AJAX Gamma User manual

DETECTION TECHNOLOGY USER MANUAL

3
Copyright C 2018 AJAX DETECTION TECHNOLOGY LTD. All Rights Reserved.
No part of this manual, including the products and soware described in it, may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by
any means, except documentation kept by the purchaser for backup purposes, without the express written
permission of AJAX DETECTION TECHNOLOGY LTD. (“AJAX”).
Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless
such repair, modication or alteration is authorized in writing by AJAX: or (2) the serial number of the
product is defaced or missing.
AJAX PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER
EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES FOR
CONDITIONS OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO
EVENT SHALL AJAX, ITS DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY
INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES
FOR LOSS OF PROFITS, LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF
BUSINESS AND THE LIKE), EVEN IF AJAX HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES ARISING FROM ANY DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED
FOR INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT
NOTICE, AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY AJAX. AJAX ASSUMES
NO RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR
IN THIS MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Products and corporate names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies, and are used only for identication explanation and to the
owner’s benet, without intent to infringe.

4
Contents
Safety Information .................................................................5
Where to nd more information ...................................................5
Introduction .......................................................................6
Specication Summary.............................................................7
Package Contents..................................................................8
Overview ......................................................................... 10
Hard Keys......................................................................... 11
Battery Assembly ................................................................. 13
Assembly ......................................................................... 14
Imaging Scanner Assembly ................................................. 15
Gradio Smart Assembly..................................................... 16
Initial setup ....................................................................... 17
User Interface..................................................................... 18
Settings .......................................................................... 19
Language .................................................................. 19
Time and Date ............................................................. 19
Display .................................................................... 20
Sound ..................................................................... 21
Power Mode ............................................................... 22
Storage .................................................................... 23
Bluetooth .................................................................. 24
Info ........................................................................ 25
Security.................................................................... 26
Reset ...................................................................... 27
Quick Settings .................................................................... 28
3D Ground Scan .................................................................. 29

5
Device:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Tablet: .............................................................................35
Tablet Pairing:......................................................................36
Gradio Smart .............................................................................40
Live Scan .................................................................................44
Battery ...................................................................................46
Charging the battery ...............................................................46
Precautions for operating environment .............................................46
Battery charging tips and precautions ..............................................47
Contact Information ......................................................................48
WEEE (Waste Electrical and Electronic Equipment) Statement ..............................50

6
Safety Information
The components included in this package are
prone to damage from electrostatic discharge
[ESD]. Please adhere to the following instructions
to ensure successful device assembly.
Ensure that all components are securely connected. Loose
connections may cause the device to not recognize a
component or fail to start.
Hold the device rmly when assembling or operating.
It is recommended to discharge yourself of static electricity
by touching another metal object before
handling the device.
Store the device in an electrostatic free environment
whenever the device is not in use.
Do not assemble or operate the device before
reading the user manual. This might cause
permanent damage to the components as well as
injury to the user.
If you need help during installation step, please
consult support via phone or Online help-desk.
Always turn o the device before storing the device.
Keep this user manual for future reference.
Keep this device away from humidity.
Make sure that your electrical outlet provides the same
voltage as is indicated on the Charger before connecting to
the electrical outlet.
All cautions and warning on the device and in the user
manual should be noted.
If any of the following situations arises, get the device
checked by service personnel:
Liquid has penetrated into the device.
The device has been exposed to moisture.
The device does not work well or you can not get it work
according to user manual.
The device has been dropped or damaged.
The device has obvious sign of breakage.
Do not leave the device in an environment above
60°C (140°F), it may damage the device.
Where to nd more information
Refer to the following sources for additional information
and for product and software updates.
1. AJAX websites:
The AJAX website provides updated information on AJAX
hardware and software products. Refer to the AJAX contact
information.
2. Optional documentation:
Your product package may include optional
documentation, such as warranty iers, that may have been
added by your dealer. Theses documents are not part of the
standard package.

7
Introduction
Gamma has the latest advanced detection and scanning systems to detect gold, metals and voids.
This device works on a new techniques and modern electronic foundations that oer new concepts
and dimensions in the world of ground imaging devices.
A multi-tasking gamma device that allows users to do geological exploration and surveying in its
wide ranges, with all tools and applications needed to complete the searches successfully.
This device was provided with 5-inch high-resolution colorful screen, it allows you to work with
advanced professional functions and programs to detect underground targets with full control of the
scanning properties and your path exploration journey until you reach the desired target.
This device can be used through 3 dierent detection and exploration systems
1- Gradiosmart system
2- Live Scan
3- 3D Ground Scanner
Thank you for purchasing the AJAX GAMMA detection device.
This quick Start section provides demonstration about how to assemble your device .
Some of the installations also provide video demonstrations. Please link to the URL to watch it with
the web browser on your phone or tablet. You may have even link to the URL by scanning the QR
code.

