SERVICE MANUAL
DATA
CD-R/CD STEREO SYSTEM
XR-C3RW
S/M Code No. 09-99C-338-0R1
U(S)
REVISION
• BASIC MD MECHANISM : 2ZM-3MK2 YPR4
• BASIC CD MECHANISM : AZG-1 ZD8RD
SYSTEM
XR-C3RW
CD-R/CD/
CASSEIVER
CX-NC3RW SX-WNC3
SPEAKER
This Service Manual is the “Revision Publishing” and replaces “Simple Manual”
XR-C3RW U(S)(S/M Code No. 09-99C-338-0T1).
• BASIC CD-R MECHANISM : PH1621011A
If requiring information about the CD mechanism, see Service Manual of AZG-1,
(S/M Code No. 09-001-335-3N6).

2
TABLE OF CONTENTS
SPECIFICATIONS .................................................................................................................................. 3
ACCESSORIES/PACKAGE LIST ........................................................................................................... 3
PROTECTION OF EYES FROM LASER BEAM DURING SERVICING ................................................ 4
ELECTRICAL MAIN PARTS LIST ..................................................................................................... 5-11
TRANSISTOR ILLUSTRATION ............................................................................................................ 12
FL GRID ASSIGNMENT/ANODE CONNECTION .......................................................................... 13, 14
SCHEMATIC DIAGRAM-1 (MAIN 1/2)............................................................................................ 15, 16
SCHEMATIC DIAGRAM-2 (MAIN 2/2)............................................................................................ 17, 18
WIRING-1 (MAIN) ........................................................................................................................... 19, 20
SCHEMATIC DIAGRAM-3 (FRONT) .............................................................................................. 21, 22
WIRING-2 (FRONT)........................................................................................................................ 23, 24
SCHEMATIC DIAGRAM-4 (INTERFACE) ...................................................................................... 25, 26
WIRING-3 (INTERFACE)................................................................................................................ 27, 28
SCHEMATIC DIAGRAM-5 (PT) ............................................................................................................ 29
WIRING-4 (PT)...................................................................................................................................... 30
SCHEMATIC DIAGRAM-6 (CD-R 1/2)............................................................................................ 31, 32
SCHEMATIC DIAGRAM-7 (CD-R 2/2)............................................................................................ 33, 34
WIRING-5 (CD-R) ........................................................................................................................... 35, 36
IC BLOCK DIAGRAM....................................................................................................................... 37-41
IC DESCRIPTION............................................................................................................................ 42-49
ELECTRICAL ADJUSTMENT/PRACTICAL SERVICE FIGURE ..................................................... 50-53
TAPE MECHANISM PARTS LIST 1/1 .................................................................................................. 54
TAPE MECHANISM EXPLODED VIEW 1/2 ......................................................................................... 55
TAPE MECHANISM EXPLODED VIEW 2/2 ......................................................................................... 56
MECHANICAL EXPLODED VIEW 1/1............................................................................................ 57, 58
MECHANICAL PARTS LIST 1/1 ........................................................................................................... 59
SPEAKER DISASSEMBLY INSTRUCTIONS....................................................................................... 60
SPEAKER PARTS LIST 1/1.................................................................................................................. 61

3
SPECIFICATIONS
•
Design and specifications are subject to change without
notice.
REF. NO PART NO. KANRI DESCRIPTION
NO.
ACCESSORIES/PACKAGE LIST
1 87-A90-030-010 ANT,LOOP AM-NC C
2 87-043-115-010 ANT,FEEDER FM
3 8Z-NF8-701-210 RC UNIT,RC-ZAS01
4 8Z-DF8-908-010 IB,D(J)I<D<S>>
4 8Z-DF8-903-010 IB,U(ESF)I<U<S>>

4
PROTECTION OF EYES FROM LASER BEAM DURING SERVICING
VAROITUS!
Laiteen Käyttäminen muulla kuin tässä käyttöohjeessa mainit-
ulla tavalla saattaa altistaa käyt-täjän turvallisuusluokan 1 ylit-
tävälle näkymättömälle lasersäteilylle.
VARNING!
Om apparaten används på annat sätt än vad som specificeras i
denna bruksanvising, kan användaren utsättas för osynling
laserstrålning, som överskrider gränsen för laserklass 1.
Caution: Invisible laser radiation when
open and interlocks defeated avoid expo-
sure to beam.
Advarsel:Usynling laserståling ved åbning,
når sikkerhedsafbrydere er ude af funktion.
Undgå udsættelse for stråling.
CAUTION
Use of controls or adjustments or performance of procedures
other than those specified herein may result in hazardous
radiation exposure.
ATTENTION
L'utilisation de commandes, réglages ou procédures autres que
ceux spécifiés peut entraîner une dangereuse exposition aux
radiations.
ADVARSEL!
Usynlig laserståling ved åbning, når sikkerhedsafbrydereer ude
af funktion. Undgå udsættelse for stråling.
This Compact Disc player is classified as a CLASS 1 LASER
product.
The CLASS 1 LASER PRODUCT label is located on the rear
exterior.
This set employs laser. Therefore, be sure to follow carefully the
instructions below when servicing.
WARNING!
WHEN SERVICING, DO NOT APPROACH THE LASER EXIT
WITH THE EYE TOO CLOSELY. IN CASE IT IS NECESSARY TO
CONFIRM LASER BEAM EMISSION. BE SURE TO OBSERVE
FROM A DISTANCE OF MORE THAN 30cm FROM THE
SURFACE OF THE OBJECTIVE LENS ON THE OPTICAL
PICK-UP BLOCK.
CLASS 1
KLASSE 1
LUOKAN 1
KLASS 1
LASER PRODUCT
LASER PRODUKT
LASER LAITE
LASER APPARAT
Precaution to replace Optical block
1) After the connection, remove solder shown in
the figure below.
Body or clothes electrostatic potential could ruin
laser diode in the optical block. Be sure ground
body and workbench, and use care the clothes
do not touch the diode.
Solder

5
REF. NO PART NO. KANRI DESCRIPTION
NO.
REF. NO PART NO. KANRI DESCRIPTION
NO.
ELECTRICAL MAIN PARTS LIST
IC
8Z-DF8-602-010 C-IC,LC87F65C8A-ZDF8
87-A21-459-040 C-IC,TC74ACT245F
87-A20-914-010 IC,SPS-442-1-F
87-A21-458-040 C-IC,TC74ACT244F
8A-AJ1-627-010 C-IC,EPF6016TC144-3
87-A20-696-010 C-IC,AM186EM-33KC/W
8A-AJ1-621-010 C-IC ASSY,MBM29F400TC*1 AAJ1
8A-AJ1-626-040 C-IC,AT25160N-10SC
87-017-830-080 IC,TC7W14FU
8A-AJ1-625-040 C-IC,KM6164000BLT-7LT
8A-AJ1-628-010 IC,EPC1441PC8
8A-AJ1-616-040 C-IC,CS8420-CS
87-A21-021-040 C-IC,BU2099FV
8A-AJ1-617-040 C-IC,CS4222-KS
86-NFZ-676-080 C-IC,NJM4558MD
87-017-888-080 IC,NJM4558MD
87-A21-023-040 C-IC,BA3835F
87-A20-870-010 IC,GP1F37R
87-A20-971-040 C-IC,SN74LV14APW
87-027-842-080 IC,NJM2904M
87-A21-031-040 C-IC,BU4551BF
87-A21-111-040 C-IC,M62495FP
87-070-127-110 IC,LC72131 D
87-A20-913-010 IC,LA1837NL
TRANSISTOR
87-026-609-080 TR,KTA1266GR
89-213-702-010 TR,2SB1370 (1.8W)
87-026-610-080 TR,KTC3198GR
87-A30-076-080 C-TR,2SC3052F
87-A30-075-080 C-TR,2SA1235F
87-A30-234-080 TR,CSC4115BC
87-A30-073-080 C-TR,RT1N 141C
87-A30-186-010 FET,2SK3053
87-026-245-080 TR,DTC114ES
87-A30-198-080 TR,KTC3199GR
87-049-919-010 CONN,3P EH V WHT
87-A30-087-080 C-FET,2SK2158
89-113-625-080 TR,2SA1362GR(120MHZ,0.
