The AP60/61 Mounting Kit Installation Notes 1
The AP60/61
Mounting Kit Installation Notes
The AP60-MNT can be used to attach an AP60 or AP61 Access
Point (AP) to a shelf, wall, post, ceiling, or partition hanger. The
included mounting cradle holds the AP firmly in place when
installed, and also allows for quick release when maintenance is
required.
These Installation Notes provide instructions for using the
mounting kit and modify information found in the AP60/61
Wireless Access Point Installation Guide. Please keep this
information with your Wireless Networks documentation.
Kit Components
The following items are included in the AP60-MNT:
FIGURE 1 AP60/61 Mounting Kit Packing List
15/16"
T-Rail Clip
9/16"
T-Rail Clip
Nut
Label
Cover
Cross-head
Screw
ad
w

AP60-MNT: Installation Notes
2Part 0500037-03 May 2005
Inform your supplier if there are any incorrect, missing or damaged parts. If
possible, retain the original packing materials. Use them to repack the product
in case there is a need to return it.
Prerequisites
Before using the mounting kit, you must first perform the initial AP
provisioning as described in the AP60/61 Wireless Access Point Installation
Guide. When handling the AP, be sure to follow the requirements and safety
precautions outlined in that manual.
Mounting the AP Cradle
The mounting kit can be used to install the AP60/61 in a variety of ways, each
of which is detailed in the following sections:
zOn a solid wall, shelf, or ceiling surface (see page 3)
zSuspended from a tile ceiling (see page 4)
zOn a vertical post (see page 6)
zFrom an office partition hanger (see page 6)
The following procedures describe mounting the AP cradle. The AP is then
inserted into the cradle as shown on page 7.

The AP60/61 Mounting Kit Installation Notes 3
Solid Surface Mount
The mounting kit can be used to attach the AP to a solid, flat, indoor surface
such as a wall, shelf, and ceilings.
FIGURE 2 Attaching the Cradle to a Solid Surface
Orient the cradle with its flat side against the mounting surface. If attaching
the cradle to a wall, orient it so that the notched end is positioned at the top.
Secure the cradle to the solid surface using four #6 screws (not included) or
equivalent. Use the round cradle holes (A) for solid surfaces. If attaching the
cradle to drywall, use the wide cradle holes (B) and the appropriate wall
anchors (not included) as shown above.
CAUTION—Do not use screws to attach the mounting cradle to a
suspended ceiling or other structurally weak surface. For suspended
ceilings, use the T-rail clips as described on page 4.
A
B

AP60-MNT: Installation Notes
4Part 0500037-03 May 2005
Suspended Ceiling Mount
The mounting kit can be used to hang the AP from an indoor suspended
ceiling.
1. Attach the T-rail clips to the ceiling rail.
FIGURE 3 Attaching the T-Rail Clips
The T-rail clip twists onto the ceiling rails used with standard suspended-ceiling
systems. Use either the 15/16-inch or 9/16-inch clip, as appropriate for your
ceiling. Use the mounting cradle to gauge the appropriate separation.

The AP60/61 Mounting Kit Installation Notes 5
2. Attach the cradle to the T-rail clip.
FIGURE 4 Mounting the Cradle to a Suspended Ceiling
3. Place the nut on the T-rail clip bolt to secure the cradle.
Cradle
T-Rail
Clip
Nut
Side View
Bolt
Hole

AP60-MNT: Installation Notes
6Part 0500037-03 May 2005
Vertical Post Mount
FIGURE 5 Mounting the Cradle to a Vertical Post
To mount the AP to a vertical post, thread two metal or plastic mounting straps
(not included) around the post and through the large slots on the cradle. The
straps should be flat and no wider than 1.5 cm (5/8 inches).
Office Partition Mount
FIGURE 6 Mounting the Cradle to a Partition Hanger
Strap
Slots
Hook/Bolt
Holes

The AP60/61 Mounting Kit Installation Notes 7
The cradle includes mounting holes for a variety of different office partition
hangers (not included). Use the hole most suited for your particular hanger
system’s hook or bolt.
Placing the AP into the Cradle
1. Remove the oval LED label from the front of the AP chassis.
FIGURE 7 Removing the LED label
The label conceals a mounting hole required in a later step. (You will remove
and discard this label and replace it with the extra label shipped with this kit.)

AP60-MNT: Installation Notes
8Part 0500037-03 May 2005
2. Place the AP into the mounting cradle.
FIGURE 8 Placing the AP60/61 into the Cradle
Fit the keyhole-shaped slots on the rear of the AP chassis over the cradle
mounting pin and tab. Slide the AP chassis downward so that the AP slot
captures the tab.

The AP60/61 Mounting Kit Installation Notes 9
3. Secure the AP with one of the included screws.
FIGURE 9 Installing the Cradle Screw
Use either the cross-head or hex-head screw. The hex-head screw requires a
less commonly available tool and may increase casual security. Install the
screw through the mounting hole in the front of the AP chassis (previously
covered by the LED label) and into the cradle mounting pin. Do not overtighten.
4. Apply the new LED label.
5. Secure the AP, if desired.
To prevent the unauthorized removal of the AP from its installed location, use a
Kensington MicroSaver Security Cable (not included). Wrap the security cable
around an immovable object, insert the cable’s lock into the Kensington
Security Slot on the back of the AP, and turn the key.
6. Orient the antennas.
For best performance, orient the antennas vertically.
7. Resume standard installation.
Once mounting is complete, connect the required cables and complete the
installation as described in the AP60/61 Wireless Access Point Installation
Guide.

AP60-MNT: Installation Notes
10 Part 0500037-03 May 2005
Notes

The AP60/61 Mounting Kit Installation Notes 11

AP60-MNT: Installation Notes
12 Part 0500037-03 May 2005
