SERVICE MANUAL
DATA
COMPACT DISC
STEREO SYSTEM BASIC TAPE MECHANISM : 2ZM-1 R10NM BASIC CD MECHANISM : TN-CCD1001-902M
XR-MS3 EZ,K
S/M Code No. 09-007-422-6S1
SUPPLEMENT
This Service Manual is the “Supplement” and replaces “Simple Manual”
XR-MS3 (EZ,K), (S/M Code No. 09-004-422-6T2).
This Service Manual is for XR-MS3 (EZBM) Black color.
This Service Manual contains information about the difference between
XR-MS3 (EZBM,KSM) and XR-MS3 (EZ). If requiring the other information,
see Service Manual of XR-MS3 (U,EZ), (S/M Code No. 09-002-422-6R1).
This Service Manual does not include “CD ELECTRICAL SECTION”.
These items will be issued in the next Suplement.
XR-MS3
SYSTEM SPEAKER
EZ : SX-M7
K : SX-MS7
REMOTE
CONTROLLER
EZ : RC-AAT03(B)
K : RC-AAT03
All manuals and user guides at all-guides.com
all-guides.com

– 2 –
<FM tuner section>
Tuning range 87.5 MHz to 108 MHz
Usable sensitivity (IHF) 16.8 dBf
Antenna terminals 75 ohms (unbalanced)
<MW tuner section>
Tuning range 530 Hz to 1710 Hz (10 Hz step)
531 Hz to 1602 Hz (9 Hz step)
Usable sensitivity 350 µV/m
Antenna Loop antenna
<LW tuner section>
Tuning range 144 Hz to 290 Hz
Usable sensitivity 1400 µV/m
Antenna Loop antenna
<Ampli ier section>
Power output Rated : 12 W + 12 W (6 ohms,
T.H.D. 1 %, 1 Hz / DIN 45500)
Reference : 15 W + 15 W (6 ohms,
T.H.D. 10 %, 1 Hz / DIN 45324)
DIN MUSIC POWER
20 W + 20 W
Input VIDEO / AUX:
EZ : 500 mV, K : 600 mV
Outputs SPEAKERS: accept spea ers of 6
ohms or more
PHONES (stereo mini jac ): accepts
headphones of 16 ohms or more
DIGITAL OUT (OPTICAL) jac
<Compact disc player section>
Laser Semiconductor laser (λ = 780 nm)
D-A converter 1 bit dual
Signal-to-noise ratio 85 dB (1 Hz, 0 dB)
Harmonic distortion 0.05 % (1 Hz, 0 dB)
Wow and lutter Unmeasurable
<Cassette deck section>
Track ormat 4 trac s, 2 channels stereo
Frequency response CrO2 tape : 50 Hz – 16000 Hz
Normal tape : 50 Hz – 15000 Hz
Signal-to-noise ratio 60 dB (Dolby B NR ON, CrO2 tape
pea level)
Recording system AC bias
Heads Recording / Playbac head x 1,
erase head x 1
SPECIFICATIONS
<General>
Power requirements 230 V AC, 50 Hz
Power consumption EZ : 57 W
K : 68 W
Standby power consumption EZ : 1.7 W (power-economizing
mode set to ON)
K : 1.8 W (power-economizing
mode set to ON)
Dimensions o main unit 100 x 210.6 x 271.5 mm
(W x H x D) (4 x 83/8 x 103/4 in.)
Weight o main unit 3.8 g (8 lbs 6 oz.)
<Speaker system>
Cabinet type 2 way, bass reflex (magnetic
shielded type)
Speakers Woofer : 85 mm
Tweeter: 22 mm dome type
Impedance 6 ohms
Output sound pressure level 86 dB/W/m
Dimensions 100 x 206 x 188 mm
(W x H x D) (4 x 81/8 x 71/2 in.)
Weight 1.5 g (3 lbs 5 oz.)
• Design and specifications are subject to change without notice.
• The word "BBE"and the "BBE symbol" are trademar s of BBE
Sound, Inc.
Under license from BBE Sound,Inc.
• Dolby noise reduction manufactured under license from Dolby
Laboratories Licensing Corporation.
"DOLBY" and the double-D symbol are trademar s of Dolby
Laboratories Licensing Corporation.
All manuals and user guides at all-guides.com

