Aladdin DH07 Instruction manual

DH07 shown
Manual P/N 92448
Rev. O 06/27/2016
DH07,DH08
CONVECTED AIR
DISH HEATERS
(9" Dishware)
INSTALLATION, OPERATION & MAINTENANCE MANUAL
P.O. Box 2978, Hendersonville, TN 37077-2978
1-800-888-8018 or 615-537-3600
Fax [phone]
www.aladdintemprite.com
®

Copyright © 1998 Aladdin Temp-Rite
Changes may be made to the information in this document without notication.

DH07 / DH08 CONVECTED AIR DISH HEATERS
(9" Dishware)
CONTENTS
I. MODELS 4
II. RECEIVING INSPECTIONS 5
III. INSTALLATION 5
IV. ELECTRICAL6
V. START-UP 7
VI. CLEANING 8
VII. TROUBLESHOOTING 9
VIII. PARTS LIST/DIAGRAMS 10
IX. PREVENTATIVE MAINTENANCE 14
X. SERVICE 15
XI. WARRANTY 15

DH07 / DH08
4
CONVECTED AIR DISH HEATERS
(9" Dishware)
I. MODELS
The Aladdin Convected Air Dish Heaters are available in two capacities. These units are designed specically
for use with a wide variety of 9” china and Alacite® dishware only.
(Not recommended for any type of pellet bases.)
The Aladdin Convected Air Dish Heaters are mobile, modularly designed products which are able to
be used independently or in conjunction with other units in a tray line arrangement.
Aladdin Sales Codes DH07 DH08
Number of Stacks 2 3
Capacity per Stack 60 60
Capacity (Total) 120 180
Overall Dimensions:
Length 32.58" (82.75 cm) 46.0" (116.8 cm)
Width 24.60" (62.48 cm) 24.60" (62.48 cm)
Height 42.86" (108.86 cm) 42.86" (108.86 cm)
Electrical Requirements:
Voltage / Phase 208-240V /1 208-240V /1
Amperage 16 16
Cycle 60 60
NEMA Plug Conguration 6-20P 6-20P
Approximate Shipping Weight 270 lbs. 300 lbs
FOR PARTS & SERVICE CALL 1 [phone]

5
You should carefully inspect your Dish Heater to assure that no damage has occurred in transit. If
however, damage is detected see the following damaged goods policy. Under no condition may a
damaged unit be returned to Aladdin Temp-Rite without rst obtaining written permission (return
authorization). No credit will be issued for claims not reported to Aladdin within ten (10) business days
from receipt of shipment.
ALADDIN DAMAGED GOODS POLICY
There are two types of damaged merchandise:
● Visual Damage ●Concealed Damage
Visual Damage – When the product being received is visibly damaged.
1. Receiver should not accept merchandise with visual damage.
2. Receiver must sign delivery receipt “refused merchandise due to damage” and specify damage.
3. Receiver should call Aladdin Customer Service immediately after refusal.
4. Carrier will notify Aladdin Trafc Department and a claim will be led.
5. Carrier will send acknowledgement of claim within 7 days after receiving.
Concealed Damage – When damaged merchandise cannot be externally detected.
Any receiving operation should be looking for this type of damage. Sometimes, however,
depending on the type of product, it is almost impossible to notice.
1. Merchandise must not be removed from point of delivery and all packaging must be kept intact.
2. Receiver must contact Aladdin customer service to report damage.
3. Aladdin trafc department will request inspection based on the dollar value of the cargo.
4. Aladdin trafc department will le a claim based on the ndings of the inspection.
Failure to comply with these policies will result in the customer’s responsibility to le claims.
NOTE: The installation instructions are similar for all the heaters.
A. All models are equipped with a self-leveling mechanism that is removable through the
top of the unit so that adjustments can be made to the tension springs. By adding or
rmoving springs, the proper dispensing height can be obtained. Refer to the table on page
7 to adjust the DH07 or DH08 to dispense either 9" china or Alacite® dishes. (The heaters are
factory preset for china dispensing) Adjustments should be done as part of the initial equipment
set-up or when a change of dinnerware occurs.
II. RECEIVING INSPECTIONS
III. INSTALLATION
FOR PARTS & SERVICE CALL 1 [phone]

