S E R V I C E M A N U A L

SIMPLE MANUAL

• Replace this Service Manual with ”Revision Publishing” when it is issued.

XR-H33MD

• BASIC TAPE MECHANISM: 2ZM-3MK2 YPR4N

• BASIC CD MECHANISM: 4ZG-1 Z3MD

• BASIC MD MECHANISM: 7ZG-AD • TYPE: HD

S/M Code No. 09–986–285–30A

MD/CD STEREO

CASSETTE RECEIVER

ELECTRICAL MAIN PARTS LIST - 1/6

NOTE: The characters in the suffix column indicate the part usage.

SNH33MDHD ..............XX..................................A...................

KANRI

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

87-NB8-204-010 1A GUIDE,FL 125-29-6.6 A...................

87-NB8-206-010 1A GUIDE,PLAY A...................

C 152 87-010-196-080 0E CHIP CAPACITOR,0.1-25 A...................

C 159 87-010-196-080 0E CHIP CAPACITOR,0.1-25 A...................

C 156 87-010-314-080 0E C-CAP,S 22P-50V A...................

C 157 87-010-316-080 0E C-CAP,S 33P-50 CH A...................

C 155 87-010-320-080 0E CHIP CAP 68P A...................

C 153 87-010-494-040 0E CAP,E 1-50 GAS A...................

C 151 87-010-555-040 0E CAP,E 100-10 GAS A...................

C 154 87-A10-189-040 0E CAP,E 220-10 A...................

C 160 87-010-196-080 0E CHIP CAPACITOR,0.1-25 A...................

C 161 87-010-196-080 0E CHIP CAPACITOR,0.1-25 A...................

C 166 87-010-405-040 0E CAP,E 10-50 A...................

C 165 87-012-157-080 0E C-CAP,S 330P-50 CH A...................

C 171 87-010-194-080 0E CAP, CHIP 0.047 A...................

C 174 87-010-406-040 0E CAP,E 22-50 SME A...................

C 173 87-010-406-040 0E CAP,E 22-50 SME A...................

C 172 87-010-408-040 0E CAP,E 47-50 SME A...................

C 180 87-010-194-080 0E CAP, CHIP 0.047 A...................

C 183 87-010-197-080 0E CAP, CHIP 0.01 DM A...................

C 181 87-012-156-080 0E C-CAP,S 220P-50 CH A...................

C 182 87-012-156-080 0E C-CAP,S 220P-50 CH A...................

C 191 87-012-368-080 0E C-CAP,S 0.1-50 F A...................

C 192 87-015-785-080 0E CHIP CAPACITOR, 0.1FZ-25Z A...................

C 401 87-010-196-080 0E CHIP CAPACITOR,0.1-25 A...................

C 403 87-010-318-080 0E C-CAP,S 47P-50 CH A...................

C 501 87-010-196-080 0E CHIP CAPACITOR,0.1-25 A...................

CON 101 87-099-720-010 1B CONN,30P TYK-B(P) ....................

CON 102 87-A60-055-010 0E CONN,13P V 9604S-13C A...................

CON 101 87-A60-350-010 1B CONN 30P DF8A-30P A...................

CON 251 87-099-017-010 0E CONN, 15P 6216 V A...................

CON 502 87-099-195-010 0E CONN,7P 6216 V A...................

D 108 87-A40-291-080 0E DIODE,1N4148 (CPT) A...................

D 107 87-A40-291-080 0E DIODE,1N4148 (CPT) A...................

D 110 87-A40-291-080 0E DIODE,1N4148 (CPT) A...................

D 153 87-A40-304-080 0E ZENER,DZ6.2M A...................

D 152 87-A40-468-080 0E C-DIODE,HSM2836CTR A...................

D 151 87-A40-469-080 0E C-DIODE,HSM2838CTR A...................

D 163 87-A40-291-080 0E DIODE,1N4148 (CPT) A...................

D 164 87-A40-291-080 0E DIODE,1N4148 (CPT) A...................

D 251 87-A40-468-080 0E C-DIODE,HSM2836CTR A...................

D 368 87-A40-468-080 0E C-DIODE,HSM2836CTR A...................

D 365 87-A40-468-080 0E C-DIODE,HSM2836CTR A...................

D 366 87-A40-468-080 0E C-DIODE,HSM2836CTR A...................

D 361 87-A40-468-080 0E C-DIODE,HSM2836CTR A...................

D 363 87-A40-468-080 0E C-DIODE,HSM2836CTR A...................

D 362 87-A40-468-080 0E C-DIODE,HSM2836CTR A...................

D 364 87-A40-468-080 0E C-DIODE,HSM2836CTR A...................

D 367 87-A40-468-080 0E C-DIODE,HSM2836CTR A...................

D 378 87-A40-291-080 0E DIODE,1N4148 (CPT) A...................

D 375 87-A40-291-080 0E DIODE,1N4148 (CPT) ....................

D 370 87-A40-291-080 0E DIODE,1N4148 (CPT) ....................

D 376 87-A40-291-080 0E DIODE,1N4148 (CPT) A...................

D 371 87-A40-291-080 0E DIODE,1N4148 (CPT) A...................

D 377 87-A40-291-080 0E DIODE,1N4148 (CPT) A...................

D 379 87-A40-291-080 0E DIODE,1N4148 (CPT) A...................

D 372 87-A40-291-080 0E DIODE,1N4148 (CPT) ....................

D 555 87-A40-291-080 0E DIODE,1N4148 (CPT) ....................

FB 401 87-008-372-080 0E FILTER, EMI BL OIRNI A...................

FL 101 87-NB8-617-010 2P FL,13-BT-159GK A...................

IC 101 87-NB8-618-210 2M C-IC,LC866556W-5H69 A...................

IC 101 87-NB8-619-110 2P C-IC,LC876572A-5H76 ....................

IC 161 87-NF8-614-010 1B IC,SPS-442-1-W A...................

IC 401 87-070-289-040 1B IC,BU 2092F A...................

LED 400 87-070-281-080 0E LED,SLZ736A-25-S-T1 A...................

LED 403 87-070-281-080 0E LED,SLZ736A-25-S-T1 A...................

LED 404 87-070-281-080 0E LED,SLZ736A-25-S-T1 A...................

LED 402 87-070-281-080 0E LED,SLZ736A-25-S-T1 A...................

LED 401 87-070-281-080 0E LED,SLZ736A-25-S-T1 A...................

LED 405 87-070-281-080 0E LED,SLZ736A-25-S-T1 A...................

LED 702 87-017-730-080 0E LED,SEL6214S A...................

