Alcatel-Lucent 8410D User manual

1
About Your Telephone
Your 8410D is a multi-appearance digital telephone. The display, along with the softkeys and display control buttons,
offers valuable added functionality. To familiarize yourself with the buttons and features on your 8410D telephone,
refer to the figure below and then read the following explanations.
Call appearances/feature buttons
At least three of these 10 buttons are devoted to incoming and outgoing calls (call appearances) and are labeled
with an extension number; the remaining buttons access features (feature buttons) and are labeled with a
feature name. Each has a red light telling you this is the line you are using or this is the line you will get when
you lift your handset. The green status light next to each call appearance and feature button tells you the line
or feature is being used.
Conference button
For setting up conference calls. This button is labeled <Conf>.
Dial pad
The standard 12-button pad for dialing phone numbers and accessing features. The letters “Q” and “Z” have
been added to the appropriate dial pad keys for directory access, and the “5” button on your dial pad has raised
bars for visually-impaired users.

2
Display
A 2-line by 24-character display.
Display control buttons
These four buttons are labeled Menu, Exit, Prev, and Next.
• <Menu> is used to enter Softkey Mode and access the first feature option screen.
• <Exit> is used for exiting the Display Mode and returning to Normal (call-handling) Mode.
• <Prev> and <Next> can be used to help you go back and forth through the feature option screens.
Drop button
For disconnecting from a call or dropping the last party added to a conference call.
Handset
A handset is provided for placing and receiving calls. (The handset is also known as the receiver.) In most
cases, you must lift the handset (go off-hook) or activate the speaker or speakerphone before you can use a
feature.
Handset jack
Located on the back of your telephone, this jack is used for connecting the handset.
Hold button
A red button for putting a call on hold.
Line jack
This jack is used for connecting a line cord to your telephone. Located on the back of your telephone, this jack
is labeled “LINE.”
Message light
A red light which goes on steadily when a message has been left for you.
Mute button
For turning off the microphone associated with the handset or the built-in speakerphone so the other person on
the call cannot hear you.
Ring button
A button you can use to select a personalized ring for your telephone from eight possible ringing patterns.
Softkeys
The four buttons located below the display and labeled with arrows correspond to words on the display screen.
You can use the softkeys along with display control keys to access up to 12 features on your telephone in
addition to those features administered on the call appearance/feature buttons. For a list of the features that can
be accessed with the softkeys, check with your system manager.
Speaker button
For accessing the built-in 2-way speakerphone.
Speakerphone/headset adapter jack
Located on the back of your telephone, this jack is used for connecting an external speakerphone (such as an
S101A or S201A Speakerphone) or a headset adapter (such as a 500A Headset Adapter).

3
Test button
When the telephone is initially powered up, the green light next to <Test> flashes if the link with the switch is
not (or not yet) operational. The light changes to steady green when the telephone is able to communicate with
the switch, and then goes off after a short period of time. After the telephone is powered up, you can press
<Test> to test the lights and the display on your telephone.
Transfer button
For transferring a call to another telephone.
Volume control button
For adjusting the volume of the following:
• The speakerphone when a call is in progress using the 2-way speakerphone
• The handset receiver level while a call is in progress using the handset
• The tone ringer when the speaker is off and either the handset is inactive or the tone ringer is active
Note: The Volume control button on your telephone does not control the volume level of adjunct
equipment.

