,S 0.056-50 K B A...................
C 160 87-010-186-080 CAP,CHIP 4700P A...................
C 161 87-010-186-080 CAP,CHIP 4700P A...................
C 201 87-010-186-080 CAP,CHIP 4700P A...................
C 208 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 202 87-010-258-080 CAP,E 22-35 SME A...................
C 209 87-010-260-080 CAP, ELECT 47-25V A...................
C 205 87-010-260-080 CAP, ELECT 47-25V A...................
C 203 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 206 87-012-156-080 C-CAP,S 220P-50 CH A...................
C 204 87-015-685-080 CAP,E 10-25 7L A...................
C 210 87-010-260-080 CAP, ELECT 47-25V A...................
C 258 87-010-178-080 CHIP CAP 1000P A...................
C 251 87-012-368-080 C-CAP,S 0.1-50 A...................
C 253 87-A11-595-080 C-CAP,S 0.056-50 K B A...................
C 252 87-A11-595-080 C-CAP,S 0.056-50 K B A...................
CN 102 87-A60-135-010 CONN,10P V E A...................
CN 101 87-A61-109-010 CONN,7P V TID-A A...................
D 101 87-A40-269-080 C-DIODE,MC2836 A...................
D 103 87-A40-313-080 C-DIODE,MC 2840 A...................
D 160 87-A40-270-080 C-DIODE,MC2838 A...................
D 209 87-A40-455-080 DIODE,RL203 GW A...................
ELECTRICAL MAIN PARTS LIST - 3/11

D 204 87-A40-488-080 DIODE,1SS244 A...................
D 214 87-A40-313-080 C-DIODE,MC 2840 A...................
D 210 87-A40-455-080 DIODE,RL203 GW A...................
D 211 87-A40-749-080 ZENER,UZ5.6BSB A...................
D 212 87-A40-749-080 ZENER,UZ5.6BSB A...................
IC 101 87-A21-397-010 IC,STK490-070 A...................
J 101 87-A61-159-010 JACK,PIN 4P R/W/B/0 KM A...................
L 151 87-A50-610-010 COIL,1UH K(MDEC) A...................
L 152 87-A50-610-010 COIL,1UH K(MDEC) A...................
L 251 87-A50-610-010 COIL,1UH K(MDEC) A...................
Q 161 87-A30-106-080 C-TR,CMBT5551 A...................
Q 206 87-A30-190-080 TR,CC5551 A...................
Q 209 87-A30-256-010 TR,2SD1933 A...................
Q 213 87-A30-107-070 C-TR,CMBT5401 A...................
Q 212 87-A30-255-010 TR,2SB1342 A...................
Q 210 87-A30-255-010 TR,2SB1342 A...................
Q 211 87-A30-256-010 TR,2SD1933 A...................
Q 214 87-A30-484-080 C-TR,KRA102S A...................
R 132 87-A00-258-080 RES,M/ 0.22-1W J A...................
R 131 87-A00-258-080 RES,M/ 0.22-1W J A...................
R 171 87-A00-258-080 RES,M/ 0.22-1W J A...................
R 172 87-A00-258-080 RES,M/ 0.22-1W J A...................
R 218 87-A00-257-080 RES,M/ 0.15-1W J A...................
R 278 87-A00-257-080 RES,M/ 0.15-1W J A...................
TH 201 87-A91-042-080 C-THMS,100K 55001 A...................
* 8Z-N 3-210-010 GUIDE, L A...................
C 103 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 104 87-010-313-080 CAP, CHIP 18P A...................
C 105 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 109 87-010-401-040 CAP,E 1-50 SME A...................
C 106 87-012-145-080 CAP, CHIP S 270P CH A...................
C 107 87-012-157-080 C-CAP,S 330P-50 CH A...................
C 108 87-015-681-040 E/CAP 10-16 A...................
C 118 87-010-194-080 CAP, CHIP 0.047 A...................
C 114 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 110 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 115 87-010-198-080 CAP, CHIP 0.022 A...................
C 116 87-010-493-040 CAP,E 0.47-50 GAS A...................
C 117 87-010-498-040 CAP,E 10-16 GAS A...................
C 112 87-016-460-080 C-CAP,S 0.22-16 B A...................
C 113 87-A10-189-040 CAP,E 220-10 A...................
C 119 87-A10-797-040 CAP,E 47-35 M 5L SRM A...................
C 128 87-010-178-080 CHIP CAP 1000P A...................
C 123 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 125 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 122 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 121 87-015-699-040 CAP,E 10-50 7L A...................
C 120 87-015-699-040 CAP,E 10-50 7L A...................
C 131 87-A10-189-040 CAP,E 220-10 A...................
C 132 87-A10-189-040 CAP,E 220-10 A...................
C 151 87-010-194-080 CAP, CHIP 0.047 A...................
C 196 87-010-194-080 CAP, CHIP 0.047 A...................
C 197 87-010-194-080 CAP, CHIP 0.047 A...................
C 192 87-015-785-080 CHIP CAPACITOR, 0.1 Z-25Z A...................
C 213 87-A10-189-040 CAP,E 220-10 A...................
C 306 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 305 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 301 87-010-318-080 C-CAP,S 47P-50 CH A...................
C 303 87-016-460-080 C-CAP,S 0.22-16 B A...................
C 304 87-016-460-080 C-CAP,S 0.22-16 B A...................
C 310 87-010-067-040 CAP,E 0.1-50 5L A...................
C 701 87-010-981-040 CAP,E 22-35 5L SRE A...................
C 903 87-010-176-080 C-CAP,S 680P-50 SL A...................
C 902 87-010-176-080 C-CAP,S 680P-50 SL A...................
C 906 87-010-176-080 C-CAP,S 680P-50 SL A...................
C 909 87-010-176-080 C-CAP,S 680P-50 SL A...................
C 904 87-010-176-080 C-CAP,S 680P-50 SL A...................
C 907 87-010-176-080 C-CAP,S 680P-50 SL A...................
C 908 87-010-176-080 C-CAP,S 680P-50 SL A...................
C 905 87-010-176-080 C-CAP,S 680P-50 SL A...................
C 901 87-012-157-080 C-CAP,S 330P-50 CH A...................
C 911 87-010-176-080 C-CAP,S 680P-50 SL A...................
C 912 87-010-176-080 C-CAP,S 680P-50 SL A...................
C 910 87-010-176-080 C-CAP,S 680P-50 SL A...................
C 913 87-010-176-080 C-CAP,S 680P-50 SL A...................
C 914 87-012-145-080 CAP, CHIP S 270P CH A...................
C 991 87-010-322-080 C-CAP,S 100P-50 CH A...................
CN 103 87-099-018-010 CONN,16P A...................
CN 101 87-099-720-010 CONN,30P TYK-B(P) A...................
CN 102 87-A60-054-010 CONN,14P V 9604S-14C A...................
CN 301 87-A60-079-010 CONN,08P H 9604S-08 A...................
CN 401 87-A60-057-010 CONN,11P V 9604S-11C A...................
CN 601 87-A60-062-010 CONN,05P V 9604S-05C A...................
CN 701 87-099-750-010 CONN,15P V 9604SC A...................
D 109 87-017-154-080 ZENER,HZS6C3L A...................
D 103 87-020-465-080 DIODE,1SS133 (110MA) A...................
D 310 87-A40-747-080 ZENER,UZ5.1BSB A...................
ELECTRICAL MAIN PARTS LIST - 4/11

