ALIBI ALI-NVR5000P Series User manual

ALI-NVR5000P Series
Embedded Network Video Recorder
User Manual
Products: ALI-NVR5016P, ALI-NVR5032P
ALI-NVR5000P Series Network Video Recorder
PLEASE READ THIS MANUAL BEFORE USING YOUR SYSTEM, and always follow the instructions for safety
and proper use. Save this manual for future reference.
ALI-NVR5016P_SM
7/17/14

ii
CAUTION
Do not expose this appliance to rain or moisture. Operate this device only in environments where the temperature or
humidity is within the recommended range. Operation at extreme temperatures or in very high or low humidity levels
may cause electric shock and shorten the life of the product.
CAUTION
FCC Caution: To assure continued compliance, use only shielded interface cables when connecting to computer or
peripheral devices. Any changes or modications not expressly approved by the party responsible for compliance could
void the user’s authority to operate this equipment.
NOTE
This equipment has been tested and found to comply with the limits for a Class “A” digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio
communications.
LEGAL NOTICE
Observint Technologies (Observint) products are designed to meet safety and performance standards with the use of
specic Observint authorized accessories. Observint disclaims liability associated with the use of non-Observint
authorized accessories.
The recording, transmission, or broadcast of any person’s voice without their consent or a court order is strictly
prohibited by law.
Observint makes no representations concerning the legality of certain product applications such as the making,
transmission, or recording of video and/or audio signals of others without their knowledge and/or consent. We
encourage you to check and comply with all applicable local, state, and federal laws and regulations before
engaging in any form of surveillance or any transmission of radio frequencies.
Alibi and the Alibi logo are trademarks of Observint.
Microsoft, Windows, and Internet Explorer are either registered trademarks or trademarks of Microsoft Corporation in
the United States and/or other countries. Android is a trademark of Google Inc. Use of this trademark is subject to
Google Permissions. Apple, iPhone,iPod touch, and iPad are registered trademarks of Apple Inc.
Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks
and names or their products. Observint disclaims any proprietary interest in trademarks and trade names other than
its own.
No part of this document may be reproduced or distributed in any form or by any means without the express written
permission of Observint, Inc.
© 2014 by Observint Technologies. All Rights Reserved.
11000 N. Mopac Expressway, Building 300, Austin, TX 78759
For Sales and Support, contact your distributor.

iii
ALI-NVR5000P Embedded NVR User Manual
SAFETY INSTRUCTIONS
Regulatory information
FCC information
FCC compliance: This equipment has been tested and found to comply with the limits for a digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated
in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used
in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment
in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his
own expense.
FCC conditions
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause undesired operation.
Preventive and Cautionary Tips
Before connecting and operating your device, please be advised of the following tips:
• Ensure unit is installed in a well-ventilated, dust-free environment.
• Unit is designed for indoor use only.
• Keep all liquids away from the device.
• Ensure environmental conditions meet factory specications.
• Ensure unit is properly secured to a rack or shelf. Major shocks or jolts to the unit as a result of dropping it may cause damage
to the sensitive electronics within the unit.
• Use the device in conjunction with an UPS if possible.
• Power down the unit before connecting and disconnecting accessories and peripherals.
• A factory recommended HDD should be used for this device.
• Improper use or replacement of the battery may result in hazard of explosion. Replace with the same or equivalent type only.
Dispose of used batteries according to the instructions provided by the battery manufacturer.
Safety Instructions
Read these instructions and keep them in a safe place for future reference.
• Please refer all work related to the installation of this product to qualied service personnel or system installers.
• Do not operate the appliance beyond its specied temperature, humidity or power source ratings.
• Place the unit on a at surface not prone to vibration or impact.
• Use the appliance at temperatures between 14 °F ~ 131 °F (-10 °C ~ +55 °C) and relative humidity below 90%. The input
power source for this appliance is between 90 ~ 264 Vac, 47 ~ 63 Hz.

