Aiwa XR-M22 User manual
S E R V I C E M A N U A L
SIMPLE MANUAL
•Replace this Service Manual with ”Revision Publishing” when it is issued.
XR-M22
• BASIC TAPE MECHANISM: 2ZM–1 YR8NC
• BASIC CD MECHANISM: 3ZG–3 E2NC • TYPE: HR,LH
S/M Code No. 09–991–400–3T3
COMPACT DISC STEREO SYSTEM
ELECTRICAL MAIN PARTS LIST - 1/6
NOTE: The characters in the suffix column indicate the part usage.
22LH ...................XX...................................B..................
22HR ...................XX....................................C.................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
C 302 87-010-197-080 CAP, CHIP 0.01 DM ABCDEFGH............
C 304 87-010-405-040 CAP,E 10-50 ABCDEFGH............
C 308 87-010-421-040 CAP,E 4.7-50 5L ABCDEFGH............
C 307 87-010-421-040 CAP,E 4.7-50 5L ABCDEFGH............
C 309 87-015-883-080 CHIP CAPACITOR, 0.022 (D) ABCDEFGH............
C 305 87-016-513-080 CAP,E 47-35 7L A...................
C 305 87-A10-797-040 CAP,E 47-35 M 5L SRM .BCDEFGH............
C 316 87-010-197-080 CAP, CHIP 0.01 DM ABCDEFGH............
C 317 87-010-198-080 CAP, CHIP 0.022 ABCDEFGH............
C 315 87-010-198-080 CAP, CHIP 0.022 ABCDEFGH............
C 313 87-010-263-040 CAP,E 100-10 ABCDEFGH............
C 314 87-A10-189-040 CAP,E 220-10 ABCDEFGH............
C 329 87-010-198-080 CAP, CHIP 0.022 ABCDEFGH............
C 328 87-010-320-080 CHIP CAP 68P ABCDEFGH............
C 338 87-010-197-080 CAP, CHIP 0.01 DM ABCDEFGH............
C 339 87-010-197-080 CAP, CHIP 0.01 DM ABCDEFGH............
C 331 87-010-312-080 C-CAP,S 15P-50 CH ABCDEFGH............
C 335 87-010-316-080 C-CAP,S 33P-50 CH ABCDEFGH............
C 330 87-010-318-080 C-CAP,S 47P-50 CH ABCDEFGH............
C 333 87-010-401-040 CAP,E 1-50 SME ABCDEFGH............
C 340 87-010-197-080 CAP, CHIP 0.01 DM ABCDEFGH............
CN 303 87-099-203-010 CONN,10P 6216 H ABCDEFGH............
CN 301 87-099-720-010 CONN,30P TYK-B(P) ABCDEFGH............
CN 302 87-CL4-704-010 CONN ASSY 9P DECK ABCDEFGH............
D 309 87-020-465-080 DIODE,1SS133 (110MA) ABCDEFGH............
D 316 87-017-931-080 ZENER,MTZJ5.6B ABCDEFGH............
D 322 87-020-027-080 CHIP-DIODE 1SS184 ABCDEFGH............
D 320 87-020-125-080 DIODE,1SS181 (100MA) ABCDEFGH............
FL 301 88-CE3-602-010 FL,11BT-162GK A...................
FL 301 8Z-CL7-682-110 FL,SVA-11MM23 .BCDEFGH............
GFL 1 82-NF7-210-110 GUIDE,FL (*) ABCDEFGH............
IC 303 87-A20-914-010 IC,SPS-442-1-F ABCDEFGH............
IC 301 8Z-CL7-681-010 C-IC,M38B57MC A...................
IC 301 8Z-CL7-683-010 C-IC,M38B557MC .BCDEFGH............
LED 301 87-A40-229-040 LED,SLR-342VR TB7 RED ABCDEFGH............
LED 303 87-A40-619-040 LED,SLR-56PT-T31-W GRN ABCDEFGH............
LED 302 87-A40-619-040 LED,SLR-56PT-T31-W GRN ABCDEFGH............
LED 304 87-A40-619-040 LED,SLR-56PT-T31-W GRN ABCDEFGH............
LED 305 87-A40-619-040 LED,SLR-56PT-T31-W GRN ABCDEFGH............
Q 301 87-026-245-080 TR,DTC114ES ABCDEFGH............
Q 309 89-111-624-080 TR,2SA1162Y ABCDEFGH............
Q 302 89-112-965-080 TR,2SA1296 (0.75W) ABCDEFGH............
Q 313 87-026-235-080 CHIP-TR,DTC114EK ABCDEFGH............
Q 310 87-A30-090-080 FET,2SK2541 ABCDEFGH............
Q 312 89-327-125-080 CHIP TR,2SC2712GR ABCDEFGH............
S 315 87-A90-095-080 SW,TACT EVQ11G04M ABCDEFGH............
S 316 87-A90-095-080 SW,TACT EVQ11G04M ABCDEFGH............
S 312 87-A90-095-080 SW,TACT EVQ11G04M ABCDEFGH............
S 317 87-A90-095-080 SW,TACT EVQ11G04M ABCDEFGH............
S 314 87-A90-095-080 SW,TACT EVQ11G04M ABCDEFGH............
S 313 87-A90-095-080 SW,TACT EVQ11G04M ABCDEFGH............
S 311 87-A90-095-080 SW,TACT EVQ11G04M ABCDEFGH............
S 318 87-A90-095-080 SW,TACT EVQ11G04M ABCDEFGH............
S 351 87-A90-085-010 SW,RTRY EC16B 24204 ABCDEFGH............
X 301 87-030-375-080 VIB,CF 4.19MG200 ABCDEFGH............
C 7 87-010-178-080 CHIP CAP 1000P ABCDEFGH............
C 8 87-010-198-080 CAP, CHIP 0.022 ABCDEFGH............
C 4 87-010-371-080 CAP, ELECT 470-6.3V ABCDEFGH............
C 3 87-010-401-080 CAP, ELECT 1-50V ABCDEFGH............
C 1 87-010-406-080 CAP, ELECT 22-50 ABCDEFGH............
C 17 87-010-178-080 CHIP CAP 1000P ABCDEFGH............
C 18 87-010-213-080 C-CAP,S 0.015-50 B ABCDEFGH............
C 12 87-010-401-080 CAP, ELECT 1-50V ABCDEFGH............
C 14 87-010-405-080 CAP, ELECT 10-50V ABCDEFGH............
C 16 87-010-544-080 CAP, ELECT 0.1-50V ABCDEFGH............
C 29 87-010-178-080 CHIP CAP 1000P ABCDEFGH............
