Aiwa NSX-TR77 User manual
SERVICE MANUAL
DATA
CD STEREO SYSTEM
NSX-TR77
S/M Code No. 09-029-361-6N1
U(S)
BASIC TAPE MECHANISM : ZZM-3 YPR3NC
BASIC CD MECHANISM : BZG-2 ZD5GNC2
NSX-TR77
SPEAKERSYSTEM CD
CASSEIVER
CX-SNTR77
REMOTE
CONTROLLER
RC-CAS02
SX-SNTR77
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
-2-
SPECIFICATIONS ...............................................................................................................................................................4
PROTECTION OF EYES FROM LASER BEAM DURING SERVICING ......................................................................5
NOTE ON BEFORE STARTING REPAIR ...................................................................................................................6, 7
ACCESSORIES PARTS LIST..............................................................................................................................................8
ELECTRICAL PARTS LIST .......................................................................................................................................9 ~ 24
TRANSISTOR ILLUSTRATION ........................................................................................................................................25
SCHEMATIC DIAGRAM -1/5 (MAIN C.B-1/2, AMP SECTION)........................................................................................ 26
SCHEMATIC DIAGRAM -2/5 (MAIN C.B-2/2, TUNER SECTION) ................................................................................... 27
SCHEMATIC DIAGRAM -3/5 (HP C.B)............................................................................................................................. 28
WIRING -1/4 (MAIN C.B/HP C.B) ...................................................................................................................................... 29
SCHEMATIC DIAGRAM -4/5 (FRONT C.B/DECK C.B) .................................................................................................. 30
WIRING -2/4 (FRONT C.B)................................................................................................................................................31
WIRING -3/4 (DECK C.B) .................................................................................................................................................. 32
SCHEMATIC DIAGRAM -5/5 (POWER C.B) .................................................................................................................... 33
WIRING -4/4 (POWER C.B)............................................................................................................................................... 34
ELECTRICAL ADJUSTMENT....................................................................................................................................35 ~ 41
CD TEST MODE ................................................................................................................................................................ 42
FL DISPLAY.................................................................................................................................................................43, 44
IC BLOCK DIAGRAM.......................................................................................................................................................45
IC DESCRIPTION ....................................................................................................................................................... 46, 47
MECHANICAL EXPLODED VIEW.................................................................................................................................. 48
MECHANICAL MAIN PARTS LIST ............................................................................................................................. 49, 50
COLOR NAME TABLE.....................................................................................................................................................51
TAPE MECHANISM EXPLODED VIEW <ZZM-3> ........................................................................................................ 52
TAPE MECHANISM PARTS LIST <ZZM-3> ............................................................................................................ 53, 54
GENERAL SPEAKER DISASSEMBLY INSTRUCTIONS (FOR REFERENCE) ........................................................... 55
SPEAKER PARTS LIST (SX-SNTR77) ........................................................................................................................... 56
OTHER PARTS LIST .................................................................................................................................................57, 58
TABLE OF CONTENTS -1/2
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
-3-
CD MECHANISM SECTION
CD MECHANISM SECTION .............................................................................................................................................. 59
How to Adjust the Rotating Phase of the Gear, Main Cam ................................................................................................ 59
ELECTRICAL PARTS LIST .......................................................................................................................................60 ~ 63
TRANSISTOR ILLUSTRATION .........................................................................................................................................63
BLOCK DIAGRAM-1/1 ....................................................................................................................................................... 64
WIRING-1/2 (3CD) ............................................................................................................................................................. 65
SCHEMATIC DIAGRAM -1/1 ............................................................................................................................................ 66
WIRING -2/2 (T-T).............................................................................................................................................................. 67
WAVE FORM ..................................................................................................................................................................... 68
IC BLOCK DIAGRAM......................................................................................................................................................... 69
IC DESCRIPTION ......................................................................................................................................................70 ~ 72
CD MECHANISM EXPLODED VIEW<BZG-2> ................................................................................................................. 73
CD MECHANISM PARTS LIST<BZG-2>........................................................................................................................... 74
COLOR NAME TABLE....................................................................................................................................................... 75
TABLE OF CONTENTS -2/2
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
-4-
SPECIFICATIONS -1/1
MAIN UNIT CX-NTR77 (U)
TUNER
FM tuning range 87.5 MHz to 108 MHz
FM usable sensitivity (IHF) 13.2 dBf
FM antenna terminal 75 ohms (unbalanced)
AM tuning range 530kHz to1710 kHz(10 kHzstep)
531 kHz to 1602 kHz (9 kHz step)
AM usable sensitivity 350 µV/m
AM antenna Loop antenna
AMPLIFIER
Power output 120 W + 120 W (40 Hz - 20 kHz,
THD less than 1 %, 6 ohms)
150 W + 150 W (1 kHz, THD less
than 10 %, 6 ohms)
Total harmonic distortion 0.08 % (75 W, 1 kHz, 6 ohms, DIN
AUDIO)
Input VIDEO/AUX: 700 mV
Outputs SPEAKERS: 6 ohms or more
PHONES: 32 ohms or more
CASSETTE DECK
Track format 4 tracks, 2 channels stereo
Frequency response 50 Hz – 15 kHz
Recording system AC bias
Heads DECK 1: playback x 1
DECK 2: recording/playback x 1,
erase x 1
CD PLAYER
Laser Semiconductorlaser(λ=780nm)
D/A converter 1 bit dual
Signal-to-noise ratio 85 dB (1 kHz, 0 dB)
Harmonic distortion 0.05 % (1 kHz, 0 dB)
GENERAL
Power requirements 120 V AC, 60 Hz
Power consumption 130 W
Power consumption With ECO mode on: 0.6 W
in standby mode With ECO mode off: 25 W
Dimensions (W x H x D) 260 x 324 x 391 mm
(10
1
/
4
x 12
7
/
8
x 15
1
/
2
in.)
Weight 8.7 kg (19 lbs 3 oz)
FRONT SPEAKERS SX-NTR77
Speaker system 3 way, bass reflex
Speaker units
Woofer:120mm(4
3
/
4
in.)conex3
Tweeter: 60 mm (2
3
/
8
in.) cone
Super tweeter: 20 mm (
13
/
16
in.)
ceramic
Impedance 6 ohms
Dimensions (W x H x D) 275 x 370 x 297 mm
(10
7
/
8
x 14
5
/
8
x 11
3
/
4
in.)
Weight 5.1 kg (11 lbs 4 oz)
Specificationsandexternalappearancearesubjecttochange
without notice.
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
-5-
This set employs laser. Therefore, be sure to follow carefully the
instructions below when servicing.
WARNING!!
WHEN SERVICING, DO NOT APPROACH THE LASER
EXIT WITH THE EYE TOO CLOSELY. IN CASE IT IS
NECESSARYTOCONFIRMLASERBEAMEMISSION.BE
SURE TO OBSERVE FROM A DISTANCE OF MORE
THAN 30cm FROM THE SURFACE OF THE OBJECTIVE
LENS ON THE OPTICAL PICK-UP BLOCK.
Caution: Invisible laser radiation when
open and interlocks defeated avoid
exposure to beam.
Advarsel: Usynlig laserståling vedåbning,
når sikkerhedsafbrydere er ude af funktion.
Undgå udsÊttelse for stråling.
VAROITUS!
Laiteen Käyttäminen muulla kuin tässä käyttöohjeessa
mainitulla tavalla saataa altistaa käyt-täjän
turvallisuusluokan 1 ylittävälle näkymättömälle
lasersäteilylle.
VARNING!
Om apparaten används på annat sätt än vad som
specificeras i denna bruksanvising, kan användaren
utsättas för osynling laserstrålning, som överskrider
gränsen för laserklass 1.
PROTECTION OF EYES FROM LASER BEAM DURING SERVICING -1/1
CAUTION
Use of controls or adjustments or performance of proce-
dures other than those specified herin may result in
hazardous radiation exposure.
ATTENTION
L'utillisationdecommandes,réglagesouprocéduresautres
que ceux spécifiés peut entraîner une dangereuse
exposition aux radiations.
ADVARSEL
Usynliglaserstålingvedåbning,nårsikkerhedsafbrydereer
ude af funktion. Undgå udsættelse for stråling.
This Compact Disc player is classified as a CLASS 1
LASER product.
The CLASS 1 LASER PRODUCT label is located on the
rear exterior.
CLASS 1 LASER PRODUCT
KLASSE 1 LASER PRODUKT
LUOKAN 1 LASER LAITE
KLASS 1 LASERAPPARAT
Precaution to replace Optical block
(KSM-213RSCM)
Body or clothes electrostatic potential could
ruin laser diode in the optical block. Be sure
ground body and workbench, and use care
the clothes do not touch the diode.
1) After the connection, remove solder shown in
right figure.
CD PICK-UP Assy PWB
Solder
Solder
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
-6-
NOTE ON BEFORE STARTING REPAIR -1/2
1. Forced discharge of electrolytic capacitor of power supply block
When repair is going to be attempted in the set that uses relay circuit in the power supply block, electric potential is kept charged across the
electrolytic capacitors (C101, 102) even though AC power cord is removed. If repair is attempted in this condition, secondary defect can occur.
In order to prevent the secondary trouble, perform the following measures before starting repair work.
Discharge procedure
1 Remove the AC power cord.
2 Connect a discharging resistor at an end of lead wire that has
clips at both ends. Connect the other end of the lead wire to
metal chassis.
3 Contact the other end of the discharging resistor to the
positive (+) side (+VH) of C101. (For two seconds)
4 Contact the same end of the discharging resistor as step 3 to
the negative (-) side (-VH) of C102 in the same way.
(For two seconds)
5 Check that voltage across C101 and C102 has decreased to
1 V or less using a multimeter or an oscilloscope.
Select a discharging resistor referring to the following table.
Note: The reference numbers (C101, C102) of the electrolytic capacitors can change depending on the models. Be sure to check the reference numbers
of the charging capacitors on schematic diagram before starting the discharging work.
2. Check items before exchanging the MICROCOMPUTER
Be sure to check the following items before exchanging the MICROCOMPUTER. Exchange the MICROCOMPUTER after confirming that the
MICROCOMPUTER is surely defective.
2-1. Regarding the HOLD terminal of the MICROCOMPUTER
When the HOLD terminal (INPUT) of the MICROCOMPUTER is "H", the MICROCOMPUTER is judged to be operating correctly.
When this terminal is "L", the main power cannot be turned on. Therefore, be sure to check the terminal voltage of the HOLD terminal before
exchange.
When the MICROCOMPUTER is not defective, the HOLD terminal can also go "L" when the POWER AMPLIFIER has any abnormalities
that triggers the abnormality detection circuit on the MAIN C. B. that sets the HOLD terminal to "L".
• Good or no good judgement of the MICROCOMPUTER
1 Turn on the AC main power.
2 Confirm that the main power is turned on and the HOLD terminal of the MICROCOMPUTER keeps the "H" level or not.
3 When the HOLD terminal is "L" level, the abnormality detection circuit is judged to be working correctly and the MICRO
COMPUTER is judged to be good.
Fig-1
MAIN C.B
D101
C101 C102
34
22
Charging voltage (V) Discharging Rated power (W) Parts number
(C101, 102) resistor ( )
25-48 100 3 87-A00-247-090
49-140 220 5 87-A00-232-090
CN701 CN601
Q060
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
-7-
In such a case, check also if the POWER AMPLIFIER circuit or power supply circuit has any abnormalities or not.
