Akai CEU6800-BT User manual

CEU6800-BT
INSTRUCTION MANUAL
Bluetooth Speaker For Tablets
With USB Charger
Thank you for purchasing this Bluetooth Speaker. Please read this instruction manual carefully before
using this product to ensure proper use. Keep this manual in a safe place for future reference.

EN-1
Contents
CEU6800-BT Bluetooth Speaker For Tablets
With USB Charger
1.
AC Power Adaptor
2.
AUX IN Cord
3.
If you are missing any parts above, please contact ADT Digital LLC.
Tel: [phone]
Fax: [phone]
Instruction Manual4.
Warranty Card
5.
ADT Digital LLC

C A UTION:T O P R EVENT T HE RISK O F
ELECTRIC SHOCK, DO NOT REMO V E
COVER OR BACK. NO USER-SERVICEABLE
PARTS INSIDE. REFER SERVICING TO
QUALIFIED PERSONNEL.
CAUTION
RISKOF ELECTRIC SHOCK
DO NOT OPEN
WARNING: TO REDUCE THE RISK OF
FIRE OR SHOCK HAZARD, DO NOT EXPOSE
THIS PRODUCT TO RAIN OR MOISTURE.
This symbol is intended to alert you to
the presence of uninsulated dangerous
voltage within the product’s enclosure
that might be of sufficient magnitude to
constitute a risk of electric shock. Do
not open the product’s case.
This symbol is intended to inform you
t h at important operating and
maintenance instructions are included
in the literature accompanying this
product.
DRIPPING WARNING
The product shall not beexposed to dripping or
splashing and that no objects filled with liquids,
such as vases, shall be placed on the product.
VENTILATION WARNING
The normal ventilation of the product shall not be
impeded for intended use.
Warning: Changes or modifications to this unit not
expressly approved by the party responsible for
compliance could void the user’s authority to
operate the equipment.
Le présent appareil est conforme aux Partie 15 des
règlements de la FCC et CNR d'Industrie Canada
applicables aux appareils radio exempts de licence.
L'exploitation est autorisée aux deux conditions
suivantes :
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouill
-age radioélectrique subi, même si le brouillage
est susceptible d'en compromettre le fonctionne
-ment.
This class[B] digital apparatus complies with
Canadian ICES-003.
Cet appareil numérique de la classe B est conforme
à la norme NMB-003 du Canada.
Class ll equipment symbol
This symbol indicates that the power
adaptor has a double insulation system.
EN-2
This equipment complies with FCC’s and IC’s RF
radiation exposure limits set forth for an
uncontrolled environment. The antenna(s) used for
this transmitter must be installed and operated to
provide a separation distance of at least 20 cm from
all persons and must not be collocated or operating
in conjunction with any other antenna or transmitter.
Installer must ensure that 20 cm separation
distance will be maintained between the device
(excluding its handset) and user.
FCC RADIATION EXPOSURE
STATEMENT
This device complies with Part 15 of the FCC Rules
and Industry Canada licence-exempt RSS
standard(s).
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference,
and
(2) this device must accept any interference
received, including interference that may cause
undesired operation.
FCC IMPORTANT
DECLARATION DE LA FCC RELATIVE
A L'EXPOSITION AU RAYONNEMENT
Cet appareil est conforme aux limites d'exposition
au rayonnement RF stipulées par la FCC et IC pour
une utilisation dans un environnement non contrôlé.
Les antenne utilisées pour cet émetteur doivent être
installées et doivent fonctionner à au moins 20 cm
de distance des utilisateurs et ne doivent pas être
placées près d’ autres antennes ou émetteurs ou
fonctionner avec ceux-ci. Les installateurs doivent
s'assurer qu’une distance de 20 cm sépare
l’appareil (à l'exception du combiné) des utilisateurs.
FCC ID : OWT-CEU6800BT

