S E R V I C E M A N U A L

SIMPLE MANUAL

•Replace this Service Manual with ”Revision Publishing” when it is issued.

LCX-133

• TYPE: LH

S/M Code No. 09–98C–318–0T1

COMPACT DISC STEREO SYSTEM

ELECTRICAL MAIN PARTS LIST - 1

NOTE: The characters in the suffix column indicate the part usage.

LH .....................XX..................................A...................

KANRI

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

* 8Z-CL8-201-010 GUIDE,LCD A...................

C 161 87-010-178-080 CHIP CAP 1000P A...................

C 209 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 203 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 201 87-010-375-080 CAP,E 330-10 SME A...................

C 202 87-012-350-080 C-CAP,1-25 F A...................

C 208 87-015-819-080 CAPACITOR,0.01 A...................

C 213 87-010-154-080 CAP CHIP 10P A...................

C 210 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 217 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 215 87-010-312-080 C-CAP,S 15P-50 CH ....................

C 211 87-010-314-080 C-CAP,S 22P-50V ....................

C 212 87-010-318-080 C-CAP,S 47P-50 CH A...................

C 216 87-010-400-080 CAP, ELECT 0.47-50V A...................

C 214 87-012-149-080 C-CAP,S 30P-50 CH A...................

CN 201 87-099-720-010 CONN,30P TYK-B(P) A...................

CN 202 87-A60-404-010 CONN,3P TKX-P03P-F1 A...................

D 3 87-020-465-080 DIODE,1SS133 (110MA) A...................

D 205 87-020-027-080 CHIP-DIODE 1SS184 A...................

D 204 87-020-027-080 CHIP-DIODE 1SS184 ....................

D 203 87-020-027-080 CHIP-DIODE 1SS184 ....................

D 202 87-020-465-080 DIODE,1SS133 (110MA) A...................

D 201 87-020-465-080 DIODE,1SS133 (110MA) A...................

D 209 87-020-465-080 DIODE,1SS133 (110MA) A...................

D 211 87-020-465-080 DIODE,1SS133 (110MA) A...................

D 212 87-027-825-080 ZENER,HZ9A3L A...................

D 949 87-A40-365-040 LED,L-1154 SGD A...................

D 947 87-A40-365-040 LED,L-1154 SGD A...................

D 942 87-A40-365-040 LED,L-1154 SGD A...................

D 948 87-A40-365-040 LED,L-1154 SGD A...................

D 944 87-A40-365-040 LED,L-1154 SGD A...................

D 941 87-A40-365-040 LED,L-1154 SGD A...................

D 946 87-A40-365-040 LED,L-1154 SGD A...................

D 945 87-A40-365-040 LED,L-1154 SGD A...................

D 943 87-A40-365-040 LED,L-1154 SGD A...................

FB 2 87-A90-896-080 F-BEAD, 035600STY7 A...................

IC 202 87-A20-914-010 IC,SPS-442-1-F A...................

IC 201 8Z-CL8-661-010 IC,LC867240A A...................

L 206 87-003-098-080 COIL,2.2UH A...................

LCD 201 8Z-CL8-665-010 LCD,ZCL-8 A...................

Q 202 87-026-223-080 TR,DTC143TK A...................

Q 201 87-026-237-080 CHIP-TR,DTC124XK A...................

Q 203 89-320-011-080 TR,2SC2001 (15W) A...................

S 206 87-A90-095-080 SW,TACT EVQ11G04M A...................

S 207 87-A90-095-080 SW,TACT EVQ11G04M A...................

S 203 87-A90-095-080 SW,TACT EVQ11G04M A...................

S 208 87-A90-095-080 SW,TACT EVQ11G04M A...................

S 205 87-A90-095-080 SW,TACT EVQ11G04M A...................

S 204 87-A90-095-080 SW,TACT EVQ11G04M A...................

S 201 87-A90-095-080 SW,TACT EVQ11G04M A...................

S 209 87-A90-095-080 SW,TACT EVQ11G04M A...................

S 211 87-A90-095-080 SW,TACT EVQ11G04M A...................

S 215 87-A90-095-080 SW,TACT EVQ11G04M A...................

S 210 87-A90-095-080 SW,TACT EVQ11G04M A...................

S 213 87-A90-095-080 SW,TACT EVQ11G04M A...................

S 214 87-A90-095-080 SW,TACT EVQ11G04M A...................

