Alcatel 9900 User manual

document, use and communication of its contents
not permitted without written authorization from ALCATEL
All rights reserved. Passing on and copying of this
1/683CC11095AAAATQBJA02 Issue02-January 04, 2000
ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ
ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ
ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ
ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ
ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ
Alcatel 9900
Multiservice broadband
wireless access solution
Terminal Station – release2.0
USER MANUAL

document, use and communication of its contents
not permitted without written authorization from ALCATEL
All rights reserved. Passing on and copying of this
2/68 3CC11095AAAA TQ BJA 02
Issue 02 - January 04, 2000
PAGE INTENTIONALLY LEFT BLANK

document, use and communication of its contents
not permitted without written authorization from ALCATEL
All rights reserved. Passing on and copying of this
3/683CC11095AAAA TQ BJA 02 Issue 02 - January 04, 2000
Table of contents
1 – Foreword 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.1 – Structure of the manual 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2 – Using the manual 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.3 – Safety instructions 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.3.1 – General rules 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.3.2 – Symbols on products 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.3.3 – Symbols used in the document 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2 – Equipment overview 9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1 – Overview of the A9900 system 9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.2 – Composition of the A9900 system 10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.3 – A9900 system specifications 11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.3.1 – Frequency bands used 11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.3.2 – Radio transmission specifications (typical values) 11. . . . . . . . . . . . . . . . . . . . . . . . . . .
2.3.3 – Capacity 12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.4 – Description of the Terminal Station (9900TS) 15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.5 – Examples of configuration of the Terminal Station (9900TS) 15. . . . . . . . . . . . . . . . . . . . . . . . . .
2.5.1 – Mono “NT” without repeater 15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.5.2 – Mono “NT” with repeater 15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.5.3 – Multi “NT” (max.4) with passive splitters and repeaters 16. . . . . . . . . . . . . . . . . . . . . .
2.6 – Technical specifications of the Terminal Station (9900TS) 17. . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.6.1 – RT specifications 17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.6.2 – NT specifications 17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3 – Installation of the 9900TS Terminal Station 19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.1 – Equipment delivery 19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.1.1 – Unpacking 19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.1.2 – Checking the configuration 20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.2 – Labels on the equipment 21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.3 – Installing the equipment 22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.3.1 – Information required for installation 22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.3.2 – Precautions concerning electromagnetic compatibility 22. . . . . . . . . . . . . . . . . . . . . . .
3.3.3 – Tools required 22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.4 – Installation of the Terminal Station RT unit 23. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.4.1 – Definition of assemblies with respect to chosen polarization 23. . . . . . . . . . . . . . . . . .
3.4.2 – Installation of the 9900RT on a wall or flat vertical surface 26. . . . . . . . . . . . . . . . . . .
3.4.3 – Installation of the RT unit on a tube 28. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.4.4 – Grounding the RT unit 31. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.5 – Installation of the RT/NT link 32. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.6 – Installation of the Terminal Station 9900NT Indoor Unit 34. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.6.1 – Installation of the 9900NT unit on a desktop 34. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.6.2 – Installation of the NT unit on a vertical wall support 35. . . . . . . . . . . . . . . . . . . . . . . . .