DH07 / DH08
6
CONVECTED AIR DISH HEATERS
(9" Dishware)
IV. ELECTRICAL
Refer to the specications data on page 4, the serial tag, your local code or the National Electrical
Code to be sure the unit is connected to the proper power source. A protected circuit of the cor-
rect voltage and amperage must be available for connection of the line cord. All dish heaters are
provided with a NEMA plug type 6-20P.
B. If you are dispensing Alacite® dishes a spring adjustment will be required, proceed as
follows. Lift elevating mechanism assembly up and out of stainless steel cabinet. Set it on
the oor. Disconnect but do not remove any unnecessary springs from the elevator carrier
and replace mechanism back into the heater. (See chart on page 7 for correct spring
arrangement.)
C.
See ELECTRICAL (section IV) and START- UP (section V) before plugging unit into power supply.
FOR PARTS & SERVICE CALL 1 [phone]
! WA R N I NG !
Every heater is tted with a grounded power cord and must be connected to a properly
grounded receptacle. Each receptacle must be wired to a dedicated circuit breaker rated at
not more than 20 amps.
! WA R N I NG !
To prevent electrical shock hazard, the main power switch must be turned to "off " position and
the heater disconnected from the power source whenever performing service or maintenance.
! WA R N I NG !
Hazardous voltage inside back of cabinet. Only qualied personnel totally familiar with
electrical circuits, service manual and service procedures should open or work inside unit.

7
A. OVERVIEW
These units are designed to heat china or Alacite® plates. Once the unit is turned on, the fan motor, heater
and power indicator light will come on. There is a power indicator light to let the operator know the power is
on. The fan motor will begin to circulate the heated air in and around the plates in a convection process that
promotes a quick and even heat absorption by the dinnerware.
Once the air inside the cabinet has reached the desired and preset temperature, the thermostat will continue
to maintain this temperature by regulating the power to the heater. The fan motor will run as long as the unit
is energized.
B. LOADING
Load carrier tray by carefully stacking the dishes in each cavity. Always keep the load leveled on the carrier
or it may bind. Never try to exceed the recommended dish capacities that are shown in the chart below. The
fan motor will begin to circulate the heated air in and around the plates in a convection process that promotes
a quick and even heat absorption by the dinnerware.
V. START-UP
Round Plates
Style Dimensions Aladdin Sales
codes
Springs
Required
Total Capacity
DH07 DH08
China 9" Diameter J300 8 120 180
9" Diameter J361 8 120 180
9" Diameter J461 8 120 180
9" Diameter J561 8 120 180
9" Diameter J700 8 120 180
9" Diameter J100 8 120 180
Alacite 9" Diameter K95 6 120 180
9" Diameter K97 6 120 180
9" Diameter K98 6 120 180
9" Diameter J420 4 86 129
FOR PARTS & SERVICE CALL 1 [phone]
! WA R N I NG !
Do not adjust thermostat above 190°for Alacite® plates as this may cause yellowing and/or
damage to the plates..
! CAUTION !
No type of pellet base should be heated in these dish heaters. Failure to observe this warning could
result in damage to bases or risk of re.

DH07 / DH08
8
CONVECTED AIR DISH HEATERS
(9" Dishware)
VI. CLEANING
C. POWER
Set the power switch to the "ON" position. The power switch will light up when the unit is on.
Keep the cover closed completely to insure proper and efcient heating.
Depending on the stack size, and dish material, the heating time will vary. The heater should
alays be turned on 60 to 90 minutes before dispensing. Generally, china dishes will heat
quicker than Alacite®.
D. DISPENSING
After the unit is turned off or unplugged, the dishes remaining inside the unit will remain hot for some time.
Leave the lid open to allow the unit and its contents to cool.
E. ADJUSTING THE THERMOSTAT
All models are shipped with a factory preset of 190˚F ( Max setting 220˚F). The thermostat can be adjusted, by
dial control located behind the rear panel, to adjust
1. Unplug the unit
2. Remove the rear cover
2. Adjust thermostat dial to the desired setting
3. Replace the rear cover
4. Plug unit back in to an outlet
The following procedures should be followed during the regular cleaning regimen on all of the dish heaters.
1. Turn the unit off and disconnect the plug from the outlet, and allow the cabinet to cool.
Remove plug by pulling it straight out. Never pull on the cord.
2. Pull the elevator mechanism up and out, place it on a work surface.
You can now wipe down the mechanism with a damp cloth to clean it.
3. Clean out any debris inside the cabinet and wipe the cabinet down with a damp cloth.
4. Place the elevator mechanisms back inside the cabinet and clean the outside of the cabinet with
a mild, non-abrasive soap or detergent in a warm water solution. A commercial stainless steel
cleaner can also be used for this procedure.
5. After the heater has been thoroughly cleaned and dried with a soft cloth the plug can be replaced.
NOTE: Do not use abrasives, harsh chemicals, or chlorine products for cleaning.
FOR PARTS & SERVICE CALL 1 [phone]
! CAUTION !
Operators should always wear gloves or use plate lifters when dispensing dishes.

