Service Guide
Model Series 595
Cordless Grease Gun
595-A
595-B
595-C
595-D
Español .................................Página 9
Français ................................. Page 17
Deutsch ................................. Seite 25
Italiano................................Pagina33
Description
These model guns are designed to dispense petroleum-
based greases (up to NLGI 2) for general lubrication
applications. A 36-inch (0.91 meter) long high-pressure
whip hose, heavy-duty grease coupler, 1-hour fast charger
and molded carrying case are included. The guns are
equipped with low battery and stall indicator lights and an
LED flashlight.
The guns use an 18 Volt motor with three stages of gear
reduction. A crank and yoke mechanism drives a
reciprocating piston pump. The motor is powered by a
rechargeable 18 Volt / 3000 mAh Lithium-ion battery pack.
Each model gun is designed for 3-way loading;
cartridge, suction, and loader pump (requires optional
loader fitting 322610). The guns are spring-primed and
include an air bleed valve to aid priming.
Optional Accessories
Specifications
Sound pressure (LpA) 72.3 dB(A), uncertainty (K) 3 dB(A)
Acoustic power (LWA) 83.3 dB(A), uncertainty (K) 3 dB(A)
Vibration emission value (ah) 0.6 m/s2, uncertainty (K) 1.5 m/s2
¹ NLGI 2 EP lithium grease at 75˚F (24˚C) dispensed through included hose assembly with grease coupler and against 150 psi (10 bar) added pressure
(simulates grease fitting with ball check).
Alemite,
LLC
167 Roweland Drive, Johnson City, Tennessee 37601
www.alemite.com
Copyright © 2011 by Alemite, LLC
This document contains confidential information that is the pr operty of Alemite, LLC
SER 595-A
671018 and is not to be copied, used, or disclosed to others without express written permission. Revision (05-12)
Model
Battery
Quantity Battery Charger
595-A 1
595-B 2
595-C 1
595-D 2
120 Vac / 60 Hz
(North / South America)
230 Vac / 50 Hz
(Europe / Middle East)
Includes BatteryCharger
and CarryingCase
Figure 1 Cordless Grease Gun Series 595
Cartridge
Size
psi bar Oz./Min. Gms/Min. Cartridges Ounces Gms Ounces psi bar Inches Meters Lbs Kg
8,000 552 6170 27¹16 454 14 10,000 690 36 0.91 7.2 3.3
Maximum
Pressure
Delivery Capacity
when Fully Charged
Flow Rate
Grease Cylinder Capacity
Weight
(Empty)
Bulk
Length
Hose Assembly
Pressure Rating
Shoulder Strap
Mobile Battery Charger
(12 Vdc to 18 Vdc)
Loader Fitting
339812 343154 322610

SER 595-A Cordless Grease Gun
Revision (05-12) Alemite, LLC
Figure 2 Cordless Grease Gun Models 595-A,-B,-C,-D - Exploded View
2
Figure 2 Cordless Grease Gun Series 595 - Exploded View

