AlcoSense ZENITH+ User manual

Industrial Grade Fuel Cell Breathalyser
Version 5.1. Updated August 2021.

Congratulations on buying your new AlcoSense® Zenith+ breathalyser.
Now, when you are drinking, you can be more aware of your alcohol level before
you get into the car and possibly drive dangerously.
We hope you enjoy owning your AlcoSense® Zenith+ breathalyser. If you have
any questions regarding the unit or want to speak with us further, please visit
andatech.com.au or call 1300 800 200 (between 9am and 5pm Monday to Friday).
Components
Introduction
Hook for using personal mouthpiece
Mouthpiece Slot
Power Button
Digital LCD Display
Battery cover
Groove for
opening cover
Personal
mouthpiece
Mouthpiece

Operating Instructions
Step 1:
Step 2:
Step 3:
Step 4:
Press the power button to switch on the breathalyser.
The breathalyser will warm up until it shows the ‘blow’ sign.
Blow into the mouthpiece in the breathalyser for 4 seconds or until you
hear the unit ‘click’.
The final BAC result will be displayed on the screen for 15 seconds.
To take another breath test, wait at least 3 seconds from when the test
result showed up, then press the power button again before blowing into
the mouthpiece.
Please note:
Holding the power button gives you the total number of uses and the last test results.
The breathalyser will turn off automatically when not in use.
Specifications
Indication of %BAC
Accuracy
Warm-up Time
Response Time
Use mouthpiece
Sensor Type
Power Supply
Weight
Dimensions (mm)
Calibration
Ambient Conditions
0.000 to 0.200% BAC
+/- 0.005 at 0.050% BAC
5 seconds ~ 4 minutes
Within 10 seconds at 0.10% BAC
Only compatible with AlcoSense® mouthpieces
Large industrial grade fuel cell sensor
2 x AAA alkaline batteries
85g including batteries
105 high x 50 wide x 15 deep
Every 6 months
Australian Standards Requirement: 7 months
Operations: 5 - 40 °C
Storage: 0 - 50 °C

Recalibration & Service
The AlcoSense® Zenith+ uses a fuel cell sensor to measure breath alcohol
levels. Depending upon the amount of alcohol registered by the sensor after a
period of time, it will require recalibration.
Andatech recommends the AlcoSense® Zenith+ is calibrated every 6 months.
To maintain it to Australian Standards, calibration every 7 months is required.
Please visit my.andatech.com.au to register your breathalyser and book in a
calibration.
The breath sample was not strong enough to detect a reading. After
warm up, please blow strong and steadily into the mouthpiece.
The battery power is low. Please replace the batteries with new alkaline
batteries.
If you test over 1000 tests, the Zenith+ will display the CAL sign for sec-
onds before warming up. The CAL sign will provide the appropriate time
for calibrating the sensor.
System error – Please send the breathalyser back to the supplier for
repair.
System error – Please send the breathalyser back to the supplier for
repair.
Reading is over 0.200%BAC.
Warning Display
Personal mouthpiece
The Zenith+ features a built-in permanent mouthpiece for personal use.
Push the hook to the side to extend the mouthpiece for personal testing.
To use a separate mouthpiece with the breathalyser, simply insert the
mouthpiece into the mouthpiece slot.

Warranty
The manufacturer warrants for 3 years from the date of purchase, the product to be
free from defects in workmanship or material (excluding recalibration) under normal
use. The manufacturer’s obligation under this warranty is limited to replacing,
adjusting or repairing the unit if returned along with proof of purchase. This warranty
is void if the unit has been tampered with, damaged or abused in any way.
Warnings
a. Allow at least 20 minutes after eating or drinking before testing. Any type of
alcohol remaining in the mouth of saliva may interfere with proper testing
and requires about 20 minutes to disperse. This includes alcohol-based
mouthwash or similar products.
b. Avoid testing in high wind conditions or in poorly ventilated or enclosed spaces.
Poor ventilation may also lengthen the time required for warm up between tests.
c. Do not blow smoke, saliva or other contaminants into the mouthpiece, as the
sensor may become damaged. Wait at least 20 minutes after smoking before
conducting a test.
d. Do not use the breathalyser as a tool to drink and drive.
e. Do not blow fluid into the instrument as it will damage the sensor and void your
warranty.
f. Do not store in an extreme environment where high temperature or high
humidity exists. Keep out of the reach of children.
g. To maintain accuracy, we recommend professional recalibration every 6 months.
h. Blood alcohol concentration can continue to rise for up to 2 hours after the
cessation of drinking. If a caution result or a result is close to the designated
BAC, it is recommended to wait and retest after 20 minutes.
i. It can take 10 hours or more for the alcohol level to return to a zero after a high
blood alcohol level has been reached. A further test should be carried out later
in the day of the following morning.
j. User-serviceable batteries safety:
• Do not dispose of batteries in a fire.
• Do not recharge a battery unless it is specifically marked “rechargeable”.
• Do not expose Zenith+ or batteries to heat source.
• Do not mix old and new batteries, or mix different types or makes of batteries.
• Do not allow children to play with the batteries.

