aldes MR Mono User manual

Constant Airflow Regulator MR
MR Mono - MR Modulo
Introduction
Range
Principle of operation
Construction and material
Dimensions - weights
Field of application
Aeraulics features
Acoustic features
Installation
Maintenance
Specification text
Application examples
Codes
Complementary offers
Regulation and balacing offer
Advantages

2
Constant Airflow Regulator MR
MR Mono - MR Modulo
INTRODUCTION
RANGE
• Aeraulic disturbances within HVAC systems
generate airflow variations.
• Managing to set real airflows as per those
calculated in design stage, will ensure hygiene
(ventilation) and thermal comfort (air conditioning)
while limiting noise and optimizing fan or AHU
operating costs.
2 models:
• MR Mono: 1 code = 1 factory-set airflow
• MR Modulo: 1 code = several airflow set point
(8 references).
7 diameters (mm): 80, 100, 125, 150, 160, 200 and 250.
3 Pressure ranges:
• between 50 and 250 Pa for the standard MR Mono
and the MR Modulo,
• between 150 and 650 Pa for the MR High Pressure,
• between 80 and 250 Pa for the MR Modulo VMT
(compliant with VMT technical approval).
CONSTRUCTION AND MATERIAL
➀Removable clips in PC / ABS plastic,
➁Regulating silicon membrane,
➂Double-lip airtightness seal in elastomer
➃Housing in PC / ABS plastic,
➄Rotating adjustment ring in PC / ABS plastic for
airflow setting.
The following information is directly indicated on the
product:
• Flow direction, diameter in mm and inch, operating
differential pressure range, code, production
traceability,
• MR Mono: factory airflow calibration (both in m³/h)
and cfm),
• MR Modulo: airflow setting range correlation table
(both in m³/h and cfm).
DIMENSIONS - WEIGHT
Ø B A
Ø
NE
F
Ø B A
Ø N
EF
1
4
3
2
1
3
2
5
4
PRINCIPLE OF OPERATION
• CARs (MR) purpose is airflow balancing in HVAC
ductwork.
• It can be easily inserted into a portion of a circular duct
network in order to regulate an accurate and constant
airflow within a large differential pressure range.
• The membrane inflates or deflates depending on the
pressure drop on both sides of the CAR, changing
consequently the free air passage (see illustration
below).
> This principle guarantees a constant airflow when the
upstream/downstream differential pressure varies.
Q (m3/h)
0
250
in mm MR Mono MR Modulo
Duct Ø ØN ØB E F A Weight
(kg)
F A Weight
(kg)
80 76 85 14 3 53 0,06 15 65 0,08
100 92 105 14 4 61 0,10 13 70 0,12
125
15-95 m³/h
116 132 14 4 61 0,14 13 70 0,15
125
100-190 m³/h
116 132 14 4 97 0,20 17 110 0,17
150 147 153 14 4 103 0,30 19 118 0,37
160 153 167 14 4 103 0,30 19 118 0,37
200 190 210 20 7 130 0,60 23 144 0,59
250 238 262 20 5 159 1,06 26 179 1,02
MR Mono
MR Modulo
MR Mono MR Modulo

3
Constant Airflow Regulator MR
MR Mono - MR Modulo
FIELD OF APPLICATION
• Maintaining airflows in ventilation or air conditioning
ductworks.
• Use in air supply and air exhaust.
• Operating airflow range (see diagrams).
• Tolerance in airflow over operating range:
- +/- 5 m³/h for an airflow ≤50 m³/h except VMT MR,
- +/- 10 % for an airflow > 50 m³/h except VMT MR,
- 0/+30% for VMT MR (to ensure compliance with
technical approval).
• Functional differential pressures:
- MR Modulo and standard MR: range between 50
and 250 Pa,
- MR Mono High Pressure: range between 150 and
650 Pa,
- MR Modulo VMT: range between 80 and 250 Pa.
• Temperature range of use: -10 to 60° C.
• Compliant with DIN EN 1506 (dimensions).
MR Mono Standard
MR Mono HP
MR Modulo Standard
0
(15-60 m3/h)
(15-90 m3/h)
(15-95-190 m3/h)
(110-240 m3/h)
(200-400 m3/h)
(300-650 m3/h)
100 200 300 400 500 600 800700
Q (m3/h)
Ø 80
Ø 100
Ø 125
Ø 150 / Ø 160
Ø 200
Ø 250
0200 400 600 1200800 1000
Q (m3/h)
Ø 125 (120-300 m3/h)
Ø 150 / Ø 160 (140-425 m3/h)
Ø 200 (350-700 m3/h)
Ø 250 (550-1000 m3/h)
0100 200 300 400 500 600 800700
Q (m3/h)
Ø 80
Ø 100
Ø 125Ø 125
Ø 150 / Ø 160
Ø 200
Ø 250
(20-60 m3/h)
(15-90 m3/h)
(15-85 / 100-190 m3/h)
(100-240 m3/h)
(225-400 m3/h)
(300-650 m3/h)
AERAULIC FEATURES
The curves for each diameter of the MR Mono standard, MR Mono High Pressure and MR Modulo are available on request.