LED 704 87-017-730-080 0E LED,SEL6214S A...................

LED 703 87-A40-380-080 0E LED,SEL6510C-TP5 GRN A...................

Q 153 87-A30-071-080 0E C-TR,RT1N 144C A...................

Q 151 87-A30-076-080 0E C-TR,2SC3052F A...................

Q 152 87-A30-087-080 0E C-FET,2SK2158 A...................

Q 171 87-A30-076-080 0E C-TR,2SC3052F A...................

Q 251 87-A30-073-080 0E C-TR,RT1N 141C A...................

Q 253 87-A30-159-080 0E C-TR,KTA1298Y A...................

Q 254 87-A30-159-080 0E C-TR,KTA1298Y A...................

Q 252 89-112-964-580 1A TR,2SA1296Y 0.75W 120M A...................

Q 369 87-A30-087-080 0E C-FET,2SK2158 A...................

Q 504 87-A30-087-080 0E C-FET,2SK2158 A...................

Q 506 87-A30-087-080 0E C-FET,2SK2158 A...................

Q 502 87-A30-087-080 0E C-FET,2SK2158 A...................

Q 501 89-327-143-080 0E TR,2SC2714 (0.1W) A...................

Q 505 89-327-143-080 0E TR,2SC2714 (0.1W) A...................

Q 503 89-327-143-080 0E TR,2SC2714 (0.1W) A...................

R 116 87-029-390-010 0E FUSE RES 120 1/4W A...................

S 304 87-A90-095-080 0E SW,TACT EVQ11G04M A...................

S 305 87-A90-095-080 0E SW,TACT EVQ11G04M A...................

S 303 87-A90-095-080 0E SW,TACT EVQ11G04M A...................

S 307 87-A90-095-080 0E SW,TACT EVQ11G04M A...................

S 302 87-A90-095-080 0E SW,TACT EVQ11G04M A...................

S 309 87-A90-095-080 0E SW,TACT EVQ11G04M ....................

S 308 87-A90-095-080 0E SW,TACT EVQ11G04M ....................

S 306 87-A90-095-080 0E SW,TACT EVQ11G04M A...................

S 301 87-A90-095-080 0E SW,TACT EVQ11G04M A...................

S 310 87-A90-095-080 0E SW,TACT EVQ11G04M ....................

S 325 87-A90-095-080 0E SW,TACT EVQ11G04M A...................

S 329 87-A90-095-080 0E SW,TACT EVQ11G04M A...................

S 326 87-A90-095-080 0E SW,TACT EVQ11G04M A...................

S 322 87-A90-095-080 0E SW,TACT EVQ11G04M A...................

S 327 87-A90-095-080 0E SW,TACT EVQ11G04M A...................

S 324 87-A90-095-080 0E SW,TACT EVQ11G04M A...................

S 323 87-A90-095-080 0E SW,TACT EVQ11G04M A...................

S 321 87-A90-095-080 0E SW,TACT EVQ11G04M A...................

S 328 87-A90-095-080 0E SW,TACT EVQ11G04M A...................

S 331 87-A90-095-080 0E SW,TACT EVQ11G04M A...................

S 330 87-A90-095-080 0E SW,TACT EVQ11G04M A...................

S 346 87-A90-095-080 0E SW,TACT EVQ11G04M A...................

S 343 87-A90-095-080 0E SW,TACT EVQ11G04M A...................

S 344 87-A90-095-080 0E SW,TACT EVQ11G04M A...................

S 345 87-A90-095-080 0E SW,TACT EVQ11G04M A...................

S 341 87-A90-095-080 0E SW,TACT EVQ11G04M A...................

S 349 87-A90-095-080 0E SW,TACT EVQ11G04M A...................

S 347 87-A90-095-080 0E SW,TACT EVQ11G04M A...................

S 348 87-A90-095-080 0E SW,TACT EVQ11G04M A...................

S 342 87-A90-095-080 0E SW,TACT EVQ11G04M A...................

S 351 87-A90-095-080 0E SW,TACT EVQ11G04M A...................

S 350 87-A90-095-080 0E SW,TACT EVQ11G04M A...................

SW 163 87-A90-085-010 1C SW,RTRY EC16B 24204 A...................

SW 162 87-A90-535-010 1B SW,RTRY EC16B24304 A...................

X 151 87-A70-070-080 1A VIB,CER 5.76MHZ CRHF A...................

C 602 87-010-186-080 0E CAP,CHIP 4700P A...................

C 608 87-010-196-080 0E CHIP CAPACITOR,0.1-25 A...................

C 605 87-010-196-080 0E CHIP CAPACITOR,0.1-25 A...................

C 607 87-010-321-080 0E CHIP CAPACITOR,82P(J) A...................

C 606 87-010-322-080 0E C-CAP,S 100P-50 CH A...................

C 600 87-010-380-040 0E CAP,E 47-16 SME A...................

C 601 87-010-405-040 0E CAP,E 10-50 A...................

C 603 87-010-405-040 0E CAP,E 10-50 A...................

C 604 87-010-406-040 0E CAP,E 22-50 SME A...................

C 609 87-010-545-040 0E CAP,E 0.22-50 SME A...................

C 612 87-010-176-080 0E C-CAP,S 680P-50 SL A...................

C 611 87-010-177-080 0E C-CAP,S 820P-50 SL A...................

C 614 87-010-248-040 0E CAP,E 220-10 SME A...................

C 610 87-010-322-080 0E C-CAP,S 100P-50 CH A...................

C 630 87-010-196-080 0E CHIP CAPACITOR,0.1-25 A...................

D 601 87-A40-291-080 0E DIODE,1N4148 (CPT) A...................

FB 601 87-008-372-080 0E FILTER, EMI BL OIRNI A...................

IC 601 87-017-888-080 1A IC,NJM4558MD A...................

J 601 87-A60-651-010 0E JACK,3.5MONO A...................

Q 601 87-A30-087-080 0E C-FET,2SK2158 A...................

VR 601 87-NB7-602-010 1A VR,RTRY 10KAX1 1 V A...................

FC 1 87-033-147-010 0E FUSE CLAMP ....................

FC 2 87-033-147-010 0E FUSE CLAMP ....................

FC 2 87-A90-505-080 0E FUSE CLAMP,TP00351-51 ....................

FC 1 87-A90-505-080 0E FUSE CLAMP,TP00351-51 ....................

PR 1 87-026-681-080 0E PROTECTOR,5A 60V 491 ....................

PR 2 87-026-681-080 0E PROTECTOR,5A 60V 491 ....................