L 101 8A-N E-613-010 L,BJ784GK-AN 14 A...................
IC 102 87-A21-482-010 IC,RPM6938-H4 A...................
IC 101 8A-N E-635-010 C-IC,LC876596W-**** A...................
IC 380 87-A21-577-040 C-IC,M61506 P A...................
IC 403 87-A21-021-040 C-IC,BU2099 V A...................
JW 316 87-A90-896-080 -BEAD, 035600STY7 A...................
JW 315 87-A90-896-080 -BEAD, 035600STY7 A...................
L 101 87-A50-333-010 COIL,OSC 9.43MHZ A...................
LED 313 87-A40-380-180 LED,SEL6510C-TP5 GRN A...................
LED 315 87-A40-380-180 LED,SEL6510C-TP5 GRN A...................
LED 312 87-A40-380-180 LED,SEL6510C-TP5 GRN A...................
LED 314 87-A40-380-180 LED,SEL6510C-TP5 GRN A...................
LED 311 87-A40-380-180 LED,SEL6510C-TP5 GRN A...................
Q 102 87-A30-076-080 C-TR,2SC3052 A...................
Q 108 87-A30-468-080 C-TR,KRC102S-RTK A...................
Q 112 87-A30-074-080 C-TR,RT1P 141C A...................
Q 111 87-A30-074-080 C-TR,RT1P 141C A...................
Q 301 87-A30-276-040 C-TR,DTA143EKA A...................
Q 702 87-A30-318-080 TR,CSA952K A...................
Q 703 87-A30-318-080 TR,CSA952K A...................
Q 701 87-A30-329-080 TR,CD1585BC A...................
S 317 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 315 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 316 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 314 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 313 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 312 87-A90-095-080 SW,TACT EVQ11G04M A...................
S 311 87-A90-095-080 SW,TACT EVQ11G04M A...................
C 307 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 301 87-010-318-080 C-CAP,S 47P-50 CH A...................
C 302 87-010-318-080 C-CAP,S 47P-50 CH A...................
C 305 87-012-157-080 C-CAP,S 330P-50 CH A...................
C 306 87-012-157-080 C-CAP,S 330P-50 CH A...................
C 303 87-012-157-080 C-CAP,S 330P-50 CH A...................
C 304 87-012-157-080 C-CAP,S 330P-50 CH A...................
C 315 87-010-178-080 CHIP CAP 1000P A...................
C 316 87-010-178-080 CHIP CAP 1000P A...................
C 314 87-010-180-080 C-CER 1500P A...................
C 313 87-010-180-080 C-CER 1500P A...................
C 311 87-010-198-080 CAP, CHIP 0.022 A...................
C 312 87-010-198-080 CAP, CHIP 0.022 A...................
C 319 87-012-141-080 CHIP-CAPACITOR,0.22-16 A...................
C 318 87-A10-201-080 C-CAP,S0.33-16 KB A...................
C 317 87-A10-201-080 C-CAP,S0.33-16 KB A...................
C 324 87-010-260-080 CAP, ELECT 47-25V A...................
C 325 87-010-370-080 CAP,E 330-6.3 SME A...................
C 327 87-010-404-080 CAP, ELECT 4.7-50V A...................
C 328 87-010-404-080 CAP, ELECT 4.7-50V A...................
C 320 87-012-141-080 CHIP-CAPACITOR,0.22-16 A...................
C 321 87-012-141-080 CHIP-CAPACITOR,0.22-16 A...................
C 322 87-012-141-080 CHIP-CAPACITOR,0.22-16 A...................
C 332 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 339 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 337 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 335 87-010-401-080 CAP, ELECT 1-50V A...................
C 336 87-010-401-080 CAP, ELECT 1-50V A...................
C 340 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 354 87-010-175-080 CAP 560P A...................
C 358 87-010-183-080 C-CAP,S 2700P-50 B A...................
C 359 87-010-183-080 C-CAP,S 2700P-50 B A...................
C 357 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 356 87-010-260-080 CAP, ELECT 47-25V A...................
C 352 87-012-140-080 CAP 470P A...................
C 351 87-012-140-080 CAP 470P A...................
C 355 87-012-349-080 C-CAP,S 1000P-50 CH A...................
C 360 87-010-183-080 C-CAP,S 2700P-50 B A...................
C 372 87-010-175-080 CAP 560P A...................
C 371 87-010-175-080 CAP 560P A...................
C 373 87-010-179-080 CAP,CHIP S B1200P A...................
C 374 87-010-179-080 CAP,CHIP S B1200P A...................
C 370 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 378 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 376 87-010-545-080 CAP, ELECT 0.22-50V A...................
C 375 87-010-545-080 CAP, ELECT 0.22-50V A...................
C 385 87-010-184-080 CHIP CAPACITOR 3300P(K) A...................
C 386 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 383 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 381 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 382 87-010-318-080 C-CAP,S 47P-50 CH A...................
C 384 87-010-402-080 CAP, ELECT 2.2-50V A...................
C 388 87-012-156-080 C-CAP,S 220P-50 CH A...................
CN 301 87-A60-620-010 CONN,3P V 2MM JMT A...................
CN 351 87-A60-625-010 CONN,8P V 2MM JMT A...................
IC 302 87-A20-355-010 IC,CXA1553P A...................
IC 303 87-A20-783-040 C-IC,BA7762A S A...................
L 302 87-A50-625-010 COIL,TRAP 85KHZ (SANWA) A...................
L 301 87-A50-625-010 COIL,TRAP 85KHZ (SANWA) A...................
ELECTRICAL MAIN PARTS LIST - 5/11