2-2. Regarding reset
There are cases that the machine does not work correctly because the MICROCOMPUTER is not reset even though the AC power cord is
re-inserted, or the software reset (pressing the STOP key + POWER key) is performed.
When the above described phenomenon occurs, it can lead to wrong judgement as if the MICROCOMPUTER is defective and to exchange the
MICROCOMPUTER. In such a case, perform the forced-reset by the following procedure and check good or no good of the MICROCOM
PUTER.
1 Remove the AC power cord.
2 Short both ends of the electrolytic capacitor C913 that is connected to VDD of the MICROCOMPUTER with tweezers.
3 Connect the AC power cord again. If the MICROCOMPUTER returns to the normal operation, the MICROCOMPUTER is good.
Note: The reference number or MICROCOMPUTER pin number of transistor (Q060) and electrolytic capacitor (C913) can change depending on the
models. Be sure to check the reference numbers on schematic diagram before starting the discharging work.
2-3. Confirmation of soldering state of MICROCOMPUTER
Check the soldering state of the MICROCOMPUTER in addition to the above described procedures. Be sure to exchange the
MICROCOMPUTER after surely confirming that the trouble is not caused by poor soldering but the MICROCOMPUTER itself.
NOTE ON BEFORE STARTING REPAIR -2/2
Fig-2-2
MICRO-
COMPUTER
MICROCOMPUTER
FRONT C.B
FRONT C.B
VSS
VDD
C913
17
14
C913
17
14
Short with tweezers.
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-8-
ACCESSORIES PARTS LIST -1/1
CX-SNTR77
USTC
O AS1001 8C-NFT-903-010 IB,U(ESF)BF NSX-TR77 a
O AS1002 8C-NF5-701-010 RC UNIT,RC-CAS02 ALPS a
O AS1003 87-006-225-110 ANT,LOOP ANT NC2 a
O AS1004 87-A92-345-110 ANT,WIRE FM(SEMI-ST) a
X AS1007 87-B50-053-010 WARR-CARD,USA CUST/AV,VISUAL a
X AS1008 87-B40-034-010 LBL,USA 1-800 a
X AS1009 87-B40-085-010 BAG,PV 0.04-200-350 PL a
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-9-
ELECTRICAL PARTS LIST - 1/16
CX-SNTR77
USTC
FRONT O C 0108 87-010-785-080 C-CAP,U 0.015-25 K B GRM a
FRONT O C 0153 87-010-787-080 C-CAP,U 0.022-25 K B GRM a
FRONT O C 0154 87-010-246-040 CAP,E 47-35 M 11L SME a
FRONT O C 0155 87-010-404-040 CAP,E 4.7-50 M 11L SME a
FRONT O C 0156 87-010-404-040 CAP,E 4.7-50 M 11L SME a
FRONT O C 0201 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
FRONT O C 0202 87-012-195-080 C-CAP,U 100P-50 J CH GRM a
FRONT O C 0203 87-012-195-080 C-CAP,U 100P-50 J CH GRM a
FRONT O C 0204 87-012-195-080 C-CAP,U 100P-50 J CH GRM a
FRONT O C 0301 87-012-278-080 C-CAP,U 2200P-50 K B GRM a
FRONT O C 0351 87-A10-353-080 C-CAP,U 0.22-10 K B a
FRONT O C 0383 87-A12-319-080 C-CAP,U 0.1-25 K B a
FRONT O C 0384 87-A12-319-080 C-CAP,U 0.1-25 K B a
FRONT O C 0385 87-A12-319-080 C-CAP,U 0.1-25 K B a
FRONT O C 0386 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
FRONT O C 0387 87-A12-319-080 C-CAP,U 0.1-25 K B a
FRONT O C 0601 87-010-260-040 CAP,E 47-25 M 11L SME a
FRONT O C 0911 87-012-274-080 C-CAP,U 1000P-50 K B GRM a
FRONT O C 0912 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
FRONT O C 0913 87-010-248-040 CAP,E 220-10 M 11L SME a
CX-SNTR77
USTC
FRONT O C 0915 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
FRONT O C 0916 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
FRONT O C 0917 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
FRONT O C 0919 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
FRONT O C 0920 87-010-829-080 C-CAP,U 0.047-16 Z F CM/CB a
FRONT O C 0921 87-012-282-080 C-CAP,U 4700P-50 K B GRM a
FRONT O C 0951 87-012-176-080 C-CAP,U 15P-50 J CH GRM a
FRONT O C 0952 87-012-195-080 C-CAP,U 100P-50 J CH GRM a
FRONT O C 0953 87-012-145-080 C-CAP,S 270P-50 J CH GRM a
FRONT O C 0954 87-012-184-080 C-CAP,U 33P-50 J CH GRM a
FRONT O C 0955 87-012-184-080 C-CAP,U 33P-50 J CH GRM a
FRONT O C 0961 87-010-406-040 CAP,E 22-50 M 11L SME a
FRONT O C 0963 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
FRONT O CN 0104 87-099-013-010 CONN,11P V BLK 6216 a
FRONT O CN 0201 87-099-199-010 CONN,6P H BLK 6216 a
FRONT O CN 0301 87-099-030-010 CONN,13P H BLK 6216 a
FRONT O CN 0701 87-099-720-010 CONN,30P BLK TYK-B(P) a
FRONT O CN 0731 87-099-196-010 CONN,8P V BLK 6216 a
FRONT S D 0104 87-020-465-080 DIODE,1SS133 a
FRONT S D 0301 87-A40-748-080 ZENER,UZ5.6BSA a
CX-SNTR77
USTC
FRONT S D 0302 87-020-465-080 DIODE,1SS133 a
FRONT S D 0305 87-020-465-080 DIODE,1SS133 a
FRONT S D 0306 87-020-465-080 DIODE,1SS133 a
FRONT S D 0381 87-020-465-080 DIODE,1SS133 a
FRONT S D 0382 87-020-465-080 DIODE,1SS133 a
FRONT S D 0383 87-020-465-080 DIODE,1SS133 a
FRONT S D 0384 87-020-465-080 DIODE,1SS133 a
FRONT S D 0385 87-A40-802-080 ZENER,UZ5.1BSC a
FRONT S D 0601 87-A40-269-040 C-DIODE,MC2836 a
FRONT O FL 0901 8C-NFT-601-010 FL,CNF-T BJ890GNK a
FRONT S IC 0381 87-A21-023-040 C-IC,BA3835F a
FRONT S IC 0601 87-A21-021-040 C-IC,BU2099FV a
FRONT S IC 0901 8C-NFT-602-030 C-IC,LC876764A-50J3 a
FRONT S IC 0961 87-A21-831-010 IC,SPS-442-1-F1 a
FRONT O JR 0601 88-108-101-080 C-RES,U 100-1/16W J a
FRONT O JR 0617 88-108-101-080 C-RES,U 100-1/16W J a
FRONT O JR 0619 88-108-101-080 C-RES,U 100-1/16W J a
FRONT X JW 0937 88-121-101-080 RES,100-1/8W J a
FRONT O L 0951 8C-NFT-603-010 COIL,CLK9.43MHZ POT a
FRONT O LED0201 87-A40-317-080 LED,SLR-342VCT31 RED a
CX-SNTR77
USTC
FRONT S Q 0102 87-A30-076-040 C-TR,2SC3052F a
FRONT S Q 0103 87-A30-538-040 C-TR,SRA2202S a
FRONT S Q 0301 87-A30-494-080 TR,2SA1980G a
FRONT S Q 0302 87-A30-076-040 C-TR,2SC3052F a
FRONT S Q 0303 87-A30-076-040 C-TR,2SC3052F a
FRONT S Q 0601 87-A30-495-080 TR,2SA1981Y a
FRONT S Q 0602 87-A30-495-080 TR,2SA1981Y a
FRONT S Q 0603 89-112-965-080 TR,2SA1296GR a
FRONT S Q 0901 87-A30-538-040 C-TR,SRA2202S a
FRONT O R 0109 88-108-224-080 C-RES,U 220K-1/16W J a
FRONT O R 0110 88-108-153-080 C-RES,U 15K-1/16W J a
FRONT X R 0111 88-108-333-080 C-RES,U 33K-1/16W J a
FRONT X R 0112 88-108-184-080 C-RES,U 180K-1/16W J a
FRONT O R 0114 88-108-103-080 C-RES,U 10K-1/16W J a
FRONT X R 0115 88-108-183-080 C-RES,U 18K-1/16W J a
FRONT X R 0116 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT X R 0150 88-128-332-080 C-RES, 3.3K-1/8W J a
FRONT X R 0151 88-100-000-010 JUMPER WIRE,PLATING a
FRONT X R 0152 88-100-000-010 JUMPER WIRE,PLATING a
FRONT X R 0153 88-118-821-080 C-RES,S 820-1/10W J a
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-10-
ELECTRICAL PARTS LIST - 2/16
CX-SNTR77
USTC
FRONT X R 0154 88-118-821-080 C-RES,S 820-1/10W J a
FRONT X R 0155 88-128-332-080 C-RES, 3.3K-1/8W J a
FRONT X R 0159 88-108-000-080 C-JUMPER,U a
FRONT X R 0160 88-108-000-080 C-JUMPER,U a
FRONT X R 0161 88-108-000-080 C-JUMPER,U a
FRONT X R 0162 88-108-000-080 C-JUMPER,U a
FRONT X R 0163 88-108-000-080 C-JUMPER,U a
FRONT X R 0164 88-108-000-080 C-JUMPER,U a
FRONT X R 0165 88-108-000-080 C-JUMPER,U a
FRONT X R 0166 88-108-000-080 C-JUMPER,U a
FRONT X R 0206 88-130-561-080 RES,560-1/4W J a
FRONT X R 0207 88-130-561-080 RES,560-1/4W J a
FRONT X R 0208 88-121-182-080 RES,1.8K-1/8W J a
FRONT X R 0211 88-130-561-080 RES,560-1/4W J a
FRONT X R 0212 88-130-561-080 RES,560-1/4W J a
FRONT O R 0213 88-108-103-080 C-RES,U 10K-1/16W J a
FRONT O R 0215 88-108-103-080 C-RES,U 10K-1/16W J a
FRONT O R 0216 88-108-103-080 C-RES,U 10K-1/16W J a
FRONT O R 0218 88-108-101-080 C-RES,U 100-1/16W J a
FRONT X R 0301 88-108-104-080 C-RES,U 100K-1/16W J a
CX-SNTR77
USTC
FRONT X R 0302 88-108-472-080 C-RES,U 4.7K-1/16W J a
FRONT O R 0303 88-108-153-080 C-RES,U 15K-1/16W J a
FRONT O R 0304 88-108-102-080 C-RES,U 1K-1/16W J a
FRONT X R 0306 88-108-471-080 C-RES,U 470-1/16W J a
FRONT O R 0321 88-108-103-080 C-RES,U 10K-1/16W J a
FRONT O R 0341 88-108-103-080 C-RES,U 10K-1/16W J a
FRONT O R 0351 88-108-103-080 C-RES,U 10K-1/16W J a