Cordless Grease Gun SER 595-A
393795-6 Ball Check
393757 Bleed Valve
393795-20
Electronic Circuitry*
393795-12 Head*
1
Insert, Coupler (
Insert, Coupler (Rubber) 1
2Housing Cover Housing, Right 1
3Washer, Lock Washer, Lock 10
4
Screw, Machine
Screw, Machine 8
5Screw, Tapping Screw, Tapping 4
6Trigger Trigger 2
7Screw, M3 x 6 Screw, M3 x 6 6
8
Washer, M3, Lo
Washer, M3, Lock 4
9Cover, Head Cover, Head 1
10 Ring, Retaining Ring, Retaining 2
•
11
Washer, 0.24 ID
Washer, 0.24" ID x 0.67" OD 1
12
Q31631-35.SLD
Yoke 1
13
Q31631-36.SLD
Bearing, Roller 1
14
Washer, 0.24 ID
Washer, 0.24" ID x 0.59" OD 1
15
Gear Assembly,
Gear Assembly, Output 1
16 coupler holster Holster 1
17
Head & Bearing
Head & Bearing Assembly 1
•
18 Trigger Spring Trigger Spring 1
19 Gear, Internal Gear, Internal 1
20
Q31631-25.SLD
Gear, Output Pinion 1
21
Q31631-23.SLD
Gear, Planet (Second Stage) 3
22
Q31631-21.SLD
Gear, Sun (Second Stage) 1
23
Q31631-19.SLD
Gear, Planet (First Stage) 3
24
Q31631-15.SLD
Washer 1
25 Washer, kcoL Washer, Lock 2
26 21.SLDPRT Mount, Motor 1
27
Screw, M3 x 16
Screw, M3 x 16 5
28 393795-19* Motor Assembly (with Sun Gear) 1
29 Magnet, Ring 1
30 339820 Cylinder Assembly, Grease 1
31
Switch, Three W
Switch 1
•
32 336523 Gasket 1
33
Q31631-53.SLD
O-Ring 1
•
34
Spring, Bleed V
Spring, Bleed Valve 1
•
35 Valve, Bleed Valve, Bleed 1
•
36 Plug Plug 1
37 Piston Piston 1
•
38 Pin, Roll Pin, Roll 2
•
39 340067 Hose Assembly, Grease 1Never Substitute
40 308730 Coupler, Grease 1
41 343170 Flashlight with Clip 1
42 Lens Support Lens, LED 1
43 PCB board Circuit Board, LED 1
•
44
Ball, Check, 3-8
Ball, Check, 3/8" Diameter 1
•
45 Spring, Check Spring, Check 1
•
46
Gasket (Copper)
Gasket (Copper) 1
• •
47 Plug, Check Plug, Check 1
•
48 TP Protector, Thermal 1
•
49 PCB Circuit Board and Battery Connector 1
•
1Models 595-A, -C
2Models 595-B, -D
51 Housing ASSY Housing, Left 1
343152 Charger, Battery (120 Vac / 60 Hz) 1Models 595-A, -B
343153 Charger, Battery (230 Vac / 50 Hz) 1Models 595-C, -D
53 Case, Carrying 1
A340338 Relief Valve with Gasket
B6304-B Coupler, Grease
Legend:
Alemite, LLC Revision (05-12)
Notes
52
Item No. Part No. Description Qty
Repair Kits
50 343151 Battery Pack, 18V
Optional
*Replacement of these items by other than an authorized Alemite Service Center voids the warranty.
Part numbers left blank are not available separately.
3

SER 595-A
Cordless Grease Gun
Revision (05-12)
A lemite, LLC
4
General Safety Rules
WARNING
Read all safety warnings and all instructions. Failure to follow the warnings and instructions may
result in electric shock, fire and/or serious injury. Save all warnings and instructions for future
reference. The term “power tool” in the warnings refers to your mains-operated (corded) power tool or
battery operated (cordless) power tool.
Work Area Safety
• Keep work area clean and well lit. Cluttered and dark areas invite accidents.
• Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids,
gases or dust. Power tools create sparks which may ignite the dust or fumes.
• Keep children and bystanders away while operating a power tool. Distractions can cause you to lose
control.
Electrical Safety
• Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of
electric shock.
• Avoid body contact with earthed or grounded surfaces such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
•Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk
of electric shock.
• Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep
cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk
of electric shock.
• When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord
suitable for outdoor use reduces the risk of electric shock.
• If operating a power tool in a damp location is unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of electric shock.
Personal Safety
• Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use
a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of
inattention while operating power tools may result in serious personal injury.
• Use personal protective equipment. Always wear eye protection. Safety equipment such as dust mask,
non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce
personal injuries.
• Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power
source and/or battery pack, picking up or carrying the tool. Carrying power tools with your finger on
the switch or energising power tools that have the switch on invites accidents.
• Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached
to a rotating part of the power tool may result in personal injury.
•Do not overreach. Keep proper footing and balance at all times. This enables better control of the
power tool in unexpected situations.
•Dress properly. Do not wear loose clothing or jewelry. Keep your hair, clothing and gloves away from
moving parts. Loose clothes, jewelry or long hair can be caught in moving parts.
• If devices are provided for the connection of dust extraction and collection facilities, ensure these are
connected and properly used. Use of these devices can reduce dust related hazards.

Cordless Grease Gun
SER 595-A
Alemite, LLC
5
Revision (05-12)
General Safety Rules (Continued)
WARNING
Power Tool Use and Care
• Do not force the power tool. Use the correct power tool for your application. The correct power tool
will do the job better and safer at the rate for which it was designed.
• Do not use the power tool if the switch does not turn it on and off. Any power tool that can not be
controlled with the switch is dangerous and must be repaired.
• Disconnect the plug from the power source before making any adjustments, changing accessories, or
storing power tools. Such preventive safety measures reduce the risk of starting the power tool
accidentally.
• Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power
tool or these instructions to operate the power tool. Power tools are dangerous in the hands of
untrained users.
• Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and any
other condition that may affect the power tools operation. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly maintained power tools.
• Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
•Use the power tool, accessories and tool bits etc., in accordance with these instructions and in the
manner intended for the particular type of power tool, taking into account the working conditions and
the work to be performed. Use of the power tool for operations different from intended could result in a
hazardous situation.
Battery Tool Use and Care
• Recharge only with the charger specified by the manufacturer. A charger that is suitable for one type
of battery pack may create a risk of fire when used with another battery pack.
• Use power tools only with specifically designated battery packs. Use of any other battery packs may
create a risk of injury and fire.
•When battery pack is not in use, keep it away from other metal objects like paper clips, coins,
keys, nails, screws, or other small metal objects that can make a connection from one terminal to
another. Shorting the battery terminals together may cause burns or a fire.
• Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact
accidentally occurs, flush with water. If liquid contacts eyes, additionally seek medical help. Liquid
ejected from the battery may cause irritation or burns.
Service
• Have your power tool serviced by a qualified repair person using only identical replacement parts. This
will ensure that the safety of the power tool is maintained.