4
Conventions
Conventions Used in Procedure Descriptions
<xxxxx> This represents a call appearance button, which is used exclusively for
placing or receiving calls. The button has a red light and a green status
light and is labeled with an extension number (shown as xxxxx).
<Feature> and <Feature xxxxx> Each of these represents a button that has a feature assigned to it. The
button is labeled with the feature name, sometimes followed by an
extension number (shown as xxxxx) or a person's name.
Prog Pause Mark Wait This rectangular box, 2 lines by 24 characters, represents the 8410 display
screen. Like the example to the left, the second line appearing on the
display will most likely list the features you can access with the softkeys.
[feedback tones] The tone that appears in brackets after a step indicates what you should
hear from your handset (or speakerphone) after successfully performing
that step. Click for a sample.
Special Instructions
Use the following special instructions for operating your telephone.
1The first time you use these procedures, you will need to customize them for yourself by obtaining the following
information from your system manager:
• Your system manager may assign call appearances or features to the 10 call appearance/feature buttons on your
telephone. You may also be able to use up to 12 other features accessed with the softkeys and display control
buttons. These features are in addition to the features that are administered on the call appearance/feature
buttons on your telephone. Check with your system manager to see which softkey features are available to
you.
• You may also be able to use the Speakerphone or the Speaker feature. Check with your system manager to see
what other features you can use with your switch.
• Any feature not appearing on a button or accessed with the display and softkeys can be activated or canceled
by dialing a 1-, 2-, or 3-digit feature access code. Call x3045 for the feature access codes for the features you
need.
2To operate a feature, you must have the handset off-hook (removed from the cradle of the telephone) or the speaker
or speakerphone on unless otherwise noted.
3If you receive an intercept tone (high-pitched, alternating high and low tone) while attempting to operate any
feature, you have taken too much time to complete a procedural step or have made a dialing error. Hang up, get
dial tone, and begin again at Step 1.

5
Feature Finder
Abbreviated Dialing (AD)
Allows you to store selected telephone numbers for quick and easy dialing. Each number can be a complete or
partial telephone number, an extension number, or a feature code. Numbers on your personal list are
programmable by you. Use as a timesaver for dialing frequently called, lengthy, or emergency numbers.
Audix Message Light
Turns on your Message light to let you know that a caller has left an Audix message for you. You can then
follow Audix instructions to get your message.
Automatic Callback
Sends you a special 3-burst ring indicating a previously busy or unanswered extension you dialed is now
available. Use to avoid constant redialing when you wish to speak to someone who is frequently busy on the
telephone or in and out of the office.
Note: You can use this feature only for extensions, not for outside numbers.
Call Coverage/Consult
Provides automatic redirection of certain calls to your telephone for answering. (Your system manager
determines redirected call routing.) Use to answer calls for other extensions for whom you provide coverage.
Note: If you are a covering user, you can use the Consult feature, after answering a coverage call, to
call the principal (the person for whom you are answering calls) for private consultation. Then,
you can add the calling party to the conversation, transfer the call to the principal, or return to the
calling party.
Call Forwarding All Calls
Temporarily forwards all your calls to another extension. Use when you will be away from your telephone and
you want your calls to be forwarded to a telephone number of your choice.
Call Pickup
Lets you answer a call at your telephone for another extension in your pickup group. Use when you wish to
handle a call for a group member who is absent or otherwise unable to answer.
Note: You can use this feature only if you and the called party have been assigned to the same pickup
group by your system manager.

6
Conference
Allows you to conference up to six parties on a call (including yourself) so you can conduct a 6-way
discussion. Use to set up timesaving conferences, or to spontaneously include an additional party important to
a conversation.
Directory
Searches for the extension of another user in your location by allowing you to key in the user's name with the
dial pad. Use as a handy quick reference source for extension number information.
Display Feature
This section includes the procedures for seven display features you may use with the 8410D telephone.
However, note that the display, along with the softkeys and display control buttons, can also be used for
accessing up to 12 softkey features.
Call Information <a= > it represents call information for the first call appearance button. The next button down would
be shown as <b= >, and so on, continuing through <j= > if all 10 of the buttons are used for call appearances.
When you dial an extension, that number is shown and then replaced by the called party's name and extension. When a
call is received from another extension, the caller's name is shown; when a call is received from outside, “OUTSIDE
CALL” or a trunk identifier is shown.
The display remains in Normal (call-handling) Mode until you activate one of the other display or softkey features.
After using any of these features, return to Normal (call-handling) Mode by pressing <Exit>.
Display, Softkeys, and Display Control Buttons
The softkeys are the four keys labeled with arrows located directly below the display. The four display control
buttons, labeled <Menu>, <Exit>, <Prev>, and <Next> are located under the softkeys.
Drop
Disconnects from a call without requiring you to hang up the handset, turn off the speakerphone, or press the
switchhook. Can also be used with the Conference feature to disconnect the last party added. Use whenever
you want to continue using the handset or speakerphone after ending a call.
Exit
Use <Exit> to leave Display Mode (after using any display or softkey feature) and return to Normal (call-
handling) Mode. Once you are in Normal Mode, you can use the display to identify current call appearance,
calling/called party, and calling/called number.
Handset Volume
Allows you to raise or lower the receive level volume of the handset.

