Allen-Bradley 1203-GD2 User manual

User Manual
Bulletin 1203
Serial Communications Module
RS232/422/485 (Using DF1 Protocol)
Catalog Number 1203-GD2, -GK2, -GM2

Important User Information Because of the variety of uses for this equipment and because of the
differences between this solid-state equipment and electromechanical
equipment, the user of and those responsible for applying this equipment
must satisfy themselves as to the acceptability of each application and use
of the equipment. In no event will Allen-Bradley Company be responsible
or liable for indirect or consequential damages resulting from the use or
application of this equipment.
The illustrations shown in this manual are intended solely to illustrate the
text of this manual. Because of the many variables and requirements
associated with any particular installation, the Allen-Bradley Company
cannot assume responsibility or liability for actual use based upon the
illustrative uses and applications.
No patent liability is assumed by Allen-Bradley Company with respect to
use of information, circuits or equipment described in this text.
Reproduction of the content of this manual, in whole or in part, without
written permission of the Allen-Bradley Company is prohibited.
This information in this manual is organized in numbered chapters. Read
each chapter in sequence and perform procedures when you are instructed
to do so. Do not proceed to the next chapter until you have completed all
procedures.
!ATTENTION: Identifies information about practices or
circumstances that can lead to personal injury or death, property
damage or economic loss.
Attentions help you:
•identify a hazard
•avoid the hazard
•recognize the consequences
IMPORTANT: Identifies information that is especially important for
successful application and understanding of the product.

Summary of Changes
Summary Information These changes have been made since any preliminary photocopy
documents were issued:
Chapter 1 A trademark symbol has been added to 1336 PLUS on page 1-1.
Chapter 2 •The word “board” has been changed to “module” in the last sentence of
paragraph four on page 2-1.
•The word “Default” has been added to the description of SW3.7, SW3.8
in, and DH-485 has been removed from, Figure 2.1 on page 2-2.
•The SLC 5/03 illustration in Figure 2.3 on page 2-4 has been reduced 50
percent.
Chapter 3 •The note on page 3-9 has been replaced with a new note.
•The Figure 3.2 heading on page 3-11 has been changed to include 1336
PLUS.
•The 9-pin D-shell in Figure 3.6 on page 3-14 has been changed to match
the same in Figure 3.5.
•The range (7.5 – 500HP) has been removed from the first heading on
page 3-17.
Chapter 5 •Three new tables have replaced Table 5.B on page 5-3.
•The first paragraph on page 5-4 has been changed to accommodate the
three new tables preceding this text.
•A sentence has been added to the end of Item 3, Parameter Read Full, on
page 5-4.
•The Item 8 heading, System File, on page 5–5, has been changed to
System Area.
Chapter 6 •The Figure 5.1 heading on page 6-1 has been changed to Figure 6-1, and
the figure reference in the first paragraph has changed likewise.
•The Table 5.C heading on page 6-2 has changed to Table 6.A.
Notes A Notes section has been added to the end of this document.

Summary of Changes
This Page Intentionally Left Blank

Table of Contents
i
Introduction Chapter 1
Manual Objectives 1-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Who Should Use This Manual 1-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Vocabulary 1-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Firmware Support 1-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Manual Organization 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety Precautions 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Serial Device Compatibility 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Product Description Chapter 2
Chapter Objectives 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Module Description 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SCANport Device Compatibility 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Configuration Switches 2-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation Chapter 3
Chapter Objectives 3-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Setting Module Configuration Switches 3-1. . . . . . . . . . . . . . . . . . . . . . .
Factory Switch Settings 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Switch SW1 3-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Switch SW2 3-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Switch SW3 3-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Mounting the Communications Module 3-10. . . . . . . . . . . . . . . . . . . . . . .
Enclosed Style Communications Module Dimensions 3-12. . . . . . . . . . . .
Cable Connections 3-13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
RS485/RS422/RS232 Connection Examples 3-13. . . . . . . . . . . . . . .
SCANport Link Connection 3-16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cable Requirements 3-16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1305 Drive 3-16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1336 PLUS and 1336 FORCE 3-17. . . . . . . . . . . . . . . . . . . . . . . . . . .
SMP 3 3-17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power Supply Connections 3-18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SCANport Datalink Operation Chapter 4
Chapter Objectives 4-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SCANport Datalinks. 4-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table of Contents
ii
Configuration and Interfacing Chapter 5
Chapter Objectives 5-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Basic Operation 5-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Communications Module Data Table Structure and Supported
PCCC Command List 5-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Configuration Examples 5-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DF1 Messaging with a PLC-5/80 Example
(Read Parameters 1 through 50) 5-8. . . . . . . . . . . . . . . . . . . . . . . . .
DF1 Messaging with a 1746-BAS Module Example
(Write 10 Parameters then read 10 parameters) 5-10. . . . . . . . . . . . . .
Troubleshooting Chapter 6
Chapter Objectives 6-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Specifications Chapter 7
Chapter Objectives 7-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Product Specifications 7-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Module Compatibility 7-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PLC, PLC-2, PLC-3, and PLC-5 are registered trademarks of
Allen-Bradley Company, Inc.
SMC, PLC-2/30, PLC-5/10, PLC-5/15, PLC-5/25, PLC-5/30, PLC-5/40,
PLC-5/40L, PLC-5/60L, PLC-5/80, and PLC-5/250 are trademarks of
Allen-Bradley Company, Inc.
SCANport is a registered trademark of Allen-Bradley Company, Inc.
SLC 500, SLC-5/02, and SLC-5/03 are registered trademarks of
Allen-Bradley Company, Inc.

