Alba CMP322B User manual

MP3 player
With 4GB memory
Instruction manual
CMP322B/P

Page 1
Table of contents
Rechargeable battery disposal............................3
Accessories included........................................ 4
Overview of controls.........................................4
Getting started ...........................................5
Switching the unit ON/OFF................................6
Adding music.............................................6
Earphone connection.....................................7
Standby mode............................................8
Operation ................................................8
Play/Pause..................................................8
Skip tracks ..................................................9
Volume controls............................................. 9
Troubleshooting .........................................10
Care & maintenance .....................................11
Technical specifications .................................11
Disposal information ....................................11

Page 2
Safety information
Important – Please read these instructions fully before using.
CAUTION:TO REDUCE THE RISK OFELECTRIC SHOCK,DO NOT REMOVE
ANY COVER.NO USER-SERVICEABLE PARTS INSIDE,REFER ANY
SERVICING TO QUALIFIED SERVICE PERSONNEL.
• Please read this owner’s guide
• Please take the time to follow the instructions in this owner’s guide
carefully.It will help you set up and operate your system properly and enjoy
all of its advanced features.
• Please save this owner’s guide for future reference.
• The product label is located on the back of the product.
• Do not use this product near a bathtub,washbowl,kitchen sink, and
laundry tub,in a wet basement, near a swimming pool,or anywhere else
that water or moisture is present.
• Do not allow the product to be submerged in water. Do not expose
headphone socket or battery compartment to water,as water entering the
set may cause major damage.
• Only use attachments/accessories specified by the manufacturer.
• Unplug this apparatus during lightning storms or when unused for long
periods of time - to prevent damage to this product.
• Refer all servicing to qualified service personnel
• Servicing is required when the apparatus has been damaged in any way:
such as liquid has been spilled or objects have fallen into the apparatus;
the apparatus has been exposed to rain or moisture,does not operate
normally, or has been dropped -
• Do not attempt to service this product yourself.
• Opening or removing covers may expose you to dangerous voltages or
other hazards.
• To prevent risk of fire or electric shock,avoid overloading wall outlets,
extension cords,or integral convenience receptacles.
• Use suitable power sources - Plug the product into a suitable power
source,as described in the operating instructions or as marked on the
product.

Page 3
Safety information
Before making any electrical connections,ensure the following:
• Do not bend,stretch or pull the supply cable in order to avoid electric
shock.
• The supply voltage should be the same as that indicated in the technical
specifications and the appliance rating plate.
• Batteries shall not be exposed to excessive heat such as sunshine,fire or
the like.
•
Rechargeable battery disposal
Your product contains a built-in rechargable battery covered by the
European Directive 2006/66/EC.To safeguard the functionality and safety
of your product, always take your product to an official collection point or
service centre where a professional can remove the battery.
Please inform yourself about the local rules on separate collection
of batteries because the correct disposal will help prevent negative
consequences for the environmental and human health.Please do not
dispose of your batteries with your normal household waste.Always bring
your product to a professional to remove the battery.
This product complies with Electromagnetic compatibility (2004/108/EC)
directives.

Page 4
Functions & controls
Please familiarize yourself with the parts and accessories listed below.
Accessories included
• 1 x CMP322
• 1 x Instruction manual
• 1 x USB charging cable
• 1 x earphones
Overview of controls
1: Blue Power/Playback indicator LED
2: Earphone output (3.5mm)
3: ON/OFF switch
4: Mini USB charge/PC connection socket
5: Red charge status indicator LED
6: PLAY/PAUSE button
7: VOLUME + button
8: PREVIOUS button
9: VOLUME - button
10: SKIP button
8
1
3
24
10
6
7
9
5
8
1
3
24
10
6
7
9
5
8
1
3
24
10
6
7
9
5

Page 5
User instructions
Getting started
Before use the MP3 player will require charging fully.
Follow the below instructions to charge the MP3 player.
1: Using the usb charging cable connect the mini usb plug into the usb
charge socket (4) on the bottom of the unit.
2: Connect the other end of the cable to a laptop/pc usb input or
compatible usb mains charger.
3: Power on the pc/laptop or charger .
4: During charging the red charge led (5) will flash and when fully charged
go off.
NOTE:We strongly recommend charging only via pc/ laptop to
avoid irregular led status light operation.