S 212 87-A90-095-080 SW,TACT EVQ11G04M A...................

X 201 87-030-364-010 VIB,XTAL 32.768K CT ....................

X 202 87-A70-185-010 VIB,CER 5.76MHZ TF21 A...................

8Z-CL8-682-010 FF-CABLE, 16P 1.0 180MM A...................

C 5 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 8 87-010-198-080 CAP, CHIP 0.022 A...................

C 4 87-010-248-080 CAP, ELECT 220-10V A...................

C 9 87-010-263-080 CAP, ELECT 100-10V A...................

C 6 87-010-374-080 CAP, ELECT 47-10V A...................

C 3 87-010-401-040 CAP,E 1-50 SME A...................

C 1 87-010-406-080 CAP, ELECT 22-50 A...................

C 17 87-010-178-080 CHIP CAP 1000P A...................

C 15 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 13 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 18 87-010-213-080 C-CAP,S 0.015-50 B A...................

C 10 87-010-263-080 CAP, ELECT 100-10V A...................

C 12 87-010-401-080 CAP, ELECT 1-50V A...................

C 14 87-010-405-080 CAP, ELECT 10-50V A...................

C 16 87-010-546-080 CAP, ELECT 0.33-50V A...................

C 29 87-010-178-080 CHIP CAP 1000P A...................

C 24 87-010-180-080 C-CER 1500P A...................

C 39 87-010-178-080 CHIP CAP 1000P A...................

C 34 87-010-186-080 CAP,CHIP 4700P A...................

C 38 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 35 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 36 87-010-374-080 CAP, ELECT 47-10V A...................

C 33 87-010-403-080 CAP, ELECT 3.3-50V A...................

C 37 87-010-404-080 CAP, ELECT 4.7-50V A...................

C 32 87-010-406-080 CAP, ELECT 22-50 A...................

C 31 87-010-545-080 CAP, ELECT 0.22-50V A...................

ELECTRICAL MAIN PARTS LIST - 2

C 30 87-012-140-080 CAP 470P A...................

C 40 87-010-147-080 C-CAP,S 3P-50 CH A...................

C 44 87-010-176-080 C-CAP,S 680P-50 SL A...................

C 45 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 46 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 42 87-010-313-080 CAP, CHIP 18P A...................

C 48 87-010-315-080 C-CAP,S 27P-50 CH A...................

C 59 87-010-263-080 CAP, ELECT 100-10V A...................

C 58 87-010-314-080 C-CAP,S 22P-50V A...................

C 57 87-010-314-080 C-CAP,S 22P-50V A...................

C 60 87-010-178-080 CHIP CAP 1000P A...................

C 61 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 62 87-010-248-080 CAP, ELECT 220-10V A...................

C 65 87-010-404-080 CAP, ELECT 4.7-50V A...................

C 77 87-010-112-080 CAP, ELECT 100-16V A...................

C 73 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 78 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 72 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 74 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 71 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 83 87-010-178-080 CHIP CAP 1000P A...................

C 84 87-010-178-080 CHIP CAP 1000P A...................

C 87 87-010-183-080 C-CAP,S 2700P-50 B A...................

C 86 87-010-183-080 C-CAP,S 2700P-50 B A...................

C 82 87-010-405-080 CAP, ELECT 10-50V A...................

C 81 87-010-405-080 CAP, ELECT 10-50V A...................

C 95 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 93 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 94 87-010-263-080 CAP, ELECT 100-10V A...................

C 91 87-010-380-080 CAP, ELECT 47-16V A...................

C 98 87-012-154-080 C-CAP,S 150P-50 CH A...................

C 96 87-016-459-040 CAP,E 470-10 SMG A...................

C 103 87-010-297-080 CAP CHIO 100P A...................

C 102 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 101 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 106 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 111 87-010-235-080 CAP,E 470-16 SME A...................

C 112 87-010-235-080 CAP,E 470-16 SME A...................

C 133 87-012-365-080 C-CAP,S 0.027-25VBK A...................

C 154 87-010-178-080 CHIP CAP 1000P A...................

C 157 87-010-178-080 CHIP CAP 1000P A...................

C 156 87-010-178-080 CHIP CAP 1000P A...................

C 151 87-010-194-080 CAP, CHIP 0.047 A...................

C 153 87-010-194-080 CAP, CHIP 0.047 A...................

C 159 87-010-309-080 C-CAP,1000P-50 CH A...................