EN-3
NOTE: This digital apparatus does not exceed the Class B limits for radio noise emissions from digital
apparatus as set out in the radio interference regulations of Industry Canada.
Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables aux
appareils numériques de Classe B prescrites dans le règlement sur le brouillage radioélectrique édicté par
Industrie Canada.
1.
2.
3.
4.
5.
6.
7.
8.
9.
Read Instructions- All the safety and operating instructions should beread before the product isoperated.
Retain Instructions- The safety and operating instructions should be retained for future reference.
Heed Warnings - All warnings on the product and in the operating instructions should be adhered to.
Follow instructions - All operating and use instructions should be followed.
Cleaning- Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol
cleaners. Use a damp cloth for cleaning the exterior only. Do NOT attempt to clean the inside.
Attachments- Do not use attachments not recommended by the product manufacturer as they may cause
hazards.
Water and Moisture - Do not use this product near water - for example, near a bath tub, wash bowl, kitchen
sink, or laundry tub; in a wet basement,ornear a swimming pool, and the like.
Accessories - Do not place this product on an unstable cart, stand tripod, bracket, or table. The product may
fall, causing serious injury to a child or adult, and serious damage to the product. Use only with a cart, stand,
tripod, bracket, or table recommended by the manufacturer, or sold with the product. Any mounting of the
product should follow the manufacturer’s instructions, and should use a mounting accessory recommended by
the manufacturer.
A product and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces
may cause the appliance and cart combination to overturn.
Ventilation -Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of
the product and to protect it from overheating, and these openings must not be blocked or covered. The
openings should never be blocked by placing the product on a bed, sofa, rug, or other similar surface. This
product should not be placed ina built-in installation such as a bookcase or rack unless proper ventilation is
provided.
10.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television (which can be
determined by turning the equipment off), the user is encouraged to try to correct the interference by one or
more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced / TV technician for help.

EN-4
14. Lightning- For added protection for this product during a lightning storm, or when it is leftunattended and
unused for long periodsof time, unplug it from the wall outlet. This will prevent damage tothe product due to
lightning and power-line surges.
Overloading- Do not overload wall outlets, extension cords, or integral convenience receptacles as this can
result ina risk of fire or electric shock.
Object and Liquid Entry - Never push objects ofany kind into this product through openings as they may
touch dangerous voltage points or short-out parts that could result ina fire or electric shock. Never spill liquid of
any kind on the product.
15.
16.
Power sources - This product should be operated only from the type ofpower source indicated on the marking
label. If you are not sure of the type of power supply to your home, consult your product dealer or local power
company. For products intended to operate from battery power, or other sources, refer to the operating
instruction.
Grounding or Polarization- This product may be equipped with a polarized alternating current line plug (a
plug having one bladewider than the other). This plug will fit into the power outletonlyone way. This isa safety
feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail
to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized
plug.
12.
11.
Servicing- Do not attempt to service thisproduct yourself as opening or removing covers may expose you to
dangerous voltage or other hazards. Refer all servicing to qualified service personnel.
Damage Requiring Service - Unplug this product from the wall outlet and refer servicing to qualified service
personnel under the following condition:
a)
b)
c)
d)
e)
f)
When the power-supply cord or plug is damaged,
If liquidhas been spilled, or objects have fallen into the product,
If the product has been exposed torain or water,
If the product does not operate normally by following the operating instructions. Adjust only those
controls that are covered by the operating instructions as an improper adjustment of other controls may
result in damage and will often require extensive work by a qualified technician to restore the product to
its normal operation.
If the product has been dropped or damaged in any way, and
When the product exhibits a distinct change inperformance - this indicates a need for service.
17.
18.
Replacement Parts - When replacement parts are required, be sure the service technician has used
replacement parts specified by the manufacturer or have the same characteristics as the original part.
Unauthorized substitutions may result infire, electric shock, or other hazards.
19.
Power-Cord Protection - Power supply cords should be routed so that they are not likely to be walked on or
pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience
receptacles, and the point where they exit from the product.
13.
Safety Check- Upon completion of any service or repairs to this product, ask the service technician to
perform safety checks to determine that the product is in proper operating condition.
Heat - The product should be situated away from heat sources such as radiators, heat registers, stoves, or
other products (including amplifiers) that produce heat.
Unplug this apparatus during lighting storms or when unused for long periods of time.
This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have beengiven supervisionorinstruction
concerning use of the appliance by a person responsible for their safety.
20.
21.
22.
23.