C 22 87-010-180-080 C-CER 1500P ABCDEFGH............
C 23 87-010-993-080 C-CAP,S 0.056-25 B ABCDEFGH............
C 24 87-012-155-080 C-CAP 180P-50CH ABCDEFGH............
C 20 87-016-369-080 C-CAP,S 0.033-25 B K ABCDEFGH............
C 21 87-A11-010-080 CAP,M 0.082-50 J DE ABCDEFGH............
C 26 87-A11-014-080 CAP,M 0.22-50 J DE ABCDEFGH............
C 39 87-010-178-080 CHIP CAP 1000P ABCDEFGH............
C 30 87-010-178-080 CHIP CAP 1000P ABCDEFGH............
C 34 87-010-186-080 CAP,CHIP 4700P ABCDEFGH............
C 33 87-010-401-080 CAP, ELECT 1-50V ABCDEFGH............
C 31 87-010-402-080 CAP, ELECT 2.2-50V ABCDEFGH............
C 32 87-010-403-080 CAP, ELECT 3.3-50V ABCDEFGH............
C 40 87-010-147-080 C-CAP,S 3P-50 CH ABCDEFGH............
C 44 87-010-176-080 C-CAP,S 680P-50 SL ABCDEFGH............
C 42 87-010-313-080 CAP, CHIP 18P ABCDEFGH............
C 48 87-010-315-080 C-CAP,S 27P-50 CH ABCDEFGH............
C 41 87-A11-006-080 CAP,M 0.033-50 J DE ABCDEFGH............
C 58 87-010-316-080 C-CAP,S 33P-50 CH ABCDEFGH............
C 57 87-010-316-080 C-CAP,S 33P-50 CH ABCDEFGH............
ELECTRICAL MAIN PARTS LIST - 2/6
C 50 87-012-140-080 CAP 470P ABCDEFGH............
C 62 87-010-370-080 CAP,E 330-6.3 SME ABCDEFGH............
C 76 87-A10-102-080 CAP,E 1000-10 REA ABCDEFGH............
C 80 87-010-112-080 CAP, ELECT 100-16V ABCDEFGH............
C 85 87-010-263-080 CAP, ELECT 100-10V ABCDEFGH............
C 81 87-010-405-080 CAP, ELECT 10-50V ABCDEFGH............
C 82 87-010-405-080 CAP, ELECT 10-50V ABCDEFGH............
C 84 87-012-157-080 C-CAP,S 330P-50 CH ABCDEFGH............
C 83 87-012-157-080 C-CAP,S 330P-50 CH ABCDEFGH............
C 97 87-010-197-080 CAP, CHIP 0.01 DM ABCDEFGH............
C 90 87-010-197-080 CAP, CHIP 0.01 DM ABCDEFGH............
C 96 87-010-221-080 CAP, ELECT 470-10V ABCDEFGH............
C 92 87-010-235-080 CAP,E 470-16 SME ABCDEFGH............
C 99 87-010-374-080 CAP, ELECT 47-10V ABCDEFGH............
C 91 87-010-404-080 CAP, ELECT 4.7-50V ABCDEFGH............
C 98 87-012-154-080 C-CAP,S 150P-50 CH ABCDEFGH............
C 100 87-010-318-080 C-CAP,S 47P-50 CH ABCDEFGH............
C 104 87-010-322-080 C-CAP,S 100P-50 CH ABCDEFGH............
C 106 87-010-322-080 C-CAP,S 100P-50 CH ABCDEFGH............
C 128 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDEFGH............
C 124 87-010-322-080 C-CAP,S 100P-50 CH ABCDEFGH............
C 121 87-010-322-080 C-CAP,S 100P-50 CH ABCDEFGH............
C 123 87-010-322-080 C-CAP,S 100P-50 CH ABCDEFGH............
C 127 87-010-322-080 C-CAP,S 100P-50 CH ABCDEFGH............
C 126 87-010-322-080 C-CAP,S 100P-50 CH ABCDEFGH............
C 125 87-010-322-080 C-CAP,S 100P-50 CH ABCDEFGH............
C 122 87-010-322-080 C-CAP,S 100P-50 CH ABCDEFGH............
C 129 87-010-805-080 CAP, S 1-16 ABCDEFGH............
C 131 87-010-805-080 CAP, S 1-16 ABCDEFGH............
C 132 87-010-805-080 CAP, S 1-16 ABCDEFGH............
CN 2 87-099-203-010 CONN,10P 6216 H ABCDEFGH............
CN 6 87-A60-130-010 CONN,5P V FE ABCDEFGH............
CN 3 87-A60-131-010 CONN,6P V FE ABCDEFGH............
CN 4 87-A60-248-010 CONN,16P H CFF1416 .BCDEFGH............
CN 4 87-A60-424-010 CONN,16P V TOC-B A...................
D 4 87-020-465-080 DIODE,1SS133 (110MA) ABCDEFGH............
D 21 87-020-027-080 CHIP-DIODE 1SS184 ABCDEFGH............
D 22 87-020-027-080 CHIP-DIODE 1SS184 ABCDEFGH............
FB 102 87-A90-896-080 F-BEAD, 035600STY7 ABCDEFGH............
IC 6 87-020-903-010 IC,NJM7805FA ABCDEFGH............
IC 4 87-A20-157-010 IC,TA2092N ABCDEFGH............
IC 1 87-A20-446-010 C-IC,LA9241ML ABCDEFGH............
IC 2 87-A20-459-010 C-IC,LC78622ED ABCDEFGH............
IC 10 87-001-982-010 IC,TA7291S ABCDEFGH............
Q 1 87-026-463-080 TR,2SA933S (0.3W) ABCDEFGH............
Q 83 87-026-223-080 TR,DTC143TK ABCDEFGH............
Q 84 87-026-223-080 TR,DTC143TK ABCDEFGH............
Q 81 87-026-297-080 TR,DTA144TK ABCDEFGH............
Q 82 87-026-297-080 TR,DTA144TK ABCDEFGH............
Q 99 87-026-610-080 TR,KTC3198GR ABCDEFGH............
Q 96 89-109-521-080 TR,2SA952 (0.6W) ABCDEFGH............
Q 90 89-109-521-080 TR,2SA952 (0.6W) ABCDEFGH............
Q 94 89-109-521-080 TR,2SA952 (0.6W) ABCDEFGH............
Q 98 89-318-155-080 TR,2SC1815 (0.4W) ABCDEFGH............
R 70 87-029-124-090 RESISTOR, FUSE 1/4W 2.2 ABCDEFGH............
R 73 87-029-361-090 FUSING RESISTOR, 1/2W-3.3 ABCDEFGH............
