The Alcatel-Lucent OmniAccess™8550 Web Services Gateway (WSG) rotects sensitive information from misuse satisfying
regulatory com liance requirements and makes business rocess data available when and where it is needed. The
OmniAccess 8550 WSG rovides a cor orate wide com liance infrastructure for secure automated business rocesses
within a com any and among its artner organizations. The OmniAccess 8550 WSG is a service oriented network
a liance that reduces the traditional com lexity and cost of securing internal cor orate and business-to-business
(B2B) automated business rocesses.
Alcatel-Lucent OmniAccess 8550 Web Services Gateway
The OmniAccess 8550 WSG, based on
the Alcatel-Lucent Web services run-time
message inspection technology, provides
a scalable and reliable service oriented
infrastructure for information system
in such areas as human resources,
enterprise resource planning (ERP),
customer relationship management
(CR ), and finance with security
and regulatory compliance (policy
enforcement and audit trail) that is
required for secure business process
automation. It is deployable within data
centers to secure business processes
within an organization and in the D Z
for automating business processes
with partners. The OmniAccess 8550
WSG provides a significant competitive
advantage by reducing IT system total
cost of ownership (TCO).
Product Features
The deployment of an OmniAccess
8550 WSG provides corporate-wide
security and regulatory compliance so
organizations can secure automated
business processes to meet increased
government regulations and safely
automate business processes with
partners, creating a secure automated
partner ecosystem.With the OmniAccess
8550 WSG securing business processes,
highly skilled employees have access
to information whenever they require
it, even when at a partner site.
The OmniAccess 8550 WSG also provides
unique, stateful (multi-transaction),
run-time policy enforcement and
consolidated audit trails to ensure
and demonstrate compliance with
government regulations (see Figure 1).
The OmniAccess 8550 WSG also has
the ability to mitigate risk through
consistent policy enforcement across
information systems with a user
contextual knowledge of system events.
To protect private data, the OmniAccess
8550 WSG provides information access
and change control as well as data
encryption with digital signatures.
This enables a single digital identity
within an organization that accepts
authentication from trusted partners—
the foundation for a consolidated
corporate-wide access policy.
Secure B2B processes are further
enhanced by the OmniAccess 8550
WSG through security features such
as the application firewall and auditing,
tracking and control functions that can
be used to monitor all partner activity,
including access to information by
partner employees when on-site.

2Alcatel-Lucent 8550 Web Services Gateway
protect the internal domain and ensure
data security.
Alternatively, the OmniAccess 8550 WSG
can be installed in the data center to
secure business processes within the
organization. It allows information
access policy to be consistently enforced
at run time across information systems
and can demonstrate regulatory
compliance through a user centric
consolidated audit trail. Risk is mitigated
with the proper controls and monitoring
points in place as well as through
consistent policy enforcement across
information systems with a user
contextual knowledge of system events.
Deployment architecture
The OmniAccess 8550 WSG is designed
to be deployed in the D Z of an
organization to secure business process
automation with partners (see Figure
2). The OmniAccess 8550 WSG is
typically installed behind the IP firewall
and provides service virtualization as
well as key security functions to
HQ Office
Intranet
ExtranetIdentity Management
Business Applications
Datacenter
Strategic Partner
Customer
OA8550
WSG
OA8550
WSG
OA8550
WSG
OA8550
WSG
OA8550
WSG
OA8550 Web Services Gateway
Run time stateful
policy enforcement
Identity mapping
and federation
Consolidated
audit trail
Figure 1. Core OmniAccess OA8550 WSG features
Figure 2. Typical OmniAccess 8550 WSG network deployment

3Alcatel-Lucent 8550 Web Services Gateway
Threat protection
&
XML firewall
Protects from
deliberate attacks and
malicious XML messages
XML message validation Ensures all messages are well formed
XML message control SQL Injection, Recursive Payload, Oversized Payload, Buffer Overflow,
External Entity Attacks, Oversize Attachments, Cross Site Scripting
Denial of service (DoS)
protection Prevents DoS attacks focused at web services, replay attacks
Management
Easily managed appliance
integrating with existing
management
platforms
Fault management SNMP reporting to enterprise network management platforms
Configuration management Provides Web-based G I interface with role based management control
Change management Enforces policy and configuration privileges by role and provides audit of all
policy and configuration changes
Secure hardware
accelerated
appliance
Hardened appliance to
comply with
security standards
High availability Provides automatic stateful failover for paired nodes
Open standards compliant Compliance with Web services standards W3C, SOAP, DDI, WS-Policy,
WS-Trust, WS-Security, WS-Reliable Messaging, WS-Addressing
Secured appliance
No direct operating system access - encrypted hard drive - no internal
devices allow for alternate re-boot of system - all ports disabled -
configuration files digitally locked.
Dedicated Web services
infrastructure
Hardware accelerated XML parsing & encryption with digital signing & SSL
& HTTPS
Feature group Benefit Feature Feature description
Security
&
governance
Ensures compliance
with corporate
governance policy and
government legislation
Application sessions Stateful model for Web service run-time policy
Stateful run-time policy enforce-
ment Run-time policy enforced across multiple transactions per credentialed user
ser-centric audit trail Consolidated audit trail capturing each information record viewed or modified
per credentialed user, encrypted and signed to survive legal audit
Application access control Stateful policy enforcement on access to individual Web services
Information access control Stateful policy enforcement on access to individual information records
Secure online
B2B
Enhanced security
through single point of
control to enable secure
automated workflow
among business partners
Partner authentication Strong authentication for partner institutions (X509, XKMS, RSA, 3DES, DES,
AES, SHA, PKCS, CRLs, OCSP)
Service virtualization Map external RL used by partners to private internal RL
Secured proxy point Stateful policy enforcement with cross-referenced audit on all partner activi-
ty
Data protection Data encryption and digital signing to survive legal audit
ser mobility Enables end users to seamlessly connect to web services at any partner site
Multiple partner groups Allows web services to be offered to distinct partner groups
Identity
mapping
&
federation
Consistent enterprise-
wide enforcement
of policy per
credentialed user
Single identity
Dynamic identity translation allowing access to multiple IT
systems with single credential for corporate-wide consistent policy enforce-
ment
Identity interoperability Enables acceptance of user validations from partners while meeting all
traceability and user privacy requirements (SAML, WS-Trust)
Integration with existing identity
infrastructure
Integrates with existing identity management infrastructure (LDAP, SAML,
WS-Trust)
Corporate
agility
Enables scaleable and
reliable re-use
of existing IT systems
Application interoperability Provides mediation through message and content translations for applica-
tions (XSLT)
Web service load balancing Provides round robin load balancing with session stickiness and automatic
failover
Reliable messaging Provides policy-controlled, guaranteed delivery of web service messages