T 1 87-A60-317-010 0E TERMINAL, 1P MSC ....................

T 2 87-A60-317-010 0E TERMINAL, 1P MSC ....................

WH 101 87-064-168-010 0E HOLDER,WIRE(U)2.5-7P A...................

87-067-703-010 0E TAPPING SCREW, BVT2+3-10 A...................

C 109 87-010-260-080 0E CAP, ELECT 47-25V A...................

C 108 87-010-381-080 0E CAP, ELECT 330-16V A...................

C 107 87-010-384-080 0E CAP, ELECT 100-25V A...................

C 109 87-010-408-080 0E CAP, ELECT 47-50V ....................

C 106 87-010-408-080 0E CAP, ELECT 47-50V A...................

C 101 87-010-917-090 1D CAP,E 3300-50 M SMG ....................

C 104 87-016-051-090 1B CAP,E 2200-35 SMG A...................

C 105 87-018-127-080 0E CAP, CER 470P-50V A...................

C 101 87-A10-520-090 1B CAP,E 3300-35 M SMG A...................

C 104 87-A10-627-090 1B CAP,E 2200-50 M SMG ....................

C 110 87-010-260-080 0E CAP, ELECT 47-25V A...................

C 112 87-010-263-080 0E CAP, ELECT 100-10V A...................

C 114 87-010-374-080 0E CAP, ELECT 47-10V A...................

C 113 87-010-403-080 0E CAP, ELECT 3.3-50V A...................

C 111 87-010-430-080 0E CAP, ELECT 100-63 A...................

C 123 87-010-260-080 0E CAP, ELECT 47-25V A...................

C 122 87-010-260-080 0E CAP, ELECT 47-25V A...................

C 122 87-010-408-080 0E CAP, ELECT 47-50V ....................

C 124 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 ....................

C 130 87-018-131-080 0E CAP, CER 1000P-50V ....................

D 101 87-070-178-090 0E DIODE,1N5402-BD54 A...................

D 103 87-070-178-090 0E DIODE,1N5402-BD54 A...................

D 102 87-070-178-090 0E DIODE,1N5402-BD54 A...................

ELECTRICAL MAIN PARTS LIST - 2/6

D 104 87-070-178-090 0E DIODE,1N5402-BD54 A...................

D 105 87-070-274-080 0E DIODE,1N4003 SEM A...................

D 106 87-070-274-080 0E DIODE,1N4003 SEM A...................

D 109 87-A40-291-080 0E DIODE,1N4148 (CPT) A...................

D 108 87-A40-291-080 0E DIODE,1N4148 (CPT) A...................

D 107 87-A40-312-080 0E ZENER,DZ33M A...................

D 117 87-070-274-080 0E DIODE,1N4003 SEM A...................

D 116 87-070-274-080 0E DIODE,1N4003 SEM A...................

D 110 87-A40-308-080 0E ZENER,DZ10M A...................

Q 108 87-A30-151-080 0E TR,2SA1993F A...................

Q 109 87-A30-152-080 0E TR,2SC5395F A...................

Q 106 87-A30-152-080 0E TR,2SC5395F A...................

Q 103 87-A30-152-080 0E TR,2SC5395F A...................

Q 107 87-A30-152-080 0E TR,2SC5395F A...................

Q 104 87-A30-196-080 0E TR,2SC4115SRS A...................

Q 105 87-A30-199-080 0E TR,2SB1238 A...................

Q 101 89-213-750-010 1A TR,2SB1375 (25W) A...................

Q 102 89-333-317-880 0E TR,2SC3331 (0.5W) A...................

Q 110 87-A30-151-080 0E TR,2SA1993F A...................

Q 115 87-A30-153-080 0E TR,RT1P441S A...................

Q 111 89-213-750-010 1A TR,2SB1375 (25W) A...................

R 124 87-A00-320-080 1B RES,M/F 3.3-1/4W F SN2E ....................

W 101 83-NE2-618-110 1B F-CABEL,5P-2.5 A...................

WH 102 87-064-168-010 0E HOLDER,WIRE(U)2.5-7P A...................

C 207 87-010-546-080 0E CAP, ELECT 0.33-50V A...................

C 208 87-010-546-080 0E CAP, ELECT 0.33-50V A...................

C 209 87-018-133-080 0E CAPACITOR,CER 4700P-16V A...................

C 214 87-010-260-080 0E CAP, ELECT 47-25V A...................

C 213 87-010-260-080 0E CAP, ELECT 47-25V A...................

C 212 87-010-403-080 0E CAP, ELECT 3.3-50V A...................

C 211 87-010-403-080 0E CAP, ELECT 3.3-50V A...................

C 219 87-010-544-080 0E CAP, ELECT 0.1-50V A...................

C 210 87-018-133-080 0E CAPACITOR,CER 4700P-16V A...................

C 227 87-010-260-080 0E CAP, ELECT 47-25V A...................

C 225 87-010-400-080 0E CAP, ELECT 0.47-50V A...................

C 226 87-010-400-080 0E CAP, ELECT 0.47-50V A...................

C 220 87-010-544-080 0E CAP, ELECT 0.1-50V A...................

C 229 87-018-119-080 0E CAP, CER 100P-50V A...................

C 229 87-018-123-080 0E CAP, CER 220P-50V ....................

C 224 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 ....................

C 223 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 ....................

C 221 87-A10-207-080 0E CAP,TCS 0.01-50KBUP050 ....................

C 222 87-A10-207-080 0E CAP,TCS 0.01-50KBUP050 ....................

C 230 87-018-119-080 0E CAP, CER 100P-50V A...................

C 230 87-018-123-080 0E CAP, CER 220P-50V ....................

C 237 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 ....................

C 235 87-018-209-080 0E CAP, CER 0.1-50V A...................

C 236 87-018-209-080 0E CAP, CER 0.1-50V A...................

C 256 87-018-115-080 0E CAP, CER 47P-50V ....................

C 255 87-018-115-080 0E CAP, CER 47P-50V ....................

C 257 87-018-119-080 0E CAP, CER 100P-50V ....................

D 204 87-A40-291-080 0E DIODE,1N4148 (CPT) A...................

D 203 87-A40-291-080 0E DIODE,1N4148 (CPT) A...................

D 209 87-A40-291-080 0E DIODE,1N4148 (CPT) A...................

D 201 87-A40-291-080 0E DIODE,1N4148 (CPT) A...................

D 205 87-A40-291-080 0E DIODE,1N4148 (CPT) A...................

D 202 87-A40-291-080 0E DIODE,1N4148 (CPT) A...................