FRONT O R 0352 88-108-102-080 C-RES,U 1K-1/16W J a
FRONT X R 0353 88-108-821-080 C-RES,U 820-1/16W J a
FRONT X R 0354 88-108-122-080 C-RES,U 1.2K-1/16W J a
FRONT X R 0360 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT O R 0361 88-108-101-080 C-RES,U 100-1/16W J a
FRONT X R 0380 88-108-393-080 C-RES,U 39K-1/16W J a
FRONT X R 0384 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT X R 0386 88-108-273-080 C-RES,U 27K-1/16W J a
FRONT X R 0387 88-108-273-080 C-RES,U 27K-1/16W J a
FRONT X R 0388 88-108-273-080 C-RES,U 27K-1/16W J a
FRONT X R 0390 88-121-391-080 RES,390-1/8W J a
FRONT X R 0391 88-108-472-080 C-RES,U 4.7K-1/16W J a
FRONT X R 0392 88-108-472-080 C-RES,U 4.7K-1/16W J a
FRONT X R 0393 88-108-472-080 C-RES,U 4.7K-1/16W J a
FRONT X R 0394 88-108-472-080 C-RES,U 4.7K-1/16W J a
FRONT O R 0397 88-108-223-080 C-RES,U 22K-1/16W J a
FRONT X R 0420 88-108-000-080 C-JUMPER,U a
FRONT O R 0601 88-108-103-080 C-RES,U 10K-1/16W J a
FRONT X R 0602 88-108-222-080 C-RES,U 2.2K-1/16W J a
FRONT O R 0603 88-108-103-080 C-RES,U 10K-1/16W J a
FRONT X R 0604 88-108-222-080 C-RES,U 2.2K-1/16W J a
FRONT O R 0605 88-108-103-080 C-RES,U 10K-1/16W J a
FRONT O R 0606 88-108-102-080 C-RES,U 1K-1/16W J a
FRONT X R 0607 88-108-000-080 C-JUMPER,U a
FRONT O R 0611 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT O R 0612 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT O R 0613 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT O R 0614 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT O R 0615 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT O R 0616 88-108-473-080 C-RES,U 47K-1/16W J a
FRONT O R 0618 88-108-103-080 C-RES,U 10K-1/16W J a
FRONT O R 0620 88-108-103-080 C-RES,U 10K-1/16W J a
FRONT O R 0704 88-108-102-080 C-RES,U 1K-1/16W J a
CX-SNTR77
USTC
FRONT O R 0705 88-108-102-080 C-RES,U 1K-1/16W J a
FRONT O R 0706 88-108-102-080 C-RES,U 1K-1/16W J a
FRONT O R 0707 88-108-102-080 C-RES,U 1K-1/16W J a
FRONT O R 0708 88-108-102-080 C-RES,U 1K-1/16W J a
FRONT O R 0709 88-108-101-080 C-RES,U 100-1/16W J a
FRONT O R 0710 88-108-101-080 C-RES,U 100-1/16W J a
FRONT O R 0711 88-108-101-080 C-RES,U 100-1/16W J a
FRONT O R 0712 88-108-101-080 C-RES,U 100-1/16W J a
FRONT X R 0716 88-108-472-080 C-RES,U 4.7K-1/16W J a
FRONT X R 0719 88-121-100-080 RES,10-1/8W J a
FRONT O R 0721 88-108-101-080 C-RES,U 100-1/16W J a
FRONT O R 0730 88-108-102-080 C-RES,U 1K-1/16W J a
FRONT O R 0732 88-108-101-080 C-RES,U 100-1/16W J a
FRONT O R 0733 88-108-101-080 C-RES,U 100-1/16W J a
FRONT O R 0734 88-108-102-080 C-RES,U 1K-1/16W J a
FRONT O R 0735 88-108-102-080 C-RES,U 1K-1/16W J a
FRONT O R 0740 88-108-102-080 C-RES,U 1K-1/16W J a
FRONT O R 0741 88-108-101-080 C-RES,U 100-1/16W J a
FRONT O R 0742 88-108-102-080 C-RES,U 1K-1/16W J a
FRONT X R 0743 88-108-474-080 C-RES,U 470K-1/16W J a
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-11-
ELECTRICAL PARTS LIST - 3/16
CX-SNTR77
USTC
FRONT X R 0749 88-108-474-080 C-RES,U 470K-1/16W J a
FRONT X R 0901 88-108-685-080 C-RES,U 6.8M-1/16W J a
FRONT O R 0903 88-108-103-080 C-RES,U 10K-1/16W J a
FRONT O R 0906 88-108-103-080 C-RES,U 10K-1/16W J a
FRONT X R 0907 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT X R 0908 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT X R 0909 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT X R 0910 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT X R 0911 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT X R 0912 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT X R 0913 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT X R 0914 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT X R 0915 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT X R 0916 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT X R 0921 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT X R 0922 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT X R 0923 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT X R 0924 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT X R 0925 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT X R 0926 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT X R 0927 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT X R 0928 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT X R 0929 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT X R 0930 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT X R 0931 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT X R 0932 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT X R 0933 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT X R 0934 88-108-683-080 C-RES,U 68K-1/16W J a
FRONT X R 0935 88-108-683-080 C-RES,U 68K-1/16W J a
FRONT X R 0937 88-121-102-080 RES,1K-1/8W J a
FRONT X R 0940 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT X R 0946 88-108-000-080 C-JUMPER,U a
FRONT X R 0947 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT X R 0948 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT X R 0949 88-108-000-080 C-JUMPER,U a
FRONT O R 0951 88-108-101-080 C-RES,U 100-1/16W J a
FRONT O R 0961 88-108-101-080 C-RES,U 100-1/16W J a
FRONT O R 0963 88-108-563-080 C-RES,U 56K-1/16W J a
FRONT X R 0964 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT X R 0965 88-108-104-080 C-RES,U 100K-1/16W J a
CX-SNTR77
USTC
FRONT X R 0966 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT X R 0967 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT X R 0968 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT O R 0969 88-108-103-080 C-RES,U 10K-1/16W J a
FRONT X R 0970 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT X R 0971 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT X R 0972 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT X R 0973 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT X R 0974 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT X R 0975 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT X R 0976 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT X R 0977 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT X R 0978 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT X R 0979 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT X R 0980 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT X R 0982 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT X R 0983 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT X R 0984 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT X R 0985 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT X R 0986 88-108-104-080 C-RES,U 100K-1/16W J a
CX-SNTR77
USTC
FRONT X R 0987 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT X R 0988 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT X R 0989 88-108-104-080 C-RES,U 100K-1/16W J a
FRONT X R 0999 88-108-104-080 C-RES,U 100K-1/16W J a
HP O CNA0201 8C-NFT-604-010 CONN ASSY,5P V CNF-T a
HP O J 0201 87-A61-546-010 JACK,3.5 BLAK ST W/SW HST3000 a
HP X R 0205 88-128-392-080 C-RES, 3.9K-1/8W J a
HP X R 0206 88-128-392-080 C-RES, 3.9K-1/8W J a
HP X R 0243 88-140-221-080 RES,220-1/2W J a
HP X R 0244 88-140-221-080 RES,220-1/2W J a
HP X R 0245 88-140-221-080 RES,220-1/2W J a
HP X R 0246 88-140-221-080 RES,220-1/2W J a
HP X R 0265 88-128-222-080 C-RES, 2.2K-1/8W J a
HP X R 0266 88-128-222-080 C-RES, 2.2K-1/8W J a
KEY O C 0302 87-012-274-080 C-CAP,U 1000P-50 K B GRM a
KEY O C 0303 87-012-195-080 C-CAP,U 100P-50 J CH GRM a
KEY O C 0304 87-012-195-080 C-CAP,U 100P-50 J CH GRM a
KEY O C 0305 87-012-274-080 C-CAP,U 1000P-50 K B GRM a
KEY O C 0306 87-012-195-080 C-CAP,U 100P-50 J CH GRM a
KEY O C 0307 87-012-195-080 C-CAP,U 100P-50 J CH GRM a
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-12-