SER 595-A
Cordless Grease Gun
Revision (05-12)
A lemite, LLC
6
Specific Safety Rules
WARNING
The gun can develop high pressure up to
8,000 psi (552 bar). Rupture of components can
inject grease into skin and eyes, causing serious
injury and possible amputation. If injured, seek
immediate medical attention.
Do not operate without proper safety protection,
gloves, and goggles. Hold hose at spring guard
only. Do not use if hose is damaged or worn.
Inspect hose before each use. Use only Alemite
340067 Grease Whip Hose.
This gun uses lubricants, that may be flammable
and poisonous if ingested. Do not use gun near
open flame or other fire hazards. Read all
warnings on lubricants before using this gun.
Use ear protection to reduce the risk of induced
hearing loss.
Disconnect battery pack from gun before changing
accessories, storing gun or unscrewing grease
cylinder from the gun.
Ensure the switch is in the off position before
inserting battery pack. Inserting the battery
pack into power tools that have the switch on
invites accidents.
Never attempt to open the battery pack for
any reason.
Do not expose the battery pack to water.
Do not store the battery pack in locations where
the temperature may exceed 104°F (40°C).
Charge the batterypack only at ambient temperatures
between 40°F (4°C) and 104°F (40°C).
Warning! To reduce the risk of
inj ury, the
user must read the instruction manual.
Separate collection. This product must not be
disposed of with normal household waste.
Loading and Priming the Gun
NOTE: Refer to Figure 2 for component
identification on the following procedures.
Cartridge Loading
1. Unscrew Grease Cylinder (30) from the gun.
2. Pull the follower rod and engage the groove in the
follower rod with the slot in the Grease Cylinder cap.
3. Remove the plastic cap from the cartridge.
4. Apply a film of grease to the exposed inside surface of
the cartridge.
NOTE: This is only necessary for a virgin
gun.
5. Insert the cartridge into the Grease Cylinder.
•Remove the tabbed seal from the cartridge.
6. Screw the Grease Cylinder onto the gun.
7. Disengage the follower rod from the slot in the Grease
Cylinder cap.
•Push the follower rod into the Grease Cylinder.
Suction Loading
1. Unscrew Grease Cylinder (30) from gun.
2. Insert the head of the Grease Cylinder below the
surface of the grease.
3. Slowly pull the follower rod outward from the Grease
Cylinder cap until the groove is visible.
4. Engage the groove in the follower rod with the slot in
the Grease Cylinder’s cap.
5. Screw the Grease Cylinder onto the gun.
6. Disengage the follower rod from the slot in the Grease
Cylinder cap.
•Push the follower rod into the Grease Cylinder.
Loader Pump
WARNING
The gun can be equipped with an optional
low-pressure Loader Fitting. Do not substitute with
a high-pressure grease fitting. Personal injury can
occur due to excessive pressure.
The use of a grease fitting will void the
warranty.
CAUTION
The Loader Fitting on the gun must mate with the
loader coupler. The pump may not operate if the
components are not compatible.
1. Pull the follower rod and engage the follower by
rotating the rod.
2. Seat the Loader Fitting into the loader coupler.
•Push down to hold the coupler valve open.
3. Operate the pump and view the movement of the
follower rod.