7
Hold
Puts a call on hold until you can return to it. While a call is on hold, you can place another call, activate
another feature, answer a waiting call, or leave your telephone to do another task. Use when you have a call
you don't want to drop, but have to interrupt briefly to do something else.
Inspect
Shows you call-related information for an incoming call when you are already active on a call. Use to identify
and screen new calls.
Last Number Dialed
Automatically redials the last extension or outside number you dialed. Use to save time in redialing a busy or
unanswered number.
Mute
Allows you to turn off the microphone of the built-in speakerphone or the handset. Use when you want to
confer with someone in the room with you, but you do not want the other person on the call to hear your
conversation.
Normal Display
Use <Exit> to leave Display Mode (after using any display or softkey feature) and return to Normal (call-
handling) Mode. Once you are in Normal Mode, you can use the display to identify current call appearance,
calling/called party, and calling/called number.
Ringer Volume
Allows you to adjust the ringer volume on your telephone.
Select Ring
Allows you to choose your own personalized ringing pattern for your telephone from among eight available
patterns. Use to help distinguish your incoming calls from those of other nearby telephones.
Self-Test
When the telephone is initially powered up, the green light next to <Test> flashes if the link with the switch is
not (or not yet) operational. The light changes to steady green when the telephone is able to communicate with
the switch, and then goes off after a short period of time. After the telephone is powered up, you can press
<Test> to test the lights and the display on your telephone.
Send All Calls
Temporarily sends all your calls to Audix or to the extension of a person designated by your system manager to
answer them when you cannot (perhaps a secretary or receptionist). Use when you will be away from your
desk for awhile, or when you do not wish to be interrupted by telephone calls.

8
Speakerphone
Allows you to place and answer calls or access other voice features without lifting the handset. Use the built-in
speakerphone any time you prefer hands-free communication, both speaking and listening, or for group
conference situations.
Stored Number
Allows you to check the number stored on an Abbreviated Dialing button or as an item on an Abbreviated
Dialing list. Also lets you see what number you last dialed (via Last Number Dialed feature). Use to verify
Abbreviated Dialing list items before placing a call or reprogramming a number, and to make sure the Last
Number Dialed feature is appropriate to use.
Time/Date
Shows you the date and time. Use as a handy calendar and clock.
Timer
Allows you to measure elapsed time. Use in order to keep track of time spent on a call or task.
Transfer
Transfers a call from your telephone to another extension. Use when your caller needs to speak further with
someone else.

9
Abbreviated Dialing
Note: Before you can use this feature, AD buttons must first be assigned by your system manager. (These AD
locations can be assigned to actual buttons, or you may be able to access them with the softkeys.)
If you hear the intercept tone while programming, start over from the beginning.
You may be able to use the following softkey features with Abbreviated Dialing (Press <Menu> and then the softkey
below the feature abbreviation):
• Program (labeled Prog) - You can program a telephone number, extension, or feature access code on an AD
button.
• Pause (labeled Pause) - A 1.5-second pause can be placed in an AD number, such as between an access code
and the telephone number.
• Mark (labeled Mark) - Numbers included after a Mark on an AD button are dialed in Touch-Tone signal
form.
• Wait (labeled Wait) - Numbers included after a Wait on an AD button are delayed 5 to 25 seconds until the
telephone receives dial tone from the switch.
• Suppress (labeled Spres) - Suppressed numbers are dialed but not shown on the display (an “s” appears
instead). Used for passwords or authorization codes.
To program or reprogram an AD button
1On a separate sheet of paper, write down the outside numbers, extensions, and/or feature access codes you want to
program.
Note: Each AD button will hold one complete phone number or feature access code.
2Pick up the handset. [dial tone]
3Press <Menu> and then press the softkey below Prog.
If Prog is not available on your display, press <Program> or dial the Program code *0. [dial tone]
4Press <AD xxxxx> to be programmed. [dial tone]
5Dial the outside number, extension, or feature access code you want to store (up to 24 digits).
Notes: 1) You may be able to use the softkeys to add special functions such as Pause, Mark, or Wait into
the telephone numbers programmed on the AD button.
2) If you are programming an outside number, be sure to include a leading 9 or 8, if applicable.
6Press <#>. [confirmation tone]
• The number is stored.
7Repeat Steps 4 through 6 to program additional buttons.
8Hang up or press <Drop> to end the programming.