ELECTRICAL PARTS LIST - 4/16
CX-SNTR77
USTC
KEY O C 0308 87-012-274-080 C-CAP,U 1000P-50 K B GRM a
KEY O C 0309 87-012-195-080 C-CAP,U 100P-50 J CH GRM a
KEY O C 0310 87-012-195-080 C-CAP,U 100P-50 J CH GRM a
KEY O C 0311 87-012-274-080 C-CAP,U 1000P-50 K B GRM a
KEY O C 0312 87-012-195-080 C-CAP,U 100P-50 J CH GRM a
KEY O C 0317 87-012-195-080 C-CAP,U 100P-50 J CH GRM a
KEY O C 0318 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
KEY O C 0319 87-012-195-080 C-CAP,U 100P-50 J CH GRM a
KEY O C 0320 87-012-195-080 C-CAP,U 100P-50 J CH GRM a
KEY O C 0321 87-012-195-080 C-CAP,U 100P-50 J CH GRM a
KEY O CN 0302 87-099-015-010 CONN,13P V BLK 6216 a
KEY O LED0205 87-A40-317-080 LED,SLR-342VCT31 RED a
KEY O LED0206 87-A40-317-080 LED,SLR-342VCT31 RED a
KEY O LED0207 87-A40-317-080 LED,SLR-342VCT31 RED a
KEY O LED0208 87-A40-317-080 LED,SLR-342VCT31 RED a
KEY O LED0209 87-A40-317-080 LED,SLR-342VCT31 RED a
KEY O LED0210 87-A40-317-080 LED,SLR-342VCT31 RED a
KEY O LED0211 87-A40-317-080 LED,SLR-342VCT31 RED a
KEY O LED0212 87-A40-317-080 LED,SLR-342VCT31 RED a
KEY O LED0216 87-A40-589-040 LED,SLR-56VCT31 RED a
CX-SNTR77
USTC
KEY O LED0217 87-A40-589-040 LED,SLR-56VCT31 RED a
KEY O LED0218 87-A40-589-040 LED,SLR-56VCT31 RED a
KEY O LED0219 87-A40-589-040 LED,SLR-56VCT31 RED a
KEY O LED0220 87-A40-589-040 LED,SLR-56VCT31 RED a
KEY O LED0221 87-A40-589-040 LED,SLR-56VCT31 RED a
KEY X R 0307 88-108-683-080 C-RES,U 68K-1/16W J a
KEY O R 0308 88-108-153-080 C-RES,U 15K-1/16W J a
KEY X R 0309 88-108-683-080 C-RES,U 68K-1/16W J a
KEY O R 0310 88-108-153-080 C-RES,U 15K-1/16W J a
KEY X R 0311 88-108-683-080 C-RES,U 68K-1/16W J a
KEY O R 0312 88-108-153-080 C-RES,U 15K-1/16W J a
KEY X R 0313 88-108-683-080 C-RES,U 68K-1/16W J a
KEY O R 0314 88-108-153-080 C-RES,U 15K-1/16W J a
KEY X R 0316 88-108-184-080 C-RES,U 180K-1/16W J a
KEY O R 0317 88-108-103-080 C-RES,U 10K-1/16W J a
KEY X R 0318 88-108-184-080 C-RES,U 180K-1/16W J a
KEY O R 0319 88-108-103-080 C-RES,U 10K-1/16W J a
KEY X R 0322 88-121-102-080 RES,1K-1/8W J a
KEY X R 0323 88-108-821-080 C-RES,U 820-1/16W J a
KEY X R 0324 88-121-102-080 RES,1K-1/8W J a
CX-SNTR77
USTC
KEY X R 0325 88-108-122-080 C-RES,U 1.2K-1/16W J a
KEY X R 0326 88-108-122-080 C-RES,U 1.2K-1/16W J a
KEY X R 0327 88-108-182-080 C-RES,U 1.8K-1/16W J a
KEY X R 0328 88-108-182-080 C-RES,U 1.8K-1/16W J a
KEY O R 0329 88-108-272-080 C-RES,U 2.7K-1/16W J a
KEY O R 0330 88-108-332-080 C-RES,U 3.3K-1/16W J a
KEY X R 0331 88-108-472-080 C-RES,U 4.7K-1/16W J a
KEY X R 0332 88-108-682-080 C-RES,U 6.8K-1/16W J a
KEY O R 0333 88-108-103-080 C-RES,U 10K-1/16W J a
KEY X R 0334 88-108-184-080 C-RES,U 180K-1/16W J a
KEY O R 0335 88-108-103-080 C-RES,U 10K-1/16W J a
KEY X R 0336 88-108-184-080 C-RES,U 180K-1/16W J a
KEY O R 0337 88-108-103-080 C-RES,U 10K-1/16W J a
KEY O R 0342 88-108-102-080 C-RES,U 1K-1/16W J a
KEY X R 0343 88-121-821-080 RES,820-1/8W J a
KEY O R 0344 88-108-102-080 C-RES,U 1K-1/16W J a
KEY X R 0345 88-108-122-080 C-RES,U 1.2K-1/16W J a
KEY X R 0346 88-108-122-080 C-RES,U 1.2K-1/16W J a
KEY X R 0347 88-108-182-080 C-RES,U 1.8K-1/16W J a
KEY X R 0348 88-121-103-080 RES,10K-1/8W J a
CX-SNTR77
USTC
KEY O R 0349 88-108-103-080 C-RES,U 10K-1/16W J a
KEY O R 0350 88-108-103-080 C-RES,U 10K-1/16W J a
KEY O R 0362 88-108-103-080 C-RES,U 10K-1/16W J a
KEY O R 0363 88-108-103-080 C-RES,U 10K-1/16W J a
KEY O R 0364 88-108-103-080 C-RES,U 10K-1/16W J a
KEY O R 0365 88-108-103-080 C-RES,U 10K-1/16W J a
KEY X R 0366 88-118-102-080 C-RES,S 1K-1/10W J a
KEY X R 0367 88-118-102-080 C-RES,S 1K-1/10W J a
KEY X R 0368 88-118-102-080 C-RES,S 1K-1/10W J a
KEY X R 0369 88-118-102-080 C-RES,S 1K-1/10W J a
KEY X R 0370 88-118-102-080 C-RES,S 1K-1/10W J a
KEY X R 0371 88-118-102-080 C-RES,S 1K-1/10W J a
KEY X R 0372 88-121-101-080 RES,100-1/8W J a
KEY O S 0321 87-A90-095-080 SW,TACT EVQ11G04M a
KEY O S 0322 87-A90-095-080 SW,TACT EVQ11G04M a
KEY O S 0323 87-A90-095-080 SW,TACT EVQ11G04M a
KEY O S 0324 87-A90-095-080 SW,TACT EVQ11G04M a
KEY O S 0325 87-A90-095-080 SW,TACT EVQ11G04M a
KEY O S 0326 87-A90-095-080 SW,TACT EVQ11G04M a
KEY O S 0327 87-A90-095-080 SW,TACT EVQ11G04M a
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-13-
ELECTRICAL PARTS LIST - 5/16
CX-SNTR77
USTC
KEY O S 0328 87-A90-095-080 SW,TACT EVQ11G04M a
KEY O S 0329 87-A90-095-080 SW,TACT EVQ11G04M a
KEY O S 0330 87-A90-095-080 SW,TACT EVQ11G04M a
KEY O S 0331 87-A90-095-080 SW,TACT EVQ11G04M a
KEY O S 0332 87-A90-095-080 SW,TACT EVQ11G04M a
KEY O S 0333 87-A90-095-080 SW,TACT EVQ11G04M a
KEY O S 0341 87-A90-095-080 SW,TACT EVQ11G04M a
KEY O S 0342 87-A90-095-080 SW,TACT EVQ11G04M a
KEY O S 0343 87-A90-095-080 SW,TACT EVQ11G04M a
KEY O S 0344 87-A90-095-080 SW,TACT EVQ11G04M a
KEY O S 0345 87-A90-095-080 SW,TACT EVQ11G04M a
KEY O S 0346 87-A90-095-080 SW,TACT EVQ11G04M a
KEY O S 0347 87-A90-095-080 SW,TACT EVQ11G04M a
KEY O S 0360 87-A92-249-010 SW,RTRY EC12E24704-30MM a
KEY O S 0361 87-A92-359-010 SW,RTRY EC12E24604-30MM a
KEY O S 0362 87-A92-359-010 SW,RTRY EC12E24604-30MM a
KEY O S 0363 87-A92-273-110 SW,RTRY EC12E12204 30MM a
LED O CN 0202 87-099-194-010 CONN,6P V BLK 6216 a
LED S IC 0301 87-070-289-040 C-IC,BU2092F a
LED O LED0202 87-A40-317-080 LED,SLR-342VCT31 RED a
CX-SNTR77
USTC
LED O LED0203 87-A40-317-080 LED,SLR-342VCT31 RED a
LED O LED0204 87-A40-317-080 LED,SLR-342VCT31 RED a
LED O LED0213 87-A40-317-080 LED,SLR-342VCT31 RED a
LED O LED0214 87-A40-317-080 LED,SLR-342VCT31 RED a
LED O LED0215 87-A40-317-080 LED,SLR-342VCT31 RED a
LED X R 0201 88-121-821-080 RES,820-1/8W J a
LED X R 0202 88-121-821-080 RES,820-1/8W J a
LED X R 0203 88-121-821-080 RES,820-1/8W J a
LED X R 0355 88-108-122-080 C-RES,U 1.2K-1/16W J a
LED X R 0356 88-108-122-080 C-RES,U 1.2K-1/16W J a
LED X R 0357 88-108-182-080 C-RES,U 1.8K-1/16W J a
LED X R 0358 88-108-182-080 C-RES,U 1.8K-1/16W J a
LED X R 0359 88-108-273-080 C-RES,U 27K-1/16W J a
LED O S 0355 87-A90-095-080 SW,TACT EVQ11G04M a
LED O S 0356 87-A90-095-080 SW,TACT EVQ11G04M a
LED O S 0357 87-A90-095-080 SW,TACT EVQ11G04M a
LED O S 0358 87-A90-095-080 SW,TACT EVQ11G04M a
LED O S 0359 87-A90-095-080 SW,TACT EVQ11G04M a
MAIN O C 0003 87-A12-317-080 C-CAP,U 0.1-50 Z F a
MAIN O C 0004 87-A12-317-080 C-CAP,U 0.1-50 Z F a
CX-SNTR77
USTC
MAIN O C 0005 87-A12-317-080 C-CAP,U 0.1-50 Z F a
MAIN O C 0006 87-A12-317-080 C-CAP,U 0.1-50 Z F a
MAIN O C 0009 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
MAIN O C 0010 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
MAIN O C 0011 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
MAIN O C 0012 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
MAIN O C 0013 87-012-282-080 C-CAP,U 4700P-50 K B GRM a
MAIN O C 0014 87-010-260-080 CAP,E 47-25 M 11L SME a
MAIN O C 0015 87-010-263-080 CAP,E 100-10 M 11L SME a
MAIN O C 0016 87-012-282-080 C-CAP,U 4700P-50 K B GRM a
MAIN O C 0019 87-A12-875-000 CAP,E 3300-65 M 85 IV a
MAIN O C 0020 87-A12-875-000 CAP,E 3300-65 M 85 IV a
MAIN O C 0021 87-A12-830-000 CAP,E 4700-35 M 85 GS a
MAIN O C 0022 87-A12-830-000 CAP,E 4700-35 M 85 GS a
MAIN O C 0031 87-010-263-080 CAP,E 100-10 M 11L SME a
MAIN O C 0034 87-010-260-080 CAP,E 47-25 M 11L SME a
MAIN O C 0035 87-010-404-080 CAP,E 4.7-50 M 11L SME a
MAIN O C 0036 87-010-260-080 CAP,E 47-25 M 11L SME a
MAIN O C 0060 87-010-403-080 CAP,E 3.3-50 M 11L SME a
MAIN O C 0061 87-010-260-080 CAP,E 47-25 M 11L SME a
CX-SNTR77
USTC
MAIN O C 0083 87-010-235-080 CAP,E 470-16 M SME a
MAIN O C 0097 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
MAIN O C 0101 87-012-278-080 C-CAP,U 2200P-50 K B GRM a
MAIN O C 0102 87-012-278-080 C-CAP,U 2200P-50 K B GRM a
MAIN O C 0103 87-010-545-080 CAP,E 0.22-50 M 11L SME a