C 158 87-012-359-080 C-CAP,S 0.68-10 FZ A...................

C 155 87-012-359-080 C-CAP,S 0.68-10 FZ A...................

C 152 87-012-359-080 C-CAP,S 0.68-10 FZ A...................

C 160 87-010-178-080 CHIP CAP 1000P A...................

C 163 87-010-318-080 C-CAP,S 47P-50 CH A...................

CN 3 87-009-034-010 CONN,6P PH V A...................

CN 5 87-009-345-010 CONN,2P PH H A...................

CN 4 87-A60-248-010 CONN,16P H CFF1416 A...................

CNA 0 8Z-CL8-681-010 CONN ASSY,6P CD MOTOR A...................

D 1 87-020-465-080 DIODE,1SS133 (110MA) A...................

D 2 87-020-465-080 DIODE,1SS133 (110MA) A...................

D 11 87-070-274-080 DIODE,1N4003 SEM A...................

FB 1 87-A90-896-080 F-BEAD, 035600STY7 A...................

FB 3 87-A90-896-080 F-BEAD, 035600STY7 A...................

IC 1 87-A20-446-010 C-IC,LA9241ML A...................

IC 2 87-A20-459-010 C-IC,LC78622ED A...................

IC 3 87-A20-856-010 IC,BA6898S A...................

PIN 1 86-NFZ-222-010 PIN,DIA1-6.5 A...................

PIN 2 86-NFZ-222-010 PIN,DIA1-6.5 ....................

Q 1 87-026-463-080 TR,2SA933S (0.3W) A...................

Q 91 87-026-210-080 CHIP-TR,DTC144EK A...................

Q 90 87-026-211-080 TR,DTA144EK A...................

Q 93 87-026-610-080 TR,KTC3198GR A...................

Q 94 89-112-965-080 TR,2SA1296 (0.75W) A...................

Q 92 89-213-702-010 TR,2SB1370 (1.8W) A...................

X 1 87-A70-182-010 VIB,XTAL 16.9344MHZ HC-49/U A...................

C 700 87-010-179-080 CAP,CHIP S B1200P ....................

C 701 87-010-179-080 CAP,CHIP S B1200P ....................

S 1 87-A90-178-010 SW SL1-1-2 A...................

T 1 87-A60-317-010 TERMINAL, 1P MSC A...................

T 2 87-A60-317-010 TERMINAL, 1P MSC A...................

C 209 87-010-213-080 C-CAP,S 0.015-50 B A...................

C 208 87-010-213-080 C-CAP,S 0.015-50 B A...................

C 205 87-010-401-080 CAP, ELECT 1-50V A...................

C 204 87-010-401-080 CAP, ELECT 1-50V A...................

C 203 87-010-405-080 CAP, ELECT 10-50V A...................

C 206 87-016-128-080 CAP,E 22-25 105 A...................

C 207 87-016-142-080 CAP,E 2.2-50 KME A...................

C 213 87-010-248-080 CAP, ELECT 220-10V A...................

C 219 87-010-385-080 CAP, ELECT 220-25V A...................

C 216 87-012-368-080 C-CAP,S 0.1-50 F A...................

C 215 87-016-133-080 CAP,E 330-25 KME A...................

C 217 87-016-142-080 CAP,E 2.2-50 KME A...................

C 222 87-010-237-080 CAP, ELECT 1000-16V A...................

C 220 87-010-237-080 CAP, ELECT 1000-16V A...................

C 221 87-010-385-080 CAP, ELECT 220-25V A...................

C 245 87-010-197-080 CAP, CHIP 0.01 DM A...................

ELECTRICAL MAIN PARTS LIST - 3

C 242 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 243 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 241 87-010-197-080 CAP, CHIP 0.01 DM A...................

D 201 87-020-465-080 DIODE,1SS133 (110MA) A...................

D 202 87-020-465-080 DIODE,1SS133 (110MA) A...................

IC 201 87-A20-734-010 IC,TDA2007A A...................

J 201 87-A60-420-010 JACK,3.5 ST (MSC) A...................

J 202 87-A60-754-010 TERMINAL,SPK 4P MSP-154V-05 A...................

L 202 87-005-366-010 COIL, 1UH A...................

L 201 87-005-366-010 COIL, 1UH A...................

Q 204 87-026-218-080 TR,DTC144ES (0.2W) A...................

Q 202 87-026-313-080 TR,DTC343TS A...................