4
Ø 80 Differiencial Pressure DP (Pa)
Airflow
(m3/h)
50 Pa 100 Pa 150 Pa 200 Pa
125 Hz 250 Hz 500 Hz 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A)) 125 Hz 250 Hz 500 HZ 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A)) 125 Hz 250 Hz 500 HZ 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A)) 125 Hz 250 Hz 500 HZ 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A))
15 25 21 21 15 14 9 6 23 25 30 30 27 28 23 19 34 25 32 34 34 34 31 25 40 26 34 38 40 40 37 31 45
20 25 22 22 16 15 9 6 24 26 31 31 28 28 24 19 34 26 34 35 34 35 31 26 40 27 36 38 40 40 38 32 46
25 25 23 23 17 15 10 7 24 26 32 31 28 29 24 19 35 27 35 35 34 35 32 26 41 28 37 39 40 41 38 33 46
30 25 24 23 18 16 10 7 25 27 32 32 29 29 25 19 36 28 36 36 35 36 32 27 41 29 39 40 40 41 38 33 46
35 25 25 24 18 17 11 7 25 27 33 32 29 30 25 20 36 28 37 37 35 36 32 27 42 30 41 40 40 42 39 34 47
40 25 25 24 19 18 11 8 26 28 34 33 30 30 26 20 36 29 38 37 35 37 33 28 42 31 42 41 40 42 39 35 47
45 25 26 25 20 18 12 8 27 28 35 33 30 31 26 20 37 30 39 38 36 37 33 28 43 32 44 42 40 43 39 36 48
50 25 27 26 21 19 12 8 27 29 35 33 31 32 27 20 37 31 41 38 36 38 34 29 43 33 45 43 40 43 40 36 48
60 25 29 27 23 20 13 9 29 30 37 34 32 33 28 21 39 33 43 40 36 39 35 30 44 36 49 44 41 44 41 38 49
Ø100 Differiencial Pressure DP (Pa)
Airflow
(m3/h)
50 Pa 100 Pa 150 Pa 200 Pa
125 Hz 250 Hz 500 Hz 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A)) 125 Hz 250 Hz 500 HZ 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A)) 125 Hz 250 Hz 500 HZ 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A)) 125 Hz 250 Hz 500 HZ 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A))
15 30 27 25 19 15 7 7 26 29 28 31 30 28 22 20 35 29 32 34 36 37 33 32 42 31 36 37 41 45 44 45 51
20 29 27 25 19 15 7 7 26 29 28 31 30 28 23 20 35 29 33 34 36 37 33 32 42 31 37 38 41 45 43 44 50
25 28 27 25 19 16 8 7 26 28 29 32 30 28 23 20 35 29 33 35 36 37 33 31 42 32 37 38 41 45 43 43 50
30 27 27 25 19 16 8 7 27 28 30 32 30 29 24 20 35 30 34 35 36 37 33 31 42 32 37 39 41 44 42 41 49
35 26 27 25 20 16 8 7 27 28 30 32 30 29 24 20 36 30 34 36 36 37 33 30 42 32 38 39 41 44 42 40 49
40 25 27 25 20 17 8 7 27 28 31 33 30 30 25 20 36 30 35 36 36 37 33 30 42 33 38 40 41 44 41 39 49
50 22 27 26 20 18 9 7 27 28 33 34 30 31 26 21 37 31 36 38 36 37 34 28 43 34 40 42 41 43 41 35 48
55 23 27 26 20 17 9 7 27 28 32 33 30 31 26 20 37 31 36 37 36 37 34 29 43 34 39 41 41 43 41 36 48
60 22 27 26 20 18 9 7 27 28 34 34 30 32 27 21 38 31 37 39 36 37 34 28 43 34 40 43 41 43 41 34 48
65 23 28 26 21 19 10 8 28 29 34 34 31 32 27 21 38 32 38 39 36 38 34 28 43 35 41 43 42 43 41 34 48