MAIN O C 0104 87-010-545-080 CAP,E 0.22-50 M 11L SME a
MAIN O C 0105 87-012-280-080 C-CAP,U 3300P-50 K B GRM a
MAIN O C 0106 87-012-280-080 C-CAP,U 3300P-50 K B GRM a
MAIN O C 0107 87-010-405-080 CAP,E 10-50 M 11L SME a
MAIN O C 0108 87-010-405-080 CAP,E 10-50 M 11L SME a
MAIN O C 0111 87-010-392-080 CAP,E 33-35 M 11L SME a
MAIN O C 0112 87-010-392-080 CAP,E 33-35 M 11L SME a
MAIN O C 0113 87-A10-596-080 C-CAP,S 100P-100 J CH a
MAIN O C 0114 87-A10-596-080 C-CAP,S 100P-100 J CH a
MAIN O C 0117 87-A12-317-080 C-CAP,U 0.1-50 Z F a
MAIN O C 0118 87-A12-317-080 C-CAP,U 0.1-50 Z F a
MAIN O C 0119 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
MAIN O C 0120 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
MAIN O C 0121 87-010-401-080 CAP,E 1-50 M 11L SME a
MAIN O C 0122 87-010-401-080 CAP,E 1-50 M 11L SME a
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-14-
ELECTRICAL PARTS LIST - 6/16
CX-SNTR77
USTC
MAIN O C 0123 87-010-177-080 C-CAP,S 820P-50 J SL C2012 a
MAIN O C 0124 87-010-177-080 C-CAP,S 820P-50 J SL C2012 a
MAIN O C 0125 87-A10-596-080 C-CAP,S 100P-100 J CH a
MAIN O C 0126 87-A10-596-080 C-CAP,S 100P-100 J CH a
MAIN O C 0133 87-012-282-080 C-CAP,U 4700P-50 K B GRM a
MAIN O C 0140 87-012-278-080 C-CAP,U 2200P-50 K B GRM a
MAIN O C 0186 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
MAIN O C 0187 87-A12-890-080 CAP,E 10-63 VR a
MAIN O C 0188 87-A12-890-080 CAP,E 10-63 VR a
MAIN O C 0193 87-012-273-080 C-CAP,U 820P-50 K B GRM a
MAIN O C 0194 87-012-273-080 C-CAP,U 820P-50 K B GRM a
MAIN O C 0225 87-A12-317-080 C-CAP,U 0.1-50 Z F a
MAIN O C 0226 87-A12-317-080 C-CAP,U 0.1-50 Z F a
MAIN O C 0227 87-A12-317-080 C-CAP,U 0.1-50 Z F a
MAIN O C 0228 87-A12-317-080 C-CAP,U 0.1-50 Z F a
MAIN O C 0301 87-012-275-080 C-CAP,U 1200P-50 K B GRM a
MAIN O C 0302 87-012-275-080 C-CAP,U 1200P-50 K B GRM a
MAIN O C 0303 87-012-275-080 C-CAP,U 1200P-50 K B GRM a
MAIN O C 0304 87-012-275-080 C-CAP,U 1200P-50 K B GRM a
MAIN O C 0305 87-012-270-080 C-CAP,U 470P-50 K B GRM a
CX-SNTR77
USTC
MAIN O C 0306 87-012-274-080 C-CAP,U 1000P-50 K B GRM a
MAIN O C 0363 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
MAIN O C 0451 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
MAIN O C 0452 87-010-406-080 CAP,E 22-50 M 11L SME a
MAIN O C 0453 87-012-279-080 C-CAP,U 2700P-50 K B GRM a
MAIN O C 0454 87-012-279-080 C-CAP,U 2700P-50 K B GRM a
MAIN O C 0455 87-012-279-080 C-CAP,U 2700P-50 K B GRM a
MAIN O C 0456 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
MAIN O C 0457 87-A12-361-080 CAP,M 5600P-100 J CP a
MAIN O C 0458 87-012-278-080 C-CAP,U 2200P-50 K B GRM a
MAIN O C 0459 87-012-271-080 C-CAP,U 560P-50 K B GRM a
MAIN O C 0460 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
MAIN O C 0461 87-012-158-080 C-CAP,S 390P-50 J CH GRM a
MAIN O C 0462 87-012-158-080 C-CAP,S 390P-50 J CH GRM a
MAIN O C 0463 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
MAIN O C 0464 87-012-278-080 C-CAP,U 2200P-50 K B GRM a
MAIN O C 0601 87-012-188-080 C-CAP,U 47P-50 J CH GRM a
MAIN O C 0602 87-012-188-080 C-CAP,U 47P-50 J CH GRM a
MAIN O C 0603 87-010-263-080 CAP,E 100-10 M 11L SME a
MAIN O C 0604 87-010-263-080 CAP,E 100-10 M 11L SME a
CX-SNTR77
USTC
MAIN X C 0605 88-700-740-810 CAP,M 6800P-50 J a
MAIN X C 0606 88-700-740-810 CAP,M 6800P-50 J a
MAIN O C 0607 87-012-270-080 C-CAP,U 470P-50 K B GRM a
MAIN O C 0608 87-012-270-080 C-CAP,U 470P-50 K B GRM a
MAIN O C 0609 87-010-401-080 CAP,E 1-50 M 11L SME a
MAIN O C 0610 87-010-401-080 CAP,E 1-50 M 11L SME a
MAIN O C 0611 87-012-273-080 C-CAP,U 820P-50 K B GRM a
MAIN O C 0612 87-012-273-080 C-CAP,U 820P-50 K B GRM a
MAIN X C 0613 88-700-610-810 CAP,M 1000P-50 J a
MAIN X C 0614 88-700-610-810 CAP,M 1000P-50 J a
MAIN X C 0615 88-700-610-810 CAP,M 1000P-50 J a
MAIN X C 0616 88-700-610-810 CAP,M 1000P-50 J a
MAIN X C 0617 88-700-810-810 CAP,M 0.01-50 J a
MAIN X C 0618 88-700-810-810 CAP,M 0.01-50 J a
MAIN X C 0619 88-700-810-810 CAP,M 0.01-50 J a
MAIN X C 0620 88-700-810-810 CAP,M 0.01-50 J a
MAIN O C 0631 87-012-195-080 C-CAP,U 100P-50 J CH GRM a
MAIN O C 0632 87-012-195-080 C-CAP,U 100P-50 J CH GRM a
MAIN O C 0633 87-012-284-080 C-CAP,U 6800P-50 K B GRM a
MAIN O C 0634 87-012-284-080 C-CAP,U 6800P-50 K B GRM a
CX-SNTR77
USTC
MAIN O C 0635 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
MAIN O C 0636 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
MAIN O C 0637 87-012-278-080 C-CAP,U 2200P-50 K B GRM a
MAIN O C 0638 87-012-278-080 C-CAP,U 2200P-50 K B GRM a
MAIN O C 0641 87-010-401-080 CAP,E 1-50 M 11L SME a
MAIN O C 0642 87-010-401-080 CAP,E 1-50 M 11L SME a
MAIN O C 0651 87-010-248-080 CAP,E 220-10 M 11L SME a
MAIN O C 0652 87-010-260-080 CAP,E 47-25 M 11L SME a
MAIN X C 0655 88-700-970-810 CAP,M 0.082-50 J a
MAIN X C 0656 88-700-970-810 CAP,M 0.082-50 J a
MAIN X C 0657 88-710-399-810 CAP,M 0.68-50 J TFL ECQV a
MAIN X C 0658 88-710-399-810 CAP,M 0.68-50 J TFL ECQV a
MAIN X C 0659 88-710-399-810 CAP,M 0.68-50 J TFL ECQV a
MAIN X C 0660 88-710-399-810 CAP,M 0.68-50 J TFL ECQV a
MAIN O C 0663 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
MAIN O C 0664 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
MAIN O C 0665 87-010-404-080 CAP,E 4.7-50 M 11L SME a
MAIN O C 0666 87-010-404-080 CAP,E 4.7-50 M 11L SME a
MAIN O C 0677 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
MAIN O C 0771 87-010-263-080 CAP,E 100-10 M 11L SME a
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-15-
ELECTRICAL PARTS LIST - 7/16
CX-SNTR77
USTC
MAIN O C 0772 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
MAIN X C 0781 88-108-000-080 C-JUMPER,U a
MAIN O C 0782 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
MAIN O C 0783 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
MAIN O C 0784 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
MAIN O C 0785 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
MAIN O C 0786 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
MAIN O C 0788 87-012-167-080 C-CAP,U 5P-50 C CH GRM a
MAIN O C 0789 87-A13-065-080 C-CAP,U 0.027-25 J B a
MAIN O C 0790 87-A13-065-080 C-CAP,U 0.027-25 J B a
MAIN O C 0791 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
MAIN O C 0792 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
MAIN O C 0793 87-010-404-080 CAP,E 4.7-50 M 11L SME a
MAIN O C 0795 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
MAIN O C 0796 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
MAIN O C 0797 87-010-405-080 CAP,E 10-50 M 11L SME a
MAIN O C 0798 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
MAIN O C 0799 87-010-265-080 CAP,E 33-16 M 11L SME a
MAIN O C 0800 87-010-829-080 C-CAP,U 0.047-16 Z F CM/CB a
MAIN O C 0801 87-010-403-080 CAP,E 3.3-50 M 11L SME a
CX-SNTR77
USTC
MAIN O C 0802 87-010-829-080 C-CAP,U 0.047-16 Z F CM/CB a
MAIN O C 0803 87-010-787-080 C-CAP,U 0.022-25 K B GRM a
MAIN O C 0804 87-010-263-080 CAP,E 100-10 M 11L SME a
MAIN O C 0807 87-010-400-080 CAP,E 0.47-50 M 11L SME a
MAIN O C 0808 87-010-401-080 CAP,E 1-50 M 11L SME a
MAIN O C 0809 87-010-401-080 CAP,E 1-50 M 11L SME a
MAIN O C 0810 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
MAIN O C 0814 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
MAIN O C 0815 87-010-400-080 CAP,E 0.47-50 M 11L SME a
MAIN O C 0816 87-010-400-080 CAP,E 0.47-50 M 11L SME a
MAIN O C 0821 87-010-405-080 CAP,E 10-50 M 11L SME a
MAIN X C 0822 88-108-000-080 C-JUMPER,U a
MAIN O C 0823 87-010-177-080 C-CAP,S 820P-50 J SL C2012 a
MAIN O C 0824 87-010-404-080 CAP,E 4.7-50 M 11L SME a
MAIN O C 0825 87-010-596-080 C-CAP,S 0.047-16 K R C2012 a
MAIN O C 0842 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