1
Chapter
1-1
Introduction
Manual Objectives The purpose of this manual is to provide you with the necessary
information to apply the Serial Communications Module which is available
for products that include the SCANporttcommunications port. Described
in this manual are methods for installing, configuring, and troubleshooting
the Serial Communications Module.
For information on specific features of Allen-Bradley products mentioned
herein, refer to the product user manual.
IMPORTANT: This manual should be read in its entirety before installing,
operating, servicing, or initializing the Serial Communications Module.
Who Should Use This Manual This manual is intended for qualified service personnel responsible for
setting up and servicing of these devices. You must have previous
experience with and a basic understanding of communications terminology,
configuration procedures, required equipment, and safety precautions.
To make efficient use of this Communications Module, you must be able to
program and operate serial communications devices, as well as have a
basic understanding of the parameter settings and functions of the device to
which you are communicating.
Vocabulary In this manual we refer to the:
SSerial Communications Module as “Communications Module.”
SVariable Frequency AC Drive (Bulletin 1305, 1336 FORCE, or
1336 PLUS) as the “Drive” or “SCANport device”.
SProgrammable Logic Controller as the “Programmable Controller” or
“PLC”.
SEarth Ground as “GND”.
Firmware Support This manual supports communications module firmware versions 1.xx (the
“xx” designator may vary). Features that work with specific firmware
versions will be denoted as such.

Chapter 1
Introduction
1-2
Manual Organization This manual is divided into chapters as detailed in Table 1.A.
Table 1.A
Manual Organization and Topics
Chapter Title Topics Covered Related Tasks
1 Introduction Manual objectives, audience, vocabulary,
firmware support information, manual
organization, safety precautions, and serial
device compatibility
2Product Description Communications Module features,
configuration, and diagnostics
3 Installation Mounting, power connections, switch
configuration, cabling, and hardware
4SCANport Datalink Operation Configuring SCANport device Datalinks,
Datalink operation
5Configuration and Interfacing Addressing, information transfer, and sample
programs
6 Troubleshooting LED indications and fault descriptions
7 Specifications Environmental, electrical, and communications
specifications
Safety Precautions
ATTENTION: Only personnel familiar with SCANport devices
and associated machinery should plan or implement the
installation, start-up, configuration, and subsequent maintenance of
the serial communications module. Failure to comply may result in
personal injury and/or equipment damage.
ATTENTION: This Module contains ESD (Electrostatic
Discharge) sensitive parts and assemblies. Static control
precautions are required when installing, testing, servicing, or
repairing this assembly. Component damage may result if ESD
control procedures are not followed. If you are not familiar with
static control procedures, reference Allen-Bradley Publication
8000–4.5.2, Guarding Against Electrostatic Damage or any other
applicable ESD protection handbook.

Chapter 1
Component Test Procedures
1-3
Serial Device Compatibility This Communications Module is intended for use with devices that
communicate via the following protocols:
Hardware Standard Communications Protocol
RS232 DF1
RS422 DF1
RS485 DF1
IMPORTANT: “DF1” protocol is typically used with Allen-Bradley
PLCprogrammable controllers.

