AL Tech AE-L-LBSS-28 User manual

“The applications are endless for this
canopy fixture….” National Association
of Service Station Retailers
The fixture of choice for the US Military
Altech proudly supports our troops by
keeping their military bases brightly lit and
efficient as possible!

Specifications
Wattage: 28W 40W 60W 90W
Model Number: AE-L-LBSS-28 AE-L-LBSS-40 AE-L-LBSS-60 AE-L-LBSS-90
DLC #: U-ICN-28 U-ICN-40 U-ICN-60 U-ICN-90
DLC Partner: Ultron
UL/cUL Number: E481056
Certifications:
Voltage: 120-277V(Default) / 277-480V
Power Factor: 0.98
Frequency: 50/60Hz
Lumens Efficiency: 100LM/W
Kelvin (CCT): 3500K - 5700K
CRI: 80+
IP Rating: IP67
Materials: Die cast aluminum base and ballistic polycarbonate lens
Finish: Black (Default)
LM70 Life Time: 100,000
Dimming
Availability: Built In
Warranty: 7 Years
Temperature Range: -34℃~ 54℃(-30℉~ 120℉)
Product Weight: 6.0 lbs.
Product Length: 9.5” / 242 mm
Product Width: 9.5” / 242 mm
Product Height: 2.5” / 64 mm
Replacement
Wattage: 100W 150W 200W 250W
Pending

/34

User Guide
Note:
Please read this entire manual to fully understand and safely use the luminaire. The
products can be used at the voltage of 100-277V AC, 50/60HZ, suitable for indoor and
outdoor, moisture proof and dust proof. Specifications are subject to change without
notice. Please visit www.altechefficiency.com for the most recent product information.
Unpacking:
1. Unpack and carefully examine the product.
2. Report any damage and save all packing materials if any part(s) were damaged during shipping.
3. Do not attempt to use the fixture if it is damaged.
Before You install:
1. Before installing any light fixtures, read and understand all cautions, warnings, instructions and product
labels. Failure to do so can result in injury and/or void the warranty.
2. CONSULTA QUALIFIED ELECTRICIAN TO ENSURE CORRECT BRANCH CIRCUIT CONDUCTOR.
3. The product should be installed and operated by a qualified electrician or technician in accordance
with relevant local codes.
4. Risk of electric shock. Ensure that main power source is off when wiring or soldering the sections of
the product.
Maintenance:
1. Disconnect the product from the power supply prior to cleaning.
2. Use a dry or slightly moistened cloth for cleaning.
3. Never use any chemicals or abrasive materials for cleaning.
Installation Instructions:
1. Connect the input and ground wires of the fixture to the power supply.
2. Complete all electrical connections.
3. Secure the fixture to the mounting box with screws.
4. Close the fixture, replace and tighten the housing screws.
5. Slide the hole of the mounting arm onto the pole and tighten the hexagon screw.
6. This fixture is designed for years with minimum care. For optimum performance, periodically clean the
lens with a mild, non abrasive glass cleaner and soft cloth. DO NOT use solvents or cleaners
containing abrasive agents. When cleaning the fixture, make sure you have the power turned off and
do not spray liquid cleaner directly onto the LED, socket or wiring.