87-A30-329-080 TR,CD1585BC
87-A30-190-080 TR,CC5551
87-A30-215-010 TR,2SD2025
87-A30-214-010 TR,2SB1344
87-A30-106-070 C-TR,CMBT5551
87-A30-107-070 C-TR,CMBT5401
87-026-227-080 CHIP-TR,DTA114EK
87-026-235-080 CHIP-TR,DTC114EK
87-026-230-080 CHIP-TR,DTA114YK
87-A30-256-010 TR,2SD1933
87-A30-255-010 TR,2SB1342
87-A30-071-080 C-TR,RT1N 144C
87-026-225-080 FET,2SJ106GR
87-A30-072-080 C-TR,RT1P 144C
87-A30-383-040 C-TR,DTC144WKA
87-A30-091-080 FET,2SJ460
87-A30-074-080 C-TR,RT1P 141C
87-A30-090-080 FET,2SK2541
87-A30-104-080 C-TR,RT1N 441C
89-333-317-880 TR,2SC3331 (0.5W)
89-341-165-080 CHIP TRANSISTOR 2SC4116GR
89-115-865-080 C-TR,2SA1586GR
87-A30-224-010 TR,2SA1329Y
87-A30-217-010 TR,2SB1436(R)
87-026-213-080 CHIP-TR,DTC114YK
89-327-143-080 TR,2SC2714 (0.1W)
DIODE
87-020-465-080 DIODE,1SS133 (110MA)
87-A40-547-090 DIODE,D5SBA20
87-070-274-080 DIODE,1N4003 SEM
87-A40-383-080 ZENER,MTZJ30A
87-A40-345-080 ZENER,MTZJ10C
87-A40-270-080 C-DIODE,MC2838
87-A40-269-080 C-DIODE,MC2836
87-017-931-080 ZENER,MTZJ5.6B
87-A40-393-090 DIODE,1N5402GW(F20)
87-017-447-010 DIODE,GBU4DL
87-A40-001-080 ZENER,MTZJ12C
87-A40-335-080 ZENER,MTZJ11C T-72
87-A40-246-080 DIODE,IN4148 T-72
87-017-978-080 DIODE,1N4003
87-A40-509-080 ZENER,MTZJ6.8C
87-A40-469-080 C-DIODE,HSM2838CTR
87-A40-468-080 C-DIODE,HSM2836CTR
87-017-931-070 ZENER,MTZJ5.6B
87-A40-299-080 ZENER,DZ5.1M
87-XM1-603-080 C-DIODE,1SS193
87-A40-466-080 ZENER,MTZJ2.7A
87-A40-464-080 ZENER,MTZJ3.6A
87-017-149-080 ZENER,HZS6A2L
INTERFACE C.B
C201 87-010-402-040 CAP,E 2.2-50 SME
C202 87-010-402-040 CAP,E 2.2-50 SME
C301 87-010-196-080 CHIP CAPACITOR,0.1-25
C303 87-010-380-040 CAP,E 47-16 SME
C304 87-010-196-080 CHIP CAPACITOR,0.1-25
C305 87-010-075-040 CAP,E 10-16 5L
C306 87-010-075-040 CAP,E 10-16 5L
C307 87-010-248-040 CAP,E 220-10 SME
C313 87-010-072-040 CAP,E 2.2-50 5L
C314 87-010-072-040 CAP,E 2.2-50 5L
C315 87-010-072-040 CAP,E 2.2-50 5L
C316 87-010-072-040 CAP,E 2.2-50 5L
C401 87-010-178-080 CHIP CAP 1000P
C402 87-010-178-080 CHIP CAP 1000P
C403 87-010-196-080 CHIP CAPACITOR,0.1-25
C404 87-010-196-080 CHIP CAPACITOR,0.1-25
C411 87-012-140-080 CAP 470P
C421 87-010-197-080 CAP, CHIP 0.01 DM
C701 87-012-140-080 CAP 470P
C702 87-010-235-080 CAP,E 470-16 SME
C705 87-012-368-080 C-CAP,S 0.1-50 F
C706 87-012-140-080 CAP 470P
C707 87-010-235-080 CAP,E 470-16 SME
C708 87-012-368-080 C-CAP,S 0.1-50 F
C812 87-010-182-080 C-CAP,S 2200P-50 B
C813 87-010-182-080 C-CAP,S 2200P-50 B
C814 87-010-182-080 C-CAP,S 2200P-50 B
C815 87-010-182-080 C-CAP,S 2200P-50 B
C816 87-012-156-080 C-CAP,S 220P-50 CH
C817 87-012-156-080 C-CAP,S 220P-50 CH
C818 87-010-182-080 C-CAP,S 2200P-50 B
C819 87-010-182-080 C-CAP,S 2200P-50 B
C820 87-010-182-080 C-CAP,S 2200P-50 B
C821 87-010-182-080 C-CAP,S 2200P-50 B
C822 87-012-156-080 C-CAP,S 220P-50 CH
C823 87-012-156-080 C-CAP,S 220P-50 CH
C824 87-012-368-080 C-CAP,S 0.1-50 F
C850 87-010-408-040 CAP,E 47-50 SME
C851 87-012-368-080 C-CAP,S 0.1-50 F
C852 87-010-101-040 CAP,E 220-16 SME
C853 87-010-072-040 CAP,E 2.2-50 5L
C854 87-010-402-040 CAP,E 2.2-50 SME
C855 87-010-402-040 CAP,E 2.2-50 SME

6
REF. NO PART NO. KANRI DESCRIPTION
NO.
REF. NO PART NO. KANRI DESCRIPTION
NO.