L 351 87-007-342-010 COIL,OSC 85K BIAS A...................
Q 357 87-026-609-080 TR,KTA1266GR A...................
Q 355 87-A30-063-080 C-TR,KRA104S A...................
Q 354 87-A30-087-080 C- ET,2SK2158 A...................
S R 302 87-024-355-080 S R,33K DIA6 H A...................
S R 301 87-024-355-080 S R,33K DIA6 H A...................
S R 304 87-024-355-080 S R,33K DIA6 H A...................
S R 303 87-024-355-080 S R,33K DIA6 H A...................
S R 306 87-024-356-080 S R,47K DIA6 H A...................
S R 305 87-024-356-080 S R,47K DIA6 H A...................
S R 352 87-024-356-080 S R,47K DIA6 H A...................
S R 351 87-024-356-080 S R,47K DIA6 H A...................
C 121 87-010-401-080 CAP, ELECT 1-50V A...................
C 122 87-010-401-080 CAP, ELECT 1-50V A...................
C 152 87-010-260-080 CAP, ELECT 47-25V A...................
C 163 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 177 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 178 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 174 87-012-368-080 C-CAP,S 0.1-50 A...................
C 173 87-012-368-080 C-CAP,S 0.1-50 A...................
C 172 87-012-368-080 C-CAP,S 0.1-50 A...................
C 171 87-012-368-080 C-CAP,S 0.1-50 A...................
C 176 87-A11-572-080 C-CAP,S 0.015-50 K B A...................
C 175 87-A11-572-080 C-CAP,S 0.015-50 K B A...................
C 489 87-010-402-080 CAP, ELECT 2.2-50V A...................
C 491 87-010-402-080 CAP, ELECT 2.2-50V A...................
C 492 87-010-402-080 CAP, ELECT 2.2-50V A...................
CN 101 87-A60-996-010 CONN,13P V BLK TAC-L13X-A3 A...................
J 102 87-A60-238-010 TERMINAL,SP 4P (MSC) A...................
J 103 87-A60-483-010 JACK,DIA6.3 BLK ST W/S KM A...................
Q 114 87-A30-105-080 C-TR,RT1P 441C A...................
Q 403 87-A30-202-080 C-TR,RT1P441C A...................
Q 413 87-A30-202-080 C-TR,RT1P441C A...................
R 161 87-A00-443-050 RES,390-1/2W J RP A...................
R 164 87-A00-443-050 RES,390-1/2W J RP A...................
R 163 87-A00-443-050 RES,390-1/2W J RP A...................
R 162 87-A00-443-050 RES,390-1/2W J RP A...................
C 973 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 974 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 979 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 971 87-010-381-080 CAP, ELECT 330-16V A...................
C 972 87-010-404-080 CAP, ELECT 4.7-50V A...................
C 982 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 983 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 987 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 984 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 981 87-010-260-080 CAP, ELECT 47-25V A...................
C 995 87-010-178-080 CHIP CAP 1000P A...................
C 993 87-010-178-080 CHIP CAP 1000P A...................
C 997 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 998 87-010-260-080 CAP, ELECT 47-25V A...................
C 992 87-010-312-080 C-CAP,S 15P-50 CH A...................
C 991 87-010-312-080 C-CAP,S 15P-50 CH A...................
C 999 87-A11-155-080 CAP,TC U 0.01-16 Z A...................
D 991 87-017-149-080 ZENER,HZS6A2L A...................
IC 991 87-070-127-110 IC,LC72131 D A...................
Q 981 87-A30-234-080 TR,CSC4115BC A...................
R 993 87-010-322-080 C-CAP,S 100P-50 CH A...................
R 991 87-010-322-080 C-CAP,S 100P-50 CH A...................
R 995 87-010-322-080 C-CAP,S 100P-50 CH A...................
X 991 87-A70-061-010 VIB,XTAL 4.500MHZ CSA-309 A...................
C 774 87-010-184-080 CHIP CAPACITOR 3300P(K) A...................
C 773 87-010-184-080 CHIP CAPACITOR 3300P(K) A...................
C 772 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 771 87-010-263-080 CAP, ELECT 100-10V A...................
C 788 87-010-149-080 C-CAP,S 5P-50 CH A...................
C 784 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 782 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 783 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 786 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 785 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 789 87-012-365-080 C-CAP,S 0.027-25VBK A...................
C 791 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 795 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 796 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 792 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 798 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 793 87-010-404-080 CAP, ELECT 4.7-50V A...................
C 797 87-010-405-080 CAP, ELECT 10-50V A...................
C 799 87-010-407-080 CAP, ELECT 33-50V A...................
C 790 87-012-365-080 C-CAP,S 0.027-25VBK A...................
C 803 87-010-198-080 CAP, CHIP 0.022 A...................
C 804 87-010-263-080 CAP, ELECT 100-10V A...................
C 807 87-010-400-080 CAP, ELECT 0.47-50V A...................
C 809 87-010-401-080 CAP, ELECT 1-50V A...................
C 808 87-010-401-080 CAP, ELECT 1-50V A...................
C 801 87-010-403-080 CAP, ELECT 3.3-50V A...................
ELECTRICAL MAIN PARTS LIST - 6/11