iv
• Install the unit away from heat sources such as radiators, heat registers and stoves.
• Installation of the unit near consumer electronics devices, such as stereo receiver/ampliers and televisions, is permitted as
long as the air surrounding the terminal does not exceed the above mentioned temperature range.
• Handle hard disk drives with care.
—It is possible to damage hard drives if they are moved while the NVR is powered on. To allow the hard drive to spin down
and park its heads, wait at least 10 seconds after disconnecting power before moving the unit.
—To avoid shock and vibration damage to the internal hard drive, do not move the unit while it is plugged in.
—Protect hard disk drives from static electricity.
—Do not stack hard disk drives or keep them upright.
—Do not use an electric or magnetic screwdriver to install hard disk drives.
• Do not place the unit in an enclosed area where the cooling vents are blocked or impede the ow of air through the ventilation
openings.
• Protect the power cord from being stepped on or pinched particularly at plugs and the points where they exit from the
apparatus.
• Do not drop metallic parts through slots. This could permanently damage the appliance. Turn the power o immediately and
contact qualied service personnel for service.
• Handle the appliance with care. Do not drop or shake, as this may damage the device.
• Do not expose the appliance to water or moisture, nor try to operate it in wet areas. Do not install the unit in an area where
condensation occurs. Do not operate with wet hands. Take immediate action if the appliance becomes wet. Turn the power o
and refer servicing to qualied service personnel. Moisture may damage the appliance and also cause electric shock.
• Do not use strong or abrasive detergents when cleaning the surfaces of this product. When dirt is hard to remove, use a mild
detergent and wipe gently.
• Do not overload outlets and extension cords. Electric shock or re may result.
• Save your system conguration.
• Distributing, copying, disassembling, reverse compiling, reverse engineering, and exporting, in violation of export laws, the
software provided with this product is expressly prohibited.

v
ALI-NVR5000P Embedded NVR User Manual
TABLE OF CONTENTS
Table of Contents
SECTION 1 Systems Overview...................................................................1
1.1 NVR Controls, connectors and indicators .................................................3
1.1.1 Remote control..................................................................7
1.1.2 Mouse control...................................................................8
1.1.3 Soft keyboard ...................................................................9
SECTION 2 Installing the System ...............................................................10
2.1 Getting Started: Unpacking the Equipment .............................................10
2.2 NVR installation general guidelines....................................................11
2.2.1 Installing an HDD in the NVR .....................................................11
2.2.2 NVR Placement ................................................................11
2.3 Connecting alarm devices to the NVR ..................................................12
2.3.1 Wiring alarm inputs to the NVR...................................................12
2.3.2 Wiring alarm outputs to the NVR..................................................12
2.4 Install a monitor, mouse, power.......................................................13
2.5 Connecting it together – initial system setup ...........................................14
2.5.1 Using theWizard for basic conguration setup ......................................14
2.6 Access the Menu system .............................................................21
2.7 Customize camera congurations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
2.7.1 Camera OSD setup ..............................................................23
2.7.2 Camera Image setup ............................................................23
2.7.3 Camera PTZ setup ..............................................................24
2.7.4 Camera Motion detection setup...................................................24
2.7.5 Camera Privacy Mask setup ......................................................27
2.7.6 Camera Video Tampering setup ...................................................28
2.7.7 CameraVideo Loss setup.........................................................30
2.7.8 Camera VCA setup ..............................................................32
2.8 Adding cameras manually ...........................................................32
2.8.1 Conguring customized protocols.................................................35
2.9 Conguring HDD settings ............................................................37
2.9.1 Checking HDD status.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
2.9.2 Managing Network Storage ......................................................38
2.9.3 Conguring the HDD ............................................................40
2.9.4 HDD Detect ....................................................................42