C856 87-010-402-040 CAP,E 2.2-50 SME
C951 87-010-316-080 C-CAP. S 33P-50 J CH GRM
CON901 87-099-014-010 CONN,12P 6216 V
CON902 87-099-749-010 CONN,9P V 9604SC
CON903 8Z-DF8-678-010 CONN,2P V SHIELD260MM
CON904 87-099-194-010 CONN,6P 6216V
CON905 87-A60-623-010 CONN,6P V 2MM JMT
CON906 87-A60-621-010 CONN,4P V 2MM JMT
CON907 87-A60-623-010 CONN,6P V 2MM JMT
CON908 87-049-919-010 CONN,3P EH V WHT
CON909 87-049-469-010 CONN,4P V
CON919 87-A60-619-010 CONN,2P V 2MM JMT
CON923 87-A60-619-010 CONN,2P V 2MM JMT
CON924 87-A60-619-010 CONN,2P V 2MM JMT
CON925 87-049-919-010 CONN,3P EH V WHT
FB101 87-A50-189-080 C-COIL,S BLM21B272S
FB102 87-A50-189-080 C-COIL,S BLM21B272S
L701 87-A50-267-010 COIL,33UHRCR-875D
L702 87-A50-267-010 COIL,33UHRCR-875D
R318 87-A50-190-080 C-COIL,S BLM21A102S
R319 87-A50-190-080 C-COIL,S BLM21A102S
R415 87-A50-189-080 C-COIL,S BLM21B272S
PT C.B
C1 87-010-387-080 CAP,E 470-25 SME
C3 87-A11-148-080 CAP,TC U 0.1-50 Z F
C4 87-A11-148-080 CAP,TC U 0.1-50 Z F
C5 87-A11-148-080 CAP,TC U 0.1-50 Z F
C6 87-A11-148-080 CAP,TC U 0.1-50 Z F
C14 87-016-658-000 CAP,E 4700-35 M SMG
C15 87-016-658-000 CAP,E 4700-35 M SMG
C21 87-010-928-000 CAP,E 4700-25 M SMG
C22 87-016-121-090 CAP,E 6800-16 SMG
C25 87-A11-148-080 CAP,TC U 0.1-50 Z F
C26 87-A11-148-080 CAP,TC U 0.1-50 Z F
C31 87-010-403-080 CAP, ELECT 3.3-50V
CN1 87-A60-851-010 CONN,9P V VH
CN5 8Z-DF8-623-010 CONN ASSY,3P PT
! F3 87-A91-276-080 FUSE,125MA 125V F 251
! F9 87-026-691-080 FUSE,10A 125V 251
! F10 87-026-690-080 FUSE,5A 125V 251
JW20 87-A90-210-080 FUSE,7A 125V 251
JW21 87-A90-210-080 FUSE,7A 125V 251
JW24 87-017-430-080 DIODE,RK14
! L1 87-A91-453-010 FLTR,LINE PLH10A7003R6P02B1
! PT2 8Z-NF8-661-010 PT,SUB ZNF-8(U)
! T1 87-A60-317-010 TERMINAL, 1P MSC
! T2 87-A60-317-010 TERMINAL, 1P MSC
FRONT C.B
C1 87-012-156-080 C-CAP,S 220P-50 CH
C2 87-012-156-080 C-CAP,S 220P-50 CH
C3 87-012-156-080 C-CAP,S 220P-50 CH
C4 87-012-156-080 C-CAP,S 220P-50 CH
C5 87-012-156-080 C-CAP,S 220P-50 CH
C6 87-012-156-080 C-CAP,S 220P-50 CH
C7 87-012-156-080 C-CAP,S 220P-50 CH
C8 87-012-156-080 C-CAP,S 220P-50 CH
C9 87-012-156-080 C-CAP,S 220P-50 CH
C10 87-012-156-080 C-CAP,S 220P-50 CH
C11 87-012-156-080 C-CAP,S 220P-50 CH
C12 87-012-349-080 C-CAP,S 1000P-50 CH
C13 87-012-156-080 C-CAP,S 220P-50 CH
C103 87-010-197-080 CAP, CHIP 0.01 DM
C104 87-012-156-080 C-CAP,S 220P-50 CH
C105 87-012-156-080 C-CAP,S 220P-50 CH
C107 87-012-157-080 C-CAP,S 330P-50 CH
C108 87-010-075-040 CAP,E 10-16 5L
C112 87-010-196-080 CHIP CAPACITOR,0.1-25
C113 87-016-459-040 CAP,E 470-10 SMG
C114 87-010-196-080 CHIP CAPACITOR,0.1-25
C116 87-015-694-040 E/CAP 0.47-50
C117 87-010-264-040 CAP,E 100-10 5L
C118 87-010-194-080 CAP, CHIP 0.047
C119 87-A11-071-040 CAP,E 47-50 SRG
C120 87-015-698-040 CAP,E 4.7-50 7L
C121 87-010-421-040 CAP,E 4.7-50 5L
C122 87-010-194-080 CAP, CHIP 0.047
C123 87-010-196-080 CHIP CAPACITOR,0.1-25
C124 87-010-196-080 CHIP CAPACITOR,0.1-25
C125 87-010-196-080 CHIP CAPACITOR,0.1-25
C126 87-012-155-080 C-CAP 180P-50CH
C127 87-010-196-080 CHIP CAPACITOR,0.1-25
C128 87-010-178-080 CHIP CAP 1000P
C130 87-010-312-080 C-CAP,S 15P-50 CH
C131 87-010-322-080 C-CAP,S 100P-50 CH
C195 87-010-194-080 CAP, CHIP 0.047
C196 87-010-498-040 CAP,E 10-16 GAS
C197 87-010-196-080 CHIP CAPACITOR,0.1-25
C223 87-010-405-040 CAP,E 10-50
C224 87-010-196-080 CHIP CAPACITOR,0.1-25
C251 87-010-322-080 C-CAP,S 100P-50 CH
C252 87-010-322-080 C-CAP,S 100P-50 CH
C253 87-010-322-080 C-CAP,S 100P-50 CH
C254 87-010-322-080 C-CAP,S 100P-50 CH
C255 87-010-322-080 C-CAP,S 100P-50 CH
C256 87-010-322-080 C-CAP,S 100P-50 CH
C272 87-010-322-080 C-CAP,S 100P-50 CH
C273 87-010-322-080 C-CAP,S 100P-50 CH
C351 87-012-158-080 C-CAP,S 390P-50 CH
C352 87-010-196-080 CHIP CAPACITOR,0.1-25
C353 87-010-196-080 CHIP CAPACITOR,0.1-25
C354 87-010-196-080 CHIP CAPACITOR,0.1-25
C355 87-010-196-080 CHIP CAPACITOR,0.1-25
C356 87-010-196-080 CHIP CAPACITOR,0.1-25
C357 87-010-196-080 CHIP CAPACITOR,0.1-25
C421 87-015-686-040 CAP,E 22-25 M 7L SRA
CON101 87-099-720-010 CONN,30P TYK-B(P)
CON102 87-A60-055-010 CONN,13P V 9604S-13C
CON104 87-099-017-010 CONN, 15P 6216 V
CON502 87-099-197-010 CONN, 9P 6216 V
FL101 8Z-DF8-601-010 FL,BJ735GNK
L331 87-A50-333-010 COIL,OSC 9.43MHZ
LED201 87-A40-452-080 LED,SEL6210S-TP7 RED
LED202 87-A40-452-080 LED,SEL6210S-TP7 RED
LED203 87-A40-452-080 LED,SEL6210S-TP7 RED
LED204 87-A40-452-080 LED,SEL6210S-TP7 RED
LED205 87-A40-452-080 LED,SEL6210S-TP7 RED
LED206 87-A40-451-080 LED,SEL6510C-TP7 GRN
LED207 87-A40-451-080 LED,SEL6510C-TP7 GRN
LED208 87-A40-451-080 LED,SEL6510C-TP7 GRN
LED209 87-A40-451-080 LED,SEL6510C-TP7 GRN
LED217 87-A40-619-080 LED,SLR-56PT-TE7-W GRN
LED218 87-A40-619-080 LED,SLR-56PT-TE7-W GRN
LED219 87-A40-619-080 LED,SLR-56PT-TE7-W GRN
LED220 87-A40-619-080 LED,SLR-56PT-TE7-W GRN
LED221 87-A40-619-080 LED,SLR-56PT-TE7-W GRN
LED222 87-A40-619-080 LED,SLR-56PT-TE7-W GRN
LED251 87-A40-564-010 LED,SEL6215S-LF62 RED
LED252 87-A40-564-010 LED,SEL6215S-LF62 RED
LED254 87-A40-564-010 LED,SEL6215S-LF62 RED
LED371 87-A90-825-040 LED,SLP-9131C-81H-S-T1 RED
LED601 87-A40-619-040 LED,SLR-56PT-T31-W GRN
LED602 87-A40-619-040 LED,SLR-56PT-T31-W GRN
LED603 87-A40-619-040 LED,SLR-56PT-T31-W GRN
LED604 87-A40-619-040 LED,SLR-56PT-T31-W GRN
LED605 87-A40-619-040 LED,SLR-56PT-T31-W GRN
LED606 87-A40-619-040 LED,SLR-56PT-T31-W GRN

7
REF. NO PART NO. KANRI DESCRIPTION
NO.