C 802 87-012-369-080 C-CAP,S 0.047-50 A...................
C 800 87-012-369-080 C-CAP,S 0.047-50 A...................
C 819 87-010-179-080 CAP,CHIP S B1200P A...................
C 810 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 814 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 816 87-010-400-080 CAP, ELECT 0.47-50V A...................
C 815 87-010-400-080 CAP, ELECT 0.47-50V A...................
C 811 87-010-403-080 CAP, ELECT 3.3-50V A...................
C 812 87-010-403-080 CAP, ELECT 3.3-50V A...................
C 823 87-010-177-080 C-CAP,S 820P-50 SL A...................
C 820 87-010-179-080 CAP,CHIP S B1200P A...................
C 821 87-010-405-080 CAP, ELECT 10-50V A...................
C 824 87-010-405-080 CAP, ELECT 10-50V A...................
C 825 87-010-596-080 CAP, S 0.047-16 A...................
IC 801 87-A21-560-010 IC,LA1844L-A A...................
L 801 87-A50-608-010 COIL, M DET-N(TOK) A...................
L 802 87-A91-551-010 LTR,PC JZH-450 L(TOK) A...................
L 811 87-005-847-080 COIL,2.2UH(CECS) A...................
L 822 87-A50-209-010 COIL,1POLE MPX(MIT) A...................
L 821 87-A50-209-010 COIL,1POLE MPX(MIT) A...................
R 790 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 842 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 844 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 858 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 859 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 852 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 851 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 853 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 850 87-010-260-080 CAP, ELECT 47-25V A...................
C 860 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 959 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 961 87-010-152-080 C-CAP,S 8P-50 CH A...................
C 960 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 963 87-015-785-080 CHIP CAPACITOR, 0.1 Z-25Z A...................
C 832 87-008-261-010 ILTER, S E10.7MA5-A A...................
C 831 87-008-261-010 ILTER, S E10.7MA5-A A...................
E 831 A8-8ZA-190-030 8ZA-1 EUNM A...................
J 831 87-A60-202-010 TERMINAL,ANT 4P MSP-154V-02 A...................
L 832 87-005-847-080 COIL,2.2UH(CECS) A...................
L 951 8A-N 8-667-010 COIL,AM PACK 4(TOK) A...................
Q 836 87-A30-489-080 C-TR,KRA107S A...................
Q 835 89-327-143-080 TR,2SC2714 (0.1W) A...................
87-067-703-010 TAPPING SCREW, BVT2+3-10 A...................
C 4 87-012-368-080 C-CAP,S 0.1-50 A...................
C 3 87-012-368-080 C-CAP,S 0.1-50 A...................
C 25 87-010-990-080 CAP,E 33-100 SME A...................
C 27 87-010-990-080 CAP,E 33-100 SME A...................
C 21 87-016-035-090 CAP, E 6800-35 VR A...................
C 22 87-016-035-090 CAP, E 6800-35 VR A...................
C 26 87-016-300-080 CAP,E 22-100 SME A...................
C 28 87-016-300-080 CAP,E 22-100 SME A...................
C 32 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 34 87-010-247-080 CAP, ELECT 100-50V A...................
C 31 87-010-263-080 CAP, ELECT 100-10V A...................
C 33 87-010-263-080 CAP, ELECT 100-10V A...................
C 36 87-010-381-080 CAP, ELECT 330-16V A...................
C 39 87-010-393-080 CAP, ELECT 100-35V A...................
C 38 87-010-393-080 CAP, ELECT 100-35V A...................
C 35 87-010-406-080 CAP, ELECT 22-50 A...................
C 40 87-010-190-080 S CHIP 0.01 A...................
C 60 87-010-403-080 CAP, ELECT 3.3-50V A...................
C 82 87-010-260-080 CAP, ELECT 47-25V A...................
C 81 87-010-374-080 CAP, ELECT 47-10V A...................
C 80 87-010-401-080 CAP, ELECT 1-50V A...................
CN 1 87-A60-996-010 CONN,13P V BLK TAC-L13X-A3 A...................
CN 92 87-A60-619-010 CONN,2P V 2MM JMT A...................
CN 91 87-A60-619-010 CONN,2P V 2MM JMT A...................
CNA 3 87-049-919-010 CONN,3P EH V WHT A...................
CNA 2 8A-N 3-640-110 CONN ASSY,3P (VM) AN -3 A...................
CNA 1 8A-N 8-653-010 CONN ASSY,9P TID-A(480) A...................
D 1 87-A40-673-090 DIODE,D10XB20 A...................
D 25 87-A40-553-080 DIODE,1N4003 LES A...................
D 28 87-A40-553-080 DIODE,1N4003 LES A...................
D 27 87-A40-553-080 DIODE,1N4003 LES A...................
D 26 87-A40-553-080 DIODE,1N4003 LES A...................
D 29 87-A40-781-080 ZENER,UZ36BSA A...................
D 33 87-070-274-080 DIODE,1N4003 SEM A...................
D 31 87-A40-764-080 ZENER,UZ10BSC A...................
D 65 87-A40-768-080 ZENER,UZ16BSA A...................
Q 2 87-A30-217-010 TR,2SB1436(R) A...................
Q 1 87-A30-217-010 TR,2SB1436(R) A...................
Q 9 87-A30-318-080 TR,CSA952K A...................
Q 13 89-213-702-010 TR,2SB1370 (1.8W) A...................
Q 14 89-213-702-010 TR,2SB1370 (1.8W) A...................
Q 84 87-A30-218-080 TR,2SB1237(Q) A...................
R 25 87-A00-261-080 RES,M/ 0.56-1W J A...................
WH 1 87-A90-510-010 HLDR,WIRE 2.5-9P A...................
ELECTRICAL MAIN PARTS LIST - 7/11

