INSTRUCTION MANUAL
ACTIVE NOISE ISOLATING HEADPHONE
MODEL: A58050

2
We declare that this product conforms to the following product legislation in accordance
with the following directive(s):
2014/30/EU Electromagnetic Compatibility Directive.
2014/35/EU Low Voltage Directive.
2011/65/EU Restriction of Hazardous Substances Directive.
2014/53/EU Radio Equipment Directive.
RK Wholesale LTD Quality Assurance.
DECLARATION OF CONFORMITY
TECHNICAL DATA
GUARANTEE
This product is guaranteed for 12 months
from the date of the original purchase.
If any defect arises due to faulty materials
or workmanship, the faulty product must
be returned to the place of purchase.
Refund or replacement is at the discretion
of the retailer.
The following conditions apply:
The product must be returned to the
retailer with the proof of purchase.
The product must be installed and used
in accordance with the instructions
contained in this instruction guide.
This item is for domestic purposes only.
This guarantee does not cover wear and
tear, damage, misuse or consumable
parts.
PFD has limited responsibility for
incidental or consequential loss or
damage.
Valid in the UK and Eire only.
MODEL NO: A58050
INPUT: 5V
OUTPUT: 3.7V

3
IMPORTANT INFORMATION - RETAIN FOR FUTURE USE
SAFETY INFORMATION
Important safety instructions – read carefully before use.
It is important that this instruction manual should be retained with the
appliance for future reference. These warnings have been provided in
the interest of safety. You MUST read them carefully before installation
or use.
WARNING
• Check that the voltage of the
main circuit corresponds
with the rating of the
appliance before operating.
• Please ensure that the
appliance is used on a stable,
level, and heat resistant
surface.
• DO NOT immerse cords,
plugs or any part of the
appliance in water or any
other liquid.
• DO NOT leave the appliance
unattended while it is
operating.
• Close supervision is
necessary when any
appliance is used by or near
children or pets.
• This appliance can be used
by children aged from 8 years
and above and persons with
reduced physical, sensory
or mental capabilities or
lack of experience and
knowledge if they have
been given supervision or
instruction concerning use of
the appliance in a safe way
and understand the hazards
involved.
• Children shall not play with
the appliance.
• Cleaning and user
maintenance shall not be
made by children without
supervision.
• Switch off at the wall socket
then remove the plug from
the socket when not in use or
before cleaning.
• If the supply cord or
appliance is damaged,
stop using the appliance
immediately and seek advice
from the manufacturer or its
service agent or a similarly
qualified person.
• DO NOT let the cord hang
over the edge of a table
or counter or let it come
into contact with any hot
surfaces.
• The use of accessory
attachments is not
recommended by the
appliance manufacturer,
apart from those supplied
with this product.
• DO NOT pull the plug out by
the cord as this may damage
the plug and/or the cable.

4
IMPORTANT INFORMATION - RETAIN FOR FUTURE USE
• DO NOT use this product
for anything other than its
intended use.
• This appliance is for
household use only.
• DO NOT carry the appliance
by the power cord.
• DO NOT place anything
containing liquid on top of the
unit.
• DO NOT spill liquid onto the
appliance. If this happens,
mop up the liquid and seek
advice from a qualified
technician.
• DO NOT use next to a
swimming pool.
• DO NOT put objects into any
of the openings.
• Keep the unit free from dust,
lint, etc.
• DO NOT install near any heat
sources such as radiators,
heat registers, stoves, or
other apparatus (including
amplifiers) that produce
heat.
• Only use attachments/
accessories specified by the
manufacturer.
• Unplug this apparatus during
lightning storms or when
unused for long periods of
time.
• Please ensure that the
appliance has adequate
ventilation
• Battery shall not be exposed
to excessive heat such as
sunshine, fire or the like.
• DO NOT play music at
excessive level especially
near children.
• In the unlikely event the
appliance develops a fault,
stop using
it immediately and seek
advice from the Customer
Support Team:
[phone]

5
PACKAGE CONTENTS
FEATURES AND CONTROLS
INSTRUCTION MANUAL
HEADPHONES
USB CABLE
AUDIO CABLE
PLANE ADAPTOR
TRAVEL POUCH
1. Micro USB Charging Socket
2. LED Light
3. Audio Jack (3.5mm)
4. ON/OFF
IN-LINE MICROPHONE
5. VOLUME
6. MIC
7. ON/OFF
1 2 3 4 5 6 7