Cordless Grease Gun
SER 595-A
Alemite, LLC
Revision (05-12)
7
4. Discontinue pump operation once the groove on the
follower rod is visible.
5. Disengage follower rod from follower and push
into the Grease Cylinder.
Priming the Gun
In most cases the gun will prime simply by
operating the Trigger several times.
Should grease fail to appear, air must be bled.
Force Prime
This process manually assists air within the gun to
be bled at the Bleed Valve.
1. Pull the follower rod and engage the follower by
rotating the rod.
2. Depress Bleed Valve (35) and at the same time
push on the follower rod.
Once the air is eliminated, operate the gun several
times.
Once grease appears, disengage the follower rod
from the follower and push into the Grease Cylinder.
Gun Operation
Battery Pack (50) is intentionally shipped with a
low charge.
Charge Battery Pack prior to use.
•Refer to the following section for details.
The battery needs to be charged before first use
and whenever it fails to produce sufficient power
on jobs that were easily done before. The battery
may become warm while charging; this is normal
and does not indicate a problem.
Low Battery Indicator
The low battery indicator illuminates when there
is sufficient battery charge to dispense approximately
three cartridges of grease.
Stall Indicator
The stall indicator illuminates when a stall
condition causes the thermal protector to open.
Release the trigger to turn off the stall indicator.
The thermal protector resets automatically.
CAUTION
Air pockets in the grease can cause the gun to lose
prime. Check for prime after each refill and before
lubrication.
The gun is equipped with a thermal protectorto
prevent the motor from overheating. When a blocked
bearing, line, or grease fitting causes the gun to stall,
the thermal protector will open.
For maximum motor life, avoid operating at stall
Check Valve Contamination
Should the gun fail, the outlet check may be held
open. Remove Plug (47), clean Ball (44), and the Ball
seat of Head (17).
Battery Pack and Charger Safety Rules
This manual contains important safety and operating
instructions for Battery Pack part number 343151 and Battery
Chargers 343152 and 343153.
WARNING
Before using the Battery Charger read all
instructions and cautionary markings on Battery
Charger (52), Battery Pack (50), and products using
the Battery Pack.
To reduce the risk of injury, charge only Lithium-ion
type rechargeable batteries. Other types of batteries
may burst causing injury.
An extension cord should not be used unless abso-
lutely necessary. Use of an improper extension cord
could result in a risk of fire and electric shock. If an
extension cord must be used, make sure it is 18-
gauge. Check to ensure that the pins on the plug of
the extension cord are the same number, size, and
shape as those of the plug on the Charger. Make sure
that the extension cord is properly wired and in good
electrical condition.
Do not incinerate the Battery Pack, even if it is
severelydamaged or completelyworn out. The Battery
Pack may explode in fire

SER 595-A
Cordless Grease Gun
Revision (05-12)
8
Alemite, LLC
CAUTION
Do not expose the Charger to rain, snow, or frost. To
reduce the risk of damage to electric plug and
cord, pull by the plug rather than the cord when
disconnecting the Charger.
Make sure the cord is located so that it will not be
stepped on, tripped over, or otherwise subjected to
damage or stress.
Do not operate the Charger with damagedcord or plug.
Replace immediately.
Do not operate the Charger if it has received a sharp
blow, been dropped, or otherwise damaged in any way.
Do not disassemble the Charger.
Do not charge the Battery when the temperature is
below 40° F (4°C) or above 104° F (40°C).
The Charger is designed to operate on standard
household electrical power. Do not attempt to use it on
any other voltage.
Consecutive charging may cause overheating. If you
need to recharge the Battery consecutively, wait for
about 15 minutes to allow the Charger to cool.
Do not insert foreign material into the hole for the
Battery in the Charger stand.
Do not disassemble the Battery.
Do not Store the gun and Battery assembly in
locations where the temperature may reach or exceed
104°F (40°C).
Do not short-circuit the Battery.
Do not place the Charger in an area of extreme heat
or cold. It works best at normal room temperature.
Battery Charger Operation
Charge the Battery only with the Charger provided.
Make sure power circuit voltage is same as that shown
on the charger specifications plate. Press down to
ensure the battery properly engages with the charger’s
contacts.
Function of Red and Green Lights
Red Light Flash
When the charger is powered on, the Red light
will flash once.
Green Light Flashing
Charging
Green Light On
Battery fully charged
Red Light Flashing at 4HZ
Battery will not charge
Red Light Flashing at 1HZ/5HZ
Battery too hot. Charging will restore when the
battery pack cools down to 104° F (40° C).
Battery overheating could be attributed to:
A. Long continuous running
B. Hot ambient temperature
C. One or more cells are damaged
One hour of charge time is required to fully
charge the battery.
The Battery will become slightly warm to the
touch while charging. This is normal and does not
indicate a problem.
EC DECLARATION OF CONFORMITY
Declares that under the sole responsibility for supply of the machinery described as:
TYPE/SERIES: Cordless Grease Gun
MODEL: 595-A, 595-B, 595-C, 595-D
These products are in compliance with the following European Community Directives: 2006/42/EC
The following standards were used to verify compliance with the directives:
EN60745, EN60335-1, EN60335-2
Approved by: ________________________________________ Date: ______________________________
Director of Engineering: Robert Hoefler
ALEMITE, LLC
167 Roweland Drive
Johnson City, Tennessee, USA 37601
December 14, 2011
