Alcatel-Lucent OmniTouch 4135 IP User manual
OmniTouch 4135 IP
Installation Guide
ENGLISH
110131-61-001 Rev 2a
This installation guide explains how to install the OmniTouch 4135 IP and make the basic
settings. For further instructions, please visit www.alcatel-lucent.com where you’ll nd a user
guide with full details of all the features as well as the “Installation and Administration of
OmniTouch 4135 IP” manual with a detailed description of all connection options and settings.
Connecting
Connect the OmniTouch 4135 IP
to the network with the provided
cable as illustrated below.
The OmniTouch 4135 IP is operated
directly from the network (Power over
Ethernet). If the network does not
supports this, a power adapter may be
purchased as accessory.
Place the conference phone in the middle
of the table.
The conference phone can be registered in a company SIP switch or PBX or with a public IP
telephony service provider. You can store settings for two accounts in the OmniTouch 4135 IP.
To register your phone, you must have access to the account information and all the settings that
the SIP switch or service provider requires.
Select Settings > SIP.
Enter the account information you have received.
Account name: Here you choose the name or phone number you want to appear in the
phone’s display.
Leave the default values if you have no other information.
Select a method of NAT traversal if this is required.
Save the settings by clicking the Save button.
The OmniTouch 4135 IP responds by showing REGISTERING. If the registration is successful, your selected
account name appears at the bottom of the display with a shaded square in front of it.
In some cases, it may also be necessary for you to make security settings on the Media tab.
See “Installation and Administration of OmniTouch 4135 IP”.
REGISTER AN ACCOUNT
SD memory card port
Expansion
microphone
port
Power supply
Security lock port
AUX port
Network cable port
Expansion microphone port
The OmniTouch 4135 IP must obtain a network address and be registered in a SIP switch (or
PBX) before it can be used. The easiest way to register an account and make the settings in the
OmniTouch 4135 IP is to use a PC connected to the same network and use the integrated web
server of the OmniTouch 4135 IP.
Obtaining a network address
When the conference phone is connected to the network, it usually automatically gets a network
identity (IP address) via the network’s DHCP function. If DHCP is not used in the network, please
refer to “Installation and Administration of OmniTouch 4135 IP” for instructions on setting a
static IP address.
Checking the network address
Press MENU and select the sub menu STATUS > NETWORK.
Read the quick reference guide if you want help navigating the menu system.
Check the conference phone’s network address under the heading IP ADDRESS.
Use this address to log into the web server in the conference phone.
Login
Log into the OmniTouch 4135 IP web server by entering the phone’s network address in your
computer’s web browser.
Select Admin as Prole and enter your PIN code.
The default PIN code is 1234.
GETTING STARTED
These settings should be done during the installation. A full description of all the options is given
in ”Installation and Administration of OmniTouch 4135 IP”.
Setting time and region
Select Settings > Time & Region.
Select the time zone and if you want correction for DST (Daylight saving).
It is also possible to set the time and date manually or choose a different time server.
Select the region where you are.
This setting affects the tone generation.
Save the setting.
The OmniTouch 4135 IP reboots with the new settings.
Changing the language
Select Settings > Basic.
Select the language you want from the list after Language and save the setting.
Changing the PIN
We recommend that you change the PIN code for Admin from the default setting to protect the
settings. Make a note of the new PIN code and keep it in a safe place. The administrator’s PIN
code can only be reset with a complete reset to factory settings!
Select Settings > Basic and click the Edit button on the Admin line.
Enter a new PIN code.
The PIN code may consist of 8 digits.
Click on the Set and Save buttons.
BASIC SETTINGS