70 25 28 26 21 19 10 9 28 29 35 35 31 32 27 20 38 33 39 39 37 38 35 27 43 36 42 43 42 43 41 34 49
75 26 29 26 22 20 11 10 28 30 36 35 31 33 28 20 38 34 40 40 37 38 35 27 44 37 43 44 42 43 41 34 49
85 29 30 27 23 22 13 13 30 32 38 35 32 33 29 20 39 36 42 40 37 39 35 27 44 39 46 45 42 44 41 34 49
90 31 30 27 24 22 13 14 30 33 39 36 32 34 29 19 40 37 43 41 37 39 36 27 45 40 47 45 42 44 41 34 50
Ø 125 Differiencial Pressure DP (Pa)
Airflow
(m3/h)
50 Pa 100 Pa 150 Pa 200 Pa
125 Hz 250 Hz 500 Hz 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A)) 125 Hz 250 Hz 500 HZ 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A)) 125 Hz 250 Hz 500 HZ 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A)) 125 Hz 250 Hz 500 HZ 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A))
15 24 30 27 20 15 6 13 28 27 33 36 33 31 24 21 38 29 34 38 37 35 30 29 42 31 34 40 40 39 36 36 46
25 25 30 28 21 16 7 14 28 28 33 35 33 31 24 21 38 30 34 38 37 35 30 28 42 31 35 40 40 39 37 35 46
30 25 30 28 21 16 8 14 28 28 33 35 33 31 24 21 38 30 34 38 37 35 31 28 42 32 35 40 40 39 37 34 46
45 26 31 28 23 17 9 14 29 29 33 35 33 32 23 20 38 31 35 38 37 36 31 27 42 33 37 41 40 39 38 33 46
50 27 31 28 23 18 10 14 29 29 34 35 34 32 23 19 38 31 35 38 37 36 31 26 42 33 37 41 40 40 38 33 46
60 28 31 28 24 19 11 14 30 30 34 35 34 33 23 19 39 32 36 38 37 36 32 25 42 34 38 41 40 40 39 32 46
65 29 31 28 25 19 11 14 30 30 34 34 34 33 23 19 39 32 36 38 37 37 32 25 42 34 39 41 40 40 39 31 46
70 29 31 28 25 20 12 14 30 31 34 34 34 33 23 18 39 33 37 38 37 37 32 25 42 35 39 41 40 41 40 31 47
75 30 31 28 26 20 12 14 30 31 34 34 34 34 23 18 39 33 37 38 37 37 32 24 43 35 39 41 40 41 40 31 47
80 31 31 28 26 20 13 14 31 31 34 34 34 34 23 18 39 33 37 38 37 37 32 24 43 35 40 41 41 42 41 30 47
85 31 31 28 26 21 13 15 31 32 34 34 34 34 23 18 39 34 37 38 37 38 33 24 43 36 40 41 41 43 41 30 48
90 32 31 29 27 21 14 15 31 32 34 34 34 35 23 17 39 34 38 38 38 38 33 23 43 36 41 41 41 43 42 29 48
95 32 32 29 28 22 14 15 32 32 34 34 34 35 23 17 40 35 38 38 38 38 33 23 43 37 41 41 41 44 42 29 49
ACOUSTIC FEATURES
Sound power levels of noise (Lw) at duct output:
The following tables give the sound power levels of noise (Lw) expressed in decibels per octave (dB/oct) as well as the global sound power levels
in dB(A) according to the pressure drop.
These sound power levels are results of tests carried out by a Dutch independent laboratory (PEUTZ) and are given at the duct outlet.
Measures were carried out in accordance with NF EN ISO 3741 and NF EN ISO 5135 norms, with a CAR fitted into a duct with an upstream and
downstream straight length equal to 3 diameters.
Constant Airflow Regulator MR
MR Mono Standard

