INSTRUCTION MANUAL
10W FABRIC
BLUETOOTH SPEAKER
MODEL: A58074
NEED HELP?
FOR ADVICE, SPARES AND RETURNS.
CALL:[phone]
8.30AM TO 6.00PM MONDAY-FRIDAY
VISIT: WWW.AKAIONLINE.CO

2
We declare that this product conforms to the following product legislation in accordance with
the following directive(s):
2014/30/EU Electromagnetic Compatibility Directive.
2014/35/EU Low Voltage Directive.
2011/65/EU Restriction of Hazardous Substances Directive.
2014/53/EU Radio Equipment Directive.
RK Wholesale LTD Quality Assurance.
DECLARATION OF CONFORMITY
TECHNICAL DATA
GUARANTEE
This product is guaranteed for 12 months
from the date of the original purchase.
If any defect arises due to faulty materials
or workmanship, the faulty product must be
returned to the place of purchase.
Refund or replacement is at the discretion of
the retailer.
The following conditions apply:
The product must be returned to the retailer
with the proof of purchase.
The product must be installed and used in
accordance with the instructions contained in
this instruction guide.
This item is for domestic purposes only.
This guarantee does not cover wear and tear,
damage, misuse or consumable parts.
RK Wholesale LTD has limited responsibility
for incidental or consequential loss or
damage.
Valid in the UK and Eire only.
MODEL NO: A58074
BLUETOOTH RANGE: UP TO 10 METRES
BUILT IN BATTERY: 1800MAH
POWER: 2 X 5W
PLAY TIME: APPROX. 4H30MIN
CHARGING TIME: UP TO 2.5 HOURS
BUILT-IN RECHARGEABLE BATTERY: 3.7V /1800MAH
FEATURES: MICRO SD (TF) CARD/USB DRIVE

3
IMPORTANT INFORMATION - RETAIN FOR FUTURE USE
SAFETY INFORMATION
Important safety instructions – read carefully before use.
It is important that this instruction manual should be retained with the
appliance for future reference. These warnings have been provided
in the interest of safety. You MUST read them carefully before
installation or use.
WARNING
• Check that the voltage
of the main circuit
corresponds with the
rating of the appliance
before operating.
• Please ensure that the
appliance is used on a
stable, level, and heat
resistant surface.
• DO NOT immerse cords or
any part of the appliance
in water or any other
liquid.
• DO NOT leave the
appliance unattended
while it is operating.
• Close supervision is
necessary when any
appliance is used by or
near children or pets.
• This appliance can be
used by children aged
from 8 years and above
and persons with reduced
physical, sensory or
mental capabilities or
lack of experience and
knowledge if they have
been given supervision or
instruction concerning use
of the appliance in a safe
way and understand the
hazards involved.
• Children shall not play
with the appliance.
• Cleaning and user
maintenance shall not be
made by children without
supervision.
• If the appliance is
damaged, stop using the
appliance immediately
and seek advice from
the manufacturer or
its service agent or a
similarly qualified person.
• DO NOT let the cord hang
over the edge of a table
or counter or let it come
into contact with any hot
surfaces.
• The use of accessory
attachments is not
recommended by the
appliance manufacturer,
apart from those supplied
with this product. DO NOT
use an extension cord to
charge this appliance.
• DO NOT use this product
for anything other than its
intended use.
• This appliance is for
household use only.

4
• DO NOT carry the appliance
by the USB Cable.
• DO NOT use the appliance
outdoors.
• DO NOT block any
ventilation openings &
install in accordance
with the manufacturer’s
instructions.
• DO NOT install near any
strong magnets or heat
sources such as radiators,
heat registers, stoves, or
other appliances (including
amplifiers) that produce
heat.
• Unplug the appliance from
the USB Cable during
lightning storms or when it
has been unused for long
periods of time.
• DO NOT block any
ventilation openings &
install in accordance
with the manufacturer’s
instructions.
• DO NOT install near any
strong magnets or heat
sources such as radiators,
heat registers, stoves, or
other appliances (including
amplifiers) that produce
heat.
• Unplug the appliance from
the USB Cable during
lightning storms or when it
has been unused for long
periods of time.
• If the appliance is not going
to be used for a period of
time please ensure that it
is fully disconnected from
its power source.
• If the appliance is brought
directly from a cold place
to a warm one, moisture
may condense inside the
appliance which will cause
malfunction. Should this
occur, leave the appliance
off for a few hours until the
moisture evaporates.
• DO NOT place anything
heavy on to the appliance.
• Never attempt to
disassemble the appliance.
There probably would be a
risk of electric shock and/
or harm by exposure.
• CAUTION! To reduce the
risk of electric shock, DO
NOT cover the back of the
speaker. There are NO
user-serviceable parts
inside. Refer all servicing
to the manufacturer
or qualified service
personnel.
• WARNING! DO NOT expose
the appliance to rain or
moisture to reduce the risk
of electric shock or fire.
• WARNING! DO NOT
immerse the product in
water or any other liquid.
• In the unlikely event the
appliance develops a fault,
stop using it immediately
and seek advice from the
Customer Support Team:
[phone]

