ALDI WORKZONE HCE2500 User manual

Dok./Rev.-Nr. 64124_20180907
3
Contents
User Manual
HIGH PRESSURE WASHER
YEARS
WARRANTY
5
Made in China
WORKZONE®is a registered trademark of ALDI Stores
DISTRIBUTED BY:
ALDI STORES
1 SARGENTS ROAD
MINCHINBURY NSW 2770
www.aldi.com.au
AUS
ALDI guarantees that our exclusive brand products are developed to our
stringent quality specifications. If you are not entirely satisfied with this
product, please return it to the nearest ALDI store within 60 days from the
date of purchase, for a full refund or replacement, or take advantage of our
after sales support by calling the supplier’s Customer Service Hotline.
Original instructions
MODEL:
HCE2500
suppor[email protected]
1300 855 831
AFTER SALES SUPPORT
AUS
64124
03/2019
1
1
2
3
4
5
6
7
8
9
1.1
1
23 6
10
11 12
13
14
15
16
17 18 19
Overview..............................................................................04
Utilisation.............................................................................05
Contents of Box....................................................................06
Explanation of symbols.......................................................07
Introduction.........................................................................08
Layout...................................................................................09
Scope of delivery ................................................................. 10
Intended use.........................................................................11
Safety regulations ................................................................11
Technical data.......................................................................17
Before starting the machine............................................... 18
Assembly.............................................................................. 18
Before operation ................................................................. 19
Operation..............................................................................21
Maintenance and cleaning.................................................. 22
Troubleshooting.................................................................. 23
Storage.................................................................................24
Disposal and recycling.........................................................24
Warranty details .................................................................. 25
Repair and refurbished goods or parts notice ..................26

4 5 6
Contents of Box
High pressure washer
Handle with holder for high pressure hose
High pressure hose
Holder for mains cable
Lance holder
Nozzle cleaning needle
Quick connector
Extension
Gun
Variable nozzle
Turbo nozzle
90° Turbo nozzle
Brush
Screw
Warranty Certicate
Manual
1 x
1 x
1 x
1 x
1 x
1 x
1 x
1 x
1 x
1 x
1 x
1 x
1 x
1 x
2 x
1 x
Foam sprayer
1 x
2
1
63
12
19 3
5
2
7
5
5
2
3
14
6
13
11
4
C
D
B
A
17
15
16
13
18
14
2
F
E
10

AFTER SALES SUPPORT 07
 1300 855 831  [e-mail]
MODEL:HCE2500 PRODUCT CODE: 64124 03/2019
AUS
HCE2500 Explanation of symbols
Explanation of Symbols
General note! Observe and understand all safety notes
and hints in this manual.
Read the operating instructions to reduce the risk of
injury.
Wear safety goggles.
Wear ear-muffs. The impact of noise can cause damage
to hearing.
This high pressure washer is not suitable for connecting
to the drinking water network.
Warning! High-pressure jets can be dangerous if not
used properly. Do not direct the jet at persons, animals,
live electrical equipment or the pressure washer itself.
Warning! Before installation, cleaning, alterations,
maintenance, storage and transport switch off the high
pressure washer and disconnect it from the power
supply.
Class II symbol: This high pressure washer is designed
with dual insulation and does not need to be connected
to an earthed power socket.
m Attention! Contents that provide information concerning your safety
m Caution! Failure to follow these instructions may cause risk of
injury!
m Warning! Failure to follow these instructions may cause danger to
life or danger of serious injuries!