document, use and communication of its contents
not permitted without written authorization from ALCATEL
All rights reserved. Passing on and copying of this
4/68 3CC11095AAAA TQ BJA 02
Issue 02 - January 04, 2000
3.6.3 – Installation of the NT unit on a 19” rack 36. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.6.4 – Grounding the NT unit 36. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.7 – Installation of one or more repeater modules 37. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.8 – Installation of one or several repeaters with passive splitter(s) 39. . . . . . . . . . . . . . . . . . . . . . . .
4 – Commissioning the 9900TS Terminal Station 45. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.1 – Purpose 45. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.2 – Commissioning the RT unit 45. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.2.1 – Equipment required 45. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.2.2 – Site configuration and adjustment procedures 47. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.3 – Commissioning the NT IDU 51. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.4 – Client terminal connections 52. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.4.1 – Ethernet connector 52. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.4.2 – G703 connector 52. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.4.3 – X21 connector 53. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5 – Operation and maintenance 55. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.1 – Network supervision 55. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.2 – Preventive maintenance 55. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.3 – Corrective maintenance 55. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.3.1 – Methodology 55. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.3.2 – Use of 9900LT software programs for alarm localisation 55. . . . . . . . . . . . . . . . . . . . .
5.4 – Changing the NT unit 56. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.5 – Changing the RT unit 56. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6 – Changes of configuration 57. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6.1 – Use of NT unit supervision 57. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6.2 – Declaration, deletion, reset of an NT unit 57. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6.3 – Implementation of customer services 57. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6.4 – Changing an RT unit 58. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6.5 – Changing the BS on an NT 58. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Appendix 1 – 9900 TS INSTALLATION SHEET 59. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Appendix 2 – Using the DALLET[ system by SOFRER] for 1 m & 1.5 m high mast on rooftop 61
Appendix 3 – Mounting coaxial connectors 63. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Appendix 4 – List of abbreviations/Liste des abréviations 67. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

document, use and communication of its contents
not permitted without written authorization from ALCATEL
All rights reserved. Passing on and copying of this
5/683CC11095AAAA TQ BJA 02 Issue 02 - January 04, 2000
1 – Foreword
1.1 –Structure of the manual
This manual is for users with a sound knowledge of how to operate and install point–multipoint microwave
systems and how to use a PC-based craft terminal running the Windowstoperating system. With it, you
should quickly be able to operate the equipment. It is not intended to replace the training services that we can
provide for your particular needs.
The manual is divided into seven sections followed by appendixes:
– Foreword
– Description of the equipment
– Installation of the equipment
– Servicing
– Maintenance
– Upgrading configurations
– Appendixes
1.2 –Using the manual
With this manual, you should be able to commission and operate the described equipment to a basic level.
You should always read this manual in conjunction with the attached “Update” document (if provided) so that
you are aware of the latest equipment upgrades.
Manual updates
This edition of the manual describes hardware and software releases of the following revision indexes and
above:
Hardware revision: 01
In cases where an equipment upgrade affects the content of the manual, the relevant modification should be
inserted in the “Update” document, with the same reference number, but with code type VE (instead of TQ).
When the number or extent of the changes justifies it, they should be incorporated in the body of the manual
and the manual’s revision index should be incremented. Revision bars will show the differences from the
previous version.
Note:MS-DOS,MICROSOFTandWINDOWSareregisteredtrademarksofMicrosoftCorporation.

document, use and communication of its contents
not permitted without written authorization from ALCATEL
All rights reserved. Passing on and copying of this
6/68 3CC11095AAAA TQ BJA 02
Issue 02 - January 04, 2000
1.3 –Safetyinstructions
1.3.1 – General rules
The following generalsafety precautionsmust beobserved by theinstaller andthe operator. ALCATEL
assumes no liability for the customer’s failure to comply with these requirements.
Ground the equipment:
ForSafetyClass1equipment,alwaysconnecttheearthconductorofthepowercabletoanappropriateearthing
device.
DO NOT operate the product in an explosive atmosphere or in presence of flammable gases or fumes.
For protection against fire:
replace the line fuse(s) only with fuse(s) of the same voltage and current rating and type.
Dangerous voltages:
Users must not remove equipment covers or shields. The installation and maintenance procedures described
in this manual are for use by service–trained personnel only.
DO NOT operate equipment which may be damaged:
Whenever it is possible that the safety protection features built into this equipment have been impaired,
ISOLATE FROM THE POWER SUPPLY and do not use the equipment until safe operation can be verified by
service–trained personnel. If necessary, return the equipment to Alcatel After Sales for service and repair.
DO NOT substitute parts or modify equipment:
Return the product to Alcatel Customer Service for servicing and repair.
1.3.2 – Symbols on products
1.3.2.1 – Danger symbols
When subsystems and modules have warning labels, it is extremely important to follow their instructions.
These labels are designed to indicate dangerous situations; they may contain any standard symbol or anytext
considered necessary to protect users and employees.
The most frequent danger situations and symbols are:
Danger or general warning
Prompts the user to refer to the manual.
Dangerous electrical voltages
Close to dangerous voltages (>42.4 V AC peak, 60 V DC; power level >240 VA) you will find
this warning label
Presence of heat-radiating mechanical parts