– 3 –
ELECTRICAL MAIN PARTS LIST
DESCRIPTIONREF. NO. KANRI
NO.
PART NO. KANRI
NO.
REF. NO. DESCRIPTIONPART NO.
IC
8A-CJ5-601-010 C-IC,LC876580W-5N98
87-070-246-010 IC,GP1U271X
87-A20-909-010 IC,LA4663
87-017-915-080 IC,BU4094BCF
87-017-585-080 IC,NJM4580E
87-A20-355-010 IC,CXA1553P
87-A20-783-040 C-IC,BA7762AFS
87-A21-022-040 C-IC,BA3880FS
87-A21-103-040 C-IC,MM1454XFBE
87-A21-111-040 C-IC,M62495FP
87-017-825-010 IC,GP1F32T
87-020-454-010 IC,DN6851
87-070-127-110 IC,LC72131D
87-A20-913-010 IC,LA1837NL
87-A20-440-040 C-IC,BU1920FS<EZ>
TRANSISTOR
89-213-702-010 TR,2SB1370E
87-A30-076-080 C-TR,2SC3052F
87-026-610-080 TR,KTC3198GR
87-A30-075-080 C-TR,2SA1235F
87-A30-234-080 TR,CSC4115BC
89-418-580-080 TR,2SD1858TV2
87-026-245-080 TR,DTC114ES
87-A30-198-080 TR,KTC3199GR
87-026-609-080 TR,KTA1266GR
87-026-210-080 CHIP-TR,DTC144EK
87-A30-087-080 C-FET,2SK2158
87-A30-073-080 C-TR,RT1N 141C
87-026-236-080 C-TR,DTC124EK
87-A30-086-070 C-TR,CSD1306E
87-026-211-080 C-TR,DTA144EK
87-A30-240-080 TR,CSA1585BC
87-A30-159-080 C-TR,KTA1298Y
87-A30-072-080 C-TR,RT1P 144C
87-A30-273-040 C-TR,DTC124EKA
87-A30-202-080 C-TR,RT1P441C
89-505-434-540 C-FET,2SK543(4/5)
87-A30-074-080 C-TR,RT1P 141C
89-327-143-080 C-TR,2SC2714(0.1W)
DIODE
87-020-465-080 DIODE,1SS133
87-A40-224-010 DIODE,GBU8DL
87-A40-313-080 C-DIODE,MC 2840
87-A40-346-080 ZENER,MTZJ 8.2C
87-A40-345-080 ZENER,MTZJ10C
87-070-274-080 DIODE,1N4003 SEM
87-A40-336-080 ZENER,MTZJ27D T-72
87-A40-435-080 ZENER,MTZJ30D
87-A40-270-080 C-DIODE,MC2838
87-A40-004-080 ZENER,MTZJ16A
87-070-136-080 ZENER,MTZJ5.1B
87-A40-509-080 ZENER,MTZJ6.8C
87-A40-269-080 C-DIODE,MC2836
87-A40-235-080 ZENER,MTZJ9.1C
87-A40-293-080 ZENER,DZ2.7M
87-A40-438-080 ZENER,MTZJ4.7A
87-017-149-080 ZENER,HZS6A2L
MAIN C.B
C1 87-010-194-080 CAP, CHIP 0.047
C2 87-010-194-080 CAP, CHIP 0.047
C3 87-010-196-080 CHIP CAPACITOR,0.1-25
C4 87-010-196-080 CHIP CAPACITOR,0.1-25
C5 87-010-196-080 CHIP CAPACITOR,0.1-25
C6 87-010-196-080 CHIP CAPACITOR,0.1-25
C7 87-010-194-080 CAP, CHIP 0.047
C8 87-010-196-080 CHIP CAPACITOR,0.1-25
C9 87-A12-033-090 CAP,E 6800-25 SMG30L
C10 87-010-409-080 CAP,E 220-50 SME
C11 87-010-380-080 CAP, ELECT 47-16V
C13 87-010-408-080 CAP, ELECT 47-50V
C14 87-010-235-080 CAP,E 470-16 SME
C15 87-010-387-080 CAP,E 470-25 SME
C16 87-012-369-080 C-CAP,S 0.047-50F
C17 87-012-369-080 C-CAP,S 0.047-50F
C18 87-A10-776-080 CAP,E 1000-25 M 105 KMG
C19 87-010-403-080 CAP, ELECT 3.3-50V
C30 87-010-112-080 CAP, ELECT 100-16V
C31 87-016-126-080 CAP,E 470-16 M 105 KME
C61 87-010-260-080 CAP, ELECT 47-25V
C62 87-010-496-040 CAP,E 3.3-50 GAS
C91 87-010-401-080 CAP, ELECT 1-50V
C92 87-010-263-080 CAP, ELECT 100-10V
C93 87-010-553-040 CAP,E 47-16 GAS
C101 87-010-754-080 CAP,E220-10 SRA 7L
C102 87-010-754-080 CAP,E220-10 SRA 7L
C103 87-010-196-080 CHIP CAPACITOR,0.1-25
C104 87-010-198-080 CAP, CHIP 0.022
C105 87-010-196-080 CHIP CAPACITOR,0.1-25
C106 87-010-400-040 CAP,E 0.47-50
C108 87-010-313-080 CAP, CHIP 18P
C109 87-012-156-080 C-CAP,S 220P-50 CH
C110 87-010-196-080 CHIP CAPACITOR,0.1-25
C111 87-010-079-040 CAP,E 100-6.3 5L
C112 87-010-194-080 CAP, CHIP 0.047
C114 87-010-194-080 CAP, CHIP 0.047
C115 87-010-405-040 CAP,E 10-50
C116 87-010-196-080 CHIP CAPACITOR,0.1-25
C117 87-010-196-080 CHIP CAPACITOR,0.1-25
C118 87-010-196-080 CHIP CAPACITOR,0.1-25
C129 87-010-316-080 C-CAP,S 33P-50 CH
C130 87-010-178-080 CHIP CAP 1000P
C201 87-010-491-040 CAP,E 0.22-50 GAS
C202 87-010-545-040 CAP,E 0.22-50 SME
C205 87-010-546-040 CAP,E 0.33-50
C206 87-010-546-040 CAP,E 0.33-50
C211 87-010-405-040 CAP,E 10-50
C212 87-010-260-080 CAP, ELECT 47-25V
C215 87-010-405-080 CAP, ELECT 10-50V
C216 87-010-405-080 CAP, ELECT 10-50V
C217 87-012-368-080 C-CAP,S 0.1-50 F
C218 87-012-368-080 C-CAP,S 0.1-50 F
C219 87-012-368-080 C-CAP,S 0.1-50 F
C220 87-012-368-080 C-CAP,S 0.1-50 F
C221 87-010-405-080 CAP, ELECT 10-50V
C223 87-010-196-080 C-CAP,S 0.1-25 ZF
C301 87-010-322-080 C-CAP,S 100P-50 CH
C302 87-010-322-080 C-CAP,S 100P-50 CH
C303 87-016-044-040 CAP,E 100-16 GAS
C304 87-016-044-040 CAP,E 100-16 GAS
C305 87-010-071-040 CAP,E 1-50 M 5L SRE
C306 87-010-071-040 CAP,E 1-50 M 5L SRE
C307 87-010-553-040 CAP,E 47-16 GAS
C308 87-010-555-040 CAP,E 100-10 GAS
C401 87-010-196-080 CHIP CAPACITOR,0.1-25
C402 87-010-260-080 CAP, ELECT 47-25V
C403 87-010-404-080 CAP, ELECT 4.7-50V
C404 87-010-497-080 CAP, ELECT 4.7-35V
C405 87-010-404-080 CAP, ELECT 4.7-50V
C406 87-010-404-080 CAP, ELECT 4.7-50V
C407 87-010-188-080 CAP,CHIP 6800P
C408 87-010-188-080 CAP,CHIP 6800P
C409 87-012-140-080 CAP 470P
C410 87-012-140-080 CAP 470P
All manuals and user guides at all-guides.com