D 206 87-A40-291-080 0E DIODE,1N4148 (CPT) A...................

D 212 87-A40-291-080 0E DIODE,1N4148 (CPT) A...................

D 210 87-A40-291-080 0E DIODE,1N4148 (CPT) A...................

D 211 87-A40-291-080 0E DIODE,1N4148 (CPT) A...................

D 219 87-A40-291-080 0E DIODE,1N4148 (CPT) ....................

D 217 87-A40-291-080 0E DIODE,1N4148 (CPT) ....................

D 216 87-A40-291-080 0E DIODE,1N4148 (CPT) ....................

D 218 87-A40-291-080 0E DIODE,1N4148 (CPT) ....................

D 221 87-A40-291-080 0E DIODE,1N4148 (CPT) ....................

D 222 87-A40-291-080 0E DIODE,1N4148 (CPT) ....................

D 220 87-A40-291-080 0E DIODE,1N4148 (CPT) ....................

J 201 87-A60-024-010 1B JACK 6.3BLK W/S WKM A...................

J 202 87-A60-238-010 1A TERMINAL,SP 4P (MSC) A...................

L 201 87-003-383-010 1A COIL,1UH-S A...................

L 202 87-003-383-010 1A COIL,1UH-S A...................

PR 202 87-A90-093-080 0E PROTECTOR,3A 491SERIES 60V A...................

Q 209 87-A30-112-080 0E TR,C2N5551 A...................

Q 201 87-A30-151-080 0E TR,2SA1993F A...................

Q 204 87-A30-151-080 0E TR,2SA1993F A...................

Q 202 87-A30-151-080 0E TR,2SA1993F A...................

Q 203 87-A30-151-080 0E TR,2SA1993F A...................

Q 208 87-A30-152-080 0E TR,2SC5395F A...................

Q 206 87-A30-152-080 0E TR,2SC5395F A...................

Q 205 87-A30-152-080 0E TR,2SC5395F A...................

Q 207 87-A30-152-080 0E TR,2SC5395F A...................

Q 209 87-A30-190-080 0E TR,CC5551 ....................

Q 219 87-A30-047-080 0E TR,CSD655E A...................

Q 210 87-A30-112-080 0E TR,C2N5551 A...................

Q 213 87-A30-128-010 1A TR,2SB1481 ....................

Q 214 87-A30-128-010 1A TR,2SB1481 ....................

Q 211 87-A30-130-010 1A TR,2SD2241 ....................

Q 212 87-A30-130-010 1A TR,2SD2241 ....................

Q 212 87-A30-137-010 1C TR,2SD2494 A...................

Q 211 87-A30-137-010 1C TR,2SD2494 A...................

Q 213 87-A30-138-010 1C TR,2SB1625 A...................

ELECTRICAL MAIN PARTS LIST - 3/6

Q 214 87-A30-138-010 1C TR,2SB1625 A...................

Q 218 87-A30-151-080 0E TR,2SA1993F ....................

Q 216 87-A30-152-080 0E TR,2SC5395F A...................

Q 215 87-A30-152-080 0E TR,2SC5395F A...................

Q 217 87-A30-153-080 0E TR,RT1P441S A...................

Q 210 87-A30-190-080 0E TR,CC5551 ....................

Q 220 87-A30-047-080 0E TR,CSD655E A...................

Q 221 87-A30-151-080 0E TR,2SA1993F A...................

R 224 87-A00-258-080 0E RES,M/F 0.22-1W J A...................

R 223 87-A00-258-080 0E RES,M/F 0.22-1W J A...................

R 249 87-A00-258-080 0E RES,M/F 0.22-1W J A...................

R 250 87-A00-258-080 0E RES,M/F 0.22-1W J A...................

C 308 87-010-263-080 0E CAP, ELECT 100-10V A...................

C 307 87-010-263-080 0E CAP, ELECT 100-10V A...................

C 309 87-018-115-080 0E CAP, CER 47P-50V ....................

C 301 87-018-130-080 0E CAP,TC-U 820P-50 B A...................

C 303 87-018-130-080 0E CAP,TC-U 820P-50 B A...................

C 304 87-018-130-080 0E CAP,TC-U 820P-50 B A...................

C 302 87-018-130-080 0E CAP,TC-U 820P-50 B A...................

C 315 87-010-374-080 0E CAP, ELECT 47-10V A...................

C 317 87-010-546-080 0E CAP, ELECT 0.33-50V A...................

C 318 87-010-546-080 0E CAP, ELECT 0.33-50V A...................

C 310 87-018-115-080 0E CAP, CER 47P-50V ....................

C 361 87-010-374-080 0E CAP, ELECT 47-10V A...................

C 360 87-010-401-080 0E CAP, ELECT 1-50V A...................

C 401 87-010-401-080 0E CAP, ELECT 1-50V A...................

C 402 87-010-401-080 0E CAP, ELECT 1-50V A...................

C 404 87-018-118-080 0E CAP,TC-U 82P-50 B A...................

C 403 87-018-118-080 0E CAP,TC-U 82P-50 B A...................

C 412 87-010-405-080 0E CAP, ELECT 10-50V A...................

C 411 87-010-405-080 0E CAP, ELECT 10-50V A...................

C 452 87-010-382-080 0E CAP, ELECT 22-25V A...................

C 459 87-018-128-080 0E CAP, CERA-SOL SS 560P A...................

C 458 87-018-131-080 0E CAP, CER 1000P-50V A...................

C 461 87-018-126-080 0E CAP,TC-U 390P-50 B A...................

C 462 87-018-126-080 0E CAP,TC-U 390P-50 B A...................

CON 301 87-099-827-010 0E CONN,3P S2M-3W A...................

CON 351 87-099-832-010 0E CONN,8P S2M-8W A...................

D 401 87-A40-291-080 0E DIODE,1N4148 (CPT) A...................

FB 301 87-008-372-080 0E FILTER, EMI BL OIRNI ....................

IC 301 87-017-889-010 1A IC,NJM4558LD A...................

IC 401 87-017-889-010 1A IC,NJM4558LD A...................

JW 307 87-008-372-080 0E FILTER, EMI BL OIRNI ....................

JW 305 87-008-372-080 0E FILTER, EMI BL OIRNI ....................

L 451 87-007-342-010 0E COIL,OSC 85K BIAS A...................

Q 303 87-A30-090-080 0E FET,2SK2541 A...................

Q 304 87-A30-090-080 0E FET,2SK2541 A...................

Q 301 87-A30-091-080 1E FET,2SJ460 A...................

