Akai A58052 User manual

INSTRUCTION MANUAL
CD BOOMBOX
WITH FM STEREO RADIO
MODEL: A58052

2
We declare that this product conforms to the following product legislation in accordance with the
following directive(s):
2014/30/EU Electromagnetic Compatibility Directive.
2014/35/EU Low Voltage Directive.
2011/65/EU Restriction of Hazardous Substances Directive.
2014/53/EU Radio Equipment Directive.
RKW Quality Assurance.
TECHNICAL DATA
This product is guaranteed for 12 months
from the date of the original purchase.
If any defect arises due to faulty materials
or workmanship, the faulty product must be
returned to the place of purchase.
Refund or replacement is at the discretion of
the retailer.
The following conditions apply:
The product must be returned to the retailer
with the proof of purchase.
The product must be installed and used in
accordance with the instructions contained in
this instruction guide.
This item is for domestic purposes only.
This guarantee does not cover wear and tear,
damage, misuse or consumable parts
RKW has limited responsibility for incidental
or consequential loss or damage.
Valid in the UK and Eire only.
MODEL NO: A58052/A58052BL/A58052C/A58052R
POWER SUPPLY
POWER: DC5V 1000MAH
DECLARATION OF CONFORMITY
GUARANTEE

3
IMPORTANT INFORMATION - RETAIN FOR FUTURE USE
SAFETY INFORMATION
Important safety instructions – read carefully before use.
It is important that this instruction manual should be retained with the Portable
Record Player for future reference. These warnings have been provided in the
interest of safety. You MUST read them carefully before installation or use.
WARNING
• Check that the voltage of the
main circuit corresponds with
the rating of the appliance before
operating.
• Please ensure that the appliance
is used on a stable, level, and
heat resistant surface.
• Do not immerse cords or any part
of the appliance in water or any
other liquid.
• Do not leave the appliance
unattended while it is operating.
• Close supervision is necessary
when any appliance is used by or
near children or pets.
• This appliance can be used by
children aged from 8 years and
above and persons with reduced
physical, sensory or mental
capabilities or lack of experience
and knowledge if they have been
given supervision or instruction
concerning use of the appliance
in a safe way and understand the
hazards involved.
• Children shall not play with the
appliance.
• Cleaning and user maintenance
shall not be made by children
without supervision.
• If the appliance is damaged, stop
using the appliance immediately
and seek advice from the
manufacturer or its service agent
or a similarly qualified person.
• Do not let the cord hang over the
edge of a table or counter or let
it come into contact with any hot
surfaces.
• The use of accessory
attachments is not recommended
by the appliance manufacturer,
apart from those supplied with
this product.
• Do not use this product for
anything other than its intended
use.
• This appliance is for household
use only.
• Do not carry the appliance by the
USB Cable.
• Do not use the appliance
outdoors.

4
• Do not block any ventilation
openings & install in accordance
with the manufacturer’s
instructions.
• Do not install near any strong
magnets or heat sources such as
radiators, heat registers, stoves,
or other appliances (including
amplifiers) that produce heat.
• Unplug the appliance from the
USB Cable during lightning
storms or when it has been
unused for long periods of time.
• If the appliance is not going to
be used for a period of time
please ensure that it is fully
disconnected from its power
source.
• If the appliance is brought
directly from a cold place to
a warm one, moisture may
condense inside the appliance
which will cause malfunction.
Should this occur, leave the
appliance off for a few hours until
the moisture evaporates.
• Do not place anything heavy on to
the appliance.
• Never attempt to disassemble
the appliance. There probably
would be a risk of electric shock
and/or harm by exposure.
• CAUTION! To reduce the risk of
electric shock, DO NOT cover
the back of the speaker. There
are NO user-serviceable parts
inside. Refer all servicing to the
manufacturer or qualified service
personnel.
• WARNING! DO NOT expose the
appliance to rain or moisture to
reduce the risk of electric shock
or fire.
• WARNING! DO NOT immerse the
product in water or any other
liquid.
• In the unlikely event the
appliance develops a fault,
stop using it immediately and
seek advice from the Customer
Support Team.
IMPORTANT INFORMATION - RETAIN FOR FUTURE USE

5
DISPOSAL
DISPOSAL INSTRUCTIONS FOR AKAI ITEMS IN
ACCORDANCE WITH THE WEEE DIRECTIVE.
APPLIANCES BEARING THE SYMBOL SHOWN
MAY NOT BE DISPOSED OF IN DOMESTIC
RUBBISH.
YOU ARE REQUIRED TO DISPOSE OF THE OLD
ELECTRICAL AND ELECTRONIC APPLIANCES
LIKE THIS SEPARATELY, PLEASE VISIT :
WWW.RECYCLE-MORE.CO.UK OR
WWW.RECYCLENOW.CO.UK
FOR ACCESS TO INFORMATION ABOUT THE
RECYCLING OF ITEMS.
THE WEEE DIRECTIVE, INTRODUCED IN
AUGUST 2006 STATES THAT ALL ELECTRICAL
ITEMS MUST BE RECYCLED RATHER THAN
TAKEN TO LANDFILL.
PLEASE ARRANGE TO TAKE THIS APPLIANCE
TO YOUR LOCAL REFUSE CENTRE.