– 4 –
DESCRIPTIONREF. NO. KANRI
NO.
PART NO. KANRI
NO.
REF. NO. DESCRIPTIONPART NO.
C411 87-010-404-080 CAP, ELECT 4.7-50V
C412 87-010-404-080 CAP, ELECT 4.7-50V
C413 87-010-404-080 CAP, ELECT 4.7-50V
C414 87-010-497-080 CAP, ELECT 4.7-35V
C415 87-010-197-080 CAP, CHIP 0.01 DM
C416 87-010-197-080 CAP, CHIP 0.01 DM
C417 87-010-195-080 C-CAP,S 0.068-25 F
C418 87-010-195-080 C-CAP,S 0.068-25 F
C419 87-010-260-080 CAP, ELECT 47-25V
C421 87-012-140-080 CAP 470P
C422 87-012-140-080 CAP 470P
C552 87-010-112-080 CAP, ELECT 100-16V
C553 87-010-260-080 CAP, ELECT 47-25V
C554 87-010-197-080 CAP, CHIP 0.01 DM
C555 87-010-197-080 CAP, CHIP 0.01 DM
C557 87-010-405-080 CAP, ELECT 10-50V
C573 87-010-405-080 CAP, ELECT 10-50V
C574 87-010-405-080 CAP, ELECT 10-50V
C575 87-010-322-080 C-CAP,S 100P-50 CH
C601 87-010-187-080 CAP CHIP S5600P
C602 87-010-187-080 CAP CHIP S5600P
C603 87-012-365-080 C-CAP,S 0.027-25 KB
C604 87-012-365-080 C-CAP,S 0.027-25 KB
C605 87-010-182-080 C-CAP,S 2200P-50 B
C606 87-010-182-080 C-CAP,S 2200P-50 B
C607 87-010-213-080 C-CAP,S 0.015-50 B
C608 87-010-213-080 C-CAP,S 0.015-50 B
C609 87-010-545-080 CAP, ELECT 0.22-50V
C610 87-010-491-080 CAP,E 0.22-50 GAS
C611 87-010-545-080 CAP, ELECT 0.22-50V
C612 87-010-491-080 CAP,E 0.22-50 GAS
C613 87-010-553-080 CAP,E 47-16
C614 87-010-553-080 CAP,E 47-16
C615 87-010-154-080 CAP CHIP 10P
C622 87-010-402-080 CAP, ELECT 2.2-50V
C623 87-010-402-080 CAP, ELECT 2.2-50V
C641 87-010-196-080 CHIP CAPACITOR,0.1-25
C643 87-010-805-080 CAP, S 1-16
C644 87-010-196-080 CHIP CAPACITOR,0.1-25
C661 87-010-175-080 C-CAP,S 560P-50 J SL
C662 87-010-175-080 C-CAP,S 560P-50 J SL
C677 87-018-134-080 CAP,TC U 0.01-16 NY
C702 87-018-209-080 CAP,TU U 0.1-50 ZF
C703 87-010-197-080 CAP, CHIP 0.01 DM
C704 87-010-382-040 CAP,E 22-25 SME
C706 87-010-382-040 CAP,E 22-25 SME
C902 87-012-156-080 C-CAP,S 220P-50 J CH
C903 87-010-322-080 C-CAP,S 100P-50 CH
CN1 87-A60-850-010 CONN,7P V VH
CN91 87-A60-619-010 CONN,2P V 2MM JMT
CN601 87-A60-902-010 CONN,14P V BLK FMN-BTRK
CN701 87-A60-619-010 CONN,2P V 2MM JMT
CN901 87-A60-770-010 CONN,18P B TMC-D(X)
CN902 87-A60-900-010 CONN,9P V BLK FMN-BTRK
CN903 87-A60-189-010 CONN,16P V TUC-P16P-B1<EZ>
CN904 87-099-570-010 CONN,13P TUC-P13P-B1<K>
CN905 87-A61-258-010 CONN,15P V 52806-1510
CNA002 88-805-040-820 CONN ASSY,4P 80
CNA003 88-805-051-420 CONN ASSY,5P 140
CNA201 88-805-043-020 CONN ASSY,4P 300
CNA700 8A-CJ5-634-010 CONN ASSY,2P SHLD
FC905 8A-CL5-632-010 CABLE,FFC15P-1.0 165
J201 87-A60-238-010 TERMINAL,SP 4P (MSC)
J202 87-099-801-010 JACK,PIN 1P BLK
J601 87-A60-881-010 JACK,PIN 2P MSP 242V05 PBSN
JR603 87-A50-190-080 C-COIL,S BLM21A102S
L101 87-A50-333-010 COIL,OSC 9.43MHZ
