INSTRUCTION MANUAL
WIRELESS OUTDOOR
SPEAKER
MODEL: A58060

2
We declare that this product conforms to the following product legislation in accordance
with the following directive(s):
2014/30/EU Electromagnetic Compatibility Directive.
2014/35/EU Low Voltage Directive.
2011/65/EU Restriction of Hazardous Substances Directive.
RK Wholesale LTD Quality Assurance.
DECLARATION OF CONFORMITY
TECHNICAL DATA
GUARANTEE
This product is guaranteed for 12 months
from the date of the original purchase.
If any defect arises due to faulty materials
or workmanship, the faulty product must
be returned to the place of purchase.
Refund or replacement is at the discretion
of the retailer.
The following conditions apply:
The product must be returned to the
retailer with the proof of purchase.
The product must be installed and used
in accordance with the instructions
contained in this instruction guide.
This item is for domestic purposes only.
This guarantee does not cover wear and
tear, damage, misuse or consumable
parts.
PFD has limited responsibility for
incidental or consequential loss or
damage.
Valid in the UK and Eire only.
MODEL: A58060
POWER SUPPLY
CHARGE VOLTAGE: DC 5V USB CHARGE
RECHARGEABLE BATTERY: 3.7V 800MAH
SPEAKER OUTPUT: 5W
BLUETOOTH VERSION: 2.1 + EDR

3
IMPORTANT INFORMATION  RETAIN FOR FUTURE USE
SAFETY INFORMATION
Important safety instructions – read carefully before use.
It is important that this instruction manual should be retained with the appliance for
future reference. These warnings have been provided in the interest of safety. You
MUST read them carefully before installation or use.
WARNING
• Safety Information
• Important safety instructions –
read carefully before use.
• It is important that this instruction
manual should be retained with
the outdoor speaker for future
reference. These warnings have
been provided in the interest
of safety. You MUST read them
carefully before installation or use.
• WARNING
• Check that the voltage of the main
circuit corresponds with the rating
of the appliance before operating.
• Please ensure that the appliance
is used on a stable, level, and heat
resistant surface.
• DO NOT immerse cords, plugs or
any part of the appliance in water
or any other liquid.
• DO NOT leave the appliance
unattended while it is operating.
• Close supervision is necessary
when any appliance is used by or
near children or pets.
• This appliance can be used by
children aged from 8 years and
above and persons with reduced
physical, sensory or mental
capabilities or lack of experience
and knowledge if they have been
given supervision or instruction
concerning use of the appliance
in a safe way and understand the
hazards involved.
• Children shall not play with the
appliance.
• Cleaning and user maintenance
shall not be made by children
without supervision.
• Switch off at the wall socket then
remove the plug from the socket
when not in use or before cleaning.
• If the supply cord or appliance is
damaged, stop using the appliance
immediately and seek advice from
the manufacturer or its service
agent or a similarly qualified
person.
• DO NOT let the cord hang over the
edge of a table or counter or let
it come into contact with any hot
surfaces.
• The use of accessory attachments
is not recommended by the
appliance manufacturer, apart
from those supplied with this
product.
• DO NOT pull the plug out by the
cord as this may damage the plug
and/or the cable.
• DO NOT use this product for
anything other than its intended
use.
• DO NOT carry the appliance by the
power cord.
• DO NOT place anything containing
liquid on top of the unit
• DO NOT spill liquid onto the
appliance. If this happens, mop up
the liquid and seek advice from a
qualified technician.
• DO NOT use next to a swimming
pool.

