Wiring Diagrams
1732E ArmorBlock Dual-Port EtherNet/IP
4-Point Analog Modules
Catalog Numbers 1732E-IF4M12R, 1732E-OF4M12R, 1732E-IT4IM12R,
1732E-IR4IM12R
Parts List
Your package contains one 1732E ArmorBlock™ module and these pinout guide
wiring instructions.
For complete installation instructions, refer to the Module Publication Number
table and visit http://rockwellautomation.com/literature.
Module Publication Number
Module Publication Number
1732E ArmorBlock Dual-Port EtherNet/IP 4-Point Analog Input
and Output Modules (1732E-IF4M12R, 1732E-OF4M12R) 1732E-IN006
1732E ArmorBlock Dual-Port EtherNet/IP 4-Point Thermocouple
and RTD Input Modules (1732E-IT4IM12R, 1732E-IR4IM12R) 1732E-IN005
ATTENTION: Two sets of mounting holes are used to mount the module
directly to a panel or machine. Mounting holes accommodate #6 (M3) pan
head screws. The torque specification is 0.68 Nm (6 lb-in.).
ATTENTION: To comply with the CE Low Voltage Directive (LVD), this
equipment and all connected I/O must be powered from a source compliant
with the following: Safety Extra Low Voltage (SELV) or Protected Extra Low
Voltage (PELV).
ATTENTION: To comply with UL restrictions, this equipment must be
powered from a source compliant with the following: Limited
Voltage/Limited Current.

21732E ArmorBlock Dual-Port EtherNet/IP 4-Point Analog Modules
Publication 1732E-WD003B-EN-P - July 2012
I/O Connectors Pinout Guide
Micro-style M12 5-Pin Input Female Connector – 1732E-IF4M12R
Micro-style M12 5-Pin Output Female Connector – 1732E-OF4M12R
Micro-style M12 5-Pin Input Female Connector – 1732E-IT4IM12R
D12 Micro-style 5-Pin Input Female Connector – 1732E-IR4IM12R
IMPORTANT
For information on supported sensors and sensor types for the
1732E-IT4IM12R module, see the Installation Instructions for
1732E Temperature Modules, publication 1732E-IN005.
3
4
1
2
5
(View into connector)
Pin 1 Current Input +
Pin 2 Current Common
Pin 3 Voltage Input +
Pin 4 Voltage Common
Pin 5 No Connect
45868
3
4
1
2
5
45868
(View into connector)
Pin 1 Current Output +
Pin 2 Current Common
Pin 3 Voltage Output +
Pin 4 Voltage Common
Pin 5 No Connect
3
4
1
2
5
(View into connector)
Pin 1 CJC +
Pin 2 TC +
Pin 3 CJC -
Pin 4 TC -
Pin 5 No Connect
45868
3
4
1
2
5
A
C
B
(View into connector)
Pin 1 No Connect
Pin 2 A
Pin 3 B
Pin 4 C
Pin 5 No Connect
45868 45869

1732E ArmorBlock Dual-Port EtherNet/IP 4-Point Analog Modules 3
Publication 1732E-WD003B-EN-P - July 2012
Ethernet Connector Pinout Guide
D-Code M12 Micro Network Female Connector
Power Connectors Pinout Guide
Micro-style 4-Pin Input Male Receptacle
Specifications
Attribute Value
Temperature, operating IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock):
-20…60 °C (-4…140 °F)
Temperature, ambient, max 60 °C (140 °F)
Voltage, power, min 12 V DC
Voltage, power, max 30V DC
Power consumption 3 W @ 24V DC, typical
3.5 W, max (module unloaded)
Enclosure type rating Meets IP65/66/67/69K (when marked)
(View into connector)
Pin 1 Tx+
Pin 2 Rx+
Pin 3 Tx-
Pin 4 Rx-
Pin 5 Shell
4
2
31
5
44808
1
4
3
2
3
4
1
2
45764
(View into receptacle)
Pin 1 Auxiliary power+
Pin 2 Module power+
Pin 3 Module power-
Pin 4 Auxiliary power-
45763
Male Input Female Output

Publication 1732E-WD003B-EN-P - July 2012 PN-169849
Copyright © 2012 Rockwell Automation, Inc. All rights reserved. Printed in the U.S.A.
Allen-Bradley, Rockwell Automation, ArmorBlock and TechConnect are trademarks of Rockwell Automation, Inc.
Trademarks not belonging to Rockwell Automation are property of their respective companies.
ATTENTION: This equipment is considered Group 1, Class A industrial
equipment according to IEC/CISPR 11. Without appropriate precautions,
there may be difficulties with electromagnetic compatibility in residential
and other environments due to conducted and radiated disturbance.
Certifications
Certification (when
product is marked)(1) Value
c-UR-us UL Recognized Component Industrial Control Equipment, certified
for US and Canada. See UL File E322657.
CE European Union 2004/108/EC EMC Directive, compliant with:
EN 61326-1; Meas./Control/Lab., Industrial Requirements
EN 61000-6-2; Industrial Immunity
EN 61000-6-4; Industrial Emissions
EN 61131-2; Programmable Controllers (Clause 8, Zone A & B)
C-Tick Australian Radiocommunications Act, compliant with:
AS/NZS CISPR 11; Industrial Emissions
EtherNet/IP ODVA conformance tested to EtherNet/IP specifications.
KC Korean Registration of Broadcasting and Communications
Equipment, compliant with:
Article 58-2 of Radio Waves Act, Clause 3
(1) See the Product Certification link at http://www.ab.com for Declarations of Conformity, Certificates,
and other certification details.
ATTENTION: The device meets UL Type 1 Enclosure rating.
ATTENTION: The device does not provide bonding or grounding terminal.
Customer shall provide own bonding or grounding.
