Aktino AK500 Original operating instructions

AK500 Ethernet Compact Remote Unit
Quick Installation
Part # Description CLEI Code Part # Description
AK525RU Compact RT Unit, 25 Mbps at CSA, 45 Mbps max COM9S10E AKCURB Dual Compact Unit Rack Bracket
AK512RU Compact RT Unit, 12 Mbps at CSA, 20 Mbps max COM9T10E AKCUWB Compact Unit Wall Mount Bracket
AKCUF19 Compact Unit 19 inch rack flange mounts
AKCUF23 Compact Unit 23 inch rack flange mounts
AKRUPA Compact RT Unit AC adapter
The AK5000 Ethernet product family enables point to point transport of Ethernet services over bonded pairs of copper, optimized
for CSA distances (9kft 26AWG or 12kft 24AWG). The AK5000 family includes the Ethernet Compact Remote Unit that fits into
optional 1RU high brackets for 19” and 23” racks or can be wall mounted with the optional wall mount bracket. The Compact
Remote Unit is either locally powered or line powered by the Central Office Compact Unit or Line Card. Aktino products utilize
the technology “MIMO on DMT” which uses coordinated signal processing over multiple transceivers to achieve significant
performance improvements over standard DSL technology. Refer to the AK500 Ethernet Compact CO Unit Quick Installation
(180-0034-001) or the AK500S Ethernet Multislot Shelf Quick Installation (180-0036-001) for CO installation. Refer to the
AK5000 Ethernet Technical Practice (180-0037-001) for more comprehensive information and troubleshooting.
#1 Mounting
The AK500 Compact Remote Units can be mounted with the
AKCURB Rack Bracket (see Figure 1), with the AKCUF19
or AKCUF23 Rack Flange mounts (see Figure 2), or with
the AKCUWB wall mounting bracket (see Figure 3).
#2 Connections
Frame Ground Connection (see Figure 4)
Crimp a #10 ring lug to a ground wire and attach it onto the
#10 ground stud located on the right side of the rear panel.
Use a wire gauge for grounding at least as heavy as the
power wiring. Attach the grounding wire from the Ground
Lug to a nearby grounding screw on the equipment rack or
facility ground. Note that the ground connection is
required for proper system operation.
Power Connection
The Aktino Compact Remote Unit can either be line
powered from the Aktino Central Office Unit or Line card,
or locally powered with the optional AKRUPA AC adapter.
For maximum reliability, both line power and local power
can be used simultaneously. If locally powering, plug the
AKRUPA AC adapter into the power jack on the back of the
Compact Remote Unit (see Figure 4).
Ethernet Data Connections (See Figure 5)
Attach Ethernet data cables to any of the four 10/100BaseT
RJ45 plugs on the front panel or insert an SFP module in the
front panel slot. Generally, any 100BaseFX or 1000BaseX
SFP module is compatible; contact Aktino Customer Service
with any question regarding SFP compatibility.
Caution In order to comply with the intrabuilding lightning
surge requirements, intrabuilding Ethernet wiring must be
shielded, and the shield for the wiring must be grounded at
both ends.
Figure 1 Rack Bracket Mounting
Figure 2 Rack Flange Mounting
Figure 3 Wall Mounting
AK500 Ethernet Compact Remote Units 1 Document 180-0035-001 R04