4
IMPORTANT INFORMATION  RETAIN FOR FUTURE USE
WHAT’S IN THE BOX & FEATURES
• DO NOT use in wet or damp
surroundings or conditions.
• DO NOT put objects into any of the
openings.
• Keep the unit free from dust, lint
etc.
• DO NOT install near any heat
sources such as radiators,
heat registers, stoves, or other
apparatus (including amplifiers)
that produce heat.
• Only use attachments/accessories
specified by the manufacturer
• Unplug this apparatus during
lightning storms or when unused
for long periods of time.
• Please ensure that the appliance
has adequate ventilation
• Battery shall not be exposed to
excessive heat such as sunshine,
fire or the like.
• DO NOT play music at excessive
level especially near children.
• In the unlikely event the appliance
develops a fault, stop using it
immediately and seek advice from
the Customer Support Team:
[phone]
INSTRUCTION MANUAL
BLUETOOTH/WIRELESS OUTDOOR SPEAKER
3.5MM AUXILIARY CABLE
MICRO USB CHARGING CABLE
KEY FEATURES
1. BLUETOOTH INDOOR AND OUTDOOR SPEAKER
2. STREAM MUSIC WIRELESSLY USING BLUETOOTH ENABLED DEVICES
3. WIRELESS RANGE  33 FEET
4. BUILTIN COLOUR CHANGING LED LIGHTS
5. USB/MICRO SD TF PLAYBACK USB & MICRO SD TF CARD NOT INCLUDED
6. BUILTIN FM RADIO
7. MICROPHONE INPUT
8. BUILTIN AUX INPUT
9. BUILTIN RECHARGEABLE BATTERY
10. EASY CARRYING HANDLE

5
PART IDENTIFICATION
1. CHARGING LED INDICATOR
2. CHARGING PORT
3. AUXILIARY PORT
4. LED DISPLAY
5. MICROPHONE INPUT
6. USB SLOT
7. MICRO SD TF CARD SLOT
8. SPEAKER & LIGHT SHOW
9. ON/OFF SWITCH
10. MODE BUTTON
11. SKIP BACKWARD/DECREASE
VOLUME
12. PLAY/PAUSE BUTTON
13. SKIP FORWARD/INCREASE VOLUME
14. MIC VOLUME BUTTON
15. CARRYING HANDLE
CONTROLS
1
98
2
10
3
11
4
12 13 14 15
5 6 7

6
USING YOUR APPLIANCE
BEFORE FIRST USE:
• Remove the speaker from the box.
• Remove any packaging from the
product.
• Retain all packaging until you have
checked and counted all the parts
and contents against the parts list.
For best results, fully charge the unit
before use.
1. Connect the USB cable (included) to
the charging port of the speaker and
insert the other end into the USB port
on your computer or similar power
source.
2. The Red LED at the back turns on
indicating that the battery is being
charged. Once it is fully charged, the
Red LED will turn off. It takes around
6 hours to fully charge the battery.
NOTE: In order to have better battery life,
please do not charge for over 6 hours.
Overcharging the speaker can adversely
impact the battery life.
NOTE: Turn the speaker off when it’s not
in use to save battery power.
TURNING THE SPEAKER ON/OFF:
1. To turn on, slide the ON/OFF switch to
the ON position.
2. To turn off, slide the “ON/OFF” switch
to the OFF Position.
SWITCHING TO BLUETOOTH PAIRING
MODE:
1. Turn on the speaker using the ON/
OFF switch.
2. The LED display will turn blue to
indicate the speaker is now in pairing
mode.
NOTE: The speaker will automatically pair
with previously paired devices
PAIRING YOUR DEVICE VIA BLUETOOTH:
Your Bluetooth Speaker can wirelessly
stream audio from any Bluetooth enabled
device within 27-33 Feet. Simply follow the
below steps.
1. Turn on the speaker using the ON/
OFF switch.
2. The LED display will turn blue to
indicate the speaker is now in pairing
mode.
3. Activate the Bluetooth on your mobile
device or computer.
4. It will search for various devices.
5. Select ‘A58060’ to pair with the
speaker, and pair it with this device.
6. If required, enter the password ‘0000’
to confirm to finalise pairing.
7. Once it has successfully paired, you
will hear an indication tone.
8. If it fails to pair it within the time
frame or you want to pair it with a
new device; please follows the steps
outlined above.
9. Select your favourite song via your
Bluetooth device and music should
now stream through speaker.
NOTE: If you insert an SD card or USB
flash drive whilst using the Bluetooth
function, the speaker will automatically
switch to the USB/SD function. To return
to the Bluetooth function, press the MODE
button.