5
Ø 160 Differiencial Pressure DP (Pa)
Airflow
(m3/h)
50 Pa 100 Pa 150 Pa 200 Pa
125 Hz 250 Hz 500 Hz 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A)) 125 Hz 250 Hz 500 HZ 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A)) 125 Hz 250 Hz 500 HZ 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A)) 125 Hz 250 Hz 500 HZ 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A))
110 28 31 32 28 27 19 14 34 34 36 38 41 39 32 23 45 38 42 44 46 45 39 31 50 41 46 49 51 49 45 38 57
120 29 30 31 28 26 18 14 34 35 37 39 40 38 31 22 44 39 42 44 46 44 38 30 50 43 47 49 50 49 44 38 56
130 29 30 31 27 25 17 13 33 36 37 39 39 38 30 22 43 40 43 44 45 43 37 30 49 44 47 49 50 48 44 38 56
140 29 30 30 26 23 15 13 32 36 38 39 38 37 30 22 43 41 43 45 44 42 37 30 49 46 48 50 49 47 43 38 56
150 29 30 30 26 22 14 13 32 37 38 39 38 36 29 21 42 43 44 45 44 41 36 30 48 47 49 50 49 46 43 38 56
160 29 30 29 25 21 12 13 31 38 39 39 37 35 28 21 42 44 44 45 43 41 35 30 48 49 49 50 49 46 42 38 57
170 30 29 29 25 20 11 13 31 39 39 39 37 34 27 21 42 45 45 45 43 40 35 30 48 50 50 50 49 45 42 38 57
180 30 29 28 24 19 10 13 31 39 40 39 36 33 26 20 41 46 46 45 43 39 34 30 48 52 50 51 49 44 41 39 58
190 30 29 29 24 19 10 13 30 40 40 39 36 33 26 21 41 46 46 45 43 39 34 30 47 52 51 51 48 44 41 38 58
200 30 30 29 24 19 10 13 30 40 40 40 36 33 26 21 41 47 46 46 43 39 34 29 48 52 51 51 48 44 41 37 58
210 30 30 29 24 19 10 13 30 41 40 40 36 33 26 21 42 47 46 46 43 39 34 29 48 52 51 51 48 45 41 36 58
240 30 31 29 24 18 10 14 30 42 41 40 37 33 26 21 42 48 46 46 42 40 34 28 48 53 51 51 47 45 41 35 59
Ø 200 Differiencial Pressure DP (Pa)
Airflow
(m3/h)
50 Pa 100 Pa 150 Pa 200 Pa
125 Hz 250 Hz 500 Hz 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A)) 125 Hz 250 Hz 500 HZ 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A)) 125 Hz 250 Hz 500 HZ 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A)) 125 Hz 250 Hz 500 HZ 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A))
225 27 26 23 19 13 8 14 25 36 35 34 30 27 21 15 36 41 41 40 36 34 29 20 42 45 46 45 42 39 35 26 47
250 29 28 25 21 16 10 15 27 38 37 35 33 29 23 16 37 42 42 41 38 36 30 22 43 47 47 46 43 41 37 27 48
275 30 29 26 23 18 12 16 28 39 38 36 35 31 24 17 39 44 43 41 40 38 32 23 45 48 47 46 44 44 39 28 50
300 32 31 27 25 20 14 16 30 41 40 37 38 32 26 18 41 46 44 42 42 40 33 24 46 51 48 47 46 46 40 30 51
325 33 33 29 27 21 15 16 32 42 41 38 39 34 28 20 42 46 46 44 43 41 35 26 48 50 50 49 47 47 41 31 53
350 35 34 30 29 23 17 17 33 44 43 39 40 35 29 23 44 47 47 45 44 42 36 27 49 50 51 51 48 48 42 32 54
400 38 37 33 33 27 20 17 37 46 46 42 43 38 33 27 47 48 50 48 47 44 38 31 52 50 55 54 51 49 43 34 56
Ø 250 Differiencial Pressure DP (Pa)
Airflow
(m3/h)
50 Pa 100 Pa 150 Pa 200 Pa
125 Hz 250 Hz 500 Hz 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A)) 125 Hz 250 Hz 500 HZ 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A)) 125 Hz 250 Hz 500 HZ 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A)) 125 Hz 250 Hz 500 HZ 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A))
300 34 30 24 17 19 12 13 28 47 41 36 36 32 26 20 41 53 47 42 33 37 34 27 45 60 51 48 32 41 40 34 50
350 35 31 26 21 20 13 13 29 48 42 38 38 33 27 21 42 52 47 43 37 38 34 28 46 57 51 49 37 43 40 34 51
400 36 32 28 25 21 13 13 31 48 43 39 40 34 28 21 43 51 47 45 41 40 35 28 48 54 52 50 43 45 41 34 52
450 36 33 31 29 21 14 13 33 49 43 41 42 35 28 21 45 50 48 47 45 41 35 28 50 52 52 52 49 47 42 34 54
500 37 34 33 35 22 14 13 37 49 44 43 44 35 29 22 47 49 48 49 50 43 36 28 53 49 53 55 55 50 42 34 58
550 38 35 34 35 23 16 14 37 49 45 44 45 37 30 22 48 50 49 49 50 44 36 29 53 51 53 54 54 49 42 35 57
650 40 36 36 36 26 18 14 39 48 46 46 47 40 32 22 50 50 50 50 50 44 37 30 53 53 53 54 53 48 41 36 57
100 31 33 30 25 15 11 15 31 36 39 40 37 29 25 19 41 39 41 44 43 35 32 26 47 42 43 48 49 41 38 32 51
110 32 33 30 26 16 12 15 31 38 40 40 37 30 26 20 41 41 43 45 43 36 33 27 47 45 45 49 49 42 39 33 52
120 33 33 30 26 17 13 15 31 40 41 40 38 32 27 21 42 44 44 45 44 38 34 28 47 48 47 50 49 43 40 35 53
130 34 33 30 27 18 14 16 32 42 41 40 38 33 28 22 42 47 46 45 44 39 35 29 48 51 49 50 50 44 41 36 53
140 36 33 30 27 20 15 16 32 44 42 40 39 34 29 23 43 49 47 46 45 40 36 30 49 54 52 51 50 45 43 37 54
150 37 33 30 28 21 16 17 32 47 43 40 40 36 30 24 44 52 49 46 45 41 37 32 50 57 54 51 51 47 44 39 55
160 38 33 30 28 22 16 17 33 49 43 40 40 37 31 24 45 55 50 47 46 43 38 33 51 60 56 52 51 48 45 40 56
190 42 34 31 29 25 19 19 35 56 46 40 43 41 33 27 48 63 55 48 49 46 41 36 54 69 63 54 54 51 48 44 61
Ø 125 Differiencial Pressure DP (Pa)
Airflow
(m3/h)
50 Pa 100 Pa 150 Pa 200 Pa
125 Hz 250 Hz 500 Hz 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A)) 125 Hz 250 Hz 500 HZ 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A)) 125 Hz 250 Hz 500 HZ 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A)) 125 Hz 250 Hz 500 HZ 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A))
Constant Airflow Regulator MR