C 603 87-010-318-080 C-CAP,S 47P-50 CH A...................
C 604 87-010-318-080 C-CAP,S 47P-50 CH A...................
C 605 87-010-318-080 C-CAP,S 47P-50 CH A...................
C 606 87-010-318-080 C-CAP,S 47P-50 CH A...................
C 616 87-010-180-080 C-CER 1500P A...................
C 613 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 617 87-010-198-080 CAP, CHIP 0.022 A...................
C 619 87-010-263-080 CAP, ELECT 100-10V A...................
C 612 87-010-369-080 C-CAP,S 0.033-25 K B A...................
C 618 87-010-401-080 CAP, ELECT 1-50V A...................
C 611 87-010-956-080 CHIP-CAP,S 0.068-25B A...................
C 614 87-016-669-080 C-CAP,S 0.1-25 K B A...................
C 621 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 627 87-010-400-080 CAP, ELECT 0.47-50V A...................
C 628 87-010-400-080 CAP, ELECT 0.47-50V A...................
C 623 87-010-401-080 CAP, ELECT 1-50V A...................
C 624 87-010-401-080 CAP, ELECT 1-50V A...................
C 629 87-010-992-080 C-CAP,S 0.047-25 B A...................
C 626 87-010-992-080 C-CAP,S 0.047-25 B A...................
C 620 87-016-669-080 C-CAP,S 0.1-25 K B A...................
C 632 87-010-185-080 C-CAP,S 3900P-50 B A...................
C 631 87-010-185-080 C-CAP,S 3900P-50 B A...................
C 634 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 630 87-010-383-080 CAP, ELECT 33-25V A...................
C 639 87-010-405-080 CAP, ELECT 10-50V A...................
C 637 87-A10-307-080 CAP,M 0.1-50 J A...................
C 636 87-A10-307-080 CAP,M 0.1-50 J A...................
C 635 87-A10-307-080 CAP,M 0.1-50 J A...................
C 638 87-A10-307-080 CAP,M 0.1-50 J A...................
C 643 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 644 87-010-401-080 CAP, ELECT 1-50V A...................
C 642 87-010-401-080 CAP, ELECT 1-50V A...................
C 641 87-010-401-080 CAP, ELECT 1-50V A...................
C 675 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 679 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 673 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 672 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 671 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 682 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 680 87-010-197-080 CAP, CHIP 0.01 DM A...................
CN 605 87-099-568-010 CONN,11P TUC-P11P-B1 A...................
CN 601 87-099-719-010 CONN,30P TYK-B(X) A...................
CN 602 87-A60-131-010 CONN,6P V E A...................
D 602 87-A40-438-080 ZENER,MTZJ4.7A A...................
IC 601 87-A21-452-030 C-IC,BD3876KS2 A...................
J 601 87-A60-885-010 JACK,PIN 6P R/W MSC A...................
Q 601 87-026-610-080 TR,KTC3198GR A...................
Q 606 87-A30-086-070 C-TR,CSD1306E A...................
C 535 87-010-178-080 CHIP CAP 1000P A...................
C 536 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 533 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 532 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 531 87-010-560-080 CAP,E 10-50 GAS A...................
C 534 87-012-156-080 C-CAP,S 220P-50 CH A...................
C 541 87-010-178-080 CHIP CAP 1000P A...................
C 201 87-010-402-080 CAP, ELECT 2.2-50V A...................
C 202 87-010-402-080 CAP, ELECT 2.2-50V A...................
C 205 87-010-404-080 CAP, ELECT 4.7-50V A...................
C 209 87-016-460-080 C-CAP,S 0.22-16 B A...................
C 207 87-016-669-080 C-CAP,S 0.1-25 K B A...................
C 208 87-016-669-080 C-CAP,S 0.1-25 K B A...................
C 219 87-010-183-080 C-CAP,S 2700P-50 B A...................
C 215 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 216 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 218 87-010-198-080 CAP, CHIP 0.022 A...................
C 217 87-010-198-080 CAP, CHIP 0.022 A...................
C 213 87-010-956-080 CHIP-CAP,S 0.068-25B A...................
C 214 87-010-956-080 CHIP-CAP,S 0.068-25B A...................
C 212 87-012-365-080 C-CAP,S 0.027-25VBK A...................
C 211 87-012-365-080 C-CAP,S 0.027-25VBK A...................
C 210 87-016-460-080 C-CAP,S 0.22-16 B A...................
C 227 87-010-112-080 CAP, ELECT 100-16V A...................
C 223 87-010-178-080 CHIP CAP 1000P A...................
C 224 87-010-178-080 CHIP CAP 1000P A...................
C 226 87-010-182-080 C-CAP,S 2200P-50 B A...................
C 225 87-010-182-080 C-CAP,S 2200P-50 B A...................
C 220 87-010-183-080 C-CAP,S 2700P-50 B A...................
C 222 87-010-188-080 CAP,CHIP 6800P A...................
C 221 87-010-188-080 CAP,CHIP 6800P A...................
C 228 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 229 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 231 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 230 87-010-322-080 C-CAP,S 100P-50 CH A...................
CN 201 87-A60-546-010 CONN,11P H GRY TUC-P11X-C1 A...................
IC 201 87-A20-869-040 C-IC,M62449 P A...................
C 412 87-010-071-080 CAP, ELECT 1-50 M 5L SRE A...................
C 419 87-010-154-080 CAP CHIP 10P A...................
ELECTRICAL MAIN PARTS LIST - 8/11

C 418 87-010-154-080 CAP CHIP 10P A...................
C 427 87-010-154-080 CAP CHIP 10P A...................
C 426 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 424 87-010-408-080 CAP, ELECT 47-50V A...................
C 428 87-010-408-080 CAP, ELECT 47-50V A...................
C 439 87-010-154-080 CAP CHIP 10P A...................
C 436 87-010-235-080 CAP,E 470-16 SME A...................
C 435 87-010-382-080 CAP, ELECT 22-25V A...................
C 433 87-010-401-080 CAP, ELECT 1-50V A...................
C 432 87-010-415-080 CAP ELE SRE 10-50V A...................
C 446 87-010-154-080 CAP CHIP 10P A...................
C 440 87-010-154-080 CAP CHIP 10P A...................
C 445 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 444 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 442 87-010-401-080 CAP, ELECT 1-50V A...................
C 454 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 450 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 451 87-010-378-080 CAP, ELECT 10-16V A...................
C 452 87-010-378-080 CAP, ELECT 10-16V A...................
CNA 412 87-A60-627-010 CONN,10P V 2MM JMT A...................
CNA 411 87-A60-627-010 CONN,10P V 2MM JMT A...................
D 401 87-A40-347-080 ZENER,MTZJ2.2B A...................
D 402 87-A40-347-080 ZENER,MTZJ2.2B A...................
IC 413 87-070-391-040 IC,BA4558 A...................
IC 411 87-A21-111-040 C-IC,M62495 P A...................
IC 412 87-A21-111-040 C-IC,M62495 P A...................
Q 415 89-110-372-080 TR,2SA1037(140MHZ 200MW) A...................
Q 416 89-213-750-010 TR,2SB1375 (25W) A...................
R 401 87-A00-401-050 RES,M/ 390-1W J VTP A...................
R 402 87-A00-402-050 RES,M/ 560-1W J VTP A...................
R 403 87-A00-402-050 RES,M/ 560-1W J VTP A...................
87-067-579-010 TAPPING SCREW, BVT2+3-8 A...................
C 105 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 109 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 107 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 108 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 101 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 106 87-010-197-080 CAP, CHIP 0.01 DM A...................
C 104 87-010-313-080 CAP, CHIP 18P A...................
C 103 87-010-314-080 C-CAP,S 22P-50V A...................
C 102 87-010-374-080 CAP, ELECT 47-10V A...................
C 119 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 113 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 110 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 111 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 114 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 117 87-010-198-080 CAP, CHIP 0.022 A...................
C 115 87-010-374-080 CAP, ELECT 47-10V A...................
C 118 87-010-401-080 CAP, ELECT 1-50V A...................
C 112 87-010-404-080 CAP, ELECT 4.7-50V A...................
C 116 87-012-140-080 CAP 470P A...................
C 128 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 125 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 126 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 120 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 124 87-010-263-080 CAP, ELECT 100-10V A...................
C 122 87-010-311-080 CAP 12P A...................
C 123 87-010-311-080 CAP 12P A...................
C 129 87-010-384-080 CAP, ELECT 100-25V A...................
C 121 87-010-401-080 CAP, ELECT 1-50V A...................
C 127 87-010-555-040 CAP,E 100-10 GAS A...................
C 134 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 131 87-010-263-080 CAP, ELECT 100-10V A...................
C 139 87-010-314-080 C-CAP,S 22P-50V A...................
C 132 87-010-401-080 CAP, ELECT 1-50V A...................
C 136 87-010-405-080 CAP, ELECT 10-50V A...................
C 135 87-010-405-080 CAP, ELECT 10-50V A...................
C 142 87-010-182-080 C-CAP,S 2200P-50 B A...................
C 143 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 141 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 149 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 148 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 144 87-010-312-080 C-CAP,S 15P-50 CH A...................
C 147 87-010-405-080 CAP, ELECT 10-50V A...................
C 140 87-010-552-040 CAP,E 22-16 GAS A...................
C 146 87-012-154-080 C-CAP,S 150P-50 CH A...................
C 145 87-012-154-080 C-CAP,S 150P-50 CH A...................
C 153 87-010-178-080 CHIP CAP 1000P A...................
C 154 87-010-178-080 CHIP CAP 1000P A...................
C 159 87-010-178-080 CHIP CAP 1000P A...................
C 150 87-010-405-080 CAP, ELECT 10-50V A...................
C 152 87-010-405-080 CAP, ELECT 10-50V A...................
C 151 87-010-405-080 CAP, ELECT 10-50V A...................
C 158 87-012-154-080 C-CAP,S 150P-50 CH A...................
C 157 87-012-154-080 C-CAP,S 150P-50 CH A...................
C 155 87-A10-369-080 C-CAP,S 0.47-16 K B A...................
C 160 87-010-178-080 CHIP CAP 1000P A...................
ELECTRICAL MAIN PARTS LIST - 9/11