6
PACKAGE CONTENTS
PART IDENTIFICATION
1. SPEAKER
2. USB POWER JACK
(BACK)
3. CONTROL PANEL
4. ON/OFF
5. BLUETOOTH
6. LED LIGHT
7. PLAY/PAUSE
8. AUX INPUT
9. SKIP BACKWARD
10. VOLUME
11. SKIP FORWARD
FEATURES AND CONTROLS
1. INSTRUCTION MANUAL
2. RETRO SPEAKER
3. AUX-IN CABLE
4. USB CABLE
91110
1
4 5 6 7 8
2 3

7
USING YOUR APPLIANCE
BEFORE FIRST USE
1. Remove the product from the box.
2. Remove any packaging from the product.
3. Please retain all packaging until you
have checked and counted all the parts
and the contents against the parts list.
4. Your appliance is now ready for normal
use.
POWERING ON AND CHARGING THE
BATTERY
Your Retro Speaker can be powered by a
rechargeable battery.
1. Insert one end of the USB Cable into
the USB jack and plug the other into the
USB jack of a computer or external USB
power source.
2. Flip the ON/OFF switch into the ON
position to turn the speaker on.
3. While charging, the LED Light on the
Volume knob will illuminate red. Once
the battery is fully charged the light
will turn off. Note: It’s recommended
to fully charge the battery before first
use. It should take 6 hours to charge the
battery.
4. When finished charging, unplug the USB
Cable from the power jack and your
computer.
Note: The speaker can still be used while
charging the battery, but will take more time
to fully charge.
USING THE CONTROLS
1. ON/OFF – Turns the speaker on and off.
2. Skip Backwards – Skip to previous track.
3. Bluetooth – Pairs your speaker with your
external device.
4. Volume – Controls the volume level.
5. LED Light – Indicates when the speaker
is charging, ready for pairing via
Bluetooth and when successfully paired
with an external device.
6. Skip Forward – Skip to the next track.
7. Play/Pause – Plays or Pauses audio.
8. AUX – Connects to an external device via
an AUX cable.
USING BLUETOOTH
1. Flip the ON/OFF switch to the ON
position. The LED light on the Volume
knob will flash blue.
2. Turn on Bluetooth on in your external
device and look for “A58052”.
3. Select the speaker name and pair it with
your device. If a password is required,
press “0000”.
4. Once you’re connected the LED light will
stop flashing indicating your device has
successfully paired.
5. If pairing is unsuccessful, restart both
devices and repeat the steps above.
6. Use the media controls on the Control
Panel to control playback.

8
USING YOUR APPLIANCE
USING AUX
1. Put the ON/OFF switch to the ON
position.
2. Insert the supplied Aux cable into the
Aux jack on the top of the speaker.
3. Insert the other end of the cable into the
line-out jack or headphone jack on your
external audio device.
4. Use the Volume control knob to adjust
volume and other media controls on the
control panel to control playback. Note:
You can also control playback on your
auxiliary device.
Note: If the line-out of your external device
is connected, you only need to adjust
system’s volume control. If the headphone
jack is connected, the volume may need
to be adjusted on both the speaker and
your external device to achieve the desired
volume.

9
TROUBLESHOOTING
CLEANING & MAINTENANCE
1. Clean the unit with a soft, damp cloth.
Never use chemicals or hard abrasives.
2. Keep this unit away from wet or damp
surroundings.
3. Store in a clean, dry place.
Problem Solution Solution
The unit will
not turn on. (no
power)
The unit is disconnected your
computer or external USB power
source.
Connect USB Cable to the USB
Power Jack of the speaker and then
plug into your computer’s USB jack.
No sound Volume not adjusted.
Wrong source selected.
Device not turned ON.
Volume is set too low.
Adjust the volume level.
Select the correct source.
Turn ON the device.
Adjust the Volume control knob to
increase the volume.
Sound is distorted Volume level is set too high. Decrease the volume.
Unit becomes
warm after
extended play at
high volume.
This is normal. Turn the unit o for some time or
lower the volume.

10
NOTES

11
NOTES

Need help?
For advice, spares and returns.
Call:[phone]
8.30am to 6.00pm Monday-Friday
Visit: www.akaionline.co
Distributed throughout the UK by RKW LTD
*REGISTER YOUR PRODUCT ONLINE AT WWW.AKAIONLINE.CO
AND ENJOY 3 YEARS PEACE OF MIND
AKAI CUSTOMER SUPPORT TEAM
[phone]
0617.V1