WARRANTY DETAILS
It is our aim to provide you with quality products that you can trust. Our products
come with guarantees that cannot be excluded under the Australian Consumer
Law. You are entitled to a replacement or a refund for a major failure and for
compensation for any other reasonably foreseeable loss or damage.
You are also entitled to have the goods repaired or replaced if the goods fail to be
of acceptable quality and the failure does not amount to a major failure.
The Guarantee
The product is guaranteed to be free from defects in workmanship and parts
for a period of 3 years from date of purchase. Defects that occur within this
warranty period, under normal use and care, will be repaired, replaced or
refunded at our discretion, solely at our option with no charge for parts and
labour. The benefits conferred by this warranty are in addition to all rights and
remedies in respect of the product that the consumer has under the Trade
Practices Act and similar state laws.
Proof of Purchase
This warranty is valid for the original purchase and is not transferable. Please
keep your purchase docket or receipt as proof of purchase and as proof of date
on which the purchase was made. The purchase docket (or a copy) or receipt
must be presented with the warranty when making a claim under this warranty.
Service during the Warranty Period
To claim for warranty, contact us on 1300 800 200 or support@ andatech.com.au
to get an RA# (Return Authorisation Number). Ensure that the RA# is clearly
stated on the outside of the packaging and that the product is properly packaged
so that no damage occurs to the product during transit. Shipping of the product
back to us for warranty will be at your cost. A product return without the RA# or
proof of purchase will not be accepted.

Extent of Warranty
This warranty is limited to defects in workmanship or parts. All defective
products or parts will be repaired or replaced. This warranty does not cover
manuals and packaging.
Normal Wear and Tear
This warranty does not cover normal wear and tear to the product or parts.
Exclusions
This warranty does not cover:
• Calibration costs.
• Any defect caused by an accident, misuse, abuse, improper operation, lack
of reasonable care, unauthorised modification, loss of parts, tampering or
attempted repair by a person not authorised by the distributor.
• Any product that has been damaged by a lightning strike either directly or
indirectly or a main power surge or liquid ingress.
• The product if it is located outside of Australia.
• Any damage caused by improper power input or improper cable connection.

Limits
AUSTRALIAN BLOOD ALCOHOL LIMITS: Adult License 0.05% BAC
Some drivers are restricted to lower levels of BAC. Please refer to your local
transport authority for your correct limit. If in any doubt do not drink and drive.
The safest level when driving is none at all. Alcohol impairs your judgement and
can make you drowsy and sleepy.
Disclaimer
PLEASE NOTE:
This product must be used in accordance with the instructions in this manual
and – in particular - must not be allowed to get wet.
This product is intended to provide the user with an indication of alcohol on the
breath. However, neither the manufacturer nor the supplier gives any warranty
(express or implied) that the product can give any indication of blood alcohol
level.
A person’s BAC (Blood Alcohol Concentration) can only be accurately measured
by the administration of a blood test. This product only measures breath alcohol
content which, in turn, only gives an approximately indication of blood alcohol
concentration.
In these circumstances the user of this product should not rely on the
information provided thereby as an accurate indication of his blood alcohol
concentration or of his level of intoxication or of his fitness to drive and in
particular should not take any action in reliance on such information as the
product can provide no more than an indication of alcohol on the breath.
If the user of this product makes any decision or takes any action based on the
use of the product such decision or such action shall be at the sole risk of the
user and neither the manufacturer nor the supplier assumes any responsibility
for such decision or action. In particular, neither the manufacturer nor the
supplier shall be in any way liable if the user of the product asserts that the
product led him to believe that he was fit to operate a motor vehicle and is
subsequently found not to be so fit.
This product is certified pursuant to Australian Standard AS 3547 as a type 2
hand held quantitative device.
1.
2.
3.
4.
5.
6.

Product Registration Form
Register your AlcoSense Zenith+ warranty, receive calibration reminders
and book in calibrations online at my.andatech.com.au
Alternatively, fill out this form and forward to the address below along
with a copy of your proof of purchase
Andatech Pty Ltd
PO BOX 3038, Nunawading VIC 3131 Australia
Product ...........................................................................................................
Serial Number.................................................................................................
Date of Purchase ............................................................................................
Place of Purchase ...........................................................................................
Surname .........................................................................................................
Given Name .....................................................................................................
Address ...........................................................................................................
Suburb .............................................................................................................
Postcode................................State .................................................................
Contact no. ......................................................................................................
Email ...............................................................................................................
AlcoSense® Zenith+

Product Registration
Register online at my.andatech.com.au
or complete this form and forward to
Andatech Pty Ltd
PO BOX 3038
Nunawading VIC 3131
Australia
Please
Affix
Stamp
here