REF. NO PART NO. KANRI DESCRIPTION
NO.
LED607 87-A40-619-040 LED,SLR-56PT-T31-W GRN
LED608 87-A40-619-040 LED,SLR-56PT-T31-W GRN
LED650 87-A40-451-080 LED,SEL6510C-TP7 GRN
S301 87-A91-024-180 SW,TACT KSH0611BT
S302 87-A91-024-180 SW,TACT KSH0611BT
S303 87-A91-024-180 SW,TACT KSH0611BT
S304 87-A91-024-180 SW,TACT KSH0611BT
S305 87-A91-024-180 SW,TACT KSH0611BT
S306 87-A91-024-180 SW,TACT KSH0611BT
S307 87-A91-024-180 SW,TACT KSH0611BT
S308 87-A91-024-180 SW,TACT KSH0611BT
S309 87-A91-024-180 SW,TACT KSH0611BT
S310 87-A91-024-180 SW,TACT KSH0611BT
S311 87-A91-024-180 SW,TACT KSH0611BT
S312 87-A91-024-180 SW,TACT KSH0611BT
S313 87-A91-024-180 SW,TACT KSH0611BT
S314 87-A91-024-180 SW,TACT KSH0611BT
S315 87-A90-095-080 SW,TACT EVQ11G04M
S316 87-A90-095-080 SW,TACT EVQ11G04M
S317 87-A90-095-080 SW,TACT EVQ11G04M
S318 87-A90-095-080 SW,TACT EVQ11G04M
S319 87-A90-095-080 SW,TACT EVQ11G04M
S320 87-A91-024-180 SW,TACT KSH0611BT
S321 87-A91-024-180 SW,TACT KSH0611BT
S322 87-A91-024-180 SW,TACT KSH0611BT
S323 87-A91-024-180 SW,TACT KSH0611BT
S324 87-A90-095-080 SW,TACT EVQ11G04M
S325 87-A91-024-180 SW,TACT KSH0611BT
S326 87-A91-024-180 SW,TACT KSH0611BT
S327 87-A91-024-180 SW,TACT KSH0611BT
S328 87-A91-024-180 SW,TACT KSH0611BT
S329 87-A90-095-080 SW,TACT EVQ11G04M
S330 87-A90-095-080 SW,TACT EVQ11G04M
S331 87-A90-095-080 SW,TACT EVQ11G04M
S334 87-A91-024-180 SW,TACT KSH0611BT
S335 87-A91-024-180 SW,TACT KSH0611BT
S337 87-A91-024-180 SW,TACT KSH0611BT
SW101 87-A90-535-010 SW,RTRY EC16B24304
SW102 87-A90-950-010 SW,RTRY EC12E12504 ENCORDER
TP108 87-009-371-010 CONNECTOR, 6P
MAIN C.B
C1 87-012-369-080 C-CAP,S 0.047-50F
C2 87-012-369-080 C-CAP,S 0.047-50F
C3 87-012-368-080 C-CAP,S 0.1-50 F
C4 87-012-368-080 C-CAP,S 0.1-50 F
C5 87-012-368-080 C-CAP,S 0.1-50 F
C6 87-012-368-080 C-CAP,S 0.1-50 F
C9 87-A10-520-000 CAP,E 3300-35 M SMG
C10 87-A10-520-000 CAP,E 3300-35 M SMG
C21 87-010-385-080 CAP, ELECT 220-25V
C22 87-010-385-080 CAP, ELECT 220-25V
C23 87-010-247-080 CAP, ELECT 100-50V
C24 87-010-247-080 CAP, ELECT 100-50V
C25 87-010-430-080 CAP, ELECT 100-63
C26 87-010-263-080 CAP, ELECT 100-10V
C27 87-010-197-080 CAP, CHIP 0.01 DM
C28 87-010-263-080 CAP, ELECT 100-10V
C29 87-010-247-080 CAP, ELECT 100-50V
C30 87-010-381-080 CAP, ELECT 330-16V
C31 87-010-235-080 CAP,E 470-16 SME
C32 87-010-405-080 CAP, ELECT 10-50V
C33 87-010-405-080 CAP, ELECT 10-50V
C34 87-012-368-080 C-CAP,S 0.1-50 F
C35 87-010-198-080 CAP, CHIP 0.022
C36 87-010-198-080 CAP, CHIP 0.022
C40 87-010-112-080 CAP, ELECT 100-16V
C50 87-010-182-080 C-CAP,S 2200P-50 B
C51 87-010-180-080 C-CER 1500P
C61 87-010-260-080 CAP, ELECT 47-25V
C62 87-010-403-080 CAP, ELECT 3.3-50V
C91 87-010-401-080 CAP, ELECT 1-50V
C92 87-010-380-080 CAP, ELECT 47-16V
C93 87-010-380-080 CAP, ELECT 47-16V
C101 87-012-368-080 C-CAP,S 0.1-50 F
C101 87-010-178-080 CHIP CAP 1000P
C102 87-012-368-080 C-CAP,S 0.1-50 F
C102 87-010-178-080 CHIP CAP 1000P
C103 87-012-368-080 C-CAP,S 0.1-50 F
C103 87-010-405-080 CAP, ELECT 10-50V
C104 87-010-405-080 CAP, ELECT 10-50V
C105 87-012-368-080 C-CAP,S 0.1-50 F
C107 87-012-368-080 C-CAP,S 0.1-50 F
C107 87-010-408-080 CAP, ELECT 47-50V
C108 87-012-368-080 C-CAP,S 0.1-50 F
C108 87-010-408-080 CAP, ELECT 47-50V
C109 87-012-368-080 C-CAP,S 0.1-50 F
C109 87-010-322-080 C-CAP,S 100P-50 CH
C110 87-012-368-080 C-CAP,S 0.1-50 F
C110 87-010-322-080 C-CAP,S 100P-50 CH
C111 87-010-260-080 CAP, ELECT 47-25V
C112 87-010-260-080 CAP, ELECT 47-25V
C113 87-012-368-080 C-CAP,S 0.1-50 F
C113 87-A10-946-080 C-CAP,S 220P-100 J CH
C114 87-012-368-080 C-CAP,S 0.1-50 F
C114 87-A10-946-080 C-CAP,S 220P-100 J CH
C115 87-012-368-080 C-CAP,S 0.1-50 F
C116 87-012-368-080 C-CAP,S 0.1-50 F
C117 87-012-368-080 C-CAP,S 0.1-50 F
C117 87-010-400-080 CAP, ELECT 0.47-50V
C118 87-012-368-080 C-CAP,S 0.1-50 F
C118 87-010-400-080 CAP, ELECT 0.47-50V
C119 87-012-154-080 C-CAP,S 150P-50 CH
C120 87-012-368-080 C-CAP,S 0.1-50 F
C121 87-012-368-080 C-CAP,S 0.1-50 F
C121 87-010-178-080 CHIP CAP 1000P
C122 87-010-154-080 CAP CHIP 10P
C122 87-010-178-080 CHIP CAP 1000P
C123 87-010-176-080 C-CAP,S 680P-50 SL
C123 87-010-154-080 CAP CHIP 10P
C124 87-010-176-080 C-CAP,S 680P-50 SL
C124 87-010-831-080 C-CAP,U,0.1-16F
C125 87-012-368-080 C-CAP,S 0.1-50 F
C125 87-010-831-080 C-CAP,U,0.1-16F
C126 87-012-368-080 C-CAP,S 0.1-50 F
C126 87-010-831-080 C-CAP,U,0.1-16F
C127 87-012-368-080 C-CAP,S 0.1-50 F
C127 87-012-368-080 C-CAP,S 0.1-50 F
C128 87-012-368-080 C-CAP,S 0.1-50 F
C128 87-012-368-080 C-CAP,S 0.1-50 F
C129 87-010-191-080 C-CAP,S 0.015-50 F
C129 87-012-368-080 C-CAP,S 0.1-50 F
C130 87-010-191-080 C-CAP,S 0.015-50 F
C130 87-012-368-080 C-CAP,S 0.1-50 F
C131 87-012-368-080 C-CAP,S 0.1-50 F
C131 87-010-197-080 CAP, CHIP 0.01 DM
C132 87-010-197-080 CAP, CHIP 0.01 DM
C132 87-010-252-080 CAP, ELECT 1000-6.3V
C133 87-010-197-080 CAP, CHIP 0.01 DM
C133 87-010-391-040 CAP,E 10-35 SME
C134 87-012-142-080 CAP, S 0.33-16
C137 87-012-368-080 C-CAP,S 0.1-50 F
C138 87-012-368-080 C-CAP,S 0.1-50 F
C139 87-012-368-080 C-CAP,S 0.1-50 F
C201 87-010-197-080 CAP, CHIP 0.01 DM
C203 87-012-368-080 C-CAP,S 0.1-50 F
C203 87-010-177-080 C-CAP,S 820P-50 SL
C204 87-016-526-080 C-CAP,S 0.47-16 BK
C204 87-010-177-080 C-CAP,S 820P-50 SL

8
REF. NO PART NO. KANRI DESCRIPTION
NO.