Q 302 87-A30-091-080 1E FET,2SJ460 A...................

Q 307 87-A30-091-080 1E FET,2SJ460 ....................

Q 305 87-A30-091-080 1E FET,2SJ460 ....................

Q 308 87-A30-091-080 1E FET,2SJ460 ....................

Q 305 87-A30-151-080 0E TR,2SA1993F A...................

Q 307 87-A30-151-080 0E TR,2SA1993F A...................

Q 308 87-A30-151-080 0E TR,2SA1993F A...................

Q 309 87-A30-151-080 0E TR,2SA1993F A...................

Q 306 87-A30-154-080 0E TR,RT1N441S A...................

Q 310 87-A30-151-080 0E TR,2SA1993F A...................

Q 442 87-A30-151-080 0E TR,2SA1993F A...................

Q 443 87-A30-151-080 0E TR,2SA1993F A...................

Q 455 87-A30-152-080 0E TR,2SC5395F ....................

Q 453 89-333-317-880 0E TR,2SC3331 (0.5W) A...................

Q 451 89-333-317-880 0E TR,2SC3331 (0.5W) A...................

Q 454 89-333-317-880 0E TR,2SC3331 (0.5W) A...................

R 325 87-A40-291-080 0E DIODE,1N4148 (CPT) ....................

SFR 451 87-A90-636-080 0E SFR,33K H RH0638C LG A...................

SFR 452 87-A90-636-080 0E SFR,33K H RH0638C LG A...................

C 602 87-018-130-080 0E CAP,TC-U 820P-50 B A...................

C 601 87-018-130-080 0E CAP,TC-U 820P-50 B A...................

C 619 87-010-401-080 0E CAP, ELECT 1-50V A...................

C 616 87-010-408-080 0E CAP, ELECT 47-50V A...................

C 617 87-010-408-080 0E CAP, ELECT 47-50V A...................

C 613 87-010-545-080 0E CAP, ELECT 0.22-50V A...................

C 611 87-010-545-080 0E CAP, ELECT 0.22-50V A...................

C 614 87-010-545-080 0E CAP, ELECT 0.22-50V A...................

C 612 87-010-545-080 0E CAP, ELECT 0.22-50V A...................

C 615 87-018-104-080 0E CAP,TC-U 10P-50 SL A...................

C 620 87-010-401-080 0E CAP, ELECT 1-50V A...................

CON 602 87-099-014-010 0E CONN,12P 6216 V A...................

CON 601 87-099-719-010 1B CONN,30P TYK-B(X) ....................

CON 601 87-A60-349-010 1A CONN 30P DF8A-30S A...................

D 601 87-A40-466-080 0E ZENER,MTZJ2.7A A...................

D 602 87-A40-466-080 0E ZENER,MTZJ2.7A A...................

FB 601 87-008-372-080 0E FILTER, EMI BL OIRNI ....................

IC 602 87-001-486-080 0E FUSE, ICP-N15 ....................

IC 601 87-A20-715-010 1C IC,M62439SP A...................

J 601 87-A60-398-010 0E JACK,PIN 2P R/W HSP-242V24 A...................

C 131 87-010-263-080 0E CAP, ELECT 100-10V ....................

C 132 87-010-380-080 0E CAP, ELECT 47-16V ....................

C 133 87-010-401-080 0E CAP, ELECT 1-50V ....................

D 131 87-A40-291-080 0E DIODE,1N4148 (CPT) ....................

D 130 87-A40-291-080 0E DIODE,1N4148 (CPT) ....................

ELECTRICAL MAIN PARTS LIST - 4/6

PIN 101 87-A60-109-010 0E CONN,2P V S2M-2W ....................

PIN 102 87-A60-110-010 0E CONN,4P V S2M-4W ....................

Q 122 87-026-609-080 0E TR,KTA1266GR ....................

Q 121 87-A30-152-080 0E TR,2SC5395F ....................

C 707 87-010-112-080 0E CAP, ELECT 100-16V A...................

C 709 87-010-248-080 0E CAP, ELECT 220-10V A...................

C 701 87-010-404-080 0E CAP, ELECT 4.7-50V A...................

C 704 87-018-131-080 0E CAP, CER 1000P-50V A...................

C 705 87-018-131-080 0E CAP, CER 1000P-50V A...................

C 706 87-018-131-080 0E CAP, CER 1000P-50V A...................

C 703 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 A...................

C 702 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 A...................

C 710 87-010-112-080 0E CAP, ELECT 100-16V A...................

C 715 87-018-119-080 0E CAP, CER 100P-50V ....................

C 713 87-018-149-080 0E CAP,TC-U 15P-50 CH A...................

C 712 87-018-149-080 0E CAP,TC-U 15P-50 CH A...................

D 701 87-A40-302-080 0E ZENER,DZ5.6M A...................

IC 701 87-070-127-110 1D IC,LC72131 D A...................

L 701 87-005-847-080 0E COIL,2.2UH(CECS) A...................

Q 701 87-A30-196-080 0E TR,2SC4115SRS A...................

R 723 87-A00-320-080 1B RES,M/F 3.3-1/4W F SN2E ....................

X 701 87-A70-061-010 1A VIB,XTAL 4.500MHZ CSA-309 A...................

C 738 87-010-260-080 0E CAP, ELECT 47-25V A...................

C 732 87-010-404-080 0E CAP, ELECT 4.7-50V A...................

C 733 87-010-545-080 0E CAP, ELECT 0.22-50V A...................

C 731 87-010-545-080 0E CAP, ELECT 0.22-50V A...................

C 734 87-010-545-080 0E CAP, ELECT 0.22-50V A...................

C 735 87-018-132-080 0E CAP, CER 2200P-16V A...................

C 736 87-018-132-080 0E CAP, CER 2200P-16V A...................

C 737 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 A...................

C 743 87-010-101-080 0E CAP, ELECT 220-16 A...................

C 742 87-010-400-080 0E CAP, ELECT 0.47-50V A...................

C 741 87-010-404-080 0E CAP, ELECT 4.7-50V A...................

C 740 87-018-127-080 0E CAP, CER 470P-50V A...................

C 746 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 A...................

D 702 87-A40-291-080 0E DIODE,1N4148 (CPT) ....................

D 731 87-A40-291-080 0E DIODE,1N4148 (CPT) A...................

IC 731 87-A20-716-010 1E IC,TA2040AP A...................

Q 731 87-A30-155-080 0E TR,RT1P141S A...................

X 731 87-030-394-010 1B VIB,CER CSA3.6MGF228 A...................

C 758 87-010-112-080 0E CAP, ELECT 100-16V A...................