8
Research Principle Multi-detection systems and functions, contains 3 optional systems
Operating Principle Processing data and digital signals and converting them to visual and audible results
Processor Architecture MIPS 32
Operation processor M4K™ Core
Display Screen TFT Color LCD, 800 x 480 WVGA, 16-bit color depth
Battery 7.4 volts, 3300 mAh
Power Rating 400 mA
Battery Endurance Typical usage time 10 hours*
Power Adapter 240-100 VAC / 15 VDC - EU Plug
Storage 1 GB / it can save to 1000 scans.
Sound High quality sounds, 32 KBIT/S, MP3
Notications Sound and tactile feedback congurable in the settings menu for
Bluetooth 2.4 GHz, sensitivity up to -80dBm.
Languages Multilingual User Interface with support for 8 languages.
Date and Time Real Time Clock could be set manually or Automatically via GPS time.
Login Restriction Congurable PIN.
Dimensions 145x45x24 cm
Overall Dimensions 82x52x20 cm
Package Total Weight 5 kg
Assembly Weight 1 Kg (~2 lbs) as assembled in gure(1.2); 1.7 Kg (~3.75 lbs)as assembled in gure(1.1).
Operating temperature From -10° C to 60° C (14° F - 140° F)
Storage temperature From -10° C to 80° C (14° F - 176° F)
Humidity Could be stored and operated at relative humidity level up to 90%.
AJAX Detection Technology has been working on an innovation in detection eld to expand the
horizons and opportunities for new experience leading to ecient work-ow.
Specication Summary
*- Typical battery endurance is subjected to battery life degradation and environmental factors.

9
Package Contents
1
12
2
3
4
6
10
11
5
8
9
7

10
1Main Unit
2Imaging Scanner
3Gradio Smart Sensor
4Battery Pack
5Carrying Pole
6Extension Pole
7Device Clamp
8Clamp Bolt x2
9Clamp Nut x2
10 Bolt
11 Nut
12 Headphones
Check your device package for the following items:
Package Contents
• The items supplied with the device and any available accessories may vary depending on the
region or service provider.
• The supplied items are designed only for this device and may not be compatible with other
devices.
• Appearances and specications are subject to change without prior notice.
• You can purchase additional accessories from your local AJAX retailer. Make sure they are
compatible with the device before purchase.
• Use only AJAX-approved accessories. Using unapproved accessories may cause the
performance problems and malfunctions that are not covered by the warranty.
• Availability of all accessories is subject to change depending entirely on manufacturing
companies. For more information about available accessories, go to the AJAX website.

11
Overview
Headphone Jack
Charge Port
Main Unit
Control Buttons
Display Screen

12
Hard Keys
Power Key
Back
Navigation Arrows
OK
Quick Settings
Grip

13
Hard Keys
Key Function
Power • Press and hold to turn the device on or o.
• Press to turn on or lock the screen.
OK • Conrm/enter the selected option.
Back • Go to previous menu, cancel.
Navigation Keys • Navigation through the device interface.
Quick Settings • Press to drop the quick settings menu.
Grip Key • Multi-purposed key for ease of access while
searching.
Turning the device on and o
Press and hold the Power key for a few seconds to turn on the device.
When you turn on your device for the rst time or after performing a data reset,
follow the on-screen
Instructions to set up your device.
To turn o the device, press and hold the Power key, and then tap Power o.
Follow all posted warnings and directions from authorized personnel in areas
where
The use of wireless devices is restricted, such as airplanes and hospitals.

14
Battery Assembly
1
2
DETECTION TECHNOLOGY
34
1- Press rmly at the ridges and push
outwards to remove the battery cover.
2- Insert the battery pack inside the
compartment.
3- Connect the wires and make sure
they are securely attached.
4- Insert the connector inside the
compartment and put the cover back
on the grip.
gure 1 -Battery Assembly

15
1
9
8
5
6
3
2
4
10 7
11
Assembly
gure 2 -Imaging Scanner Assembly

16
Imaging Scanner Assembly
1- Align the clamp with the holes on the pole.
2- Insert the screws into the clamp.
3- Put the Main Unit inside the clamp.
4- Put the nuts on the screws and tighten them.
5- Unlatch the pole lock.
6- Insert the second pole and adjust the length.
7- Lock the latch back in securely.
8- Align the Imaging Scanner with the second pole tip.
9- Insert the screw.
10- Adjust the Imaging Scanner angle and tighten the nut.
11- Wrap the cable around the second pole and insert the connection module in the front
of the Main Unit.
Assembly

17
Assembly
gure 3 -Gradio Smart Assembly
1
2Gradio Smart Assembly
1- Align the notches in front of the
device with the back of the Gradio
Smart Module.
2- Press rmly until the Module is
secured back into the device.

18
Initial setup
When you turn on your device for the rst time
or after performing a data reset, follow the on-
screen instructions to set up your device.
• The initial setup procedures may vary
depending on the device’s software and your
region.
1Turn on the device.
Press and hold to turn the device on
2Select a language.
Select your preferred device language and
select B.
3Set Time and Date.
Press HIto move, and Jto change values.
After setting the parameters the Main Menu will
show on the display.
Note:
The time format is 24h (hh:mm) e.g. 19:42
The date format is day/month/year (DD/MM/yyyy) e.g. 30/03/2018.
Deutsch
English
Español
Français
Türkçe
Italiano

19
User Interface
Battery Indicator
Bluetooth Indicator
Volume
Time
Settings Icon
Search Systems

20
Deutsch
English
Español
Français
Türkçe
Italiano
Settings
Language
The device supports 8 dierent languages for
the interface (English, French, German, Spanish,
Italian, Russian, Turkish and Arabic)
Select language and press Bto set the
language to the device.
Time and Date
Press HIto move, and Jto change values.
Note:
The time format is 24h (hh:mm) e.g. 19:42
The date format is day/month/year (DD/MM/yyyy) e.g. 30/03/2019.