Chapter 1
Introduction
1-4
This Page Intentionally Left Blank.

2
Chapter
2-1
Product Description
Chapter Objectives In this chapter, you will read about:
Communications Module features
Location of configuration switches
Module Description The Serial Communications Module is an optional interface device
designed to provide a direct, digital link between serial communications
devices and any device that uses SCANport. The current list of products
that use SCANport includes: 1305, 1336 PLUS, 1336 FORCE, and SMP3
controllers. The module connects to these products through the SCANport
port.
The Communications Module is available in both Open style (Figure 2.1)
and Enclosed (Figure 2.2) type configurations. The Open style module
mounts inside certain drives, depending on drive size (see Table 2.A for
details). The Enclosed module mounts independently and can be used with
any compatible SCANport device.
Table 2.A
Serial Device Configurations
Designation Enclosure Power Supply Source Used With:
Open Style Open PC Board Supplied by Drive 1336 PLUS*
1336 FORCE**
Enclosed IP30 24V DC separately supplied or
120/240V AC separately supplied
1305
1336 PLUS
1336 FORCE
SMP3
Other SCANport products
* 7.5HP and higher sizes only
** 7.5HP and higher sizes with Standard Adapter board only

Chapter 2
Product Description
2-2
SCANport Device Compatibility The SCANport Serial Communications Module is compatible with the
following Allen-Bradley devices:
Device Firmware Revision
1336 PLUS All
1336 FORCE All
1305 MicroDrive 2.0 or newer
SMC
SMP
Figure 2.1
Open Style Communications Module
TX (ADAPTER TRANSMIT)
SERIAL STATUS
1. LED Off: Adapter Power Removed
2. LED Flashing Green: Link OK, Off Line
3. LED Solid Green: Link OK, On Line
4. LED Solid Red: Fault
SCANport STATUS
1. LED Off: Adapter Power Removed
2. LED Flashing Green: Link OK, Not Connected
3. LED Solid Green: Link OK, Connected
4. LED Solid Red: Fault
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
SW1
SW2
SW3
LED Indicators
J4
J2
9-Pin D-Shell
SW1.1 – SW1.2 = Serial Mode Select
SW1.3 – SW1.8 = Adapter Address
SW2.1 – SW2.3 = Baud Rate Selection
SW2.4 = Parity Enable
SW2.5 = Parity Sense (Even/Odd)
SW2.6 = Stop Bits
SW2.7 = Point-to-Point/Multi-Drop
SW2.8 = CRC/BCC Check
SW3.1 = Logic Command/Status and
Reference/Feedback
SW3.2 = Datalink A Settings
SW3.3 = Datalink B Settings
SW3.4 = Datalink C Settings
SW3.5 = Datalink D Settings
SW3.6 = Duplicate Message Detection
SW3.7, SW3.8 = Application Timeout
Default Value
AB0394C
Serial
Communications
Module
(DF1 Protocol)
RS-485
RX (ADAPTER RECEIVE)

Chapter 2
Product Description
2-3
Figure 2.2
Enclosed Style Serial-to-SCANport Communications Module
Power
Connection
SCANport
Connector
Diagnostic
LEDS
RX
SCANport Status
Serial Status
TX
Serial Channel
D-Shell Connector
AB0395C
BOTTOM VIEW AB0415B
SW1SW2SW3818181
O
I
Switch SW3
– Logic Command/Status and
Reference/Feedback
– Datalink A, B, C, D Settings
– Application Timeout
Default Value
– Duplicate Message Detection
Switch SW1
– Serial Mode Select
– Adapter Address
Switch SW2
– Baud Rate Selection
– Parity Enable
– Parity Sense (Even/Odd)
– Stop Bits
– Point-to-Point/Multi-Drop
– CRC/BCC Check
O
I

Chapter 2
Product Description
2-4
Figure 2.3
Typical Serial Communications/SCANport Device Interconnect
IBM PC
PLC
.
.
.
Communication
Module
1336
PLUS
Open Style
Comm
Module
1305*
Micro
Drive
SMP 3
Communication
Module
SLC 5/03
Serial Port
SCANport
SCANport
Other Serial
Devices
.
.
.
AB0396C
Serial Comm Link

Chapter 2
Product Description
2-5
Configuration Switches The Serial Communications Module contains three DIP Switches: SW1,
SW2, and SW3 (Figure 2.1 and Figure 2.2). Switches are set ON or OFF as
detailed in Figure 2.4. For a detailed explanation of switch configuration,
refer to Chapter 3.
Figure 2.4
ConfigurationSwitches
Side View of Typical
Switches Switch Designation as shown in this manual
Rocker Switch
Open
Open
Open (Off)
Close (On)
Side Switch
Open
Open
Off
On
AB0397A

Chapter 2
Product Description
2-6
This Page Intentionally Left Blank.