www.alcatel-lucent.com
Alcatel, Lucent, Alcatel-Lucent and the Alcatel-Lucent logo are trademarks of Alcatel-Lucent. All other
trademarks are the property of their respective owners. Alcatel-Lucent assumes no responsibility for
the accuracy of the information presented, which is subject to change without notice.
© 2008 Alcatel-Lucent. All rights reserved. P/N 031953-00 Rev C 10/08
System configuration
The Alcatel-Lucent OmniAccess 8550 WSG is a
high–performance, 2U, rack-mountable network
element consisting of:
• Two Quad-Core Intel E5345 Xeon processors
(2.33 GHz, 80 watts, 1333 FSB), each with 8
B of L2 cache
• 8 GB of CPU memory with advanced ECC
(multi-bit error) protection
• 146 GB hot-pluggable hard drives with RAID1
SAS disk array
• Fully redundant power supplies
• Fully redundant fans
• Six 10BaseT/100BaseTX/1000BaseTX network
interfaces that support bonding for redundancy
• Built-in high-performance SSL/TLS and crypto-
graphic hardware
• Built-in high-performance X L processing
hardware
• Front panel hardware alarm indicators
• Includes universal rail kit for 19-inch racks
Physical dimensions
• Height: 3.38 in. (8.59 cm.)
• Width: 17.54 in. (44.54 cm)
• Depth: 23.65 in. (60.07 cm)
• Weight: 60 lb (27.22 kg)
Power Specifications
• Input (per power supply)
¬ Line voltage: 100 VAC - 132 VAC
200 VAC - 240 VAC
¬ Input current: 3.3 A (at 120 VAC)
2.3 A (at 220 V AC)
¬ Input power: 370 W (at 120 VAC)
470 W (at 220 VAC)
• BTU rating max: 1272 (for 120 VAC)
1610 (for 220 VAC)
Standards compliance
• WSR 1.1
• WSS 1.0
• WSS-Signature
• WSS-Encryption
• WS-Trust
• WSSE 1.0
• WSDL 1.1
• SOAP 1.1/1.2
• XSLT 1.0
• XPath 1.0
• UDDI 3.0
• HTTP 1.0/1.1
• TLSv1/SSLv3
• DES, 3DES, AES, RC4, SHA-1, D5, PKCS #10,
X.509, RSA, DSA
• LDAP 3.0
• SA L 1.1
• SN P
• SFTP
• IEEE 802.3, 802.3u, 802.3ab
Regulatory
EEMMCC
ICES-003 Interference causing equipment standard for digital apparatus
FCC Part 15 Class B FCC rules for radio frequency devices under FCC 15 of the rules of FCC
EN55022, Class A/B Information technology equipment (ITE) - Radio disturbance characteristics - Limits and methods of
measurement - Class A/B
EN55024 ITE - Immunity characteristics - Limits and methods of measurements
CISP 24 ITE - Immunity characteristics - Limits and methods of measurements
AS/NZS CISP 22 Limits and methods of measurement of radio disturbance characteristics of information
technology equipment
SSaaffeettyy
CAN/CSA C22.2 No 60950-1-03 / UL 60950-1 ITE - Safety - Part 1: General Requirements
FDA 21 CF 1040 Performance Standard for Light-Emitting Products
IEC 60825-1 (2001) Safety of laser products - Part 1: Equipment classification, requirements and user's guide.
IEC 60825-2 (2000-05) Safety of laser products - Part 2: Safety of optical fiber communication systems
EN60950-1 Safety of information technology equipment
IEC 60950-1 Information technology equipment - Safety - Part 1: General requirements
AS/NZS 60950-1:2001 Approval and test specification - Safety of information technology equipment including electrical
business equipment
TTeelleeccoomm
IEEE 802.3 Carrier Sense ultiple Access with Collision Detection (CS A/CD) access method and
PHY Layer Specification
EECC DDiirreeccttiivveess
OHS 2002/95/EC Directive 2002/95/EC of the European Parliament and of the Council of 27 January 2003 on the Restriction of the use
of certain Hazardous Substances in Electrical and Electronic Equipment (ROHS)
Technical s ecifications
