INSTRUCTION MANUAL
ON EAR HEADPHONES WITH WIRELESS
BLUETOOTH CONNECTIVITY
MODEL: A58078

2
We declare that this product conforms to the following product legislation in accordance
with the following directive(s):
2014/30/EU Electromagnetic Compatibility Directive.
2014/35/EU Low Voltage Directive.
2011/65/EU Restriction of Hazardous Substances Directive.
2014/53/EU Radio Equipment Directive.
RK Wholesale LTD Quality Assurance.
DECLARATION OF CONFORMITY
TECHNICAL DATA
GUARANTEE
This product is guaranteed for 12 months
from the date of the original purchase.
If any defect arises due to faulty materials
or workmanship, the faulty product must
be returned to the place of purchase.
Refund or replacement is at the discretion
of the retailer.
The following conditions apply:
The product must be returned to the
retailer with the proof of purchase.
The product must be installed and used
in accordance with the instructions
contained in this instruction guide.
This item is for domestic purposes only.
This guarantee does not cover wear and
tear, damage, misuse or consumable
parts.
RK Wolesale Ltd has limited responsibility
for incidental or consequential loss or
damage.
Valid in the UK and Eire only.
MODEL NO: A58078
POWER SUPPLY CHARGE VOLTAGE: DC 5V (USB)
BATTERY: 3.7V 300MAH
CHARGING TIME: 2-3HOURS
PLAY TIME (HEADPHONE MODE): 4-6 HOURS,
FM RANGE: 87.5-1080MHZ

3
IMPORTANT INFORMATION - RETAIN FOR FUTURE USE
SAFETY INFORMATION
Important safety instructions – read carefully before use.
It is important that this instruction manual should be retained with the
appliance for future reference. These warnings have been provided in
the interest of safety. You MUST read them carefully before installation
or use.
WARNING
• Check that the voltage of the
main circuit corresponds
with the rating of the
appliance before operating.
• Please ensure that the
appliance is used on a stable,
level, and heat resistant
surface.
• DO NOT immerse cords,
plugs or any part of the
appliance in water or any
other liquid.
• Close supervision is
necessary when any
appliance is used by or near
children or pets.
• This appliance can be used
by children aged from 8 years
and above and persons with
reduced physical, sensory
or mental capabilities or
lack of experience and
knowledge if they have
been given supervision or
instruction concerning use of
the appliance in a safe way
and understand the hazards
involved.
• Children shall not play with
the appliance.
• Cleaning and user
maintenance shall not be
made by children without
supervision.
• Switch off at the wall socket
then remove the plug from
the socket when not in use or
before cleaning.
• If the supply cord or
appliance is damaged,
stop using the appliance
immediately and seek advice
from the manufacturer or its
service agent or a similarly
qualified person.
• DO NOT let the cord hang
over the edge of a table
or counter or let it come
into contact with any hot
surfaces.
• The use of accessory
attachments is not
recommended by the
appliance manufacturer
apart from those supplied
with this product. DO NOT
use extension cords with the
appliance.
• DO NOT pull the plug out by
the cord as this may damage
the plug and/or the cable.

4
IMPORTANT INFORMATION - RETAIN FOR FUTURE USE
• DO NOT use this product
for anything other than its
intended use.
• DO NOT carry the appliance
by the power cord.
• DO NOT place anything
containing liquid on top of the
unit.
• DO NOT spill liquid onto the
appliance. If this happens,
mop up the liquid and seek
advice from a qualified
technician.
• DO NOT use next to a
swimming pool.
• DO NOT put objects into any
of the openings.
• Keep the unit free from dust,
lint, etc.
• DO NOT install near any heat
sources such as radiators,
heat registers, stoves, or
other apparatus (including
amplifiers) that produce
heat.
• Only use attachments/
accessories specified by the
manufacturer.
• Unplug this apparatus during
lightning storms or when
unused for long periods of
time.
• Please ensure that the
appliance has adequate
ventilation
• Battery shall not be exposed
to excessive heat such as
sunshine, fire or the like.
• DO NOT play music at
excessive level especially
near children.
• In the unlikely event the
appliance develops a fault,
stop using
it immediately and seek
advice from the Customer
Support Team:
[phone]

5
PACKAGE CONTENTS
FEATURES AND CONTROLS
INSTRUCTION MANUAL
HEADPHONES
AUX CABLE
USB CHARGING CABLE
1. POWER ON/OFF/PAUSE/PLAY
2. VOLUME +/NEXT SONG
3. VOLUME -/PREVIOUS SONG
4. CALL ACCEPT/CANCEL/REJECT/
MODE-FM
5. LED LIGHT
6. AUDIO INPUT/LINE IN PORT
7. MICRO USB PORT
8. TF CARD SLOT
5 6 7
8
1
2
3
4