document, use and communication of its contents
not permitted without written authorization from ALCATEL
All rights reserved. Passing on and copying of this
7/683CC11095AAAA TQ BJA 02 Issue 02 - January 04, 2000
1.3.2.2 – Earth symbols
Terminal for connecting the protective earth conductor in power supply wiring
Other earth terminal
1.3.2.3 – Other symbols
Indicates compliance with European standards
1.3.3 – Symbols used in the document
These symbols alert the reader the possible risks. They indicate:
– the cause and type of danger,
– the possible consequences,
– the preventive action.
1.3.3.1 – Warning
–protection of personnel,
– warning of a possible dangerous situation,
– danger of fatal or serious injury.
1.3.3.2 – Precautions
–protection of equipment,
– warning of a procedure, practice or condition that could be dangerous to
equipment or its environment,
– danger of damage to the equipment or its environment; permanentloss of data
possible.
– This symbol, introducing the description of a procedure, indicates that it will
cause the link to be temporarily disconnected.
$
– Thissymbol,introducingthedescriptionofaprocedure, indicatesthat itcannot
be continued without a full knowledge of the data contained in the procedure
sheet concerning the stations concerned.
STOP

document, use and communication of its contents
not permitted without written authorization from ALCATEL
All rights reserved. Passing on and copying of this
8/68 3CC11095AAAA TQ BJA 02
Issue 02 - January 04, 2000
PAGE INTENTIONALLY LEFT BLANK

document, use and communication of its contents
not permitted without written authorization from ALCATEL
All rights reserved. Passing on and copying of this
9/683CC11095AAAA TQ BJA 02 Issue 02 - January 04, 2000
2 – Equipment overview
2.1 –Overview of the A9900 system
The Alcatel 9900 is a multi–service broadband wireless local loop system designed to provide telecom
services to small and medium–sized enterprises.
Broad band WLL (Wireless Local Loop) system, Alcatel 9900 allows operators to offer rapid provision – to a
large number of client sites – of a comprehensive range of telephone and data transmission services.
For cellular phone network operators, Alcatel 9900 offers the possibility of linking base stations to base
station controllers. This makes Alcatel 9900 an economical transmission solution, for the implementation or
extension of high traffic density areas coverage.
Formixed network operators (fixedandmobile), Alcatel 9900enablesto connect,withthe samesystem,fixed
professional end user as well as base stations of cellular telephony.
Figure 1 – A9900 System – Local point–multipoint service distribution –
SME
Company D
Company C
Company A
Company B
Independantprofession
Independantprofession

document, use and communication of its contents
not permitted without written authorization from ALCATEL
All rights reserved. Passing on and copying of this
10/68 3CC11095AAAA TQ BJA 02
Issue 02 - January 04, 2000
2.2 –Compositionof the A9900 system
An A9900 network cell consists of the following:
Sa common base station designated 9900BS;
Sand several terminal stations distributed across the user sites, and designated 9900TS.
Figure 2 – Base Station and Terminal Stations
“Digital Base Station”
DBS
“Terminal Stations”
“Radio Base Station”
RBS
9900BS
nx9900TS