X 1 87-A70-046-010 VIB,XTAL 16.934MHZ ABCDEFGH............
87-067-579-010 TAPPING SCREW, BVT2+3-8 ABCDEFGH............
C 209 87-010-186-080 CAP,CHIP 4700P ABCDEFGH............
C 208 87-010-546-080 CAP, ELECT 0.33-50V ABCDEFGH............
C 207 87-010-546-080 CAP, ELECT 0.33-50V ABCDEFGH............
C 210 87-010-186-080 CAP,CHIP 4700P ABCDEFGH............
C 214 87-010-260-080 CAP, ELECT 47-25V ABCDEFGH............
C 213 87-010-260-080 CAP, ELECT 47-25V ABCDEFGH............
C 212 87-010-403-080 CAP, ELECT 3.3-50V ABCDEFGH............
C 211 87-010-403-080 CAP, ELECT 3.3-50V ABCDEFGH............
C 219 87-010-544-080 CAP, ELECT 0.1-50V ABCDEFGH............
C 221 87-010-189-080 C-CAP,S 8200P-50 B ...DEFGH............
C 222 87-010-189-080 C-CAP,S 8200P-50 B ...DEFGH............
C 227 87-010-260-080 CAP, ELECT 47-25V ABCDEFGH............
C 229 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 220 87-010-544-080 CAP, ELECT 0.1-50V ABCDEFGH............
C 229 87-012-156-080 C-CAP,S 220P-50 CH .BCDEFGH............
C 230 87-010-322-080 C-CAP,S 100P-50 CH A...................
C 230 87-012-156-080 C-CAP,S 220P-50 CH .BCDEFGH............
C 261 87-010-197-080 CAP, CHIP 0.01 DM ABCDEFGH............
C 276 87-010-178-080 CHIP CAP 1000P ...DEFGH............
C 273 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDEFGH............
C 275 87-012-145-080 CAP, CHIP S 270P CH ...DEFGH............
C 274 87-012-145-080 CAP, CHIP S 270P CH ...DEFGH............
D 204 87-020-465-080 DIODE,1SS133 (110MA) ABCDEFGH............
D 206 87-020-465-080 DIODE,1SS133 (110MA) ABCDEFGH............
D 209 87-020-465-080 DIODE,1SS133 (110MA) ABCDEFGH............
D 203 87-020-465-080 DIODE,1SS133 (110MA) ABCDEFGH............
D 205 87-020-465-080 DIODE,1SS133 (110MA) ABCDEFGH............
D 202 87-020-465-080 DIODE,1SS133 (110MA) ABCDEFGH............
D 201 87-020-465-080 DIODE,1SS133 (110MA) ABCDEFGH............
D 210 87-020-465-080 DIODE,1SS133 (110MA) ABCDEFGH............
D 211 87-020-465-080 DIODE,1SS133 (110MA) ABCDEFGH............
J 231 87-A60-420-010 JACK,3.5 ST (MSC) ABCDEFGH............
J 241 87-A60-217-010 TERMINAL,SPKR 4P ABCDEFGH............
L 201 87-005-366-010 COIL, 1UH ABCDEFGH............
ELECTRICAL MAIN PARTS LIST - 3/6
L 202 87-005-366-010 COIL, 1UH ABCDEFGH............
Q 202 87-A30-197-080 TR,KTA1267GR ABCDEFGH............
Q 201 87-A30-197-080 TR,KTA1267GR ABCDEFGH............
Q 203 87-A30-197-080 TR,KTA1267GR ABCDEFGH............
Q 204 87-A30-197-080 TR,KTA1267GR ABCDEFGH............
Q 205 87-A30-198-080 TR,KTC3199GR ABCDEFGH............
Q 208 87-A30-198-080 TR,KTC3199GR ABCDEFGH............
Q 207 87-A30-198-080 TR,KTC3199GR ABCDEFGH............
Q 206 87-A30-198-080 TR,KTC3199GR ABCDEFGH............
Q 209 89-333-317-080 TR,2SC3331 (0.5W) ABCDEFGH............
Q 217 87-026-219-080 TR,DTA144ES (0.3W) ABCDEFGH............
Q 213 87-A30-126-010 TR,2SB1616 ABCDEFGH............
Q 214 87-A30-126-010 TR,2SB1616 ABCDEFGH............
Q 211 87-A30-127-010 TR,2SD2478 ABCDEFGH............
Q 212 87-A30-127-010 TR,2SD2478 ABCDEFGH............
Q 215 87-A30-198-080 TR,KTC3199GR ABCDEFGH............
Q 216 87-A30-198-080 TR,KTC3199GR ABCDEFGH............
Q 210 89-333-317-080 TR,2SC3331 (0.5W) ABCDEFGH............
Q 263 87-026-609-080 TR,KTA1266GR ABCDEFGH............
Q 262 89-406-555-080 TR,2SD655 (0.5W) ABCDEFGH............
Q 261 89-406-555-080 TR,2SD655 (0.5W) ABCDEFGH............
R 223 87-A00-258-080 RES,M/F 0.22-1W J ABCDEFGH............
R 224 87-A00-258-080 RES,M/F 0.22-1W J ABCDEFGH............
R 249 87-A00-258-080 RES,M/F 0.22-1W J ABCDEFGH............
R 250 87-A00-258-080 RES,M/F 0.22-1W J ABCDEFGH............
C 102 87-010-197-080 CAP, CHIP 0.01 DM ABCDEFGH............
C 109 87-010-260-080 CAP, ELECT 47-25V ABCDEFGH............
C 108 87-010-381-080 CAP, ELECT 330-16V ABCDEFGH............
C 107 87-010-384-080 CAP, ELECT 100-25V ABCDEFGH............
C 106 87-010-408-080 CAP, ELECT 47-50V ABCDEFGH............
C 105 87-012-140-080 CAP 470P ABCDEFGH............
C 101 87-016-495-090 CAP,E 3300-25 SMG ABCDEFGH............
C 104 87-A10-011-090 CAP,E 2200-25 SMG ABCDEFGH............
C 111 87-010-247-080 CAP, ELECT 100-50V ABCDEFGH............
C 110 87-010-260-080 CAP, ELECT 47-25V ABCDEFGH............
C 112 87-010-263-080 CAP, ELECT 100-10V ABCDEFGH............
C 114 87-010-374-080 CAP, ELECT 47-10V ABCDEFGH............
C 113 87-010-403-080 CAP, ELECT 3.3-50V ABCDEFGH............
C 115 87-A11-007-080 CAP,M 0.047-50 J DE ABCDEFGH............
C 116 87-A11-007-080 CAP,M 0.047-50 J DE ABCDEFGH............
