AJAX SpaceControl User manual

Ajax SpaceControl User manual
Updated July 6, 2023
Ajax SpaceControl is a miniature key fob with accidental click protection. It
allows setting the Ajax system in the armed, night or disarmed mode and
switching on an alarm.
As it is the two-way communication, you will know whether the system has
received the Ajax SpaceControl command.
Operating as part of the Ajax system, the key fob is connected to the via the
protected protocol. In addition, the key fob can be used to control any
third-party security central unit through the or
integration module.
The key fob is set up through the iOS and Android-based
.
Functional elements
hub
Jeweller
uartBridge ocBridge Plus
mobile app for
smartphones
Buy key fob Ajax SpaceControl
Chat With This Website
Summarize
We value your privacy
We use cookies to enhance your browsing experience, serve personalized ads or content, and analyze our trac. By
clicking "Accept All", you consent to our use of cookies.Cookie Policy
Reject All Accept AllCustomize

Buttons can be assigned when using a key fob with hub and Ajax uartBridge. At the
moment, the feature of modication of commands (and deactivation) of the key fob
buttons when using with the Ajax hub is not available.
Using the key fob
1. System arming button
2. System disarming button
3. Night mode button
4. Panic button (activates the alarm)
5. Light indicators
6. The hole for attaching the key fob
00:00
00:12
We value your privacy
We use cookies to enhance your browsing experience, serve personalized ads or content, and analyze our trac. By
clicking "Accept All", you consent to our use of cookies.Cookie Policy

Maximum connection distance between the key fob and the hub — 1,300
meters. This distance is reduced by walls, inserted oors and any objects
hindering the signal transmission.
Ajax SpaceControl operates only with one security system (Ajaх or third-party
via the integration module). If you connect the key fob to a new security system,
it will cease to interact with the previous system. However, the key fob will not
be automatically deleted from the list of devices of the hub.
The key fob can:
To turn off the actuated security system (siren), press the disarming mode
button on the keyf ob.
Accidental click protection is available on the Ajax SpaceControl with rmware version
5.54.1.0 and higher.
Operational Indication
The key fob reports its status only after any button is pressed.
Type and color of indication of the key fob display depends on the rmware
version of the device. You can nd out the rmware version in the Ajax
application →Devices → key fob. Information about the rmware version is
displayed at the very bottom.
Indication Event
4 green key fob LEDs ashes 6 times The key fob is not registered with any security
system
Arm the system — press the button once
Turn on the night mode — press the button once
Disarm the system — press the button once
Switch on an alarm — press the button once
We value your privacy
We use cookies to enhance your browsing experience, serve personalized ads or content, and analyze our trac. By
clicking "Accept All", you consent to our use of cookies.Cookie Policy

2 green LED next to the pressed button lights up
once
The key fob command has been sent over to the
security system
Firmware version 3.16 and lower
The LED next to the pressed button quickly
ashes green 4 times
Firmware version 3.18 and higher
The central LED lights up red briey
The command has not been delivered as the
security system is too far away and cannot
receive the command
2 LED next to the button lights up green twice.
Then 4 key fob LED ashes green 6 times
The key fob has been removed from the security
system devices
The central LED lights up green for a few
seconds Linking a key fob to the security system
Firmware version 3.18 and higher
The central LED lights up green for
approximately half a second
The system has executed the key fob command
Firmware version 3.18 and higher
The central LED lights up red for approximately
half a second
The system has not executed the key fob
command — integrity verication is enabled in
the system and one of the devices is faulty
Firmware version 3.16 and lower
After the main indication, the central LED lights
up green once and gradually goes out
Firmware version 3.18 and higher
After the main indication, the central LED lights
up red once and goes out gradually
The key fob battery needs replacement. In this
case, the key fob commands are delivered to
the security system.
Firmware version 3.16 and lower
Continuous short LED ashes of green light
Firmware version from 3.18 to 3.52
Continuous short LED ashes of red light
Key fobs with rmware version 3.53 and
latestdo not function when the battery charge
The battery charge level is unacceptably low.
The battery requires replacement.
In this operation mode, the key fob commands
are not delivered to the security system.
What is system integrity check?
Battery replacement
Battery replacement
We value your privacy
We use cookies to enhance your browsing experience, serve personalized ads or content, and analyze our trac. By
clicking "Accept All", you consent to our use of cookies.Cookie Policy