vi
TABLE OF CONTENTS
2.10 Conguring Exception Alarms.........................................................44
2.11 Setting sensor alarms................................................................45
2.12 Setting alarm response actions........................................................49
SECTION 3 Startup, Shutdown, Reboot. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
3.1 Starting Up, Shutting Down and Rebooting the NVR......................................54
3.1.1 Startup .......................................................................54
3.1.2 Shutdown .....................................................................54
3.1.3 Rebooting the NVR .............................................................55
SECTION 4 LiveView Interface .................................................................56
4.1 Operations in Live view mode.........................................................56
4.1.1 Front panel operation on Live view................................................57
4.1.2 Using the mouse in Live view.....................................................58
4.1.3 Using an Auxiliary monitor.......................................................58
4.1.4 LiveView Status icons ...........................................................59
4.2 Quick Setting Toolbar ................................................................59
4.3 LiveView pop-up menu..............................................................61
4.3.1 Live View settings ..............................................................61
4.4 Channel-Zero Encoding ..............................................................63
SECTION 5 PTZ Controls.......................................................................64
5.1 Conguring PTZ settings .............................................................64
5.2 Setting PTZ presets, patrols and patterns ...............................................65
5.2.1 Customizing Presets. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65
5.2.2 Calling Presets .................................................................66
5.2.3 Customizing Patrols.............................................................67
5.2.4 Calling Patrols..................................................................68
5.2.5 Customizing Patterns. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .69
5.2.6 Calling Patterns ................................................................70
5.3 PTZ Control Panel ...................................................................70
SECTION 6 Record, Playback andVideo Backup...................................................72
6.1 Conguring record settings...........................................................73
6.1.1 Setting camera parameters ......................................................73
6.1.2 Conguring Record schedule .....................................................74
6.1.3 Conguring Capture schedule ....................................................78
6.1.4 Conguring Motion Detection Recording...........................................79
6.1.5 Manual record .................................................................82

vii
ALI-NVR5000P Embedded NVR User Manual
TABLE OF CONTENTS
6.1.6 Conguring HDD Group for Recording..............................................83
6.1.7 Files Protection.................................................................84
6.2 Playback...........................................................................85
6.2.1 Instant playback by channel .....................................................85
6.2.2 Playing back video by channel....................................................86
6.2.3 Playing Back byTime............................................................89
6.2.4 Playback by Event Search ........................................................90
6.2.5 Playback by Tag ................................................................93
6.2.6 Smart Playback ................................................................96
6.2.7 Playback using System logs ......................................................97
6.2.8 Playing Back an external le .....................................................99
6.2.9 Auxiliary Functions - Playback frame by frame.....................................101
6.2.10 Auxiliary Functions - Reverse Playback of Multi-channel.............................101
6.2.11 Digital Zoom..................................................................102
6.3 Backing up Record Files - Export......................................................103
6.3.1 Quick Export ..................................................................103
6.3.2 Export by video search .........................................................105
6.3.3 Export by Event Search .........................................................108
6.3.4 Exporting Video Clips during playback ............................................110
SECTION 7 Managing User Accounts ...........................................................115
7.1 Adding a user account ..............................................................115
7.2 Deleting a user account .............................................................119
7.3 Editing a user account ..............................................................119
7.3.1 Edit admin user ...............................................................120
SECTION 8 Network Settings .................................................................122
8.1 Conguring General Settings ........................................................122
8.2 Conguring Advanced Settings.......................................................123
8.2.1 Conguring DDNS .............................................................123
8.2.2 Conguring NTP Server.........................................................125
8.2.3 Conguring Remote Alarm Host .................................................126
8.2.4 Conguring Multicast ..........................................................126
8.2.5 Conguring RTSP ..............................................................127
8.2.6 Conguring Server and HTTP Ports ...............................................128
8.2.7 Conguring Email .............................................................128
8.2.8 Conguring UPnP™ ............................................................131

viii
TABLE OF CONTENTS
SECTION 9 System Maintenance ..............................................................132
9.1 System Information ................................................................132
9.2 Log Information, Log Export .........................................................132
9.2.1 Log Search. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .133
9.3 Import / Export system conguration .................................................136
9.4 Upgrade Firmware .................................................................139
9.5 Default ...........................................................................141
9.6 Net Detect ........................................................................141
9.6.1 Checking Network Trac .......................................................141
9.6.2 Testing Network Delay and Packet Loss ...........................................142
9.6.3 Exporting Network Packet ......................................................143
9.6.4 Checking the network status ....................................................144
9.6.5 Checking Network Statistics .....................................................145
9.6.6 HDD Detect ...................................................................146
9.7 Hot Spare device backup ............................................................148
9.7.1 Identifying the Hot Spare device .................................................149
9.7.2 Setting the Working device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .149
9.7.3 Managing Hot Spare System ....................................................150
9.8 Conguring Disk Clone..............................................................152
SECTION 10 Remote Access....................................................................154
10.1 Remote login......................................................................154
10.2 Remote Live View screen ............................................................157
10.3 Remote Playback screen ............................................................159
10.4 Remote Log screen .................................................................161
10.5 Remote Conguration screen ........................................................162
SECTION 11 Cleaning.........................................................................164
SECTION 12 Specications ....................................................................165
APPENDIX A Glossary .........................................................................167
APPENDIX B FAQ .............................................................................168
APPENDIX C HDD Installation ..................................................................169
C.1 NVR compatible HDDs ..............................................................169
C.2 HDD Installation ...................................................................169
APPENDIX D NVR Compatible Cameras ..........................................................174