6
USING YOUR APPLIANCE
BEFORE FIRST USE
1. Remove the product from the box.
2. Remove any packaging from the
product.
3. Please retain all packaging until you
have checked and counted all the
parts and the contents against the
parts list.
4. Your appliance is now ready for
normal use.
CHARGING YOUR HEADPHONES
For best results, fully charge the unit
before use.
1. Connect one end of the included USB
cable into your computer or sound
device, and the other end into the
charging port of the earphones.
2. The red indicator light will turn on
when charging.
3. It takes approximately two to three
hours for the earphones to charge
fully.
4. The red indicator will go out once the
earphones are fully charged.
5. When the headphones are running
out of battery an alarm will sound.
The headphones with then turn off
automatically after 3-5 minutes.
Note: Your earphones cannot be used
while charging.
POWERING ON/OFF & BLUETOOTH
1. Press the Play/Pause/Power On/Off
button for about 4 seconds, until the
red and blue indicator lights start
flashing alternately.
2. Turn on the Bluetooth function on
your smartphone.
3. Search for Bluetooth devices and
select ‘A58078’.
4. Enter the code ‘0000’ if needed.
5. If pairing is successful, the blue
indicator light will start flashing.
Note: Your Bluetooth Headphones need to
be paired with your smartphone for your
first use. After this, the headphones will
connect to your smartphone automatically
when they are switched on.
If you have an incoming call, any music
you are listening to will pause, allowing
you to answer the call. Your music will
continue once the call is ended.
ANSWERING A CALL
IPHONE/SAMSUNG/HTC/SONY ETC.
Pick up via Headset
1. When a call comes in, quick press the
Mode/Phone button once to answer.
Press the Mode/Phone button again
to end the call.
Pick up via Phone
1. To answer the call through your
smartphone, simply press the answer
button when the call is incoming.
ENDING A CALL
1. You can end the call via your phone
or by quick pressing the Mode/Phone
button on your headset once more.
REJECTING A CALL
1. Hold the Mode/Phone button for 2
seconds and then release.

7
LISTENING TO MUSIC
Once the headset is paired with your
device you can stream music wirelessly
through the headphone. Should you
encounter any problems while streaming
please refer your device’s user manual for
further information.
PLAYING MUSIC
When you listen to music, you can press
the Play/Pause, Skip Backward and Skip
Forward buttons to select the music you
want to listen to and control the volume.
• Skip Forward: Short press the Skip
Forward Button.
• Skip Backward: Short press the Skip
Backward button.
• + Volume: Long press the Skip
Forward button.
• - Volume: Long Press the Skip
Backward button.
FM MODE
1. Short Press the Mode/phone button
once to enter the FM mode, then
press the play/pause button to scan
and memorize the FM radio stations.
2. Press back forward and skip forward
button once to select the desired
channels. Press and hold the (+) or (-)
button to adjust the volume.
3. When the volume reaches its max
level an alarm (beep) will sound.
Always be careful when increasing
the volume on any device.
Note: To switch from MP3 mode to FM
mode, or from FM mode to Bluetooth
mode, quick press the Mode/Phone button
once until you reach the required mode.
WIRED HEADPHONE USE
• Plug the 3.5mm cable to the “Line
in” port and plug the other end into
the computer or other music device.
The headset will then work as a wired
unit.
Note: While in Line in mode, the FM/MP3
and Bluetooth function will not work and
you will not be able to adjust the volume
via the headphone buttons.
MUSIC PLAYBACK WITH SD CARD
1. Transfer your chosen tracks onto the
SD/TF card with the application of
your choice.
2. Insert the SD/TF card into the SD/
TF slot. Press the Mode select button
until the TF option is reached. Use
the Play/Forward/Previous buttons to
skip through and play your tracks.
DO’S AND DON’TS
• Do not play music at excessive
levels as damage to hearing and/or
equipment may result.
• Do not use in wet or in damp
surroundings.

8
TROUBLESHOOTING THE APPLIANCE
PROBLEM POSSIBLE SOLOUTION
The headphones won’t
charge.
Try a different USB charging cable or AC adapter to see if the
fault lies with the included USB cable.
I can’t find the
‘A58078’
Bluetooth device.
Make sure the earphones are in pairing mode.
Press the Play/Pause button for about 4 seconds until the red
and blue indicator lights flash alternately. Please check if your
Bluetooth device has already connected with another set of
headphones automatically. If so, disconnect them.
I can’t connect to my
phone.
Make sure the headset is charged. Make sure the headset is
within 10 meters (33 feet) of the phone, with no solid objects in
between. Check or redo the Bluetooth settings in the phone.
Try to pair the headset again.
CLEANING AND CARE
IMPORTANT:
1. Clean the appliance with a soft, damp
cloth. Never use chemicals or hard
abrasives.
2. Keep this unit away from wet or damp
surroundings.
3. Store the headphones in a cool, dry
place.
4. The crossed out wheelie bin symbol
on this item indicates that this
product needs to be disposed of
in an environmentally friendly way
when it becomes of no further use
or has worn out. Contact your local
authorities for details of where to take
the item for re-cycling.

9
RECYCLING
DISPOSAL OF THE UNIT
Appliances bearing the symbol shown here may not be disposed of in domestic rubbish.
You are required to dispose of old electrical and electronic appliances like this
separately.
Please visit www.recycle-more.co.uk or www.recyclenow.co.uk for access to information
about the recycling of electrical items.
Please visit www.weeeireland.ie for access to information about the recycling of
electrical items purchased in Ireland.
The WEEE directive, introduced in August 2006, states that all electrical items
must be recycled, rather than taken to landfill.
Please arrange to take this appliance to your local Civic Amenity site for
recycling, once it has reached the end of its life.

10
NOTES

11

*REGISTER YOUR PRODUCT ONLINE AT WWW.AKAIONLINE.CO
AND ENJOY 3 YEARS PEACE OF MIND
AKAI CUSTOMER SUPPORT TEAM
[phone]
Need help?
For advice, spares and returns.
Call:[phone]
8.30am to 6.00pm Monday-Friday
Visit: www.akaionline.co
Distributed throughout the UK by RK Wholesale LTD
0418.V1