C 753 87-010-408-080 0E CAP, ELECT 47-50V A...................

C 757 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 A...................

C 759 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 A...................

C 756 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 ....................

C 752 87-018-143-080 0E CAP,TC-U 4.7P-50 CH A...................

C 762 87-010-400-080 0E CAP, ELECT 0.47-50V A...................

C 764 87-010-401-080 0E CAP, ELECT 1-50V A...................

C 763 87-010-401-080 0E CAP, ELECT 1-50V A...................

C 769 87-010-403-080 0E CAP, ELECT 3.3-50V A...................

C 761 87-010-404-080 0E CAP, ELECT 4.7-50V A...................

C 766 87-010-407-080 0E CAP, ELECT 33-50V A...................

C 765 87-018-115-080 0E CAP, CER 47P-50V A...................

C 768 87-018-208-080 0E CAP 0.047-50F A...................

C 774 87-010-405-080 0E CAP, ELECT 10-50V A...................

C 771 87-010-406-080 0E CAP, ELECT 22-50 A...................

C 773 87-018-131-080 0E CAP, CER 1000P-50V A...................

C 770 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 A...................

C 773 87-018-195-080 0E CAP, CER 1200P-16V ....................

C 773 87-018-196-080 0E CAP, CER 1500P-16V ....................

C 785 87-010-405-080 0E CAP, ELECT 10-50V A...................

C 786 87-010-405-080 0E CAP, ELECT 10-50V A...................

C 789 87-010-546-080 0E CAP, ELECT 0.33-50V A...................

C 787 87-018-132-080 0E CAP, CER 2200P-16V ....................

C 788 87-018-132-080 0E CAP, CER 2200P-16V ....................

C 788 87-018-196-080 0E CAP, CER 1500P-16V A...................

C 787 87-018-196-080 0E CAP, CER 1500P-16V A...................

C 783 87-018-202-080 0E CAP.CERAM.6800PF ....................

C 784 87-018-202-080 0E CAP.CERAM.6800PF ....................

C 790 87-010-546-080 0E CAP, ELECT 0.33-50V A...................

D 752 87-A40-291-080 0E DIODE,1N4148 (CPT) A...................

D 751 87-A40-291-080 0E DIODE,1N4148 (CPT) A...................

IC 751 87-A20-438-010 1D IC,LA1837 A...................

IC 751 87-A20-913-010 1D IC,LA1837NL ....................

L 751 87-A50-165-010 1A COIL,FM DET-N(TOK) A...................

L 752 87-A90-053-010 1C FLTR,PCFMT-060(TOK) A...................

L 771 87-A50-165-010 1A COIL,FM DET-N(TOK) ....................

L 771 87-A50-266-010 1A COIL,FM DET-2N(TOK) ....................

L 772 87-A90-051-010 1B FLTR,CFAZ-450(TOK) ....................

L 772 87-A90-733-010 1B FLTR,PCFAZH-450 (TOK) ....................

C 856 87-010-405-080 0E CAP, ELECT 10-50V ....................

C 855 87-010-405-080 0E CAP, ELECT 10-50V ....................

C 859 87-018-109-080 0E CAP, CER 22P-50V ....................

C 858 87-018-109-080 0E CAP, CER 22P-50V ....................

C 851 87-018-123-080 0E CAP, CER 220P-50V ....................

C 852 87-018-123-080 0E CAP, CER 220P-50V ....................

C 853 87-018-127-080 0E CAP, CER 470P-50V ....................

C 857 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 ....................

C 860 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 ....................

IC 851 87-A20-502-010 1H IC,BU1920 ....................

L 851 87-005-847-080 0E COIL,2.2UH(CECS) ....................

Q 851 87-A30-152-080 0E TR,2SC5395F ....................

ELECTRICAL MAIN PARTS LIST - 5/6

X 851 89-KT1-608-010 1C X,TAL,4.332MHZ ....................

C 808 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 A...................

C 804 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 A...................

C 803 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 A...................

C 801 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 ....................

C 802 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 ....................

C 809 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 A...................

C 812 87-010-408-080 0E CAP, ELECT 47-50V A...................

C 813 87-018-131-080 0E CAP, CER 1000P-50V ....................

C 810 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 A...................

C 811 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 A...................

C 924 87-014-049-080 0E CAP,PP 470P-100 J ....................

C 923 87-018-102-080 0E CAP,TC-U 6.8P-50 SL ....................

C 921 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 ....................

C 922 87-018-142-080 0E CAP,TC-U 3.9P-50 CH ....................

C 938 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 ....................

C 937 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 ....................

C 944 87-018-147-080 0E CAP,TC-U 10P-50 CH ....................

C 944 87-018-148-080 0E CAP,TC-U 12P-50 CH A...................

CF 802 82-785-747-010 1A CF MS2 GHY R ....................

CF 801 87-008-261-010 1A FILTER, SFE10.7MA5-A A...................

CF 802 87-008-261-010 1A FILTER, SFE10.7MA5-A A...................

CF 801 87-008-423-010 1A CERAMIC FILTER, SFE10.7 ....................

D 923 87-A40-291-080 0E DIODE,1N4148 (CPT) ....................

D 921 87-A40-291-080 0E DIODE,1N4148 (CPT) ....................

D 922 87-A40-291-080 0E DIODE,1N4148 (CPT) ....................

FFE 801 A8-6ZA-190-030 0E 6ZA-1 FEUNM ....................

FFE 801 A8-6ZA-191-130 6ZA-1 FEENM ....................

FFE 801 A8-6ZA-192-030 2Y 6ZA-1 FEJNM ....................

FFE 801 A8-6ZA-19B-070 6ZA-1 YFEUNC ....................

FFE 801 A8-6ZA-19C-170 6ZA-1 YFEENC ....................

FFE 801 A8-6ZA-19D-070 6ZA-1 YFEJNC A...................

J 801 87-033-239-010 1A TERMINAL,HSP-154V-2 A...................

J 801 87-A60-403-010 TERMINAL,ANT PAL 2P HSP-312V05 ....................

L 801 87-005-847-080 0E COIL,2.2UH(CECS) A...................

L 901 87-NF4-650-010 1D COIL,AM PACK 4N(TOK) A...................

L 942 87-A50-019-010 0E COIL,OSC LW(COI) ....................

L 941 87-A50-020-010 0E COIL,ANT LW(COI) ....................

L 981 87-NF4-650-010 1D COIL,AM PACK 4N(TOK) ....................

L 981 87-NF4-651-010 1D COIL,AM PACK2N(TOM) ....................