10
To place an AD call
1Press the selected <AD xxxxx>. [ringback tone]
• The call is automatically dialed.
Note: Before you can use this feature, AD buttons must first be assigned by your system manager.
A programmed number in your personal list can be up to 24 digits and characters. You can also program a number on
an Automatic Dialing button that is not stored in your personal list. This programmed number can be up to 16 digits
and characters. Each digit counts as one character; special characters, such as pause and suppress, count as two
characters. The Automatic Dialing button can be used for one-touch dialing of frequently called numbers.
To program or reprogram an outside number, extension, or feature code into a personal list
1On a separate sheet of paper, write down the outside numbers, extensions, and/or feature access codes you want to
program as items on your personal lists(s).
Note: Each telephone number or feature code is stored as a separate list item.
2Pick up the handset. [dial tone]
3Press <Menu> and then press the softkey below Prog.
or press <Program> or dial the Program Personal List code *01. [dial tone]
4Dial the list item (0, 1, 2…). [dial tone]
5Dial the number you want to store (up to 24 digits).
Note: You may be able to use the softkeys to add special features such as Pause, Mark, or Wait into the
telephone numbers programmed on the AD button.
If you are programming an outside number, be sure to include a trunk code, if applicable.
6Press <#>. [confirmation tone]
• The number is stored.
7Repeat Steps 5 through 7 if you want to program additional items.
9Hang up or press <Drop> to end programming.
Note: Keep a copy of your own personal lists.
To place a call using an AD list button or code
1Press <Pers List> [dial tone]
or dial the Personal List feature access code *7
2Dial the desired list item (0, 1, 2…).

11
[ringback tone]
• The call is automatically dialed.
Audix
To retrieve a message when your Message light is on
1See the Audix Documentation for instructions.
Automatic Callback
You can access this feature with the softkeys only if the feature's abbreviation, AutCB, appears on the second line of
one of the feature option screens.
To automatically place another call to an extension that was busy, did not answer, or returned a call waiting
ringback tone
1Press <Menu> and then press the softkey below AutCB during the call attempt or, if AutCB is not available on
your display, press <AutoCallBk> during the call attempt. [confirmation tone]
Note: If you send your calls to coverage after activating Automatic Callback, your callback calls will
still ring at your extension and will not be redirected to coverage.
2Hang up.
• You will get a 3-burst ring when both you and the called extension are idle; when you answer, regular ringing
is sent to the called party.
3Lift the handset when you hear the 3-burst ring.
Note: Automatic Callback is automatically canceled after 30 minutes.
To cancel Automatic Callback
1While on-hook, press <Menu> and then press the softkey below AutCB again or, if AutCB is not available on
your display, press <AutoCallBk> again (while on-hook).
Call Coverage
You can access the Consult feature with the softkeys only if the feature's abbreviation, Cnslt, appears on the second line
of one of the feature option screens.