MAIN X C 0843 88-108-000-080 C-JUMPER,U a
MAIN O C 0844 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
MAIN X C 0845 88-108-000-080 C-JUMPER,U a
MAIN X C 0846 88-108-000-080 C-JUMPER,U a
CX-SNTR77
USTC
MAIN X C 0847 88-108-000-080 C-JUMPER,U a
MAIN X C 0848 88-108-000-080 C-JUMPER,U a
MAIN X C 0849 88-108-000-080 C-JUMPER,U a
MAIN O C 0850 87-010-260-080 CAP,E 47-25 M 11L SME a
MAIN O C 0851 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
MAIN O C 0852 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
MAIN O C 0853 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
MAIN O C 0860 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
MAIN O C 0901 87-012-169-080 C-CAP,U 7P-50 D CH GRM a
MAIN X C 0906 88-108-000-080 C-JUMPER,U a
MAIN O C 0908 87-012-162-080 C-CAP,U 1P-50 C CH GRM a
MAIN O C 0909 87-A10-915-080 C-CAP,U 1000P-25 J CH a
MAIN O C 0911 87-012-167-080 C-CAP,U 5P-50 C CH GRM a
MAIN O C 0912 87-012-195-080 C-CAP,U 100P-50 J CH GRM a
MAIN O C 0914 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
MAIN O C 0915 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
MAIN O C 0917 87-012-164-080 C-CAP,U 2P-50 C CH GRM a
MAIN O C 0920 87-012-180-080 C-CAP,U 22P-50 J CH GRM a
MAIN O C 0921 87-012-186-080 C-CAP,U 39P-50 J CH GRM a
MAIN O C 0922 87-012-174-080 C-CAP,U 12P-50 J CH GRM a
CX-SNTR77
USTC
MAIN O C 0923 87-A10-039-080 C-CAP,U 470P-50 J CH a
MAIN O C 0924 87-012-162-080 C-CAP,U 1P-50 C CH GRM a
MAIN O C 0926 87-012-195-080 C-CAP,U 100P-50 J CH GRM a
MAIN O C 0928 87-012-176-080 C-CAP,U 15P-50 J CH GRM a
MAIN O C 0931 87-A12-319-080 C-CAP,U 0.1-25 K B a
MAIN X C 0940 88-108-000-080 C-JUMPER,U a
MAIN O C 0959 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
MAIN O C 0960 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
MAIN O C 0961 87-012-169-080 C-CAP,U 7P-50 D CH GRM a
MAIN O C 0962 87-010-401-080 CAP,E 1-50 M 11L SME a
MAIN O C 0963 87-A12-319-080 C-CAP,U 0.1-25 K B a
MAIN O C 0971 87-010-381-080 CAP,E 330-16 M SME a
MAIN O C 0972 87-010-404-080 CAP,E 4.7-50 M 11L SME a
MAIN O C 0973 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
MAIN O C 0974 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
MAIN O C 0979 87-012-195-080 C-CAP,U 100P-50 J CH GRM a
MAIN O C 0981 87-010-260-080 CAP,E 47-25 M 11L SME a
MAIN O C 0982 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
MAIN O C 0983 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
MAIN O C 0984 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-16-
ELECTRICAL PARTS LIST - 8/16
CX-SNTR77
USTC
MAIN O C 0987 87-012-286-080 C-CAP,U 0.01-25 K B GRM a
MAIN O C 0991 87-012-176-080 C-CAP,U 15P-50 J CH GRM a
MAIN O C 0992 87-012-176-080 C-CAP,U 15P-50 J CH GRM a
MAIN O C 0993 87-012-274-080 C-CAP,U 1000P-50 K B GRM a
MAIN O C 0995 87-012-274-080 C-CAP,U 1000P-50 K B GRM a
MAIN O C 0997 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
MAIN O C 0998 87-010-260-080 CAP,E 47-25 M 11L SME a
MAIN O C 0999 87-A11-155-080 CAP,TC U 0.01-16 Z F a
MAIN O CF 0831 87-008-261-010 FLTR,CF SFE10.7MA5 a
MAIN O CF 0832 87-008-261-010 FLTR,CF SFE10.7MA5 a
MAIN X CLP0301 87-A60-884-010 PIN,DIA1 COATING-SHS a
MAIN X CLP0601 87-A60-884-010 PIN,DIA1 COATING-SHS a
MAIN X CLP0602 87-A60-884-010 PIN,DIA1 COATING-SHS a
MAIN O CN 0101 87-009-195-010 CONN,5P V WHT EH a
MAIN O CN 0301 87-A60-620-010 CONN,3P V 2MM JMT a
MAIN O CN 0302 87-A60-625-010 CONN,8P V 2MM JMT a
MAIN O CN 0601 87-099-719-010 CONN,30P H BLK TYK-B(X) a
MAIN O CN 0602 87-A60-131-010 CONN,6P V FE a
MAIN S D 0009 87-A40-839-090 DIODE,G5SBA60L-6088 a
MAIN S D 0010 87-A40-839-090 DIODE,G5SBA60L-6088 a
CX-SNTR77
USTC
MAIN S D 0011 87-A40-270-040 C-DIODE,MC2838 a
MAIN S D 0012 87-020-465-080 DIODE,1SS133 a
MAIN S D 0013 87-A40-764-080 ZENER,UZ10BSC a
MAIN S D 0029 87-A40-775-080 ZENER,UZ27BSB a
MAIN S D 0033 87-020-465-080 DIODE,1SS133 a
MAIN S D 0041 87-A40-270-040 C-DIODE,MC2838 a
MAIN S D 0042 87-A40-269-040 C-DIODE,MC2836 a
MAIN S D 0060 87-020-465-080 DIODE,1SS133 a
MAIN S D 0063 87-A40-270-040 C-DIODE,MC2838 a
MAIN S D 0064 87-A40-269-040 C-DIODE,MC2836 a
MAIN S D 0076 87-A40-269-040 C-DIODE,MC2836 a
MAIN S D 0077 87-A40-270-040 C-DIODE,MC2838 a
MAIN S D 0101 87-A40-269-040 C-DIODE,MC2836 a
MAIN S D 0103 87-020-465-080 DIODE,1SS133 a
MAIN S D 0104 87-020-465-080 DIODE,1SS133 a
MAIN S D 0105 87-A40-269-040 C-DIODE,MC2836 a
MAIN S D 0106 87-A40-269-040 C-DIODE,MC2836 a
MAIN S D 0107 87-A40-270-040 C-DIODE,MC2838 a
MAIN S D 0108 87-A40-270-040 C-DIODE,MC2838 a
MAIN S D 0109 87-A40-488-080 DIODE,1SS244 a
CX-SNTR77
USTC
MAIN S D 0110 87-A40-488-080 DIODE,1SS244 a
MAIN S D 0150 87-A40-270-040 C-DIODE,MC2838 a
MAIN S D 0160 87-A40-270-040 C-DIODE,MC2838 a
MAIN S D 0185 87-A40-370-090 DIODE,RK46-P20 a
MAIN S D 0186 87-A40-370-090 DIODE,RK46-P20 a
MAIN S D 0187 87-A40-747-080 ZENER,UZ5.1BSB a
MAIN S D 0188 87-A40-749-080 ZENER,UZ5.6BSB a
MAIN S D 0189 87-A40-270-040 C-DIODE,MC2838 a
MAIN S D 0190 87-A40-269-040 C-DIODE,MC2836 a
MAIN S D 0191 87-A40-764-080 ZENER,UZ10BSC a
MAIN S D 0192 87-020-465-080 DIODE,1SS133 a
MAIN S D 0193 87-020-465-080 DIODE,1SS133 a
MAIN X D 0194 88-100-000-010 JUMPER WIRE,PLATING a
MAIN S D 0201 87-020-465-080 DIODE,1SS133 a
MAIN S D 0280 87-A40-269-040 C-DIODE,MC2836 a
MAIN S D 0281 87-A40-270-040 C-DIODE,MC2838 a
MAIN S D 0301 87-A40-269-040 C-DIODE,MC2836 a
MAIN S D 0661 87-A40-745-080 ZENER,UZ4.7BSA a
MAIN S D 0662 87-A40-745-080 ZENER,UZ4.7BSA a
MAIN X D 0801 88-100-000-010 JUMPER WIRE,PLATING a
CX-SNTR77
USTC
MAIN S D 0803 87-020-465-080 DIODE,1SS133 a
MAIN O D 0902 87-A40-916-040 C-VARI-CAP,HVC202A a
MAIN O D 0903 87-A40-916-040 C-VARI-CAP,HVC202A a
MAIN X D 0944 88-100-000-010 JUMPER WIRE,PLATING a
MAIN O D 0951 87-A40-799-040 C-VARI-CAP,KV1610S a
MAIN S D 0991 87-017-149-080 ZENER,HZS6A2L a
MAIN S D 0994 87-020-465-080 DIODE,1SS133 a
MAIN X FB 0601 88-108-000-080 C-JUMPER,U a
MAIN X FB 0602 88-108-000-080 C-JUMPER,U a
MAIN X FB 0603 88-100-000-010 JUMPER WIRE,PLATING a
MAIN S IC 0001 87-A21-364-010 IC,NJM7806FA(A) a
MAIN S IC 0601 87-A22-235-040 C-IC,M61518FP a
MAIN S IC 0602 87-017-022-080 C-IC,NJM2068M-D(T1) a
MAIN S IC 0801 87-A22-060-010 IC,LA1845N-A a
MAIN S IC 0991 87-A21-928-010 IC,LC72131D-N a
MAIN O J 0203 87-A61-820-010 TERMINAL,SP 4P MSC(V0) a
MAIN O J 0602 87-A60-881-010 JACK,PIN 2P MSP 242V05 PBSN a
MAIN X J 0831 87-A60-202-010 TERMINAL,ANT 4P MSP-154V-02 a
MAIN X JR 0835 88-108-561-080 C-RES,U 560-1/16W J a
MAIN O L 0201 87-A50-610-010 COIL,1UH K(MDEC) a
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-17-
ELECTRICAL PARTS LIST - 9/16
CX-SNTR77
USTC
MAIN O L 0202 87-A50-610-010 COIL,1UH K(MDEC) a
MAIN O L 0451 87-007-342-010 COIL,OSC 85KHZ BIAS a
MAIN O L 0801 87-A50-608-010 COIL,FM DET-N(TOK) a
MAIN O L 0802 87-A91-551-010 FLTR,PCFJZH-450 L(TOK) a
MAIN O L 0811 87-005-847-080 COIL,2.2UH K CECS a
MAIN O L 0832 87-005-847-080 COIL,2.2UH K CECS a
MAIN O L 0901 87-A50-110-010 COIL,FM BPF EX a
MAIN O L 0903 86-ZA1-624-010 COIL,FM RF-1 a
MAIN O L 0904 86-ZA1-622-010 COIL,FM ANT/RF-U a
MAIN O L 0906 87-005-847-080 COIL,2.2UH K CECS a
MAIN O L 0907 86-ZA1-627-010 COIL,FM OSC-U a
MAIN O L 0908 88-ZA1-624-010 COIL,FM IFT 7-6.2 (COILS) a
MAIN O L 0952 87-A50-752-010 COIL,MW ANT(2B) a
MAIN O L 0953 87-A50-753-010 COIL,MW OSC(2B) a
MAIN ! O PT 0001 8C-NFT-607-010 PT,U CNF-T a
MAIN S Q 0001 87-A30-494-080 TR,2SA1980G a
MAIN S Q 0002 87-A30-494-080 TR,2SA1980G a
MAIN S Q 0003 87-A30-076-040 C-TR,2SC3052F a
MAIN S Q 0004 87-A30-494-080 TR,2SA1980G a
MAIN S Q 0009 87-A30-494-080 TR,2SA1980G a
CX-SNTR77
USTC
MAIN S Q 0010 87-A30-076-040 C-TR,2SC3052F a
MAIN S Q 0011 89-213-702-010 TR,2SB1370E a
MAIN S Q 0012 87-A30-630-080 TR,2SC5343GL a
MAIN S Q 0013 87-A30-076-040 C-TR,2SC3052F a
