ALDI WZTS 2000 User manual

TABLE SAW
WZTS 2000
ID: #05007
m
y
h
a
n
s
e
c
o
n
t
r
o
l
.
c
o
m
M
A
N
U
A
L
D
E
V
E
L
O
P
E
D
I
N
G
E
R
M
A
N
Y
User-friendly
Manual
User Manual
Spend a little Live a lot
Original instructions

QR codes take you where you want to go
quickly and easily
Whether you require product information, spare parts or accessories, de-
tails on warranties or aftersales services, or if you want to watch a product
demonstration video, our QR codes will take you there in no time at all.
What is a QR code?
A QR code (QR = Quick Response) is a type of matrix that can be read with a
smartphone camera and that contains a link to a website or contact details,
for example.
Advantage:You do not need to manually enter a website address or contact
details.
This is how it works
To scan the QR code, all you need is a smartphone with QR code reader soft-
ware and an internet connection.* This type of software can be downloaded
for free from your app store.
Try it out now
Just scan the QR code with your smartphone and find out
more about the Aldi product you have purchased.*
Your Aldi Service Portal
All details mentioned above can also be found in the
Aldi Service Portal at www.aldi.co.uk.
*Depending on your tariff plan you may be charged for the connection.

Dok./Rev.-Nr. 94004_20160623
Overview .............................................................................4
Scope of delivery/device parts...........................................6
General information............................................................ 7
Reading and storing the user manual ..................................7
Explanation of symbols ...........................................................7
Safety ...................................................................................8
Proper use................................................................................. 8
Residual risks............................................................................ 9
Safety instructions................................................................... 9
Supplementary safety instructions..................................... 12
Checking the saw and pack contents................................17
Assembly ........................................................................... 18
Mounting the table extensions ............................................18
Mounting the support legs ................................................... 19
Mounting/adjusting the splitting wedge .......................... 20
Mounting the saw blade guard............................................22
Mounting the parallel guide .................................................22
Mounting the waste bag .......................................................23
Connecting the extraction device........................................23
Operation........................................................................... 23
Setting the cutting depth......................................................23
Setting the cutting angle ......................................................23
Parallel guide ..........................................................................24
Cross guide ..............................................................................25
Laser..........................................................................................25
Switching the table saw on and off .....................................26
Sawing......................................................................................27
Removing jammed material ................................................ 29
Changing the saw blade....................................................... 29
Cleaning............................................................................. 31
Maintenance and care....................................................... 32
Storage ..............................................................................33
Transport ........................................................................... 33
Troubleshooting................................................................34
Technical data ...................................................................35
Noise information .............................................................36
Ordering spare parts.........................................................36
Disposal.............................................................................. 37
Disposing of the packaging ..................................................37
Disposing of the table saw ....................................................37
Declaration of conformity.................................................38
Warranty Card....................................................................39
Warranty conditions..........................................................40
Contents

A
1
11
6
5
2
10
9
8
7
1319 18 17 16 15 1420
24
22
23
B26
29
31 30
37
36
33
27
35
4
34
32
3
12
28
21
25
4
GB IRE

D
BC 29
40
42
41
43
46
50
49
48
51
53
54
52
2855
29
44
39
45
47
25
38
5
GB IRE

Pack contents⁄device parts
1Saw table 29 Splitting wedge
2Table insert (with fixing screws, 2×) 30 Waste bag
3Guide groove (saw table) 31 Eccentric lever (parallel guide)
4Right table width extension 32 Viewing window (parallel guide)
5Left table width extension 33 Parallel guide
(with carriage screw and knurled nut, 2×)
6Table length extension 34 Guide rail (cross guide)
7Long table support, 2× 35 Knurled knob (cross guide)
8Short table support, 4× 36 Cross guide
(with carriage bolt and knurled nut, 2×)
9Centre brace, 4× 37 Stop rail (cross guide)
10 Stop rail (parallel guide) 38 Push stick holder
11 Push stick 39 Clamping plate (for securing the splitting wedge)
12 Tip guard, 2× 40 Clamp bolt (for securing the splitting wedge)
13 Support leg, 4× 41 Pressure disc (saw blade)
14 Rubber foot, 4× 42 Outer saw blade flange
15 Carriage bolt, 8× 43 Hexagon bolt (saw blade)
16 M6×12 mm hexagon bolt, 10× 44 Saw blade
17 M6×16 mm hexagon bolt, 14× 45 Rail with scale (saw table)
18 Spring washer, 24× 46 Locking knob
19 Flat washer, 34× 47 Angle scale (cutting angle)
20 Hexagon nut, 18× 48 Crank wheel
21 Large washer, 8× 49 Crank
22 Ring spanner 50 Power switch (green: I/red: 0)
23 Saw blade key 51 Battery compartment cover (laser)
24 AF10 spanner 52 Laser switch (laser on: /laser off: 0)
25 Adapter (extractor connection for the
saw table) 53 Batteries (laser), 2× 1.5 V AAA/LR03
26 Saw blade guard 54 Battery compartment (laser)
27 Lens head screw (saw blade guard) 55 Long hole (splitting wedge)
28 Laser
GB IRE
The product contents include two
type AAA/LR3 1.5 V batteries.
6

