Allen-Bradley 140G-M-NVM Series User manual

Bul. 140G/140MG
140G-M-RMX, 140G-M-NVM_, 140G-M-RVM_, 140G-N7, 140G-N8
PN-258433
DIR 1000479R0612 (Version 01)
Installation - Installazione - Instalación
Instalação - -
WARNING: To prevent electrical shock, disconnect from power source before
installing or servicing. Install in suitable enclosure. Keep free from contaminants.
(Follow NFPA70E requirements).
AVVERTENZA: Per prevenire infortuni, togliere tensione prima dell'installazione o
manutenzione. Installare in custodia idonea. Tenere lontano da contaminanti.
(Seguire i requisiti NFPA70E).
WARNUNG: Vor Installations- oder Servicearbeiten Stromversorgung zur
Vermeidung von elektrischen Unfällen trennen. Die Geräte müssen in einem
passenden Gehäuse eingebaut und gegen Verschmutzung geschützt werden.
(Befolgen Sie die Anforderungen nach NFPA70E).
AVERTISSEMENT: Avant le montage et la mise en service, couper l'alimentation
secteur pour éviter toute décharge. Prévoir une mise en coffret ou armoire
appropriée. Protéger le produit contre les environnements agressifs. (Vous devez
respecter la norme NFPA70E).
ADVERTENCIA: Desconéctese de la corriente eléctrica, antes de la instalación o
del servicio, a fin de impedir sacudidas eléctricas. Instálelo en una caja apropiada.
Manténgalo libre de contaminantes. (Cumpla con los requisitos NFPA70E).
ATENÇÃO: Para evitar choques, desconectar da corrente elétrica antes de fazer a
instalação ou a manutenção. Instalar em caixa apropriada. Manter livre de
contaminantes. (Cumpra as exigências da norma NFPA70E).
Rotary operating mechanism with: external handle or external handle with internal NFPA 79 operating handle
(4) M4 - 35 mm (4) M4 - 35 mm
Bushing
Cotter
Pin
Bushing
Cotter
Pin
CLACK
Cat No.
140G-M-RMX
Cat No.
140G-M-RMX
Cat No.
140U-HM4
140U-HM4E
Cat No.
194R-R7
194R-R8
Cat No.
140U-HM4
140U-HM4E
Cat No.
140G-N7
140G-N8
Cat No.
140G-M-OSB (2) M4 - 40 mm

PN-258433
DIR 1000479R0612 (Version 01) (2)
2
4
1
2
4
3
3
1
C
mm
(in.)
C
MIN MAX
2
1 1
229
(9)
679.4
(26 - 3/4)
229
(9)
533
(21)
305
(12)
450.8
(17 - 3/4)
C
35
(1 - 3/8)
C
-
127
(5)
Cat
194R-R7
194R-R8
3
(1/8)
Ø 3
(Ø 1/8)
35
(1 - 3/8)
3
(1/8)
Ø 3
(Ø 1/8)
3
Cat
140G-N7
140G-N8
C
MIN MAX
280
(11)
679.4
(26 - 3/4)
280
(11)
533
(21)
305
(12)
450.8
(17 - 3/4)
2
mm
(in.)
3
C
-
127
(5)
1
2

PN-258433
DIR 1000479R0612 (Version 01) (3)
5
6
5
6
77
88
2
9.7 lb-in
(1.1 Nm)
9.7 lb-in
(1.1 Nm)
9.7 lb-in
(1.1 Nm)
9.7 lb-in
(1.1 Nm)

PN-258433
DIR 1000479R0612 (Version 01)
1
22
33
(4)
3
1
or or
1
2
3
1
2
3
4
12.4 lb-in
(1.4 Nm)
12.4 lb-in
(1.4 Nm)
12.4 lb-in
(1.4 Nm)
12.4 lb-in
(1.4 Nm)

PN-258433
DIR 1000479R0612 (Version 01) (5)
12
40053-308-01 (4)
Printed in U.S.A.
BULLETIN 190/194R/140U
DRILLING TEMPLATE
GABARIT DE PERFORATION
BOHRSCHABLONE
PLANTILLA DE PERFORACIÓN
MODELO DE PERFORAÇÃO
STAMPO PREFORATO
-HM1
-HM1E
-HM4
-HM4E
190/194R 194R 140U
4 - ø 5.5 mm
4 - 7/32 " DIA.
ø 65 mm
2-9/16 " DIA.
-HM1-N1
-HM1E-N1
-HM4-N1
-HM4E-N1
-HM1-N2
-HM1E-N2
-HM4-N2
-HM4E-N2
-HM1-N3
-HM1E-N3
-HM4-N3
-HM4E-N3
-HM4E
-HM4
40053-308-01 (4)
Printed in U.S.A.
BULLETIN 190/194R/140U
DRILLING TEMPLATE
GABARIT DE PERFORATION
BOHRSCHABLONE
PLANTILLA DE PERFORACIÓN
MODELO DE PERFORAÇÃO
STAMPO PREFORATO
-HM1
-HM1E
-HM4
-HM4E
190/194R 194R 140U
4 - ø 5.5 mm
4 - 7/32 " DIA.
ø 65 mm
2-9/16 " DIA.
-HM1-N1
-HM1E-N1
-HM4-N1
-HM4E-N1
-HM1-N2
-HM1E-N2
-HM4-N2
-HM4E-N2
-HM1-N3
-HM1E-N3
-HM4-N3
-HM4E-N3
-HM4E
-HM4
TAPE
75
(2 - 61/64)
75
(2 - 61/64)
37.5
(1 - 15/32) 37.5
(1 - 15/32)
Front of Cover
Partie frontale du panneau
Vorderseite des deckels
Frente de la tapa
Frente da tampa
Parte frontale del panello
(4) - ø 5.5
( (4) - ø 7/32)
ø 65
(ø 2 - 9/16)
mm
(in.)
44
33
5
2.8 Nm
(25 lb-in)
2.8 Nm
(25 lb-in)
1.2 - 4.8
(3/64 - 3/16)

PN-258433
DIR 1000479R0612 (Version 01) - (L8716)
Copyright © 2014 Rockwell Automation, Inc. All Rights Reserved. Printed in USA.
Publication 140G-IN030B-MU-P - April 2014
Allen-Bradley, Rockwell Software, and Rockwell Automation are trademarks of Rockwell Automation, Inc.
Trademarks not belonging to Rockwell Automation are property of their respective companies.
Rockwell Automation maintains current product environmental information on its website at http://www.rockwellautomation.com/rockwellautomation/about-us/sustainability-ethics/product-environmental-compliance.page.
6 mm
(.24 in) Max
6 mm
(.24 in) Max