Page 6
Switching the unit ON/OFF
To conserve battery life you can switch the unit off when not connected to
a power source.
1: Set the ON/OFF switch (3) to the ON position to power the unit ON. The
blue led (1) will illuminate.
2: To switch the unit OFF set the ON/OFF switch to the OFF position.The
blue led (1) will go off.
Adding music
Once the unit is charged or during charging (pc/laptop connection only)
you can copy MP3/WMA files to the MP3 player.
1: When the unit is connected to a pc or laptop a driver is automatically
installed and the device is then available in the list of devices (Named
CMP322_4G).
2: Copying MP3/WMA files is a simple as dragging & dropping files to the
device.During file transfer the blue led will flash quickly.
3: Should you have trouble finding the device, on a pc this can be found in
the ‘computer’ or ’my computer’ screen.
User instructions

Page 7
User instructions
Earphone connection
Instructions for earphone usage.
1: Connect the 3.5mm earphone plug into the EARPHONE socket (2) on
the unit.
2: When the volume is adjusted above 85dB an audible warning sound
will be heard to warn you of excessive sound pressure.This will not
be heard again until you lower the volume below 85dB and raise once
more.
To prevent possible hearing damage,do not listen
at high volume levels for long periods.
If you hear no sound during playback,do not turn
the volume up as the music may suddenly begin
at a high volume.
Excessive sound pressure from earphones and headphones can
cause hearing loss.
To avoid damaging your ears, adjust the volume to the lowest safe
level before playing, and turn up to the desired level when playback
has started.

Page 8
Standby mode
1: To enter standby mode press and hold the PLAY/PAUSE button (6).
The blue power led (1) will go off.
2: To wake the unit press and hold the PLAY/PAUSE button (6) once
more.The blue power led (1) will illuminate.
Operation
Follow the below instructions to begin operating the MP3 player.
Play/Pause
1:Press the PLAY/PAUSE button (6) to begin playback.During
playback the blue playback indicator will flash slowly
2: Press again to pause playback. During pause mode the blue playback
indicator will remain solid.
3: Should you wish to listen to music while charging you press the PLAY/
PAUSE button (6) to begin playback & press once more to pause
playback.
User instructions

Page 9
Skip tracks
1: To skip to the next track press the SKIP button (10).Press
repeatedly to skip several tracks at once.
2: To skip to the previous track press the PREVIOUS button (10).
Press repeatedly to skip several tracks at once.
Volume controls
1: To increase the volume level press the VOLUME + button (7).
2: To decrease the volume level press the VOLUME- button (9).
User instructions

Page 10
Troubleshooting
In the unlikely event of difficulties with your appliance please
follow the trouble shooting guide below.If the problem persists,
visit the technical support website: www.argos-support.co.uk
Problem Reason(s) Solution(s)
• No Power • The unit requires
charging
• Connect to a PC or laptop
using the supplied cable
to charge. Or purchase a
compatible USB mains
charger.
• No Sound • Volume is too low
• Playback is not
initiated
• No MP3 files have
been copied to the
internal memory
• The earphones have
not been connected
correctly
• Increase the volume
• Press the PLAY/PAUSE
button
• Follow ‘Adding music’
instructions on page 6 of
this manual
• Insert the 3.5mm
earphone plug into the
earphone socket on the
MP3 player
• Sound is
distorted
• Volume is too high • Reduce the volume
• Cannot
charge the
unit
• The ON/OFF switch
is set to the OFF
position
• Set the ON/OFF switch to
the ON position.
User instructions

Page 11
User instructions
Care & maintenance
All care and cleaning operations should be carried out with the unit
unplugged from the mains power.
Occasionally wipe the cabinet with a lint free duster. Never clean the unit
with liquids or solvents.
Technical specifications
Capacity:...........................................................4GB
Interface:....................................................... USB 2.0
Max playback time:................................................8 Hrs
Battery type: ..............................................3.7V 120mAh
File type supported: ............................MP1,MP2, MP3 & WMA
Operating system:...........................Windows 2000,XP or above
Dimensions:...........................D 8.3mm*W 28.6mm*H 59.5mm
Weight:............................................................14.6g
Disposal information
WEEE marking“Information for the consumer”Disposal of your
old product Your product is designed and manufactured with
high quality materials and components,which can be recycled
and reused.When this crossed out wheeled bin symbol is
attached to a product it means the product is covered by the
European Directive 2002/96/EC.Please make yourself aware of the local
collection system for electrical and electronic products.Please act
according to your local rules and do not dispose of your old products with
your normal household waste.The correct disposal of your old product will
help prevent potential negative consequences for the environment and
human health.
This product complies with European low voltage (2006/95/EC)
and electromagnetic compatibility (2004/108/EC) directives.

Guarantee
PRODUCT GUARANTEE
This productis guaranteed against manufacturing defects for a period of
Year
This product is guaranteed for twelve months from the date of original purchase.
Any defect that arises due tofaulty materials or workmanship will either be replaced,
refunded or repaired free of charge where possible during this period by the dealer from
whom you purchased the unit.
The guarantee is subjectto the following provisions:
The guarantee does not cover accidental damage, misuse, cabinet parts,knobs or
consumable items.
The productmust be correctly installed and operated in accordance with the instructions
contained in this manual.
It must be used solely for domestic purpose.
The guarantee will be rendered invalided if the product is re-sold or has been damaged by
inexpert repair.
Specifications are subject tochange without notice.
The manufacturer disclaims any liability for the incidental or consequential damages.
The guarantee is in addition to, and does not diminish your statutory or legal rights.
Guarantor: Argos Limited
489 - 499 Avebury Boulevard
Central Milton Keynes
MK9 2NW