1
ALI-NVR5000P Embedded NVR User Manual
SECTION 1: SYSTEM OVERVIEW
SECTION1
Systems Overview
Congratulations on purchasing your new Embedded NVR security system! Your system includes the following key features:
General
• Each channel supports dual-stream video.
• Up to 16 network cameras (ALI-NVR5016P) or 32 network cameras (ALI-NVR5032P)
• NVR supports cameras from several manufacturers. Refer to “APPENDIX D NVR Compatible Cameras” on page 168.
• Independent conguration for each channel including resolution, frame rate, bit rate, image quality, etc.
• The quality of the input and output record is congurable.
Local Monitoring
• Simultaneous HDMI, VGA and CVBS monitor output with resolutions up to 1920 x 1080.
• Multiple screen display in Live view is supported; the display sequence of channels is congurable.
• Congurable Live View display of groups and tours.
• Live view Quick setting menu.
• Motion detection, video tampering, video exception alert and video loss alert functions.
• Privacy mask.
• Zooming in by clicking the mouse and PTZ tracing by dragging mouse.
HDD Management
• Supports up to 4 internal SATA hard disk drives, with a maximum of 4TB storage capacity in each drive.
• 8 network disks (8 NAS disks, or 7 NAS disks+1 IP SAN disk) can be connected.
• Supports HDD S.M.A.R.T. and bad sector detection.
• Supports eSATA disk for recording or backup
• Supports HDD group management.
• Supports HDD standby function.
• Supports HDD property: redundancy, read-only, read/write (R/W)
• Supports HDD quota management; a dierent capacity can be assigned to each camera channel.
• Support disk clone to an eSATA disk.
Recording and Playback
• Holiday recording schedule conguration.
• Normal and event video encoding parameters.
• Multiple recording types: manual, normal or motion
• Eight recording time periods with separated recording types.
• Supports pre-record and post-record for motion detection recording, and pre-record time for schedule and manual recording.

2
• Tag marker insertions, search and playback by tags.
• Lock/unlocking video les.
• Searching and playing back record les by channel number, recording type, start time, end time, etc.
• Motion analysis for the selected area in the video.
• Zoom in/out during playback.
• Forward/reverse, fast/slow playback.
• Forward/reverse multi-channel playback.
• Supports pause, skip forward and skip backward during playback.
• Up to 16-channel synchronous playback at 720p resolution
• Manual capture, continuous capture of video images and playback of captured pictures.
Backup
• Export video data to USB, SATA or eSATA device.
• Export video clips during playback.
• Management and maintenance of backup devices.
• Either Normal or Hot Spare working mode is congurable to constitute an N+1 hot spare system.
Alarm and Exception
• Congurable arming time of alarm input/output.
• Alarm for video loss, motion detection, tampering, abnormal signal, video input/output standard mismatch, illegal login,
network disconnected, IP coniction, abnormal record/capture, HDD error, and HDD full, etc.
• Alarm triggers full screen monitoring, audio alarm, notifying surveillance center, sending email and alarm output.
• Automatic restore when system is abnormal.
Other Local Functions
• Operable by front panel, mouse, remote control, and control keyboard.
• Three-level user management; admin user is allowed to create many operating accounts and dene their operating
permission, which includes the limit to access any channel.
• Operation, alarm, exceptions and log recording and searching.
• Manually triggering and clearing alarms.
• Import and export of device conguration information.
Network Functions
• Self-adaptive 10M/100M/1000M network interface with multi-address, load balance, network fault tolerance, etc.
• 16 independent PoE network interfaces
• IPv6 supported
• Supports TCP/IP, PPPoE, DHCP, DNS, DDNS, NTP, SADP, SMTP, SNMP, NFS and iSCSI I protocols.
• Supports TCP, UDP and RTP for unicast.
SECTION 1: SYSTEM OVERVIEW