08 AFTER SALES SUPPORT
 [e-mail]  1300 855 831
MODEL:HCE2500 PRODUCT CODE: 64124 03/2019
AUS
Introduction HCE2500
I. Introduction
Congratulations on choosing to buy a WORKZONE®product.
All products brought to you by WORKZONE®are manufactured to the highest
standards of performance and safety, and as part of our philosophy of customer
service and satisfaction, are backed by our comprehensive 5Year Warranty.
We hope you will enjoy using your purchase for many years to come.
Note:
According to the applicable product liability law the manufacturer of this high pres-
sure washer is not liable for damages which arise on or in connection with this high
pressure washer in case of:
• improper handling,
• non-compliance with the instructions for use,
• repairs by third party, non-authorised skilled workers,
• installation and replacement of non-original spare parts,
• improper use,
• failures of the electrical system due to the non-compliance with the electrical
specications and the Australian regulations.
Recommendations:
Read the entire text of the operating instructions prior to the assembly and operation
of the high pressure washer.
These operating instructions are intended to make it easier for you to get familiar
with your high pressure washer and utilise its intended possibilities of use.
The operating instructions contain important notes on how to work safely, properly
and economically with your high pressure washer and how to avoid dangers, save
repair costs, reduce downtime, and increase the reliability and working life of the
high pressure washer.
In addition to the safety regulations contained herein, you must in any case comply
with the applicable regulations of your country with respect to the operation of the
high pressure washer.
Put the operating instructions in a clear plastic folder to protect them from dirt and
humidity, and store them near the high pressure washer. The instructions must
be read and carefully observed by each operator prior to starting the work. Only
persons who have been trained in the use of the high pressure washer and have
been informed on the related dangers and risks are allowed to use the high pressure
washer. The required minimum age of 16 years must be met.

AFTER SALES SUPPORT 09
 1300 855 831  [e-mail]
MODEL:HCE2500 PRODUCT CODE: 64124 03/2019
AUS
Introduction/Layout HCE2500
In addition to the safety notes contained in the present operating instructions and
the special regulations of your country, the generally recognised technical rules for
the operation of this high pressure washer must be observed.
II. Layout (Fig. 1/1.1)
1 Handle with holder for high pressure hose
2 High pressure hose
3 Holder for mains cable
4 On / off switch
5 Connection for high pressure hose
6 Lance holder
7 Accessories holder
8 Transport wheel
9 Water inlet connection
10 750ml Foam sprayer
11 Nozzle cleaning needle
12 Quick connector
13 Extension
14 Gun
15 Variable nozzle
16 Turbo nozzle
17 90° Turbo nozzle
18 Brush
19 Screw

AUS
Scope of delivery HCE2500
10 AFTER SALES SUPPORT
 [e-mail]  1300 855 831
MODEL:HCE2500 PRODUCT CODE: 64124 03/2019
III. Scope of delivery
High pressure washer (1x)
Handle with holder for high pressure hose (1x)
High pressure hose (1x)
Holder for mains cable (1x)
Lance holder (1x)
Nozzle cleaning needle (1x)
Quick connector (1x)
Extension (1x)
Gun (1x)
Variable nozzle (1x)
Turbo nozzle (1x)
90° Turbo nozzle (1x)
Brush (1x)
Foam sprayer (1x)
Screw (2x)
Warranty Certicate (1x)
Manual (1x)
• Open the packaging and take out the high pressure washer carefully.
• Remove the packaging material as well as the packaging and transport bracing
(if available).
• Check that the delivery is complete.
• Check the high pressure washer and accessory parts for transport damage.
• If possible, store the packaging until the warranty period has expired.
m Attention!
The high pressure washer and packaging materials are not toys!
Children must not be allowed to play with plastic bags, lm and small parts!
There is a risk of swallowing and suffocation!

AUS
HCE2500 Intended use/Safety regulations
AFTER SALES SUPPORT 11
 1300 855 831  [e-mail]
MODEL:HCE2500 PRODUCT CODE: 64124 03/2019
IV. Intended use
The high pressure washer is designed to clean vehicles, machines, buildings, fa-
cades, etc. in private, domestic use.
The high pressure washer is to be used only for its prescribed purpose. Any other use
is deemed to be a case of misuse. The user / operator and not the manufacturer will
be liable for any damage or injuries of any kind caused as a result of this.
Please note that the high pressure washer has not been designed for use in commer-
cial, trade or industrial applications. Our warranty will be voided if the high pressure
washer is used in commercial, trade or industrial businesses or for equivalent pur-
poses.
This high pressure washer is not allowed to be used by persons (including children)
with reduced physical, sensory or mental capacities or those with a lack of experience
and knowledge.
V. Safety regulations
General power tool safety warnings and personal safety
m Caution! Read all safety regulations and instructions. Failure to follow the
warnings and instructions may result in electric shock, re and/or serious injury.
Save all warnings and instructions for future reference. The term “power tool” in
the warnings refers to your mains-operated (corded) power tool or battery-op-
erated (cordless) power tool.
1. Work area safety
• Keep work area clean and well lit. Cluttered or dark areas invite accidents.
• Do not operate power tools in explosive atmospheres, such as in the presence of
ammable liquids, gases or dust. Power tools create sparks which may ignite the
dust or fumes.
• Keep children and bystanders away while operating a power tool. Distractions can
cause you to lose control.
2. Electrical safety
• Power tool plugs must match the outlet. Never modify the plug in any way. Do not
use any adapter plugs with earthed (grounded) power tools. Unmodied plugs and
matching outlets will reduce risk of electric shock.
• Avoid body contact with earthed or grounded surfaces, such as pipes, radiators,
ranges and refrigerators. There is an increased risk of electric shock if your body