document, use and communication of its contents
not permitted without written authorization from ALCATEL
All rights reserved. Passing on and copying of this
11/683CC11095AAAA TQ BJA 02 Issue 02 - January 04, 2000
2.3 –A9900system specifications
2.3.1 – Frequency bands used
25 GHz frequency band:
– CEPT T/R 13–02E European recommendation 24.5 – 26.5 GHz
26 GHz frequency band:
– MPT (Japan) 25.25 – 27 GHz
28 GHz frequency band:
– 27 GHz (LMCS – Canada) 27.35 – 28.35
– 28 GHz (CEPT) 27.5 – 28.6, 29.1 – 29.5
– 29 GHz (LMD – USA) 27.5 – 28.35, 29.10 – 29.25
2.3.2 – Radio transmission specifications (typical values)
The following table gives the main characteristics of the A9900 wireless system.
A downstream (BS to TS)carrier is combined with up to four upstream (TS to BS) carriers.
Downstream
Channel bandwidth 14 MHz 28 MHz
Occupied bandwidth 13.63 MHz 27.25 MHz
Modulation QPSK QPSK
Cross bit rate 20.19 Mbit/s 40.37 Mbit/s
Code Convol. 7/8 (k=7) Convol. 7/8 (k=7)
Interlace depth 12 depth 12
Code Reed–Solomon
(204,188,8) Reed–Solomon (204,188,8)
Bit rate before coding 16.19 Mbit/s 32.38 Mbit/s
Link budget 25 GHz 28 GHz 25 GHz 28 GHz
RBS output power 17 dBm 17 dBm 17 dBm 17 dBm
Transmit antenna gain 15 dB 15 dB 15 dB 15 dB
Receive antenna gain 35 dB 34.5 dB 35 dB 34.5 dB
Rx RF level for error ratio = 10–10 – 83.5 dBm – 83.5 dBm – 80.5 dBm – 80.5 dBm
System gain 150.5 dB 150 dB 147.5 dB 147 dB

document, use and communication of its contents
not permitted without written authorization from ALCATEL
All rights reserved. Passing on and copying of this
12/68 3CC11095AAAA TQ BJA 02
Issue 02 - January 04, 2000
Upstream
Channel bandwidth 3.5 MHz 7 MHz
Occupied bandwidth 3.36 MHz 6.72 MHz
Modulation D–QPSK D–QPSK
Cross bit rate 5.38 Mbit/s 10.75 Mbit/s
Code Convol. 7/8 (k=7) Convol. 7/8 (k=7)
Interface depth 12 depth 12
Code Reed–Solomon
(63,53,5) Reed–Solomon (63,53,5)
Bit rate before coding 4.19 Mbit/s 8.38 Mbit/s
Link budget 25 GHz 28 GHz 25 GHz 28 GHz
RBS output power 12 dBm 12 dBm 12 dBm 12 dBm
Transmit antenna gain 35 dB 34.5 dB 35 dB 34.5 dB
Receive antenna gain 15 dB 15 dB 15 dB 15 dB
Rx RF level for error ratio = 10–10 – 87 dBm – 87 dBm – 84 dBm – 84 dBm
System gain 149 dB 148.5 dB 146 dB 145.5 dB
2.3.3 – Capacity
The network capacity depends on the traffic mix betwen the services and leased lines or telephony services.
It also depends on the channeling and the number of upstream channels.
The following tables give the characteristics of three combinations: minimum, medium and maximum circuit
throughput; however, any intermediate combination is possible.
28 / 7 MHz channeling:
Downlink: 28 MHz Trafic MIX: circuit capacity
Uplink: 1 x 7 MHz Minimum Medium Maximum
nb of circuits: 64 kbit/s 0 60 121
ATM uplink capacity (cells/s) 18,980 9,569 0
ATM downlink capacity (cells/s)* 76,141 67,084 57,877
Downlink : 28 MHz Trafic MIX: circuit capacity
Uplink : 2 x 7 MHz Minimum Medium Maximum
nb of circuits: 64 kbit/s 0 120 242
ATM uplink capacity (cells/s) 37,961 19,137 0
ATM downlink capacity (cells/s)* 76,141 58,028 39,613