REF. NO PART NO. KANRI DESCRIPTION
NO.
C205 87-010-189-080 C-CAP,S 8200P-50 B
C206 87-012-368-080 C-CAP,S 0.1-50 F
C207 87-012-156-080 C-CAP,S 220P-50 CH
C208 88-XMY-614-080 C-CAP,TN 10U-10 TCFG A
C209 87-012-368-080 C-CAP,S 0.1-50 F
C209 87-010-403-080 CAP, ELECT 3.3-50V
C210 87-012-368-080 C-CAP,S 0.1-50 F
C210 87-010-403-080 CAP, ELECT 3.3-50V
C211 88-XMY-614-080 C-CAP,TN 10U-10 TCFG A
C211 87-010-181-080 CAP,CHIP S 1800P
C212 87-010-181-080 CAP,CHIP S 1800P
C213 87-010-403-080 CAP, ELECT 3.3-50V
C214 87-010-403-080 CAP, ELECT 3.3-50V
C215 87-010-322-080 C-CAP,S 100P-50 CH
C216 87-010-322-080 C-CAP,S 100P-50 CH
C217 87-010-260-080 CAP, ELECT 47-25V
C218 87-010-260-080 CAP, ELECT 47-25V
C219 87-A10-946-080 C-CAP,S 220P-100 J CH
C220 87-A10-946-080 C-CAP,S 220P-100 J CH
C225 87-012-368-080 C-CAP,S 0.1-50 F
C226 87-012-368-080 C-CAP,S 0.1-50 F
C227 87-010-186-080 CAP,CHIP 4700P
C228 87-010-186-080 CAP,CHIP 4700P
C229 87-010-993-080 C-CAP,S 0.056-25 B
C230 87-010-993-080 C-CAP,S 0.056-25 B
C231 87-010-196-080 CHIP CAPACITOR,0.1-25
C232 87-010-196-080 CHIP CAPACITOR,0.1-25
C233 87-010-190-080 S CHIP F 0.01
C234 87-010-190-080 S CHIP F 0.01
C235 87-010-182-080 C-CAP,S 2200P-50 B
C235 87-016-285-080 CAP,E 47-100SME
C236 87-010-182-080 C-CAP,S 2200P-50 B
C236 87-016-285-080 CAP,E 47-100SME
C237 87-010-322-080 C-CAP,S 100P-50 CH
C238 87-010-322-080 C-CAP,S 100P-50 CH
C239 87-010-196-080 CHIP CAPACITOR,0.1-25
C240 87-010-407-080 CAP, ELECT 33-50V
C243 87-010-407-080 CAP, ELECT 33-50V
C301 87-010-178-080 CHIP CAP 1000P
C302 87-010-178-080 CHIP CAP 1000P
C303 87-010-178-080 CHIP CAP 1000P
C304 87-010-178-080 CHIP CAP 1000P
C305 87-010-198-080 CAP, CHIP 0.022
C307 87-010-263-080 CAP, ELECT 100-10V
C308 87-010-263-080 CAP, ELECT 100-10V
C309 87-010-318-080 C-CAP,S 47P-50 CH
C310 87-010-318-080 C-CAP,S 47P-50 CH
C311 87-010-598-080 C-CAP,S 0.068-16VRK
C312 87-010-598-080 C-CAP,S 0.068-16VRK
C313 87-010-187-080 CAP CHIP S5600P
C314 87-010-187-080 CAP CHIP S5600P
C315 87-010-263-080 CAP, ELECT 100-10V
C317 87-010-546-080 CAP, ELECT 0.33-50V
C318 87-010-546-080 CAP, ELECT 0.33-50V
C326 87-010-198-080 CAP, CHIP 0.022
C327 87-012-368-080 C-CAP,S 0.1-50 F
C360 87-010-401-080 CAP, ELECT 1-50V
C399 87-012-140-080 CAP 470P
C401 87-010-544-080 CAP, ELECT 0.1-50V
C402 87-010-544-080 CAP, ELECT 0.1-50V
C403 87-010-321-080 CHIP CAPACITOR,82P(J)
C404 87-010-321-080 CHIP CAPACITOR,82P(J)
C405 87-010-197-080 CAP, CHIP 0.01 DM
C406 87-010-197-080 CAP, CHIP 0.01 DM
C407 87-010-197-080 CAP, CHIP 0.01 DM
C408 87-010-197-080 CAP, CHIP 0.01 DM
C409 87-010-182-080 C-CAP,S 2200P-50 B
C410 87-010-182-080 C-CAP,S 2200P-50 B
C411 87-010-405-080 CAP, ELECT 10-50V
C412 87-010-405-080 CAP, ELECT 10-50V
C451 87-010-198-080 CAP, CHIP 0.022
C452 87-010-382-080 CAP, ELECT 22-25V
C453 87-010-183-080 C-CAP,S 2700P-50 B
C454 87-010-183-080 C-CAP,S 2700P-50 B
C454 87-010-805-080 CAP, S 1-16
C455 87-010-183-080 C-CAP,S 2700P-50 B
C455 87-010-805-080 CAP, S 1-16
C456 87-010-197-080 CAP, CHIP 0.01 DM
C456 87-010-552-040 CAP,E 22-16 GAS
C457 87-012-368-080 C-CAP,S 0.1-50 F
C458 87-010-178-080 CHIP CAP 1000P
C459 87-010-175-080 CAP 560P
C461 87-012-158-080 C-CAP,S 390P-50 CH
C462 87-012-158-080 C-CAP,S 390P-50 CH
C501 87-010-401-080 CAP, ELECT 1-50V
C502 87-010-401-080 CAP, ELECT 1-50V
C507 87-010-196-080 CHIP CAPACITOR,0.1-25
C508 87-010-196-080 CHIP CAPACITOR,0.1-25
C605 87-010-179-080 CAP,CHIP S B1200P
C606 87-010-179-080 CAP,CHIP S B1200P
C609 87-010-213-080 C-CAP,S 0.015-50 B
C610 87-010-213-080 C-CAP,S 0.015-50 B
C611 87-010-545-080 CAP, ELECT 0.22-50V
C612 87-010-545-080 CAP, ELECT 0.22-50V
C613 87-010-545-080 CAP, ELECT 0.22-50V
C614 87-010-545-080 CAP, ELECT 0.22-50V
C615 87-010-154-080 CAP CHIP 10P
C616 87-010-385-080 CAP, ELECT 220-25V
C617 87-010-385-080 CAP, ELECT 220-25V
C631 87-010-178-080 CHIP CAP 1000P
C632 87-010-178-080 CHIP CAP 1000P
C669 87-010-322-080 C-CAP,S 100P-50 CH
C670 87-010-322-080 C-CAP,S 100P-50 CH
C677 87-010-197-080 CAP, CHIP 0.01 DM
C701 87-010-381-080 CAP, ELECT 330-16V
C702 87-010-404-080 CAP, ELECT 4.7-50V
C703 87-010-197-080 CAP, CHIP 0.01 DM
C704 87-010-197-080 CAP, CHIP 0.01 DM
C709 87-010-322-080 C-CAP,S 100P-50 CH