EN-5
Children should be supervised to ensure that they do not play with the appliance.
Ensure children and babies do not play with plastic bags or any packaging materials.
24.
25.
To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.
Avertissement: pour réduire le risque d’incendie ou de choc électrique, ne pas exposer cet appareil
sous la pluie et l’humidité.
The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such
as vases, shall be placed on apparatus.
L’appareil ne doit pas être exposé aux écoulements ou aux éclaboussures et aucun objet ne contenant
de liquide, tel qu’un vase, ne doit être placé sur l’objet.
The MAINS plug / power adaptor is used as the disconnect device, it should remain readily operable
during intended use.
In order to disconnect the apparatus from the mains completely, the main plug / power adaptor should
be disconnected from the mains socket outlet completely.
La prise du secteur ne doit pas être obstruée ou doit être facilement accessible pendant son utilisation.
Pour être complètement déconnecté de l’alimentation d’entrée, la prise doit être débranchée du secteur.
WARNINGS:

EN-6
FRONT VIEW
1. Adjustable Tilting Tablet Holder
2. Rubber Spacer
3. ON/OFF, PAIRING & AUX Indicator
4. POWER ON/OFF Switch
5. USB Charger Port
6. AUX IN Jack
7. DC IN Jack
123
467
5
REAR VIEW

EN-7
CONNECTING TO AC POWER
POWERING ON/OFF THE UNIT
This unit is supplied with an AC adaptor. Please follow the following steps to connect this AC adaptor.
1. Unwind the power cord of the AC adaptor to its full length.
2. Connect the DC plug of the AC adaptor to the DC IN jack on the rear of the unit.
3. Plug the AC adaptor to the AC socket outlet (120V, 60Hz). Connecting this system to any other
power source may cause damage to the system.
Note:
- For sufficient ventilation, please keep other objects or walls at least 10cm away from the unit.
- When the unit is not operated by the AC power or unused for long period of time, please remove the
power adapter from the wall outlet and unplug from the main unit.
1. After connecting the AC power, slide the POWER ON/OFF switch in the rear of the unit to ‘ON’
position for switching on.
2. The unit is then in ‘Bluetooth Mode’ if there is no audio connection cable plugged to the AUX IN
jack. (Please see section of ‘BLUETOOTH OPERATION’ for details.)
3. While an audio connection cable is plugged into the AUX IN jack of the unit, the ‘Bluetooth Mode’
will be disabled and you can connect the other end of the cable to external audio device for
playback. (Please see section of ‘LISTENING FROM AUX IN JACK’ for details.)
4. After using, slide the POWER ON/OFF switch to ‘OFF’ position to turn off the unit.
AC Power Adaptor
AC Socket
Outlet

EN-8
.
1. Place your iPad of tablet in landscape position on the holder of the unit for watching video or
listening music. It is not recommend to place these mobile devices in portrait position because of
the stability.
2. Adjust your desired viewing angle of these mobile devices by pulling and tilting the tablet holder.
PLACING TABLET
iPad
or
Tablet
Adjust the viewing angle
Using AUX IN jack

EN-9
BLUETOOTH OPERATION
LISTENING FROM AUX IN JACK
Pairing with a Bluetooth device
If the unit has never been paired with a Bluetooth device before, you need to follow the pairing
instructions below to link the Bluetooth speaker with your Bluetooth device.
1. Slide the Power switch to ON position on the rear of unit.
2. The unit will search the paired device with the PAIRING indicator flashing quickly in blue and two
"Beep” will be heard.
3. Turn on Bluetooth function of your device and enable the search or scan function to find
CEU6800-BT. (See your device's instructions to add or setup a Bluetooth device).
4. Select "CEU6800-BT" from the device list when it appears on your device screen. If required, enter
the pass code "0000" to pair (link) CEU6800-BT with your device.
5. After successfully paired with a device, the PAIRING indicator will be flashing slowly in blue and you
will hear a “Beep” which confirms the pairing had been done.
Note: If you cannot pair the unit with your Bluetooth enabled device, you can try to turn off and then
turn on the unit again for pairing.
This unit includes an AUX input jack to allow you to connect external devices, such as an iPhone /iPod
or MP3 player, and listen to the music stored on your external device through the speakers of this unit.
1. Connect one end of AUX IN cord to the AUX IN jack on the rear of the unit and
the other end to the line out jack (or earphone jack) on your external audio device.
2. Set the POWER ON/OFF switch to turn on the unit. The ON/OFF indicator will light in blue steadily.
3. Operate your external device as usual to select and play music.
4. Adjust the volume controls on your external audio device to the desired volume level.
5. Turn off your external audio device when finish listening.
6. Slide the POWER ON/OFF switch to OFF position to turn the unit off and unplug the AUX IN cord
from the AUX IN Jack and your external audio device.
Playing from a paired Bluetooth device
You can play music from your Bluetooth device wirelessly to Bluetooth speaker by following the steps
below after successfully paired.
1. To select your favorite song, press the PLAY button on your Bluetooth device to start playback.
2. Adjust the VOLUME +/- buttons of your Bluetooth device until you obtain a comfortable listening
level.
Notes:
1. Your Bluetooth enabled device will not play the music through the speaker, even if connected (linked)
if the device does not support the A2DP Bluetooth profile.
2. Remember to turn off the Bluetooth speaker after you have finished listening. Please also slide the
power ON/OFF switch of the unit to the OFF position.
3. Please do not forget to switch off the power of your external audio device as well if you do not use it
for other purposes.