12
To answer a call for a coworker for whom you are a coverage point
1Press <xxxxx> of the incoming call when the ringing begins or the green light flashes.
Note: The call is not at your telephone until the green light is flashing.
To leave a message for a coworker to call the original caller's extension
1Press <Cvr CallBk> while connected to the call. [confirmation tone]
To talk privately with a coworker after answering a redirected call
1Press <Transfer>. [dial tone]
• The call is put on hold.
2Press <Menu> and then press the softkey below Cnslt or, if Cnslt is not available on your display, press
<Consult> or dial your coworker's extension. [3-burst ring to coworker]
3You can privately discuss the call; if your coworker is not available, press the fluttering <xxxxx> to reconnect the
call.
4Press <Transfer> again to send the call to your coworker or press <Conf> to make it a 3-party call.
Call Forwarding All Calls
You can access this feature with the softkeys only if the feature's abbreviation, CFrwd, appears on the second line of
one of the feature option screens.
To temporarily redirect all calls to an extension of your choice
1While on-hook or off-hook, press <Menu> and then press the softkey below CFrwd or, if CFrwd is not available
on your display, press <Call Fwd> (while on-hook or off-hook) or dial the Call Forward code *2 (while off-hook).
[dial tone]
2Dial the extension or number where the calls will be sent. [confirmation tone]
Note: Some telephones have restrictions on where calls can be forwarded (see your system manager).
3Hang up.
Note: You may hear a ring-ping tone from your telephone as each call is forwarded.

13
To cancel Call Forwarding
1While on-hook, press <Menu> and then press the softkey below CFrwd [dial tone]
or, if CFrwd is not available on your display, press <Call Fwd> (while on-hook) or dial the Call Forward Cancel
code #2 (while off-hook). [confirmation tone]
• Your calls will now ring at your own telephone.
Call Pickup
You can access this feature with the softkeys only if the feature's abbreviation, CPkUp, appears on the second line of
one of the feature option screens.
To answer a call placed to a member of your pickup group when your telephone is idle
1Press <Menu> and then press the softkey below CPkUp or, if CPkUp is not available on your display, press
<CallPickup> or dial the Call Pickup code #4.
• You are connected to the ringing call.
Conference
To add another party to a call (for a total of up to six parties)
1Press <Conf>. [dial tone]
• The present call is put on hold, and you are given a new call appearance; all of the other parties remain
connected to each other.
2Dial the number of the new party and wait for an answer.
3You can privately discuss the call with the new party at this time; if there is no answer or the line is busy, press the
fluttering <xxxxx> to return to the held call.
4Press <Conf> again.
• All parties are now connected.
5Announce the call.
6Repeat Steps 1 through 5 for additional conference connections.
To add a call you have put on hold to another call to which you are connected
1Press <Conf>.

14
[dial tone]
• The held call light continues to flutter; the current call light also flutters.
• You are given a new call appearance.
2Press <xxxxx> of the call on hold (first call).
3Press <Conf> again.
• All parties are now connected.
4Announce the call.
To drop the last party added to a conference call
1Press <Drop>.
• The last party you added is dropped.
• You remain connected to the other parties.
Note: The parties other than the last one must disconnect to be released from the conference call.
Directory
You can access this feature with the softkeys only if the feature's abbreviation, Dir, appears on the second line of one of
the feature option screens.
To search the directory for a name
1Press <Menu> and then press the softkey below Dir or, if Dir is not available on your display, press <Directory>.
2Key in the selected name using the dial pad: last name, comma (use <*> ), first name or initial.
3Press <Next Msg> for each successive directory name you wish to see.
4To search for a new name, begin again at Step 1.
5To exit the directory, press <Exit>.
To place a call to the name shown
1Lift the handset.
2While the name is shown, press <Call Disp>.
Note: You can also leave your handset on-hook. The speakerphone will turn on automatically when
you press <Call Disp>.