level is unacceptably low, do not communicate
commands to the hub, and do not notify with
LED indication
Connecting the key fob to the Ajax System
Connection to hub
Before starting connection:
Only users with administrative privileges can add the device to the hub.
How to connect key fob to hub:
1. Following the hub instruction recommendations, install the
on your smartphone. Create an account, add the hub to the application, and
create at least one room.
Ajax application
2. Go to the Ajax application.
3. Switch on the hub and check the internet connection (via Ethernet cable
and/or GSM network).
4. Ensure that the hub is disarmed and does not start updates by checking its
status in the mobile application.
1. Select theAdd Deviceoption in the Ajax application.
2. Name the device, scan/write manually the QR Code (located inside the body,
on the battery xture and packaging), and select the location room.
3. SelectAdd— the countdown will begin.
4. Simultaneously press the button for armed mode and the panic button
— the key fob will blink with the central LED. For the detection and
We value your privacy
We use cookies to enhance your browsing experience, serve personalized ads or content, and analyze our trac. By
clicking "Accept All", you consent to our use of cookies.Cookie Policy

The key fob connected to the hub will appear in the list of devices of the hub in
the application.
Connecting the key fob to Third-Party Security Systems
To connect the key fob to a third-party security central unit using the
or integration module, follow the
recommendations in the manual of the respective device.
States
Parameter Value
Battery Charge
Battery level of the device. Two states available:
Accidental Press Protection Indicates the method of protection against
accidental clicks:
interfacing to occur, the key fob should be located within the coverage area
of the wireless network of the hub (at a single protected object).
Ajax
uartBridge Ajax ocBridge Plus
1. Devices
2. Ajax SpaceControl
ОК
Battery discharged
How battery charge is displayed in
Ajax apps
Off
Long press
Double click
We value your privacy
We use cookies to enhance your browsing experience, serve personalized ads or content, and analyze our trac. By
clicking "Accept All", you consent to our use of cookies.Cookie Policy

The function is available on key fobs with
rmware version 5.54.1.0 and higher
The status of the connection with the ReX range
extender
Displayed if the key fob is working through a
Panic Panic button status
Permanent Deactivation Displays the device’s status: active or
completely disabled by the user
Firmware Firmware version of the key fob. It is not
possible to change the rmware
Device ID Device identier
Setting Up the key fob
Setting Value
Name Device name, can be edited
Room Selecting the virtual room to which the device is
assigned
Group Management
Selection of a security group that the key fob
manages. You can select All groups or a single
group.
👆 Conguration is available only after group
mode activation
User Selection key fob user.
Key fob is unassigned:
radio signal range extender
1. Devices
2. Ajax SpaceControl
3. Settings
Key fob events are sent to Ajax apps under
the key fob name.
We value your privacy
We use cookies to enhance your browsing experience, serve personalized ads or content, and analyze our trac. By
clicking "Accept All", you consent to our use of cookies.Cookie Policy

Key fob is assigned to user:
Panic Turning on/off the panic button
Accidental Press Protection
Choosing the method of protection against
accidental clicks:
The function is available on key fobs with
rmware version 5.54.1.0 and higher
Alert with a siren if panic button is pressed
If the toggle is enabled, pressing a panic button
activates connected to the
system. Ajax SpaceControl activates all sirens,
regardless of the groups they are in.
User Guide Opens the device User manual
Permanent Deactivation
Allows a user to deactivate the device without
deleting it from the system. Once deactivated,
the device will no longer execute system
commands and participate in automation
scenarios. Additionally, the panic button of a
deactivated device will be disabled.
Security mode management rights are
determined by key fob settings.
Key fob events are sent to Ajax apps under
the user’s name.
The key fob has the same security mode
management rights as the user.
Off — protection is turned off
Long press — in order for the key fob to
transmit the command to the hub, you need
to press and hold the button for more than
1.5 seconds
Double press — in order for the key fob to
transmit the command to the hub, you need
to double-press the button with a pause of
no more than 0.5 seconds between the
presses
Ajax sirens
Learn more
We value your privacy
We use cookies to enhance your browsing experience, serve personalized ads or content, and analyze our trac. By
clicking "Accept All", you consent to our use of cookies.Cookie Policy