AUS
Safety regulations HCE2500
12 AFTER SALES SUPPORT
 [e-mail]  1300 855 831
MODEL:HCE2500 PRODUCT CODE: 64124 03/2019
is earthed or grounded. Do not expose power tools to rain or wet conditions. Water
entering a power tool will increase the risk of electric shock.
• Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the
power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged
or entangled cords increase the risk of electric shock.
• When operating a power tool outdoors, use an extension cord suitable for outdoor
use. Use of a cord suitable for outdoor use reduces the risk of electric shock.
• If operating a power tool in a damp location is unavoidable, use a residual current
device (RCD) protected supply. Use of an RCD reduces the risk of electric shock.
• If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualied persons in order to avoid a hazard.
3. Personal safety
• Stay alert, watch what you are doing and use common sense when operating
a power tool. Do not use a power tool while you are tired or under the inuence
of drugs, alcohol or medication. A moment of inattention while operating power
tools may result in serious personal injury.
• Use personal protective equipment. Always wear eye protection. Protective equip-
ment such as dust mask, non-skid safety shoes, hard hat, or hearing protection
used for appropriate conditions will reduce personal injuries.
• Prevent unintentional starting. Ensure the switch is in the off-position before
connecting to power source and/or battery pack, picking up or carrying the tool.
Carrying power tools with your nger on the switch or energising power tools that
have the switch on invites accidents.
• Remove any adjusting key or wrench before turning the power tool on. A wrench
or a key left attached to a rotating part of the power tool may result in personal
injury.
• Do not overreach. Keep proper footing and balance at all times. This enables
better control of the power tool in unexpected situations.
• Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing
and gloves away from moving parts. Loose clothes, jewellery or long hair can be
caught in moving parts.
• If devices are provided for the connection of dust extraction and collection facil-
ities, ensure these are connected and properly used. Use of dust collection can

AUS
HCE2500 Safety regulations
AFTER SALES SUPPORT 13
 1300 855 831  [e-mail]
MODEL:HCE2500 PRODUCT CODE: 64124 03/2019
reduce dustrelated hazards.
4. Power tool use and care
• Do not force the power tool. Use the correct power tool for your application. The
correct power tool will do the job better and safer at the rate for which it was
designed.
• Do not use the power tool if the switch does not turn it on and off. Any power tool
that cannot be controlled with the switch is dangerous and must be repaired.
• Disconnect the plug from the power source and/or the battery pack from the pow-
er tool before making any adjustments, changing accessories, or storing power
tools. Such preventive safety measures reduce the risk of starting the power tool
accidentally.
• Store idle power tools out of the reach of children and do not allow persons unfa-
miliar with the power tool or these instructions to operate the power tool. Power
tools are dangerous in the hands of untrained users.
• Maintain power tools. Check for misalignment or binding of moving parts, break-
age of parts and any other condition that may affect the power tool’s operation. If
damaged, have the power tool repaired before use. Many accidents are caused by
poorly maintained power tools.
• Use the power tool, accessories and tool bits etc. in accordance with these
instructions, taking into account the working conditions and the work to be per-
formed. Use of the power tool for operations different from those intended could
result in a hazardous situation.
Caution!
Residual risks
Even if you use this electric power tool in accordance with instructions,
certain residual risks cannot be rules out. The following hazards may arise in
connection with the equipment’s construction and layout:
1. Lung damage if no suitable protective dust mask is used.
2. Damage to hearing if no suitable ear protection is used.
3. Health damage caused by hand-arm vibrations if the equipment is used over a
prolonged period or is not properly guided and maintained.