3
ALI-NVR5000P Embedded NVR User Manual
SECTION 1: SYSTEM OVERVIEW
• Auto/manual port mapping by UPnP™.
• Remote web browser access by HTTPS ensures high security.
• Remote reverse playback via RTSP.
• Support accessing by platform via ONVIF.
• Remote search, playback, download, locking and unlocking of the record les, and support downloading les broken transfer
resume.
• Remote parameters setup; remote import/export of device parameters.
• Remote viewing of the device status, system logs and alarm status.
• Remote keyboard operation.
• Remote locking and unlocking of control panel and mouse.
• Remote HDD formatting and program upgrading.
• Remote system restart and shutdown.
• RS-232, RS-485 transparent channel transmission.
• Alarm and exception information can be sent to the remote host
• Remotely start/stop recording.
• Remotely start/stop alarm output.
• Remote PTZ control.
• Remote JPEG capture.
• Virtual host function is provided to get access and manage the IP camera directly.
• Two-way audio and voice broadcasting.
• Embedded WEB server.
1.1 NVR Controls, connectors and indicators
Your new security system is easy to use and easy to setup. This section includes the function and use of the components included
with a NVR system. For installation instructions, refer to Section 2. Advanced control and conguration procedures are included in
Sections 3 through 9.
NVR Front Panel (ALI-NVR5016P and ALI-NVR5032P)
Control Buttons Composite keysStatus indicatorsPower and USB ports (2) Jog Shuttle control
Front panel

4
Name Function / Description
Status Indicators POWER Turns green when NVR is powered up.
READY The indicator is green when the device is running normally.
Status Indicators
(cont.)
STATUS
The light is green when the IR remote control is enabled;
The light is red when the function of the composite keys (SHIFT) are used;
The light is out when none of the above condition is met.
ALARM The light is red when there is an alarm occurring.
HDD Blinks red when HDD is reading/writing.
Tx/Rx Blinks green when network connection is functioning normally.
Control Buttons
DIRECTION
In menu mode, the direction buttons are used to navigate between dierent elds and items and select setting
parameters.
In playback mode, the Up and Down buttons are used to speed up and slow down record playing, and the Left and
Right buttons are used to move the recording 30s forwards or backwards.
In the image setting interface, the up and down button can adjust the level bar of the image parameters.
In live view mode, these buttons can be used to switch channels.
ENTER
The Enter button is used to conrm selection in menu mode; or used to check checkbox elds and ON/OFF switch.
In playback mode, it can be used to play or pause the video.
In single-frame play mode, pressing the Enter button will play the video by a single frame.
In auto sequence view mode, the buttons can be used to pause or resume auto sequence.
Composite Keys
SHIFT Switch between the numeric or letter input and functions of the composite keys. (Input letter or numbers when the
light is out; Realize functions when the light is red.)
1/MENU Enter numeral “1”;
Access the main menu interface.
2/ABC/F1
Enter numeral “2”;
Enter letters “ABC”;
The F1 button when used in a list eld will select all items in the list.
3/DEF/F2
Enter numeral “3”;
Enter letters “DEF”;
The F2 button is used to change the tab pages.
In PTZ control mode, it zooms in the image.
Composite Keys
(cont.) 4/GHI/ESC
Enter numeral “4”;
Enter letters “GHI”;
Exit and back to the previous menu.
SECTION 1: SYSTEM OVERVIEW

5
ALI-NVR5000P Embedded NVR User Manual
SECTION 1: SYSTEM OVERVIEW
Name Function / Description
Composite Keys
(cont.)
5/JKL/EDIT
Enter numeral “5”;
Enter letters “JKL”;
Delete characters before cursor;
Check the checkbox and select the ON/OFF switch;
Start/stop record clipping in playback.
6/MNO/PLAY
Enter numeral “6”;
Enter letters “MNO”;
Playback, for direct access to playback interface.
7/PQRS/REC
Enter numeral “7”;
Enter letters “PQRS”;
Open the manual record interface.
8/TUV/PTZ
Enter numeral “8”;
Enter letters “TUV”;
Access PTZ control interface.
9/WXYZ/
PREV
Enter numeral “9”;
Enter letters “WXYZ”;
Multi-channel display in live view.
0/A
Enter numeral “0”, or letter “A”
Shift the input methods in the editing text eld. (Upper and lowercase, alphabet, symbols or numeric input).
Press the button twice to switch the main and auxiliary output.
JOG SHUTTLE Control
Move the active selection in a menu. It will move the selection up and down.
In Live View mode, it can be used to cycle through dierent channels.
In the Playback mode, it can be used to jump 30s forward/backward in video les.
In PTZ control mode, it can control the movement of the PTZ camera.
POWER ON/OFF Power on/o switch.
USB Interfaces Universal Serial Bus (USB) ports for additional USB devices such as a mouse or Hard Disk Drive (HDD).
NVR Backpanel (ALI-NVR5016P and ALI-NVR5032P).
Internal Ethernet switch ports LAN
RS-485, Alarms IN / OUT Power connector
Fan outlet ON / OFF switch
Video Out (CVBS, VGA, HDMI)
Audio OUT Ground
RS-232
eSATA
USB
Item Description
eSATA Connects external SATA HDD, CD/DVD-RW.
RS-232 Interface DB9 (male) connector for RS-232 devices