7
USING YOUR APPLIANCE
MODE SELECTION:
1. Press the MODE button to switch
between the different functions of the
speaker. The functions are: Bluetooth,
SD (TF Card), USB, AUX and FM
Radio.
CONTROLS:
NOTE: An indication tone will alert you
when the volume is adjusted to the
maximum level.
Function Operation Button
Increase / Decrease
Volume Playing music Long press the + or - button to adjust the volume to your desired level
Pause Playing music Press once to pause the music
Play Pause Press once resume the music
Previous track Playing music Short press the button to the previous
track
Next track Playing music Short press the button to the next track
AUX-IN MODE:
1. Turn on the speaker.
2. Plug the 3.5 mm auxiliary cord
(included) into the speaker’s auxiliary
port. Connect the other end of the
cable to an audio device (such as an
MP3 Players, computer, tablet, etc.).
3. Press the MODE button until you
reach AUX mode.
NOTE: The LED display will first show
“Lod” then “LINE”.
4. Select your favourite song at the
source device.
NOTE: Once the AUX cable is connected to
the speaker, music playing via Bluetooth
will be stopped. You can only control
media through the source device, while
playing music in Auxiliary mode.
USB/SD (TF CARD) MODE:
1. Turn on the speaker.
2. Insert a Micro SD (TF) card or USB
flash drive into the USB or Micro
SD (TF) card slots. The LED display
will show “Lod” and then switch
to “SD” or “USB”. Your music will
then automatically play through the
speaker.
3. Press the or button to move
forward or backward on your playlist.
4. Press the button to Play or Pause
a track.
NOTE: To return to Bluetooth mode, press
the MODE button to select it.

8
USING YOUR APPLIANCE
FM RADIO:
1. Turn on the speaker.
2. Plug the auxiliary cord (included) into
the auxiliary port. Leave the other end
of the cord open. Note: The auxiliary
cord serves as a FM Antenna, while
the speaker is in FM Radio mode.
3. Press the “MODE” button until FM
mode is selected; the LED display
will show “Lod” first and then FM
frequency.
4. Press the button once. The device
will automatically search and store all
FM Radio stations.
5. To change the stations, press the
or buttons.
CAUTION! Do not play music at excessive
levels especially near children, as damage
to hearing may occur.
TURNING ON/OFF THE COLOUR
CHANGING LED LIGHTS:
1. Turn on the speaker.
2. Long press the “MODE” button to turn
the colour changing LED lights on or
off.
USING THE MICROPHONE:
1. Turn on the speaker.
2. Insert the microphone plug (not
included) into the speaker’s
Microphone input.
3. Turn on the Microphone.
4. Long press the or buttons, and
press MIC volume button to adjust the
desired output level.
5. You’re now ready for Karaoke.

9
TROUBLESHOOTING
CLEANING & MAINTENANCE
RECYCLING
1. Clean the unit with a soft, damp
cloth. Never use chemicals or hard
abrasives.
2. Keep this unit away from wet or damp
surroundings.
Problem Possible Cause Solution
Low sound level Source (Tablet, Mobile Phone,
Laptop, etc.) volume too low. Use the volume control located on the control panel
to adjust the volume to your
desired level.
Sound distorted Battery nearly dead. Charge Battery.
No sound at all. Source (Tablet, Mobile Phone,
Laptop.) turned off.
Speaker turned off.
Volume turned down source.
Media paused on source.
Turn the source on.
Turn the speaker on.
Adjust volume source.
Play media from source.
DISPOSAL OF THE UNIT
Appliances bearing the symbol shown
here may not be disposed of in domestic
rubbish.
You are required to dispose of old
electrical and electronic appliances like
this separately.
Please visit www.recycle-more.co.uk
or www.recyclenow.co.uk for access to
information
about the recycling of electrical items.
Please visit www.weeeireland.ie for
access to information about the recycling
of electrical items purchased in Ireland.
The WEEE directive, introduced in August
2006, states that all electrical items must
be recycled, rather than taken to landfill.
Please arrange to take this appliance to
your local Civic Amenity site for recycling,
once it has reached the end of its life.

10

11

*REGISTER YOUR PRODUCT ONLINE AT WWW.AKAIONLINE.CO
AND ENJOY 3 YEARS PEACE OF MIND
AKAI CUSTOMER SUPPORT TEAM
[phone]
Need help?
For advice, spares and returns.
Call:[phone]
8.30am to 6.00pm Monday-Friday
Visit: www.akaionline.co
Distributed throughout the UK by RK Wholesale LTD
0818.V2