C 122 87-010-260-080 CAP, ELECT 47-25V ABCDEFGH............
C 123 87-010-260-080 CAP, ELECT 47-25V ABCDEFGH............
C 131 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDEFGH............
C 132 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDEFGH............
C 151 87-015-785-080 CHIP CAPACITOR, 0.1FZ-25Z ABCDEFGH............
D 108 87-020-465-080 DIODE,1SS133 (110MA) ABCDEFGH............
D 107 87-A40-341-080 ZENER,MTZJ 36 A ABCDEFGH............
D 102 87-A40-535-080 DIODE,1N5393-GOODARK ABCDEFGH............
D 103 87-A40-535-080 DIODE,1N5393-GOODARK ABCDEFGH............
D 104 87-A40-535-080 DIODE,1N5393-GOODARK ABCDEFGH............
D 101 87-A40-535-080 DIODE,1N5393-GOODARK ABCDEFGH............
D 106 87-A40-553-080 DIODE,1N4003 LES ABCDEFGH............
D 105 87-A40-553-080 DIODE,1N4003 LES ABCDEFGH............
D 110 87-A40-345-080 ZENER,MTZJ10C ABCDEFGH............
D 116 87-A40-553-080 DIODE,1N4003 LES ABCDEFGH............
D 117 87-A40-553-080 DIODE,1N4003 LES ABCDEFGH............
PR 201 87-A90-070-080 PROTECTOR,3.5A 251 A...................
PR 202 87-A90-070-080 PROTECTOR,3.5A 251 A...................
PR 202 87-A90-473-080 PROTECTOR,3.5A 491SERIES 60V .BCDEFGH............
PR 201 87-A90-473-080 PROTECTOR,3.5A 491SERIES 60V .BCDEFGH............
Q 104 87-A30-196-080 TR,2SC4115SRS ABCDEFGH............
Q 107 87-A30-198-080 TR,KTC3199GR ABCDEFGH............
Q 106 87-A30-198-080 TR,KTC3199GR ABCDEFGH............
Q 109 87-A30-198-080 TR,KTC3199GR ABCDEFGH............
Q 105 89-113-187-080 TR,2SA1318TU ABCDEFGH............
Q 101 89-213-702-010 TR,2SB1370 (1.8W) ABCDEFGH............
Q 102 89-333-317-080 TR,2SC3331 (0.5W) ABCDEFGH............
Q 115 87-026-219-080 TR,DTA144ES (0.3W) ABCDEFGH............
Q 110 87-A30-197-080 TR,KTA1267GR ABCDEFGH............
Q 112 87-A30-198-080 TR,KTC3199GR ABCDEFGH............
Q 111 89-213-702-010 TR,2SB1370 (1.8W) ABCDEFGH............
W 101 8Z-CL7-652-010 CONN ASSY,8P ZCL7 A...................
W 101 8Z-CL7-652-110 CONN ASSY,8P ZCL7 .BCDEFGH............
C 303 87-010-177-080 C-CAP,S 820P-50 SL ABCDEFGH............
C 304 87-010-177-080 C-CAP,S 820P-50 SL ABCDEFGH............
C 307 87-010-263-080 CAP, ELECT 100-10V ABCDEFGH............
C 308 87-010-263-080 CAP, ELECT 100-10V ABCDEFGH............
C 313 87-010-184-080 CHIP CAPACITOR 3300P(K) ABCDEFGH............
C 314 87-010-184-080 CHIP CAPACITOR 3300P(K) ABCDEFGH............
C 311 87-010-195-080 C-CAP,S 0.068-25 F ABCDEFGH............
C 312 87-010-195-080 C-CAP,S 0.068-25 F ABCDEFGH............
C 315 87-010-374-080 CAP, ELECT 47-10V ABCDEFGH............
C 317 87-010-546-080 CAP, ELECT 0.33-50V ABCDEFGH............
C 318 87-010-546-080 CAP, ELECT 0.33-50V ABCDEFGH............
C 321 87-010-405-080 CAP, ELECT 10-50V ABCDEFGH............
C 349 87-010-322-080 C-CAP,S 100P-50 CH A..DEFGH............
C 340 87-012-156-080 C-CAP,S 220P-50 CH .BCDEFGH............
C 350 87-010-322-080 C-CAP,S 100P-50 CH A..DEFGH............
C 361 87-010-374-080 CAP, ELECT 47-10V ABCDEFGH............
C 362 87-010-401-080 CAP, ELECT 1-50V ABCDEFGH............
C 406 87-010-188-080 CAP,CHIP 6800P ABCDEFGH............
C 405 87-010-188-080 CAP,CHIP 6800P ABCDEFGH............
ELECTRICAL MAIN PARTS LIST - 4/6
C 403 87-010-321-080 CHIP CAPACITOR,82P(J) ABCDEFGH............
C 404 87-010-321-080 CHIP CAPACITOR,82P(J) ABCDEFGH............
C 402 87-010-401-080 CAP, ELECT 1-50V ABCDEFGH............
C 401 87-010-401-080 CAP, ELECT 1-50V ABCDEFGH............
C 407 87-010-426-080 C-CAP,S 0.012-25 B ABCDEFGH............
C 408 87-010-426-080 C-CAP,S 0.012-25 B ABCDEFGH............
C 459 87-010-175-080 CAP 560P ABCDEFGH............
C 458 87-010-178-080 CHIP CAP 1000P ABCDEFGH............
C 453 87-010-183-080 C-CAP,S 2700P-50 B ABCDEFGH............
C 454 87-010-183-080 C-CAP,S 2700P-50 B ABCDEFGH............
C 455 87-010-183-080 C-CAP,S 2700P-50 B ABCDEFGH............
C 456 87-010-197-080 CAP, CHIP 0.01 DM ABCDEFGH............
C 451 87-010-198-080 CAP, CHIP 0.022 ABCDEFGH............
C 452 87-010-382-080 CAP, ELECT 22-25V ABCDEFGH............
C 457 87-A10-772-080 CAP,M 5600P-50 J ABCDEFGH............
C 461 87-012-158-080 C-CAP,S 390P-50 CH ABCDEFGH............
C 462 87-012-158-080 C-CAP,S 390P-50 CH ABCDEFGH............
CN 351 87-A60-624-010 CONN,7P V 2MM JMT ABCDEFGH............
D 311 87-020-465-080 DIODE,1SS133 (110MA) ...DEFGH............
D 311 87-070-345-080 DIODE,IN4148 A...................
D 310 87-070-345-080 DIODE,IN4148 A...................
IC 301 87-017-889-010 IC,NJM4558LD ABCDEFGH............