6
Item Description
VIDEO OUT
(CVBS, VGA, HDMI)
CVBS - BNC connector for video output
VGA - DB15 connector for VGA compatible monitor. Supports 1920 × 1080p @ 60 Hz, 1600 × 1200 @ 60 Hz,
1280 × 1024 @ 60 Hz, 1280 × 720 @ 60 Hz/, 1024 × 768 @ 60 Hz
HDMI - HDMI connector for an HDMI compatible monitor. Supports 1920 × 1080p @ 60 Hz, 1600 × 1200 @ 60 Hz,
1280 × 1024 @ 60 Hz, 1280 × 720 @ 60 Hz/, 1024 × 768 @ 60 Hz
LINE IN BNC connector for audio input.
RS-485, ALARMS IN/OUT See below, next topic
AC 100V ~ 240V AC 100V ~ 240V power supply.
ON / OFF Switch Switch for powering the device on or o.
GROUND Terminal for ground. Connect to earth ground before powering on the NVR.
LAN Interface 10/100/1000BASE-T Ethernet network interface
USB interface Universal Serial Bus (USB) ports for additional devices such as USB mouse and USB Hard Disk Drive (HDD).
AUDIO OUT CVBS AUDIO OUT - BNC connector for audio output. This connector is synchronized with CVBS video output
VGA AUDIO OUT - BNC connector for audio output. This connector is synchronized with VGA video output
Internal Ethernet switch
ports 16 ports for IP cameras. These ports provide Power over Ethernet (PoE) to the cameras.
RS-485, ALARMS IN/OUT
Item Description
SW ON
RS-485 termination switch:
Up position is not terminated.
Down position is terminated with 120 Ω resister.
RS-485 (T+, T-, R+. R-) T+ and T- pins connect to R+ and R- pins of PTZ receiver respectively.
KB
Controller port:
D+, D- pin connects to Ta, Tb pin of controller.
For cascading devices, the rst NVR’s D+, D- pin should be connected with the D+, D- pin of the next NVR
ALARM IN (1 through 16) Alarm inputs 1 - 16. Alarm input is tied to ground through the alarm sensor. See “2.3.1 Wiring alarm inputs to the NVR” on page
12 for more information.
ALARM OUT
(1-G through 4-G) Alarm outputs 1 - 4 with ground terminations. See “2.3.2 Wiring alarm outputs to the NVR” on page 12 for more information.
SECTION 1: SYSTEM OVERVIEW