6
ACOUSTIC FEATURES
Sound power levels of noise (Lw) at duct output:
The following tables give the sound power levels of noise (Lw) expressed in decibels per octave (dB/oct) as well as the global sound power levels
in dB(A) according to the pressure drop.
These sound power levels are results of tests carried out by a Dutch independent laboratory (PEUTZ) and are given at the duct outlet.
Measures were carried out in accordance with NF EN ISO 3741 and NF EN ISO 5135 norms, with a CAR fitted into a duct with an upstream and
downstream straight length equal to 3 diameters.
Constant Airflow Regulator MR
MR Modulo
Ø 80 Differiencial Pressure DP (Pa)
Airflow
(m3/h)
50 Pa 100 Pa 150 Pa 200 Pa
125 Hz 250 Hz 500 Hz 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A)) 125 Hz 250 Hz 500 HZ 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A)) 125 Hz 250 Hz 500 HZ 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A)) 125 Hz 250 Hz 500 HZ 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A))
15 19 25 24 18 21 7 6 26 19 29 30 28 32 22 18 36 25 35 36 36 43 34 22 45 31 40 42 43 53 48 26 56
20 19 25 24 19 21 8 7 26 20 30 31 29 32 23 18 36 26 35 36 36 42 34 23 45 31 41 42 43 52 47 27 55
25 20 25 24 19 21 8 7 27 21 30 31 29 32 23 19 36 27 36 37 36 42 34 24 45 32 41 42 43 51 46 29 54
30 20 25 24 20 21 8 8 27 22 31 31 29 32 24 19 37 28 37 37 36 42 34 25 45 33 42 42 42 50 45 31 53
35 20 25 24 20 21 9 8 27 23 32 32 30 33 25 19 37 29 37 37 36 41 35 26 44 33 42 42 42 49 45 33 52
40 20 26 24 21 21 9 8 27 24 32 32 30 33 25 20 37 30 38 37 36 41 35 27 44 34 43 42 42 48 44 34 51
45 20 26 24 21 21 10 9 27 26 33 32 30 33 26 20 37 30 38 37 36 40 35 28 44 35 44 42 42 47 44 36 51
50 21 26 24 21 21 10 9 27 27 33 33 31 33 27 20 38 31 39 38 36 40 35 30 44 36 44 42 41 46 43 38 50
60 21 26 25 22 21 12 10 28 29 34 34 31 33 29 21 39 33 40 38 36 39 36 32 44 37 45 42 41 44 43 41 50
Ø 100 Differiencial Pressure DP (Pa)
Airflow
(m3/h)
50 Pa 100 Pa 150 Pa 200 Pa
125 Hz 250 Hz 500 Hz 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A)) 125 Hz 250 Hz 500 HZ 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A)) 125 Hz 250 Hz 500 HZ 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A)) 125 Hz 250 Hz 500 HZ 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A))
15 20 26 22 14 15 8 3 23 24 32 31 29 25 18 17 34 31 32 35 34 34 31 29 40 38 32 38 38 43 43 40 48
20 21 27 22 15 14 8 4 24 25 32 32 30 25 19 17 34 31 33 35 34 34 31 28 40 37 33 39 39 42 42 39 48
25 22 27 23 16 14 8 6 24 25 33 33 30 26 19 17 35 31 34 36 35 34 31 28 41 36 34 39 40 42 42 38 48
30 23 27 24 17 14 8 7 25 26 33 33 31 27 20 17 35 31 35 37 36 35 31 27 41 35 36 40 41 42 41 37 48
35 23 28 24 18 15 8 8 25 27 34 34 31 27 21 17 36 31 35 38 37 35 31 27 42 34 37 41 41 42 41 36 48
45 24 28 25 19 15 7 9 26 27 34 35 32 28 21 17 37 31 36 39 37 35 31 26 42 34 38 42 42 42 40 35 48
50 27 30 28 21 15 7 13 28 29 36 37 34 30 23 17 39 31 39 41 40 36 31 25 44 32 42 45 45 42 39 32 49
55 26 29 27 20 15 7 11 27 29 35 36 34 29 22 17 38 31 38 40 39 36 31 25 43 32 40 44 44 42 40 33 49
60 28 31 28 22 15 7 14 29 30 36 38 35 30 24 18 40 31 40 42 41 37 32 24 45 31 43 46 46 42 39 31 50
65 27 30 27 22 16 7 14 29 30 36 37 34 31 24 18 39 31 40 42 40 37 32 25 44 32 43 46 45 43 39 32 50
70 26 29 27 22 16 8 14 28 30 36 37 34 31 24 18 39 32 40 41 39 38 33 25 44 33 44 45 44 43 40 32 49
75 26 28 26 21 17 8 14 28 30 36 36 33 32 25 18 39 32 41 41 39 38 33 26 44 34 45 45 44 44 41 33 50
80 24 27 24 21 18 9 14 27 30 37 35 32 33 26 18 38 33 42 40 38 40 34 27 45 36 46 44 42 46 42 35 50
90 23 26 24 20 18 10 14 27 31 37 34 32 34 26 18 39 34 42 39 37 40 35 27 45 37 47 44 42 47 42 35 51
Ø 125 Differiencial Pressure DP (Pa)
Airflow
(m3/h)
50 Pa 100 Pa 150 Pa 200 Pa
125 Hz 250 Hz 500 Hz 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A)) 125 Hz 250 Hz 500 HZ 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A)) 125 Hz 250 Hz 500 HZ 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A)) 125 Hz 250 Hz 500 HZ 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A))
15 32 23 22 19 16 4 2 24 29 29 28 28 33 15 15 36 31 31 32 31 36 26 24 39 33 32 35 34 47 37 32 49
25 32 25 23 20 17 5 5 26 31 31 30 29 33 17 15 36 33 33 34 33 36 28 24 40 35 35 38 37 45 37 32 47
30 32 26 24 21 17 6 6 26 32 32 31 30 32 18 15 37 34 34 36 34 36 28 24 41 35 36 39 38 43 37 32 47
45 33 29 26 22 19 8 10 28 34 35 35 32 32 21 16 38 36 38 39 37 37 30 24 43 37 41 44 42 42 37 31 48
50 33 30 27 23 19 9 12 29 35 36 36 33 32 22 17 38 36 39 41 38 37 30 24 44 38 42 45 44 42 38 31 49
60 34 32 28 24 20 11 15 30 36 38 38 34 32 24 17 40 38 42 43 40 38 32 24 46 39 45 49 46 43 38 30 51
65 34 33 29 24 20 12 16 31 37 39 39 35 32 25 17 40 39 43 45 41 38 32 24 46 40 46 50 48 44 38 30 52
70 34 34 30 25 21 13 18 32 38 40 40 35 32 26 18 41 39 44 46 42 39 33 24 47 41 48 52 49 45 38 30 53
75 34 35 31 25 21 14 19 32 39 42 41 36 32 27 18 42 40 46 47 44 39 33 24 48 42 49 53 50 46 39 29 54
80 35 36 31 26 22 14 20 33 39 43 43 37 32 29 18 43 41 47 49 45 39 34 24 49 42 51 55 52 47 39 29 56
85 35 37 32 27 22 15 22 34 40 44 44 37 32 30 19 44 42 48 50 46 40 34 24 50 43 52 56 53 48 39 29 57
90 35 38 33 27 23 16 23 35 41 45 45 38 32 31 19 45 42 49 51 47 40 35 24 51 44 54 58 54 48 39 29 59
95 36 39 34 28 23 17 25 36 42 46 46 39 33 32 19 46 43 51 53 48 40 36 24 53 45 55 60 56 49 39 28 60