PR2 87-026-689-080 PROTECTOR,1A 60V 491
PR3 87-A90-195-080 PROTECTOR 7A 125V 49
PR4 87-A90-195-080 PROTECTOR 7A 125V 49
PR5 87-026-689-080 PROTECTOR,1A 60V 491
WH005 87-A90-507-010 HLDR,WIRE 2.5-4P
FRONT C.B
C102 87-010-415-040 CAP,E 10-50 5L
C103 87-012-157-080 C-CAP,S 330P-50 CH
C104 87-010-421-040 CAP,E 4.7-50 5L
C105 87-010-421-040 CAP,E 4.7-50 5L
C106 87-010-408-040 CAP,E 47-50 SME
C107 87-012-369-080 C-CAP,S 0.047-50F
C108 87-010-197-080 CAP, CHIP 0.01 DM
C109 87-010-197-080 CAP, CHIP 0.01 DM
C110 87-010-196-080 CHIP CAPACITOR,0.1-25
C111 87-012-368-080 C-CAP,S 0.1-50 F
C200 87-018-119-080 CAP,TC U 100P-50
C301 87-010-196-080 CHIP CAPACITOR,0.1-25
CN101 87-A60-778-010 CONN,18P B TMC-D(P)
FL101 8A-CL5-608-010 FL,9-ST-19GONK
LED101 87-A40-317-080 LED,SLR-342VCT31 RED
LED301 87-A40-786-080 LED,SMLS1BE16WTP4 BLU/UMB
LED302 87-A40-786-080 LED,SMLS1BE16WTP4 BLU/UMB
LED303 87-A40-786-080 LED,SMLS1BE16WTP4 BLU/UMB
R102 87-022-355-080 C-RES,S10K-1/10W F
R103 87-022-355-080 C-RES,S10K-1/10W F
S102 87-A91-743-010 SW,JOG 3-2-1 RE01311PCE2
S201 87-A90-095-080 SW,TACT EVQ11G04M
S202 87-A90-095-080 SW,TACT EVQ11G04M
S203 87-A90-095-080 SW,TACT EVQ11G04M
S204 87-A90-095-080 SW,TACT EVQ11G04M
S205 87-A90-095-080 SW,TACT EVQ11G04M
S206 87-A90-095-080 SW,TACT EVQ11G04M
S207 87-A90-095-080 SW,TACT EVQ11G04M
S208 87-A90-095-080 SW,TACT EVQ11G04M
S209 87-A90-095-080 SW,TACT EVQ11G04M
S210 87-A90-095-080 SW,TACT EVQ11G04M
S211 87-A90-095-080 SW,TACT EVQ11G04M
S212 87-A90-095-080 SW,TACT EVQ11G04M
S213 87-A90-095-080 SW,TACT EVQ11G04M
S214 87-A90-095-080 SW,TACT EVQ11G04M
S215 87-A90-095-080 SW,TACT EVQ11G04M
S216 87-A90-095-080 SW,TACT EVQ11G04M
TAPE C.B
C303 87-012-157-080 C-CAP,S 330P-50 CH
C304 87-012-157-080 C-CAP,S 330P-50 CH
C307 87-010-196-080 CHIP CAPACITOR,0.1-25
C311 87-010-198-080 CAP, CHIP 0.022
C312 87-010-198-080 CAP, CHIP 0.022
C315 87-012-278-080 CHIP CAP,U 2200P-50B
C316 87-012-278-080 CHIP CAP,U 2200P-50B
C317 87-A10-201-080 C-CAP,S0.33-16 KB
C318 87-A10-201-080 C-CAP,S0.33-16 KB
C319 87-012-141-080 CHIP-CAPACITOR,0.22-16F
C320 87-012-141-080 CHIP-CAPACITOR,0.22-16F
C321 87-A10-025-080 C-CAP,U 0.22-16Z F
C322 87-A10-025-080 C-CAP,U 0.22-16Z F
C324 87-010-260-040 CAP,E 47-25 SME
C325 87-010-370-040 CAP,E 330-6.3 SME
C327 87-010-404-040 CAP,E 4.7-50 SME
C328 87-010-404-040 CAP,E 4.7-50 SME
C332 87-010-196-080 CHIP CAPACITOR,0.1-25
C335 87-010-401-040 CAP,E 1-50 SME
C336 87-010-401-040 CAP,E 1-50 SME
C337 87-010-196-080 CHIP CAPACITOR,0.1-25
C339 87-010-831-080 C-CAP,U,0.1-16F
C340 87-010-196-080 CHIP CAPACITOR,0.1-25
C351 87-012-140-080 CAP 470P
C352 87-012-140-080 CAP 470P
!
!
!
!
All manuals and user guides at all-guides.com