Q 201 87-026-313-080 TR,DTC343TS A...................

Q 205 87-026-609-080 TR,KTA1266GR A...................

Q 203 89-213-702-010 TR,2SB1370 (1.8W) A...................

C 109 87-010-404-080 CAP, ELECT 4.7-50V A...................

C 126 87-010-190-080 S CHIP F 0.01 A...................

C 128 87-010-192-080 C-CAP,S 0.022-50 F A...................

C 129 87-010-192-080 C-CAP,S 0.022-50 F A...................

C 127 87-010-403-080 CAP, ELECT 3.3-50V A...................

C 125 87-010-928-090 CAP,E 4700-25 SMG A...................

C 135 87-010-101-080 CAP, ELECT 220-16 A...................

C 136 87-010-112-080 CAP, ELECT 100-16V A...................

C 134 87-010-178-080 CHIP CAP 1000P ....................

C 132 87-010-178-080 CHIP CAP 1000P ....................

C 133 87-010-178-080 CHIP CAP 1000P ....................

C 133 87-010-190-080 S CHIP F 0.01 A...................

C 132 87-010-190-080 S CHIP F 0.01 A...................

C 130 87-010-192-080 C-CAP,S 0.022-50 F A...................

C 131 87-010-192-080 C-CAP,S 0.022-50 F A...................

C 138 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 137 87-010-260-080 CAP, ELECT 47-25V A...................

C 143 87-010-263-080 CAP, ELECT 100-10V A...................

C 141 87-012-140-080 CAP 470P A...................

C 144 87-018-134-080 CAPACITOR,TC-U 0.01-16 A...................

CF 102 87-033-213-080 CLAMP, FUSE A...................

CF 101 87-033-213-080 CLAMP, FUSE A...................

D 101 87-020-465-080 DIODE,1SS133 (110MA) A...................

D 100 87-020-465-080 DIODE,1SS133 (110MA) A...................

D 102 87-020-465-080 DIODE,1SS133 (110MA) A...................

D 108 87-A40-393-090 DIODE,1N5402GW(F20) ....................

D 106 87-A40-393-090 DIODE,1N5402GW(F20) A...................

D 105 87-A40-393-090 DIODE,1N5402GW(F20) A...................

D 104 87-A40-393-090 DIODE,1N5402GW(F20) A...................

D 103 87-A40-393-090 DIODE,1N5402GW(F20) A...................

D 114 87-017-932-080 ZENER,MTJ6.2B A...................

D 116 87-020-465-080 DIODE,1SS133 (110MA) A...................

D 113 87-020-465-080 DIODE,1SS133 (110MA) A...................

D 115 87-070-334-080 ZENER,MTZJ10B A...................

F 101 87-035-416-010 FUSE,T3A 250V UL ....................

F 101 87-035-457-010 FUSE,3.15A 250V TW/C A...................

J 101 87-099-608-010 JACK, DC HEC3800 ....................

PR 101 87-026-689-080 PROTECTOR,1A 60V 491 A...................

PR 101 87-035-495-080 FUSE,3/4A 125V D/U/C ....................

PR 100 87-A90-069-080 FUSE,2A 125V 251 ....................

PR 100 87-A90-091-080 PROTECTOR,2A 491 A...................

Q 103 87-026-610-080 TR,KTC3198GR A...................

Q 108 87-026-610-080 TR,KTC3198GR A...................

Q 104 87-026-610-080 TR,KTC3198GR A...................

Q 106 87-026-610-080 TR,KTC3198GR A...................

Q 107 87-A30-185-010 TR,2SD1381FQR A...................

Q 111 87-026-610-080 TR,KTC3198GR A...................

Q 110 89-213-702-010 TR,2SB1370 (1.8W) A...................

R 130 87-A00-506-090 RES,FUSE 150-1/4W J A...................

W 2 8Z-CL8-690-010 F-CABLE,2P 2.5 180MM A...................

8Z-CL8-686-010 CONN ASSY,8P RPH A...................

C 408 87-010-248-080 CAP, ELECT 220-10V A...................

C 401 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 402 87-010-401-080 CAP, ELECT 1-50V A...................

C 407 87-010-405-080 CAP, ELECT 10-50V A...................

C 409 87-010-405-080 CAP, ELECT 10-50V A...................

C 405 87-010-406-080 CAP, ELECT 22-50 A...................

