Hatco B-950P User manual

© 2022 Hatco Corporation 1
2. Verify the mounting position of the posts on each base plate.
The posts are pre-installed on each base plate in the center
position. They can be moved to the offset position, if necessary:
a. Use the included hex wrench to loosen the set screw
securing the post to the base plate flange. Remove the base
plate from the post.
 b.Usinga7/16″ socket wrench,removethe nutonthe bolt
inside the base plate flange that secures the flange to the
base plate. Then, reinstall the posts in the offset position
of the base plate. Use a torque wrench to tighten the nut to
20 ft-lbs.
Legs in offset position.Legs in center position.
Base Plate
Flange Post
3. Open up the stabilizer tabs on the base plates.
• The base plate of each post assembly has retractable
stabilizer tabs that can be pivoted out for extra stability during
installation or operation.
Tabs in retracted postion. Tabs pivoted to open postion.
4. Prepare to install the glass panel.
• There are two mounting holes provided on each side of the
glasspanel.Choosetheholepositionthatwillworkforthe
installation. Install the provided filler cap assembly in the
unused holes using a coin to hand-tighten.
Filler Cap
Cover
Filler Cap
Cover
Use coin
here.
Underside
of glass
panel.
Filler Cap
Assembly
installed.
Top side
of glass
panel.
P/N 07.14.007.00-1222 [B950P_IG]
INSTALLATION GUIDE
Hatco / ADM Sneezeguards
Portable Sneeze Guards
Model B-950P
Model B-950P Portable Sneeze Guards are available in single bay
widthsfrom24″–66″(610–1676mm).Alloftheavailablewidths
areheightadjustablefrom13″–24″(330–610mm)andhave a
commonbaseplatedepthof14″(356mm).
For additional information regarding Model B-950P, scan the QR
Code below:
https://www.sneezeguard.com/info.php?
Model=B-950P-GLASS&pid=79&osCsid=q3ksj3df96tqad14o2vhcqrnu6
Important Safety Information
To avoid injury and damage to equipment or property, read the
following safety information before installing this equipment.
Do not attempt to assemble and install sneeze guards
alone. Installation of sneeze guards requires two or
more people, dependent upon unit.
Do not place anything on top of sneeze guard. It is not
designed to be a weight-bearing component.
Use non-abrasive cleaners and cloths only. Abrasive
cleaners and cloths could scratch finish of unit,
marring its appearance and making it susceptible to
soil accumulation. Use of abrasive materials will void
warranty.
Assembly and Installation
 1. Unpackallcomponents.Verifythattheappropriatenumberof
the items below are present.:
 •GlassPanel,3/8″
 •PostandBasePlateAssembly,BrushedStainlessSteel
 •EndPanel,3/8″Glassx2(optional)
 •HardwarePacket(includeshexwrenchandextrasetscrews)
Glass Panel
Post and
Base Plate
Assembly
Height
Adjustment
Twist-Lock Nut
Glass
Clamp

© 2022 Hatco Corporation2
 6. Adjusttheangleoftheglasspanel,ifnecessary.NOTICE: Two
people are required for this step.
• The angle of the glass panel can be adjusted in 15°
increments.
• Simultaneously loosen the thumb screw/hex cap screw on
each glass clamp, carefully rotate the glass panel to the
desired position, and re-tighten the thumb screws/hex cap
screw.
Hex Cap
Screw
Move shield
to desired
angle.
Shield
removed
for clarity.
 7. Adjusttheheightoftheglasspanel,ifnecessary.Thisstepwill
require two people.
 a.Oneachpost,loosenthesafetysetscrewonthetwist-lock
nut,andturnthetwist-locknutcounterclockwisetoloosen.
b. Carefully move the glass panel to the desired height.
 c.Oneachpost,turnthetwist-locknutclockwisetosecureits
position,andtightenthesafetysetscrewonthetwist-lock
nut.
Safety Set
Screw
Twist-Lock
Nut
Move both
extendable
posts to desired
height.
Shield
removed
for clarity.
Cleaning/Maintenance
Clean the unit daily using non-abrasive cloths and cleaners.
• The glass panel can be cleaned using a standard glass cleaner.
Options and Accessories
End Panels
End Panels with a depth of 18″ (457 mm) are available for all
B-950P portable sneeze guards.
LED Light Bar
AnLEDlightbarisavailableasafactory-installedoptionforcertain
sizesandcanbeconfiguredwithacordandplugorabatterypack.
5. Install the glass panel onto the glass clamp of each post and
base plate assembly.
a. Remove the machine screw that secures the top plate of
each glass clamp. Remove the top plate and nylon washer
from each clamp.
 b.Positiontheglasspanelontopoftheglassclamp,making
sure the edge brace on each clamp is against the side of the
glass.
NOTE: Always position nylon washers with the raised lip facing the
glass.
c. Place the nylon washer followed by the top plate onto the
glass panel aligned with each glass clamp, and secure in
position using the machine screw. Tighten the screw until it
holds the glass securely—do not over-tighten.
Glass Clamp
Machine Screw
Edge
Brace
Top Plate
Nylon
Washer
Machine
Screw
Glass Panel
installed onto
Post and Base
Plate Assembly
NOTE: Always loosen the thumb screws/hex cap screws on the
glass clamps before attempting to the adjust the angle of
the glass panel. Failure to loosen the screws will strip the
internal grip fittings.