7
ALI-NVR5000P Embedded NVR User Manual
SECTION 1: SYSTEM OVERVIEW
1.1.1 Remotecontrol
The enter key on the remote control or the front panel has the same function as a mouse left click. The IR Range of the remote
control is 10 meters. The buttons on the remote control correspond with the buttons on the front panel.
23
18
9
17
7 5
6 4
11141518 16
1213 10
Item Name Function
1POWER Power on/o the device.
2DEV Enables/Disables Remote Control.
3Alphanumeric Buttons Use for entering numerical data
4EDIT Button Delete characters before cursor, check the checkbox and select the ON/OFF switch, start/stop record
clipping in playback
5 A Button Adjust focus in the PTZ Control menu, also used to switch between input methods (upper and lowercase
alphabet, symbols and numeric input).
6REC Button Open the manual record interface
7PLAY Button Playback, for direct access to playback interface.
8 INFO Button Reserved.
9VOIP/MON button Switch between main and spot output. In PTZ Control mode, it is used to zoom out the image.
10 MENU button
Press the button will help you return to the Main menu (after successful login).
Press and hold the button for 5 seconds to turn o audible key beep.
In PTZ Control mode, the MENU/WIPER button will start wiper (if applicable).
11 PREV button Switch between single screen and multi-screen mode.
In PTZ Control mode, it is used to adjust the focus in conjunction with the A/FOCUS+ button.
12 DIRECTION/ENTER buttons
DIRECTION: These buttons are used to navigate between dierent elds and items in menus.
In the Playback mode, the Up and Down buttons are used to speed up and slow down recorded video. The
Left and Right button select the next and previous record les.
In Live View mode, these buttons can be used to cycle through channels.
In PTZ control mode, they can control the movement of the PTZ camera.
ENTER: The ENTER button is used to conrm selection in any of the menu modes.
It can also be used to tick checkbox elds.
In Playback mode, it can be used to play or pause the video.
In single-frame Playback mode, pressing the button will advance the video by a single frame.
In Auto-switch mode, it can be used to stop /start auto switch.

8
Item Name Function
13 PTZ button Enter the PTZ Control mode (if applicable).
In the PTZ Control mode, it is used to adjust the iris of the PTZ camera.
14 ESC button Return to the previous menu.
Press for Arming/disarming the device in Live View mode.
15 RESERVED Reserved for future usage.
16 F1 button
Select all items on the list when used in a list eld.
In PTZ Control mode, it will turn on/o PTZ light (if applicable).
In Playback mode, it is used to switch between play and reverse play.
17 PTZ Control buttons Buttons to adjust the iris, focus and zoom of a PTZ camera.
18 F2 button Cycle through tab pages.
In synchronous playback mode, use to switch between channels.
1.1.2 Mousecontrol
A standard 3-button (left/right/scroll-wheel) USB mouse can also be used with this NVR. To use a USB mouse:
1. Plug USB mouse into the either a front panel or backpanel USB connector of the NVR.
2. The mouse will be automatically detected. If the mouse is not detected, the mouse may not be compatible with the NVR.
Please refer to the recommended device list from your provider.
The operation of the mouse:
Action Eect
Right click Live view: Show menu.
Menu: Exit current menu to upper level menu.
Left click
Single click: Live view: Select channel and show the quick set menu.
Menu: Select and enter.
Double click: Live view: Switch between single-screen and multi-screen.
Click and drag: PTZ control: pan, tilt and zoom.
Tamper-proof, privacy mask and motion detection: Select target area.
Digital zoom-in: Drag and select target area.
Live view: Drag channel/time bar
Scroll wheel
Scroll up: Live view: Previous screen.
Menu: Previous item.
Scroll down: Live view: Next screen.
Menu: Next item.
SECTION 1: SYSTEM OVERVIEW

9
ALI-NVR5000P Embedded NVR User Manual
SECTION 1: SYSTEM OVERVIEW
1.1.3 Softkeyboard
One of two on-screen keyboards appears when you click in a eld that accepts a entry, such as a password or name or a numerical
value. A third keyboard which includes symbols can also be opened while in the numeric keyboard. The alphanumeric keyboard
is shown in the following picture. Some control keys toggle their function when they are clicked. A numerical keyboard, shown
beneath, appears for numerical entries such as an IP address.
Uppercase /
Lowercase Backspace
Switch to
numeric Enter
Soft keyboard - alphanumeric
Switch to
symbols Backspace
Switch to
alphanumeric Enter
Soft keyboard - numeric
Switch to
alphanumeric Backspace
Switch to
numeric Enter
Soft keyboard - symbols

10
SECTION2
Installing the System
2.1 Getting Started: Unpacking the Equipment
What’s in the box
Your system includes:
• ALI-NVR5000P series NVR
• Remote Control
• USB mouse
• 6 foot Ethernet cable
• 6 foot HDMI cable
• Power cable for NVR
• SATA and power HDD interface cables additional for internal hard disk drives
Remove the equipment from its packaging and place it on a at, clean surface. Inspect each item. If any visible damage is present,
contact your supplier for a replacement. Verify that your order is complete.
What you need
Although each security system installation is dierent, most require the following items not included with your system
components:
• VGA or HDMI compatible computer monitor
• IP cameras and cables compatible with the NVR
• Tools to install the cameras and route power and video cables
• Fasteners to attach the cameras to the mounting surfaces
• A display device to connect to the NVR. The NVR will connect directly to a VGA video monitor or an HDMI monitor (HDMI cable
is provided). The display device is usually needed only for system setup. It can be disconnected when the NVR is networked for
access across a LAN or Internet.
• Uninterruptible power supply (UPS). This device is used to ensure system stability during voltage surges, sags, and outages. If a
UPS is not available, a power strip with strong surge protection is highly recommended.
SECTION 2: INSTALLING THE SYSTEM