7
Constant Airflow Regulator MR
Ø 160 Differiencial Pressure DP (Pa)
Airflow
(m3/h)
50 Pa 100 Pa 150 Pa 200 Pa
125 Hz 250 Hz 500 Hz 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A)) 125 Hz 250 Hz 500 HZ 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A)) 125 Hz 250 Hz 500 HZ 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A)) 125 Hz 250 Hz 500 HZ 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A))
110 31 31 30 24 19 10 12 33 36 37 40 34 31 25 17 40 38 40 44 39 37 32 26 45 39 43 48 44 43 38 33 52
120 31 31 30 24 19 11 13 32 37 38 40 34 31 25 17 41 39 41 44 40 37 32 26 46 41 44 48 44 43 39 33 53
130 31 31 30 24 19 11 13 31 38 38 40 35 32 26 18 41 41 42 44 40 38 33 26 46 42 45 49 44 43 39 33 53
140 31 31 30 25 20 11 13 31 39 39 40 36 32 26 18 41 42 43 45 40 38 33 26 46 44 47 49 45 44 39 33 54
150 31 31 30 25 20 11 13 31 40 40 40 36 33 26 18 41 43 44 45 41 39 33 26 46 46 48 49 45 44 39 33 55
160 31 31 30 26 20 11 13 31 42 41 39 37 33 27 19 42 44 45 45 41 39 33 26 47 47 49 50 45 44 40 33 56
170 31 31 30 26 21 12 14 31 43 41 39 38 34 27 19 42 46 46 45 42 40 34 27 47 49 51 50 45 45 40 33 56
180 32 31 30 27 21 12 14 32 44 42 39 39 34 27 20 43 47 47 45 42 40 34 27 48 50 52 50 45 45 40 33 57
190 31 31 30 27 22 13 14 32 43 42 39 39 35 28 21 43 47 47 45 42 40 34 27 48 50 51 50 45 45 40 33 57
200 31 31 30 27 22 13 14 32 43 42 39 39 35 29 21 43 47 46 45 42 40 35 28 47 50 51 49 45 44 40 33 56
210 30 31 31 28 22 14 14 32 43 41 39 39 36 30 22 43 47 46 45 42 40 35 28 47 50 50 49 45 44 40 34 56
240 29 31 31 28 23 17 13 33 42 40 40 40 37 32 25 44 46 44 44 42 40 37 30 48 50 48 48 44 43 40 34 55
Ø 200 Differiencial Pressure DP (Pa)
Airflow
(m3/h)
50 Pa 100 Pa 150 Pa 200 Pa
125 Hz 250 Hz 500 Hz 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A)) 125 Hz 250 Hz 500 HZ 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A)) 125 Hz 250 Hz 500 HZ 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A)) 125 Hz 250 Hz 500 HZ 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A))
225 29 27 24 23 18 11 13 27 39 39 36 33 31 26 18 39 43 42 41 39 37 32 24 44 46 45 46 44 42 38 29 49
250 30 28 26 24 19 12 13 29 41 40 37 35 33 26 19 40 44 43 42 40 38 32 24 45 47 47 45 44 42 37 28 49
275 31 30 27 26 20 13 13 30 42 41 38 38 34 27 20 42 46 45 42 41 38 32 24 45 49 48 45 44 42 36 27 49
300 32 32 29 27 21 14 14 31 44 41 39 40 36 28 21 44 47 46 42 42 39 32 23 46 50 50 45 44 42 35 26 49
325 34 33 30 29 23 16 14 33 45 42 40 41 37 30 23 44 48 47 44 43 40 34 26 48 51 51 48 45 44 38 28 51
350 36 34 31 31 25 18 15 35 46 43 40 42 37 31 25 45 49 48 46 44 42 36 28 49 52 53 52 47 46 40 31 53
400 39 37 34 35 28 21 17 38 48 45 42 43 39 34 28 47 51 51 50 47 45 40 32 53 55 57 59 50 50 44 36 58
Ø 250 Differiencial Pressure DP (Pa)
Airflow
(m3/h)
50 Pa 100 Pa 150 Pa 200 Pa
125 Hz 250 Hz 500 Hz 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A)) 125 Hz 250 Hz 500 HZ 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A)) 125 Hz 250 Hz 500 HZ 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A)) 125 Hz 250 Hz 500 HZ 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A))
300 38 33 29 25 22 12 12 33 44 38 40 40 31 22 15 42 43 44 42 38 37 29 22 44 43 49 44 36 41 36 30 47
350 38 33 30 27 22 13 12 33 46 40 41 41 33 24 17 44 46 46 44 41 38 31 24 46 46 51 46 40 43 38 32 49
400 38 34 31 30 23 13 13 34 47 42 42 43 34 26 18 46 49 47 45 44 40 33 26 48 50 52 48 44 45 40 33 52
450 37 34 33 33 23 14 13 36 49 44 43 45 36 28 20 47 51 49 47 47 42 35 28 50 54 54 51 49 47 42 35 54
500 37 34 34 36 24 15 14 38 50 46 45 47 37 29 22 49 54 51 49 50 43 37 30 53 58 55 53 53 49 44 37 57
550 38 36 37 38 26 18 15 40 50 46 45 47 38 31 23 49 53 51 49 50 44 38 31 53 57 55 53 54 50 44 37 57
650 40 39 41 42 31 23 18 44 49 46 46 46 40 33 25 50 52 50 50 51 45 39 32 54 55 54 54 55 51 45 38 58
100 36 35 32 30 25 16 14 34 43 43 42 39 36 31 23 44 46 45 47 45 41 38 32 50 48 48 51 50 46 44 39 54
110 36 35 31 30 25 17 15 34 43 43 42 39 36 31 24 44 47 46 47 45 42 38 32 50 50 48 51 50 47 45 40 55
120 36 34 31 30 25 18 15 34 44 43 42 40 36 31 24 44 48 46 47 46 43 39 33 50 52 49 52 51 48 45 40 55
130 37 34 31 29 25 18 16 34 44 42 41 40 37 32 25 44 50 47 47 46 43 40 33 51 54 50 52 51 49 46 41 56
140 37 34 31 29 25 19 17 34 45 42 41 40 37 32 25 45 51 47 47 47 44 40 34 51 56 51 52 52 50 47 42 57
150 37 34 31 29 24 20 17 34 45 42 41 41 37 33 26 45 52 47 47 47 45 41 34 52 58 52 53 53 51 48 42 58
160 38 34 31 29 24 20 18 34 46 42 41 41 38 33 26 46 54 48 47 48 46 42 35 53 61 53 53 54 53 49 43 59
190 39 33 31 29 24 22 20 34 47 41 41 43 39 35 28 46 58 49 48 50 48 44 37 54 67 57 54 56 56 51 46 62
Ø 125 Differiencial Pressure DP (Pa)
Airflow
(m3/h)
50 Pa 100 Pa 150 Pa 200 Pa
125 Hz 250 Hz 500 Hz 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A)) 125 Hz 250 Hz 500 HZ 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A)) 125 Hz 250 Hz 500 HZ 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A)) 125 Hz 250 Hz 500 HZ 1000 Hz 2000 Hz 4000 Hz 8000 Hz Overall Lw (dB(A))