C 164 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 163 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 166 87-010-405-080 CAP, ELECT 10-50V A...................
C 161 87-010-405-080 CAP, ELECT 10-50V A...................
C 167 87-010-405-080 CAP, ELECT 10-50V A...................
C 162 87-010-405-080 CAP, ELECT 10-50V A...................
C 169 87-012-154-080 C-CAP,S 150P-50 CH A...................
C 165 87-A10-369-080 C-CAP,S 0.47-16 K B A...................
C 171 87-010-178-080 CHIP CAP 1000P A...................
C 172 87-010-178-080 CHIP CAP 1000P A...................
C 179 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 178 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 175 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 174 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 170 87-012-154-080 C-CAP,S 150P-50 CH A...................
C 173 87-018-209-080 CAP, CER 0.1-50V A...................
C 177 87-A10-369-080 C-CAP,S 0.47-16 K B A...................
C 187 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 183 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 188 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 184 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 189 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 186 87-010-405-080 CAP, ELECT 10-50V A...................
C 185 87-010-405-080 CAP, ELECT 10-50V A...................
C 182 87-010-405-080 CAP, ELECT 10-50V A...................
C 181 87-010-405-080 CAP, ELECT 10-50V A...................
C 180 87-010-405-080 CAP, ELECT 10-50V A...................
C 194 87-010-154-080 CAP CHIP 10P A...................
C 193 87-010-154-080 CAP CHIP 10P A...................
C 191 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 192 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 198 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 196 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 197 87-010-405-080 CAP, ELECT 10-50V A...................
C 195 87-010-405-080 CAP, ELECT 10-50V A...................
C 190 87-010-405-080 CAP, ELECT 10-50V A...................
C 199 87-A10-369-080 C-CAP,S 0.47-16 K B A...................
C 202 87-010-154-080 CAP CHIP 10P A...................
C 201 87-010-154-080 CAP CHIP 10P A...................
C 209 87-010-154-080 CAP CHIP 10P A...................
C 204 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 203 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 206 87-010-401-080 CAP, ELECT 1-50V A...................
C 207 87-010-405-080 CAP, ELECT 10-50V A...................
C 208 87-010-405-080 CAP, ELECT 10-50V A...................
C 205 87-A10-369-080 C-CAP,S 0.47-16 K B A...................
C 210 87-010-154-080 CAP CHIP 10P A...................
C 212 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 211 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 214 87-010-405-080 CAP, ELECT 10-50V A...................
C 215 87-010-405-080 CAP, ELECT 10-50V A...................
C 216 87-010-405-080 CAP, ELECT 10-50V A...................
C 219 87-010-993-080 C-CAP,S 0.056-25 B A...................
C 213 87-A10-369-080 C-CAP,S 0.47-16 K B A...................
C 222 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 224 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 228 87-010-405-080 CAP, ELECT 10-50V A...................
C 227 87-010-405-080 CAP, ELECT 10-50V A...................
C 226 87-012-155-080 C-CAP 180P-50CH A...................
C 225 87-012-155-080 C-CAP 180P-50CH A...................
C 220 87-A10-369-080 C-CAP,S 0.47-16 K B A...................
C 236 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 232 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 237 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 239 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 230 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 238 87-010-314-080 C-CAP,S 22P-50V A...................
C 242 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 244 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 240 87-010-314-080 C-CAP,S 22P-50V A...................
C 243 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 241 87-010-405-080 CAP, ELECT 10-50V A...................
C 261 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 260 87-010-378-080 CAP, ELECT 10-16V A...................
C 270 87-012-155-080 C-CAP 180P-50CH A...................
C 306 87-010-183-080 C-CAP,S 2700P-50 B A...................
C 309 87-010-184-080 CHIP CAPACITOR 3300P(K) A...................
C 305 87-010-184-080 CHIP CAPACITOR 3300P(K) A...................
C 303 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 304 87-012-393-080 C-CAP,S 0.22-16 R K A...................
C 301 87-012-393-080 C-CAP,S 0.22-16 R K A...................
C 302 87-012-393-080 C-CAP,S 0.22-16 R K A...................
C 308 87-016-669-080 C-CAP,S 0.1-25 K B A...................
C 307 87-016-669-080 C-CAP,S 0.1-25 K B A...................
C 310 87-010-183-080 C-CAP,S 2700P-50 B A...................
C 317 87-010-183-080 C-CAP,S 2700P-50 B A...................
C 318 87-010-183-080 C-CAP,S 2700P-50 B A...................
ELECTRICAL MAIN PARTS LIST - 10/11