6
USING YOUR APPLIANCE
BEFORE FIRST USE
1. Remove the product from the box.
2. Remove any packaging from the
product.
3. Please retain all packaging until you
have checked and counted all the
parts and the contents against the
parts list.
4. Your appliance is now ready for
normal use.
CHARGING YOUR HEADPHONES
For best results, fully charge the unit
before use.
Connect one end of the included USB
cable into your computer (or a device
made for USB charging), and the other
end into the headphone’s charging port,
which is under the left ear cap.
1. The LED light will turn red while
charging.
2. It will take about 2 hours if charging
on an empty battery.
3. The LED light will turn off once it’s
finished charging.
4. Unplug the USB cable from the
headphone and charging device.
5. A fully charged battery can last up to
16 hours of use (talking/listening to
audio).
Note: Your earphones cannot be used
while charging.
Note: When the battery is low the LED
Light will flash red.
POWERING ON/OFF & NOISE CANCELLATION
1. Press the ON/OFF button to turn the
headphones on, and the LED light will
turn green to show it’s powered on.
2. Press the ON/OFF button again to
turn the appliance off. The LED light
will turn off.
3. Noise Cancellation: This feature
activates when the headphones are
turned ON via the ON/OFF switch, and
turns OFF when ON/OFF button is
pressed again.
PLAYING MUSIC
1. To listen to music, connect one end of
the audio cable into the audio jack of
your music device.
2. Plug the other end into the
headphone’s audio jack.
3. Press the ON/OFF button to turn the
headphones on.
4. Control playback and volume on the
in-line remote.
5. Turn the headphones off when
finished using them.
Note: When using on a plane, please use a
2-pin Plane adaptor.
DO’S AND DON’TS
• Do not play music at excessive
levels as damage to hearing and/or
equipment may result.
• Do not use in wet or in damp
surroundings.
• Do not play music at excessive level
especially near children.

7
TROUBLESHOOTING THE APPLIANCE
PROBLEM POSSIBLE SOLOUTION
The headphones won’t
charge.
Make sure the USB cable is securely plugged into the headphone
USB port and the USB port of a charging device.
If not, try a different USB charging cable to see if the fault lies
with the included USB cable.
How will I know when
my headphones are
charging?
The LED Light on the headphones will turn red to indicate it is
charging.
There is no sound. Make sure the audio cable is securely plugged into the
headphones and your music device.
If so, check to see if the volume is turned up on your device, and
use the controls to begin playback.
CLEANING AND CARE
IMPORTANT:
1. Clean the appliance with a soft, damp
cloth. Never use chemicals or hard
abrasives.
2. Keep this unit away from wet or damp
surroundings.
3. Store the headphones in a cool, dry
place.
4. The crossed out wheelie bin symbol
on this item indicates that this
product needs to be disposed of
in an environmentally friendly way
when it becomes of no further use
or has worn out. Contact your local
authorities for details of where to take
the item for re-cycling.

8
RECYCLING
DISPOSAL OF THE UNIT
Appliances bearing the symbol shown here may not be disposed of in domestic rubbish.
You are required to dispose of old electrical and electronic appliances like this
separately.
Please visit www.recycle-more.co.uk or www.recyclenow.co.uk for access to information
about the recycling of electrical items.
Please visit www.weeeireland.ie for access to information about the recycling of
electrical items purchased in Ireland.
The WEEE directive, introduced in August 2006, states that all electrical items
must be recycled, rather than taken to landfill.
Please arrange to take this appliance to your local Civic Amenity site for
recycling, once it has reached the end of its life.

9
NOTES

10
NOTES

11

*REGISTER YOUR PRODUCT ONLINE AT WWW.AKAIONLINE.CO
AND ENJOY 3 YEARS PEACE OF MIND
AKAI CUSTOMER SUPPORT TEAM
[phone]
Need help?
For advice, spares and returns.
Call:[phone]
8.30am to 6.00pm Monday-Friday
Visit: www.akaionline.co
Distributed throughout the UK by RK Wholesale LTD
0218.V2