3
Chapter
3-1
Installation
Chapter Objectives In this chapter you will learn how to:
Mount the Communications Module
Configure the Communications Module
Connect power
Connect SCANport and serial communications cables
Read this chapter completely before you attempt to install or configure
your Communications Module. Double check all connections and option
selections before you apply power.
IMPORTANT: Switch selections take effect only on power-up. If
selections are changed after power is applied, cycle the power to use the
new settings.
Setting Module This publication describes switches as being either on or off. If the switch
Configuration Switches assembly has the word OPEN printed on it, the word OPEN corresponds to
OFF (0).
When making configuration changes to the Communications Module, use
the addressing conventions of the PLC/SLC processor or serial device
through which you are communicating. In all cases, each serial device must
have a unique address the target processor can recognize.
ATTENTION: When you make changes to the switch settings, use
a blunt, pointed instrument such as a ball point pen. Do not use a
pencil because the lead (graphite) of the pencil may damage the
switch assembly.
ATTENTION: Failure to check connections and switch settings
for compatibility with you application when configuring the
communications module could result in personal injury and/or
equipment damage due to unintended or undesirable operation.
ATTENTION: It is recommended that when a system is
configured for the first time, that the motor be disconnected from
the machine or process during initial testing.

Chapter 3
Installation
3-2
Factory Switch Settings
Switch Setting Communication Mode
SW1-8 Off Module Address = 1
SW1-7 Off
SW1-6 Off
SW1-5 Off
SW1-4 Off
SW1-3 On
SW1-2 Off RS232 (DF1 Protocol)
SW1-1 Off
SW2-8 Off BCC Checksum
SW2-7 Off Point-to-Point
SW2-6 Off 1 Stop Bit
SW2-5 Off Parity Disabled
SW2-4 Off Even Parity (if enabled)
SW2-3 On 9600 Baud
SW2-2 On
SW2-1 Off
SW3-8 Off No Application Timeout (Disabled)
SW3-7 Off
SW3-6 On Duplicate Message Detection Enabled
SW3-5 Off Disable Datalink D
SW3-4 Off Disable Datalink C
SW3-3 Off Disable Datalink B
SW3-2 Off Disable Datalink A
SW3-1 Off Disable Logic Command/Status and
Reference/Feedback

Chapter 3
Installation
3-3
Switch SW1
Switch SW1 is used to select:
Serial communications mode (RS232/RS422/RS485)
Communications Module address
SW1
O
F
F
O
N87 65 43 21
Communications
Module Address Communications Mode Selection AB0398B
Table 3.A
Switch SW1 Settings for Communications Mode
Switch
Value
(Decimal) SW1-2 SW1-1 Communications Mode
0 Off Off RS232 (DF1 Protocol)
1 Off On RS422 (DF1 Protocol)
2 On Off RS485 (DF1 Protocol)
3 On On Not Used