document, use and communication of its contents
not permitted without written authorization from ALCATEL
All rights reserved. Passing on and copying of this
13/683CC11095AAAA TQ BJA 02 Issue 02 - January 04, 2000
Downlink : 28 MHz Trafic MIX: circuit capacity
Uplink : 3 x 7 MHz Minimum Medium Maximum
nb of circuits: 64 kbit/s 0 180 363
ATM uplink capacity (cells/s) 56,941 28,706 0
ATM downlink capacity (cells/s)* 76,141 48,971 21,349
Downlink : 28 MHz Trafic MIX: circuit capacity
Uplink : 4 x 7 MHz Minimum Medium Maximum
nb of circuits: 64 kbit/s 0 240 484
ATM uplink capacity (cells/s) 75,922 38,275 0
ATM downlink capacity (cells/s)* 76,141 39,915 3,084
14/3.5 MHz channeling:
Downlink: 14 MHz Trafic MIX: circuit capacity
Uplink: 1 x 3.5 MHz Minimum Medium Maximum
nb of circuits: 64 kbit/s 0 30 60
ATM uplink capacity (cells/s) 9,412 4,706 0
ATM downlink capacity (cells/s)* 38,047 33,519 28,990
Downlink : 14 MHz Trafic MIX: circuit capacity
Uplink : 2 x 3,5 MHz Minimum Medium Maximum
nb of circuits: 64 kbit/s 0 60 120
ATM uplink capacity (cells/s) 18,824 9,412 0
ATM downlink capacity (cells/s)* 38,047 28,990 19,934
Downlink : 14 MHz Trafic MIX: circuit capacity
Uplink : 3 x 3,5 MHz Minimum Medium Maximum
nb of circuits: 64 kbit/s 0 90 180
ATM uplink capacity (cells/s) 28,235 14,118 0
ATM downlink capacity (cells/s)* 38,047 24,462 10,877
Downlink : 14 MHz Trafic MIX: circuit capacity
Uplink : 4 x 3,5 MHz Minimum Medium Maximum
nb of circuits: 64 kbit/s 0 120 240
ATM uplink capacity (cells/s) 37,647 18,824 0
ATM downlink capacity (cells/s)* 38,047 19,934 1,821

document, use and communication of its contents
not permitted without written authorization from ALCATEL
All rights reserved. Passing on and copying of this
14/68 3CC11095AAAA TQ BJA 02
Issue 02 - January 04, 2000
* : part of the ATM downlink bit rate can be used for dynamic bandwidth allocation. This proportion varies within
the following limits:
– 2.5 % of the bit rate , if one upstream channel is used,
– 4 % of the bit rate , if two upstream channels are used,
– 5.5 % of the bit rate , if three upstream channels are used,
– 7 % of the bit rate , if four upstream channels are used.

document, use and communication of its contents
not permitted without written authorization from ALCATEL
All rights reserved. Passing on and copying of this
15/683CC11095AAAA TQ BJA 02 Issue 02 - January 04, 2000
2.4 –Descriptionof the Terminal Station (9900TS)
The A9900 system Terminal Station (9900TS) consists of the following main elements:
San external transceiver constituting the radio antenna part and designated “RT” (Radio
Termination);
Sa user connection unit constituting the “indoor” part and designated NT (Network Termination);
Sa cable linking the RT and NT and called the indoor–outdoor cable;
Sdependingon the configurations (see sections 2.5 3.7 3.8), one (or more) repeater module(s), or
(and) one (or more) splitter module(s).
2.5 –Examples of configuration of the Terminal Station (9900TS)
2.5.1 – Mono “NT” without repeater
0 to 70 m
RT NT
2.5.2 – Mono “NT” with repeater
repeater repeater
0 to 70 m
RT
NT
Fixed lenght:
70 m Fixed lenght: 70 m
A repeater compensates 70 meters of cable.
The system can support maximum three 70 m cable sections and two repeaters.

document, use and communication of its contents
not permitted without written authorization from ALCATEL
All rights reserved. Passing on and copying of this
16/68 3CC11095AAAA TQ BJA 02
Issue 02 - January 04, 2000
2.5.3 – Multi “NT” (max.4) with passive splitters and repeaters
Figure 3 – Example of assembly with passive splitters and repeaters
repeater
RT
NT
NT1
0 to 70 meters
splitter
NT2
NT3
Fixed lenght
50 mèters
Fixed lenght
50 meters
repeater
splitter
repeater
Fixed lenght
50 meters
Fixed lenght
50 meters
Fixed lenght
70 meters
The system can support 2 repeaters and 3 passive splitters per route. Route means the path between a NT
unit and the RT unit.
The fixed distance between two repeaters or between a repeater and a NT unit is 50 meters if a passive splitter
is used.
The fixed distance between two repeaters or between a repeater and a NT unit is 30 meters if two passive
splitters are used.