– 5 –
DESCRIPTIONREF. NO. KANRI
NO.
PART NO. KANRI
NO.
REF. NO. DESCRIPTIONPART NO.
C354 87-010-175-080 CAP 560P
C355 87-010-178-080 CHIP CAP 1000P
C356 87-010-260-040 CAP,E 47-25 SME
C357 87-010-197-080 CAP, CHIP 0.01 DM
C358 87-010-183-080 C-CAP,S 2700P-50 B
C359 87-010-183-080 C-CAP,S 2700P-50 B
C360 87-010-183-080 C-CAP,S 2700P-50 B
C370 87-010-196-080 CHIP CAPACITOR,0.1-25
C371 87-010-177-080 C-CAP,S 820P-50 SL
C372 87-010-177-080 C-CAP,S 820P-50 SL
C373 87-010-179-080 CAP,CHIP S B1200P
C374 87-010-179-080 CAP,CHIP S B1200P
C375 87-010-545-040 CAP,E 0.22-50 SME
C376 87-010-545-040 CAP,E 0.22-50 SME
C378 87-010-196-080 CHIP CAPACITOR,0.1-25
C386 87-010-759-080 C-CAP,U, 0.1-25F
C388 87-012-266-080 C-CAP,U 220P-50 B
CN251 87-A60-626-010 CONN,9P V 2MM JMT
CN351 87-A60-625-010 CONN,8P V 2MM JMT
CN601 87-A60-891-080 C-CONN,14P V FMN-BMTTN-TF
CN902 87-A60-888-080 C-CONN,9P V FMN-BMTTN-TF
FC601 8A-CL5-628-010 CABLE,FFC14P-1.0 160
FC902 8A-CL5-627-010 CABLE,FFC9P-1.0 220
L301 87-A50-049-010 COIL,TRAP 85K(COI)
L302 87-A50-049-010 COIL,TRAP 85K(COI)
L351 87-007-342-010 COIL,OSC 85K BIAS
SFR303 87-024-435-080 SFR 33K RH 063EC
SFR304 87-024-435-080 SFR 33K RH 063EC
SFR305 87-A90-433-080 SFR,50K H NVZ6TLTA
SFR306 87-A90-433-080 SFR,50K H NVZ6TLTA
SFR351 87-A90-433-080 SFR,50K H NVZ6TLTA
SFR352 87-A90-433-080 SFR,50K H NVZ6TLTA
VM C.B
C27 87-012-140-080 CAP 470P
C29 87-010-247-080 CAP, ELECT 100-50V
CN3 87-009-033-010 CONNECTOR, 5P
HP-JACK C.B
C201 87-010-194-080 C-CAP,S 0.047-25 ZF<K>
C202 87-010-194-080 C-CAP,S 0.047-25 ZF<K>
CN102 87-A60-668-010 CONN,4P H 2MM JMT
J101 87-A60-420-010 JACK,3.5 ST (MSC)
PT C.B
C1 87-A10-479-080 CAP,CER 2200P-250 M E KH
CN1 87-A60-645-010 CONN,3P V VH
CN2 87-A60-621-010 CONN,4P V 2MM JMT
PT1 8Z-NF8-662-010 PT,SUB ZNF-8(E)<EZ>
PT1 8Z-NF8-659-010 PT,SUB ZNF-8(E)TAM<K>
PT2 8A-CJ5-622-010 PT,ACJ-5 EZ
RY1 87-A90-977-010 RELAY,AC12V DG12D1-O(M)
T1 87-A60-317-010 TERMINAL, 1P MSC
T2 87-A60-317-010 TERMINAL, 1P MSC
TUNER C.B
C701 87-010-381-080 CAP,ELECT 330-16V
C702 87-010-404-080 CAP,ELECT 4.7-50V
C703 87-012-286-080 CAP,U 0.01-25
C704 87-012-286-080 CAP,U 0.01-25
C709 87-012-195-080 C-CAP,U 100P-50CH
C711 87-010-260-080 CAP,ELECT 47-25V
C712 87-010-831-080 C-CAP,U,0.1-16F
C713 87-012-286-080 CAP,U 0.01-25
C714 87-012-286-080 CAP,U 0.01-25
C715 87-012-195-080 C-CAP,U 100P-50CH
C717 87-012-286-080 CAP,U 0.01-25
C719 87-012-286-080 CAP,U 0.01-25
C720 87-012-195-080 C-CAP,U 100P-50CH
C721 87-012-176-080 CAP,15P
C722 87-012-176-080 CAP,15P
C723 87-012-274-080 CHIP CAP,U 1000P-50B
