Aiwa VX-S135U User manual

BASIC VIDEO MECHANISM : OVD-6
INTEGRATED COLOR TV/STEREO
VIDEO CASSETTE RECORDER
VX-S135
S/M Code No. 09-995-325-1C1
U
SERVICE MANUAL
DATA
CORRECTION
This Service Manual contains information about correction on Service Manual of VX-S135(TYPE:U)
(S/M Code No. 09-995-325-1O1).

920074 Printed in Singapore
2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110-8710, JAPAN TEL:[phone]
2. BASIC ADJUSTMENTS
(VCR SECTION)
ELECTRICAL ADJUSTMENTS
2-3: VCO FREERUN
1.
2.
3.
4.
5.
6.
7.
Place the set with Aging Test for more than 10 minutes.
Receive the UHF. (RF Input)
Disconnect the Antenna while receiving the UHF.
Once turn off the Power and turn on the Power again.
Approxi. 3 seconds later, input the Antenna again.
Connect the digital voltmeter to TP601.
Adjust the L610 until the digital voltmeter is 3.1 ± 0.05V.
