ELECTRICAL MAIN PARTS LIST - 1/7
NOTE: The characters in the suffix column indicate the part usage.
S ......................OO..................................A...................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
C 1 87-010-387-080 1A CAP,E 470-25 SME A...................
C 4 87-010-403-080 0E CAP, ELECT 3.3-50V A...................
C 9 87-010-917-090 1D CAP,E 3300-50 M SMG A...................
C 8 87-010-917-090 1D CAP,E 3300-50 M SMG A...................
C 2 87-018-209-080 0E CAP, CER 0.1-50V ....................
C 5 87-A10-479-080 0E CAP,CER 2200P-250 M E KH A...................
C 10 87-018-209-080 0E CAP, CER 0.1-50V A...................
C 11 87-018-209-080 0E CAP, CER 0.1-50V A...................
CN 1 87-A60-851-010 0E CONN,9P V VH A...................
D 6 87-020-465-080 0E DIODE,1SS133 (110MA) A...................
D 1 87-020-465-080 0E DIODE,1SS133 (110MA) A...................
D 2 87-020-465-080 0E DIODE,1SS133 (110MA) A...................
D 7 87-020-465-080 0E DIODE,1SS133 (110MA) A...................
D 4 87-020-465-080 0E DIODE,1SS133 (110MA) A...................
D 3 87-020-465-080 0E DIODE,1SS133 (110MA) A...................
D 5 87-020-465-080 0E DIODE,1SS133 (110MA) A...................
D 8 87-A40-548-090 1A DIODE,D3SBA20 A...................
PR 3 87-026-682-080 0E PROTECTOR,10A 60V491 A...................
PR 2 87-026-682-080 0E PROTECTOR,10A 60V491 A...................
PR 3 87-026-691-080 1A FUSE,10A 125V 251 ....................
PR 2 87-026-691-080 1A FUSE,10A 125V 251 ....................
PR 1 87-A91-276-080 1B FUSE,125MA 125V F 251 ....................
PT 2 8Z-NF8-660-110 1C PT,SUB ZNF-8(D) A...................
PT 2 8Z-NF8-661-010 1D PT,SUB ZNF-8(U) ....................
PT 2 8Z-NF8-662-010 1D PT,SUB ZNF-8(E) ....................
Q 1 87-026-245-080 0E TR,DTC114ES A...................
Q 2 87-A30-198-080 0E TR,KTC3199GR A...................
RY 1 87-A90-976-010 1B RELAY,AC12V SDT-S-112LMR A...................
T 2 87-A60-317-010 0E TERMINAL, 1P MSC A...................
T 1 87-A60-317-010 0E TERMINAL, 1P MSC A...................
87-NF5-203-010 1A GUIDE,FL A...................
8Z-NB6-221-010 GUIDE,OPE A...................
8Z-NB6-223-010 GUIDE,DIRECT CD A...................
8Z-NB6-224-010 GUIDE,FUN A...................
* 8Z-NB6-610-010 2B PWB,COMB FRONT A...................
C 143 87-010-194-080 0E CAP, CHIP 0.047 A...................
C 141 87-010-263-040 0E CAP,E 100-10 A...................
C 155 87-010-154-080 0E CAP CHIP 10P A...................
C 158 87-010-178-080 0E CHIP CAP 1000P A...................
C 159 87-010-196-080 0E CHIP CAPACITOR,0.1-25 A...................
C 152 87-010-196-080 0E CHIP CAPACITOR,0.1-25 A...................
C 151 87-010-264-040 0E CAP,E 100-10 5L A...................
C 153 87-010-493-040 0E CAP,E 0.47-50 GAS A...................
C 156 87-010-854-080 0E C-CAP,S 560PCH A...................
C 154 87-A10-189-040 0E CAP,E 220-10 A...................
C 166 87-010-075-040 0E CAP,E 10-16 5L A...................
C 161 87-010-196-080 0E CHIP CAPACITOR,0.1-25 A...................
C 160 87-010-196-080 0E CHIP CAPACITOR,0.1-25 A...................
C 165 87-012-157-080 0E C-CAP,S 330P-50 CH A...................
C 171 87-010-194-080 0E CAP, CHIP 0.047 A...................
C 174 87-010-406-040 0E CAP,E 22-50 SME A...................
C 172 87-010-408-040 0E CAP,E 47-50 SME A...................
C 173 87-010-981-040 0E CAP,E 22-35 5L SRE A...................
C 180 87-010-194-080 0E CAP, CHIP 0.047 A...................
C 183 87-010-197-080 0E CAP, CHIP 0.01 DM A...................
C 182 87-012-156-080 0E C-CAP,S 220P-50 CH A...................
C 181 87-012-156-080 0E C-CAP,S 220P-50 CH A...................
C 192 87-010-196-080 0E CHIP CAPACITOR,0.1-25 A...................
C 191 87-012-368-080 0E C-CAP,S 0.1-50 F A...................
C 281 87-010-561-040 0E CAP,E 100-16 GAS A...................
C 402 87-010-196-080 0E CHIP CAPACITOR,0.1-25 A...................
C 405 87-010-318-080 0E C-CAP,S 47P-50 CH A...................
C 407 87-010-318-080 0E C-CAP,S 47P-50 CH A...................
C 403 87-010-318-080 0E C-CAP,S 47P-50 CH A...................
C 408 87-010-318-080 0E C-CAP,S 47P-50 CH A...................
C 406 87-010-318-080 0E C-CAP,S 47P-50 CH A...................
C 404 87-010-318-080 0E C-CAP,S 47P-50 CH A...................
C 401 87-010-560-040 0E CAP,E 10-50 GAS A...................
C 410 87-010-196-080 0E CHIP CAPACITOR,0.1-25 A...................
C 413 87-010-318-080 0E C-CAP,S 47P-50 CH A...................
C 412 87-010-318-080 0E C-CAP,S 47P-50 CH A...................
C 411 87-010-318-080 0E C-CAP,S 47P-50 CH A...................
C 451 87-010-561-040 0E CAP,E 100-16 GAS A...................
C 703 87-010-196-080 0E CHIP CAPACITOR,0.1-25 A...................
C 705 87-010-196-080 0E CHIP CAPACITOR,0.1-25 A...................
C 706 87-010-196-080 0E CHIP CAPACITOR,0.1-25 A...................
C 701 87-010-196-080 0E CHIP CAPACITOR,0.1-25 A...................
C 707 87-010-196-080 0E CHIP CAPACITOR,0.1-25 A...................
C 704 87-010-196-080 0E CHIP CAPACITOR,0.1-25 A...................
C 702 87-012-158-080 0E C-CAP,S 390P-50 CH A...................
CN 102 87-099-030-010 0E CONN,13P 6216H A...................
CN 101 87-A60-350-010 1B CONN 30P DF8A-30P A...................
CN 252 87-099-209-010 0E CONN,4P 6216H A...................
CN 352 87-099-031-010 0E CONN,14P 6216 H A...................
CN 351 87-099-031-010 0E CONN,14P 6216 H A...................
CN 451 87-099-209-010 0E CONN,4P 6216H A...................