MAIN S Q 0014 87-A30-075-040 C-TR,2SA1235F a
MAIN S Q 0015 87-A30-075-040 C-TR,2SA1235F a
MAIN S Q 0060 87-A30-076-040 C-TR,2SC3052F a
MAIN S Q 0061 87-A30-075-040 C-TR,2SA1235F a
MAIN S Q 0062 87-A30-076-040 C-TR,2SC3052F a
MAIN S Q 0063 87-A30-075-040 C-TR,2SA1235F a
MAIN S Q 0064 87-A30-076-040 C-TR,2SC3052F a
MAIN S Q 0101 87-A30-675-040 C-TR,2SD1306NE07TL a
MAIN S Q 0102 87-A30-675-040 C-TR,2SD1306NE07TL a
MAIN S Q 0103 87-A30-669-040 C-TR,SBT5401 a
MAIN S Q 0104 87-A30-669-040 C-TR,SBT5401 a
MAIN S Q 0105 87-A30-669-040 C-TR,SBT5401 a
MAIN S Q 0106 87-A30-669-040 C-TR,SBT5401 a
MAIN S Q 0107 87-A30-076-040 C-TR,2SC3052F a
MAIN S Q 0108 87-A30-076-040 C-TR,2SC3052F a
MAIN S Q 0109 87-A30-076-040 C-TR,2SC3052F a
CX-SNTR77
USTC
MAIN S Q 0110 87-A30-076-040 C-TR,2SC3052F a
MAIN S Q 0111 87-A30-672-080 TR,2N5551C a
MAIN S Q 0112 87-A30-672-080 TR,2N5551C a
MAIN S Q 0113 87-A30-076-040 C-TR,2SC3052F a
MAIN S Q 0114 87-A30-076-040 C-TR,2SC3052F a
MAIN S Q 0115 87-A30-670-040 C-TR,SBT5551 a
MAIN S Q 0116 87-A30-670-040 C-TR,SBT5551 a
MAIN S Q 0121 87-A30-672-080 TR,2N5551C a
MAIN S Q 0122 87-A30-672-080 TR,2N5551C a
MAIN S Q 0123 87-A30-669-040 C-TR,SBT5401 a
MAIN S Q 0124 87-A30-669-040 C-TR,SBT5401 a
MAIN S Q 0126 87-A30-669-040 C-TR,SBT5401 a
MAIN S Q 0127 87-A30-076-040 C-TR,2SC3052F a
MAIN S Q 0128 87-A30-076-040 C-TR,2SC3052F a
MAIN S Q 0130 87-A30-670-040 C-TR,SBT5551 a
MAIN S Q 0131 87-A30-098-010 TR,FP1016 a
MAIN S Q 0132 87-A30-098-010 TR,FP1016 a
MAIN S Q 0133 87-A30-097-010 TR,FN1016 a
MAIN S Q 0134 87-A30-097-010 TR,FN1016 a
MAIN S Q 0183 87-A30-186-010 FET,2SK3053 a
CX-SNTR77
USTC
MAIN S Q 0184 87-A30-186-010 FET,2SK3053 a
MAIN S Q 0185 87-A30-076-040 C-TR,2SC3052F a
MAIN S Q 0186 87-A30-075-040 C-TR,2SA1235F a
MAIN S Q 0187 87-A30-075-040 C-TR,2SA1235F a
MAIN S Q 0235 87-A30-075-040 C-TR,2SA1235F a
MAIN S Q 0280 87-A30-538-040 C-TR,SRA2202S a
MAIN S Q 0281 87-A30-669-040 C-TR,SBT5401 a
MAIN S Q 0301 87-A30-091-080 FET,2SJ460 a
MAIN S Q 0302 87-A30-091-080 FET,2SJ460 a
MAIN S Q 0303 87-A30-090-080 FET,2SK2541 a
MAIN S Q 0304 87-A30-090-080 FET,2SK2541 a
MAIN S Q 0305 87-A30-091-080 FET,2SJ460 a
MAIN S Q 0306 87-A30-091-080 FET,2SJ460 a
MAIN S Q 0307 87-A30-090-080 FET,2SK2541 a
MAIN S Q 0308 87-A30-090-080 FET,2SK2541 a
MAIN S Q 0309 87-A30-090-080 FET,2SK2541 a
MAIN S Q 0451 87-A30-630-080 TR,2SC5343GL a
MAIN S Q 0452 87-A30-076-040 C-TR,2SC3052F a
MAIN S Q 0453 89-333-317-880 TR,2SC3331(T/U) a
MAIN S Q 0454 89-333-317-880 TR,2SC3331(T/U) a
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-18-
ELECTRICAL PARTS LIST - 10/16
CX-SNTR77
USTC
MAIN S Q 0601 87-A30-538-040 C-TR,SRA2202S a
MAIN S Q 0835 87-A30-521-080 C-TR,2SC5345SF/S(O) a
MAIN S Q 0836 87-A30-677-040 C-TR,SRA2207S a
MAIN S Q 0901 89-503-602-080 C-FET,2SK360E a
MAIN S Q 0902 87-A30-664-080 C-TR,2SC2620B a
MAIN S Q 0904 87-A30-699-040 C-TR,2SC5477-T22 a
MAIN S Q 0981 87-A30-494-080 TR,2SA1980G a
MAIN S Q 0982 87-A30-076-040 C-TR,2SC3052F a
MAIN S Q 0983 87-A30-076-040 C-TR,2SC3052F a
MAIN X R 0003 88-128-109-080 C-RES, 1-1/8W J a
MAIN X R 0004 88-128-109-080 C-RES, 1-1/8W J a
MAIN X R 0007 88-128-109-080 C-RES, 1-1/8W J a
MAIN X R 0008 88-128-109-080 C-RES, 1-1/8W J a
MAIN X R 0009 88-108-273-080 C-RES,U 27K-1/16W J a
MAIN X R 0010 88-108-273-080 C-RES,U 27K-1/16W J a
MAIN X R 0011 88-118-472-080 C-RES,S 4.7K-1/10W J a
MAIN X R 0012 88-118-472-080 C-RES,S 4.7K-1/10W J a
MAIN X R 0013 88-108-472-080 C-RES,U 4.7K-1/16W J a
MAIN X R 0014 88-118-100-080 C-RES,S 10-1/10W J a
MAIN X R 0015 88-108-104-080 C-RES,U 100K-1/16W J a
CX-SNTR77
USTC
MAIN X R 0020 88-128-129-080 C-RES, 1.2-1/8W J a
MAIN X R 0021 88-128-129-080 C-RES, 1.2-1/8W J a
MAIN O R 0022 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN X R 0023 88-118-101-080 C-RES,S 100-1/10W J a
MAIN O R 0024 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN X R 0026 88-118-472-080 C-RES,S 4.7K-1/10W J a
MAIN X R 0027 88-118-472-080 C-RES,S 4.7K-1/10W J a
MAIN X R 0028 88-108-221-080 C-RES,U 220-1/16W J a
MAIN O R 0029 88-108-473-080 C-RES,U 47K-1/16W J a
MAIN X R 0030 88-129-000-080 CHIP JUMPER a
MAIN X R 0031 88-108-154-080 C-RES,U 150K-1/16W J a
MAIN X R 0032 88-118-472-080 C-RES,S 4.7K-1/10W J a
MAIN O R 0033 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN O R 0035 88-108-123-080 C-RES,U 12K-1/16W J a
MAIN X R 0037 88-128-182-080 C-RES, 1.8K-1/8W J a
MAIN X R 0038 88-128-182-080 C-RES, 1.8K-1/8W J a
MAIN X R 0041 88-100-000-010 JUMPER WIRE,PLATING a
MAIN X R 0042 88-129-000-080 CHIP JUMPER a
MAIN X R 0043 88-129-000-080 CHIP JUMPER a
MAIN X R 0044 88-128-271-080 C-RES, 270-1/8W J a
CX-SNTR77
USTC
MAIN X R 0045 88-128-331-080 C-RES, 330-1/8W J a
MAIN X R 0046 88-121-271-080 RES,270-1/8W J a
MAIN X R 0047 88-128-331-080 C-RES, 330-1/8W J a
MAIN X R 0048 88-128-221-080 C-RES, 220-1/8W J a
MAIN X R 0049 88-121-221-080 RES,220-1/8W J a
MAIN O R 0050 88-108-153-080 C-RES,U 15K-1/16W J a
MAIN O R 0051 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN O R 0052 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN X R 0053 88-108-683-080 C-RES,U 68K-1/16W J a
MAIN O R 0054 88-108-562-080 C-RES,U 5.6K-1/16W J a
MAIN X R 0055 88-108-222-080 C-RES,U 2.2K-1/16W J a
MAIN X R 0056 88-118-680-080 C-RES,S 68-1/10W J a
MAIN X R 0057 88-108-472-080 C-RES,U 4.7K-1/16W J a
MAIN O R 0058 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN X R 0059 88-108-221-080 C-RES,U 220-1/16W J a
MAIN X R 0060 88-108-471-080 C-RES,U 470-1/16W J a
MAIN O R 0061 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN O R 0062 88-108-223-080 C-RES,U 22K-1/16W J a
MAIN O R 0063 88-108-223-080 C-RES,U 22K-1/16W J a
MAIN O R 0064 88-108-103-080 C-RES,U 10K-1/16W J a
CX-SNTR77
USTC
MAIN O R 0065 88-108-123-080 C-RES,U 12K-1/16W J a
MAIN X R 0066 88-108-104-080 C-RES,U 100K-1/16W J a
MAIN O R 0067 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN O R 0068 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN O R 0069 88-108-101-080 C-RES,U 100-1/16W J a
MAIN X R 0070 88-128-393-080 C-RES, 39K-1/8W J a
MAIN X R 0071 88-128-393-080 C-RES, 39K-1/8W J a
MAIN X R 0072 88-128-393-080 C-RES, 39K-1/8W J a
MAIN X R 0073 88-128-393-080 C-RES, 39K-1/8W J a
MAIN X R 0082 88-128-682-080 C-RES, 6.8K-1/8W J a
MAIN X R 0083 88-128-682-080 C-RES, 6.8K-1/8W J a
MAIN X R 0084 88-128-682-080 C-RES, 6.8K-1/8W J a
MAIN X R 0085 88-128-682-080 C-RES, 6.8K-1/8W J a
MAIN O R 0091 88-108-823-080 C-RES,U 82K-1/16W J a
MAIN X R 0092 88-108-393-080 C-RES,U 39K-1/16W J a
MAIN O R 0093 88-108-153-080 C-RES,U 15K-1/16W J a
MAIN O R 0094 88-108-823-080 C-RES,U 82K-1/16W J a
MAIN X R 0095 88-108-393-080 C-RES,U 39K-1/16W J a
MAIN O R 0096 88-108-153-080 C-RES,U 15K-1/16W J a
MAIN O R 0103 88-108-473-080 C-RES,U 47K-1/16W J a
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-19-
ELECTRICAL PARTS LIST - 11/16
CX-SNTR77
USTC
MAIN O R 0104 88-108-473-080 C-RES,U 47K-1/16W J a
MAIN X R 0105 88-108-273-080 C-RES,U 27K-1/16W J a
MAIN X R 0106 88-108-273-080 C-RES,U 27K-1/16W J a
MAIN O R 0107 88-108-101-080 C-RES,U 100-1/16W J a
MAIN O R 0108 88-108-101-080 C-RES,U 100-1/16W J a
MAIN X R 0109 88-118-332-080 C-RES,S 3.3K-1/10W J a
MAIN X R 0110 88-118-332-080 C-RES,S 3.3K-1/10W J a
MAIN X R 0111 88-118-102-080 C-RES,S 1K-1/10W J a
MAIN X R 0112 88-118-102-080 C-RES,S 1K-1/10W J a
MAIN X R 0113 88-118-273-080 C-RES,S 27K-1/10W J a
MAIN X R 0114 88-118-273-080 C-RES,S 27K-1/10W J a
MAIN X R 0115 88-128-222-080 C-RES, 2.2K-1/8W J a
MAIN X R 0116 88-128-222-080 C-RES, 2.2K-1/8W J a
MAIN O R 0117 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN O R 0118 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN X R 0119 88-118-101-080 C-RES,S 100-1/10W J a