C 313 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 316 87-010-374-080 CAP, ELECT 47-10V A...................
C 315 87-010-374-080 CAP, ELECT 47-10V A...................
C 312 87-010-374-080 CAP, ELECT 47-10V A...................
C 319 87-010-545-080 CAP, ELECT 0.22-50V A...................
C 311 87-012-393-080 C-CAP,S 0.22-16 R K A...................
C 320 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 321 87-010-263-080 CAP, ELECT 100-10V A...................
C 401 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 403 87-010-401-080 CAP, ELECT 1-50V A...................
C 402 87-010-404-080 CAP, ELECT 4.7-50V A...................
C 405 87-018-147-080 CAP,TC-U 10P-50 CH A...................
C 504 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................
C 502 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 506 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 508 87-018-119-080 CAP, CER 100P-50V A...................
C 511 87-018-113-080 CAP, CER 33P-50V A...................
C 510 87-018-131-080 CAP, CER 1000P-50V A...................
C 512 87-A11-132-080 CAP,TC U 0.01-50 K B A...................
CN 101 87-A60-057-010 CONN,11P V 9604S-11C A...................
CN 103 88-AR1-658-010 CONN ASSY,2P (AC-3) A...................
CN 105 8Z-N D-645-010 CONN,ASSY 10P A...................
CN 102 8Z-N D-648-010 CONN,ASSY 10P A...................
D 101 87-A40-291-080 DIODE,1N4148 (CPT) A...................
D 301 87-017-931-080 ZENER,MTZJ5.6B A...................
D 402 87-A40-291-080 DIODE,1N4148 (CPT) A...................
D 401 87-A40-291-080 DIODE,1N4148 (CPT) A...................
D 403 87-A40-291-080 DIODE,1N4148 (CPT) A...................
D 404 87-A40-348-080 ZENER,MTZJ3.3A A...................
B 102 87-008-372-080 ILTER, EMI BL OIRNI A...................
B 104 87-008-372-080 ILTER, EMI BL OIRNI A...................
B 103 87-008-372-080 ILTER, EMI BL OIRNI A...................
B 105 87-008-372-080 ILTER, EMI BL OIRNI A...................
B 106 87-008-372-080 ILTER, EMI BL OIRNI A...................
B 108 87-008-474-080 -BEAD,EMI BL02RN1 A...................
B 109 87-008-474-080 -BEAD,EMI BL02RN1 A...................
B 107 87-008-474-080 -BEAD,EMI BL02RN1 A...................
B 110 87-003-223-080 ERRITE BEAD BL02RN2 A...................
B 112 87-003-223-080 ERRITE BEAD BL02RN2 A...................
IC 106 87-017-022-080 IC,NJM2068M-D(T1) A...................
IC 107 87-017-022-080 IC,NJM2068M-D(T1) A...................
IC 105 87-017-022-080 IC,NJM2068M-D(T1) A...................
IC 108 87-020-784-080 IC,TC4053B A...................
IC 109 87-020-784-080 IC,TC4053B A...................
IC 103 87-020-903-010 IC,NJM7805 A A...................
IC 101 87-A20-823-010 C-IC,YSS248 A...................
IC 102 87-A20-824-010 C-IC,CS4226 A...................
IC 118 87-001-604-080 IC,TC74HCU04 A...................
IC 114 87-017-022-080 IC,NJM2068M-D(T1) A...................
IC 110 87-017-022-080 IC,NJM2068M-D(T1) A...................
IC 112 87-017-022-080 IC,NJM2068M-D(T1) A...................
IC 111 87-017-022-080 IC,NJM2068M-D(T1) A...................
IC 113 87-017-022-080 IC,NJM2068M-D(T1) A...................
IC 119 87-020-784-080 IC,TC4053B A...................
IC 115 87-A20-870-010 IC,GP1 37R A...................
IC 117 87-A21-018-040 C-IC,M65849B P631D A...................
IC 121 87-002-298-080 IC,TC74HC00A A...................
IC 120 87-017-022-080 IC,NJM2068M-D(T1) A...................
J 101 87-A60-573-010 JACK,PIN 1P ORN A...................
L 106 87-003-097-080 COIL,1UH A...................
L 103 87-005-274-080 COIL,68UH K LAL03 A...................
L 105 87-008-501-080 LTR,DSS306-B101 A...................
L 104 87-008-501-080 LTR,DSS306-B101 A...................
L 102 87-A50-095-010 COIL,68UH RCR875D A...................
P 1 86-N Z-222-010 PIN,DIA1-6.5 A...................
Q 105 87-A30-071-080 C-TR,RT1N 144C A...................
Q 106 87-A30-075-080 C-TR,2SA1235 A...................
Q 107 87-A30-257-080 C-TR,2SD1306E A...................
Q 404 87-026-608-080 C-TR,DTC 123 JK A...................
X 102 87-A70-115-010 VIB,XTAL 12.288MHZ A...................
X 101 87-A70-116-010 VIB,XTAL 10.00MHZ A...................
ELECTRICAL MAIN PARTS LIST - 11/11