15
Display, Softkeys, and Control Buttons
Entering Softkey Mode and Viewing the Three Feature Option Screens
There are three separate feature option screens. Each of these screens allows you to select from four different features.
You can enter Softkey Mode by pressing the display option button labeled <Menu>. The following is an example of a
feature option screen.
Prog Pause Mark Wait
The top line of each feature option screen shows you the status of each of the four features. An arrow appears above the
feature name or abbreviation if that feature is active. If there is no arrow above the feature, the feature is not active.
Note: If the feature requires you to dial a telephone number or extension, such as Call Forwarding, you will
temporarily see the digits you are dialing, rather than the arrow, above the feature name.
The second line on each feature option screen shows the features you can access. To use any of these features, you
must press the softkey below the feature name or abbreviation. For example, on the feature option screen shown
previously, you can insert a .5 second pause (or multiple pauses) into an autodial number by pressing the softkey below
Pause during programming. Pressing the Pause softkey repeatedly will insert a longer pause.
To see the next set of four features, press the display control button labeled <Next>; to move back a screen, press the
display control button labeled <Prev>. Press <Next> or <Prev> until the feature you want to use appears on the second
line.
Note: An error tone (one beep) sounds when you have made a mistake in your softkey entries.
Press <Exit> at any time to exit softkey mode and return to Normal (call-handling) Mode.
Other Softkey Features That May Be On Your Display
Other options that might be available on your softmenu are
Abbreviation Feature
AD Abbreviated Dialing (can be multiple buttons)
AutoCB Automatic Callback
CFrwd Call Forwarding All Calls
Cnslt Consult
Count ACD Stroke Count (can be up to 10 buttons)
CPkUp Call Pickup
Dir Directory*
Excl Manual Exclusion
HFAns Internal Auto Answer
Inspt Inspect
Last Last Number Dialed
RngOf Ringer Off
SAC Send All Calls
SFunc Abbreviated Dialed Special Function

16
Spres Abbreviated Dialing Suppress
Stats ACD Agent Statistics
Stop Abbreviation Dialing Stop/ Indefinite Wait
Timer Timer
TmDay (or DayTm) Date and Time
View Stored Number
* A <Call Display> button should be administered if access to System Directory is provided. It is also desirable for
<Next Display> to be administered.
Using the Softkeys to Activate a Feature
Your display and softkeys allow you to access up to 12 switch-related features. For example, you may want to use the
Call Forwarding All Calls feature to send all your calls to another extension while you are away from your phone. You
can activate this feature with the softkeys in the following way:
To access a feature with the softkeys (Call Forwarding All Calls is used in this example)
1Press <Menu>.
• The display shows the initial feature option screen:
LWC CnLWC AutCB Timer
2Press <Next>.
• The display shows:
CFrwd CPark TmDay PCall
3To use the Call Forwarding All Calls feature, press the softkey below CFrwd and then dial the extension to which
your calls should be forwarded.
Note: When the feature is activated, after the display screen shows you the digits you are dialing, an
arrow appears above the feature. If there is not an arrow above the feature, the feature is off.
When you wish to cancel Call Forwarding All Calls, press the softkey under CFrwd again. The arrow above
CFrwd (showing feature status indication) disappears. Your calls will no longer be forwarded
Drop
To disconnect from a normal call and obtain dial tone without hanging up the handset
1Press <Drop>. [dial tone]
Note: If you press <Drop> during a conference call, the last party added will be dropped, and you will
remain connected to the other parties.

17
Exit
To exit any display feature and return to normal display
1Press <Exit>.
• The display shows call information for the active call appearance.
Handset Volume
To raise or lower the receive level volume of the handset
1While handset is off-hook, press the Volume control button.
Press the right half of the Volume control button to raise the volume. Press the left half of the Volume control
button to lower the volume.
• The display shows:
HANDSET L >>>>> H
There are eight possible volume settings. One arrow is the lowest setting, and eight arrows is the highest setting.
Hold
To put a call on hold while you answer another call, make a call, or perform some other task
1Press <Hold>.
• The green light next to the held call flutters.
Note: If you put a conference call on hold, the other parties remain connected.
To return to the held call
1Press <xxxxx> of the held call.
• You are connected to the held call.
Note: If you are active on a call and you press the <xxxxx> of the held call, the active call will be
dropped.