EN-10
CHARGING YOUR PORTABLE DEVICE
TROUBLESHOOTING
Adjust the volume.
Connect the adaptor properly.
Electrostatic discharge. Turn off the unit, disconnect the
adaptor from outlet socket and
then reconnect after a few
seconds.
The USB cable (not included) is
not plugged into the USB jack on
the unit.
The main unit does not
react to any button
being presssed
There is no sound
coming from speaker
Plug the USB cable (not included)
into the USB jack on the unit.
PROBLEM POSSIBLE CAUSE SOLUTION
Sound is distorted Volume level is set too high. Decrease the volume of the
speaker.
Sound source is distorted and
has poor quality.
Replace with other good quality
sound sources.
Volume is not adjusted on the
Bluetooth device.
Adaptor is not correctly connected
to AC socket outlet.
No charging
This unit features a USB port for charging your portable device (iPad, tablet, iPhone, Android phone,
etc.) when used with the USB charging cord that came with your device.
1. Plug one end of the USB cable (not included) into the USB charging port located in the rear of the
unit.
2. Plug the other end of the cord into the device you wish to charge.
3. Observe the battery charge indicator on your portable device to make sure the charging process
be performed normally.
CAUTION:
Before charging, please refer to the user manual of the device you wish to charge to make sure the
charging current requested does not exceed 2.4A (2400mA). Overloading the charging circuit may
damage the unit permanently and void the warranty.
1. The USB charging port of this unit supplies a DC 5V output at 2.4A (2400mA) maximum current to
charge your portable device battery and it cannot support any other voltage range.
2. Make sure the device you want to charge has a battery charge rating of DC 5V only.
3. The USB port of this unit is designed for portable device battery charging only and it cannot
support data transfer or connect to computer.
4. Do not connect the USB port of this unit to other external power charger USB ports, it may damage
both units and void the warranty.
If a fault occurs, first check the points listed below before taking the unit for repair. If you are unable to
remedy a problem by following these hints, consult your dealer or service center.
WARNING: Under no circumstances should you try to repair the unit yourself, as this would invalidate
the guarantee.

1. Place the unit on a level surface away from sources of direct sunlight, excessive heat caused by
heating equipment, humidity, rain or sand.
2. Protect your furniture when placing your unit on a natural wood and lacquered finish. A cloth or other
protective material should be placed between it and the furniture.
3. Do not clean your unit by water directly. Clean the unit with a soft, clean cloth slightly moistened with
plain lukewarm water only.
4. Stronger cleaning agents, such as Benzene, thinner or similar materials can damage the surface of
the unit.
5. Do not attempt to disassemble your product.
6. Do not paint your product with lacquer or aerosol.
7. Do not drop, throw or try to bend your product.
8. Do not expose your product to open flames.
EN-11
CARE AND MAINTENANCE
SPECIFICATION
8W x 2, 8 Ohms, 3 inch.
Weight 2.34 lb. ( 1.06 kg)
DC 5V 2.4A
USB Charger
Speakers
Dimensions
Bluetooth
12.99” W x 5.43” D x 6.50” H
330W x 138D x 165H mm
Bluetooth Specification version 3.0
Support profile A2DP
Output Power 3W (RMS) x 2
IMPORTANT: Due to the continued functioning of revisions and improvements in the design of our
products, specifications are subject to change without notice.
The Bluetooth word mark and logo are registered trademarks owned by Bluetooth SIG, Inc., and any
use of such marks by Arts Digital Technology for AKAI is under license.
®
Power Source:
AC Adaptor
Input: AC 100-240V~ 50/60Hz
Output: DC 9V 3.5A