IC 401 87-017-889-010 IC,NJM4558LD ABCDEFGH............
L 451 87-007-342-010 COIL,OSC 85K BIAS ABCDEFGH............
Q 306 87-026-218-080 TR,DTC144ES (0.2W) A...................
Q 306 87-026-219-080 TR,DTA144ES (0.3W) .BCDEFGH............
Q 308 87-A30-090-080 FET,2SK2541 .BCDEFGH............
Q 307 87-A30-090-080 FET,2SK2541 .BCDEFGH............
Q 305 87-A30-090-080 FET,2SK2541 .BCDEFGH............
Q 309 87-A30-197-080 TR,KTA1267GR ABCDEFGH............
Q 315 87-026-223-080 TR,DTC143TK A...................
Q 310 87-A30-197-080 TR,KTA1267GR ABCDEFGH............
Q 442 87-A30-197-080 TR,KTA1267GR ABCDEFGH............
Q 441 87-A30-197-080 TR,KTA1267GR ABCDEFGH............
Q 452 87-A30-198-080 TR,KTC3199GR ...DEFGH............
Q 451 89-333-317-080 TR,2SC3331 (0.5W) ABCDEFGH............
Q 453 89-333-317-080 TR,2SC3331 (0.5W) ABCDEFGH............
Q 454 89-333-317-080 TR,2SC3331 (0.5W) ABCDEFGH............
C 602 87-010-177-080 C-CAP,S 820P-50 SL A...................
C 601 87-010-177-080 C-CAP,S 820P-50 SL A...................
C 602 87-010-180-080 C-CER 1500P .BCDEFGH............
C 601 87-010-180-080 C-CER 1500P .BCDEFGH............
C 609 87-010-213-080 C-CAP,S 0.015-50 B ABCDEFGH............
C 603 87-010-322-080 C-CAP,S 100P-50 CH .BCDEFGH............
C 615 87-010-154-080 CAP CHIP 10P ABCDEFGH............
C 610 87-010-213-080 C-CAP,S 0.015-50 B ABCDEFGH............
C 619 87-010-401-080 CAP, ELECT 1-50V ABCDEFGH............
C 617 87-010-408-080 CAP, ELECT 47-50V ABCDEFGH............
C 616 87-010-408-080 CAP, ELECT 47-50V ABCDEFGH............
C 613 87-010-545-080 CAP, ELECT 0.22-50V ABCDEFGH............
C 611 87-010-545-080 CAP, ELECT 0.22-50V ABCDEFGH............
C 612 87-010-545-080 CAP, ELECT 0.22-50V ABCDEFGH............
C 614 87-010-545-080 CAP, ELECT 0.22-50V ABCDEFGH............
C 620 87-010-401-080 CAP, ELECT 1-50V ABCDEFGH............
C 635 87-010-178-080 CHIP CAP 1000P ...DEFGH............
C 638 87-010-182-080 C-CAP,S 2200P-50 B ...DEFGH............
C 631 87-010-197-080 CAP, CHIP 0.01 DM .BCDEFGH............
C 661 87-010-178-080 CHIP CAP 1000P ...DEFGH............
C 663 87-010-196-080 CHIP CAPACITOR,0.1-25 .BCDEFGH............
CN 202 87-099-719-010 CONN,30P TYK-B(X) ABCDEFGH............
CN 671 87-099-210-010 CONN,5P 6216 H .BCDEFGH............
CN 671 87-099-212-010 CONN,5P 6216 V A...................
D 603 87-020-465-080 DIODE,1SS133 (110MA) .....FGH............
D 602 87-A40-466-080 ZENER,MTZJ2.7A ABCDEFGH............
D 601 87-A40-466-080 ZENER,MTZJ2.7A ABCDEFGH............
IC 601 87-A21-111-040 C-IC,M62495FP ABCDEFGH............
J 601 87-A60-354-010 JACK,PIN 2P MSP -242V-05 ABCDEFGH............
PR 601 87-026-689-080 PROTECTOR,1A 60V 491 .BCDEFGH............
PR 601 87-A90-410-080 FUSE,0.5A 125V 251 A...................
PR 601 87-A91-153-080 FUSE,630MA 125V 251 ....................
Q 602 87-026-502-080 DTC144TS ABCDEFGH............
Q 601 87-026-502-080 DTC144TS ABCDEFGH............
Q 603 87-026-502-080 DTC144TS ABCDEFGH............
JW 10 87-A90-896-080 F-BEAD, 035600STY7 .BCDEFGH............
JW 311 87-020-465-080 DIODE,1SS133 (110MA) .BC.................
L 96 87-003-097-080 COIL,1UH ....................
C 814 87-012-286-080 CAP, U 0.01-25 ABCDEFGH............
C 820 87-010-234-080 CAP 47-16 ...DEFGH............
C 820 87-010-260-080 CAP, ELECT 47-25V ABC.................
C 909 87-012-286-080 CAP, U 0.01-25 ABCDEFGH............
C 910 87-012-286-080 CAP, U 0.01-25 ABCDEFGH............
C 942 87-012-172-080 CAPACITOR CHIP U 10P CH ...DEFGH............
C 949 87-A10-039-080 C-CAP,U 470P-50 J CH ...DEFGH............
C 958 87-010-197-080 CAP, CHIP 0.01 DM ...DEFGH............
C 959 87-010-831-080 C-CAP,U,0.1-16F .BCDEFGH............
C 963 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDEFGH............
C 962 87-010-401-080 CAP, ELECT 1-50V ...DEFGH............
C 961 87-012-170-080 C-CAP,U 8P-50 CH ABC.................
CF 802 82-785-747-010 CF MS2 GHY R ...DEFGH............
CF 801 87-008-261-010 FILTER, SFE10.7MA5-A ABC.................
CF 802 87-008-261-010 FILTER, SFE10.7MA5-A ABC.................
CF 801 87-008-423-010 CERAMIC FILTER, SFE10.7 ...DEFGH............
ELECTRICAL MAIN PARTS LIST - 5/6
D 944 87-020-465-080 DIODE,1SS133 (110MA) ...DEFGH............
D 942 87-A40-270-080 C-DIODE,MC2838 ...DEFGH............
FFE 801 A8-6ZA-191-130 6ZA-1 FEENM ...D.FG.............
FFE 801 A8-6ZA-19C-170 6ZA-1 YFEENC ....E..H............
FFE 801 A8-8ZA-190-030 8ZA-1 FEUNM A...................
FFE 801 A8-8ZA-193-070 8ZA-1 YFEUNC .BC.................
J 801 87-033-241-010 TERMINAL,ANT AJ-2039 ...DEFGH............