Q 801 87-A30-156-080 0E TR,RT1P144S A...................

Q 803 89-305-352-380 0E TR,2SC535(B/C) A...................

Q 935 87-A30-092-080 0E FET,2SK439E/F ....................

Q 933 87-A30-164-080 0E TR,CSC2001K ....................

Q 941 87-A30-155-080 0E TR,RT1P141S ....................

Q 942 87-A30-164-080 0E TR,CSC2001K ....................

TC 942 87-011-221-080 1A CAP, TRIMMER 30P ....................

87-A60-317-010 0E TERMINAL, 1P MSC A...................

C 131 87-010-263-080 0E CAP, ELECT 100-10V A...................

C 132 87-010-380-080 0E CAP, ELECT 47-16V A...................

C 133 87-010-401-080 0E CAP, ELECT 1-50V A...................

D 130 87-A40-291-080 0E DIODE,1N4148 (CPT) A...................

D 131 87-A40-291-080 0E DIODE,1N4148 (CPT) A...................

FC 101 87-033-147-010 0E FUSE CLAMP A...................

FC 102 87-033-147-010 0E FUSE CLAMP A...................

PIN 101 87-A60-109-010 0E CONN,2P V S2M-2W A...................

PIN 102 87-A60-110-010 0E CONN,4P V S2M-4W A...................

Q 122 87-026-609-080 0E TR,KTA1266GR A...................

Q 121 87-A30-152-080 0E TR,2SC5395F A...................

SW 101 87-A90-234-010 1A SW,SL 1-2-2 SW2201 A...................

ELECTRICAL MAIN PARTS LIST - 6/6

NOTE: The characters in the suffix column indicate the part usage.

SNH33MDHD ..............XX..................................A...................

KANRI

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

87-NB8-901-310 2A IB,D(J)I ....................

87-NB8-903-110 2A IB,D(J)I-H35 ....................

87-NB8-904-110 2A IB,D(J)I-H37 ....................

87-NB8-907-210 2A IB,D(J)I-3000 ....................

87-NB8-909-110 2A IB,U(ESF)I ....................

87-NB8-913-110 2A IB,HD(EC)I A...................

87-NB8-914-010 1B IB,HD(EC)M ....................

87-NB8-915-110 1D IB,K(E)I ....................

87-NB8-916-010 2Y IB,E(9L)I ....................

87-NB8-918-010 IB,D(J)M-H35 ....................

87-NB8-919-010 IB,D(J)M-H37 ....................

87-NB8-920-010 IB,D(J)M-3000 ....................

87-NB8-921-010 1B IB,D(J)M ....................

87-NB8-923-010 IB,U(ESF)M ....................

87-NB8-925-010 IB,K(E)M ....................

87-NB8-926-010 IB,E(9L)M ....................

87-009-724-010 1B PLUG,CONVERSION IR39 A...................

87-043-106-010 1A WIRE, FM ANT (Z) ....................

87-043-115-010 1A ANT,FEEDER FM A...................

88-NF8-691-010 1H RC UNIT,RC-7AS06 A...................

ANT 0 87-006-225-010 1D AM LOOP ANT NC2 A...................

ACCESSORIES/PACKAGE LIST - 1

NOTE: The characters in the suffix column indicate the part usage.

SNH33MDHD ..............XX..................................A...................

KANRI

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

86-NF6-007-010 1C WINDOW,TOP A...................

86-NF6-101-010 1D WINDOW TOP UL ....................

87-NB8-001-410 2A CABI,FR D ....................

87-NB8-002-010 1C CABI,REAR S ....................

87-NB8-003-010 1C BOX,CASS 1 A...................

87-NB8-004-010 1C BOX,CASS 2 A...................

87-NB8-005-010 1C PANEL,LEFT A...................

87-NB8-006-010 1C PANEL,RIGHT A...................

87-NB8-007-010 1B PANEL,TRAY A...................

87-NB8-008-110 2A PANEL,FR A...................

87-NB8-009-010 1A WINDOW,CD A...................

87-NB8-010-010 1B WINDOW,DISPLAY A...................

87-NB8-012-010 0E WINDOW,CASS 1 A...................

87-NB8-013-010 0E WINDOW,CASS 2 A...................

87-NB8-014-010 1B WINDOW,FLAP N A...................

87-NB8-031-210 2A CABI,FR D35 ....................

87-NB8-032-210 2A CABI,FR D37 ....................

87-NB8-033-210 2A CABI,FR D3000 ....................

87-NB8-034-210 2A CABI,FR U ....................

87-NB8-035-210 2A CABI,FR H A...................

87-NB8-036-210 2A CABI,FR E ....................

87-NB8-041-010 1C CABI,REAR S35 ....................

87-NB8-042-010 1C CABI,REAR S37 ....................

87-NB8-043-010 1C CABI,REAR S3000 ....................

87-NB8-044-010 1C CABI,REAR US ....................

87-NB8-046-010 1C CABI,REAR EZS ....................

87-NB8-047-210 1C CABI,REAR KS ....................

87-NB8-049-010 1C CABI,REAR SNM ....................

87-NB8-050-010 1D CABI,REAR HDS A...................

87-NB8-051-010 1C PANEL,LEFT U ....................

87-NB8-052-010 1C PANEL,RIGHT U ....................

87-NB8-053-010 1C BOX,CASS 1 ST ....................

87-NB8-054-010 1C BOX,CASS 2 ST ....................

87-NB8-055-010 1B PANEL,TRAY ST ....................

87-NB8-056-010 CABI,REAR SNM35 ....................

87-NB8-057-010 CABI,REAR SNM37 ....................

87-NB8-058-010 CABI,REAR SNM3000 ....................

87-NB8-059-010 CABI,REAR USNM ....................

87-NB8-060-010 CABI,REAR EZSNM ....................

87-NB8-061-010 CABI,REAR KSNM ....................

87-NB8-062-010 1D CABI,REAR HDSNM ....................

87-NB8-065-010 1B WINDOW,DISPLAY E ....................

87-NF6-021-010 1C PANEL,TOP A...................

87-NB8-015-010 1B KNOB,RTRY VOL A...................

87-NB8-017-010 0E KNOB,RTRY MIC A...................

87-NB8-019-010 0E KEY,POWER A...................

87-NB8-020-010 1B KEY,FUNCTION A...................

87-NB8-021-110 1B KEY,GEQ A...................

87-NB8-022-010 1A KEY,T-BASS A...................

87-NB8-024-010 1D KEY,CD A...................

87-NB8-025-110 1C KEY,MD REC A...................