14 AFTER SALES SUPPORT
 [e-mail]  1300 855 831
MODEL:HCE2500 PRODUCT CODE: 64124 03/2019
AUS
Safety regulations HCE2500
5. Service
• Have your power tool serviced by a qualied repair person using only identical
replacement parts. This will ensure that the safety of the power tool is maintained.
• If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualied persons in order to avoid a hazard.
Electrical safety:
mCaution: to avoid accidents and injuries from electric shocks:
• The plug and socket of an extension cable must be water-tight!
m Unsuitable extension cables can be dangerous as people can be harmed
by an electric shock!
• Protect the electric plug connections against moisture.
• If there is a risk of ooding, x the plug connections in an area that is safe from
ooding.
• Ensure that the mains voltage matches the specications on the rating plate.
• Connection to the mains must be carried out by an experienced electrician and
meet the requirements of the Australian standards.
• The electrical installation shall be according to national wiring rules.
• The device must only be connected to a mains socket via a residual-current circuit
breaker (RCD) with a rated leakage current of not more than 30 mA. Fuse: at least
13 ampere.
• Before each use, check the high pressure washer, cable and plug for damage.
• If the power cable for this high pressure washer is damaged, it must be replaced
by the manufacturer, a customer service agent of the same or a similarly qualied
person in order to prevent hazards.
• Do not pull the plug from the socket by the cable. Protect the cable from heat, oil
and sharp edges.

AUS
HCE2500 Safety regulations
AFTER SALES SUPPORT 15
 1300 855 831  [e-mail]
MODEL:HCE2500 PRODUCT CODE: 64124 03/2019
• Do not carry or x the high pressure washer by the cable.
• Use only extension cables that are protected from spray water and designed for
outdoor use. Always fully unroll a cable drum before use. Check the cable for
damage.
• Before any work on the high pressure washer, during work breaks and in the case
of non-use, remove the plug from the socket.
• Wear sturdy footwear to protect against electric shock.
• To protect against electric shock, operate the high pressure washer only in an
upright position.
High pressure washer safety warnings
Risk of unsafe operation
• Unsafe operation of your high pressure washer could lead to serious injury or
death to you or others.
• The spray gun/wand is a powerful cleaning tool that could look like a toy to a
child.
• Reactive force of spray results in gun/lance movement, potentially causing the
operator to slip, fall or misdirect the spray. Improper control of gun/wand can
result in injuries to self, others and property damage.
• Become familiar with the operation and controls of the high pressure washer.
• Keep children away from the high pressure washer at all times.
• Never modify or remove the safety features of this high pressure washer.
• Do not operate the high pressure washer with missing, broken or unauthorized
parts.
• Never leave wand unattended while unit is running.
• Keep work area free of obstacles.
• Stand on stable surface and grip gun/lance rmly. Expect the gun to kick back
when engaged
• Do not use ammable or explosive liquids such as gasoline, fuel oil, kerosene,-
solvents or thinners. Pump should only be used with liquids compatible with
water blaster component materials. Failure to follow to this warning can result in
serious personal injury, death and/or property damage.

16 AFTER SALES SUPPORT
 [e-mail]  1300 855 831
MODEL:HCE2500 PRODUCT CODE: 64124 03/2019
AUS
Safety regulations HCE2500
• Water high pressure washer must be located on a solid level surface. IF could tip
or fall causing serious injury.
m Warning! Do not use the appliance within range of persons unless they wear
protective clothing.
m Warning! High pressure jets can be dangerous if subject to misuse. The jet
must not be directed at persons, live electrical equipment or the appliance itself.
m Warning! Do not direct the jet against yourself or others in order to clean
clothes or foot-wear.
m Warning! To ensure appliance safety, use only original spare parts from the
manufacturer or approved by the manufacturer.
m Warning! High pressure hoses, ttings and couplings are important for the
safety of the appliance. Use only hoses, ttings and couplings recommended by
the manufacturer.
m Warning! Do not use the appliance if a supply cord or important parts of the
appliance are damaged, e.g. safety devices, high pressure hoses, trigger gun.
This high pressure washer is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge.
m Warning! Water that has owed through backow preventer is considered to be
non-potable.
• Children being supervised not to play with the appliance.
• High pressure washers shall not be used by children. Children should be super-
vised to ensure that they do not play with the high pressure washer.
m Warning! Do not use appliance without reading the instruction sheet.
m Warning! This high pressure washer has been designed for use with the clean-
ing agent supplied or recommended by the manufacturer. The use of other cleaning
agents or chemicals may adversely affect the safety of the high pressure washer.
m Warning! High pressure washers shall not be used by children or untrained
personnel.
m Warning! During use of high pressure cleaners, aerosols may be formed. Inhala-
tion of aerosols can be hazardous to health
m Warning! Inadequate extension cords can be dangerous. If an extension cord is
used, it shall be suitable for outdoor use, and the connection has to be kept dry and
off the ground. It is recommended, that this is accomplished by means of a cord reel