J 801 87-A60-202-010 TERMINAL,ANT 4P MSP-154V-02 ABC.................
L 832 87-005-847-080 COIL,2.2UH(CECS) ...DEFGH............
L 942 87-A50-019-010 COIL,OSC LW(COI) ...DEFGH............
L 941 87-A50-020-010 COIL,ANT LW(COI) ...DEFGH............
L 981 87-NF4-650-010 COIL,AM PACK 4N(TOK) ABC.................
L 981 87-NF4-651-110 COIL,AM PACK2N(TOM) ...DEFGH............
Q 806 87-A30-072-080 C-TR,RT1P 144C ABCDEFGH............
Q 805 89-327-143-080 TR,2SC2714 (0.1W) ABCDEFGH............
Q 948 87-A30-257-080 C-TR,2SD1306E ...DEFGH............
Q 947 89-505-434-540 C-FET,2SK543(4/5) ...DEFGH............
Q 951 87-A30-074-080 C-TR,RT1P 141C ...DEFGH............
Q 952 87-A30-257-080 C-TR,2SD1306E ...DEFGH............
TC 942 87-011-164-010 CAPACITOR,TRIMMER 30P ...DEFGH............
C 758 87-012-167-080 C-CAP,U 5P-50 CH ABCDEFGH............
C 757 87-012-188-080 C-CAP,U 47P-50 CH ABCDEFGH............
C 753 87-012-195-080 C-CAP,U 100P-50CH ...DEFGH............
C 761 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDEFGH............
C 766 87-010-197-080 CAP, CHIP 0.01 DM ...DEFGH............
C 769 87-010-234-080 CAP 47-16 .BC.................
C 769 87-010-260-080 CAP, ELECT 47-25V A..DEFGH............
C 764 87-012-337-080 C-CAP,U 56P-50 CH ABC.................
C 774 87-010-263-080 CAP, ELECT 100-10V ABCDEFGH............
C 771 87-010-383-080 CAP, ELECT 33-25V ABCDEFGH............
C 777 87-010-400-080 CAP, ELECT 0.47-50V ABCDEFGH............
C 778 87-010-401-080 CAP, ELECT 1-50V ABCDEFGH............
C 779 87-010-401-080 CAP, ELECT 1-50V ABCDEFGH............
C 775 87-010-404-080 CAP, ELECT 4.7-50V ABCDEFGH............
C 770 87-010-829-080 CAP, U 0.047-16 ABCDEFGH............
C 786 87-010-405-080 CAP, ELECT 10-50V ABCDEFGH............
C 785 87-010-405-080 CAP, ELECT 10-50V ABCDEFGH............
C 788 87-010-785-080 C-CAP,U0.015-25BK ...DEFGH............
C 787 87-010-785-080 C-CAP,U0.015-25BK ...DEFGH............
C 789 87-012-275-080 C-CAP,U 1200P-50 B ABCDEFGH............
C 783 87-012-286-080 CAP, U 0.01-25 ABCDEFGH............
C 796 87-010-403-080 CAP, ELECT 3.3-50V ABCDEFGH............
C 794 87-010-406-080 CAP, ELECT 22-50 ABCDEFGH............
C 795 87-010-596-080 CAP, S 0.047-16 ABCDEFGH............
C 793 87-012-273-080 C-CAP,U 820P-50 B ABC.................
C 790 87-012-275-080 C-CAP,U 1200P-50 B ABCDEFGH............
C 797 87-012-276-080 CAP, CHIP SS 1500 PBK ..CDEFGH............
C 798 87-012-276-080 CAP, CHIP SS 1500 PBK ..CDEFGH............
C 798 87-012-278-080 C-CAP,U 2200P-50 B AB..................
C 797 87-012-278-080 C-CAP,U 2200P-50 B AB..................
C 793 87-A10-915-080 C-CAP,U 1000P-25 J CH ...DEFGH............
D 773 87-020-465-080 DIODE,1SS133 (110MA) ABCDEFGH............
IC 771 87-A20-913-010 IC,LA1837NL ABCDEFGH............
L 771 87-A50-266-010 COIL,FM DET-2N(TOK) ABCDEFGH............
L 772 88-CL4-693-010 FLTR,PCFAYH-450 (TOK) ABCDEFGH............
L 781 87-005-847-080 COIL,2.2UH(CECS) ...DEFGH............
C 709 87-010-322-080 C-CAP,S 100P-50 CH ABC.................
C 701 87-010-381-080 CAP, ELECT 330-16V ABCDEFGH............
C 702 87-010-404-080 CAP, ELECT 4.7-50V ABCDEFGH............
C 711 87-010-263-080 CAP, ELECT 100-10V ABCDEFGH............
C 712 87-010-831-080 C-CAP,U,0.1-16F ...DEFGH............
C 713 87-012-286-080 CAP, U 0.01-25 ABCDEFGH............
C 712 87-015-785-080 CHIP CAPACITOR, 0.1FZ-25Z .BC.................
C 727 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDEFGH............
C 728 87-010-248-080 CAP, ELECT 220-10V ABCDEFGH............
C 721 87-012-176-080 CAP 15P ABCDEFGH............
C 722 87-012-176-080 CAP 15P ABCDEFGH............
C 720 87-012-195-080 C-CAP,U 100P-50CH ABCDEFGH............
C 729 87-012-274-080 CHIP CAP,U 1000P-50B ABCDEFGH............
C 725 87-018-131-080 CAP, CER 1000P-50V ...DEFGH............
D 722 87-020-465-080 DIODE,1SS133 (110MA) .BCDEFGH............
D 721 87-A40-234-080 ZENER,MTZJ5.6A ABCDEFGH............
IC 721 87-070-127-110 IC,LC72131 D ABCDEFGH............
Q 711 87-A30-196-080 TR,2SC4115SRS ABCDEFGH............
X 721 87-A70-061-010 VIB,XTAL 4.500MHZ CSA-309 ABCDEFGH............
C 859 87-012-286-080 CAP, U 0.01-25 .....FGH............
C 865 87-010-196-080 CHIP CAPACITOR,0.1-25 .....FGH............
C 864 87-010-405-080 CAP, ELECT 10-50V .....FGH............
C 866 87-010-405-080 CAP, ELECT 10-50V .....FGH............
C 869 87-012-180-080 C-CAP,U 22P-50 CH .....FGH............
C 868 87-012-184-080 C-CAP,U 33P-50 CH .....FGH............
C 861 87-012-199-080 CAP 220P .....FGH............
C 862 87-012-199-080 CAP 220P .....FGH............
C 863 87-012-270-080 CAP, U 470P-50 .....FGH............
C 867 87-012-286-080 CAP, U 0.01-25 .....FGH............