C711 87-010-260-080 CAP, ELECT 47-25V
C712 87-010-196-080 CHIP CAPACITOR,0.1-25
C713 87-010-197-080 CAP, CHIP 0.01 DM
C714 87-010-197-080 CAP, CHIP 0.01 DM
C721 87-010-312-080 C-CAP,S 15P-50 CH
C722 87-010-312-080 C-CAP,S 15P-50 CH
C723 87-010-178-080 CHIP CAP 1000P
C725 87-010-178-080 CHIP CAP 1000P
C727 87-010-196-080 CHIP CAPACITOR,0.1-25
C728 87-010-248-080 CAP, ELECT 220-10V
C751 87-010-197-080 CAP, CHIP 0.01 DM
C755 87-010-197-080 CAP, CHIP 0.01 DM
C756 87-010-197-080 CAP, CHIP 0.01 DM
C757 87-010-318-080 C-CAP,S 47P-50 CH
C758 87-010-149-080 C-CAP,S 5P-50 CH
C759 87-012-156-080 C-CAP,S 220P-50 CH
C760 87-012-156-080 C-CAP,S 220P-50 CH
C761 87-010-196-080 CHIP CAPACITOR,0.1-25
C762 87-010-197-080 CAP, CHIP 0.01 DM
C763 87-010-194-080 CAP, CHIP 0.047
C764 87-010-319-080 C-CAP,S 56P-50 CH
C765 87-010-197-080 CAP, CHIP 0.01 DM
C766 87-010-197-080 CAP, CHIP 0.01 DM
C767 87-010-405-080 CAP, ELECT 10-50V
C768 87-010-197-080 CAP, CHIP 0.01 DM
C769 87-010-408-080 CAP, ELECT 47-50V
C770 87-015-821-080 C-CAP 0.047
C771 87-010-407-080 CAP, ELECT 33-50V
C772 87-010-194-080 CAP, CHIP 0.047
C773 87-010-196-080 CHIP CAPACITOR,0.1-25
C774 87-010-263-080 CAP, ELECT 100-10V

9
REF. NO PART NO. KANRI DESCRIPTION
NO.
REF. NO PART NO. KANRI DESCRIPTION
NO.
C775 87-010-404-080 CAP, ELECT 4.7-50V
C776 87-010-197-080 CAP, CHIP 0.01 DM
C777 87-010-400-080 CAP, ELECT 0.47-50V
C778 87-010-401-080 CAP, ELECT 1-50V
C779 87-010-401-080 CAP, ELECT 1-50V
C780 87-010-196-080 CHIP CAPACITOR,0.1-25
C781 87-010-405-080 CAP, ELECT 10-50V
C782 87-010-405-080 CAP, ELECT 10-50V
C783 87-015-819-080 CAPACITOR,0.01
C784 87-010-197-080 CAP, CHIP 0.01 DM
C785 87-010-400-080 CAP, ELECT 0.47-50V
C786 87-010-400-080 CAP, ELECT 0.47-50V
C789 87-010-179-080 CAP,CHIP S B1200P
C790 87-010-179-080 CAP,CHIP S B1200P
C791 87-010-405-080 CAP, ELECT 10-50V
C793 87-010-177-080 C-CAP,S 820P-50 SL
C794 87-010-406-080 CAP, ELECT 22-50
C795 87-010-596-080 CAP, S 0.047-16
C796 87-010-403-080 CAP, ELECT 3.3-50V
C797 87-010-183-080 C-CAP,S 2700P-50 B
C798 87-010-183-080 C-CAP,S 2700P-50 B
C799 87-010-194-080 CAP, CHIP 0.047
C812 87-010-197-080 CAP, CHIP 0.01 DM
C813 87-010-197-080 CAP, CHIP 0.01 DM
C814 87-010-197-080 CAP, CHIP 0.01 DM
C815 87-010-197-080 CAP, CHIP 0.01 DM
C816 87-010-197-080 CAP, CHIP 0.01 DM
C819 87-010-197-080 CAP, CHIP 0.01 DM
C820 87-010-408-080 CAP, ELECT 47-50V
C821 87-010-197-080 CAP, CHIP 0.01 DM
C822 87-010-197-080 CAP, CHIP 0.01 DM
C823 87-010-197-080 CAP, CHIP 0.01 DM
C828 87-010-196-080 CHIP CAPACITOR,0.1-25
C829 87-010-196-080 CHIP CAPACITOR,0.1-25
C959 87-010-196-080 CHIP CAPACITOR,0.1-25
C960 87-010-196-080 CHIP CAPACITOR,0.1-25
C961 87-010-152-080 C-CAP,S 8P-50 CH
C967 87-010-197-080 CAP, CHIP 0.01 DM
C968 87-010-197-080 CAP, CHIP 0.01 DM
C972 87-012-368-080 C-CAP,S 0.1-50 F
C973 87-012-349-080 C-CAP,S 1000P-50 CH
C974 87-010-322-080 C-CAP,S 100P-50 CH
C977 87-012-153-080 C-CAP,S 120P-50 CH
C981 87-015-785-080 CHIP CAPACITOR, 0.1FZ-25Z
C985 87-010-178-080 CHIP CAP 1000P
C989 87-012-276-080 CAP, CHIP SS 1500 PBK
C994 87-012-165-080 CAP 3P
C995 87-012-368-080 C-CAP,S 0.1-50 F
C996 87-012-368-080 C-CAP,S 0.1-50 F
C997 87-012-368-080 C-CAP,S 0.1-50 F
C998 87-012-368-080 C-CAP,S 0.1-50 F
C999 87-012-368-080 C-CAP,S 0.1-50 F
CF801 87-008-261-010 FILTER, SFE10.7MA5-A
CF802 87-008-261-010 FILTER, SFE10.7MA5-A
CN101 8Z-DF8-615-010 CONN,40P H IMSA-9031B
CN102 87-009-034-010 CONN,6P PH V
CN104 87-009-349-010 CONN,6P PH H
CN151 87-009-034-010 CONN,6P PH V
CN201 87-009-034-010 CONN,6P PH V
CN202 87-009-347-010 CONN,4P PH H WHT
CN301 87-A60-620-010 CONN,3P V 2MM JMT
CN351 87-A60-625-010 CONN,8P V 2MM JMT
CN451 87-009-032-010 CONNECTOR,4P YEL
CN452 87-A60-457-010 CONN,4P V TID-X
CN601 88-NF9-657-010 CONN,30P H BLK TYK-B(X)
CN603 87-099-014-010 CONN,12P 6216 V
CNA1 8Z-NF8-669-110 CONN ASSY,9P VH
FB602 87-008-372-080 FILTER, EMI BL OIRNI
FFE801 A8-6ZA-19C-170 6ZA-1 YFEENC
J201 87-A60-929-010 JACK,DIA6.3 BLK ST W/S TAI
J203 87-A60-238-010 TERMINAL,SP 4P (MSC)
J204 87-A60-750-010 JACK,PIN 4P R/W BLUE
J602 87-A60-881-010 JACK,PIN 2P MSP 242V05 PBSN
J801 87-A60-202-010 TERMINAL,ANT 4P MSP-154V-02
