7” DRIVING LIGHTS
& 22” LIGHT BAR SET
INSTRUCTION MANUAL
IMPORTANT:
V 1.2.1

2
Contents
Page
WARRANTY DETAILS ...............................................................................................................................................3
REPAIR AND REFURBISHED GOODS OR PARTS NOTICE .............................................................................4
WELCOME ..........................................................................................................................................................5
CONTENTS, SPECIFICATIONS, INTENDED USE ..............................................................................................6
WARNING SAFEGUARDS .......................................................................................................................................7
INSTALLING THE LED DRIVING LIGHTS & LIGHT BAR...............................................................................7-8
WIRING INSTALLATION......................................................................................................................................8-9
OVERVIEW OF LED DRIVING LIGHTS & LIGHT BAR..................................................................................... 10
TROUBLESHOOTING, CLEANING, MAINTENANCE & DISPOSAL ........................................................... 11

Warranty Details