AFTER SALES SUPPORT 17
 1300 855 831  [e-mail]
MODEL:HCE2500 PRODUCT CODE: 64124 03/2019
AUS
HCE2500 Safety regulations/Technical data
which keeps the socket at least 60 mm above the ground.
m Warning! Ensure that any exhaust emissions are not in the vicinity of air intakes.
m Warning! Always switch off the mains disconnecting switch when leaving the
high pressure washer unattended.
VI. Technical data
Mains connection 230 - 240 V~ / 50 Hz
Power consumption 2400 W
Mains cable length approx. 5 m
Safety class II
Degree of protection IPX5
Rated/operating pressure 12 MPa
Max. permissible pressure 18 MPa / 2600 PSI
Max. inow pressure 0.4 MPa
Inow temperature 5 - 50 °C
Working ow rate, water 5.5 l/min
Max. working ow rate, water 6.8 l/min
Weight approx. 9 kg
Foam producer capacity 0.75 l
Noise and Vibration
Sound pressure level (LpA)78 dB(A)
Uncertainty KpA 3 dB(A)
Sound power level (LWA): 94 dB(A)
Vibration (ah). < 2.5 m/s2
Wear ear-muffs.
The impact of noise can cause damage to hearing.
Sound and vibration values were measured with a standardized test method.

18 AFTER SALES SUPPORT
 [e-mail]  1300 855 831
MODEL:HCE2500 PRODUCT CODE: 64124 03/2019
AUS
Technical data/Assembly HCE2500
The specied vibration value was established in accordance with a standardized
testing method. It may change according to how the electric high pressure washer is
used and may exceed the specied value in exceptional circumstances.
The specied vibration value can be used to compare the high pressure washer with
other electric power tools.
The specied vibration value can be used for initial assessment of a harmful effect.
Keep the noise emissions and vibrations to a minimum:
• Only use appliances which are in perfect working order.
• Service and clean the appliance regularly.
• Adapt your working style to suit the appliance.
• Do not overload the appliance.
• Have the appliance serviced whenever necessary.
• Switch the appliance off when it is not in use.
• Wear protective gloves.
VII. Assembly
m Warning! Ensure the high pressure washer is correctly and completely
assembled before use.
Mounting of the quick connector (Fig.2)
1 Remove the black cap from the back side of the high pressure washer.
2 Mount the quick connector (12) to the water inlet connection (9) at the back side
of the high pressure washer.
Mounting of the handle with holder for high pressure hose (Fig.2)
1 Push the handle with holder for high pressure hose (1) onto the fastening points
at the top of the high pressure washer.
2 Secure the handle with holder for high pressure hose (1) with the screws (19).
Use for this a screwdriver (not included).
Mounting of the holder for mains cable and lance holder (Fig.2)
1 Attach the holder for mains cable (3) and the lance holder (6) onto the both