JR201 87-A91-685-080 C-F-BEAD, BLM11B121SB
JW811 87-008-372-080 FILTER, EMI BL OIRNI
L101 87-003-383-010 COIL,1UH-S
L102 83-XM1-617-080 C-COIL,BK2125HM601
L102 87-003-383-010 COIL,1UH-S
L103 83-XM1-617-080 C-COIL,BK2125HM601
L105 87-A91-502-080 C-F-BEAD, BLM11B750SA
L106 83-XM1-617-080 C-COIL,BK2125HM601
L107 83-XM1-617-080 C-COIL,BK2125HM601
L108 83-XM1-617-080 C-COIL,BK2125HM601
L125 83-XM1-617-080 C-COIL,BK2125HM601
L126 83-XM1-617-080 C-COIL,BK2125HM601
L201 87-005-780-080 C-COIL,10UH FLC32C
L201 87-003-383-010 COIL,1UH-S
L202 87-005-780-080 C-COIL,10UH FLC32C
L202 87-003-383-010 COIL,1UH-S
L451 87-007-342-010 COIL,OSC 85K BIAS
L771 87-A50-266-010 COIL,FM DET-2N(TOK)
L772 87-A91-110-010 FLTR,PCFJZH-450 (TOK)
L781 87-005-847-080 COIL,2.2UH(CECS)
L832 87-005-847-080 COIL,2.2UH(CECS)
L981 8Z-ZA1-650-010 COIL,AM PACK4C (TOK)
R20 87-A00-261-080 RES,M/F 0.56-1W J
R110 83-XM1-617-080 C-COIL,BK2125HM601
R128 83-XM1-617-080 C-COIL,BK2125HM601
R129 87-A00-257-080 RES,M/F 0.15-1W J
R130 87-A00-257-080 RES,M/F 0.15-1W J
R131 87-A00-257-080 RES,M/F 0.15-1W J
R132 87-A00-257-080 RES,M/F 0.15-1W J
R140 83-XM1-617-080 C-COIL,BK2125HM601
R150 87-010-178-080 CHIP CAP 1000P
R152 87-010-178-080 CHIP CAP 1000P
R165 87-A00-257-080 RES,M/F 0.15-1W J
R166 87-A00-257-080 RES,M/F 0.15-1W J
R202 87-010-322-080 C-CAP,S 100P-50 CH
R231 87-A00-258-080 RES,M/F 0.22-1W J
R232 87-A00-258-080 RES,M/F 0.22-1W J
R233 87-A00-258-080 RES,M/F 0.22-1W J
R234 87-A00-258-080 RES,M/F 0.22-1W J
R265 87-A00-258-080 RES,M/F 0.22-1W J
R266 87-A00-258-080 RES,M/F 0.22-1W J
R392 87-012-349-080 C-CAP,S 1000P-50 CH
R467 87-022-607-010 RES,M/F 0.47-1W J
R468 87-A00-420-080 C-RES,S 100K-1/10W B
R469 87-022-355-080 C-RES,S10K-1/10W F
R470 87-A00-420-080 C-RES,S 100K-1/10W B
R471 87-A00-420-080 C-RES,S 100K-1/10W B
R472 87-A00-420-080 C-RES,S 100K-1/10W B
R942 87-A91-667-080 C-F-BEAD, U BLM11B102S
R949 87-A91-667-080 C-F-BEAD, U BLM11B102S
R972 87-A91-667-080 C-F-BEAD, U BLM11B102S
R973 87-A91-667-080 C-F-BEAD, U BLM11B102S
! RY2 87-A90-976-010 RELAY,AC12V SDT-S-112LMR
SFR451 87-024-355-080 SFR,33K DIA6 H
SFR452 87-024-355-080 SFR,33K DIA6 H
T981 87-A91-639-010 TRANS,BALUN FM
WH1 87-A90-510-010 HLDR,WIRE 2.5-9P
X101 8A-AJ1-619-080 VIB,XTAL 33MHZ AT-49
X102 87-A70-236-040 C-VIB,XTAL 33.8688MHZ DSO751SA
X721 87-A70-061-010 VIB,XTAL 4.500MHZ CSA-309
CD-R C.B
C101 87-012-368-080 C-CAP,S 0.1-50 F
C102 87-012-368-080 C-CAP,S 0.1-50 F
C103 87-012-368-080 C-CAP,S 0.1-50 F

10
REF. NO PART NO. KANRI DESCRIPTION
NO.
REF. NO PART NO. KANRI DESCRIPTION
NO.
C104 87-012-368-080 C-CAP,S 0.1-50 F
C105 87-012-368-080 C-CAP,S 0.1-50 F
C106 87-010-401-040 CAP,E 1-50 SME
C107 87-012-368-080 C-CAP,S 0.1-50 F
C108 87-012-368-080 C-CAP,S 0.1-50 F
C110 87-012-368-080 C-CAP,S 0.1-50 F
C113 87-012-368-080 C-CAP,S 0.1-50 F
C114 87-012-368-080 C-CAP,S 0.1-50 F
C115 87-012-368-080 C-CAP,S 0.1-50 F
C116 87-012-368-080 C-CAP,S 0.1-50 F
C117 87-012-368-080 C-CAP,S 0.1-50 F
C118 87-012-368-080 C-CAP,S 0.1-50 F
C119 87-012-154-080 C-CAP,S 150P-50 J CH GRM
C120 87-012-368-080 C-CAP,S 0.1-50 F
C121 87-012-368-080 C-CAP,S 0.1-50 F
C122 87-010-154-080 CAP CHIP,10P
C123 87-010-154-080 CAP CHIP,10P
C124 87-010-831-080 C-CAP,U,0.1-16F
C125 87-010-831-080 C-CAP,U,0.1-16F
C126 87-010-831-080 C-CAP,U,0.1-16F
C127 87-012-368-080 C-CAP,S 0.1-50 F
C128 87-012-368-080 C-CAP,S 0.1-50 F
C129 87-012-368-080 C-CAP,S 0.1-50 F
C130 87-012-368-080 C-CAP,S 0.1-50 F
C131 87-012-368-080 C-CAP,S 0.1-50 F
C132 87-010-252-080 CAP,ELECT 1000-6.3V
C133 87-010-391-040 CAP,E 10-35 SME
C137 87-012-368-080 C-CAP,S 0.1-50 F
C138 87-012-368-080 C-CAP,S 0.1-50 F
C201 87-010-197-080 CAP,CHIP 0.01 DM
C203 87-012-368-080 C-CAP,S 0.1-50 F
C204 87-016-526-080 C-CAP,S 0.47-16 BK
C205 87-010-189-080 C-CAP,S 8200P-50 B
C206 87-012-368-080 C-CAP,S 0.1-50 F
C207 87-010-994-080 C-CAP,S 680P-50 J CH
C208 88-XMY-614-080 C-CAP,TN 10U-10 TCFG A
C209 87-012-368-080 C-CAP,S 0.1-50 F
C210 87-012-368-080 C-CAP,S 0.1-50 F
C211 88-XMY-614-080 C-CAP,TN 10U-10 TCFG A
C235 87-010-182-080 C-CAP,S 2200P-50 B
C236 87-010-182-080 C-CAP,S 2200P-50 B
C241 87-012-368-080 C-CAP,S 0.1-50 F
C454 87-010-805-080 CAP,S 1-16
C455 87-010-805-080 CAP,S 1-16