18
To answer a new call while active on another
1Press <Hold>.
• The green light next to the held call flutters.
2Press <xxxxx> of the incoming call.
• You are connected to the incoming call.
Inspect
You can access this feature with the softkeys only if the feature's abbreviation, Inspt, appears on the second line of one
of the feature option screens.
Note: If you are currently on a call and a new call comes in, the display automatically shows you information on
the new call. You do not need to use the Inspect feature in this situation. However, you can use the Inspect
feature to see who is on a call that has been placed on hold.
To see who is on hold while on a call
1Press <Menu> and then press the softkey below Inspt or, if Inspt is not available on your display, press
<Inspect>.
2Press <xxxxx> of the held call.
• The information is shown on the display screen; you remain connected to the present call.
3To return to the held call, press <Exit> and <xxxxx> of the held call.
Last Number Dialed (Redial)
You can access this feature with the softkeys only if the feature's abbreviation, Last, appears on the second line of one
of the feature option screens.
To automatically redial the last number you dialed (up to 24 digits) (extension, outside number, or trunk/feature
access code)
1While on-hook or off-hook, press <Menu> and then press the softkey below Last or, if Last is not available on
your display, press <LastDialed> (while on-hook or off-hook) or dial the Last Number Dialed code 659 (while off-
hook).
Mute
Note: When you are talking on the handset, the Mute feature affects the microphone associated with the handset
rather than the speakerphone.
This feature has no effect on an external speakerphone attached to your telephone.

19
To prevent the other party from hearing you (to mute the handset or speakerphone microphone)
1Press <Mute>.
• The red light next to <Mute> goes on, and the other party cannot hear you.
2When you are ready to resume conversation with the other party, press <Mute> again.
• The red light next to <Mute> goes off, and the other party can hear you again.
The Mute feature turns off automatically when you hang up, or switch from the speakerphone to the handset or from the
handset to the speakerphone.
Normal Display
To exit any display feature and return to normal display
1Press <Exit>
• Display will show call information for active call appearance
Ringer Volume
To adjust the ringer volume (speaker is not active)
1To raise the volume, press the right half of the Volume control button. To lower the volume, press the left half of
the Volume control button.
• The display shows the following:
RINGER L >>>>> H
• One full ring cycle will sound to demonstrate the new volume.
There are eight possible volume settings. One arrow is the lowest setting, and eight arrows is the highest setting.
Select Ring
To select a personalized ring
1While on-hook, press <Ring> (or <Shift> then <Hold> if you don’t have a <Ring> button)
• The red light next to <Ring> winks.
• The current ringing pattern plays and repeats every three seconds
• The ringing pattern you are hearing is displayed.
SELECT RING PATTERN: 1
2Cycle through the ringing patterns by pressing (and then releasing) <Ring> (or <Hold>)
• The red light next to <Ring> continues to wink.

20
• The ringing pattern you are hearing is displayed.
Note: You can also press <Next> or <Prev> to cycle through all eight ringing patterns.
3If you want to save the ringing pattern currently being played, do not press <Ring> anymore. You will hear the
selected ringing pattern two more times, and then it will automatically be saved.
• You hear confirmation tone (two rising tones).
• The red light next to <Ring> goes off.
Note: If you receive a call, go off-hook, or lose power during selection, the process is interrupted and
you must start again.
Self-Test
To test the lights and the display on your telephone
1While on-hook or off-hook, press and hold <Test>.
• The green light next to <Test> goes on.
Note: If the green light next to <Test> flashes rather than goes on steadily, it means the telephone is not
communicatingwith the switch.In such a case, call the Helpdesk at x2964.
• The lights go on steadily in four groups, and the display fills in all the segments.
2To end test, release <Test>.
• The lights return to the pretest state; the green light next to <Test> goes off.
Note: If the display orthe lights donot respondduringthe test, call the Helpdesk at x2964 toopen a
trouble ticket.
Send All Calls
You can access this feature with the softkeys only if the feature's abbreviation, SAC, appears on the second line of one
of the feature option screens.
To send all calls immediately to coverage (if your system manager has provided a coverage path for your
extension)
1While on-hook, press <Menu> and then press the softkey below SAC or, if SAC is not available on your display,
press <Send Calls> (while on-hook) or dial the Send All Calls code *3 (while off-hook). [confirmation tone]
Note: You may hear a ring-ping tone from your telephone as each call is redirected.