C 410 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 413 87-010-401-080 CAP, ELECT 1-50V A...................

C 412 87-010-406-080 CAP, ELECT 22-50 A...................

C 418 87-010-426-080 C-CAP,S 0.012-25 B A...................

C 415 87-010-426-080 C-CAP,S 0.012-25 B A...................

C 419 87-012-140-080 CAP 470P ....................

C 422 87-010-112-080 CAP, ELECT 100-16V A...................

C 429 87-010-178-080 CHIP CAP 1000P A...................

C 420 87-010-197-080 CAP, CHIP 0.01 DM ....................

C 430 87-010-178-080 CHIP CAP 1000P A...................

C 431 87-010-178-080 CHIP CAP 1000P A...................

C 432 87-010-264-080 CAP,E 100-10 5L A...................

C 434 87-015-695-080 CAP,E 1-50 7L A...................

CN 401 87-009-036-010 CONNECTOR, 8P PH V WHT A...................

D 405 87-020-465-080 DIODE,1SS133 (110MA) A...................

D 404 87-020-465-080 DIODE,1SS133 (110MA) A...................

IC 401 87-001-596-010 IC,NJM4580L A...................

L 401 88-CL6-609-010 COIL,BIAS 8CL6 A...................

Q 402 87-CD7-603-080 TR,SS8050 ....................

Q 403 87-CD7-603-080 TR,SS8050 A...................

ELECTRICAL MAIN PARTS LIST - 4

SW 401 8Z-CL8-668-010 SW,RP ZCL8 A...................

C 306 87-010-322-080 C-CAP,S 100P-50 CH A...................

C 301 87-010-401-080 CAP, ELECT 1-50V A...................

C 302 87-010-401-080 CAP, ELECT 1-50V A...................

C 309 87-010-545-080 CAP, ELECT 0.22-50V A...................

C 308 87-010-545-080 CAP, ELECT 0.22-50V A...................

C 305 87-010-545-080 CAP, ELECT 0.22-50V A...................

C 304 87-010-545-080 CAP, ELECT 0.22-50V A...................

C 311 87-010-182-080 C-CAP,S 2200P-50 B A...................

C 310 87-010-263-080 CAP, ELECT 100-10V A...................

C 312 87-010-263-080 CAP, ELECT 100-10V A...................

C 316 87-010-404-080 CAP, ELECT 4.7-50V A...................

C 319 87-010-404-080 CAP, ELECT 4.7-50V A...................

C 315 87-010-404-080 CAP, ELECT 4.7-50V A...................

C 314 87-010-405-080 CAP, ELECT 10-50V A...................

C 317 87-010-405-080 CAP, ELECT 10-50V A...................

C 318 87-010-405-080 CAP, ELECT 10-50V A...................

C 313 87-010-405-080 CAP, ELECT 10-50V A...................

C 320 87-010-404-080 CAP, ELECT 4.7-50V A...................

C 339 87-010-178-080 CHIP CAP 1000P ....................

C 335 87-010-197-080 CAP, CHIP 0.01 DM ....................

C 332 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 334 87-010-197-080 CAP, CHIP 0.01 DM ....................

C 337 87-010-197-080 CAP, CHIP 0.01 DM A...................

C 336 87-010-197-080 CAP, CHIP 0.01 DM A...................

CN 301 87-099-719-010 CONN,30P TYK-B(X) A...................

D 302 87-070-136-080 ZENER,MTZJ5.1B A...................

D 301 87-A40-347-080 ZENER,MTZJ2.2B A...................

IC 301 87-A20-715-010 IC,M62439SP A...................

J 301 87-A60-881-010 JACK,PIN 2P MSP 242V05 PBSN A...................

L 301 87-003-098-080 COIL,2.2UH A...................

Q 300 87-026-610-080 TR,KTC3198GR A...................

C 803 87-018-047-080 CAP, CER 0.01-16V ....................

C 814 87-012-286-080 CAP, U 0.01-25 ....................

C 812 87-012-286-080 CAP, U 0.01-25 A...................

C 828 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 829 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 820 87-010-260-080 CAP, ELECT 47-25V A...................

C 823 87-012-286-080 CAP, U 0.01-25 A...................

C 822 87-012-286-080 CAP, U 0.01-25 A...................

C 821 87-012-286-080 CAP, U 0.01-25 A...................

C 909 87-012-286-080 CAP, U 0.01-25 ....................