87-NB8-026-010 1B KEY,MD EJECT A...................

87-NB8-027-110 1C KEY,MD ENTER(*) A...................

87-NB8-028-010 1B KEY,RDS ....................

87-NB8-030-110 1E KEY,ASSY PLAY A...................

88-NF8-016-010 1A KNOB,RTRY JOG A...................

81-532-080-010 1A LABEL, CASS. COMPT A...................

87-NF6-616-010 1B CONN ASSY,8P RPB A...................

84-ZG1-245-210 0E CAP,OPTICAL A...................

82-NF5-218-010 0E SPR-T,EJECT 1 (SIN) A...................

82-NF5-219-010 0E SPR-T,EJECT 2 (SIN) A...................

82-NF5-229-010 0E PLATE,LOCK A...................

86-NF9-224-010 0E SPR-C,LOCK A...................

87-NB8-210-010 0E SPR-T,FLAP A...................

87-NBG-206-010 1B HLDR,FAN A...................

87-NF4-216-010 0E HLDR,LOCK 1 A...................

87-NF4-217-010 0E HLDR,LOCK 2 A...................

87-NF4-221-010 0E HLDR,CABLE A...................

87-NF8-220-010 1A DMPR,150 A...................

88-NF5-208-010 0E HLDR,PWB-M N A...................

87-067-584-010 0E TAPPING SCREW, BVT2+3-6 A...................

87-067-688-010 0E BVTT+3-6 A...................

87-067-703-010 0E TAPPING SCREW, BVT2+3-10 A...................

87-078-019-010 0E S-SCREW,IT+4-6 A...................

87-721-096-410 0E QT2+3-10 GLD A...................

87-721-097-410 0E QT2+3-12 GLD A...................

87-723-096-410 0E QT2+3-10W/O SLOT BL A...................

87-B10-184-010 0E BVTT+3-20 W/O SLOT A...................

87-NF4-224-010 0E S-SCREW,IT3B+3-8 CU A...................

87-003-317-010 1C F-BEAD,F0H2515-LG7 ....................

87-050-053-010 1B AC CORD ASSY,U-2 ....................

87-050-079-010 1C AC-CORD ASSY,E ....................

87-050-097-010 1A AC CORD ASSY,H A...................

87-050-098-010 1B AC CODE ASSY,D ....................

87-085-184-010 0E BUSHING, AC CORD (D) A...................

87-085-185-010 0E BUSHING, AC CORD (E) ....................

MECHANICAL PARTS LIST - 1/2

87-085-189-010 0E BUSHING, CORD (U) ....................

87-A80-007-110 1F AC CORD ASSY,K BLK ....................

87-A90-296-210 2M MOT ASSY,F614R-12MC-15 A...................

88-906-171-110 0E FF-CABLE,6P 1.25 A...................

88-907-251-110 1A FF-CABLE, 7P 1.25 A...................

88-912-151-110 1A FF-CABLE, 12P 1.25 A...................

88-913-271-110 1A FF-CABLE, 13P 1.25 A...................

88-915-091-110 1A FF-CABLE, 15P 1.25 A...................

C 239 87-010-402-080 0E CAP, ELECT 2.2-50V ....................

C 240 87-010-402-010 0E CAP,ELECT 2.2-50SME ....................

C 258 87-018-119-080 0E CAP, CER 100P-50V ....................

C 260 87-018-131-080 0E CAP, CER 1000P-50V ....................

C 261 87-018-131-080 0E CAP, CER 1000P-50V ....................

C 495 87-018-209-080 0E CAP, CER 0.1-50V ....................

C 491 87-018-209-080 0E CAP, CER 0.1-50V ....................

C 490 87-018-209-080 0E CAP, CER 0.1-50V ....................

C 800 87-018-134-080 0E CAPACITOR,TC-U 0.01-16 A...................

D 105 87-A40-470-080 0E DIODE,1SS254 ....................

F 101 87-035-223-010 1A FUSE, 1.25AT ....................

F 101 87-035-224-010 1A FUSE, 1.6AT A...................

F 101 87-035-413-010 1A FUSE T 1.6A 250V UL ....................

F 101 87-035-414-010 1A FUSE, T2A 250V UL ....................

PT 101 87-NB8-606-010 2Y PT,7NB-8D ....................

PT 101 87-NB8-610-010 2Y PT,7NB-8HD A...................

PT 101 87-NB8-627-010 2D PT,7NB-8EZ ....................

PT 101 87-NB8-628-010 2D PT,7NB-8K ....................

PT 101 88-NF8-604-010 2Y PT,8NF-8U ....................

87-NB8-204-010 1A GUIDE,FL 125-29-6.6 A...................

87-NB8-206-010 1A GUIDE,PLAY A...................

WH 101 87-064-168-010 0E HOLDER,WIRE(U)2.5-7P A...................

87-067-703-010 0E TAPPING SCREW, BVT2+3-10 A...................

W 101 83-NE2-618-110 1B F-CABEL,5P-2.5 A...................

WH 102 87-064-168-010 0E HOLDER,WIRE(U)2.5-7P A...................

87-A60-317-010 0E TERMINAL, 1P MSC A...................

MECHANICAL PARTS LIST - 2/2

Other manuals for XR-H33MD

Table of contents

Popular Stereo Receiver manuals by other brands

Marantz

Marantz CINEMA 70S owner's manual

Kenwood

Kenwood KMDX92 instruction manual

Yamaha

Yamaha RX-830 owner's manual

Pioneer

Pioneer AVH-Z7250BT owner's manual

Yamaha

Yamaha RX-750 owner's manual

Denon

Denon AVR-1311 owner's manual

Denon

Denon AVR-S760H owner's manual

Denon

Denon AVR-X7200W Service manual

Pioneer

Pioneer SC-LX904 Initial setup guide

Sony

Sony XAV-1500 operating instructions

Radio Shack

Radio Shack DX-399 owner's manual

Sony

Sony STR-DE535 - Fm Stereo/fm-am Receiver operating instructions

Pioneer

Pioneer SX-1000TA operating instructions

Yamaha

Yamaha MusicCast TSR-5B3D owner's manual

Sony

Sony STR-DE335 - Fm Stereo/fm-am Receiver operating instructions

Sony

Sony STR-DG500 - Multi Channel Av Receiver Service manual

Panasonic

Panasonic AJSD955B - DVCPRO50 STUDIO DECK Brochure & specs

Pioneer

Pioneer SX-838 Service manual

Aiwa XR-H33MD Instructions for use

Popular Stereo Receiver manuals by other brands
