AlcoSense STEALTH User manual

Version 2.1. July 2019

Operating Instructions
1. Press the power button.
2. Unit will warm up until it displays “blow” sign.
3. Blow steadily into the mouthpiece, a tone will be heard once you start to
blow. Then a click will be heard once sampling is complete.
4. The result is displayed for 15 seconds, after which 5 beeps will be heard
and the back light will turn off.
5. You can then take a second test by pressing and holding down the power
switch. The unit will then repeat steps 2 to 4.
6. The unit will automatically turn off when not in use.
Dear customer
Congratulations on buying your new AlcoSense®Stealth breathalyser.
Now, if you are drinking, you are more aware of your alcohol level before you get into
the car and possibly drive dangerously.
We hope you enjoy owning your AlcoSense®Stealth breathalyser. If you have any
questions regarding the unit or want to speak with us further, please visit
andatech.com.au or call 1300 800 200 (between 9am and 5pm Monday to Friday).
*To check the accumulated total test counts, press and hold onto the power switch.
Please note: When inserting the mouthpiece,
only insert to the first line indicator. Failure to
observe this point may damage the unit.

1. Press the power button.
2. Unit will warm up until it displays “blow” sign.
3. Blow steadily into the mouthpiece, a tone will be heard once you start to
blow. Then a click will be heard once sampling is complete.
4. The result is displayed for 15 seconds, after which 5 beeps will be heard
and the back light will turn off.
5. You can then take a second test by pressing and holding down the power
switch. The unit will then repeat steps 2 to 4.
6. The unit will automatically turn off when not in use.
Contents: Breathalyser, hard case, mouthpieces (x5), AAA batteries (x2), pouch,
hand strap and user’s manual
Mouthpiece
Mouthpiece Slot
3 Digit LCD Display
Power Button
Hand Strap Slot
Battery Cover

Limits
AUSTRALIAN BLOOD ALCOHOL LIMITS: Adult License 0.05%
Some drivers are restricted to lower levels of BAC. Please refer to your local
transport authority for your correct limit. If in any doubt do not drink and drive.
The safest level when driving is none at all. Alcohol impairs your judgement and
can make you drowsy or sleepy.
The AlcoSense®Stealth uses a fuel cell sensor to measure breath alcohol levels.
Depending upon the amount of alcohol registered by the sensor after a period of
time, it will require recalibration. Andatech recommends the AlcoSense®Stealth to
be calibrated every 6 months or after 500 uses, whichever comes first. To maintain
to Australian Standards, calibration every 6 months is required. For technical
support please contact 1300 800 200.
0.000 to 0.400% BAC
+/- 0.005 at 0.100% BAC
5 seconds - 2 minutes
Within 10 seconds at 0.100% BAC
10 seconds
Compatible with Andatech mouthpiece only
Fuel cell sensor
2 x 1.5V AAA size alkaline batteries
100g including batteries
106 (height) x 50 (width) x 20 (thickness)
Operation: 0 to 40°C Storage: 0 to 50°C
Manufacturer recommended: every 500 tests
or 6 months, whichever comes first
Australian Standards Requirement: 6 months
Indication of %BAC
Accuracy
Warm-up Time
Response Time
Recycle Time
Mouthpiece
Sensor Type
Power Supply
Weight
Dimensions (mm)
Ambient conditions
Calibration

This product must be used in accordance with the instructions in this manual
and - in particular - must not be allowed to get wet.
This product is intended to provide the user with an indication of alcohol on the
breath. However, neither the manufacturer nor the supplier gives any warranty
(express or implied) that the product can give any indication of blood alcohol level.
A person’s BAC (Blood Alcohol Concentration) can only be accurately measured by the
administration of a blood test. This product only measures breath alcohol content
which, in turn, only gives an approximately indication of blood alcohol concentration.
In these circumstances the user of this product should not rely on the
information provided thereby as an accurate indication of his blood alcohol
concentration or of his level of intoxication or of his fitness to drive and in
particular should not take any action in reliance on such information as the
product can provide no more than an indication of alcohol on the breath.
If the user of this product makes any decision or takes any action based on the
use of the product such decision or such action shall be at the sole risk of the
user and neither the manufacturer nor the supplier assumes any responsibility
for such decision or action. In particular, neither the manufacturer nor the
supplier shall be in any way liable if the user of the product asserts that the
product led him to believe that he was fit to operate a motor vehicle and is
subsequently found not to be so fit.
This product is certified pursuant to Australian Standard AS 3547.
1.
2.
3.
4.
5.
6.

a. Allow at least 20 minutes after eating or drinking before testing. Any type of
alcohol remaining in the mouth of saliva may interfere with proper testing and
requires about 20 minutes to disperse. This includes alcohol-based mouthwash
or similar products.
b. Avoid testing in high wind conditions or in poorly ventilated or enclosed spaces.
Poor ventilation may also lengthen the time required for warm up between tests.
c. Do not blow smoke, saliva or other contaminants into the mouthpiece, as the
sensor may become damaged. Wait at least 20 minutes after smoking before
conducting a test.
d. Do not use the AlcoSense®Stealth breathalyser as a tool to drink and drive.
e. Do not blow fluid into the instrument as it will damage the sensor and void your
warranty.
f. Do not store in an extreme environment where high temperature or high
humidity exists. Keep out of the reach of children.
g. Blood alcohol concentration can continue to rise for up to 2 hours after the
cessation of drinking. If a caution result or a result is close to the designated
BAC, it is recommended to wait and retest after 20 minutes.
h. It can take 10 hours or more for the alcohol level to return to a zero after a high
blood alcohol level has been reached. A further test should be carried out later
in the day of the following morning.
i. User-serviceable batteries safety:
• Do not dispose of batteries in a fire.
• Do not recharge a battery unless it is specifically marked “rechargeable”.
• Do not expose the AlcoSense®Stealth or batteries to heat source.
• Do not mix old and new batteries, or mix different types or makes of batteries.
• Do not allow children to play with the batteries.
If you see ‘bAt’ on the display screen, the battery power is low.
Please replace the batteries.
If you see ‘Flow’ on the display screen, the breath sample was
not strong enough for measurement. Please power on the unit
again and use a strong and steady breath during sampling.