8
INSTALLATION
• The MR will push-fit into circular ducts in close proximity to a take-off or a terminal.
• It is important to observe the MR orientation corresponding to the airflow direction indicated on the MR.
• Horizontal / vertical mounting possible.
• In order to avoid acoustic and aeraulic disturbance it is recommended to respect the following distance between the MR and the terminal
(grille / diffuser / inlet):
- in exhaust: D = 1 Ø,
- in supply: D = 3 Ø.
MR Modulo mounting and setting
Air exhaust
1 Ø
Ø
1. Adujst the airflow setting
Rotate the adjustment ring for a tool-free airflow setting until the desired airflow according to the correlation table.
2. Position the MR Modulo
Introduce the MR in the duct according to the arrow which shows
the airflow direction. Minimum straight upstream and downstream
distances must be observed. There is no recommendation regarding
the membane positioning.
3. Product localization
MR Modulo is delivered with a sticker which will be needed to be
manually filled on site (MR diameter and airflow setting) and placed
directly onto the duct to show where the MR Modulo has been
mounted.
Big diametersSmall diameters
Constant Airflow Regulator MR
MR Mono - MR Modulo
360°
125
140
Air supply
Ø
3 Ø

9
INSTALLATION
MAINTENANCE
• MR performances are not altered by clogging, therefore it requires practically no special maintenance.
• If used in an atmosphere where there is a lot of particles, sleeves with inspection window (see MAF page 14) are recommended to allow regular
inspection.
• Clean with soapy water. When cleaning, plug the hole on the plastic body, at the base of the bulb, in order to avoid any blocking of this orifice and
to prevent any liquid or foreign body from passing inside the bulb..
m3/h cfm
K 100 59
J 110 65
I 120 71
H 130 76
G 140 82
E 150 88
C 160 94
A 190 112
Constant Airflow Regulator MR
MR Modulo
Ø 125 (100 à 190 m3/h)
m3/h cfm
R 100 59
P 110 65
O 120 71
M 130 76
L 140 82
K 150 88
J 160 94
H 170 100
G 180 106
F 190 112
E 200 118
D 210 124
A 240 141
m3/h cfm
U 225 132
S 250 147
Q 275 162
N 300 177
M 325 191
J 350 206
D 400 235
m3/h cfm
U 300 177
R 355 209
O 400 235
L 450 265
I 500 294
G 550 324
A 650 383
Ø 150 - Ø 160 Ø 200 Ø 250
m3/h cfm m3/h cfm
K 20 12 - -
J 25 15 - -
H 30 18 - -
G 35 21 45 26
F 40 24 50 29
B 45 26 60 35
m3/h cfm m3/h cfm
L 15 9 - -
J 20 12 - -
H 25 15 - -
F 30 18 - -
E 35 21 70 41
D 40 24 75 44
C 45 26 80 47
A 55 32 90 53
m3/h cfm m3/h cfm
L 15 9 - -
I 25 15 - -
G - - 60 35
F 30 18 65 38
D - - 70 41
C - - 75 44
B 45 26 80 47
A 50 29 85 50
Ø 80 Ø 100 Ø 125 (15 à 85 m3/h)
Correlation table
MR MODULO SPECIFICATION TEXT
• CARs will be manufactured from ABS plastic without chlorine. They will provide a constant airflow rate, for use in air conditioning
and ventilation systems. They will include an airflow adjustment system and a regulation system as describe below:
- regulation mechanism with a stainless steel spring and a silicone membrane,
- airflow setting system thanks to an adjustment rotating ring (tool-free).
They provide accuracy in airflow over a differential pressure range between 50 and 250 Pa, of:
• +/- 5 m³/h for airflow ≤50 m³/h,
• +/- 10% for airflow > 50 m³/h.
Installation will be possible in duct and accessories as well independent of orientation.
Positioning and sealing will be ensured by a double-lip seal in elastomer.
Type MR Modulo, Aldes brand.
For certain diameters, the same letter on the ring may correspond to two airflow values.
To enable this, the shim must be inserted or removed .
m3/h m3/h
With
wedge
Without
wedge
E 36 -
D 40 74
C 45 80
B 50 -
A 55 84
Ø 125 VMT
(36 à 84 m3/h)
Ø 170 VMT
(100 à 180 m3/h)
Ø 160 VMT Ø 200 VMT Ø 250 VMT
m3/h
K 100
J 110
I 120
H 125
G 140
E 145
D 150
B 155
A 170
m3/h
P 120
O 125
N 130
M 140
L 145
J 155
I 170
H 185
F 195
E 200
m3/h
U 230
T 255
S 270
R 280
Q 290
P 305
O 315
M 325
L 340
K 350
J 360
I 370
H 380
F 390
D 400
C 410
A 420
m3/h
W 260
V 270
U 280
T 295
S 310
R 325
Q 345
O 365
M 380
L 400
K 425

10
APPLICATION EXAMPLE
Airflow stabilization within an HVAC
network portion
Ø
3 Ø3 Ø
Exhausted airflow stabilization
1/ MR installed after a supply plenum box
3/ MR installed before a fancoil
2/ MR installed after a BIM-type grille
• In exhaust, a 1Ø-distance is recommended between
the CAR and the terminal to insure air velocity
harmonization in the duct to avoid aeraulic and
acoustic disturbance.
1 Ø
Ø
Ø
1 Ø
Ø
1 Ø
2/ MR installed before a BIM-type grille
Ø
3 Ø
Supply airflow stabilization
throughout a terminal
• In supply as well a 3Ø-distance is recommended
between the CAR and the terminal to insure air
velocity harmonization in the duct to avoid aeraulic
and acoustic disturbance.
1/ MR installed before a supply plenum box
3 Ø
Ø
3 Ø
Ø
Constant Airflow Regulator MR
MR Mono - MR Modulo