IC 851 87-A20-440-040 C-IC,BU1920FS .....FGH............
L 851 87-005-847-080 COIL,2.2UH(CECS) .....FGH............
Q 853 87-A30-076-080 C-TR,2SC3052F .....FGH............
X 851 87-A70-091-010 VIB,XTAL 4.332MHZ CSA-309 .....FGH............
C 526 87-010-112-080 CAP, ELECT 100-16V ABCDEFGH............
C 527 87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDEFGH............
C 528 87-010-374-080 CAP, ELECT 47-10V ABCDEFGH............
ELECTRICAL MAIN PARTS LIST - 6/6
C 529 87-010-401-080 CAP, ELECT 1-50V ABCDEFGH............
C 530 87-010-401-080 CAP, ELECT 1-50V ABCDEFGH............
C 532 87-010-402-080 CAP, ELECT 2.2-50V ABCDEFGH............
C 531 87-010-405-080 CAP, ELECT 10-50V ABCDEFGH............
C 537 87-010-546-080 CAP, ELECT 0.33-50V ABCDEFGH............
C 538 87-010-546-080 CAP, ELECT 0.33-50V ABCDEFGH............
C 533 87-A10-999-080 CAP,M 0.01-50 J DE ABCDEFGH............
C 534 87-A10-999-080 CAP,M 0.01-50 J DE ABCDEFGH............
C 535 87-A10-999-080 CAP,M 0.01-50 J DE ABCDEFGH............
C 536 87-A10-999-080 CAP,M 0.01-50 J DE ABCDEFGH............
D 501 87-A40-523-080 ZENER,MTZJ9.1B ABCDEFGH............
IC 501 87-A20-946-040 C-IC,MM1434XF ABCDEFGH............
C 101 87-010-387-080 CAP,E 470-25 SME ABCDEFGH............
CN 101 87-099-408-010 CONN,8P EH V WHT .BCDEFGH............
D 107 87-020-465-080 DIODE,1SS133 (110MA) ABCDEFGH............
D 108 87-020-465-080 DIODE,1SS133 (110MA) ABCDEFGH............
FC 101 87-A90-505-080 FUSE CLAMP,TP00351-51 ABC.................
FC 102 87-A90-505-080 FUSE CLAMP,TP00351-51 ABC.................
PR 102 87-026-681-080 PROTECTOR,5A 60V 491 .BCDEFGH............
PR 101 87-026-681-080 PROTECTOR,5A 60V 491 .BCDEFGH............
PR 101 87-026-690-080 FUSE,5A 125V 251 A...................
PR 102 87-026-690-080 FUSE,5A 125V 251 A...................
PR 104 87-A91-276-080 FUSE,125MA 125V F 251 ....................
PT 102 8Z-NF8-661-010 PT,SUB ZNF-8(U) A...................
PT 102 8Z-NF8-662-010 PT,SUB ZNF-8(E) ...DEFGH............
PT 102 8Z-NF8-663-010 PT,SUB ZNF-8(H) .BC.................
Q 101 87-026-610-080 TR,KTC3198GR ABCDEFGH............
RY 102 87-045-389-010 RELAY,OSA-SS-212DM5 ....................
RY 102 87-A90-976-010 RELAY,AC12V SDT-S-112LMR A..DEFGH............
RY 102 87-A91-281-010 RELAY,AC DC12V OSA-SS-212DM5 .BC.................
SW 101 87-A90-234-010 SW,SL 1-2-2 SW2201 .BC.................
T 101 87-A60-317-010 TERMINAL, 1P MSC ABCDEFGH............
T 102 87-A60-317-010 TERMINAL, 1P MSC ABCDEFGH............
MECHANICAL PARTS LIST - 1/1
NOTE: The characters in the suffix column indicate the part usage.
22LH ...................XX...................................B..................
22HR ...................XX....................................C.................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
8Z-CL7-001-010 CABI,FR U A...................
8Z-CL7-001-210 CABI,FR U ...DE...............
8Z-CL7-003-010 CABI,FR LH .BC.................
8Z-CL7-004-010 CABI,FR EZ-M34 .....F..............
8Z-CL7-005-010 CABI,FR EZ-M36 ......GH............
8Z-CL7-011-010 PANEL,REAR U1 A...................
8Z-CL7-011-110 PANEL,REAR U1 ....................
8Z-CL7-013-010 PANEL,REAR LH ....................
8Z-CL7-015-010 PANEL,REAR HRJ ..C.................
8Z-CL7-016-010 PANEL,REAR K ...D................
8Z-CL7-017-010 PANEL,REAR EZ-M34 .....F..............
8Z-CL7-018-010 PANEL,REAR EZ-M36 ......G.............
8Z-CL7-019-010 PANEL,REAR USC ....................
8Z-CL7-020-010 PANEL,REAR LHSC .B..................
8Z-CL7-021-010 PANEL,REAR KSC ....E...............
8Z-CL7-022-010 PANEL,REAR EZSC- M34 ....................
8Z-CL7-023-010 PANEL,REAR EZSC- M36 .......H............
8Z-CL7-026-010 CABI,TOP ABCDEFGH............
8Z-CL7-031-010 PANEL,BOX-CASS A...................
8Z-CL7-031-110 PANEL,BOX-CASS .BCDEFGH............
8Z-CL7-036-010 PANEL,TRAY A...................
8Z-CL7-036-110 PANEL,TRAY .BCDEFGH............
8Z-CL7-041-010 PANEL,FR ABCDEFGH............
8Z-CL7-060-010 KEY,POWER ASSY A...................
8Z-CL7-060-110 KEY,POWER ASSY .BCDEFGH............
8Z-CL7-062-010 KEY,OPEN A...................
8Z-CL7-062-110 KEY,OPEN .BCDEFGH............
8Z-CL7-063-010 KEY,FUNC ASSY ABCDEFGH............
8Z-CL7-065-010 KEY,CONT ASSY ABCDEFGH............
8Z-CL7-067-010 KEY,GEQ ABCDEFGH............
8Z-CL7-069-010 KEY,Q-SOUND ABCDEFGH............
8Z-CL7-070-010 KEY,ECO ABCDEFGH............
8Z-CL7-081-010 KNOB,RTRY VOL A...................
8Z-CL7-081-110 KNOB,RTRY VOL .BCDEFGH............
87-B00-002-010 BADGE,AIWA 30 ABS SIL ABCDEFGH............
8Z-CL7-051-010 WINDOW,DISP ABCDE...............
8Z-CL7-052-010 WINDOW,CASS ABCDEFGH............
8Z-CL7-055-010 WINDOW,DISP EZ .....FGH............