AFTER SALES SUPPORT 19
 1300 855 831  [e-mail]
MODEL:HCE2500 PRODUCT CODE: 64124 03/2019
AUS
HCE2500 Assembly/Before operation
fastening points at the side of the high pressure washer.
Mounting of the high pressure hose (Fig.3)
1 Remove the black cap from connection for high pressure hose (5).
2 Connect the high pressure hose (2) with the connection for high pressure hose
(5).
Mounting of the high pressure hose and the gun (Fig.4)
1 Plug the high pressure hose (2) into the gun (14).
2 For removal of the high pressure hose (2), push the lever (B) and pull out the
high pressure hose (2).
Mounting of the extension and the accessories (Fig.4)
1 Plug the extension (13) into the gun (14) and twist it.
2 If you require the brush (18), plug it into the gun (14) instead of the extension (13)
and twist it.
3 Plug the required accessory (10; 15; 16; 17) into the extension (13).
4 For removal, press the button (A) and remove the accessory.
VIII. Before operation
It is recommend for the power supply to this high pressure washer either to be
connected via a residual current device circuit-breaker, which interrupts the power
ow as soon as the leakage current to earth exceeds 30 mA for 30 ms, or for it to be
equipped with an earth tester.
Before you connect the high pressure washer to the mains supply make sure that
the data on the rating plate are identical to the mains data. Warning! Always pull
the power plug before making adjustments to the high pressure washer

1AFTER SALES SUPPORT
 [e-mail]  1300 855 831
MODEL:HCE2500 PRODUCT CODE: 64124 03/2019
Using the high pressure washer correctly
• The high pressure washer must be stood on a level, stable surface.
• It is recommended that you adopt the correct operating position every time you
use the high pressure washer with one hand on the gun and the other on the
lance.
• Never direct the water jet at electrical lines or the high pressure washer itself.
• Never use the high pressure washer in potentially explosive areas under any
circumstances!
• The operating temperature must be between +5 and + 50 °C.
• Do not cover or modify the lance or the spray nozzles in any way.
• The high pressure washer is designed to be used with cold or lukewarm water
(max. 50 °C); higher temperatures can damage the high pressure washer.
• Do not use water that is dirty, gritty or contains any chemical products, as these
could impair operation and shorten the life of the high pressure washer.
m Warning! Risk of explosion Do not spray ammable liquids.
mWarning! Water that has passed through the non-return valve is not drinkable.
m Warning! If cleaning agent gets into contact with your skin or into your eye,
rinse immediately with lots of clean water. Then consult a doctor or follow the steps
described on the safety data sheet or provided by the manufacturer of the cleaning
agent.
Water inlet connector (Fig. 1/2)
The quick connector (12) has a standard hose coupling system. Plug the hose cou-
pling of the supply hose (min. Ø 1/2“/13 mm) to the quick connector (12).
Always use a reinforced hose with a standard coupling for the water inlet. The hose
should be at least 6 m in length (not supplied).
A backow preventer must be installed between the drinking water and the high
pressure washer! Ask your local plumber about this.
AUS
Before operation HCE2500
20

AFTER SALES SUPPORT 21
 1300 855 831  [e-mail]
MODEL:HCE2500 PRODUCT CODE: 64124 03/2019
AUS
HCE2500 Before Operation/Operation
Electrical connections
• Before you connect the high pressure washer to the power supply make sure that
the data on the rating plate are identical to the supply voltage.
• If you use any extension cables, make sure that they are suitable for outdoor use
and have large enough wires:
1 – 10 m: 1.5 mm²
10-30 m: 2.5 mm²
• Insert the power plug on the power cable into the socket outlet.
IX. Operation
m Warning! Be prepared for the recoil force of the emitted water jet! Ensure
that you are standing rmly and that you are holding the gun (14) securely,
otherwise you could injure yourself or other people.
Never operate the high pressure washer with a closed water tap. Dry running
will damage the high pressure washer!
Using the gun (Fig.1/4)
1 Turn on the water tap entirely.
2 Switch on the high pressure washer with the On / off switch (4). Only ever switch
on the high pressure washer once you have connected all of the water pipes
and they do not leak. The motor switches on until the required pressure has
built up. After the pressure has built up, the motor switches off.
3 Press the security switch (C) to unlock the gun starting lever (D). The nozzle
operates by pressure and the motor switches back on.
4 Releasing the gun starting lever (D) causes the high pressure washer to switch
off. The system remains pressurised.
5 After using the high pressure washer press the security switch (C) to lock the
gun starting lever.
Usage of the accessories (Fig.4)
Foam sprayer (10): Fill the foam sprayer (10) with detergent. The width of the beam
can be adjusted by turning the nozzle (F). By turning the knob (E), the foam volume
can be adjusted.
Variable nozzle (15): This accessory is intended for ordinary cleaning works. The
water jet can be adjusted by turning the variable nozzle (15).