MAIN X R 0120 88-118-101-080 C-RES,S 100-1/10W J a
MAIN X R 0121 88-118-101-080 C-RES,S 100-1/10W J a
MAIN X R 0122 88-118-101-080 C-RES,S 100-1/10W J a
MAIN X R 0123 88-128-222-080 C-RES, 2.2K-1/8W J a
CX-SNTR77
USTC
MAIN X R 0124 88-128-222-080 C-RES, 2.2K-1/8W J a
MAIN X R 0125 88-128-102-080 C-RES, 1K-1/8W J a
MAIN X R 0126 88-128-102-080 C-RES, 1K-1/8W J a
MAIN X R 0127 88-118-390-080 C-RES,S 39-1/10W J a
MAIN X R 0128 88-118-390-080 C-RES,S 39-1/10W J a
MAIN O R 0129 87-A00-262-080 RES,M/F 0.15-2W J a
MAIN O R 0130 87-A00-262-080 RES,M/F 0.15-2W J a
MAIN O R 0131 87-A00-262-080 RES,M/F 0.15-2W J a
MAIN O R 0132 87-A00-262-080 RES,M/F 0.15-2W J a
MAIN X R 0133 88-108-152-080 C-RES,U 1.5K-1/16W J a
MAIN X R 0134 88-108-152-080 C-RES,U 1.5K-1/16W J a
MAIN X R 0135 88-108-222-080 C-RES,U 2.2K-1/16W J a
MAIN X R 0136 88-108-222-080 C-RES,U 2.2K-1/16W J a
MAIN O R 0137 88-108-101-080 C-RES,U 100-1/16W J a
MAIN O R 0138 88-108-101-080 C-RES,U 100-1/16W J a
MAIN X R 0141 88-118-102-080 C-RES,S 1K-1/10W J a
MAIN X R 0142 88-118-102-080 C-RES,S 1K-1/10W J a
MAIN X R 0143 88-108-392-080 C-RES,U 3.9K-1/16W J a
MAIN X R 0144 88-108-392-080 C-RES,U 3.9K-1/16W J a
MAIN O R 0151 88-108-473-080 C-RES,U 47K-1/16W J a
CX-SNTR77
USTC
MAIN O R 0152 88-108-473-080 C-RES,U 47K-1/16W J a
MAIN X R 0153 88-118-390-080 C-RES,S 39-1/10W J a
MAIN X R 0154 88-118-390-080 C-RES,S 39-1/10W J a
MAIN X R 0155 88-108-682-080 C-RES,U 6.8K-1/16W J a
MAIN X R 0156 88-108-682-080 C-RES,U 6.8K-1/16W J a
MAIN X R 0157 88-121-472-080 RES,4.7K-1/8W J a
MAIN X R 0158 88-108-472-080 C-RES,U 4.7K-1/16W J a
MAIN O R 0159 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN X R 0160 88-118-103-080 C-RES,S 10K-1/10W J a
MAIN X R 0161 88-108-472-080 C-RES,U 4.7K-1/16W J a
MAIN X R 0162 88-108-472-080 C-RES,U 4.7K-1/16W J a
MAIN X R 0163 88-108-472-080 C-RES,U 4.7K-1/16W J a
MAIN X R 0164 88-108-472-080 C-RES,U 4.7K-1/16W J a
MAIN X R 0165 88-108-152-080 C-RES,U 1.5K-1/16W J a
MAIN X R 0166 88-108-152-080 C-RES,U 1.5K-1/16W J a
MAIN O R 0167 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN X R 0168 88-118-473-080 C-RES,S 47K-1/10W J a
MAIN X R 0171 88-118-222-080 C-RES,S 2.2K-1/10W J a
MAIN X R 0172 88-118-222-080 C-RES,S 2.2K-1/10W J a
MAIN X R 0173 88-118-182-080 C-RES,S 1.8K-1/10W J a
CX-SNTR77
USTC
MAIN X R 0174 88-118-182-080 C-RES,S 1.8K-1/10W J a
MAIN X R 0175 88-118-331-080 C-RES,S 330-1/10W J a
MAIN X R 0176 88-118-331-080 C-RES,S 330-1/10W J a
MAIN X R 0178 88-118-103-080 C-RES,S 10K-1/10W J a
MAIN O R 0179 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN O R 0180 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN X R 0181 88-108-222-080 C-RES,U 2.2K-1/16W J a
MAIN X R 0182 88-108-222-080 C-RES,U 2.2K-1/16W J a
MAIN X R 0183 88-128-392-080 C-RES, 3.9K-1/8W J a
MAIN X R 0184 88-121-102-080 RES,1K-1/8W J a
MAIN O R 0185 88-108-332-080 C-RES,U 3.3K-1/16W J a
MAIN X R 0186 88-118-102-080 C-RES,S 1K-1/10W J a
MAIN X R 0187 88-118-103-080 C-RES,S 10K-1/10W J a
MAIN X R 0188 88-118-222-080 C-RES,S 2.2K-1/10W J a
MAIN X R 0189 88-128-392-080 C-RES, 3.9K-1/8W J a
MAIN X R 0190 88-128-392-080 C-RES, 3.9K-1/8W J a
MAIN X R 0192 88-128-392-080 C-RES, 3.9K-1/8W J a
MAIN O R 0193 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN O R 0194 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN O R 0195 88-108-473-080 C-RES,U 47K-1/16W J a
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
-20-
ELECTRICAL PARTS LIST - 12/16
CX-SNTR77
USTC
MAIN O R 0196 88-108-473-080 C-RES,U 47K-1/16W J a
MAIN O R 0197 88-108-473-080 C-RES,U 47K-1/16W J a
MAIN O R 0198 88-108-473-080 C-RES,U 47K-1/16W J a
MAIN X R 0199 88-121-225-080 RES,2.2M-1/8W J a
MAIN X R 0204 88-128-392-080 C-RES, 3.9K-1/8W J a
MAIN X R 0207 88-128-392-080 C-RES, 3.9K-1/8W J a
MAIN X R 0208 88-128-392-080 C-RES, 3.9K-1/8W J a
MAIN X R 0217 88-108-683-080 C-RES,U 68K-1/16W J a
MAIN X R 0218 88-108-105-080 C-RES,U 1M-1/16W J a
MAIN O R 0219 88-108-153-080 C-RES,U 15K-1/16W J a
MAIN X R 0220 88-118-154-080 C-RES,S 150K-1/10W J a
MAIN X R 0221 88-128-180-080 C-RES, 18-1/8W J a
MAIN X R 0222 88-128-180-080 C-RES, 18-1/8W J a
MAIN X R 0223 88-128-180-080 C-RES, 18-1/8W J a
MAIN X R 0227 88-108-471-080 C-RES,U 470-1/16W J a
MAIN X R 0228 88-108-471-080 C-RES,U 470-1/16W J a
MAIN X R 0247 88-130-100-080 RES,10-1/4W J a
MAIN X R 0248 88-130-100-080 RES,10-1/4W J a
MAIN X R 0249 88-128-100-080 C-RES, 10-1/8W J a
MAIN X R 0250 88-128-100-080 C-RES, 10-1/8W J a
CX-SNTR77
USTC
MAIN X R 0280 88-128-473-080 C-RES, 47K-1/8W J a
MAIN X R 0281 88-108-152-080 C-RES,U 1.5K-1/16W J a
MAIN O R 0282 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN O R 0283 88-108-224-080 C-RES,U 220K-1/16W J a
MAIN O R 0284 88-108-224-080 C-RES,U 220K-1/16W J a
MAIN X R 0285 88-108-333-080 C-RES,U 33K-1/16W J a
MAIN O R 0286 88-108-473-080 C-RES,U 47K-1/16W J a
MAIN O R 0287 88-108-473-080 C-RES,U 47K-1/16W J a
MAIN X R 0301 88-108-393-080 C-RES,U 39K-1/16W J a
MAIN X R 0302 88-108-393-080 C-RES,U 39K-1/16W J a
MAIN O R 0303 88-108-823-080 C-RES,U 82K-1/16W J a
MAIN O R 0304 88-108-823-080 C-RES,U 82K-1/16W J a
MAIN O R 0305 88-108-224-080 C-RES,U 220K-1/16W J a
MAIN X R 0451 88-121-222-080 RES,2.2K-1/8W J a
MAIN X R 0453 88-118-472-080 C-RES,S 4.7K-1/10W J a
MAIN X R 0454 88-121-829-080 RES,8.2-1/8W J a
MAIN X R 0455 88-108-183-080 C-RES,U 18K-1/16W J a
MAIN X R 0456 88-108-183-080 C-RES,U 18K-1/16W J a
MAIN X R 0457 88-108-104-080 C-RES,U 100K-1/16W J a
MAIN O R 0458 88-108-563-080 C-RES,U 56K-1/16W J a
CX-SNTR77
USTC
MAIN X R 0459 88-118-472-080 C-RES,S 4.7K-1/10W J a
MAIN X R 0460 88-108-229-080 C-RES,U 2.2-1/16W J a
MAIN O R 0463 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN O R 0464 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN X R 0601 88-108-680-080 C-RES,U 68-1/16W J a
MAIN X R 0602 88-108-680-080 C-RES,U 68-1/16W J a
MAIN X R 0603 88-108-394-080 C-RES,U 390K-1/16W J a
MAIN X R 0604 88-108-394-080 C-RES,U 390K-1/16W J a
MAIN X R 0605 88-108-122-080 C-RES,U 1.2K-1/16W J a
MAIN X R 0606 88-108-122-080 C-RES,U 1.2K-1/16W J a
MAIN X R 0607 88-108-183-080 C-RES,U 18K-1/16W J a
MAIN X R 0608 88-108-183-080 C-RES,U 18K-1/16W J a
MAIN X R 0609 88-108-472-080 C-RES,U 4.7K-1/16W J a
MAIN X R 0610 88-121-472-080 RES,4.7K-1/8W J a
MAIN X R 0611 88-108-682-080 C-RES,U 6.8K-1/16W J a
MAIN X R 0612 88-108-682-080 C-RES,U 6.8K-1/16W J a
MAIN X R 0613 88-108-682-080 C-RES,U 6.8K-1/16W J a
MAIN X R 0614 88-108-682-080 C-RES,U 6.8K-1/16W J a
MAIN X R 0615 88-108-273-080 C-RES,U 27K-1/16W J a
MAIN X R 0616 88-108-273-080 C-RES,U 27K-1/16W J a
CX-SNTR77
USTC
MAIN X R 0617 88-121-822-080 RES,8.2K-1/8W J a
MAIN X R 0618 88-121-822-080 RES,8.2K-1/8W J a
MAIN O R 0619 88-108-153-080 C-RES,U 15K-1/16W J a
MAIN O R 0620 88-108-153-080 C-RES,U 15K-1/16W J a
MAIN O R 0621 88-108-332-080 C-RES,U 3.3K-1/16W J a
MAIN O R 0622 88-108-332-080 C-RES,U 3.3K-1/16W J a
MAIN X R 0623 88-108-472-080 C-RES,U 4.7K-1/16W J a
MAIN X R 0624 88-108-472-080 C-RES,U 4.7K-1/16W J a
MAIN O R 0625 88-108-332-080 C-RES,U 3.3K-1/16W J a
MAIN O R 0626 88-108-332-080 C-RES,U 3.3K-1/16W J a
MAIN X R 0627 88-108-222-080 C-RES,U 2.2K-1/16W J a
MAIN X R 0628 88-108-222-080 C-RES,U 2.2K-1/16W J a
MAIN O R 0629 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN O R 0630 88-108-103-080 C-RES,U 10K-1/16W J a
MAIN X R 0631 88-108-222-080 C-RES,U 2.2K-1/16W J a
MAIN X R 0632 88-108-222-080 C-RES,U 2.2K-1/16W J a
MAIN O R 0633 88-108-272-080 C-RES,U 2.7K-1/16W J a
MAIN O R 0634 88-108-272-080 C-RES,U 2.7K-1/16W J a
MAIN O R 0635 88-108-102-080 C-RES,U 1K-1/16W J a
MAIN O R 0636 88-108-102-080 C-RES,U 1K-1/16W J a
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