General information
7
www.einhell.co.uk
AFTER SALES SUPPORT
GB
IRE
0044 151 649 1500
0044 1890 946 244
GB IRE
General information
Reading and storing the user manual
This user manual accompanies this table saw. It contains important
information on safety, usage and care.
Read this user manual carefully before using the table saw. Pay
particular attention to the safety instructions and warnings. Failure to
follow the instructions in this user manual may result in serious injury or damage to
the table saw.
Comply with applicable local or national regulations concerning the use of this
product. Keep this user manual in a safe place for future reference. If you pass the
table saw on to third parties, please be absolutely sure to include this user manual.
Explanation of symbols
The following symbols and signal words are used in this user manual, on the table
saw or on the packaging.
WARNING! Designates a hazard that may lead to death or severe
injury if not avoided.
CAUTION! Designates a hazard that may lead to minor or moder-
ate injury if not avoided.
NOTICE! Warns against potential damages to property.
This symbol provides you with useful supplementary information on as-
sembly or operation.
Declaration of conformity (see chapter “Declaration of conformity”):
Products marked with this symbol meet all applicable Community regu-
lations for the European Economic Area.
Read the user manual.
Wear protective goggles.

Safety
8
www.einhell.co.uk
AFTER SALES SUPPORT
8
GB IRE
GB
IRE
0044 151 649 1500
0044 1890 946 244
Wear a dust mask.
Wear ear protection.
Attention! Risk of injury due to sharp edges.
This table saw is equipped with a class 2 laser.
Do not look into the laser beam.
This symbol identifies the table saw as a device belonging to protection
class II.
Safety
Proper use
The table saw is exclusively designed for private use and for hobby and DIY projects
for the following purposes:
• for cutting wood of all kinds lengthwise in accordance with the size of the
machine,
• for cutting wood of all kinds (only with the cross guide) crosswise in
accordance with the size of the machine.
Round lumber, regardless of the kind, must not be cut.
Only saw blades suitable for the machine (HM or CV saw blades) may be used. The use
of HSS saw blades and cutting discs of any kind is prohibited.
Any other applications are expressly prohibited and are deemed improper use.
Neither the manufacturer nor the retailer can accept any responsibility for injury,
loss or damage caused by misuse of this product of any kind. Examples of misuse are
given in the following non-exhaustive list:
• Using the table saw for other than the intended purposes;
• Failure to observe the safety instructions and warnings as well as the assembly,
operating, maintenance and cleaning instructions contained in this user manual;
• Failure to comply with any regulations relating to accident prevention,
occupational medicine or safety, which specifically and/or generally apply to
the use of this table saw;
• Use of accessories or spare parts that are not suitable for the table saw;

Safety
9
www.einhell.co.uk
AFTER SALES SUPPORT
GB
IRE
0044 151 649 1500
0044 1890 946 244
GB IRE
• Modifications to the table saw;
• Repair of the table saw by parties other than the manufacturer or a qualified
professional;
• Use of the table saw for commercial or industrial applications;
• Operation or maintenance of the table saw by persons not familiar with how to
handle the table saw and/or who are not aware of the related risks.
Residual risks
Despite proper use, inconspicuous residual risks cannot be completely ruled out.
The following risks may arise due to the nature of the table saw:
• Touching the exposed areas of the saw blade.
• Reaching into the rotating saw blade (cut injury).
• Kickback of the work piece and parts of the work piece if used improperly.
• Saw blade breaks.
• Projection of defective hard metal parts of the saw blade.
• Hearing loss in the event of failure to use the required ear protection.
• Damage to the eyes if the required safety goggles are not used.
• Injury to health if the required dust mask is not used.
• Emission of wood dust that is harmful to health if used in enclosed spaces.
Safety instructions
ATTENTION! When using power tools, the following basic safety measures must be
taken in order to provide protection against electric shocks, risk of injury and fire.
Read all these notes before using this power tool and keep the safety instructions in a
safe place.
Working safely
1. Keep work area clean and well lit.
• Disorganisation in your work area poses a risk of accident.
2. Take any environmental factors into account.
• Do not expose the power tools to rain.
• Do not operate the power tools in wet or damp rooms.
• Ensure that the work area is well lit.
• Do not use the power tools if there is a risk of fire or explosion.

Safety
10
www.einhell.co.uk
AFTER SALES SUPPORT
10
GB IRE
GB
IRE
0044 151 649 1500
0044 1890 946 244
3. Protect yourself against electrical shock.
• Avoid contact between your body and earthed parts (e.g. pipes,
radiators, electric stoves, cooling units).
4. Keep other persons away.
• Do not allow other persons, particularly children, to touch the power tool
or cable. Keep them away from your work area.
5. Store unused power tools in a safe area.
• Unused power tools should be stored in a dry, elevated or closed off area
that is out of the reach of children.
6. Do not overload the power tool.
• It works better and more safely within the specified power range.
7. Use the right power tool.
• Do not use any low-power machines to perform heavy-duty work.
• Do not use the power tool for purposes other than the intended one. Do
not use e.g. a handheld circular saw to cut tree branches or wood blocks.
8. Dress properly.
• Do not wear any loose-fitting clothing or jewellery as it could be caught
by moving parts.
• It is recommended that you wear firm footwear when working outdoors.
• If you have long hair, wear a hair net.
9. Use protective equipment.
• Wear protective goggles.
• Use a breathing mask when performing dusty work.
10. Connect the dust extraction device.
• If there are any ports for dust extractors and collectors, make sure that
they are connected and used properly.
11. Do not use the cable for purposes other than the intended one.
• Do not use the cord to pull the plug out of the socket. Protect the cord
against heat, oil and sharp edges.
12. Secure the work piece.
• Use clamping fixtures or a vice to hold the work piece. This will ensure
that it is more securely held than it would be with your hand.