1AFTER SALES SUPPORT
 [e-mail]  1300 855 831
MODEL:HCE2500 PRODUCT CODE: 64124 03/2019
AUS
Operation/Maintenance and cleaning HCE2500
22
Turbo nozzle (16): This accessory is intended for stubborn dirt.
90° Turbo nozzle (17): The 90° Turbo nozzle (17) can be used for cleaning gutters
and car underbodies.
Brush (18): The brush (18) can be used for cleaning cars and large areas. This acce-
sory operates in a low pressure mode.
After use
1. Disconnect the high pressure washer from water supply.
2. Empty the high pressure washer by using the gun for a few seconds.
3. Switch off the high pressure washer.
4. Disconnect the high pressure washer from power supply.
5. Let the high pressure washer cool down.
6. Check after each use if the high pressure washer is damaged.
X. Maintenance and cleaning
Pull out the power plug before every maintenance operation. This also includes
connecting to the water supply or trying to eliminate leaks. There is a risk of electro-
cution or of injury from moving parts.
Cleaning
It is recommended to clean the high pressure washer after each use.
Never direct the water jet against the high pressure washer, nor clean the
high pressure washer under owing water. This could give rise to the danger
of electric shock and damage the high pressure washer!
Always keep the high pressure washer clean. Do not use any detergents or solvents.
• Always keep the ventilation slots clean and free from dirt and dust.
• Only clean the high pressure washer with a soft brush or a slightly moist cloth.
• If nozzles are soiled or blocked, you can remove any foreign bodies in the nozzle
using the nozzle cleaning needle (11).
Maintenance
The high pressure washer is maintenance free.

AFTER SALES SUPPORT 23
 1300 855 831  [e-mail]
MODEL:HCE2500 PRODUCT CODE: 64124 03/2019
AUS
HCE2500 Troubleshooting
XI. Troubleshooting
Problem Possible Cause Action
The high pres-
sure washer
does not work.
No electrical voltage to the high
pressure washer.
Check the fuse, power cable
and power plug and have
them replaced by qualied
personnel if necessary.
The cross section of the extension
cable is not large enough and/or
the extension cable is too long.
Use extension cables with
larger cross sections and/or
use shorter extension cables.
The mains voltage is lower than
that specied.
Contact the power supply
company if necessary.
The high pressure washer is
frozen. Check and thaw if necessary.
The motor
starts but
there is no
pressure
build-up.
Air intake in the water inlet.
Check the supply hose and
hose connectors and replace
if necessary.
Water cock closed. Turn open the water cock.
The operating
pressure is
irregular.
Air intake in the water inlet.
Check the supply hose and
hose connectors and replace
if necessary.

1AFTER SALES SUPPORT
 [e-mail]  1300 855 831
MODEL:HCE2500 PRODUCT CODE: 64124 03/2019
AUS
Storage/Disposal and recycling HCE2500
24
XII. Storage
Storage (Fig.5)
• Clean up the high pressure washer before storing.
• Drain all the water from the high pressure washer.
• Disconnect the unit from the water supply.
• Store the gun (14) and extension (13) in the lance holder (6).
• Hook the mains cable onto the holder for mains cable (3).
• The high pressure hose (2) can be stored at the backside of the handle with holder
for high pressure hose (1).
• The nozzle cleaning needle (11) and other accessories can be stored in the acces-
sory holder (7).
• Protect the high pressure washer and its accessories from frost when they have
not been completely drained of all water.
• Protect the high pressure washer from dust.
• Ensure that children cannot reach the high pressure washer.
• Store the pressure washer and its accessories in a frost-free room.
XIII. Disposal and recycling
The equipment is supplied in packaging to prevent it from being damaged in transit.
The raw materials in this packaging can be reused or recycled. The equipment and its
accessories are made of various types of material, such as metal and plastic. Never
place defective equipment in your household refuse. The equipment should be taken
to a suitable collection center for proper disposal.
If you do not know the whereabouts of such a collection point, you should ask in your
local council ofces.