C725 87-018-131-080 CAP,TC U 1000P-50 KB<K>
C727 87-010-196-080 CHIP CAPACITOR,0.1-25
C728 87-010-248-080 CAP,ELECT 220-10V
C729 87-012-274-080 CHIP CAP,U 1000P-50B
C731 87-012-286-080 CAP,U 0.01-25
C733 87-012-280-080 C-CAP,U 3300P-50 KB
C734 87-012-280-080 C-CAP,U 3300P-50 KB
C752 87-012-282-080 C-CAP,U 4700P-50 KB
C753 87-012-195-080 C-CAP,U 100P-50 J CH
C755 87-012-286-080 CAP,U 0.01-25
C756 87-012-286-080 CAP,U 0.01-25
C757 87-012-188-080 C-CAP,U 47P-50 CH
C758 87-012-167-080 C-CAP,U 5P-50 CH
C761 87-010-196-080 C-CAP,S 0.1-25 ZF
C762 87-012-286-080 CAP,U 0.01-25
C763 87-010-829-080 CAP,U 0.047-16
C764 87-012-145-080 C-CAP,S 270P-50 J CH<EZ>
C764 87-012-270-080 C-CAP,U 470P-50 KB<K>
C765 87-012-286-080 CAP,U 0.01-25
C766 87-010-197-080 C-CAP,S 0.01-25 KB
C768 87-012-286-080 CAP,U 0.01-25
C769 87-010-260-080 CAP,ELECT 47-25V
C770 87-010-829-080 CAP,U 0.047-16
C771 87-010-383-080 CAP,ELECT 33-25V
C772 87-010-829-080 CAP,U 0.047-16
C773 87-010-196-080 CHIP CAPACITOR,0.1-25
C774 87-010-263-080 CAP,ELECT 100-10V
C775 87-010-404-080 CAP,ELECT 4.7-50V
C776 87-012-286-080 CAP,U 0.01-25
C777 87-010-493-080 CAP,E 0.47-50 M 5L SRE
C778 87-010-401-080 CAP,ELECT 1-50V
C779 87-010-401-080 CAP,ELECT 1-50V
C780 87-010-196-080 CHIP CAPACITOR,0.1-25
C781 87-010-405-080 CAP,ELECT 10-50V
C782 87-010-405-080 CAP,ELECT 10-50V
C783 87-012-286-080 CAP,U 0.01-25
C784 87-012-286-080 CAP,U 0.01-25
C785 87-010-402-080 CAP,ELECT 2.2-50V
C786 87-010-402-080 CAP,ELECT 2.2-50V
C787 87-012-275-080 C-CAP,U 1200P-50 B
C788 87-012-275-080 C-CAP,U 1200P-50 B
C789 87-012-275-080 C-CAP,U 1200P-50 B
C790 87-012-275-080 C-CAP,U 1200P-50 B
C791 87-010-405-080 CAP,ELECT 10-50V
C793 87-012-273-080 C-CAP,U 820P-50 B
C794 87-010-406-080 CAP,ELECT 22-50
C795 87-010-596-080 CAP,S 0.047-16
C796 87-010-403-080 CAP,ELECT 3.3-50V
C797 87-012-276-080 C-CAP,U 1500P-50 KB
C798 87-012-276-080 C-CAP,U 1500P-50 KB
C799 87-010-829-080 CAP,U 0.047-16
C812 87-012-286-080 CAP,U 0.01-25
C814 87-012-286-080 CAP,U 0.01-25
C820 87-010-260-080 CAP,ELECT 47-25V
C821 87-012-286-080 CAP,U 0.01-25
C822 87-012-286-080 CAP,U 0.01-25
C823 87-012-286-080 CAP,U 0.01-25
C828 87-010-196-080 CHIP CAPACITOR,0.1-25
C829 87-010-196-080 CHIP CAPACITOR,0.1-25
C859 87-012-286-080 C-CAP,U 0.01-25 KB<EZ>
C861 87-012-199-080 C-CAP,U 220P-50 J CH<EZ>
C862 87-012-199-080 C-CAP,U 220P-50 J CH<EZ>
C863 87-012-270-080 C-CAP,U 470P-50 KB<EZ>
C864 87-010-405-080 CAP,E 10-50 M 11L SME<EZ>
!
!
!
!
!
!
!
!
All manuals and user guides at all-guides.com