Unpair Device Disconnects the device from the hub and
deletes its settings
Key fob maintenance and battery replacement
When cleaning the key fob body, use any means suitable for equipment
maintenance.
Do not use for cleaning Ajax SpaceControl any substances containing alcohol,
acetone, gasoline, and other active solvents.
The pre-installed battery provides up to 5 years of operation of the key fob
during normal use (one arming and disarming of the security system per day).
More frequent use can reduce battery life. You can check battery level at any
time in the Ajax app.
Keep new and used batteries away from children. Do not ingest battery, Chemical Burn
Hazard.
The pre-installed battery is sensitive to low temperatures and if the key fob is
signicantly cooled, the battery level indicator in the app may show incorrect
values until the key fob gets warm.
The value of the battery level is not updated regularly, but only after pressing one of the
buttons at the key fob.
When the battery is discharged, the user will receive a notication in the Ajax
app, and the key fob LED will slowly light up and go out red each time the button
is pressed (key fobs with rmware version 3.16 and lower light up green).
How long Ajax devices operate on batteries, and what affects this
Battery replacement
We value your privacy
We use cookies to enhance your browsing experience, serve personalized ads or content, and analyze our trac. By
clicking "Accept All", you consent to our use of cookies.Cookie Policy

Tech Specs
Number of buttons 4
Panic button Yes
Accidental click protection
Available with the rmware version 5.54.1.0 and
higher. Manufacture date from March 19, 2020
Radio communication protocol
Jeweller
Radio frequency band
866.0 – 866.5 MHz
868.0 – 868.6 MHz
868.7 – 869.2 MHz
905.0 – 926.5 MHz
915.85 – 926.5 MHz
921.0 – 922.0 MHz
Depends on the region of sale.
Compatibility
Operates with all Ajax ,
, ,
Effective radiated power 6.01 dBm / 3.99 mW (limit 20 mW)
Modulation of the radiosignal GFSK
Radio signal range Up to 1,300 m (any obstacles absent)
Power supply 1 battery CR2032A, 3 V
Service life from the battery Up to 5 years (depending on the usage
frequency)
Operating temperature range From -25°С to +50°С
Operating humidity Up to 95%
Overall dimensions 65 × 37 × 10 mm
Weight 13 g
Service life 10 years
How to nd out the manufacture
date of a detector or device
Learn more
hubs radio signal
range extenders ocBridge Plus
uartBridge
We value your privacy
We use cookies to enhance your browsing experience, serve personalized ads or content, and analyze our trac. By
clicking "Accept All", you consent to our use of cookies.Cookie Policy

Certication
Security Grade 2, Environmental Class III in
conformity with the requirements of EN 50131-
1, EN 50131-3, EN 50131-5-3
Complete Set
Warranty
Warranty for the Limited Liability Company “Ajax Systems Manufacturing”
products is valid for 2 years after the purchase and does not apply to the pre-
installed battery.
If the device does not work correctly, you should rst contact the support
service — in half of the cases, technical issues can be solved remotely!
Technical support:
Compliance with standards
1. Ajax SpaceControl
2. Battery CR2032 (pre-installed)
3. Quick start guide
The full text of the warranty
User Agreement
suppor[email protected]
We value your privacy
We use cookies to enhance your browsing experience, serve personalized ads or content, and analyze our trac. By
clicking "Accept All", you consent to our use of cookies.Cookie Policy

Subscribe to the newsletter about safe life. No spam
Subscribe
Email
We value your privacy
We use cookies to enhance your browsing experience, serve personalized ads or content, and analyze our trac. By
clicking "Accept All", you consent to our use of cookies.Cookie Policy