NOTE: The characters in the suffix column indicate the part usage.
U ......................XX..................................A...................
KANRI
RE .NO PARTS NO. NO. DESCRIPTION SU IX
88-N 3-090-010 RING, OOT A...................
8A-N 3-028-010 BOX,CASS L A...................
8A-N 3-029-010 BOX,CASS R A...................
8A-N 3-039-010 PANEL,CASS L A...................
8A-N 3-040-010 PANEL,CASS R A...................
8A-N 3-042-010 PANEL ASSY,TRAY A...................
8A-N 3-047-010 PANEL,CD A...................
8A-N 3-048-010 PANEL,RE LECTOR- CD A...................
8A-N 3-049-010 PANEL,KEY-CD A...................
8A-N 3-058-010 WINDOW,CASS L A...................
8A-N 3-059-010 WINDOW,CASS R A...................
8A-N E-031-010 PANEL, R U A...................
8A-N E-051-010 WINDOW,DISP U A...................
8Z-N 3-048-010 COVER, BOTTOM A...................
* 8A-N 3-026-010 CABI,BOTTOM A...................
* 8A-N 3-027-010 CABI,STEEL A...................
* 8A-N E-001-010 CABI, R A...................
* 8A-N E-011-010 CABI,REAR USM A...................
8A-N 3-061-010 KEY,GEQ A...................
8A-N 3-063-010 KEY ASSY,OPE A...................
8A-N 3-065-010 KEY,KARAOKE A...................
8A-N 3-067-010 KEY,BBE A...................
8A-N 3-068-010 KEY,JOG A...................
8A-N 3-070-010 KEY,ECO A...................
8A-N 3-071-010 KEY,CD A...................
8A-N 3-073-010 KEY,REC U A...................
8A-N 3-076-010 RING,VOL A...................
8A-N 3-078-010 RING,JOG U A...................
8A-N 3-081-010 KNOB,RTRY VOL A...................
8A-N 3-082-010 KNOB,RTRY JOG A...................
8A-N E-062-010 KEY,L E A...................
8A-N E-072-010 KEY, UNC AC3 A...................
81-532-080-010 LABEL, CASS. COMPT A...................
8A-N 3-087-010 RE LECTOR,JOG A...................
8A-N 3-088-010 RE LECTOR, UNC A...................
8A-N 3-089-010 RE LECTOR,CD A...................
8A-N 3-090-010 RE LECTOR,CASS L A...................
8A-N 3-091-010 RE LECTOR,CASS R A...................
8Z-N 3-643-010 CONN ASSY,3P PB A...................
8Z-N 3-644-010 CONN ASSY,8P RPB A...................
84-ZG1-245-210 CAP,OPTICAL A...................
82-N 5-218-010 SPR-T,EJECT 1 (SIN) A...................
82-N 5-219-010 SPR-T,EJECT 2 (SIN) A...................
82-N 5-229-010 PLATE,LOCK A...................
86-N 9-224-010 SPR-C,LOCK A...................
87-064-185-010 HLDR,WIRE A...................
87-N 4-216-010 HLDR,LOCK 1 A...................
87-N 4-217-110 HLDR,LOCK 2 A...................
87-N 4-221-010 HLDR,CABLE A...................
87-N 8-220-010 DMPR,150 A...................
8A-N 3-225-010 COVER, HLDR A...................
8A-N 3-228-010 HLDR,PWB-PT A...................
8A-N 3-229-110 HLDR,BRACKET A...................
* 8A-N 3-201-010 GUIDE,LED- UNC A...................
* 8A-N 3-203-010 GUIDE,LED-CD A...................
* 8A-N 3-213-010 HLDR,HT-SINK L A...................
* 8A-N 3-214-010 HLDR,HT-SINK R A...................
* 8A-N 3-221-010 HLDR,IC-VM A...................
* 8A-N 3-223-010 HLDR, AN A...................
* 8A-N 8-206-010 HLDR,PWB M A...................
* 8A-N E-207-010 HLDR,PWB-AC3 A...................
87-067-579-010 TAPPING SCREW, BVT2+3-8 A...................
87-067-581-010 TAPPING SCREW, BVT2+3-15 A...................
87-067-641-010 UTT2+3-8(W/O SLOT)BL A...................
87-067-689-010 TAPPING SCREW, BVTT+3-8 A...................
87-067-703-010 TAPPING SCREW, BVT2+3-10 A...................
87-067-758-010 BVT2+3-12 W/O SLOT A...................
87-067-761-010 TAPPING SCREW, BVT2+3-10 A...................
87-067-975-010 S-SCREW,IT+4-8 A...................
87-591-095-410 TAPPING SCREW, QIT+3-8 (GLD) A...................
87-721-096-410 QT2+3-10 GLD A...................
87-721-097-410 QT2+3-12 GLD A...................
87-N 4-224-010 S-SCREW,IT3B+3-8 CU A...................
* 87-067-822-010 BVT2+3-20 W/O SLOT A...................
* 8A-N 3-208-010 HLDR,CHAS L A...................
* 8A-N 3-209-010 HLDR,CHAS R A...................
* 8A-N 3-210-010 HLDR,SIDE L A...................
* 8A-N 3-211-010 HLDR,SIDE R A...................
* 8A-N 3-212-010 HLDR,REAR A...................
87-010-260-080 CAP, ELECT 47-25V A...................
87-012-154-080 C-CAP,S 150P-50 CH A...................
MECHANICAL PARTS LIST - 1/2

87-012-156-080 C-CAP,S 220P-50 CH A...................
87-018-123-080 CAP, CER 220P-50V A...................
87-A40-747-080 ZENER,UZ5.1BSB A...................
87-A91-422-010 BUSHING,AC CORD(U) A...................
87-A91-423-010 AN,AD0612DS-D7OGL A...................
87-A91-711-010 AN, 3110GL-B4W-B34-H02 -400MM A...................
88-905-081-110 -CABLE, 5P 1.25 A...................
88-906-481-110 -CABLE, 6P 1.25 480MM A...................
88-908-381-110 -CABLE,8P 1.25 A...................
88-910-201-110 -CABLE, 10P 1.25 200MM A...................
88-914-481-110 -CABLE, 14P 1.25 480MM A...................
88-915-161-110 -CABLE, 15P 1.25 A...................
101 87-035-494-010 USE,10A 125V T 237 A...................
B 101 87-A90-562-010 -BEAD,9.5-17.5-28.5 BRH A...................
PT 101 8A-N E-601-010 PT,U EI105-60 AN -14 A...................
W 101 87-A80-149-010 AC CORD ASSY,U BLK A...................
87-067-703-010 TAPPING SCREW, BVT2+3-10 A...................
87-067-703-010 TAPPING SCREW, BVT2+3-10 A...................
WH 102 87-A90-460-010 HLDR,WIRE 2.5-7P A...................
WH 101 87-A90-460-010 HLDR,WIRE 2.5-7P A...................
87-067-703-010 TAPPING SCREW, BVT2+3-10 A...................
WH 1 87-A90-510-010 HLDR,WIRE 2.5-9P A...................
87-067-579-010 TAPPING SCREW, BVT2+3-8 A...................
MECHANICAL PARTS LIST - 2/2

NOTE: The characters in the suffix column indicate the part usage.
U ......................XX..................................A...................
KANRI
RE .NO PARTS NO. NO. DESCRIPTION SU IX
8A-N E-903-010 IB,U (ES ) M A...................
87-006-225-010 AM LOOP ANT NC2 A...................
87-043-115-010 ANT, EEDER M A...................
8Z-N D-702-010 RC UNIT,RC- ZAS22 A...................
ACCESSORIES / PACKAGE LIST - 1/1

SCHEMATIC DIAGRAM _1 (MAIN)

SCHEMATIC DIAGRAM _2 (DECK)

SCHEMATIC DIAGRAM_3(TUNER)

SCHEMATIC DIAGRAM_4(GEQ)

SCHEMATIC DIAGRAM_5(DISPLAY)