document, use and communication of its contents
not permitted without written authorization from ALCATEL
All rights reserved. Passing on and copying of this
17/683CC11095AAAA TQ BJA 02 Issue 02 - January 04, 2000
2.6 –Technicalspecifications of the Terminal Station (9900TS)
2.6.1 – RT specifications
Designation Description Observations
Dimensions HxLxD 200(mm)x200(mm)x50(mm)
antenna diameter: 26 cm
cf. diagram
in § 3 Installation
Weight 2 kg 
Operating temperature –33°C to + 55°C
2.6.2 – NT specifications
There are three types of NT unit:
9900 NCA 001 9900 NCA 002 9900 NCD 001
Telephony, leased lines 2 x E1 (G703+G703) 2 x E1 (G703 + X21) 
Data 2 x 10bT Eth 2 x 10bT Eth 2 x 10bT Eth
Designation Description Observations
Dimensions WxHxD 19”x1Ux240(mm) cf. diagram
in § 3 Installation
Weight 3 kg 
Supply voltage 85V–264V AC 
Data interface 10 Base T Ethernet 
E1 interface G703 and/or X21 
Operating temperature –5°C to + 45°C

document, use and communication of its contents
not permitted without written authorization from ALCATEL
All rights reserved. Passing on and copying of this
18/68 3CC11095AAAA TQ BJA 02
Issue 02 - January 04, 2000
PAGE INTENTIONALLY LEFT BLANK

document, use and communication of its contents
not permitted without written authorization from ALCATEL
All rights reserved. Passing on and copying of this
19/683CC11095AAAA TQ BJA 02 Issue 02 - January 04, 2000
3 – Installation of the 9900TS Terminal Station
3.1 –Equipmentdelivery
When you receive the equipment in its packaging:
– Check the condition of the packaging.
– If damaged, make your reservations known to the carrier without delay.
3.1.1 – Unpacking
Considerations
– Unpack the equipment according to the instructions on the packaging.
– Takeaninventoryandidentifyanymissingitems.Ifthedeliverydoesnotmatchthedeliveryadvicenote,
notify ALCATEL within 48 hours of receipt of the equipment.
Stages (Figure 4)
1. Open the cover flap of the package lid.
2. Remove the cardboard packing wedge protecting the box’s contents.
3. Remove the RT unit, taking care not to damage the antenna.
4. Remove the slotted casing from the box.
5. Remove the packaged items fixed in the slots of the casing.
6. Detach the drilling template if wall–mounting is to take place.
mounting kit
Figure 4 – Unpaking the RT unit
radio unit
and antenna
wall mount
bearing mount
polarisation kit
User manual “N” connector and
attachment hardware

document, use and communication of its contents
not permitted without written authorization from ALCATEL
All rights reserved. Passing on and copying of this
20/68 3CC11095AAAA TQ BJA 02
Issue 02 - January 04, 2000
Figure 5 – Unpacking the NT unit
The NT unit equipment is protected by safety cover. Do not unpack the equipment in advance if it is not to be
installed immediately.
3.1.2 – Checking the configuration
The Terminal Station components are delivered in cardboard boxes:
– the RT unit (also called RT or RT radio)and its installation accessories are in one box,
– the NT unit (also called NT) and its installation accessories are in another box,
Depending on the site configurations, the delivery will include individual boxes containing:
– one or more splitter modules,
– one or more repeater modules.
3.1.2.1 – Content of boxes
EQUIPMENT CONTENTS
RT UNIT 1 RTwith antenna mounted assembly
1 wall mount
1 bearing mount
1 horizontal polarisation kit with screw accessories
2 U bolts
1 bag containing 1 type “N” 75 ohm connector four M6x50 screws with washers and
plugs; four M8 nuts with washers, 2 terminal lugs and one M6x20 screw with washers
1 installation manual