It is our aim to provide you with quality products that you can trust. Our products
come with guarantees that cannot be excluded under the Australian Consumer
Law. You are entitled to a replacement or a refund for a major failure and for
compensation for any other reasonably foreseeable loss or damage.
You are also entitled to have the goods repaired or replaced if the goods fail to be of
acceptable quality and the failure does not amount to a major failure.
The Guarantee
The product is guaranteed to be free from defects in workmanship and parts
for a period of 3 years from date of purchase. Defects that occur within this
warranty period, under normal use and care, will be repaired, replaced or refunded
at our discretion, solely at our option with no charge for parts and labour. The
benefits conferred by this warranty are in addition to all rights and remedies in
respect of the product that the consumer has under the Trade Practices Act and
similar state laws.
Proof of Purchase
This warranty is valid for the original purchase and is not transferable. Please keep
your purchase docket or receipt as proof of purchase and as proof of date
on which the purchase was made. The purchase docket (or a copy) or receipt must
be presented with the warranty when making a claim under this warranty.
Service during the Warranty Period
To claim for warranty, contact us on 1300 800 200 or [email protected] to
get an RA# (Return Authorisation Number). Ensure that the RA# is clearly stated
on the outside of the packaging and that the product is properly packaged so that
no damage occurs to the product during transit. Shipping of the product back to us
for warranty will be at your cost. A product return without the RA# or proof of
purchase will not be accepted.
Extent of Warranty
This warranty is limited to defects in workmanship or parts. All defective products
or parts will be repaired or replaced. This warranty does not cover manuals and
packaging.
Normal Wear and Tear
This warranty does not cover normal wear and tear to the product or parts.
Exclusions
This warranty does not cover:
• Calibration costs.
• Any defect caused by an accident, misuse, abuse, improper operation, lack of
reasonable care, unauthorised modification, loss of parts, tampering or
attempted repair by a person not authorised by the distributor.
• Any product that has been damaged by a lightning strike either directly or
indirectly or a main power surge or liquid ingress.
• The product if it is located outside of Australia.
• Any damage caused by improper power input or improper cable connection.

The manufacturer warrants for 3 years of the product
to be free from defects in workmanship or material
(excluding re-calibration) in normal service from the
date of purchase. Manufacturer’s obligation under this
warranty is limited to replacing, adjusting or repairing
the unit if returned along with proof of purchase. This
warranty is void if the unit has been tampered with,
damaged or abused in any way.
It is our aim to provide you with quality products that you can trust. Our products
come with guarantees that cannot be excluded under the Australian Consumer
Law. You are entitled to a replacement or a refund for a major failure and for
compensation for any other reasonably foreseeable loss or damage.
You are also entitled to have the goods repaired or replaced if the goods fail to be of
acceptable quality and the failure does not amount to a major failure.
The Guarantee
The product is guaranteed to be free from defects in workmanship and parts
for a period of 3 years from date of purchase. Defects that occur within this
warranty period, under normal use and care, will be repaired, replaced or refunded
at our discretion, solely at our option with no charge for parts and labour. The
benefits conferred by this warranty are in addition to all rights and remedies in
respect of the product that the consumer has under the Trade Practices Act and
similar state laws.
Proof of Purchase
This warranty is valid for the original purchase and is not transferable. Please keep
your purchase docket or receipt as proof of purchase and as proof of date
on which the purchase was made. The purchase docket (or a copy) or receipt must
be presented with the warranty when making a claim under this warranty.
Service during the Warranty Period
To claim for warranty, contact us on 1300 800 200 or [e-mail] to
get an RA# (Return Authorisation Number). Ensure that the RA# is clearly stated
on the outside of the packaging and that the product is properly packaged so that
no damage occurs to the product during transit. Shipping of the product back to us
for warranty will be at your cost. A product return without the RA# or proof of
purchase will not be accepted.
Extent of Warranty
This warranty is limited to defects in workmanship or parts. All defective products
or parts will be repaired or replaced. This warranty does not cover manuals and
packaging.
Normal Wear and Tear
This warranty does not cover normal wear and tear to the product or parts.
Exclusions
This warranty does not cover:
• Calibration costs.
• Any defect caused by an accident, misuse, abuse, improper operation, lack of
reasonable care, unauthorised modification, loss of parts, tampering or
attempted repair by a person not authorised by the distributor.
• Any product that has been damaged by a lightning strike either directly or
indirectly or a main power surge or liquid ingress.
• The product if it is located outside of Australia.
• Any damage caused by improper power input or improper cable connection.

Serial no.
Product Registration Form
Visit my.andatech.com.au to register your warranty online and
receive calibration reminders. Alternatively, complete this form and
forward to the address below with a copy of your proof of purchase:
Andatech Pty. Ltd.
PO Box 3038, Nunawading VIC 3131, Australia.

Register online at my.andatech.com.au
or complete this form and forward to