11
ALI-NVR5000P Embedded NVR User Manual
2.2 NVR installation general guidelines
2.2.1 InstallinganHDDintheNVR
If you purchased your NVR without an internal HDD, you must install one for the NVR to function properly. Follow the procedure In
“APPENDIX C HDD Installation” on page 122. If your HDD has an HDD, skip this procedure and continue installing the system with
step “2.2.2 NVR Placement” on page 11.
2.2.2 NVRPlacement
Your monitoring and recording equipment is the core device for constant surveillance and the reliable capture of video evidence.
Observint Technologies strongly suggest that it be installed in a secure location with access limited to authorized personnel.
NVRs and monitors generate heat and should be placed in a clean and well ventilated area. A high temperature environment will
reduce the life span and reliability of the equipment. Additionally, the NVR is not weatherproof, so avoid exposure to liquids and
excessive dust. Do not place objects along the sides or behind the NVR that will block airow through the unit.
Uninterruptible power supplies
It is strongly suggested that power to the system be routed through an uninterruptible power supply (UPS). These devices will keep
your security system running through most power outages, in addition to providing excellent surge and sag protection. The UPS
should support the NVR and all cameras to ensure normal operation during abnormal power conditions.
Proximity to other cameras and the local LAN
Your NVR connect to other devices through Ethernet networks. The NVR contains two network interfaces: one to a local area
network (LAN) through the LAN connector on the back panel, and the other directly to IP cameras plugged into the POE 1 - 16
connectors.
POE 1 - 16 (camera channels) LAN
RS-485, Alarms IN / OUT Power connector
Fan outlet ON / OFF switch
Monitor Out (HDMI, VGA, CVBS)
Audio OUT Ground
eSata
USB
The IP cameras you monitor with your NVR can be connected to either the Ethernet connectors on the back panel or the local LAN.
However, the number of cameras the NVR monitors on the LAN plus the number of those it monitors through the camera channel
connectors on the back panel cannot exceed the channel capacity of your NVR.
SECTION 2: INSTALLING THE SYSTEM

12
If you are using Cat 5e or Cat 6 copper (Ethernet) cable to connect your cameras to the NVR, or other cameras to the LAN, the cable
distance from the NVR (or switch on the LAN) should not exceed 330 feet (100 meters). If a longer cable run is required, the use of
an active hardware device such as a repeater or switch is necessary.
Place the NVR in a location that is secure, well ventilated and clean. The NVR should be positioned such that the back panel
connectors are accessible and the ventilation holes on the sides and top and the fan outlet on the back are not blocked.
2.3 Connecting alarm devices to the NVR
2.3.1 WiringalarminputstotheNVR
You can wire up to 16 alarm inputs to the NVR. Alarm input wiring connects to the RS-485, Alarm IN/OUT connector blocks on the
back of the NVR.
Sensor
– +
Typical ALARM IN wiring
2.3.2 WiringalarmoutputstotheNVR
The NVR provides 4 alarm output terminations. These terminations for each output are on the ALARM OUT connector block on the
back of the NVR , and are labeled 1 - G, 2 - G, 3 - G, 4 - G (G = ground termination).
There are 4 jumpers (JP1, JP2, JP3, and JP4) inside the chassis on the alarm termination PC board, associated with ALARM OUT
pins 1, 2, 3 and 4 respectively. Initially, these jumpers are in place. If connecting an alarm output to a DC loaded alarm out circuit,
the jumper must be in place. If connecting the alarm output to an AC loaded alarm, the corresponding jumper must be removed.
Example: If you connect an AC load to the alarm output 3 of the NVR, then you must remove the JP 3.
To remove a jumper for AC load alarm circuits:
1. Disconnect all cabling from the NVR.
SECTION 2: INSTALLING THE SYSTEM