C 910 87-012-286-080 CAP, U 0.01-25 ....................

C 942 87-012-172-080 CAPACITOR CHIP U 10P CH ....................

C 940 87-012-286-080 CAP, U 0.01-25 ....................

C 947 87-012-286-080 CAP, U 0.01-25 ....................

C 949 87-A10-039-080 C-CAP,U 470P-50 J CH ....................

C 958 87-010-197-080 CAP, CHIP 0.01 DM ....................

C 959 87-010-831-080 C-CAP,U,0.1-16F A...................

C 952 87-012-286-080 CAP, U 0.01-25 ....................

C 963 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 960 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 962 87-010-401-080 CAP, ELECT 1-50V ....................

C 961 87-012-170-080 C-CAP,U 8P-50 CH A...................

CF 802 82-785-747-010 CF MS2 GHY R ....................

CF 801 87-008-261-010 FILTER, SFE10.7MA5-A A...................

CF 802 87-008-261-010 FILTER, SFE10.7MA5-A A...................

CF 801 87-008-423-010 CERAMIC FILTER, SFE10.7 ....................

D 944 87-020-465-080 DIODE,1SS133 (110MA) ....................

D 942 87-A40-270-080 C-DIODE,MC2838 ....................

FFE 801 A8-6ZA-19C-170 6ZA-1 YFEENC ....................

FFE 801 A8-6ZA-19D-070 6ZA-1 YFEJNC ....................

FFE 801 A8-8ZA-193-070 8ZA-1 YFEUNC A...................

J 801 87-A60-202-010 TERMINAL,ANT 4P MSP-154V-02 A...................

J 801 87-A60-880-010 TERMINAL,ANT-PAL 2P MSP-313V-0 ....................

L 832 87-005-847-080 COIL,2.2UH(CECS) ....................

L 942 87-A50-019-010 COIL,OSC LW(COI) ....................

L 941 87-A50-020-010 COIL,ANT LW(COI) ....................

L 981 87-NF4-650-010 COIL,AM PACK 4N(TOK) A...................

L 981 87-NF4-651-110 COIL,AM PACK2N(TOM) ....................

Q 806 87-A30-072-080 C-TR,RT1P 144C A...................

Q 805 89-327-143-080 TR,2SC2714 (0.1W) A...................

Q 948 87-A30-086-070 C-TR,CSD1306E ....................

Q 947 89-505-434-540 C-FET,2SK543(4/5) ....................

Q 951 87-A30-074-080 C-TR,RT1P 141C ....................

Q 952 87-A30-086-070 C-TR,CSD1306E ....................

TC 942 87-011-164-010 CAPACITOR,TRIMMER 30P ....................

C 731 87-012-286-080 CAP, U 0.01-25 A...................

C 758 87-012-167-080 C-CAP,U 5P-50 CH A...................

C 757 87-012-188-080 C-CAP,U 47P-50 CH A...................

C 753 87-012-195-080 C-CAP,U 100P-50CH ....................

C 756 87-012-286-080 CAP, U 0.01-25 A...................

C 755 87-012-286-080 CAP, U 0.01-25 ....................

C 761 87-010-196-080 CHIP CAPACITOR,0.1-25 ....................

C 766 87-010-197-080 CAP, CHIP 0.01 DM ....................

C 769 87-010-260-080 CAP, ELECT 47-25V A...................

C 763 87-010-829-080 CAP, U 0.047-16 A...................

C 768 87-012-286-080 CAP, U 0.01-25 A...................

C 762 87-012-286-080 CAP, U 0.01-25 ....................

C 765 87-012-286-080 CAP, U 0.01-25 A...................

C 764 87-012-337-080 C-CAP,U 56P-50 CH A...................

C 773 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 774 87-010-263-080 CAP, ELECT 100-10V A...................

C 771 87-010-383-080 CAP, ELECT 33-25V A...................

C 777 87-010-400-080 CAP, ELECT 0.47-50V A...................

C 778 87-010-401-080 CAP, ELECT 1-50V A...................

C 779 87-010-401-080 CAP, ELECT 1-50V A...................

C 775 87-010-404-080 CAP, ELECT 4.7-50V A...................

C 772 87-010-829-080 CAP, U 0.047-16 A...................

C 770 87-010-829-080 CAP, U 0.047-16 A...................

C 776 87-012-286-080 CAP, U 0.01-25 A...................