Chapter 3
Installation
3-4
Table 3.B
Switch SW1 Settings for Serial Device Addressing
ÁÁÁÁ
Á
ÁÁ
Á
Á
ÁÁ
Á
ÁÁÁÁ
Module
Address
(Decimal)
ÁÁÁÁÁ
Á
ÁÁÁ
Á
Á
ÁÁÁ
Á
ÁÁÁÁÁ
Module
Address
(Octal)
ÁÁÁÁ
Á
ÁÁ
Á
Á
ÁÁ
Á
ÁÁÁÁ
SW1-8
ÁÁÁÁÁ
Á
ÁÁÁ
Á
Á
ÁÁÁ
Á
ÁÁÁÁÁ
SW1-7
ÁÁÁÁ
Á
ÁÁ
Á
Á
ÁÁ
Á
ÁÁÁÁ
SW1-6
ÁÁÁÁÁ
Á
ÁÁÁ
Á
Á
ÁÁÁ
Á
ÁÁÁÁÁ
SW1-5
ÁÁÁÁ
Á
ÁÁ
Á
Á
ÁÁ
Á
ÁÁÁÁ
SW1-4
ÁÁÁÁÁ
Á
ÁÁÁ
Á
Á
ÁÁÁ
Á
ÁÁÁÁÁ
SW1-3
ÁÁÁÁ
ÁÁÁÁ
0
ÁÁÁÁÁ
ÁÁÁÁÁ
0
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
1
ÁÁÁÁÁ
ÁÁÁÁÁ
1
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
On
ÁÁÁÁ
ÁÁÁÁ
2
ÁÁÁÁÁ
ÁÁÁÁÁ
2
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
On
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
3
ÁÁÁÁÁ
ÁÁÁÁÁ
3
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
On
ÁÁÁÁÁ
ÁÁÁÁÁ
On
ÁÁÁÁ
ÁÁÁÁ
4
ÁÁÁÁÁ
ÁÁÁÁÁ
4
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
On
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
5
ÁÁÁÁÁ
ÁÁÁÁÁ
5
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
On
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
On
ÁÁÁÁ
ÁÁÁÁ
6
ÁÁÁÁÁ
ÁÁÁÁÁ
6
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
On
ÁÁÁÁ
ÁÁÁÁ
On
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
7
ÁÁÁÁÁ
ÁÁÁÁÁ
7
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
On
ÁÁÁÁ
ÁÁÁÁ
On
ÁÁÁÁÁ
ÁÁÁÁÁ
On
ÁÁÁÁ
ÁÁÁÁ
8
ÁÁÁÁÁ
ÁÁÁÁÁ
10
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
On
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
9
ÁÁÁÁÁ
ÁÁÁÁÁ
11
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
On
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
On
ÁÁÁÁ
10
ÁÁÁÁÁ
12
ÁÁÁÁ
Off
ÁÁÁÁÁ
Off
ÁÁÁÁ
On
ÁÁÁÁÁ
Off
ÁÁÁÁ
On
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
11
ÁÁÁÁÁ
ÁÁÁÁÁ
13
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
On
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
On
ÁÁÁÁÁ
ÁÁÁÁÁ
On
ÁÁÁÁ
ÁÁÁÁ
12
ÁÁÁÁÁ
ÁÁÁÁÁ
14
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
On
ÁÁÁÁÁ
ÁÁÁÁÁ
On
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
13
ÁÁÁÁÁ
ÁÁÁÁÁ
15
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
On
ÁÁÁÁÁ
ÁÁÁÁÁ
On
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
On
ÁÁÁÁ
ÁÁÁÁ
14
ÁÁÁÁÁ
ÁÁÁÁÁ
16
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
On
ÁÁÁÁÁ
ÁÁÁÁÁ
On
ÁÁÁÁ
ÁÁÁÁ
On
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
15
ÁÁÁÁÁ
ÁÁÁÁÁ
17
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
On
ÁÁÁÁÁ
ÁÁÁÁÁ
On
ÁÁÁÁ
ÁÁÁÁ
On
ÁÁÁÁÁ
ÁÁÁÁÁ
On
ÁÁÁÁ
ÁÁÁÁ
16
ÁÁÁÁÁ
ÁÁÁÁÁ
20
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
On
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
17
ÁÁÁÁÁ
ÁÁÁÁÁ
21
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
On
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
On
ÁÁÁÁ
ÁÁÁÁ
18
ÁÁÁÁÁ
ÁÁÁÁÁ
22
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
On
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
On
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
19
ÁÁÁÁÁ
23
ÁÁÁÁ
Off
ÁÁÁÁÁ
On
ÁÁÁÁ
Off
ÁÁÁÁÁ
Off
ÁÁÁÁ
On
ÁÁÁÁÁ
On
ÁÁÁÁ
ÁÁÁÁ
20
ÁÁÁÁÁ
ÁÁÁÁÁ
24
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
On
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
On