11
Constant Airflow Regulator MR
STANDARD RANGE CODES
• Ø 80 to 250 mm • Qnom from 15 to 650 m3/h.
• Ø 80 to 250 mm • Qnom from 15 to 650 m3/h. • Ø 80 to 250 mm • Qnom from 20 to 650 m3/h.
Ø (mm) Airflow (m3/h) Code
125 110 11016071
150 11016072
200 11016073
240 11016074
290 11016075
150 210 11016076
260 11016077
310 11016078
380 11016079
Ø (mm) Airflow (m3/h) Code
160 210 11016081
260 11016082
310 11016083
380 11016084
200 350 11016086
440 11016087
530 11016088
620 11016089
700 11016090
Ø (mm) Airflow (m3/h) Code
250 550 11016091
600 11016092
800 11016093
950 11016094
1 000 11016095
Ø (mm) Airflow (m3/h) Code
80 15 11016226
20 11016227
25 11016228
30 11016229
35 11016230
40 11016231
45 11016232
50 11016233
60 11016234
100 15 11016235
20 11016236
25 11016237
30 11016238
35 11016239
40 11016240
45 11016241
50 11016242
55 11016243
60 11016244
65 11016245
70 11016246
75 11016247
80 11016248
85 11016249
90 11016250
Ø (mm) Airflow (m3/h) Code
125 15 11016251
25 11016252
30 11016253
45 11016254
50 11016255
60 11016256
65 11016257
70 11016258
75 11016259
80 11016260
85 11016261
90 11016262
95 11016263
100 11016264
105 11016265
110 11016266
115 11016267
120 11016268
125 11016269
130 11016270
140 11016271
150 11016272
160 11016273
190 11016274
150 110 11016275
130 11016276
150 11016277
170 11016278
210 11016279
240 11016280
Ø (mm) Airflow (m3/h) Code
160 120 11016281
130 11016282
140 11016283
150 11016284
160 11016285
170 11016286
180 11016287
190 11016288
200 11016289
210 11016290
240 11016291
200 200 11016292
225 11016293
250 11016294
275 11016295
300 11016296
325 11016297
350 11016298
400 11016299
250 300 11016300
350 11016301
400 11016302
450 11016303
500 11016304
550 11016305
650 11016306
MR Mono
HIGH PRESSURE RANGE CODES
• Ø 125 to 250 mm • Qnom from 110 to 1 000 m3/h.
STANDARD RANGE CODES STANDARD RANGE CODES
Ø (mm) Airflow (m3/h) Code
80 20-60 11016307
100 15-90 11016308
125 15-85 11016309
125 100-190 11016310
150 100-240 11016311
160 100-240 11016312
200 225-400 11016313
250 300-650 11016314
MR Modulo MR Modulo VMT
Ø (mm) Airflow (m3/h) Code
125 36-84 11016194
125 100-170 11016195
160 120-200 11016196
200 230-420 11016197
250 260-425 11016198

12
COMPLEMENTARY OFFERS
Constant Airflow Regulator MR
MR Mono - MR Modulo
MAF
MR performances are not altered by clogging, therefore it
requires practically no special maintenance.
• If used in an atmosphere where there is a lot of particles,
sleeves with inspection window are recommended to
allow regular inspection.
• When cleaning, plug the hole on the plastic body, at the
base of the bulb, in order to avoid any blocking of this
orifice and to prevent any liquid or foreign body from
passing inside the membrane.
Description Code
Manchon à fenêtre Ø 100 11013121
Manchon à fenêtre Ø 125 11013122
Manchon à fenêtre Ø 150 11013123
Manchon à fenêtre Ø 160 11013124
Manchon à fenêtre Ø 200 11013125
Manchon à fenêtre Ø 250 11013126
MR Max
• The MR Max is especially adapted for specific systems
requiring big diameter (up to 400 mm), high pressure
(up to 1 000 Pa) and high airflow (up to 4 000 m3/h).
• The MR Max is available from diameter 80 mm to 400 mm.
• The MR Max works with a free-moving control plate.
The airflow can be set from outsite.
Description Code
MR Max Ø 80 11016389
MR Max Ø 100 11016390
MR Max Ø 125 11016391
MR Max Ø 160 11016392
MR Max Ø 200 11016393
MR Max Ø 250 11016394
MR Max Ø 315 11016395
MR Max Ø 400 11016396
Duct Ø (mm) Airflow range (m3/h) L (mm) H (mm)
80 40 - 125 215 70
100 70 - 220 245 70
125 100 - 280 245 70
160 180 - 500 315 70
200 250 - 900 315 70
250 500 - 150 315 70
315 800 - 280 345 110
400 1 000 - 4 000 415 110
H
Ø
L

13
REGULATION AND AIR-BALANCING OFFER FOR HVAC DUCWORKS
Constant Airflow Regulator MR
MR Mono - MR Modulo
Passive range
Balancing dampers.
Automatic range
Constant airflow steadiness irrespective of pressure variations.
Active range
Variable flow rate control according to instructions.
RG
Commissioning damper
MR Mono
Constant Airf low Regulator
single-airflow
MDA Mod
Timed proportional regulation
damper
CRGN
Rectangular balancing dampers
MR Modulo
Constant Airflow Regulator
multiairflow
VAV
Variable Air Volume
Iris
Iris damper
MR Max
Constant Airflow Regulator high
pressure, high airflows
RMA
Motorized Constant Airflow
Regulator motorized

14
Constant Airflow Regulator MR
Notes

15
Constant Airflow Regulator MR
Notes

Constant Airflow Regulator MR
MR Mono - MR Modulo
Avantages
Regulating technology with a flexible bulb exclusive to Aldes, offering:
• a reliability of acoustic and aeraulic performances,
• a regulating reliability unaltered by clogging,
• an operating silence: no clatter or other parasitical sound due to pressure variations,
• horizontal or vertical mounting,
• a use for air supply or air exhaust with the same product.
MR Mono and MR Modulo ranges propose:
• a wide range of airflows and diameters available,
• an optimum stock management with the MR Modulo (8 references for 7 diameters)
• a high quality product (designed and produced in Europe)
• a userfriendly installation: no commissioning, tool-free airflow setting
(for MR Modulo), no wiring required (mechanically self-powered), can be fitted in both
ducting and accessories,
• Smart design:
- Double-lip ring seal for a better positioning and less leakage,
- Rotative ring for on-site airflow setting (Aldes Patent for the MR Modulo),
- Plastic fire-resistance recyclable without chlorine, stainless steel regultion spring.
Use of the constant airflow regulator MR guarantees:
• hygienic air quality (ventilation) or thermal comfort of occupants (air-conditioning),
• a simplification of the installation studies for air distribution ductworks,
• reduced operating costs,
• substantial time saved in installation linked to absence of commissioning (MR Mono
range),
• maximum flexibility on site with tool-free airflow setting (MR Modulo range)
w
ww.aldes.com
■ALDES AÉRAULIQUE - Headquaters: Tél : [phone]
■ALDES INTERNATIONAL - Tél : [phone]
MR_modulo_Tech_Corp_En_1 - 04/2019 - RCS Lyon 956 506 828 - Aldes - Aldes reserves the right to make changes to its products due to technical developments.