5
PACKAGE CONTENTS
FEATURES AND CONTROLS
INSTRUCTION MANUAL
FABRIC BLUETOOTH SPEAKER
MICRO USB CABLE
3.5MM AUX CABLE
1. M function key
2. Volume +
3. Volume -
4. Prev
5. Next
6. Play/Pause/Hands free call
7. Power ON/OFF
8. Charging port
9. Power LED
10. TF port
11. USB port
12. AUX port
1
7 8 9 10 11 12
2 3 4 5 6

6
USING YOUR APPLIANCE
BEFORE FIRST USE
1. Remove the speaker from the box.
2. Remove any packaging from the
product.
3. Retain all packaging until you have
checked and counted all the parts and
contents against the parts list.
4. Dispose of the packaging in a
responsible manner.
CHARGING THE SPEAKER
To charge the Fabric Bluetooth Speaker,
connect the supplied micro USB cable to the
USB charging port and the other end to your
computer or USB charging device.
The LED light at the front of the unit will
ash red to indicate the speaker is charging.
Make sure to charge for at least 4 hours
before using the Speaker for the rst time.
PAIRING A SPEAKER WITH PHONE /
BLUETOOTH ENABLED DEVICE
1. Turn on the Bluetooth speaker.
2. Turn on your Bluetooth enabled device
and activate the Bluetooth function.
3. Search for the Bluetooth device,
“A58074” will show up.
4. If required, enter the password ‘0000’
to conrm and nalize pairing.
5. Your Speaker should now be paired
with your device. The LED light at
the front of the unit will ash blue to
indicate the pairing was successful.
TURNING ON YOUR SPEAKER
To turn on your speaker, ick the On/O
switch onto the ON position by sliding it
from left to right. You will nd this switch
inside the protective cover at the back of
the unit, next to the USB, Micro-SD and AUX
ports.
To turn the speaker o, ick this switch
back the other way to return it to the OFF
position.
MODE SELECTION
This speaker supports playback through
Bluetooth, from TF/SD or USB external
storage devices.
Press the ‘M’ key repeatedly to cycle
through the speaker’s available playback
modes until you reach your desired mode.
PLAYING MUSIC
Play/Pause: To begin playback, press
the Play/Pause button. The speaker will
automatically begin playing the selected
song or audio track. To pause playback at
any time, press the button again while the
speaker is in operation
Skipping Tracks: To skip to the next track
on your playlist, press the NEXT button. To
skip back to the previous track, press the
PREV button.
Hands-Free Calls: This device is equipped
with a built-in mic, which allows you to
make and receive hands-free calls.
To answer an incoming call hands-free
using your speaker, press the Play/Pause
button while on Bluetooth mode. The
sound from your call will automatically be
redirected to your speaker.
Volume Up / Volume Down: To increase
playback volume, short press the ‘+’ key
repeatedly until you have reached your
desired volume.
To decrease playback volume, short press
the ‘-’ key repeatedly until you have reached
your desired volume.

7
PROBLEM POSSIBLE CAUSE SOLUTIONS
Low sound level Source (Tablet, Mobile
Phone, Laptop, etc.)
volume too low.
Battery is dead.
Adjust the source volume to your desired level.
Charge the battery.
Sound distorted Battery is nearly dead. Charge the battery.
No sound at all Source (Tablet, Mobile
Phone, Laptop) turned
o.
Speaker turned o.
Volume turned down
source.
Media paused on
source.
Turn the source on.
Turn the speaker on.
Adjust volume source.
Play media from source.
Turn the speaker on.
Adjust the volume source.
Play media from the source.
Bluetooth function not
working Speaker not paired to source device.
Bluetooth mode not
selected.
Check that both the speaker and the source device
are turned on.
Check that the speaker and the source device are
correctly paired.
Check that the LED light at the front of the unit is
ashing blue as this indicates the speaker is in
Bluetooth mode.
TROUBLESHOOTING THE APPLIANCE

8
CLEANING AND CARE
IMPORTANT:
• Clean the appliance with a soft, damp
cloth. Never use chemicals or hard
abrasives.
• Keep this unit away from wet or damp
surroundings.
• Store in a cool, dry place.
• The crossed out wheelie bin symbol
on this item indicates that this
product needs to be disposed of in an
environmentally friendly way when it
becomes of no further use or has worn
out.
• Contact your local authorities for
details of where to take the item for
re-cycling
RECYCLING
DISPOSAL OF THE UNIT
Appliances bearing the symbol shown here may not be disposed of in domestic rubbish.
You are required to dispose of old electrical and electronic appliances like this separately.
Please visit www.recycle-more.co.uk or www.recyclenow.co.uk for access to information
about the recycling of electrical items.
Please visit www.weeeireland.ie for access to information about the recycling of
electrical items purchased in Ireland.
The WEEE directive, introduced in August 2006, states that all electrical items must
be recycled, rather than taken to landll.
Please arrange to take this appliance to your local Civic Amenity site for recycling,
once it has reached the end of its life.

9
NOTES

10
NOTES

11
NOTES

*REGISTER YOUR PRODUCT ONLINE AT WWW.AKAIONLINE.CO
AND ENJOY 3 YEARS PEACE OF MIND
AKAI CUSTOMER SUPPORT TEAM
[phone]
NEED HELP?
FOR ADVICE, SPARES AND RETURNS.
CALL:[phone]
8.30AM TO 6.00PM MONDAY-FRIDAY
VISIT: WWW.AKAIONLINE.CO
DISTRIBUTED THROUGHOUT THE UK BY RK WHOLESALE LTD
0319.V2