Ground lug (#10) AK525RU only
R4R3 T4R2T2 T3
R5T5 T8R7R6T6 T7 R8
POWER
3.3A15V -
+
R1T1
12VDC OUT
-+
PAIRS 5-8
PAIRS 1-4
56
12
78
34
MultiPair Connection
The MultiPair pluggable connector is used to connect the
Aktino Compact Remote to the outside plant pairs. The
AK512RU uses one four pair connector. The AK525RU
uses two four pair connectors. Insert the tip and rings into
the connector as shown in Figure 6. Tighten screws on top
of the connector. Insert the connector into the MSPAN plug
on the back of the Compact Remote Unit (see Figure 4). The
Compact Remote Unit MSPAN cable’s shield should
generally not be connected to ground (leave open).
Figure 6 Compact Remote Unit MSPAN Pluggable
Connector
Management Craft Port
Local management craft access is through the MGMT port
on the front panel IF remote management is enabled from
the CO shelf or unit.
1) Connect an Ethernet cable between the maintenance
computer and the Compact Remote Unit’s MGMT port.
2) The Compact Remote Unit has a factory default IP
address of 192.168.10.2.
3) Configure the maintenance computer’s IP address to
192.168.10.3 and Netmask to 255.255.255.0. Note the
maintenance computer’s original settings.
4) Run AktinoView V3 using 192.168.10.2 as the IP
address for the Aktino unit. The default user name and
password is “superuser” (case sensitive).
5) If desired, the Aktino units can now be monitored with
AktinoView. The Compact Remote Unit provides read
only capability only, system parameters cannot be
change. Note, MSPAN must be up to monitor the
system.
6) Exit AktinoView V3.
7) Reconfigure the maintenance computer’s IP address to
original setting.
Figure 4 Compact Remote Unit Back Panel (AK525RU shown)
Replaceable Air Filter and
Fan Assembly
Local Power input
Management Craft Port
12VDC OUT - See AK5000 Ethernet
Technical Practice for details
Figure 5 Compact Remote Unit Front Panel (AK525RU shown)
R
4
T4
R
8
T8
R
3
T1 R1 T2
R
2 T3
R
7
R
6 T7
T6 Second connector for
AK525RU only
R
5
T5
AK500 Ethernet Compact Remote Units 2 Document 180-0035-001 R04

#3 Monitoring (see Table 1)
AktinoView V3 or higher software is used to monitor the
system. Load AktinoView V3 software onto the
maintenance computer per the instructions on the CDROM
package.
Provisioning from the CO shelf or unit
Provisioning can only be done from the CO shelf or unit.
AktinoView V3 uses the front panel MGMT Ethernet port
for access to the Aktino unit. AktinoView V3 should be
started verify the health of the circuit. The default user name
and password is “superuser”. To provide system security,
the password for superuser and user accounts should be set
up with AktinoView V3 Craft Access tabs under the
Provisioning tab.
See Table 1 below for provisioning parameters available at
the CO shelf or unit. Ethernet and other parameters are
available via the Provisioning tabs.
Table 1 Common Provisioning Selections (provisionable
from the CO shelf or unit only)
Parameter Values
MSPAN Rate Rate (Kbps)
# Pairs 1 to 4 (AK512), 1 to 8 (AK525)
Individual pairs can be set to UP or
DOWN in the Pair menu
Line Powering
Off, -135v, -185v (-185v default)
Note, line powering is only on
AK5xxLCP line card and
AK5xxCUP compact unit
MSPAN SNR Margin
(MSPAN menu) 0..18db (5db default)
Ethernet Parameters Each port’s parameter values can be
p
rovisioned in the Ethernet tabs
#4 System Health Verification
As soon as power is applied to the CO unit (and the RT unit
if locally powered), the system automatically starts up. The
front panel indicators show the status of the system (see
Figure 5 and Table 2). If any of the LEDs is not Normal,
AktinoView V3 can be used to determine the source of the
problem.
AktinoView V3 main status screen shows an overview of the
system. Performance monitoring for Ethernet, MSPAN, and
Pair is available through the tabs. Current system alarms
(see Table 3) are displayed on the main status screen. Alarm
history and logs are available through the tabs.
Table 2 Front Panel Indicators
LED Condition Function
STATUS
Off
Green
Re
d
Power off
Normal
Unit in alar
m
LOCAL
PWR Off
Green
Local power is not connected
Local power is connecte
d
PAIR
STATUS
Off
Solid green
Flashing green
Solid re
d
Pair is disabled
Pair is up
Pair is acquiring
Pair LOS/Open circuit/Short
10/100BaseT
Act Off Green No data present Data present
10/100BaseT
L
k
Off
Green Ethernet link is down Ethernet link is up
100B-FX
1000B-X
Off
Green
SFP is not present
SFP present and active
Table 3 Common Alarms (displayed by AktinoView V3)
Alarm Fault Troubleshooting
MSPAN LOS MultiPair Span pairs are down, check pairs
MSPAN Capacity
MultiPair Span capacity below configured
rate; increase number of pairs or decrease
system margin or reduce rate. Check Pairs
PM to ensure proper ope
r
ation.
Pair LOS Pair is connected but not receiving signal,
check Pair PM.
Pair Open Circuit Pair is not connecte
d
AK500 Ethernet Compact Remote Units 3 Document 180-0035-001 R04