C 780 87-010-196-080 CHIP CAPACITOR,0.1-25 A...................

C 786 87-010-401-080 CAP, ELECT 1-50V A...................

C 785 87-010-401-080 CAP, ELECT 1-50V A...................

C 785 87-010-405-080 CAP, ELECT 10-50V ....................

C 786 87-010-405-080 CAP, ELECT 10-50V ....................

C 781 87-010-405-080 CAP, ELECT 10-50V A...................

C 782 87-010-405-080 CAP, ELECT 10-50V A...................

C 789 87-012-275-080 C-CAP,U 1200P-50 B A...................

C 787 87-012-284-080 CAP, U 6800P-50 ....................

C 788 87-012-284-080 CAP, U 6800P-50 ....................

C 783 87-012-286-080 CAP, U 0.01-25 A...................

C 784 87-012-286-080 CAP, U 0.01-25 A...................

C 796 87-010-403-080 CAP, ELECT 3.3-50V A...................

C 791 87-010-405-080 CAP, ELECT 10-50V A...................

C 794 87-010-406-080 CAP, ELECT 22-50 A...................

C 795 87-010-596-080 CAP, S 0.047-16 A...................

C 799 87-010-829-080 CAP, U 0.047-16 A...................

C 793 87-012-273-080 C-CAP,U 820P-50 B A...................

C 790 87-012-275-080 C-CAP,U 1200P-50 B A...................

C 793 87-012-275-080 C-CAP,U 1200P-50 B ....................

C 797 87-012-278-080 C-CAP,U 2200P-50 B A...................

C 798 87-012-278-080 C-CAP,U 2200P-50 B A...................

D 771 87-020-465-080 DIODE,1SS133 (110MA) ....................

D 773 87-020-465-080 DIODE,1SS133 (110MA) A...................

IC 771 87-A20-913-010 IC,LA1837NL A...................

L 771 87-A50-266-010 COIL,FM DET-2N(TOK) A...................

L 772 87-A90-733-010 FLTR,PCFAZH-450 (TOK) A...................

L 781 87-005-847-080 COIL,2.2UH(CECS) ....................

C 701 87-010-381-080 CAP, ELECT 330-16V A...................

C 702 87-010-404-080 CAP, ELECT 4.7-50V A...................

C 709 87-012-195-080 C-CAP,U 100P-50CH A...................

C 704 87-012-286-080 CAP, U 0.01-25 A...................

C 703 87-012-286-080 CAP, U 0.01-25 A...................

C 711 87-010-263-080 CAP, ELECT 100-10V A...................

ELECTRICAL MAIN PARTS LIST - 5

MECHANICAL PARTS LIST - 1

NOTE: The characters in the suffix column indicate the part usage.

LH .....................XX..................................A...................

KANRI

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

8Z-CL8-670-010 SPKR,WOOFER 4OHM 5W A...................

8Z-CL8-695-010 CORD,SPKR BLK A...................

8Z-CL8-101-010 CABI,FR SPKR A...................

8Z-CL8-102-010 CABI,REAR SPKR A...................

8Z-CL8-103-010 FRAME,SPKR A...................

87-067-581-010 TAPPING SCREW, BVT2+3-15 A...................

8Z-CL8-001-010 CABI,FR U A...................

8Z-CL8-005-010 CABI,FR B ....................

8Z-CL8-007-010 BOX,CASS A...................

8Z-CL8-008-010 PANEL,CASS A...................

8Z-CL8-011-010 CABI,REAR U ....................

8Z-CL8-013-010 CABI,REAR EZ ....................

8Z-CL8-014-010 CABI,REAR K ....................

8Z-CL8-019-010 LID,CD B ....................

8Z-CL8-020-010 LID,CD A...................

8Z-CL8-012-010 CABI,REAR LH A...................

8Z-CL8-021-010 CHAS,CD A...................

8Z-CL8-025-010 KEY,CONT A...................

8Z-CL8-027-010 KEY,POWER A...................

8Z-CL8-028-010 KEY,GEQ A...................

8Z-CL8-031-010 KEY,CONT B ....................

8Z-CL8-029-010 KEY,VOL A...................

8Z-CL8-030-010 KEY,CASS A...................

87-B00-002-010 BADGE,AIWA 30 ABS SIL A...................

8Z-CL8-023-010 WINDOW,CASS A...................

8Z-CLJ-022-010 WINDOW,DISP A...................