– 6 –
DESCRIPTIONREF. NO. KANRI
NO.
PART NO. KANRI
NO.
REF. NO. DESCRIPTIONPART NO.
C865 87-010-196-080 C-CAP,S 0.1-25 ZF<EZ>
C866 87-010-405-080 CAP,E 10-50 M 11L SME<EZ>
C867 87-012-286-080 C-CAP,U 0.01-25 KB<EZ>
C868 87-012-184-080 C-CAP,U 33P-50 J CH<EZ>
C869 87-012-180-080 C-CAP,U 22P-50 J CH<EZ>
C940 87-012-286-080 C-CAP,U 0.01-25 KB
C942 87-012-168-080 C-CAP,U 6P-50 D CH<EZ>
C942 87-012-172-080 C-CAP,U 10P-50 D CH<K>
C947 87-012-286-080 C-CAP,U 0.01-25 KB
C949 87-A10-039-080 C-CAP,U 470P-50 J CH
C952 87-012-286-080 C-CAP,U 0.01-25 KB
C958 87-010-197-080 C-CAP,S 0.01-25 KB
C959 87-010-831-080 C-CAP,U 0.1-16 ZF
C960 87-010-196-080 CHIP CAPACITOR,0.1-25
C962 87-010-401-080 CAP,E 1-50 M 11L SME
CF801 87-008-423-010 FLTR,CF SFE10.7MS3G-A
CF802 82-785-747-010 CF,MS2 GHY R
CN701 87-A60-700-010 CONN,13P H GRY TUC-P13X-C1<K>
CN701 87-A60-650-010 CONN,16P H GRY TUC-P16X-C1<EZ>
FFE801 A8-6ZA-191-130 6ZA-1 FEENM
J801 87-033-241-010 TERMINAL,ANT 2P AJ-2039
L771 87-A50-266-010 COIL,FM DET-2N(TOK)
L772 87-A91-110-010 FLTR,PCFJZH-450(TOK)<EZ>
L772 87-A90-733-010 FLTR,PCFAZH-450(TOK)<K>
L781 87-005-847-080 COIL,2.2UH CECS
L791 87-A50-027-010 COIL,1 POLE MPX(TOK)
L792 87-A50-027-010 COIL,1 POLE MPX(TOK)
L832 87-005-847-080 COIL,2.2UH K CECS
L851 87-005-847-080 COIL,2.2UH K CECS<EZ>
L941 87-A50-020-010 COIL,ANT LW(COI)252KHZ
L942 87-A50-019-010 COIL,OSC LW(COI) 856KHZ
L981 8Z-ZA1-665-010 COIL,AM PACK 2(TOK)<EZ>
L981 87-NF4-651-110 COIL,AM PACK 2N(TOM)<K>
TC942 87-011-164-010 TRIMMER,CER 30P 4.5X3.9 VCT31
X721 87-A70-061-010 VIB,XTAL 4.500MHZ CSA-309
X851 87-A70-091-010 VIB,XTAL 4.332MHZ CSA-309<EZ>
DECK C.B
CNA1 82-ZM1-636-010 CONN ASSY,9P
SFR1 87-024-581-010 SFR,3.3K H KVSF637A
SOL2 82-ZM1-634-010 SOL ASSY,23K
SW2 87-036-110-010 SW,MICRO SPPB62
SW3 87-036-110-010 SW,MICRO SPPB62
SW4 87-036-110-010 SW,MICRO SPPB62
SW5 87-036-110-010 SW,MICRO SPPB62
SW6 87-A90-248-010 SW,MICRO ESE11SH2CXQ
W1 82-ZM1-625-010 RBN-CORD,4P-5S
RELAY C.B
CN301 88-NF8-616-010 CONN ASSY,8P RPB
All manuals and user guides at all-guides.com
all-guides.com

