ZSK T8 Operation instructions

Version 1.0 [GB]- 2014
Tutorial
T8-/T8-2 Control unit
Network- and MY.ZSK Setup

Subject to change!
Änderungen vorbehalten!
© ZSK Stickmaschinen GmbH
Printed in Germany
[ GB ] 02361011

General
5. August 2014/DC Version 1.0 [GB] - 2014 1-3
1. General
1.1 Glossary
All described functions of the control unit T8-/T8-2 will be started at
the Base Screen.
Keynames
The used key notations of function describtions will be shown in the T8-/T8-
2-fi gure above.
Keys for controlling operation of the software are usually depicted as follows:
• [R1] Select machine design
Figure: 1.1:
T8-/T8-2 Base Screen

1-4 Version 1.0 [GB] - 2014 5. August 2014/DC
Glossary
Recurring key functions
The following recurring key functions always have the same position and func-
tion in the screen shots. These functions will be explained here for simplifi ca-
tions and they will be displayed in function description only as key functions.
[L7] Defaults
When using this function, the settings shown in the screen will be reset to default.
[L8] Confi rm
With this function you confi rm the accuracy of your selection, settings and
entries. The control unit applies your values and generally leads to the previous
menu.
[R8] Previous
Herewith you can cancel the current operation at any time. Changes which have
been made will not be applied and the previous menu will be shown again.
Used input examples
The user names, paths etc. displayed in the fi gures, are exemplary only and they
have to be adjusted to your own personal needs at the respective locations.
Listings
Displayed Listings in the screen images will be created automatically and there-
fore they may vary from listings displayed on your T8-/T8-2-control unit.

5. August 2014/DC Version 1.0 [GB] - 2014 1-5
Load design from remote client
2. T8-/T8-2 Network
2.1 Load design from remote client
When using a MY.ZSK system in conjunction with a MY.ZSK router, a ZSK
embroidery machine with T8-/T8-2-control unit in a local network, a connection
to another network can be established with a shared folder via a parallel connec-
tion. In this process the MY.ZSK router acts as a bypass allowing the requested
connection through.
This way from this remote client which is not connected to the local network
for example an embroidery pattern can be loaded directly or via a barcode
reader in the machine .
Requirements:
Local network with router and connection to the Internet.
Networked ZSK embroidery machine with T8-/T8-2 control unit.
MY.ZSK system with MY.ZSK router in the local network.
Access to a remote domain or a remote client.
Figure: 1.2:
Functional layout

1-6 Version 1.0 [GB] - 2014 5. August 2014/DC
IP Adress of T8-/T8-2 control in local network
2.2 IP Adress of T8-/T8-2 control in local network
In a network, the IP addresses of the connected individual devices are usually
generated and managed automatically by a DHCP server in the router of the
network. In some cases it is required to assign a static IP address to the con-
nected devices. This then needs to be set manually in the control software of the
device. In the router, this address is then applied to the connected device and
reserved.
2.2.1 Assign IP address automatically (DHCP)
• [L7] Software- /hardware settings
• [R3] Network setup
• [R1] IP-Address and subnet mask
Figure: 1.3:
Dialogue:
Software-/hardware set-
tings
Figure: 1.4:
Dialogue:
Network setup

5. August 2014/DC Version 1.0 [GB] - 2014 1-7
IP Adress of T8-/T8-2 control in local network
• Press [L3] Obtain from DHCP Server, to activate the reception of an IP
address from the DHCP server of the router.
• [L8] Confi rm
2.2.2 Assign static IP address
• [L7] Software- /Hardware settings
• [R3] Network setup
Figure: 1.5:
Dialogue:
Network IP Address and
subnet mask
Figure: 1.6:
Dialogue:
Software-/Hardware set-
tings

1-8 Version 1.0 [GB] - 2014 5. August 2014/DC
IP Adress of T8-/T8-2 control in local network
• [L1] IP Address and subnet mask
• Press [L2] Issue manually… to activate the function.
• [R3] IP adress
• Enter the static IP address for the control unit.
[TAB] = Change to the next input fi eld.
• [L8] Confi rm
Figure: 1.7:
Dialogue:
Network setup
Figure: 1.8:
Dialogue:
Netzwerk IP address and
subnet mask
Figure: 1.9:
Dialogue:
Enter Network IP address

5. August 2014/DC Version 1.0 [GB] - 2014 1-9
Establish path to the remote domain or client
2.3 Establish path to the remote domain or client
The T8-/T8-2 control unit can be connected to a remote domain, or a remotely
located client over the Internet. In this way, the access to any embroidery pat-
tern pool is possible. In order to establish the connection please follow the
instructions here:
2.3.1 Client authentifi cation / Login
When accessing remote clients, servers or domains, a registration (authentica-
tion) is required in the network to be accessed. In order to obtain the login
data (username / password) for these networks, please contact the responsible
network administrator. Enter the login information in your control panel :
• [L7] Software-/hardware settings
• [R3] Network setup
• [R1] Network user name
Figure: 1.10:
Dialogue:
Software-/hardware set-
tings
Figure: 1.11:
Dialogue:
Network setup

1-10 Version 1.0 [GB] - 2014 5. August 2014/DC
Establish path to the remote domain or client
• Enter the login name for the remote network or remote client.
• Press [OK], in order to confi rm the entry.
• [R2] Network password
• Enter the password for the remote network or remote client.
• Press [OK], in order to confi rm the entry.
Figure: 1.12:
Dialogue:
Enter network user name
Figure: 1.13:
Dialogue:
Network setup
Figure: 1.14:
Dialogue:
Enter network password