C456 87-010-552-040 CAP,E 22-16 GAS
C457 87-012-368-080 C-CAP,S 0.1-50 F
C491 87-010-498-040 CAP,E 10-16 M 5L SRE
C492 87-010-498-040 CAP,E 10-16 M 5L SRE
C966 87-010-196-080 CHIP CAPACITOR,0.1-25
C967 87-010-197-080 CAP,CHIP 0.01 DM
C968 87-010-197-080 CAP,CHIP 0.01 DM
C971 87-010-178-080 C-CAP,S 1000P-50 KB
C972 87-010-196-080 CHIP CAPACITOR,0.1-25
C974 87-010-322-080 C-CAP,S 100P-50 CH
C976 87-010-196-080 CHIP CAPACITOR,0.1-25
C977 87-010-196-080 CHIP CAPACITOR,0.1-25
C978 87-010-196-080 CHIP CAPACITOR,0.1-25
C985 87-010-178-080 C-CAP,S 1000P-50 KB
C992 87-012-191-080 C-CAP,U 68P-50 J CH
C995 87-010-196-080 CHIP CAPACITOR,0.1-25
C997 87-A11-517-080 C-CAP,S 820P-50 K CG
C998 87-010-196-080 CHIP CAPACITOR,0.1-25
C999 87-010-196-080 CHIP CAPACITOR,0.1-25
C1000 87-010-193-080 C-CAP,S 0.033-25 ZF
C1001 87-012-157-080 C-CAP,S 330P-50 J CH
C1002 87-012-157-080 C-CAP,S 330P-50 J CH
C1003 87-012-157-080 C-CAP,S 330P-50 J CH
C1004 87-012-153-080 C-CAP,S 120P-50 J CH
C1005 87-012-153-080 C-CAP,S 120P-50 J CH
C1006 87-018-125-080 CAP,TC U 330P-50 K
C1007 87-018-125-080 CAP,TC U 330P-50 K
C1008 87-018-120-080 CAP,TC U 120P-50 K
C1011 87-010-322-080 C-CAP,S 100P-50 J CH
CN101 87-A60-458-010 CONN,40P V IMSA-9031B
CN102 87-009-034-010 CONN,6P PH V
CN201 87-009-038-010 CONN,10P PH
CN202 87-009-038-010 CONN,10P PH
CN451 8A-AJ1-637-010 CONN ASSY,4P 240MM-PWLMT
CN452 87-A60-457-010 CONN,4P V TID-X
CNA101 8A-AJ1-632-010 CONN ASSY,40P 140MM-IDE
CNA103 8A-AJ1-633-010 CONN ASSY,7P 270MM-PWM
CNA452 8A-AJ1-631-010 CONN ASSY,4P 270MM-PD
JR201 87-A91-685-080 C-F-BEAD,BLM11B121SB
L102 83-XM1-617-080 C-COIL,BK2125HM601
L103 83-XM1-617-080 C-COIL,BK2125HM601
L105 87-A91-502-080 C-F-BEAD,BLM11B750SA
L106 83-XM1-617-080 C-COIL,BK2125HM601
L107 83-XM1-617-080 C-COIL,BK2125HM601
L108 83-XM1-617-080 C-COIL,BK2125HM601
L112 83-XM1-617-080 C-COIL,BK2125HM601
L113 83-XM1-617-080 C-COIL,BK2125HM601
L114 83-XM1-617-080 C-COIL,BK2125HM601
L115 83-XM1-617-080 C-COIL,BK2125HM601
L116 83-XM1-617-080 C-COIL,BK2125HM601
L117 83-XM1-617-080 C-COIL,BK2125HM601
L118 83-XM1-617-080 C-COIL,BK2125HM601
L120 83-XM1-617-080 C-COIL,BK2125HM601
L121 87-A50-190-080 C-COIL,S BLM21A102S
L122 87-A50-190-080 C-COIL,S BLM21A102S
L123 83-XM1-617-080 C-COIL,BK2125HM601
L125 83-XM1-617-080 C-COIL,BK2125HM601
L126 83-XM1-617-080 C-COIL,BK2125HM601
L201 87-005-780-080 C-COIL,10UH FLC32C
L202 87-005-780-080 C-COIL,10UH FLC32C
R150 87-010-178-080 C-CAP,S 1000P-50 KB
R202 87-010-322-080 C-CAP,S 100P-50 J CH
R210 83-XM1-617-080 C-COIL,BK2125HM601
R468 87-A00-420-080 C-RES,S 100K-1/10W B
R469 87-022-355-080 C-RES,S 10K-1/10W F
R470 87-A00-420-080 C-RES,S 100K-1/10W B
R471 87-A00-420-080 C-RES,S 100K-1/10W B
R472 87-A00-420-080 C-RES,S 100K-1/10W B
R932 83-XM1-617-080 C-COIL,BK2125HM601
R941 87-A91-667-080 C-F-BEAD,U BLM11B102S
R942 87-A91-667-080 C-F-BEAD,U BLM11B102S
R949 87-A91-667-080 C-F-BEAD,U BLM11B102S
R972 87-A91-667-080 C-F-BEAD,U BLM11B102S
R973 87-A91-667-080 C-F-BEAD,U BLM11B102S
X101 8A-AJ1-619-080 VIB,XTAL 33MHZ AT-49
X102 87-A70-236-040 C-VIB,XTAL 33.8688MHZ DSO751SA

1211
88
A
Resistor Code
Chip Resistor Part Coding
Figure
Value of resistor
Chip resistor
Wattage Type Tolerance
1/16W
1/10W
1/8W
1608
2125
3216
5%
5%
5%
CJ
CJ
CJ
Form LW t
1.6 0.8 0.45
2 1.25 0.45
3.2 1.6
108
118
128
: A
: A
CHIP RESISTOR PART CODE
0.55
Resistor Code
Dimensions (mm)
Symbol
1/16W 1005 5% CJ 1.0 0.5 0.35 104
Lt
W
• Regarding connectors, they are not stocked as they are not the initial order items.
The connectors are available after they are supplied from connector manufacturers upon the order is received.
TRANSISTOR ILLUSTRATION
ECBECB ECB
E
B
C
2SA1235F
2SA1362GR
2SA1586GR
2SC2714
2SC3052F
2SC4116GR
2SK2158
CD1585BC
CMBT5401
CMBT5551
2SC3331
CSC4115BC CC5551
KTA1266
KTC3198
ECB
ECB
ECB D
S
G
2SA1329Y
2SB1342
2SB1344
2SB1370
2SB1370E
2SD1933
2SD2025
2SK3053
2SJ106GR
DTA114EK
DTA114YK
DTA143EK
DTC114EK
DTC114YK
DTC144WKA
RT1N141C
RT1N144C
RT1N441C
RT1P141C
RT1P144C
2SJ460
2SK2541
DTC114ES
KTC3199GR
2SB1436

1413
FL GRID ASSIGNMENT/ANODE CONNECTION

1615
SCHEMATIC DIAGRAM-1 (MAIN 1/2)
MAIN C.B 1/2

1817
SCHEMATIC DIAGRAM-2 (MAIN 2/2: TUNER SECTION)
MAIN 2/2 (TUNER SECTION)