8Z-CL7-085-010 LENS,RC ABCDEFGH............
82-NF5-228-010 SPR-C,LOCK ABCDEFGH............
82-NF5-229-010 PLATE,LOCK ABCDEFGH............
82-ZM1-264-010 LVR,EJECT R ABCDEFGH............
85-CE6-217-010 HLDR, LOCK ABCDEFGH............
87-NF8-220-010 DMPR,150 ABCDEFGH............
88-CL4-215-010 CUSH,FOOT FR ABCDEFGH............
88-CL4-216-010 CUSH,FOOT REAR ABCDEFGH............
88-CL4-220-010 SPR-T,CASS ABCDEFGH............
8Z-CL7-201-010 FRAME,BOX-CASS A...................
8Z-CL7-201-110 FRAME,BOX-CASS .BCDEFGH............
8Z-CL7-205-010 HLDR,CD A...................
8Z-CL7-205-110 HLDR,CD .BCDEFGH............
8Z-CL7-213-010 HLDR,TRANS U ....................
8Z-CL7-214-010 HLDR,TRANS LH .B.DEFGH............
8Z-CL7-215-010 HLDR,TRANS HR ..C.................
87-067-703-010 TAPPING SCREW, BVT2+3-10 ABCDEFGH............
87-067-758-010 BVT2+3-12 W/O SLOT .BCDEFGH............
87-571-032-410 VIT+2-3 ABCDEFGH............
* 87-B10-230-010 BVT2+3-10 W/O SLOT SILVER CR ABCDEFGH............
* 87-B10-231-010 QT1+3-12 SILVER CR ABCDEFGH............
* 87-B10-250-010 BVT2+3-12 W/O SLOT CR SILVER .BCDEFGH............
87-050-108-010 AC CORD ASSY,K 3PH ....E...............
87-067-703-010 TAPPING SCREW, BVT2+3-10 ABCDEFGH............
87-A80-092-010 AC CORD ASSY,E BLK SUN FAI .BC..FGH............
87-A80-108-010 AC CORD ASSY,K BLK 3P ...D................
87-A80-110-010 AC CORD ASSY,U SPT-2W A...................
88-905-121-110 FF-CABLE, 5P 120MM A...................
88-905-211-110 FF-CABLE, 5P 1.25 210MM A...................
88-905-251-110 FF-CABLE 5P 1.25 .BCDEFGH............
88-906-171-110 FF-CABLE,6P 1.25 A...................
88-906-261-110 FF-CABLE,6P 1.25 260MM .BCDEFGH............
88-910-261-210 FF-CABLE, 10P 1.25 260MM ABCDEFGH............
C 803 87-A10-207-080 CAP,TCS 0.01-50KBUP050 ...DEFGH............
CN 301 88-CL4-701-010 CONN ASSY,7P RPEH ABCDEFGH............
F 101 87-035-222-010 FUSE, 1AT ....................
F 101 87-035-411-010 FUSE TIA 250V UL A...................
F 101 87-035-454-010 FUSE,1.6A 250V T W/C .BC.................
PT 101 8Z-CL7-642-010 PT,U A...................
PT 101 8Z-CL7-643-010 PT,EZ ...DEFGH............
PT 101 8Z-CL7-644-010 PT,LH .BC.................
W 0 88-905-231-110 FF-CABLE, 5P 1.25 230MM .BCDEFGH............
W 0 8Z-CL7-704-010 FF-CABLE, 16P 1.0 ABCDEFGH............
87-067-579-010 TAPPING SCREW, BVT2+3-8 ABCDEFGH............
W 101 8Z-CL7-652-010 CONN ASSY,8P ZCL7 A...................
W 101 8Z-CL7-652-110 CONN ASSY,8P ZCL7 .BCDEFGH............
ACCESSORIES / PACKAGE LIST - 1/1
NOTE: The characters in the suffix column indicate the part usage.
22LH ...................XX...................................B..................
22HR ...................XX....................................C.................
KANRI
REF.NO PARTS NO. NO. DESCRIPTION SUFFIX
8Z-CL7-901-010 IB,U(ESF) -M A...................
8Z-CL7-901-110 IB,U(ESF) -M ....................
8Z-CL7-902-010 IB,H(ECA)-M22 -M ....................
8Z-CL7-903-010 IB,E(9L)-M34 -M .....FG.............
8Z-CL7-904-010 IB,K(E)-M33 -M ...D................
8Z-CL7-905-010 IB,LH(ESP) -M ....................
8Z-CL7-909-010 IB,H(ECA) -M22-C ..C.................
8Z-CL7-911-010 IB,U(ESF) -C ....................
8Z-CL7-912-010 IB,LH(ESP) -C .B..................
8Z-CL7-913-010 IB,K(E) -M33-C ....E...............
8Z-CL7-914-010 IB,E(9L)- M34/36-C .......H............
87-CL4-762-010 SPKR CER TWEETER .BC.................
87-CL4-764-010 CORD SPKR .BC.................
8Z-CL7-761-010 SPKR, WOOFER .BC.................
86-CT4-036-010 BADGE,AIWA ....................
87-067-758-010 BVT2+3-12 W/O SLOT .BC.................
87-761-097-410 VFT2+3-10 GLD .BC.................
88-CL4-216-010 CUSH,FOOT REAR .BC.................
8Z-CL7-107-010 BADGE,AIWA SILVER .BC.................
SP 0 8Z-CL7-101-010 SPKR,PANEL FR .BC.................
SP 0 8Z-CL7-103-010 SPKR,GRILL FRAME .BC.................
87-006-225-010 AM LOOP ANT NC2 A..D.FG.............
87-043-115-010 ANT,FEEDER FM ABC.................
87-A90-030-010 ANT,LOOP AM-NC C .BC.E..H............
87-A90-118-010 ANT,WIRE FM (Z) ...DEFGH............
87-A91-017-010 PLUG,CONVERSION JT-0476 .BC.................
8Z-CK4-951-010 RC UNIT,RC-ZAT03 A...................
8Z-CK4-952-010 RC UNIT,RC-ZAT04 ...D.FG.............
8Z-CK4-962-010 RC UNIT,RC-ZAT04 (VS) .BC.E..H............
SCHEMATIC DIAGRAM _1 (MAIN 1/2)
SCHEMATIC DIAGRAM _2 (MAIN 2/2)
SCHEMATIC DIAGRAM _3 (FRONT)
SCHEMATIC DIAGRAM _4 (CD)
SCHEMATIC DIAGRAM _5 (PT)
PrintedinSingapore
Tokyo Japan
4
9420025
Table of contents
Other Aiwa Stereo System manuals