WIRING – 1 (MAIN / VM) <1 / 2>
181920212223242526272829303132
A
B
C
D
E
F
G
H
I
J
K
L
M
N
P
Q
R
S
T
U
17 16151413121110987654321
All manuals and user guides at all-guides.com

151413121110987654321
A
B
C
D
E
F
G
H
I
J
K
L
M
N
P
Q
R
S
T
U
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32
WIRING – 1 (MAIN / VM) <2 / 2>
– 8 –
All manuals and user guides at all-guides.com

– 9 –
SCHEMATIC DIAGRAM - 1 (MAIN 1/2 (AMP) / HP-JACK)
All manuals and user guides at all-guides.com

– 10 –
SCHEMATIC DIAGRAM - 2 (MAIN 2/2 (MICON))
All manuals and user guides at all-guides.com

WIRING – 2 (FRONT / HP-JACK)
123456789101112131415
A
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
– 11 –
All manuals and user guides at all-guides.com
all-guides.com

– 12 –
SCHEMATIC DIAGRAM - 3 (FRONT)
All manuals and user guides at all-guides.com

WIRING - 3 (TAPE)
876543211345678
A
B
C
D
E
F
G
H
I
J
K
L
M
N
P
Q
R
S
T
U
2
A
B
C
D
E
F
G
H
I
J
K
L
M
N
P
Q
R
S
T
U
9 10111213141516910111213141516
– 13 –
All manuals and user guides at all-guides.com

– 14 –
SCHEMATIC DIAGRAM - 4 (TAPE / DECK / RELAY)
All manuals and user guides at all-guides.com

– 15 –
SCHEMATIC DIAGRAM - 5 (VM)
All manuals and user guides at all-guides.com

WIRING – 4 (PT)
123456789101112131415
A
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
– 16 –
All manuals and user guides at all-guides.com
all-guides.com

– 17 –
SCHEMATIC DIAGRAM - 6 (PT)
All manuals and user guides at all-guides.com

WIRING – 5 (EZ : TUNER)
123456789101112131415
A
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
– 18 –
All manuals and user guides at all-guides.com

– 19 –
SCHEMATIC DIAGRAM - 7 (EZ : TUNER)
All manuals and user guides at all-guides.com

WIRING – 6 (K : TUNER)
123456789101112131415
A
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
– 20 –
All manuals and user guides at all-guides.com