8Z-CL8-024-010 WINDOW,TOP A...................

86-CD0-223-010 COVER, CHUCK A...................

86-NFZ-231-010 DMPR,70 A...................

8Z-CL8-201-010 GUIDE,LCD A...................

8Z-CL8-204-010 CUSH,FOOT A...................

8Z-CL8-206-010 SPR-P,REC A...................

8Z-CL8-209-010 SPR-T,CASS A...................

87-036-368-010 MAGNET A...................

87-064-108-010 HLDR NC LATCH A...................

87-NF8-220-010 DMPR,150 A...................

88-CD9-211-110 RING,CHUCK A...................

88-CH6-019-010 PANEL,CD A...................

8Z-CL8-205-010 SPR-T,CD A...................

8Z-CL8-211-010 BASE,CHUCK A...................

87-761-096-410 VFT2+3-10 GLD A...................

87-067-703-010 TAPPING SCREW, BVT2+3-10 A...................

87-067-579-010 TAPPING SCREW, BVT2+3-8 A...................

87-571-033-410 TAPPING SCREW, VIT+2-4 A...................

87-651-036-410 VT1+2-8 A...................

87-342-074-010 UT2+2.6-8 A...................

87-B10-231-010 QT1+3-12 SILVER CR A...................

87-B10-230-010 BVT2+3-10 W/O SLOT SILVER CR A...................

87-067-758-010 BVT2+3-12 W/O SLOT A...................

87-050-098-010 AC CODE ASSY,D ....................

87-050-108-010 AC CORD ASSY,K 3PH ....................

87-A80-092-010 AC CORD ASSY,E BLK SUN FAI A...................

ACCESSORIES/PACKAGE LIST

NOTE: The characters in the suffix column indicate the part usage.

LH .....................XX..................................A...................

KANRI

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

8Z-CLJ-901-010 IB,LH (ESP)C A...................

8Z-CLJ-902-010 IB,E (9L)C ....................

8Z-CLJ-903-010 IB,K (E)C ....................

8Z-CLJ-905-010 IB,D (J)C ....................

8Z-CL8-670-010 SPKR,WOOFER 4OHM 5W A...................

8Z-CL8-695-010 CORD,SPKR BLK A...................

87-067-581-010 TAPPING SCREW, BVT2+3-15 A...................

87-067-703-010 TAPPING SCREW, BVT2+3-10 A...................

87-761-096-410 VFT2+3-10 GLD A...................

87-B00-002-010 BADGE,AIWA 30 ABS SIL A...................

8Z-CL8-101-010 CABI,FR SPKR A...................

8Z-CL8-102-010 CABI,REAR SPKR A...................

8Z-CL8-103-010 FRAME,SPKR A...................

8Z-CL8-204-010 CUSH,FOOT A...................

87-043-115-010 ANT,FEEDER FM A...................

87-A90-030-010 ANT,LOOP AM-NC C A...................

87-A90-118-010 ANT,WIRE FM (Z) ....................

87-A91-017-010 PLUG,CONVERSION JT-0476 A...................

8Z-CK4-951-010 RC UNIT,RC-ZAT03 ....................

8Z-CK4-952-010 RC UNIT,RC-ZAT04 A...................

SCHEMATIC DIAGRAM _1

SCHEMATIC DIAGRAM _2

Other manuals for LCX-133

Table of contents

Popular Stereo System manuals by other brands

Sony

Sony HCD-VX88 Service manual

Philips

Philips MCM398D/12 user manual

Sony

Sony CMT-SPZ90DB operating instructions

LG OM4560 owner's manual

JVC

JVC UX-G3 instructions

Odys

Odys ODYS - LOOP instruction manual

Panasonic

Panasonic SC-AK100 operating instructions

Sharp

Sharp CD-G10000V Operation manual

Bogen

Bogen NEARSCAPES 4.1 manual

Panasonic

Panasonic SCPM29 - MINI HES W/CD PLAYER operating instructions

Meyer

Meyer LD-3 operating instructions

THOMSON

THOMSON MIC302U manual

Philips

Philips MCM530 Service manual

Sony

Sony SS-CEP50 Service manual

Cetacea Sound

Cetacea Sound CVS-II user guide

Sony

Sony MHC-V21D Service manual

Denon

Denon UCD-250 Service manual

Exibel

Exibel BDX600-UK user manual

Aiwa LCX-133 User manual

Popular Stereo System manuals by other brands
