Assembly Instruction Item#:310-1716

2
BEFORE YOU BEGIN
Before beginning assembly, make sure all parts are present. Compare parts received with the “Parts List.” If
any part is missing or damaged, do NOT attempt to assemble the product. Please read and understand this
entire manual before attempting to assemble, operate or install this product.
GENERAL INFORMATION
Your new patio furniture is made from the finest materials available. It should provide many years of
enjoyment with minimal care.
Keep your patio furniture clean and apply a coat of wax a few times a year. For best results, clean the patio
furniture with warm soapy water and use an outdoor furniture wax. If you use furniture covers, always make
sure the furniture is clean and completely dry before covering as mold may form in dark, wet places. Check
the bolts on your patio furniture regularly to make sure they are tight.
To provide a rust free product, this patio furniture is made of Cast Aluminum which is a relatively soft
material. Be careful not to over-tighten your hardware. Stripped hardware is not covered under the
manufacturer’s warranty. The weight limit for each seat is 225 lbs.
SAFETY INFORMATION
WARNING
DO NOT stand or allow children to stand on the assembled product. DO NOT tighten bolts completely until
instructed to do so. After final alignment, make sure all nuts and bolts are securely fastened. NEVER use a
power tool to assemble or tighten your furniture. Perform periodic checks to make sure the hardware is
secure and tighten if needed.
CAUTION
READ all instruction before beginning assembly. Failure to do so may result in faulty assembly and potential
injury. Assemble the items on a soft, non-abrasive surface such as a carpet or cardboard to avoid damaging
the item.
inForMaTion

3
D
A
C
E
PARTS LIST
F
B
ARotary Table 1
B
Long Support Panel
1
C1
D2
Table Top
K
Washer/Spring Washer
/nut/Plastic cap ( 8mm)
Qty: 13
(12 for assem + 1 extra)
I
8x30mm Stud
Qty: 5
(4 for assem + 1 extra)
M
Wrench
Qty: 1
N
Screwdriver
/Cross Screwdriver
Qty: 2
O
Extra-Adjustable
Foot
Qty: 1
ParT DEScriPTion QuanTiTY
harDWarE conTEnTS
E2
Short Support Panel
Rotary Ring
G
6x40mm Bolt/
Plastic Nut (6mm)
Qty: 4
(3 for assem + 1 extra)
H
6x15mm Bolt
Qty: 4
(3 for assem + 1 extra)
J
8x35mm Stud
Qty: 9
(8 for assem + 1 extra)
L
Washer/SpringWasher/
nut/Plastic cap ( 6mm)
Qty: 4
(3 for assem + 1 extra)
F4
Table Leg

ASSEMBLY
5
Place the Table Top(C) with the underside facing skywards.
Fit the Stud(I) by turning into the 4 points on the underside of Table Top(C)
with the Screwdriver(N).
Step 1
Step 2
Fix the Stud(J) to the Table Leg(F) by using Screwdriver (N).
Next, attach Table Leg(F) to studs on Table Top(C) using Washer, Spring
Washer and Nut(K) with Wrench(M) .
DO NOT tighten, yet.
Step 3
I
N
C
N
J
M
K
K
K
F

6
ASSEMBLY
Step 4
NOTE: To HOLD the legs together in positon, the LEGS SUPPORT
PANELS WILL OVERLAP AT ALL 04 (four) CORNERs.
First, attach the Leg Support(D/E) with Groove End to the Studs(J) and then
attach Support Panel(D/E) without Groove End to Studs(J), together.
Then affix the Leg Support(D/E) to the table legs with the Washers, Spring
Washers and Nuts(K) using the Wrench(M).
DO NOT tighten, yet . Repeat the same process for all 04 (four) contact
points of the Table Legs and the Legs Support Panels.Once all the panels are
in place,proceed to TIGHTEN the screw-bolts of the legs, in a rotational
sequential manner.By this action, it allows the table legs to be locked into
position, evenly, thus reducing wobbles.Thereafter, lock all the Leg Support
Panels tightly into position.
D
M
K
E

ASSEMBLY
Step 5
Put Bolts(G) into the hole on the inner ring of Rotaty Ring(B),then screw
nuts(G) on the opposite side and tighten it with Cross Srewdriver(N) and
Wrench(M).Note the screw should enter from the large circle of the
tapered hole on Rotaty Ring to the small circle
Step 6
Turn the Rotaty Ring(B) so that the screw on Rotaty Ring is upward, and then
align holes in the outer ring of Rotaty Ring(B) with the hole on the Rotary Table(A).
Insert Bolts(H) into the holes and tighten them with Cross Srewdriver(N) .
G
G
H
H
H
G
G
G
G
B
A
N
N
6

ASSEMBLY
Step 7
Put Rotary Table (A) on Table Top (C) align bolts on Rotary Table with holes
on table top,insert Bolts into the holes.Then affix the Rotary Table to the
Table Top with the Washers,Spring Washers and Nuts (L) using the Wrench
(M).Add Plastic Caps on all bolt ends.Adjust the leg pre-installed Levellers until
the Table is level with the ground.
M
L