9
VII. TROUBLESHOOTING
COMPLAINT PROBLEM SOLUTION
A. Unit does not operate and no lights are on 1. No power 1. Make sure plug is connected and switch is ON.
Check for power to the receptacle
2. Bad power switch 2. Replace power switch
3. Loose wiring 3. Check and secure wiring
B. Unit heats, but fan does not operate 1. Defective motor 1. Replace motor
2. Jammed or loose fan blade 2. Replace or tighten blade
3. Loose wiring 3. Determine fault and correct
C. Unit does not heat, but fan operates 1. Defective heating element 1. Replace heating element
2. Open high limit switch
2. Replace switch. Check for causes before restart-
ing equipment
3. Loose wiring 3. Check and secure wiring
D. Plate temperature is too low, fan operating 1. Thermostat set too low 1. Readjust thermostat
2. Jammed or loose fan blade 2. Replace or tighten blade
3. Cover is open 3. Close cover
E. Plate temperature is too high, fan is
operating
1. Thermostat set too high 1. Readjust thermostat
2. Closed thermostat 2. Replace thermostat
3. Closed high limit switch 3. Replace high limit switch
F. Cover is loose 1. Hinge screws are missing
or loose 1. Replace or tighten screws
G. Elevator Binds 1. Improper springs 1. Check springs chart and use correct number of
springs. Make sure identical number and size of
springs are on each side of elevator
2. Debris on guide rods 2. Clean off debris
H. Cabinet does not roll easily 1. Debris on wheel or axle 1. Clean out debris
2. No lubrication 2. Lubricate axles with load bearing grease. Lubri-
cate swivel bearings with 30-weight oil.
FOR PARTS & SERVICE CALL 1 [phone]
! WA R N I NG !
Do not steam or pressure clean or hose down the cabinet. This could damage the equipment
and possibly cause an electrical shock to the operator.
! WA R N I NG !
Repairs to be done by qualied service personnel only.

DH07 / DH08
10
CONVECTED AIR DISH HEATERS
(9" Dishware)
VIII. PARTS LIST/DIAGRAMS
ITEM
#
DESCRIPTION ALADDIN
PART #
DH07
Qty.
DH08
Qty.
1A Lid assembly-End
(for units prior to Dec 2011)
92496 2 2
1B Lid assembly-End
(for units after Nov. 2011)
11558 2 2
2A Lid assembly-Center
(for units prior to Dec 2011)
92497 - 1
2B Lid assembly-Center
(for units after Nov. 2011)
11559 - 1
3A Hinge, RH & LH 10173 2 3
3B Hinge, RH & LH
(for units before December 2011)
92203 2 3
4 Switch guard 10570 2 3
5 Lid handle 92500 2 3
6A Push/Pull handle 99594 1 1
6B Push/Pull handle
(for units before March 2009)
92501 - -
7 Rear louvered panel DH07 10554 1 -
8 Rear louvered panel DH08 10553 - 1
9Cord-10 foot length 94837 1 1
10 Plug- NEMA 6-20 straight blade 92504 1 1
11 Plug-NEMA L6-20 twist lock 29781 1 1
12 Switch kit 93989 - -
ITEM
#
DESCRIPTION ALADDIN
PART #
DH07
Qty.
DH08
Qty.
12a On/off switch 97539 1 1
13 Motor-208/230V,60hz.1ph. 3200
rpm ♠13064 1 1
13a Motor conversion kit ♣13068 - -
14 High limit switch-257°F manual
reset
11760 1 1
14a High limit (for SN prior to
DH07A13136 & DH08A13071)
92507 - -
15 Thermostat-85-220 °F92508 1 1
16 Knob, Thermostat-85-220 °F92509 1 1
17 Heating element-208-240V 92511 1 1
18 na
19 Fan Blade, 5/16" bore 92512 1 1
20 Caster 5" swivel 97223 2 2
21 Caster 5" swivel with brake 92516 2 2
22 Elevator spring 12405 16 24
23 Elevator bushing 10816 8 12
24 Elevator guide rod 10638 4 6
25 Elevator assembly 92520 2 3
26* Corner bumpers 93052 4 4
NOTES:
*Corner Bumpers are used in place of wrap around bumpers on units manufactured after August 1999.
♠For the SN and above DH07 F16431 and DH08 E16218
♣For SN prior to DH07 F16431 and DH08 E16218
FOR PARTS & SERVICE CALL 1 [phone]

11
DH07
EXPLODED VIEW DRAWING
Corner Bumpers are used in place
of wrap around bumpers on units
manufactured after August 1999.
26
20
21
FOR PARTS & SERVICE CALL 1 [phone]

DH07 / DH08
12
CONVECTED AIR DISH HEATERS
(9" Dishware)
DH08
EXPLODED VIEW DRAWING
21
20
Corner Bumpers are used in place
of wrap around bumpers on units
manufactured after August 1999.
26
FOR PARTS & SERVICE CALL 1 [phone]