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
21
ÁÁÁÁÁ
ÁÁÁÁÁ
25
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
On
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
On
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
On
ÁÁÁÁ
ÁÁÁÁ
22
ÁÁÁÁÁ
ÁÁÁÁÁ
26
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
On
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
On
ÁÁÁÁ
ÁÁÁÁ
On
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
23
ÁÁÁÁÁ
ÁÁÁÁÁ
27
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
On
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
On
ÁÁÁÁ
ÁÁÁÁ
On
ÁÁÁÁÁ
ÁÁÁÁÁ
On
ÁÁÁÁ
ÁÁÁÁ
24
ÁÁÁÁÁ
ÁÁÁÁÁ
30
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
On
ÁÁÁÁ
ÁÁÁÁ
On
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
25
ÁÁÁÁÁ
ÁÁÁÁÁ
31
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
On
ÁÁÁÁ
ÁÁÁÁ
On
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
On
ÁÁÁÁ
ÁÁÁÁ
26
ÁÁÁÁÁ
ÁÁÁÁÁ
32
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
On
ÁÁÁÁ
ÁÁÁÁ
On
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
On
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
27
ÁÁÁÁÁ
ÁÁÁÁÁ
33
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
On
ÁÁÁÁ
ÁÁÁÁ
On
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
On
ÁÁÁÁÁ
ÁÁÁÁÁ
On
ÁÁÁÁ
28
ÁÁÁÁÁ
34
ÁÁÁÁ
Off
ÁÁÁÁÁ
On
ÁÁÁÁ
On
ÁÁÁÁÁ
On
ÁÁÁÁ
Off
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
29
ÁÁÁÁÁ
ÁÁÁÁÁ
35
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
On
ÁÁÁÁ
ÁÁÁÁ
On
ÁÁÁÁÁ
ÁÁÁÁÁ
On
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
On
ÁÁÁÁ
ÁÁÁÁ
30
ÁÁÁÁÁ
ÁÁÁÁÁ
36
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
On
ÁÁÁÁ
ÁÁÁÁ
On
ÁÁÁÁÁ
ÁÁÁÁÁ
On
ÁÁÁÁ
ÁÁÁÁ
On
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
31
ÁÁÁÁÁ
ÁÁÁÁÁ
37
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
On
ÁÁÁÁ
ÁÁÁÁ
On
ÁÁÁÁÁ
ÁÁÁÁÁ
On
ÁÁÁÁ
ÁÁÁÁ
On
ÁÁÁÁÁ
ÁÁÁÁÁ
On
ÁÁÁÁ
ÁÁÁÁ
32
ÁÁÁÁÁ
ÁÁÁÁÁ
40
ÁÁÁÁ
ÁÁÁÁ
On
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
33
ÁÁÁÁÁ
ÁÁÁÁÁ
41
ÁÁÁÁ
ÁÁÁÁ
On
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
On
ÁÁÁÁ
ÁÁÁÁ
34
ÁÁÁÁÁ
ÁÁÁÁÁ
42
ÁÁÁÁ
ÁÁÁÁ
On
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
On
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
35
ÁÁÁÁÁ
ÁÁÁÁÁ
43
ÁÁÁÁ
ÁÁÁÁ
On
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
On
ÁÁÁÁÁ
ÁÁÁÁÁ
On
ÁÁÁÁ
ÁÁÁÁ
36
ÁÁÁÁÁ
ÁÁÁÁÁ
44
ÁÁÁÁ
ÁÁÁÁ
On
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
On
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
37
ÁÁÁÁÁ
45
ÁÁÁÁ
On
ÁÁÁÁÁ
Off
ÁÁÁÁ
Off
ÁÁÁÁÁ
On
ÁÁÁÁ
Off
ÁÁÁÁÁ
On
ÁÁÁÁ
ÁÁÁÁ
38
ÁÁÁÁÁ
ÁÁÁÁÁ
46
ÁÁÁÁ
ÁÁÁÁ
On
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
On
ÁÁÁÁ
ÁÁÁÁ
On
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
39
ÁÁÁÁÁ
ÁÁÁÁÁ
47
ÁÁÁÁ
ÁÁÁÁ
On
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
On
ÁÁÁÁ
ÁÁÁÁ
On
ÁÁÁÁÁ
ÁÁÁÁÁ
On
ÁÁÁÁ
ÁÁÁÁ
40
ÁÁÁÁÁ
ÁÁÁÁÁ
50
ÁÁÁÁ
ÁÁÁÁ
On
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
On
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
41
ÁÁÁÁÁ
ÁÁÁÁÁ
51
ÁÁÁÁ
ÁÁÁÁ
On
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
On
ÁÁÁÁÁ
ÁÁÁÁÁ
Off
ÁÁÁÁ
ÁÁÁÁ
Off
ÁÁÁÁÁ
ÁÁÁÁÁ
On