13
ELEVATOR ASSEMBLY EXPLODED VIEW DRAWING
22
24
23
25
FOR PARTS & SERVICE CALL 1 [phone]

DH07 / DH08
14
CONVECTED AIR DISH HEATERS
(9" Dishware)
IX. PREVENTATIVE MAINTENANCE
WIRING DIAGRAM
CASTERS
1. Check casters for freedom of movement and proper brake retention.
2. Maintain casters free of debris. (mop strings, paper plastic, hair nets, etc.)
3. Clean or replace as required.
4. Replace caster when rubber tread is less than ¼" from rim.
CORD & PLUG
1. Inspect plug blades for distortion and replace if any blades are missing, bent or broken.
2. Inspect cord wiring for integrity at termination points by having qualied service person remove the
back panel from cabinet. Make sure the cord sheathing extends into the cabinet interior. If wires
are showing on the outside of the cabinet, remove the unit from use and have repairs made before
turning on power to the unit.
DISPENSING MECHANISM
1. Periodically check springs for proper dishware dispensing by lling each cavity with dishware and
checking to see that it indexes as dishes are removed. If dishes do not index properly, and unit is
not overloaded, replace springs.
FOR PARTS & SERVICE CALL 1 [phone]

15
X. SERVICE
In the event service is required on your Aladdin DH07 / DH08 Series Plate Heaters
please call:
ALADDIN TEMP-RITE SERVICE DEPARTMENT 1-800-888-5426
IX. PREVENTATIVE MAINTENANCE
XI. WARRANTY
ALADDIN TEMP-RITE®
EQUIPMENT
LIMITED WARRANTY
Effective August 1, 2005
Aladdin Temp-Rite®(“ATR”) warrants to the original purchaser that the equipment listed below shall be free from defects in material and
workmanship under normal use for the applicable warranty term set forth below. ATR’s obligation under this warranty is limited to the repair
or replacement, at the sole option of ATR, of any part which upon inspection and examination by ATR or its authorized agent is found to be
defective. A written description detailing the nature of the claimed defect, together with the equipment claimed to be defective if required by
ATR, must be delivered to ATR or its authorized agent within 30 days of discovery of the claimed defect (but in no event later than 30 days
after the expiration of the applicable warranty term).
EQUIPMENT
WARRANTY TERM
PARTS LABOR
DH07 1 Year 90 Days
DH08 1 Year 90 Days
*The warranty term commences 30 days after the date of ATR’s invoice for the equipment.
THE WARRANTIES AND REPRESENTATIONS OF ATR CONTAINED HEREIN ARE EXPRESSLY IN LIEU OF, AND THE BUYER
WAIVES, ANY AND ALL OTHER WARRANTIES EXPRESS OR IMPLIED, INCLUDING THE WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE, AND ANY OTHER REMEDIES AGAINST ATR, WHETHER BASED UPON CONTRACT,
NEGLIGENCE, STRICT LIABILITY OR OTHERWISE. ATR SHALL NOT BE LIABLE FOR ANY CONSEQUENTIAL OR INCIDENTAL
DAMAGES OR ECONOMIC LOSS OF ANY NATURE (INCLUDING WITHOUT LIMITATION LOSS OF REVENUES AND/OR PROFITS)
THAT MAY BE CLAIMED TO RESULT FROM ANY NEGLIGENCE OR BREACH OF WARRANTY OR CONTRACT BY ATR.
Exceptions and Exclusions
This warranty is issued only to the original purchaser, and is not transferable and applies only to the products installed within the United
States of America, its territories and Canada. During the term of any labor warranty, ATR will pay all pre-approved shipping charges
incurred in returning defective equipment to ATR and labor costs incurred in the removal and reinstallation of such equipment. Contact
ATR before returning any defective equipment or otherwise performing any warranty repairs. ATR assumes no liability for any work or
repair performed without its prior approval. After the expiration of any labor warranty, the original purchaser is responsible for all shipping
charges incurred in returning defective equipment to ATR and labor for removing and reinstalling such equipment. ATR shall not be
responsible for the replacement of expendable items like lamps and fuses or product failure resulting from normal wear and tear, improper
installation, misuse, sabotage, abuse, neglect, accident, unauthorized alterations to repair, or other factors beyond the control of ATR.
Neither this warranty, nor the liability of ATR may be modied or extended by action of any agent, distributor or other person or by custom
or practice.
CALL ATR TOLL FREE AT 1-800-888-5426 IF YOU HAVE ANY QUESTIONS ABOUT THIS WARRANTY OR YOUR ATR PRODUCT.
FOR PARTS & SERVICE CALL 1 [phone]

250 East Main Street, Hendersonville, TN 37075
1-800-888-8018 ● www.aladdintemprite.com ●[e-mail]
